LG Electronics USA L1150 Dual-Band GSM Phone User Manual L1150 040401
LG Electronics USA Dual-Band GSM Phone L1150 040401
Users Manual
L1150
User Guide
Unpacking 8
For Your Safety 9
Your Phone 14
Phone Components 14
Your Phone’s Features 15
Display Information 17
Getting Started 19
Installing the SIM Card 19
Charging the Battery 22
Turning Your
Phone On and Off 24
Access Codes 25
Security code 25
Barring Password 25
General Functions 26
Making a Call 26
Making a Call by Send Key 26
Making International Calls 26
Ending a Call 26
Making a Call
From the Phonebook 27
Adjusting the Volume 27
Answering a Call 27
Manner Mode (Quick) 28
Signal Strength 28
Entering Text 28
Selecting
Functions and Options 33
Phonebook 34
In-Call Menu 35
During a Call 35
Making a Second Call 35
Swapping
Between Two Calls 35
Answering an Incoming Call 35
Rejecting an Incoming Call 36
Muting the Microphone 36
Multiparty or
Conference Calls 37
Making a Second Call 37
Setting up a
Conference Call 37
Activate the
Conference Call on Hold 37
Adding Calls to the
Conference Call 37
Private Call in a
Conference Call 38
Ending a Conference Call 38
Menu Tree 39
Camera 42
Take Picture 42
Gallery 43
All Pictures 43
5
4
General Pictures 43
Phonebook Pictures 43
Memory Status 44
Message 44
Text Messages 44
Write Message 45
Inbox 46
Outbox 47
Drafts 47
Settings 47
Delete All 48
Instant Messaging 49
Sign On (Login/Connect) 49
Saved Conversations 49
Setting 50
IM Provider 50
Multimedia Messages 56
Write Message 56
Inbox 57
Outbox 58
Drafts 59
Settings 60
Voice Mail 61
Listen to Voice Mail 61
Voice Mailbox Number 61
Download Messages 62
Inbox 62
Receive 62
Info Service 63
Receive 63
Inbox 63
Topics 63
Alert 63
Auto Display 63
Languages 64
Templates 64
Text 64
Multimedia 65
Business Card 65
Memory Status 65
MEdia Net 66
mMode 68
Bookmarks 68
Go To URL 69
Access Point 69
Cache Settings 70
Clear Cache 70
Cache Check 70
Security Certificates 70
Wap Information 70
Table of Contents
7
6
Games & Apps. 71
My Games & Apps 71
Bookmarks 72
View Information 73
Memory Status 73
Java Version 73
My Folder 74
My Sounds 74
My Games 74
My Multimedia Contents 74
My Graphics 75
My Gallery 75
Recent Calls 76
Missed Calls 76
Dialed Calls 76
Received Calls 77
Delete Recent Calls 77
Call Durations 77
Last Call 77
Received Calls 77
Dialed Calls 77
All Calls 77
Call Costs 78
Last Call’s Cost 78
All Calls’ Cost 78
Cost Settings 78
Call Cost’s Limit 78
Set Tariff 78
Auto Display 78
Data Information 78
WAP Information 78
External Device 78
Total Data 78
Tools 80
Alarm Clock 80
Calendar 81
Voice Recording 83
Calculator 84
Memo 84
World time 85
Unit Converter 86
Infrared 86
Phone Book 88
Contact List 88
Add New 89
Speed Dials 89
Voice Tag List 90
Caller Groups 91
Copy All 92
Delete All 92
Settings 93
Information 93
Settings 94
Sounds 94
My Ringtones 94
Ringtones 94
Volume 94
Message Alert Tones 94
Key Tones 95
Voice Recording 95
Display 96
My Wallpaper 96
Backlight 96
Languages 97
Meny style 97
Date & Time 98
Set Date 98
Date Format 98
Set time 98
Time Format 98
Auto Update 98
Call Settings 99
Call Forwarding 99
Answer Mode 100
Send My Number 100
Call Waiting 100
Minute Minder 101
Voice Dial 101
Auto Redial 102
Closed User Group 102
TTY 102
Send DTMF 103
Security 104
PIN Code Request 104
Call Barring Service 104
Fixed Dial Number (FDN) 105
Change Codes 105
Connection 106
Network Selection 106
World Phone 106
GPRS Attach 107
Access Point 107
Reset Access Point 107
Reset Settings 107
Q & A 108
Accessories 111
Safety Guidelines 113
Glossary 127
Index 130
9
8
Important Information
This user guide contains important information on the use and operation of
this phone. Please read all the information carefully for optimal
performance and to prevent any damage to, or misuse of, the phone. Any
changes or modifications not expressly approved in this user guide could
void your warranty for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not expose
your phone to high humidity areas, such as the bathroom, swimming pool,
etc.
Always store your phone away from heat. Never store your phone in
settings that may expose it to temperatures less than 32°F or greater than
104°F, such as outside during a snowstorm or in your car on a hot day.
Exposure to excessive cold or heat will result in malfunction, damage
and/or catastrophic failure.
Be careful when using your phone near other electronic devices. RF
emissions from your mobile phone may affect nearby inadequately
shielded electronic equipment. You should consult with manufacturers of
any personal medical devices such as pacemakers and hearing aides to
determine if they are susceptible to interference from your mobile phone.
Turn off your phone in a medical facility or at a gas station.
Never place your phone in a microwave oven as this will cause the battery
to explode.
IMPORTANT! Please read the TIA SAFETY INFORMATION on page
113 before using your phone.
Check to make sure that you have all the parts shown below.
Unpacking For Your Safety
Handset Standard
Battery
User GuideTravel Adapter
11
10
Safety Information
Please read and observe the following information for the safe and proper
use of your phone and to prevent any unanticipated damage. Also, keep the
user’s manual in an accessible place at all times after reading it.
]
Unplug the power cord and charger during a lightning storm to avoid
electric shock or fire.
]
Do not use your phone in high explosive areas as the phone may
generate sparks.
]
Do not put your phone in a place subject to excessive dust, and keep the
minimum required distance between the power cord and heat sources.
]
Do not damage the power cord by bending, twisting, pulling, or
subjecting it to heat. Do not use the plug if it is loose as it may cause
fire or electric shock.
]
Hold the power cord plug firmly to plug and unplug the power cord.
Ensure the plug is firmly connected. If it is not firmly connected, it may
cause excessive heat or fire.
]
Do not place a heavy item on the power cord. Do not allow the power
cord to be crimped as it may cause fire or electric shock.
]
Be careful not to let the battery contact metal conductors such as a
necklace or coins. When shorted, it may cause an explosion.
]
Do not disassemble or impact the battery as it may cause electric shock,
short-circuit, and fire. Store the battery in a place out of reach of
children.
]
Using a damaged battery or placing a battery in your mouth may cause
serious injury.
]
Do not place items containing magnetic components such as a credit
card, phone card, bank book or a subway ticket, near your phone. The
magnetic strip can be damaged by the phone.
]
Do not hold or let the antenna come in contact with your body during a
call.
]
Talking on your phone for a long period of time may reduce the call
quality due to heat generated during the use of the phone.
]
Do not allow excessive vibration or impact to the phone.
]
When you do not plan to use the phone for a long period of time, store it
in a safe area with the power cord unplugged.
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of the United States,
with its action in Report and Order FCC 96-326, adopted an updated safety
standard for human exposure to radio frequency (RF) electromagnetic
energy emitted by FCC regulated transmitters. Those guidelines are
consistent with the safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC guidelines and these
international standards.
For Your Safety For Your Safety
13
12
CAUTION
Use only the supplied and approved antenna. Use of unauthorized antennas
or modifications could impair call quality, damage the phone, void your
warranty and/or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged antenna
comes into contact with skin, a minor burn may result. Contact your local
dealer for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with the back of
the phone kept 1.5cm between the user's body and the back of the phone.
To comply with FCC RF exposure requirements, a minimum separation
distance of 1.5cm must be maintained between the user’s body and the
back of the phone. Belt-clips, holsters, and similar accessories containing
metallic components should not be used. Body-worn accessories that
cannot maintain 1.5 cm separation distance between the user's body and
the back of the phone, and have not been tested for typical body-worn
operations may not comply with FCC RF exposure limits and should
be avoided.
Vehicle Mounted External Antenna (optional, if
available)
A minimum separation distance of 8 inches (20 cm) must be maintained
between the user/bystander and the vehicle mounted external antenna to
satisfy FCC RF exposure requirements.
For more information about RF exposure, visit the FCC website at
www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC rules.
Operation is subject to the following two conditions: (1) This device and
its accessories may not cause harmful interference, and (2) this device and
its accessories must accept any interference received, including
interference that may cause undesired operation.
Cautions for Battery
]
Do not disassemble.
]
Do not short-circuit.
]
Do not expose to high temperature: 60°C (140°F).
]
Do not incinerate.
Battery Disposal
]
Please dispose of your battery properly or bring to your local wireless
carrier for recycling.
]
Do not dispose in fire or with hazardous or flammable materials.
Adapter (Charger) Cautions
]
Using the wrong battery charger could damage your phone and void
your warranty.
]
The adapter or battery charger is intended for indoor use only.
Do not expose the adapter or battery charger to direct sunlight or use it in
places with high humidity, such as the bathroom.
For Your Safety For Your Safety
15
14
1. Earpiece
7. Active flip
8. Display screen
9. Navigation key
2. Left soft key
3. Side keys
4. Send key
10. Confirmation key
11. Right soft key
12. Message key
15. Clear key
16. Infrared port
14. End / Power key
6. Microphone
5. Alpha numeric keys
13. Camera key
Your Phone’s Features
1. Earpiece
2,11. Left soft key / Right soft key: Each of these keys
perform the functions indicated by the text on the display immediately
above them.
3. Side keys: These keys are used to control the volume of key tone in
standby mode and speaker volume during a call.
4. Send key: You can dial a phone number and answer incoming calls.
Press this key in standby mode to quickly access the most recent
incoming, outgoing and missed calls.
5. Alphanumeric keys: These keys are used to dial a number in standby
mode and to enter number or characters in edit mode.
6. Microphone: Can be muted during a call for privacy.
7. Active flip: Open the flip to answer an incoming call and close to end
the call.
8. Display screen: Displays phone status icons, menu items, Web
information, pictures and more in full color.
9. Navigation key: Use for quick access to phone functions.
10. Confirmation key: Long press will launch the WAP browser. Allows
you to select and confirm menu options.
12. Message key: Use to retrieve or send voice and text messages.
13. Camera key: Press this key to use the camera feature. Directly goes to
the camera mode.
14. End/Power key: Allows you to power the phone on or off, end calls, or
return to Standby Mode.
15. Clear key: Allows you to delete the characters entered or return you to
the previous screen.
16. Infrared port: Indicates that you have activated the infrared features to
communicate with an IrDA-compliant device and to send or receive
data.
Phone Components
Your Phone Your Phone
17
16
Ear-microphone
jack
Camera
Antenna
External
dispaly
Icon area
Text and
graphic area
Soft key
indications
Camera key
Infrared port
Backlight
A backlight illuminates the display and the keypad. When you press any
key or open the folder, the backlight turns on. It turns off if no key is
pressed within a given period of time, depending on the Backlight menu
option. After one minute, the display turns off to conserve your battery
power. To specify the length of time the backlight is active, set the
Backlight menu option (Menu 9.2.2). See page 96 for further details.
External Display
Your phone has an external display on the cover. It indicates when you
have an incoming call or a message. It also alerts you at the specified time
when you set an alarm by turning on its backlight and showing
corresponding icon on it.
Display Information
Your Phone Your Phone
Area Description
First line Displays various icons. See page 18
Middle lines Dispaly messages, instructions and Any information that
you enter, such As number to be dialed.
Last line Shows the functions currently Assigned to the two soft
keys.
19
18
Installing the SIM Card
When you subscribe to a cellular network, you are provided with a plug-in
SIM card loaded with your subscription details, such as your PIN, any
optional services available and many others.
1. If necessary, switch off the phone by holding down the key until
the power-off image displays.
2. Remove the battery. To do so:
1Pull and hold the battery lock above the battery toward the top of the
phone.
2Lift the battery away, as shown.
Getting Started
Your Phone
On-Screen Icons
The table below describes various display indicators or icons that appear
on the phone’s display screen.
Icon Description
Indicates the strength of the network signal.
Indicates a call is in progress.
Indicates that you are roaming off the network.
Indicates that GPRS service is available.
Indicates the alarm has been set and is on.
Indicates the status of the battery charge.
Indicates the receipt of a text message.
Indicates the receipt of a MMS message.
Indicates the receipt of a voice mail.
Indicates that the vibration ringer has been set.
Indicates the receipt of an e-mail message.
Indicates the Loud menu in Profiles.
Indicates the Quiet menu in Profiles.
Indicates the Headset menu in Profiles.
Indicates the Car menu in Profiles.
Indicates the General menu in Profiles.
Indicates that you can use the download message service.
Indicates the Schedule function.
Important! The plug-in SIM card and its contacts can be easily damaged
by scratches or bending, so be careful when handling, inserting
or removing the card. Keep all SIM cards out of the reach of
small children.
1
2
21
20
Getting Started
5. Press the battery until it clicks into place. Make sure that the battery is
properly installed before switching the phone on.
Getting Started
Note When you need to remove the SIM card, slide it, as shown, and take it
out of the socket.
4. Place the battery so that the tabs on the end align with the slots at the
bottom of the phone.
3. Slide the SIM card into the SIM card socket so that it locks the card into
place. Make sure that the notched corner is bottom left and the gold
contacts of the card face into the phone.
23
22
Getting StartedGetting Started
3. When charging is finished, disconnect the adapter from the power outlet
and from the phone by pressing on the gray tabs on both sides of the
connector while pulling the connector out.
Notice
]
If your phone is powered on while charging, you’ll see the bars in the
battery indicator icon cycle.
When the battery is fully charged, the bars in the battery indicator icon will
flash on and off
]
If your phone is powered off, the display will show the charging status.
‘Charging’ or ‘Full’ will be displayed.
If the battery fails to charge completely:
]
After turning the phone on and off, please attempt to recharge the battery.
]
After detaching and reattaching the battery, please attempt to recharge the
battery.
Charging
External Display (Sub LCD)
Charging the Battery
Use of unauthorized accessories could damage your phone and invalidate
your warranty.
To use the travel adapter provided with your phone:
1. With the battery in position on the phone, connect the lead from the
travel adapter to the bottom of the phone. Check that the arrow on the
lead connector is facing towards the front of the phone.
2. Connect the adapter to a standard AC wall outlet. Only use the travel
adapter that comes included with the package.
Warning You must unplug the adapter before we remove the battery from
the phone during charging; otherwise, the phone could be
damaged.
Full
1
1
2
25
24
Turning Your Phone On and Off
1. Open the flip.
2. Hold down the key until the phone switches on.
3. If the phone asks for a PIN, enter the PIN and press the left soft key
[OK]. For further details, see page 104.
The phone searches for your network and after finding it, the idle screen,
illustrated below, appears on both displays. Now, you can make or
receive a call.
4. When you wish to switch the phone off, hold down the key until
the power-off image displays.
Note The display language is preset to English at the factory. To change the
language, use the Languages menu option (Menu 9.2.3).
For further details, see page 97.
Access Codes
You can use the access codes described in this section to avoid
unauthorized use of your phone. The access codes can be changed by using
the Change Codes feature [Menu 9.5.4].
Security code (4 to 8 digits)
The security code protects the unauthorized use of your phone. The default
security code is set to ‘0000’ and the security code is required to delete all
phone entries and to activate the Restore Factory Settings menu. The
security code default setting can be modified from the Security Settings
menu.
Barring Password
The barring password is required when you use the Call Barring function.
The password is obtained from the service provider when you subscribe to
this function. See page 104 for further details.
Getting StartedGetting Started
27
26
Making a Call From the Contact List
You can store names and phone numbers dialed frequently in the SIM card
as well as the phone memory known as the Contact List.
You can dial a number by simply looking up a name in the contact list. For
more details on the Contact List feature, please refer to page 88.
Adjusting the Volume
During a call, if you want to adjust the earpiece volume, use the side keys
of the phone.
In idle mode with the flip cover open, you can adjust the key volume using
the side keys.
Answering a Call
When you receive a call, the phone rings and the flashing phone icon
appears on the screen. If the caller can be identified, the caller’s phone
number(or name if stored in your phonebook) is displayed.
1. Open the flip and press the key or the left soft key to answer an
incoming call. If the Any Key menu option(Menu 9.4.2) has been set to
, any key press will answer a call except for the key or the right
soft key.
2. End the call by closing the phone or pressing the key.
Notice You can answer a call while using the phonebook or other menu
features.
Notice
]
To reject an incoming call, press and hold the side keys on the left side of
the phone without opening the flip.
]
If the Flip Open menu option(Menu 9.4.2) is set to , you do not need
to press any key. You can answer the call simply by opening the flip.
General Functions
General Functions
Making a Call
1. Make sure your phone is powered on.
2. Enter a phone number including the area code. To edit a number on the
display screen, press the right/left navigation keys to move the cursor to
desired position or simply press the key to erase one digit at a
time.
]
Press and hold the key to erase the entire number.
3. Press the key to call the number.
4. When finished, press the key.
Making a Call by Send Key
1. Press the key, and the most recent incoming, outgoing and missed
phone numbers will be displayed.
2. Select the desired number by using the navigation key.
3. Press the key.
Making International Calls
1. Press and hold the key for the international prefix. The ‘+’
character can be replaced with the international access code.
2. Enter the country code, area code, and the phone number.
3. Press the key.
Ending a Call
When you have finished a call, press the key.
Manner Mode (Quick)
When the flip is closed, Manner Mode can be activated by pressing and
holding down side keys.
Signal Strength
If you are inside a building, being near a window may give you better
reception. You can see the strength of your signal by the signal indicator
( ) on your phone’s display screen.
Entering Text
You can enter alphanumeric characters by using the phone’s keypad. For
example, storing names in the phonebook, writing a message, creating a
personal greeting or scheduling events in the calendar all require entering
text.
Following text input methods are available in the phone.
T9 Mode
This mode allows you to enter words with only one keystroke per letter.
Each key on the keypad has more than one letter. The T9 mode
automatically compares your keystrokes with an internal linguistic
dictionary to determine the correct word, thus requiring far fewer
keystrokes than the traditional ABC mode.
ABC Mode
This mode allows you to enter letters by pressing the key labeled with the
required letter once, twice, three or four times until the letter is displayed.
123 Mode(Numbers Mode)
Type numbers using one keystroke per number. To change to 123 mode in
a text entry field, press key until 123 mode is displayed.
29
28
Symbolic Mode
This mode allows you to enter special characters.
Changing the Text Input Mode
1. When you are in a field that allows characters to be entered, you will
notice the text input mode indicator in the upper right corner of the
display.
2. If you want to change modes, press and hold down the key. The
available modes are displayed.
Using the T9 Mode
The T9 predictive text input mode allows you to enter words easily with a
minimum number of key presses. As you press each key, the phone begins
to display the characters that it thinks you are typing based on a built-in
dictionary. As new letters are added, the word changes to reflect the most
likely candidate from the dictionary.
1. When you are in the T9 predictive text input mode, start entering a word
by pressing keys to Press one key per letter.
]
The word changes as letters are typed - ignore what’s on the screen
until the word is typed completely.
]
If the word is still incorrect after typing completely, press the down
navigation key once or more to cycle through the other word options.
Example: Press to type Good
Press [down navigation key] to type
Home
]
If the desired word is missing from the word choices list, add it by
using the ABC mode.
Notice You can select a different T9 language from the menu option. The
default setting on the phone is T9 enabled mode.
To turn it off, select the T9 Off option from the menu.
General FunctionsGeneral Functions
31
30
Characters in the Order Display
Upper Case Lower Case
. , - ? ! ’ @: 1 . , - ? ! ’ @: 1
A B C Ç À Â Á Ä 2 a b c ç à â á ä 2
D E F É È Ê Ë 3 d e f é è ê ë 3
G H I Î Ï Í 4 g h i î ï í 4
J K L 5 j k l 5
M N O Ô Ó Ö Ñ 6 m n o ô ó ö ñ 6
P Q R S 7 p q r s ß 7
T U V Ù Û Ú Ü 8 t u v ù û ú ü 8
W X Y Z 9 w x y z 9
Space Key Space Key
2. Enter the whole word before editing or deleting any keystrokes.
3. Complete each word with a space by pressing the key.
To delete letters, press . Press and hold down to erase entire
words.
Using the ABC Mode
Use the to keys to enter your text.
1. Press the key labeled with the required letter:
]
Once for the first letter
]
Twice for the second letter
]
And so on
2. To insert a space, press the key once. To delete letters, press the
key. Press and hold down the key to clear the display.
Notice To exit the text input mode without saving your input,
press . The phone returns to the previous menu level.
Notice Refer to the table below for more information on the characters
available using the keys.
Using the 123 (Numbers) Mode
The 123 Mode enables you to enter numbers in a text message
(a telephone number, for example).
Press the keys corresponding to the required digits before manually
switching back to the appropriate text entry mode.
1
2
3
4
5
6
7
8
9
0
Key
General Functions General Functions
33
32
General Functions
Using the Symbol Mode
The Symbol Mode enables you to enter various symbols or special
characters.
To enter a symbol, press the key. Use the navigation keys to select the
desired symbol and press tthe left soft key [OK].
Your phone offers a set of functions that allow you to customize the phone.
These functions are arranged in menus and sub-menus, accessed via the
two soft keys marked and . Each menu and sub-menu allows
you to view and alter the settings of a particular function.
The roles of the soft keys vary according to the current context; the label
on the bottom line of the display just above each key indicates its current
role.
Press the left soft key to
access the available
Menu.
Press the right soft key
to access the available
Names.
Selecting Functions and Options
35
34
Your phone provides a number of control functions that you can use during
a call. To access these functions during a call, press the left soft key
[Options].
During a Call
The menu displayed on the handset screen during a call is different than
the default main menu displayed when in idle screen, and the options are
described below.
Making a Second Call
You can get a number you wish to dial from the phonebook to make a
second call. Press the left soft key then select Contact List.
Swapping Between Two Calls
To switch between two calls, press the left soft key or key, and then
select Swap.
Answering an Incoming Call
To answer an incoming call when the handset is ringing, simply press the
key. The handset is also able to warn you of an incoming call while
you are already on a call. A tone sounds in the earpiece, and the display
will show that a second call is waiting. This feature, known as Call
Waiting, is only available if your network supports it. For details of how
to activate and deactivate it see Call Waiting [Menu 9.4.4].
If Call Waiting is on, you can put the first call on hold and answer the
second, by pressing . You can end the current call and answer the
waiting call by pressing the left soft key and then selecting Active call
menu of End call.
In-Call Menu
You can store phone numbers and their corresponding names in the
memory of your SIM card.
In addition, you can store up to 255 numbers and names in the phone
memory.
The SIM card and phone memory, although physically separate, are
utilized like a single entity known as the Contact List. (See page 88 for
details)
Phonebook
37
36
In-Call Menu In-Call Menu
Rejecting an Incoming Call
You can reject an incoming call without answering by simply pressing
the key.
During a call, you can reject an incoming call by pressing the left soft key,
which is the [Menu] key and selecting the Reject call or by pressing
the key.
Muting the Microphone
You can mute the microphone during a call by pressing the [Menu] key
then selecting Mute or right soft key [Mute]. The handset can be
unmuted by pressing the Unmute menu or right soft key [Unmute].
When the handset is muted, the caller cannot hear you, but you can still
hear them.
Multiparty or Conference Calls
The multiparty or conference service provides you with the ability to have
a simultaneous conversation with more than one caller, if your network
service provider supports this feature. A multiparty call can only be set up
when you have one active call and one call on hold, both calls having been
answered. Once a multiparty call is set up, calls may be added,
disconnected or separated (that is, removed from the multiparty call but
still connected to you) by the person who set up the multiparty call. These
options are all available from the In-Call menu. The maximum callers in a
multiparty call are five. Once started, you are in control of the multiparty
call, and only you can add calls to the multiparty call.
Making a Second Call
You can make a second call while currently on a call. Enter the second
number and press the . When the second call is connected, the first
call is automatically placed on hold. You can swap between calls, by
pressing the key.
Setting Up a Conference Call
To set up a conference call, place one call on hold and while the active call
is on, press the left soft key and then select the Join menu of Conference
call.
Activate the Conference Call on Hold
To activate a conference call on hold, press the left soft key, and then press
the key.
Adding Calls to the Conference Call
To add a call to an existing conference call, press the left soft key, and then
select the Join menu of Conference call.
39
38
*:
Shown only if supported by CPHS(Common PCS Handset Specification)
The following illustration shows the available menu structure and indicates
the:
]
Number assigned to each menu option.
]
Page where you can find the feature description.
1. Camera (see page 42)
1.1 Take Picture
1.2 Gallery
1.3 Memory Status
2. Messages (see page 45)
2.1 Text Messages
2.1.1 Write Message
2.1.2 Inbox
2.1.3 Outbox
2.1.4 Drafts
2.1.5 Settings
2.1.6 Delete All
2.2 Instant Messaging
2.2.1 Sign On
2.2.2 Saved Conversations
2.2.3 Settings
2.2.4 IM Provider
2.3 Multimedia Messages
2.3.1 Write Message
2.3.2 Inbox
2.3.3 Outbox
2.3.4 Drafts
2.3.5 Settings
2.4 Voice Mail
2.4.1 Listen To Voice Mail
2.4.2 Voice Mailbox Number
2. Messages (continued)
2.5 Download Messages
2.5.1 Inbox
2.5.2 Receive
2.6 Info Service
2.6.1 Receive
2.6.2 Inbox
2.6.3 Topics
2.6.4 Alert
2.6.5 Auto Display
2.6.6 Languages
2.7 Templates
2.7.1 Text
2.7.2 Multimedia
2.7.3 Business Card
2.8 Memory Status
3. MEdia Net (see page 66)
3.1 mMode
3.2 Bookmarks
3.3 Go To URL
3.4 Access Point
3.5 Cache Settings
3.5.1 Clear Cache
3.5.2 Cache Check
3.6 Security Certificates
3.7 WAP Information
*
*
Menu Tree
In-Call Menu
Private Call in a Conference Call
To have a private call with one caller from a conference call, display the
number of the caller you wish to talk to on the screen, then press the left
soft key. Select the Private menu of Conference call to put all the other
callers on hold.
Ending a Conference Call
Currently displayed caller from a conference call can be disconnected by
pressing the key.
41
40
*:
Shown only if supported by CPHS(Common PCS Handset Specification)
*:
Shown only if supported by CPHS(Common PCS Handset Specification)
9 Settings (see page 94)
9.1 Sounds
9.2 Display
9.3 Date & Time
9.3.1 Set Date
9.3.2 Date Format
9.3.3 Set Time
9.3.4 Time Format
9.3.5 Auto Update
9.4 Call Settings
9.4.1 Call Forwarding
9.4.2 Answer Mode
9.4.3 Send My Number
9.4.4 Call Waiting
9.4.5 Minute Minder
9.4.6 Voice Dial
9.4.7 Auto Redial
9.4.8 Closed User Group
9.4.9 TTY
9.4.0 Send DTMF
9.5 Security
9.5.1 PIN Code Request
9.5.2 Security Settings
9.5.3 Fixed Dial Number
9.5.4 Change Codes
9.6 Connection Settings
9.6.1 Network Selection
9.6.2 World Phone
9.6.3 GPRS Attach
9.6.4 Access Point
9.6.5 Reset Access Point
9.7 Reset Setting
*
*
*
*
*
4. Games & Apps. (see page 71)
4.1 My Games & Apps.
4.2 Bookmarks
4.3 View Information
4.3.1 Memory Status
4.3.2 Java Version
5. My Folder (see page 74)
5.1 My Sounds
5.2 My Games
5.3 My Multimedia Contents
5.4 My Graphics
5.5 My Gallery
6. Recent Calls (see page 76)
6.1 Missed Calls
6.2 Dialed Calls
6.3 Received Calls
6.4 Delete Recent Calls
6.5 Call Durations
6.5.1 Last Call
6.5.2 Received Calls
6.5.3 Dialed Calls
6.5.4 All Calls
6.6 Call Costs
1.6.1 Last Call’s Cost
1.6.2 All Calls’ Cost
6.7 Cost Settings
1.7.1 Call Cost’s Limit
1.7.2 Set Tariff
1.7.3 Auto Display
6. Recent Calls (continued)
6.8 Data Information
1.8.1 WAP Information
1.8.2 External Device
1.8.3 Total Data
7. Tools (see page 80)
7.1 Alarm Clock
7.2 Calendar
7.3 Voice Recording
7.4 Calculator
7.5 Memo
7.6 World Time
7.7 Unit Converter
7.8 Infrared
8. Phonebook (see page 88)
8.1 Contact List
8.2 Add New
8.3 Speed Dials
8.4 Voice Tag List
8.5 Caller Groups
8.6 Copy All
8.7 Delete All
8.8 Settings
8.9 Information
Menu TreeMenu Tree
*
*
43
42
The phone supports 5 modes that can be set to capture images and they are
48x80, 128x160, 160x120, 320x240 and 640x480. However Zoom,
Brightness, Color/Gray setting, Video Mode and Continuous Capture
functions are not supported except for Up/Down Display switching.
You can access camera feature directly by pressing and holding the about
2 seconds.
Take Picture Menu 1.1
Using the camera module built in your phone, you can take pictures of
people or events while on the move. Additionally, you can send photos to
other people in a picture message.
The right soft key [Options] will bring up the following options.
]
Image Size: Sets the image size to one of 48
X
80(Phonebook),
128
X
160(Mobile),160
X
120(QQVGA), 320
X
240 (QVGA),
640
X
480(VGA), and. The selected image size displays on the capture
screen.
]
Brightness:
]
White Balance:
]
Zoom: Determines the zoom rate.
]
Image Effect: Allows you to apply special effects to the picture. Press
the left or right navigtion key to find the tone you want to use. Color,
Sepia, Mono are available.
]
Multishot
]
Shutter Sound: Allows you to select a sound when you press the
shutter.
Sound 1 / Sound 2 / Sound 3 / Silent
]
Default Settings: This restores the original camera settings (Size,
Brightness, Zoom, etc.).
Camera Camera
Gallery Menu 1.2
In this menu, you can review the pictures you have taken.
This feature offers the ability to store all captured photo images in an
album. When no images have been captured, the Empty message will be
displayed. The picture will display the last image viewed. The title of the
image will be displayed on top as well as the the index number of the
displayed image. The left or right navigation key is used to view previous
or next image.
All Pictures (Menu 1.2.1)
You can view all pictures.
General Pictures (Menu 1.2.2)
You can view all pictures except of Phonebook Pictures.
Phonebook Pictures (Menu 1.2.3)
This is where 48x80 size images can be stored and they can be added to the
phone contact list.
The following options are available for All Pictures, General Pictures
and Phonebook Pictures menu.
]
Add To Existing Contact (Only available for Phonebook Pictures
menu): Allows you to add the picture in a Contact List to each entry
which you want.
]
Send Photo: allows you to send a multimedia message using the taken
picture. For further details about sending multimedia messages, see
page 56.
]
Set As Wallpaper: Set selected photo image as a wallpaper.
]
Delete: Delete current image.
45
44
Memory Status Menu 1.3
This indicates the available memory capacity. The total available memory
is 300KB and the remaining capacity is displayed.
]
Slideshow: The Slide Show mode will display the images in slide show
format. The images are shown every 1.5 second intervals when in All
Pictures mode. General Pictures mode will display all images except for
the Phonebook size (48x80) in slide show format. Phonebook Pictures
will only display the Phonebook size images.
]
Rename: Allows you to rename the taken picture.
]
Delete All: Delete all images in the album.
]
Picture Information: Displays Title, Size, Date and Time information on
selected image.
Camera
Text Messages Menu 2.1
Your phone receives voice mail notification messages and Short Message
Service (SMS) messages.
Voice mail and SMS are network services. Please contact your service
provider for more information.
When the icon appears, you have received a new voice mail. When
the icon appears, you have received a new text message. If the
message memory is full, an error message is displayed, the icon
flashes and you cannot receive any new messages. Use the Delete option in
the Inbox (Menu 2.1.2) to delete obsolete messages. Once there is space in
the memory any undelivered SMS messages will be received (provided
sufficient space is available).
Write Message (Menu 2.1.1)
You can write and edit text messages of up to 918 characters.
1. Type in a message using key presses. For details on how to enter text,
refer to page 28 (Entering Text).
2. After completing the message select the required option by pressing the
left soft key [Options].
The following options are available.
]
Send To Number: Enter the phone number or select the number from
the phone book.
]
Send To Email: Enter the email or select the email from the phone
book.
]
Save To Drafts: Save the message so that it can be sent later.
]
T9 Languages: Choose between English or Spanish T9 language. For
details on how to enter text, refer to page 29 (Using the T9 Mode).
]
Clear Text: Deletes the written message.
]
Exit Editor: Exit the text editor.
*
*:Shown only if supported by SIM card
Message
47
46
The following options are available. (Press the right soft key [Attach])
]
Symbol: Attach special characters.
]
Picture: Send and receive text messages that contain pictures, known as
‘picture messages’. Several preset pictures are available in the phone
and they can be replaced with new ones received from other sources.
]
Animation: Attaching an animation in a message can be
done through EMS(Enhanced Messaging Service).
]
Sound: Attach sounds that are available for short message.
]
Text Templates: Use the text templates already set in the phone.
]
Phone Number: Attach a phone number.
]
Business Card: Attach your name card.
Inbox (Menu 2.1.2)
Received text messages, page messages, and email lists may be searched
and the contents may be viewed.Received messages are displayed from
newest to oldest.
The following options are available.
]
Reply: Replies to the received message.
]
Delete: Deletes the selected message from the Inbox.
]
Forward: Forwards a received message to other recipients. After
recipients are entered, the message can be forwarded.
]
Return Call: Call back the sender.
]
Extract: Extract picture, sound, text webpage and email address from
the message. They will be saved in My Folder, phonebook or
bookmarks.
MessageMessage
Outbox (Menu 2.1.3)
View lists and contents of sent messages in this menu and also verify if
transmission was successful.
The following options are available.
]
Forward: Forwards the current message to other recipients.
]
Delete: Deletes the selected message from the Outbox.
Drafts (Menu 2.1.4)
This menu option shows the preset message list. Scroll through the list
using the up/down navigation keys.
The following options are available.
]
Edit: You can edit a selected message.
]
Delete: Deletes the selected preset message.
Settings (Menu 2.1.5)
This menu allows you to set up default SMS information.
]
Message Types: Allows you to set the default message type (Text,
Voice, Fax, Paging, X.400, E-mail, ERMES). The network can convert
the messages into the selected format. The type of message you desire
can be set to Text Type.
]
Valid Period: Allows you to set the length of time for which your text
messages will be stored at the SMS center while attempts are made to
deliver them to the recipient. Possible values are Maximum, 30 Minutes,
1 Hour, 6 Hours, 1 Day and 1 Week which can be authorized by your
service provider.
***
*
*:Shown only if supported by SIM card
49
48
]
Delivery Reports: Allows you to activate or deactivate the report
function. When this function is activated, the network informs you
whether or not your message has been delivered.
]
Reply With Same Service: Allows the recipient of your SMS message
to send you a reply via your message center, if the service is provided by
the network.
]
Message Center Number: Allows you to store or change the number of
your email gateway required when sending text messages. You must
obtain this number from your service provider.
]
Email Gateway: Allows you to store or change the number of your
email gateway required when sending text messages.
]
Subject: If you set it to on, allows you to enter the subject.
]
Bearer Setting: You can select GPRS or GSM. Contact your network
operator or service provider for information related to setting a selected
bearer, pricing and connection speed.
GSM Preferred/GPRS Preferred
Delete All (Menu 2.1.6)
Allows you to delete all messages.
*
*
*
*
*:Shown only if supported by SIM card
Message Message
Instant Messaging Menu 2.2
Instant Message feature can only be used with the support of the network
operator or the community. For Instant Message users like AIM, ICQ,
MSN and Yahoo, a valid user ID will be required in order to Login(Sign
On/Connect) and exchange messages as well as check the online status.
There are three ways to use the Instant Message feature.
1. Through the Main Menu.
2. Through the Message short key (the right navigation key).
3. Through the IM hotkey (the left navigation key). Short pressing the
hotkey will bring up the Login screen and long pressing the hotkey will
automatically begin the login process for the IM community selected
previously.
The menu items below might not appear since not all IM communities
support the various options. Also the menu strings may appear differently
based on the selected IM communities.
Offline Menu
Sign On (Login / Connect) (Menu 2.2.1)
This allows users to Login by filling in the User ID (Screen Name / ICQ#)
and Password.
Saved Conversations (Menu 2.2.2)
This is where a user can view saved conversation.
51
50
Message Message
Settings (Menu 2.2.3)
]
Screen Name: You may select the Screen Name to be used while in the
IM service.
]
Availability: You may select your availability status to Not Available
(Away / Do Not Disturb).
]
Mood: You may select your current mood as in Happy, Sad, Angry,
Jealous, In Love, Sleep, etc.
]
Status Text: You may select your current status in free text format.
IM Provider (Menu 2.2.4)
This menu option offers the ability to store your Login information such as
the User ID and Password.
]
Activate: You may select the default Community.
]
Settings
* Screen Name (User ID / ICQ #): You can store the User ID.
* Password: You can store the Password.
* Binding Protocol: You can select the Bearer type.
* SMS GW Number: You can change the SMS gateway number.
]
Rename: You can change the Community name.
]
Delete: You can delete the Community information
]
Delete All: You can delete all information related to the Community, but
Default Community settings are preserved.
]
Add New Provider: You can add a new Community.
Note When changing or adding a new Community, please check with your
Network provider.
Note When changing or adding a new Community, please check with your
Network provider.
Online Menu / 1 to 1 conversation
After successful Login (Sign On / Connect), a contact list with buddies will
appear on screen. Depending on the cursor location in the contact list,
following menu options will be available.
When cursor is located on the Unknown List (Strangers)
View/Hide Contacts (View/Hide Buddies): This provides the option to
view or hide the selected contacts (buddies) from the list.
Chat (Send IM / Send Message): This offers the ability send a message to
non buddies. When selected, User ID (Screen Name / ICQ#) must be
typed in prior to starting an IM session or conversation.
]
Settings
• Screen Name: You may select the Screen Name to be used while in the
IM service.
• Availability: You may select your availability status to Not Available
(Away / Do Not Disturb).
• Mood: You may select your current mood as in Happy, Sad, Angry,
Jealous, In Love, Sleep, etc.
• Status Text: You may select your current status in free text format.
• Watcher List: You may view your buddies presence information from the
list.
• View Options: You may allow only buddies online from your contact list
or everyone to view.
]
Saved Conversations: You may view or delete the stored conversation
session.
]
Logout (Sign Off / Disconnect): This begins the Logout (Sign Off /
Disconnect) process.
53
52
Message Message
When cursor is located on the Unknown Contact (Strangers)
]
Chat(Send IM/Send Message)/View: This will allow you to converse
with the selected Unknown Contact (Stranger).
]
Block/Unblock Contact (Block/Unblock Buddy): This allows or blocks
conversation with the selected Unknown Contact (Stranger).
]
Add To List: This allows you to add the Unknown Contact (Stranger) to
the Contact (Buddy) list. After the selecting the contactlist (buddylist),
you may add the Unknown Contact (Strange) and once completed it is
automatically deleted from the Unknown List (Strangers).
]
Delete IM: Selected Unknown Contact (Stranger) is deleted.
]
Settings: Please refer to the Settings Menu on page 52.
]
Saved Conversations: You may view or delete the stored conversation
session.
]
Logout (Sign Off/Disconnect): This begins the Logout (Sign Off /
Disconnect) process.
When cursor is located on the Contactlist (Mobile Device)
]
View/Hide Contacts (View/Hide Buddies): This allows the selected
contacts (buddies) in the list to be viewed or hidden.
]
Refresh List: This refreshes the presence information of the contacts
(buddies) within the contactlist (Mobile Device).
]
Rename List: This renames the selected contactlist.
]
Add List: This adds a new contactlist.
]
Add Contact: This adds the selected contact (buddy) to the contactlist,
but only after browsing the Community.
]
Delete List: This deletes the selected contactlist.
]
Settings: Please refer to the Settings Menu on page 52.
]
Saved Conversations: You may view or delete the stored conversation
session.
]
Logout (Sign Off/Disconnect): This begins the Logout (Sign Off /
Disconnect) process.
When cursor is located on the Contact (Buddy)
]
Chat(Send IM/Send Message)/View: This will display a screen where
conversation with selected Contact (Buddy) can take place.
]
Rename Contact(Rename Buddy): Selected Contact (Buddy) name can
be changed or renamed.
]
Block / Unblock Contact (Block / Unblock Buddy): This allows or
blocks conversation with the selected Unknown Contact (Stranger).
]
Subscribe To (Set Alert): This sets the automatic update of presence
information for a selected Contact (Buddy).
]
Unsubscribe To (Clear Alert): This cancels the automatic update
presence setting for a selected Contact (Buddy).
]
Delete Contact (Delete Buddy): This deletes the selected Contact
(Buddy).
]
View Information: This allows for viewing of the selected Contact
(Buddy) information.
]
Settings: Please refer to the Settings Menu on page 52.
]
Saved Conversations: You may view or delete the stored conversation
session.
]
Logout (Sign Off/Disconnect): This begins the Logout (Sign Off /
Disconnect) process.
55
54
Message Message
Menu options available in the Conversation screen
]
Send: Typed message can be sent.
]
Back To List: This brings the screen back to the contact (buddy) list.
]
End Conversation: This ends the active conversation and clears the
conversation buffer.
]
Block / Unblock Contact (Block / Unblock Buddy): This allows or
blocks conversation with the selected Unknown Contact (Stranger).
]
Save Conversation: Stores currently active conversation.
]
View Information: Selected Unknown Contact (Stranger) information
can be viewed.
]
T9 Languages: This selects the T9 predictive mode Language.
* Within the conversation screen, you can insert a template using the
SK2.
Online Menu / Group chat
When cursor is located on the Group List
]
View/Hide Groups: You can choose to view or hide the Group Chat List.
]
Join New Group: This allows you to join a new Group Chat. In order to
join, Group ID is required.
]
Search Group: You can join after searching the Group chat.
]
Make Group: A new group chat can be created after typing in the group
ID and the welcome note.
]
Settings: Please refer to the Settings Menu on page 52.
]
Saved Conversations: You may view or delete the stored conversation
session.
]
Logout (Sign Off/Disconnect): This begins the Logout (Sign Off /
Disconnect) process.
Menu options available in the group chat screen (only if
it’s been created by yourself)
]
Send: This sends the typed message to all active members within the
Group Chat.
]
Invite Others: This allows you to invite other contact (buddy) to the
group chat. You can use the contact (buddy) list within the menu or by
inviting based on the search results.
]
Back To List: This brings the screen back to the contact (buddy) list.
]
Leave Group: When leaving the active group chat session, the buffer is
cleared.
]
Save Conversation: Stored conversation can be viewed or deleted.
]
Delete Group: This deletes the entire active group chat.
]
Show Members (People here/Now chatting): This displays current
members who have joined the active group chat session.
]
T9 Languages: This selects the T9 predictive mode Language.
57
56
Message Message
Multimedia Messages Menu 2.3
A multimedia message can contain text, images, and/or sound clips. This
feature can be used only if it is supported by your network operator or
service provider. Only devices that offer compatible multimedia message
or e-mail features can receive and multimedia messages. Attach to add
Symbol, Picture, Sound, Recorded Voice, Text Template.
Write Message (Menu 2.3.1)
The following options are available.
• Send: Support mutiple number and email addresses.
• Preview: To see the multimedia message you wrote.
• Save: Allows you to save multimedia messages in draft or as templates.
• Delete: Deletes the MMS message.
• Settings: Allows you to set timer for slide and text. Or, allows you to
make the message contents aligned right, left, top and bottom.
• Add Slide: Allows you to add a slide before or after current slide.
• Remove Slide: Deletes the selected slide.
• Add Image: Allows you to add a image before or after current image.
• Add Sound: Allows you to add a sound before or after current sound.
• Delete Image: Deletes the current image.
• Delete Sound: Deletes the current sound.
Inbox (Menu 2.3.2)
You will be alerted when you have received messages. They will be stored
in the Inbox. In the Inbox, you can identify each message by icons. For
detail, see the icon directive below.
If the phone has ‘no space for message’, you can make space in each
repository by deleting messages, media and applications.
• Timer Stop: Timer stop menu is displayed when you receive the
message including various pictures. Usually, the pictures slide
automatically. However, if you select this menu, you can see the next
picture by pressing the left soft key manually.
• Previous Slide: View the previous page.
• Restart: Allows you to replay multimedia messages.
• Save Message: Allows you to save a multimedia message in draft or as
template.
• Save Items: Allows you to extract picture and sound. They will be saved
in My Folder or phonebook.
• Details: Allows you, to view information about received messages;
Sender’s address, Subject (only for multimedia message), Message date
& time, Message type, Message size.
• Reply: Allows you to reply to the sender.
• Reply All: Allows you to reply to the senders.
• Delete Message: Allows you to delete the current message.
• Forward: Allows you to forward the selected message to other
recipients.
59
58
Message Message
Outbox (Menu 2.3.3)
Allows you to see sent messages here. For sent message, you can see the
delivery status.
• Timer Stop: Timer stop menu is displayed when you receive the
message including various pictures. Usually, the pictures slide
automatically. However, if you select this menu, you can see the next
picture by pressing the left soft key manually.
• Previous Slide: View the previous page.
• Restart: Allows you to replay current messages.
• Save Message: Allows you to save multimedia message in draft or as
template.
• Save Items: Save the item such as image or sound as an attachment in a
message.
• Details: Allows you to view information about outbox messages; Subject
(only for multimedia message), Message date & time, Message type,
Message size.
• Reply: Allows you to reply to the current message.
• Reply All: Allows you to reply to the all messages.
• Delete Message: Allows you to delete the current message.
• Forward: Allows you to forward the current message to other recipients.
Drafts (Menu 2.3.4)
Using this menu, you can preset up to five multimedia messages that you
use most frequently. This menu shows the preset multimedia message list.
The following options are available.
• Send: Support mutiple number and email addresses.
• Preview: To see the multimedia message you wrote.
• Save: Allows you to save multimedia messages in draft or as templates.
• Delete: Allows you to delete the image or sound.
• Settings: Allows you to set timer for slide or text. Or, allows you to make
the message contents aligned right, left, top and bottom.
• Add Slide: Allows you to add a slide before or after current slide.
• Remove Slide: Allows you to move to previous or next slide.
• Add Image: Allows you to add a image before or after current image.
• Add Sound: Allows you to add a sound before or after current sound.
61
60
Message Message
Settings (Menu 2.3.5)
Via this menu, you can set up default multimedia message information.
The following options are available:
]
Message Subject: Enter the message title.
]
Slide Duration: Display the duration of each page when writing the
message.
]
Alignment: Set the position of a message and text message.
• Image Bottom • Image Left
• Image Top • Image Right
]
Valid Period: Set the duration for keeping messages on the network
server.
]
Auto Download
• On: If you select this, messages are downloaded automatically on
receipt.
• Confirm: Requires you to confirm you want to download the message.
• Off: Defers downloading messages.
]
Message Center URL: Enter the address of an MMS server to use the
MMS service.
]
Access Point: For further details, see page 74.
Voice Mail Menu 2.4
This menu provides you with a quick way of accessing your voice mailbox
(if provided by your network).
Before using this feature, you must enter the voice server number obtained
from your service provider.
When new voicemail is received, the symbol will be displayed on the
screen. Please check with your network service provider for details of their
service in order to configure the handset accordingly.
Listen To Voice Mail (Menu 2.4.1)
Before using this feature, you must enter the voice server number obtained
from your service provider (see menu option 2.4.2). You can then select
this option and press the OK soft key to listen to your messages.
You can quickly connect to the first voice server by pressing and holding
the key in Idle Mode.
Voice Mailbox Number (Menu 2.4.2)
Allows you to change the voice mail server number, if necessary.
*
*:Shown only if supported by SIM card
Note Voice Mail is a network feature. Please contact your service provider
for further details.
63
62
Message Message
Download Messages Menu 2.5
Inbox (Menu 2.5.1)
You can order push messages from WAP service providers.
Push messages are notifications of, for example, news headlines and they
may contain a text message or address of a WAP service. For availability
and subscription, contact your WAP service provider.
Service providers can update an existing push message every time a new
push message is received. Messages can be updated even if you have
moved them to another folder. Push messages expire and they are deleted
automatically.
]
Information: Shows the information of received push messages.
]
Load: Allows you to connect to a specific site using the information in
the received push message.
]
Delete: Delete the selected push message.
Receive (Menu 2.5.2)
You can set the option whether you will receive the message or not.
Info Service Menu 2.6
Info service messages are text messages sent by the network to GSM
phone users. They provide general information such as weather reports,
traffic news, taxis, pharmacies, and stock prices. Each type of information
is associated with a number, which can be obtained from the service
provider. When you receive an info service message, a popup message will
indicate a new message receipt or the info service message will be
displayed directly. In standby mode, the following options are available
when viewing the info service message.
Receive (Menu 2.6.1)
Ability to enable or disable the reception of broadcast messages.
Inbox (Menu 2.6.2)
The list of received broadcast messages can be searched and the contents
viewed.
Topics (Menu 2.6.3)
To create new topics, press the left soft key[Select] and then select the new
topics menu by pressing the left soft key [Options].
You can Deactivate, Edit, Delete and Add New topics by pressing the left
soft key [Select].
Alert (Menu 2.6.4)
Ability to select the alert type for a new message.
Auto Display (Menu 2.6.5)
This option will automatically display all broadcast messages received.
Scroll through the messages using the up/down navigation keys.
*
*:Shown only if supported by SIM card
65
64
Message Message
Languages (Menu 2.6.6)
This option allows you to select the language preferred. The cell
broadcast message will be displayed in the language selected.
If you use all languages supported by phone, select ‘Automatic’ at the
bottom of the list.
Templates Menu 2.7
There are 6 predefined messages in the list. You can view and edit the
template messages or create new messages. Two options are available:
Text and Multimedia.
Text (Menu 2.7.1)
• Please call me back
• I’m late. I will be there at
• Where are you now?
• I’m on the way.
• Urgent! Please contact.
• I love you
The following options are available.
]
Edit: Allows you to write a new message or edit the selected template
message.
]
Send Via Text Message: Sends the selected template message by SMS.
]
Send Via Multimedia Message: Sends the selected template message
by MMS.
]
Delete: Allows you to delete the selected template message.
Multimedia (Menu 2.7.2)
For further details, see page 57.
• Send: Support mutiple number and email addresses.
• Preview: To see the multimedia message you wrote.
• Save: Allows you to save multimedia messages in draft or as templates.
• Delete: Deletes the MMS message.
• Settings: Allows you to set timer for slide and text. Or, allows you to
make the message contents aligned right, left, top and bottom.
• Add Slide: Allows you to add a slide before or after current slide.
• Remove Slide: Deletes the selected slide.
• Add Image: Allows you to add a image before or after current image.
• Add Sound: Allows you to add a sound before or after current sound.
• Delete Image: Deletes the current image.
• Delete Sound: Deletes the current sound.
Business Card (Menu 2.7.3)
This option allows you to make your own name card. Key in the Name,
Mobile number, Office number,Fax number and E-mail address.
]
Edit: Allows you to write a new message or edit the selected name card.
]
Send Via Text Message: Sends the selected name card by SMS.
]
Send Via Multimedia Message: Sends the selected name card by MMS.
]
Delete: Allows you to delete the selected name card.
Memory Status Menu 2.8
You can check the current memory status of each memory for SMS and
MMS.
67
66
You can access various WAP(Wireless Application Protocol) services such
as banking, news, weather reports, and flight information. These services are
specially designed for mobile phones and they are maintained by the WAP
service providers.
Check the availability of WAP services, pricing and tariffs with your
network operator and/or the service provider whose service you wish to use.
Service providers will also give you instructions on how to use their
services.
Please contact your service provider to open an Internet account. To use the
Web Browser, you must indicate your phone number via the Own number
menu option (See page 93 for further details.)
To launch the browser in standby mode, press and hold down the key.
Once connected, the homepage is displayed. The content depends on the
service provider.
You can open any WWW page by entering its URL address.
To exit the browser at any time, press the key. The idle screen is
displayed.
Navigating with the WAP Browser
You can surf the Internet using either the phone keys or the WAP Browser
menu.
Using the Phone Keys
When surfing the Internet, the phone keys function differently from the
phone mode.
Key Description
up/down navigation key Scroll each line of the content area
left navigation key Return to the previous page
Return to the startup homepage
MEdia Net MEdia Net
Using the WAP Browser Menu
There are various menu options available when surfing the Wireless Web.
]
Home: Connect the homepage which was set in active profile.
]
Bookmarks: Set the current homepage as a new bookmark or move the
established bookmark.
]
Forward: Move to previous page.
The following example shows the functionality of browser menu
‘Forward’.
1. Navigation Page A → Page B → Page C → Page D
2. On Page D, select a menu ‘Back’, it will place a user in Page C.
3. On Page C, if select a menu ‘Back’, move to Page B. else if select a
menu ‘Forward’, move to Page D again.
]
Go to URL: Connect to the specific URL after editing.
]
History: View all URL lists which have connected so far.
]
Save Items: Save the item in current page which you connect.
]
Snapshots: Save current page.
]
Messages: Save the short message or push message.
]
Reload: Connect the server again and then bring back the page.
]
Clear Cache: Remove all contexts saved in cache.
]
Mail Server: Set or move to the mail server.
]
Advanced: Set the specific item related to connect or display the
browser.
]
About: View the information of S/W version.
Note The WAP Browser menus may vary, depending on your version of the
browser.
69
68
MEdia Net MEdia Net
mMode Menu 3.1
Connect to a homepage. The homepage may be the site which is defined in
the activated profile. It will be defined by the Service Provider if you have
not defined it in the activated profile.
Bookmarks Menu 3.2
Your phone may have some pre-installed bookmarks for sites not affiliated
with LG. LG does not warrant or endorse these sites. If you choose to
access them, you should take the same precautions, for security or content,
as you would with any site.
Options in the Bookmarks view
Options available in the Bookmarks are: New Bookmark and New Folder
]
New Bookmark:
• Connect: Connect to the URL address to download the ringtone.
• View: Check the settings of profile.
• Edit: Modify the settings of profile.
• Move: Move the ringtone to the other folder.
• Delete: Delete the URL address.
• New Bookmark: Create new bookmark in current folder.
• New Folder: Create new sub-folder.
• Send URL: Allows the stored URL under Bookmark to be sent via
SMS to another person.
]
New Folder
• Open:
• Rename:
• Delete: Delete the URL address.
• Edit: Modify the settings of profile.
• New Bookmark: Create new bookmark in current folder.
• New Folder: Create new sub-folder.
Go To URL Menu 3.3
You can directly connect to the site you want. You need to enter a specific
URL.
Access Point Menu 3.4
A Profile is the network information used to connect to the internet.
]
Activate: Set a current profile as a default.
]
Settings: Edit the various items of the current profile.
]
Rename: Revise the name of profile.
]
Add New: Create new profile.
]
Delete: Delete the profile.
]
Delete All: Allows all Profiles within the Access Point to be deleted so
please take precaution prior to using this option.
mMode
1. Activate
2. Settings
3. Rename
4. Delete
5. Add New
6. Delete All
71
70
Cache Settings Menu 3.5
The information or services you have accessed are stored in the cache
memory of the phone.
Clear Cache (Menu 3.5.1)
Remove all contexts saved in cache.
Cache Check (Menu 3.5.2)
Set a value whether a connection attempt is made through cache or not.
Security Certificates Menu 3.6
A list of the available certificates is shown.
WAP Information Menu 3.7
The WAP Browser version is displayed.
Note A cache is a buffer memory, which is used to store data temporarily.
MEdia Net
Java is a technology developed by Sun Microsystems. Similar to the way
you would download the Java Applet using the standard Netscape or MS
Internet Explorer browsers, Java MIDIet can be downloaded using the
WAP enabled phone. Depending on the service provider, all Java based
programs such as Java games can be downloaded and run on a phone.
Once downloaded, the Java program can be viewed within the My Games
& Apps. menu where you can select, execute or delete. The Java program
files saved in the phone are in .JAD and .JAR formats.
My Games & Apps Menu 4.1
Games & Apps. menu displays the list of Java programs downloaded using
the WAP. All previous downloaded programs can be selected, deleted or
viewed in detail within the Games & Apps. menu. From the list within the
Application menu, the following options are available:
]
Open: Open the selected program. The list includes all Java programs
installed in the phone.
]
Delete: Delete the selected program. Once deleted, you will not be able
to restore the program unless it is downloaded again using the WAP.
]
Details: Display detailed information on the selected program. This
includes the program name, program size, program version, vendor
information and the website address or the URL.
]
Send Information: Selected Java MIDIet information such as MIDIet
name, size, version, vendor and jad URL can be sent via SMS.
Note The JAR file is a compressed format of the Java program and the JAD
file is a description file that includes all detailed information. From the
network, prior to download, you can view all detailed file descriptions
from the JAD file.
Warning Only J2ME (Java 2 Micro Edition) based programs will run in a
phone environment.
The J2SE (Java 2 Standard Edition) based programs will only run
in a PC environment.
Games & Apps.
73
72
Games & Apps.
View Information Menu 4.3
The downloaded programs using the WAP are stored in the phone
memory. There is a maximum memory capacity in a phone and once you
exceed this memory, you will not be able to store any more programs. The
View Information menu allows you to check the available memory
capacity in a phone.
Memory Status (Menu 4.3.1)
Displays maximum memory capacity and total available memory
information.
Java Version (Menu 4.3.2)
Displays current Java version.
Bookmarks Menu 4.2
When a new Java program is downloaded using the WAP, the address
from which a download takes place is known as a bookmark. The Java
menu includes a bookmark list for downloading Java programs and this
bookmark list can be viewed from the Bookmarks menu.
]
Connect: Selected address in the bookmark is used for data connection.
After successful connection, desired Java program can be downloaded
from the list.
]
View: Detailed information on a bookmark can be viewed such as name
of bookmark and address of bookmark.
]
Delete: Selected bookmark is deleted. Deleted bookmark cannot be
restored so caution is required when deleting bookmarks.
]
Edit: Selected bookmark can be edited. Editing a bookmark is done in
the order of URL ’ Title ’ Profile(Access Point) ’ User ID ’ Password.
When creating a new bookmark, same order is followed. The service
provider can require user ID and password information, but if none is
provided, no input is necessary.
]
Add New: New bookmark is added. If there is no Bookmark, you get a
display indicating that there is no Bookmark. Bookmarks can be added
by pressing the left soft key[Add].
]
Send URL: Selected bookmark URL can be sent via SMS.
]
Delete All: This deletes all of the selected bookmark as well as the
bookmarks directory within the My Games & Apps menu.
Games & Apps.
Note After selecting the Connect function to access the Java MIDlet
Provider’s server, you may choose one of many Java programs to
download and install into your phone. Once connected to the server,
the Go button can be pressed to view the JAD information on a desired
program. The Get button will begin the download and install process.
The download and install process will take place simultaneously and
once download is complete you can immediately run the Java program.
The installed Java program can be selected to run at a later time from
the Games & Apps. menu.
75
74
My Sounds Menu 5.1
The left soft key [Options] will bring up the following options.
]
Send Via Text Message: iMelody Sound can be sent via SMS.
]
Send Via Multimedia Message: Downloaded Sound can be sent via
MMS.
]
Set As Ring Tone: This sets the Ring Tone with currently selected
Sound.
]
Edit Title: This deletes the Title of currently selected Sound.
]
Delete: This deletes currently selected Sound.
]
Delete All: This deletes all sounds.
My Games Menu 5.2
For further details, see page 71 (Menu 4.1).
My Multimedia Contents Menu 5.3
The left soft key [Options] will bring up the following options.
]
Send Via Text Message: EMS Animation can be sent via SMS.
]
Send Via Multimedia Message: Downloaded Animation can be sent via
MMS.
]
Set As Wallpaper: Currently selected Animation can be set as a
Wallpaper.
]
Edit Title: Title of currently selected Animation can be edited.
]
Delete: Currently selected Animation can be deleted.
]
Delete All: All Animations can be deleted.
My Graphics Menu 5.4
The left soft key [Options] will bring up the following options.
]
Send Via Text Message: EMS Picture can be sent via SMS.
]
Send Via Multimedia Message: Downloaded Picture can be sent via
MMS.
]
Set As Wallpaper: Currently selected Picture can be set as a Wallpaper.
]
Edit Title: Title of currently selected Picture can be edited.
]
Delete: Currently selected Picture can be deleted.
]]
Delete All: All Pictures can be deleted.
My Gallery Menu 5.5
For further details, see page 43 (Menu 1.2).
My Folder My Folder
Note Sounds supplied as default can only be used under the Set As Ring
Tone mode.
Note Pictures supplied as default can only be used under the Set As
Wallpaper mode.
77
76
Received Calls Menu 6.3
This option lets you view the last 20 incoming calls. You can also:
• View the number if available and call it, or save it in the phonebook
• Enter a new name for the number and save both in the phonebook
• Send a message by this number
• Delete the call from the list
• Delete all incoming calls from the list
Delete Recent Calls Menu 6.4
Allows you to delete Missed, Received and Dialed call lists. You can
delete all call lists at one time.
Call Durations Menu 6.5
Allows you to view the duration of your incoming and outgoing calls. You
can also reset the call times. The following timers are available:
Last Call (Menu 6.5.1)
Length of the last call.
Received Calls (Menu 6.5.2)
Length of the incoming calls.
Dialed Calls (Menu 6.5.3)
Length of the outgoing calls.
All Calls (Menu 6.5.4)
Total length of all calls made and incoming calls since the timer was last
reset.
Recent Calls Recent Calls
You can check the record of missed, received, and dialed calls only if the
network supports the Calling Line Identification (CLI) within the service
area.
The number and name (if available) are displayed together with the date and
time at which the call was made. You can also view call times and costs.
Missed Calls Menu 6.1
This option lets you view the last 10 unanswered calls. You can also:
• View the number if available and call it, or save it in the phonebook
• Enter a new name for the number and save both in the phonebook
• Send a message by this number
• Delete the call from the list
• Delete all missed calls from the list
Dialed Calls Menu 6.2
This option lets you view the last 20 outgoing calls(called or attempted).
You can also:
• View the number if available and call it or save it in the phonebook
• Enter new name for the number and save both in the phonebook
• Send a message by this number
• Delete the call from the list
• Delete all incoming calls from the list
79
78
Set Tariff (Menu 6.7.2)
You can set the currency type and the unit price. Contact your service
providers to obtain charging unit prices. To select the Currency or 1 Unit
in this menu, you need the PIN2 code.
Auto Display (Menu 6.7.3)
This network service allows you to see automatically the cost of your last
calls. If you select On in Auto Display menu, you can see the cost of the
last call when the call is released.
Note When all units have been used, no calls can be made except emergency
calls. Depending on the SIM card, you need the PIN2 code to set a call
cost limit.
Data Information Menu 6.8
You can check the amount of data transferred over the network through the
GPRS information option. In addition, you can also view how much time
you are online.
WAP Information (Menu 6.8.1)
You can check the data volume and the duration through WAP.
External Device (Menu 6.8.2)
You can check the data volume and the duration through GPRS by using
an external device such as a serial port.
Total Data (Menu 6.8.3)
You can check the total amount of data through WAP and an external
device.
Notice GPRS General Packet Radio Service
Notice The actual time invoiced for calls by your service provider may vary,
depending upon network features, rounding-off for billing, and so
forth.
Call Costs Menu 6.6
Call costs allows you to check the cost of the last call or all calls. The call
costs are displayed separately for each SIM card. To reset the cost, you
need the PIN2 code.
The following options are available:
Last Call’s Cost (Menu 6.6.1)
Cost of the last call made.
All Calls’ Cost (Menu 6.6.2)
Total cost of all calls made since the cost counter was last reset. If the total
cost exceeds the maximum cost set, you will no longer be able to make any
calls, except calls to the emergency services, until you reset the counter.
Cost Settings Menu 6.7
Call Cost’s Limit (Menu 6.7.1)
This network service allows you to limit the cost of your calls by selected
charging units. If you select Read, the number of remaining unit is shown.
If you select Change, you can change your charge limit.
*
*
Notice The actual cost invoiced for calls by your service provider may vary,
depending upon network features, rounding-off for billing, tax, and
so forth.
Recent Calls Recent Calls
81
80
Calendar Menu 7.2
When you enter this menu a calendar will be displayed. Top of the
screen indicates sections for date. Square cursor is used to locate a
particular day. The under bar on the calendar indicates a schedule or
memo on that day. This function helps to remind you of the schedule and
memo. The phone will sound an alarm tone if it has been set for a
specific note.
For changing the day, month, and year.
]
View: Press the left soft key [Options] to delete or edit the note you
selected.
]
Edit: Allows you to edit the schedule.
]
Delete: Allows you to delete the schedule.
]
Add New: You can edit maximum of 30 characters and create up to 30
notes.
]
Calendar:Allows you to consult the calendar.
]
Scheduler Tone: The phone can sound an alarm tone when the
scheduled date for an event has been reached with this option.
Note Your phone should be switched on to use this function.
Key Description
up/down navigation key
left/right navigation key
key/ key
key/ key
Weekly
Daily
Yearly
Monthly
Alarm Clock Menu 7.1
Set the alarm to ring at a specific time. In the Alarm Clock menu, the
following options are available:
On: Set the time(hour and minute) for activating the alarm.
1. Enter the menu.
2. Select [On] by pressing the right/left navigation keys.
3. If you want to set the time for activating the alarm, press the down
navigation key.
4. Enter the required time, press the down navigation key.
5. The following options are available.
• Once: The alarm rings only once and is then deactivated.
• Daily: The alarm rings every day at the same time.
• Weekly: The alarm rings every week on the same day and at the same
time.
• Monthly: The alarm rings every month on the same day and at the
same time.
6. Allows you to select the alarm melody by using the right/left navigation
keys.
7. Press the left soft key [Set].
Off: Cancel the alarm.
Notice If this option is set to On, the alarm will ring at the specified time,
even when the phone is switched off.
To stop the alarm when it rings, open the phone and press the right
soft key[Quit].
Tools Tools
83
82
Voice Recording Menu 7.3
Allows you to record a memo. You can record up to 3 voice messages with
each message up to 30 seconds.
You can use the Voice Memo feature to:
• Play the recorded voice memos
• Delete one or all voice memos
1. Once recording is started, the message ‘Recording...’ and the remaining
time is displayed.
2. If you want to finish recording, press the left soft key [Save].
]
Play: Allows you to play back all memos recorded, starting with the
most recent memo. The screen displays the date and time when the
memo was recorded.
]
Delete: Allows you to delete a specific memo. All memos recorded are
played back, starting with the most recent one.
]
Record New: Allows you to record a memo.
]
Rename: Allows you to rename a specific memo.
]
Send Via Multimedia Message: Sends the selected voice memo by
MMS.
]
Delete All: Allows you to delete all memos. Press the left soft key[OK]
to confirm.
Note If all memo locations are full, you must delete an old memo before
recording a new one.
]
View All Schedules: Shows the notes that are set for all days. Use the
up/down navigation keys to browse through the note lists. You can use
the menu by press the left soft key [Options].
]
Go To Date: Allows you to jump to a specific date.
]
Delete Past: Delete past schedule event that has already been notified.
]
Delete All: Delete all schedules. You are asked to confirm your action.
Note You can see Edit, Delete,View all schedules, Delete past, and Delete
all menus dependent on setting of the schedule.
Tools Tools
85
84
World Time Menu 7.6
Allows you to check the current Greenwich Mean Time(GMT) and 51
major cities around the world, using the left/right navigation keys.
The screen shows the city name, current date and time.
To select the time zone in which you are located, proceed as follows:
1. Select the city corresponding to your time zone by pressing the left/right
navigation keys one or more times. The local date and time are
displayed.
2. Press the left soft key [Options].
3. If you want to set, press the key.
4. If you want to set Daylight Savings, press the key in
Options menu.
Note The time zone setting of each city in World time menu may be affected
by network condition.
Calculator Menu 7.4
Using this feature, you can use the phone as a calculator. The calculator
provides the basic arithmetic functions: addition, subtraction,
multiplication and division.
Using the Calculator
1. Enter the first number using the numeric keys.
2. Use the navigation keys to select a sign for calculation.
3. To calculate the result, press the left soft key [Result]or key.
The following options are available.
]
View: Allows you to view the memo.
]
Delete: Allows you to delete the memo. You can press the left soft key
[Options → Delete] to edit the memo displayed.
]
Edit: If you select a memo that already exists, you can press the left soft
key [Options → Edit] to edit the memo displayed.
]
Add New: Add a new memo, up to 20 memos and 40 characters per
each memo.
]
Delete All: Allows you to delete all memos. You are asked to confirm
your action.
Memo Menu 7.5
To write, edit and delete a memo on a specific date, proceed as follows.
1. Press the left soft key [Add].
2. Input the memo and press the left soft key [Options].
The following options are available.
]
Save: Allows you to save the memo.
]
T9 Languages: Allows you to select the T9 language to use in memo.
]
Exit Editor: Allows you to exit in memo editor.
Or
1. Select a Memo.
2. Press the left soft key [Options].
Note To include a decimal point, press the key.
Tools Tools
87
86
PC Sync PC Sync is a program for data exchange between PC and the
phone by a data cable. Therefore, if you want to use this function,
you have to buy the accessory kit.
IrDA port
IrDA port
Unit Converter Menu 7.7
This converts any measurement into a unit you want.
There are 4 types that can be converted into units: Length, Surface,
Weight, and Volume.
1. You can select one of four unit types by pressing the left soft key [Unit].
2. Select the standard value by using the left/right navigation keys.
3. Select the unit you want to convert by pressing the up/down navigation
keys.
4. You can check the converted value for the unit you want. Also, you can
input a decimal number by pressing the key.
Infrared Menu 7.8
This feature allows you to send or receive data/fax through the infrared
port. To use an infrared connection:
• Install the modem driver for receiving or sending the data/fax.
• Install the network dial-up software supplied by your service provider or
fax application program for a fax call on your PC.
• Configure and activate an IrDA-compliant infrared port on your PC.
• Activate the infrared feature on the phone; the symbol appears on the
right side at the bottom of the display.
• Dial the network service number given to you by the service provider.
If there is no communication between your phone and the IrDA-compliant
device within 30 seconds after activation of the feature, it is automatically
deactivated.
For further details, contact your service provider.
Tools Tools
89
88
Phonebook Phonebook
You can store phone numbers and their corresponding names in the memory
of your SIM card. In addition, you can store up to 255 numbers and names in
the phone memory. The SIM card and phone memories, although physically
separate, are used as if they were a single entity, called the phonebook.
Contact List Menu 8.1
1. When the idle screen is displayed, press the right soft key [Names].
2. Press the left soft key [Select].
3. If you want to edit, delete, copy an entry, or to add the voice to one, select
[Options].
4. Once you have found the required entry, press the to dial the number.
• View Detail: To view in detail the selected name.
• Delete: You can delete an entry.
• Write Text Message: You can write a text message. For further details,
see page 44.
• Write Multimedia Message: You can write a multimedia message. For
further details, see page 56.
• Edit: You can edit the name, mobile number, home number, office
number, E-mail, group, memo and picture by press the left soft key
[Select].
• Copy To Phone: You can copy an entry from SIM to phone or from phone
to SIM.
• Voice Tag: You can add voice to the entry or change the voice tag.
• Main Number: You can select the main number out of your mobile, home
or office numbers. Choose the one that is most often used. The main
number will be displayed first, if you set this.
Add New Menu 8.2
You can add a phonebook entry by using this function. Phone memory
capacity is 255 entries. SIM card memory capacity depends on the cellular
service provider. You can also save 20 characters of name in the phone
memory, and save characters in the SIM card. The number of characters is
dependent on the SIM.
1. Open the phonebook first by pressing the right soft key [Names] in
standby mode.
2. Scroll to highlight New Contact, and press the left soft key [Select].
3. Select the memory you want to save: SIM or Phone.
a. Enter a name and then press the down navigation key.
b. Enter a number and then press the down navigation key.
c. You can set a group for the entry by pressing the right/left navigation
key.
d. Press left soft key [Save].
Speed Dials Menu 8.3
You can assign any of the keys, to with a name list entry. You
can call directly by pressing this key for 2-3 seconds.
1. Open the phonebook first by pressing the right soft key [Names] in a
standby mode.
2. Scroll to Speed Dials, then press the left soft key [Select].
3. If you want to add a number to speed dial, select <Empty>. Then, you
can search the name from the phonebook.
4. Select the name from the speed dial. You can change and delete the
name. In addition, you can call by this number, write text message, and
multimedia message.
Note You can also scroll through the phonebook from the beginning, In idle
mode with the flip cover open, by pressing the down navigation key
directly.
91
90
Voice Tag List Menu 8.4
You can see all the phone numbers which contain voice. You can also call
directly by pressing the key. After selecting the phone number by
using the up/down navigation keys, press the left soft key [Options] and it
will offer the following submenus:
]
Listen: You can play back the voice attached to a phone number.
]
Change: You can change the voice attached to a phone number.
]
Remove: You can delete the voice attached to a phone number.
]
Call: You can call by selecting this submenu.
]
Add New Voice Tag: You can add a new voice to phone number.
]
Remove All: You can delete all the voice attached to a phone number.
Caller Groups Menu 8.5
There are 7 predefined groups as well as one additional group labeled
Others where you can create your own lists.
1. You can set the phone to ring in a specific way and display a preselected
graphic icon when a particular person calls you.
2. Scroll to Caller Groups then press the left soft key [Select] to enter this
menu.
3. Every Group list will be displayed : Family, VIP, Friends, Colleague,
Group 1, Group 2, Others.
4. Select the Group name that you want to manage by pressing
the left soft key [Options].
5. You will see the following submenus under the predefined groups
except for the Others group.
• Member List: Allows you to see the member list in the group.
• Group Ring Tone: Allows you to select the ring tone to be used when
you receive a voice phone call from a person in the group.
• Group Icon: Allows you to select the graphic icon to be displayed
when you receive a call from a person in the group.
• Add Member: Allows you to add the member to the group.
• Delete Member: Allows you to delete the member in the group.
• Rename: Allows you to assign a name to the group.
PhonebookPhonebook
Note The voice can only be attached to the main number which you set. For
example, if you change the main number, voice will be automatically
attached to the changed number. This means that you cannot attach
voice to mobile, office and home numbers simultaneously. You can add
a voice tag to a phone number in the SIM card. The voice tag can be
erased if you remove or change the SIM card.
93
92
PhonebookPhonebook
Copy All Menu 8.6
You can copy or move entries from the SIM card memory to the phone
memory and vice versa.
]
SIM To Phone: You can copy the entry from the SIM card to phone
memory.
]
Phone To SIM: You can copy the entry from the phone memory to the
SIM card.
The following options are available:
• Keep Original: When copying, Original Dial Number is kept.
• Delete Original: When copying, Original Dial Number will
be erased.
Delete All Menu 8.7
You can delete all entries in the SIM, Phone and Voice Tag List. This
function requires the security code except for Voice.
Press the key to return to the standby mode.
Information Menu 8.9
]
Service Dial Number: You can view the list of Service Dialing
Numbers (SDN) assigned by your network provider(If supported by the
SIM card). Such numbers include the emergency, directory assistance
and voice mail numbers.
1. Select the Service dial number option.
2. The names of the available services will be shown.
3. Use the up/down navigation keys to select a service. Press the key.
]
Memory Status: You can check how many names and numbers are
stored in the phonebook (SIM card and phone memories).
]
Own Number: Allows you to display your phone number in the SIM
card.
*
*
Settings Menu 8.8
1. Set Memory: Scroll to highlight the Set Memory option, then press the
left soft key [Select].
• If you select Variable when adding entry, the phone will ask where to
store.
• If you select SIM or Phone, the phone will store an entry to the SIM or
the phone.
2. View Options: Scroll to highlight the View Options option, then press
the left soft key [Select].
• If you select Names Only or With Picture, the phone will search an
entry by Name or the Number.
• If you select Names Only, no picture will be displayed with the entry
in the Contact List.
• If you select With Picture, a picture can be displayed with the entry in
the Contact List.
*:Shown only if supported by SIM card
95
94
Sounds Menu 9.1
You can use the Sound Settings feature to customize various settings, such
as the:
]
Ring melody, volume and type
]
Sounds made when you press a key, make an error or receive a message
My Ringtones (Menu 9.1.1)
This option allows you to select the required ring melody. You can choose
between many different melodies. If you have downloaded any sounds
from the Internet or received any ring tone messages, you can view the list
in this menu.
Volume (Menu 9.1.2)
]
Ringtone: To set the volume level for the ringing tones.
]
Key Tone: To set the volume level for keypad tones.
]
Power On Tone: This menu option allows you to select a melody that
the phone sounds when it is switched on
]
Call: This can adjust the volume level.
]
Ear Mic: When using the Ear Mic, volume level can be adjusted.
]
Car Kit: When using the Car Kit, volume level can be adjusted.
Message Alert Tones (Menu 9.1.3)
This menu option allows you to select how the phone informs you that a
new message has been received.
Key Tones (Menu 9.1.4)
This menu option allows you to select a tone that the phone sounds when
you press a key. You can select an option from Beep and Voice.
Voice Recording (Menu 9.1.5)
For further details, see page 83 (Menu 7.3).
Settings Settings
Note When the phone is in the Silent mode, you cannot change the sound
settings.
97
96
Display Menu 9.2
You can change the background image and the display style for Menu
Mode according to your preference.
My Wallpaper (Menu 9.2.1)
This option allows you to change the background image (wallpaper) to be
displayed in idle mode.
To change the background image, proceed as follows.
1. Scroll through the list by pressing the left or right navigation key.
You have various preset images available. You can also select the blank
background and any images downloaded from the Internet.
2. Press the left soft key [Select] when the required image is highlighted.
The selected image is displayed.
Backlight (Menu 9.2.2)
You can select whether or not the phone uses the backlight. A marginal
increase in the standby/talk time can be achieved by turning the backlight
off.
]
Main LCD
• Off means that the backlight is never on.
• 10 seconds turns the backlight off 10 seconds after the last key was
pressed.
• 30 seconds turns the backlight off 30 seconds after the last key was
pressed.
• 60 seconds turns the backlight off 60 seconds after the last key was
pressed.
• Always on turns the backlight always on while flip is opened.
]
Sub LCD
Off/10 seconds/30 seconds/60 seconds/Always on
Languages (Menu 9.2.3)
You can select the display language. When the language option is set to
Automatic, the language is automatically selected according to the
language of the SIM card used. English will be set if the language on the
SIM card is not supported in the phone.
Menu Style (Menu 9.2.4)
This option allows you to select the menu display style. You can choose
either Icon Style or List Style.
*
*:Shown only if supported by SIM card
SettingsSettings
99
98
Date & Time Menu 9.3
Set Date (Menu 9.3.1)
Allows you to enter the day, month and year. You can change the date
format via the Date Format menu option.
Format : Allows you to change the time and date formats.
Date Format (Menu 9.3.2)
YYYY/MM/DD(year/month/day)
DD/MM/YYYY(day/month/year)
MM/DD/YYYY(month/day/year)
Set time (Menu 9.3.3)
Allows you to enter the current time. You can choose the time format via
the Time Format menu option.
Time Format (Menu 9.3.4)
24 Hours/12 Hours
Auto Update (Menu 9.3.5)
Select On to set the phone to automatically update the time and date
according to the current time zone.
SettingsSettings
Call Settings Menu 9.4
To change the settings for call diverting:
Call Forwarding (Menu 9.4.1)
When this network service is activated, you can direct your incoming calls
to another number, for example, to your voice mailbox number. For
details, contact your service provider. Select one of the divert options, for
example, select If busy to divert voice calls when your number is busy or
when you reject incoming calls.
The following options are available:
]
All Voice Calls: Diverts voice calls unconditionally.
]
If Busy: Diverts voice calls when the phone is in use.
]
If No Reply: Diverts voice calls which you do not answer.
]
If Out Of Reach: Diverts voice calls when the phone is switched off or
out of coverage.
]
All Data Calls: Diverts to a number with a PC connection
unconditionally.
]
All Fax Calls: Diverts to a number with a fax connection
unconditionally.
• Activate: Activates the corresponding service.
- To Voice Mail: Forwards to voice mail center. This function does not
include All Data Calls and All Fax Calls menus.
- To Other Number: Inputs the number for diverting.
• Cancel: Cancels the corresponding service.
• View Status: Checks the status of the service.
]
Cancel All: Cancels all call divert service.
*
*:Shown only if supported by SIM card
101
100
Answer Mode (Menu 9.4.2)
Allows you to determine when to answer the phone.
]
Flip open: This option allows you to answer a call simply by opening
the flip.
]
Any key: You can answer an incoming call by pressing any key, except
the key.
]
Send Key Only: You can answer an incoming call by only pressing
the key.
Send My Number (Menu 9.4.3)
This network service allows you to set your phone number to be displayed
(On) or hidden (Off) from the person to whom you are calling. Select Set
By Network to reset the phone to the setting that you have agreed upon
with your service provider.
Call Waiting (Menu 9.4.4)
The network will notify you of a new incoming call while you have a call
in progress. Select Activate to request the network to activate call waiting,
Cancel to request the network to deactivate call waiting, or View Status,
to check if the function is active or not.
*
*
*:Shown only if supported by SIM card
SettingsSettings
Minute Minder (Menu 9.4.5)
This option allows you to specify whether the phone must beep every
minute during an outgoing call to keep you informed of the length of the
call.
Voice Dial (Menu 9.4.6)
You can make a phone call by saying a voice tag that has been added to a
contact card. Any spoken word(s) can be a voice tag. Before using voice
dialing, note that:
• Voice tags are not language dependent. They are dependent on the
speaker’s voice.
• Voice tags are sensitive to background noise. Record them and make
calls in a quiet environment.
• When recording a voice tag or making a call by using a voice tag, the
loudspeaker is in use. Hold the phone at a short distance away from your
mouth and face so that the proximity sensor does not turn the loudspeaker
off.
• Very short names are not accepted. Use long names and avoid similar
names for different numbers.
]
Automatic: You can enter the voice dial mode whenever you open the
flip.
]
Manual: You can enter the voice dial mode by holding down the
key.
Note You must say the name exactly as you said when you recorded it. This
may be difficult in, for example, a noisy environment or during an
emergency, so you should not rely solely upon voice dialing in all
circumstances.
103
102
Auto Redial (Menu 9.4.7)
Select On, and your phone will make a maximum of three attempts to
connect the call after an unsuccessful call attempt.
Closed User Group (Menu 9.4.8)
Closed user group is a network service that specifies the group of people
whom you can call and who can call you. For more information contact
your network operator or service provider. If a group index is specified, it
is used for all outgoing calls. If no group index is specified, the network
will use the preferential index (a specific index that is stored in the
network).
]
Preset: Setting the selected CUG Index.
]
On: Activating and editing the CUG Index.
]
Off: Deleting the selected CUG.
TTY (Menu 9.4.9)
The majority of users are Deaf, but commonly, a TTY is also used by Hard
of Hearing, Speech Impaired, and even Deaf and Blind individuals. When
you use a TTY, only one person can type at a time, and you should not
interrupt the other. Keep your sentences short and right to the point. If at
all possible, have a printer to facilitate your life. Try to avoid asking too
many questions at once.
Send DTMF (Menu 9.4.0)
You can send the DTMF (dual tone multi-frequency) tones of the number
on the display during a call.
This option is helpful for entering a password or account number when you
call an automated system, like a banking service.
*
*
Note TTY users must have a TTY/TDD device.
TTY: Tele Type writer
TTD: Telecommunication Device for the Deaf
*:Shown only if supported by SIM card
SettingsSettings
105
Security Menu 9.5
Various codes and passwords are used to protect the features of your
phone. They are described in the following sections (see pages 22~23)
PIN Code Request (Menu 9.5.1)
When the PIN code request feature is enabled, you must enter your PIN
each time you switch the phone on. Consequently, any person who does
not have your PIN cannot use your phone without your approval.
The following options are available:
• Enable: You must enter the PIN each time the phone is switched on.
• Disable: The phone connects directly to the network when you switch it
on.
Call Barring Service (Menu 9.5.2)
Call barring allows you to restrict from making and receiving calls with
your phone. For this function, you need the barring password, which you
can obtain from your service provider.
The following options are available:
]
All Outgoing: Calls cannot be made.
]
Outgoing International: International calls cannot be made.
]
Outgoing International Except Home Country: When abroad, calls
can be made only to numbers within the current country and to your
home country, which is where your home network provider is located.
]
All Incoming: Calls cannot be received.
]
Incoming When Abroad: Calls cannot be received when you are using
your phone outside your home service area.
Note Before disabling the PIN code request feature, you must enter your PIN
104
*
*:Shown only if supported by SIM card
]
Cancel All Barrings: All call barring settings are deactivated; calls can
be made and received normally.
]
Change Password: You can set and change the call barring password
obtained from your service provider using this option. You must enter
the current password before you can specify a new one.Once you have
entered a new password, you are asked to confirm it by entering it again.
Fixed Dial Number (FDN) (Menu 9.5.3)
Allows you to restrict your outgoing calls to selected phone numbers, if
this function is supported by your SIM card. The PIN2 code is required.
The following options are available:
]
Enable: You can only call phone numbers stored in the phonebook.
You must enter your PIN2.
]
Disable: You can call any number.
]
Number List: You can view the number list saved as fixed dial number.
Change Codes (Menu 9.5.4)
The Change codes feature allows you to change your current password to a
new one. You must enter the current password before you can specify a
new one.
You can change the access codes: Security Code, PIN1 Code, PIN2 Code
Note To use Call Barring service, you must input the network password.
When calls are barred, calls may be possible to certain emergency
numbers in some networks.
Note Not all SIM cards have a PIN2. If your SIM card does not, this menu
option is not displayed.
Note PIN: Personal Identification Number.
SettingsSettings
107
106
Connection Menu 9.6
Network Selection (Menu 9.6.1)
The Network Selection feature enables you to indicate whether the network
used when roaming(outside your home area) is selected Automatic,
Manual, and Preferred.
Automatic
Allows you to set the phone to automatically search for and select one of
the cellular networks available in your area.
The phone will be set to Automatic even though the power is off and on.
Manual
Allows you to select the desired network manually from a list of networks.
If the connection to the manually selected network is lost, the phone will
sound an error tone and ask you to select a network again. The selected
network must have a roaming agreement with your home network, that is,
the operator whose SIM card is in your phone. The phone lets you select
another network if the phone fails to access the selected network. If you
switch off the phone, the phone will be reset to Automatic.
Preferred
You can set a list of preferred networks the handset should attempt to
register with first, before attempting to register to any other networks. This
list is created from the handset’s predefined list of known networks.
World Phone (Menu 9.6.2)
GPRS Attach (Menu 9.6.3)
If you select Power On and you are in a network that supports packet data,
the phone registers to the GPRS network and sending short messages will
be done via GPRS. Also, starting an active packet data connection, for
example, to send and receive e-mail, is quicker. If you select When
Needed, the phone will use a packet data connection only if you start an
application or action that needs it. The GPRS connection is closed after it
is not used by any application.
Access Point (Menu 9.6.4)
Reset Access Point (Menu 9.6.5)
This allows Profile information to be restored to original setting. For
example, this option will restore the Profile that has been deleted by the
Delete All selection from the Access Point (Menu 3.4) submenu.
Reset Setting Menu 9.7
You can easily reset your phone to its default configuration. To do so,
proceed, as follows.
1. Select the Reset Settings menu option.
2. Enter the 4-digit phone password.
Note If there is no GPRS coverage and you have chosen Power on, the
phone will periodically try to establish a packet data connection.
Note You can select a network other than your home network only if it has a
valid roaming agreement with your home network.
SettingsSettings
Note The password is preset to 0000.
109
108
Please check to see if any problems you have encountered with the phone
are described in this section before taking the phone in for a service or
calling a service engineer.
QHow do I view the list of outgoing calls, incoming calls and missed
calls?
APress the key.
QHow do I clear all call history?
APress the left soft key[Menu] and then the key.
QHow do I view all numbers stored in memory?
APress right soft key[Names] and then .
QWhy is the connection inconsistent or not audible in certain areas?
AWhen frequency environment is unstable in a certain area, connection
may be inconsistent and not audible. Relocate to another area and try
again.
QWhy is the connection not consistent abruptly disconnects even when
established?
A When frequency is unstable or weak or if there are too many users,
connection may be cut off even after it was established. Please try again
later or attempt after relocating to other areas.
QWhy does the LCD not turn on?
A Remove the battery and turn on the power after placing it back on. If
there is no change, fully charge the battery and try again.
Q Why is there an echo when a connection is made with certain
telephones in a certain area?
AThis is called the ‘Echo Phenomenon’, where it occurs if connection
volume is too high or caused by special properties (semi electronic
telephone exchange) of the equipment on the other end.
QWhy does the phone heat up?
AThe phone may get hot when there is a very long call duration or when
games are played or even when surfing the Internet for a long time. This
has no effect upon the life of the product or performance.
QWhy is there no ring tone, but only a blinking LCD screen?
APhone may be set to ‘Vibrate only’ or in ‘Silent’ mode. In the Profiles
menu, please select ‘General’ or ‘Loud’.
Q Why does the battery life get shorter in standby mode?
A The battery is worn out. As time passes, the battery life gradually
becomes shorter. If the battery lasts about half the amount of time as
when first purchased, it’s time to purchase a new battery.
QWhy does the battery run out so quickly during normal use?
AIt is due to the user environment or a large number of calls or weak
signal.
Q&A Q&A
111
110
Travel Adapter
This adapter allows you to charge the battery.
It supports standard U.S. 120 Volt 60Hz
outlets.
It takes 5 hours to charge a completely
discharged battery.
Battery
Standard battery is available.
Vehicle Power Adapter
You can operate the phone and trickle charge
the phone battery from your vehicle by using
the vehicle power adapter.
It takes 5 hours to charge a completely
discharged battery.
There are a variety of accessories available for your mobile phone. You
can select these options according to your personal communication
requirements. Consult your local dealer for availability.
QWhy is no number dialed when you recall a phonebook entry?
A Check that the number has been stored correctly by using the Phone
book Search feature. Re-store them, if necessary.
QWhy can’t my correspondent reach me?
A Is you phone switched on ( pressed for more than three seconds)?
Are you accessing the right cellular network? Or, you may have set an
incoming call barring option.
QI cannot find the lock, PIN, or PUK code. What is my password?
A The default lock code is ‘0000’. If you forget or lose the lock code,
contact your phone dealer. If you forget or lose a PIN or PUK code, or
if you have not received such a code, contact your network service
provider
Settings Accessories
113
112
Headset
Connects to your phone, allowing hands-free
operation. Includes earpiece, microphone,
and integrated call answer/termination
button.
Data Cable Kit
Connects your phone to a PC.
TIA Safety Information
Provided herein is the complete TIA Safety Information for Wireless
Handheld phones. Inclusion of the text covering Pacemakers, Hearing
Aids, and Other Medical Devices is required in the owner’s manual for
CTIA Certification. Use of the remaining TIA language is encouraged
when appropriate.
Exposure to Radio Frequency Signal
Your wireless handheld portable telephone is a low-power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August, 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld wireless
phones. Those guidelines are consistent with the safety standards
previously set by both U.S. and international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986)
ICNIRP (1996)
Those standards were based on comprehensive and periodic evaluations of
the relevant scientific literature. For example, over 120 scientists,
engineers, and physicians from universities, government health agencies,
and industry reviewed the available body of research to develop the ANSI
Standard (C95.1).
*American National Standards Institute; National Council on Radiation
Protection and Measurements; International Commission on Non-Ionizing
Radiation Protection
The design of your phone complies with the FCC guidelines (and those
standards).
Antenna Care
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the phone and may
violate FCC regulations.
Accessories Safety Guidelines
115
Phone Operation
NORMAL POSITION: Hold the phone as you would any other telephone
with the antenna pointed up and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
]
Do not touch the antenna unnecessarily when the phone is in use.
Contact with the antenna affects call quality and may cause the phone to
operate at a higher power level than otherwise needed.
Driving
Check the laws and regulations on the use of wireless phones in the areas
where you drive. Always obey them. Also, if using your phone while
driving, please:
]
Give full attention to driving — driving safely is your first
responsibility;
]
Use hands-free operation, if available;
]
Pull off the road and park before making or answering a call if driving
conditions so require.
Electronic Devices
Most modern electronic equipment is shielded from RF signals. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6’) inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
114
Persons with pacemakers:
]
Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON;
]
Should not carry the phone in a breast pocket.
]
Should use the ear opposite the pacemaker to minimize the potential for
interference.
]
If you have any reason to suspect that interference is taking place, turn
your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your service provider.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
information.
Turn your phone OFF in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or health care facilities may
be using equipment that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any equipment that has been
added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so require.
Safety Guidelines Safety Guidelines
117
116
Aircraft
FCC regulations prohibit using your phone while in the air. Turn your
phone OFF before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF when
in a ‘blasting area’ or in areas posted: ‘Turn off two-way radio’. Obey all
signs and instructions.
Potentially Explosive Atmosphere
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always,
marked clearly. Potential areas may include: fueling areas (such as
gasoline stations); below deck on boats; fuel or chemical transfer or
storage facilities; vehicles using liquefied petroleum gas (such as propane
or butane); areas where the air contains chemicals or particles (such as
grain, dust, or metal powders); and any other area where you would
normally be advised to turn off your vehicle engine.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects, including
either installed or portable wireless equipment, in the area over the air bag
or in the air bag deployment area. If in-vehicle wireless equipment is
improperly installed and the air bag inflates, serious injury could result.
FDA Consumer Update
The U.S. Food and Drug Administration’s Center for Devices and
Radiological Health Consumer Update on Mobile Phones.
1.Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems
are associated with using wireless phones. There is no proof, however,
that wireless phones are absolutely safe. Wireless phones emit low levels
of radiofrequency energy (RF) in the microwave range while being used.
They also emit very low levels of RF when in the standby mode.
Whereas high levels of RF can produce health effects (by heating tissue),
exposure to low level RF that does not produce heating effects causes no
known adverse health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies have suggested that
some biological effects may occur, but such findings have not been
confirmed by additional research. In some cases, other researchers have
had difficulty in reproducing those studies, or in determining the reasons
for inconsistent results.
2.What is the FDA’s role concerning the safety of wireless
phones?
Under the law, the FDA does not review the safety of radiation-emitting
consumer products such as wireless phones before they can be sold, as it
does with new drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown to emit
radiofrequency energy (RF) at a level that is hazardous to the user. In
such a case, the FDA could require the manufacturers of wireless phones
to notify users of the health hazard and to repair, replace, or recall the
phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory
actions, the FDA has urged the wireless phone industry to take a number
of steps, including the following:
Safety Guidelines Safety Guidelines
119
118
]
Support needed research into possible biological effects of RF of the
type emitted by wireless phones;
]
Design wireless phones in a way that minimizes any RF exposure to the
user that is not necessary for device function; and
]
Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
The FDA belongs to an interagency working group of the federal agencies
that have responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies belong to
this working group:
o National Institute for Occupational Safety and Health
o Environmental Protection Agency
o Occupational Safety and Health Administration
o National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency working
group activities, as well.
The FDA shares regulatory responsibilities for wireless phones with the
Federal Communications Commission (FCC). All phones that are sold in
the United States must comply with FCC safety guidelines that limit RF
exposure. The FCC relies on the FDA and other health agencies for safety
questions about wireless phones.
The FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the
wireless phones themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than those they can get
from wireless phones. Base stations are thus not the subject of the safety
questions discussed in this document.
3.What kinds of phones are the subject of this update?
The term ‘wireless phone’ refers here to handheld wireless phones with
built-in antennas, often called ‘cell’, ‘mobile’, or ‘PCS’ phones. These
types of wireless phones can expose the user to measurable
radiofrequency energy (RF) because of the short distance between the
phone and the user’s head.
These RF exposures are limited by FCC safety guidelines that were
developed with the advice of the FDA and other federal health and safety
agencies. When the phone is located at greater distances from the user,
the exposure to RF is drastically lower because a person's RF exposure
decreases rapidly with increasing distance from the source. The so-called
‘cordless phones,’ which have a base unit connected to the telephone
wiring in a house, typically operate at far lower power levels, and thus
produce RF exposures far below the FCC safety limits.
4.What are the results of the research done already?
The research done thus far has produced conflicting results, and many
studies have suffered from flaws in their research methods. Animal
experiments investigating the effects of radiofrequency energy (RF)
exposures characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories. A few animal
studies, however, have suggested that low levels of RF could accelerate
the development of cancer in laboratory animals. However, many of the
studies that showed increased tumor development used animals that had
been genetically engineered or treated with cancer-causing chemicals so
as to be pre-disposed to develop cancer in the absence of RF exposure.
Other studies exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions under which people use
wireless phones, so we don’t know with certainty what the results of such
studies mean for human health.
Three large epidemiology studies have been published since December
2000. Between them, the studies investigated any possible association
between the use of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain or salivary gland,
Safety Guidelines Safety Guidelines
121
120
leukemia, or other cancers. None of the studies demonstrated the existence
of any harmful health effects from wireless phone RF exposures. However,
none of the studies can answer questions about long-term exposures, since
the average period of phone use in these studies was around three years.
5.What research is needed to decide whether RF exposure from
wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people
actually using wireless phones would provide some of the data that are
needed. Lifetime animal exposure studies could be completed in a few
years. However, very large numbers of animals would be needed to
provide reliable proof of a cancer promoting effect if one exists.
Epidemiological studies can provide data that is directly applicable to
human populations, but 10 or more years follow-up may be needed to
provide answers about some health effects, such as cancer. This is because
the interval between the time of exposure to a cancer-causing agent and the
time tumors develop — if they do — may be many, many years. The
interpretation of epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the angle at which the
phone is held, or which model of phone is used.
6.What is the FDA doing to find out more about the possible
health effects of wireless phone RF?
The FDA is working with the U.S. National Toxicology Program and with
groups of investigators around the world to ensure that high priority animal
studies are conducted to address important questions about the effects of
exposure to radiofrequency energy (RF).
The FDA has been a leading participant in the World Health Organization
International Electromagnetic Fields (EMF) Project since its inception in
1996. An influential result of this work has been the development of a
detailed agenda of research needs that has driven the establishment of new
research programs around the world. The project has also helped develop a
series of public information documents on EMF issues.
The FDA and the Cellular Telecommunications & Internet Association
(CTIA) have a formal Cooperative Research and Development
Agreement (CRADA) to do research on wireless phone safety. The FDA
provides the scientific oversight, obtaining input from experts in
government, industry, and academic organizations. CTIA-funded
research is conducted through contracts with independent investigators.
The initial research will include both laboratory studies and studies of
wireless phone users. The CRADA will also include a broad assessment
of additional research needs in the context of the latest research
developments around the world.
7.How can I find out how much radio frequency energy
exposure I can get by using my wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit radio
frequency energy (RF) exposures. The FCC established these guidelines
in consultation with the FDA and the other federal health and safety
agencies. The FCC limit for RF exposure from wireless telephones is set
at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6
W/kg). The FCC limit is consistent with the safety standards developed
by the Institute of Electrical and Electronic Engineering (IEEE) and the
National Council on Radiation Protection and Measurement. The
exposure limit takes into consideration the body’s ability to remove heat
from the tissues that absorb energy from the wireless phone and is set
well below levels known to have effects. Manufacturers of wireless
phones must report the RF exposure level for each model of phone to the
FCC. The FCC website (http://www.fcc.gov/oet/ rfsafety) gives
directions for locating the FCC identification number on your phone so
you can find your phone’s RF exposure level in the online listing.
8.What has the FDA done to measure the radio frequency
energy coming from wireless phones?
The Institute of Electrical and Electronic Engineers (IEEE) is developing
a technical standard for measuring the radio frequency energy (RF)
Safety Guidelines Safety Guidelines
123
122
exposure from wireless phones and other wireless handsets with the
participation and leadership of FDA scientists and engineers. The
standard, ‘Recommended Practice for Determining the Spatial-Peak
Specific Absorption Rate (SAR) in the Human Body Due to Wireless
Communications Devices: Experimental Techniques,’ sets forth the first
consistent test methodology for measuring the rate at which RF is
deposited in the heads of wireless phone users. The test method uses a
tissue-simulating model of the human head. Standardized SAR test
methodology is expected to greatly improve the consistency of
measurements made at different laboratories on the same phone. SAR is
the measurement of the amount of energy absorbed in tissue, either by
the whole body or a small part of the body. It is measured in watts/kg (or
milliwatts/g) of matter. This measurement is used to determine whether a
wireless phone complies with safety guidelines.
9.What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
If there is a risk from these products — and at this point we do not know
that there is — it is probably very small. But if you are concerned about
avoiding even potential risks, you can take a few simple steps to
minimize your exposure to radiofrequency energy (RF). Since time is a
key factor in how much exposure a person receives, reducing the amount
of time spent using a wireless phone will reduce RF exposure.
If you must conduct extended conversations by wireless phone every
day, you could place more distance between your body and the source of
the RF, since the exposure level drops off dramatically with distance. For
example, you could use a headset and carry the wireless phone away
from your body or use a wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless phones are
harmful. But if you are concerned about the RF exposure from these
products, you can use measures like those described above to reduce
your RF exposure from wireless phone use.
10.What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless
phones, including children and teenagers. If you want to take steps to
lower exposure to radiofrequency energy (RF), the measures described
above would apply to children and teenagers using wireless phones.
Reducing the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF exposure.
Some groups sponsored by other national governments have advised
that children be discouraged from using wireless phones at all. For
example, the government in the United Kingdom distributed leaflets
containing such a recommendation in December 2000. They noted that
no evidence exists that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit wireless phone use by
children was strictly precautionary; it was not based on scientific
evidence that any health hazard exists.
11.What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can interact with
some electronic devices. For this reason, the FDA helped develop a
detailed test method to measure electromagnetic interference (EMI) of
implanted cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard sponsored by the
Association for the Advancement of Medical instrumentation (AAMI).
The final draft, a joint effort by the FDA, medical device
manufacturers, and many other groups, was completed in late 2000.
This standard will allow manufacturers to ensure that cardiac
pacemakers and defibrillators are safe from wireless phone EMI.
The FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance requirements for
hearing aids and wireless phones so that no interference occurs when a
person uses a ‘compatible’ phone and a ‘compatible’ hearing aid at the
Safety Guidelines Safety Guidelines
125
124
same time. This standard was approved by the IEEE in 2000.
The FDA continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful interference be
found to occur, the FDA will conduct testing to assess the interference
and work to resolve the problem.
12.Where can I find additional information?
For additional information, please refer to the following resources:
FDA web page on wireless phones
(http://www.fda.gov/cdrh/phones/index.html)
Federal Communications Commission (FCC) RF Safety Program
(http://www.fcc.gov/oet/rfsafety)
International Commission on Non-lonizing Radiation Protection
(http://www.icnirp.de)
World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
National Radiological Protection Board (UK)
(http://www.nrpb.org.uk/)
Consumer Information on SAR
(Specific Absorption Rate)
This Model Phone Meets the Government’s Requirements for
Exposure to Radio Waves.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission
(FCC) of the U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were developed by
independent scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and
health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6W/kg. * Tests for SAR are conducted using
standard operating positions specified by the FCC with the phone
transmitting at its highest certified power level in all tested frequency
bands. Although SAR is determined at the highest certified power level,
the actual SAR level of the phone while operating can be well below the
maximum value. Because the phone is designed to operate at multiple
power levels to use only the power required to reach the network, in
general, the closer you are to a wireless base station antenna, the lower the
power output.
Before a phone model is available for sale to the public, it must be tested
and certified to the FCC that it does not exceed the limit established by the
government-adopted requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the ear and worn on the body)
as required by the FCC for each model. The highest SAR value for this
model phone when tested for use at the ear is 0.714 W/kg and when worn
Safety GuidelinesSafety Guidelines Safety Guidelines
127
126
on the body, as described in this user’s manual, is 0.482 W/kg. (Body-worn
measurements differ among phone models, depending upon available
accessories and FCC requirements.) While there may be differences
between SAR levels of various phones and at various positions, they all
meet the government requirement for safe exposure.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model phone is on file with
the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID BEJL1150.
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications Industry Association (CTIA) website
at http://www.wow-com.com
*In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in
measurements.
To help you understand the main technical terms and abbreviations used in
this booklet and take full advantage of the feature on your mobile phone,
here are a few definitions.
Call Barring
Ability to restrict outgoing and incoming calls.
Call Divert
Ability to reroute calls to another number.
Call waiting
Ability to inform users that they have an incoming call when engaged on
another call.
GPRS (General Packet Radio Service)
GPRS guaranties continuous connection to the Internet for mobile phone
and computer users. It is based on the Global System for Mobile
Communication (GSM) circuit-switched cellular phone connections and
the Short Message Service (SMS).
GSM (Global System for Mobile Communication)
International standard for cellular communication, guaranteeing
compatibility between the various network operators. GSM covers most
European countries and many other parts of the world.
Safety Guidelines Glossary
129
128
Java
Programming language generating applications that can run on all
hardware platforms, whether small, medium or large, without modification.
It has been promoted for and geared heavily to the Web, both for public
Web sites and Intranets. When a Java program runs from a Web page, it is
called a Java applet. When it is run on a mobile phone or pager, it is called
a MIDlet.
Line Identification Services (Caller ID)
Service allowing subscribers to view or block the telephone numbers of
callers.
Multiparty Calls
Ability to establish a conference call involving up to five additional parties.
Phone Password
Security code used to unlock the phone when you have selected the option
to lock it automatically each time it switches on.
Roaming
Use of your phone when you are outside your home area (when traveling
for example).
SDN (Service Dial Number)
Telephone numbers supplied by your network provider and giving access
to special services, such as voice mail, directory inquiries, customer
support and emergency services.
SIM (Subscriber Identification Module)
Card containing a chip with all the information required to operate the
phone (network and memory information, as well as the subscriber's
personal data). The SIM card fits into a small slot on the back of the phone
and is protected by the battery.
SMS (Short Message Service)
Network service sending and receiving messages to and from another
subscriber without having to speak to the correspondent. The message
created or received (up to 160 characters long) can be displayed, received,
edited or sent.
DATE: 2003.12.08
Patent Information
This product was manufactured under one or more of the following U.S.
patents: 5276765 5749067 6061647
Glossary Glossary
131
130
A
Access codes 25
Accessories 111
Active flip 14,15
Add new 89
Add member 91
Adjusting the volume 27
Alarm clock 80
All calls’ cost 78
Answering a call 27
Answer mode 100
Auto display 63,78
Auto redial 102
B
Backlight 16,96
Barring password 25
Battery 8,13,16,18,22,111
Bearer setting 48
Bookmarks 68,72
Business card 65
C
Cache check 70
Calculator 84
Calendar 81
Caller groups 91
Call barring service 104
Call costs 78
Call cost’s limit 78
Call divert 127
Call durations 77
Call waiting 35,100
Camera 75
Cancel all barrings 105
Change password 105
Clear cache 70
Clear key
14,
15
Closed user group 102
Conference calls 37
Copy all 92
CPHS
39,40,41
D
Delete recent calls 77
Delivery reports 48
Dialed calls 76,77
Display screen
14,
15
Display information 17
E
End key
14,
15
Ending a call 26
Entering text 28
F
FDN 105
Fixed dial number 105
Flip open 100
G
Games 71,74
Go to URL 67,69
GPRS 127
Group icon 91
Group ring tone 91
H
Headset 18,112
I
Inbox 46,57,62,63
In-call menu 35
Infrared 86
Infrared port
14,
15,16
L
Languages 64,97
Last call 77
Last call’s cost 78
Lower case 31
M
Making a Call 26
Making international calls 26
Manner Mode 28
Menu tree 39
Memo 84
Member list 91
Memory status
65,73,77
Message center url 60
Message key
14,
15
Message types 48
Microphone
14,
15
Minute minder 101
Missed calls 76
Muting the microphone 36
Multimedia messages 56
N
Navigation Key 14,15
O
Outbox 47,58
Own number 93
P
Phonebook 34,89
Phone to SIM 92
Power key
14,
15
Private call 38
Index Index
132
R
Received Calls 77
S
Security code 22,25
Send
14,
15,54,55,56,59,65
Send my number 100
Set memory 93
Service dial number 93,128
Scheduler tone 81
Shutter sound 42
Side keys
14,
15
Signal strength 28
SIM to phone 92
Speed dials 89
Sub LCD 23
T
Templates 64
Text messages 45
Time format 98
Travel adapter 111
U
Unit converter 80
Upper case 31
V
Valid period 47,60
Voice dial 101
Voice mailbox number 61
Voice memo key
14,
15
Voice messages 83
W
Wallpaper 96
WAP browser 67
WAP information 70,79
World time 85
Write message 45,56
1. Press the left soft key [Menu].
2. Scroll with the up/down navigation keys through the list of menus
until you reach the required menu.
3. Press the left soft key [OK].
4. Scroll with the up/down navigation keys through the list of options
until the required one is selected.
5. Press the left soft key [OK] to confirm.
Power on/off Press and hold .
Making a Call 1. Key in the number.
2. Press the key.
End a Call Briefly press the key.
Answer a Call Open the flip and
press the key.
Adjust the Volume Press the Side keys of
the phone.
Store numbers 1. Key in the number.
2. Press the left soft key [Options].
3. Press the left soft key [OK], [Select].
4. Enter the name.
5. Press the left soft key [Save].
Choose the 1. In standby mode, press left navigation
key.
2. Select an option:
Vibrate only, Silent, General, Loud.
3. Press the left/right navigation keys.
4. Press the key.
Search 1. Press the right soft key [Names].
2. Press the left soft key [OK].
3. Press the left soft key [Search].
(During a call)
in the Phonebook
Alert Type
Quick Reference Card
Access the Menu Function
Index
