LG Electronics USA L81AL Multi-band GSM/EDGE/WCDMA/LTE Phone with WLAN and Bluetooth User Manual LG 81AL TRF UG EN V1 0 151116 1
LG Electronics MobileComm USA, Inc. Multi-band GSM/EDGE/WCDMA/LTE Phone with WLAN and Bluetooth LG 81AL TRF UG EN V1 0 151116 1
Users Manual
Printed in China
www.lg.com
MFL69353301 (1.0)
LG L81AL
LG L81AL
USER GUIDE
www.lg.com
LG L81AL
LG L81AL
GUÍA DEL USUARIO
ENGLISH
ESPAÑOL
About this user guide
Thank you for choosing LG. Please carefully read this user guide before
using the device for the first time to ensure safe and proper use.
Ţ Always use genuine LG accessories. The supplied items are designed only for this
device and may not be compatible with other devices.
Ţ This device is not suitable for people who have a visual impairment due to the
touchscreen keyboard.
Ţ Descriptions are based on the device default settings.
Ţ Default apps on the device are subject to updates and support for these apps
may be withdrawn without prior notice. If you have any questions about an app
provided with the device, please contact a LG Service center. For user-installed
apps, please contact the relevant service provider.
Ţ Modifying the device’s operating system or installing software from unofficial
sources may damage the device and lead to data corruption or data loss. Such
actions will violate your LG licence agreement and void your warranty.
Ţ Some contents and illustrations may differ from your device depending on the
region, service provider, software version, or OS version, and are subject to
change without prior notice.
Ţ Software, audio, wallpaper, images, and other media supplied with your
device are licensed for limited use. If you extract and use these materials for
commercial or other purposes, you may be infringing copyright laws. As a user,
you are fully are entirely responsible for the illegal use of media.
Ţ Additional charges may apply for data services, such as messaging,
uploading,downloading, auto-syncing and location services. To avoid additional
charges, select a data plan suitable to your needs. Contact your service provider
to obtain additional details.
ENGLISH
2
Instructional notices
WARNING Situations that could cause injury to yourself or others, or
damage to phone or other property.
NOTE Notices or additional information.
3
LIMITED WARRANTY STATEMENT
ARBITRATION NOTICE: THIS LIMITED WARRANTY CONTAINS AN
ARBITRATION PROVISION THAT REQUIRES YOU AND LG TO RESOLVE
DISPUTES BY BINDING ARBITRATION INSTEAD OF IN COURT, UNLESS
YOU CHOOSE TO OPT OUT. IN ARBITRATION, CLASS ACTIONS AND
JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED
“PROCEDURE FOR RESOLVING DISPUTES” BELOW.
Warranty Laws
The following laws govern warranties that arise in retail sales of consumer
goods:
Ţ The California Song-Beverly Consumer Warranty Act [CC §§1790 et
seq],
Ţ The California Uniform Commercial Code, Division Two [Com C §§2101
et seq], and
Ţ The federal Magnuson-Moss Warranty Federal Trade Commission
Improvement Act [15 USC §§2301 et seq; 16 CFR Parts 701– 703].
A typical Magnuson-Moss Act warranty is a written promise that the
product is free of defects or a written promise to refund, repair, or
replace defective goods. [See 15 USC §2301(6).] Remedies include
damages for failing to honor a written warranty or service contract or
for violating disclosure provisions. [See 15 USC §2310(d).] Except for
some labeling and disclosure requirements, the federal Act does not
preempt state law. [See 15 USC §2311.]
4
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed subscriber unit and its
enclosed accessories will be free from defects in material and workmanship,
according to the following terms and conditions:
(1) The limited warranty for the product extends for TWELVE (12)
MONTHS beginning on the date of purchase of the product with
valid proof of purchase, or absent valid proof of purchase, FIFTEEN
(15) MONTHS from date of manufacture as determined by the unit's
manufacture date code.
(2) The limited warranty extends only to the original purchaser of the
product and is not assignable or transferable to any subsequent
purchaser/end user.
(3) This warranty is good only to the original purchaser of the product
during the warranty period as long as it is in the U.S., including Alaska,
Hawaii, U.S. Territories and Canada.
(4) The external housing and cosmetic parts shall be free of defects at
the time of shipment and, therefore, shall not be covered under these
limited warranty terms.
(5) Upon request from LG, the consumer must provide information to
reasonably prove the date of purchase.
(6) The customer shall bear the cost of shipping the product to the
Customer Service Department of LG. LG shall bear the cost of shipping
the product back to the consumer after the completion of service under
this limited warranty.
5
2. WHAT THIS WARRANTY DOES NOT COVER:
(1) Defects or damages resulting from use of the product in other than its
normal and customary manner.
(2) Defects or damages from abnormal use, abnormal conditions, improper
storage, exposure to moisture or dampness, unauthorized modifications,
unauthorized connections, unauthorized repair, misuse, neglect, abuse,
accident, alteration, improper installation, or other acts which are not
the fault of LG, including damage caused by shipping, blown fuses, spills
of food or liquid.
(3) Breakage or damage to antennas unless caused directly by defects in
material or workmanship.
(4) That the Customer Service Department at LG was not notified by
consumer of the alleged defect or malfunction of the product during
the applicable limited warranty period.
(5) Products which have had the serial number removed or made illegible.
(6) This limited warranty is in lieu of all other warranties, express or implied
either in fact or by operations of law, statutory or otherwise, including,
but not limited to any implied warranty of marketability or fitness for a
particular use.
(7) Damage resulting from use of non LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are
scratched or damaged due to normal customer use.
(9) Products operated outside published maximum ratings.
(10) Products used or obtained in a rental program.
(11) Consumables (such as fuses).
6
3. WHAT LG WILL DO:
LG will, at its sole option, either repair, replace or refund the purchase price
of any unit that is covered under this limited warranty. LG may choose at
its option to use functionally equivalent re-conditioned, refurbished or new
units or parts or any units. In addition, LG will not re-install or back-up
any data, applications or software that you have added to your phone. It
is therefore recommended that you back-up any such data or information
prior to sending the unit to LG to avoid the permanent loss of such
information.
4. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE DURATION
OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MARKETABILITY OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY
HEREIN. LG SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE
PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR
CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE,
THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY
OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
APPLICABLE TO THIS PRODUCT.
Some states do not allow the exclusive limitation of incidental or
consequential damages or limitations on how long an implied warranty
lasts; so these limitations or exclusions may not apply to you. This warranty
gives you specific legal rights and you may also have other rights which
7
vary from state to state.
5. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call or fax to the following telephone
numbers from anywhere in the continental United States:
Tel. 1-800-793-8896 or Fax. 1-800-448-4026
Or visit http://www.lg.com/us/support. Correspondence may also be mailed
to:
LG Electronics Service- Mobile Handsets, P.O. Box 240007, Huntsville, AL
35824
DO NOT RETURN YOUR PRODUCT TO THE ABOVE ADDRESS. Please
call or write for the location of the LG authorized service center nearest
you and for the procedures for obtaining warranty claims.
PROCEDURE FOR RESOLVING DISPUTES:
ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING
IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE
RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT
IN A COURT OF GENERAL JURISDICTION. BINDING ARBITRATION MEANS
THAT YOU AND LG ARE EACH WAIVING THE RIGHT TO A JURY TRIAL
AND TO BRING OR PARTICIPATE IN A CLASS ACTION.
Definitions. For the purposes of this section, references to “LG” mean LG
Electronics MobileComm U.S.A., Inc., its parents, subsidiaries and affiliates,
and each of their officers, directors, employees, agents, beneficiaries,
predecessors in interest, successors, assigns and suppliers; references to
“dispute” or “claim” shall include any dispute, claim or controversy of any
8
kind whatsoever (whether based in contract, tort, statute, regulation,
ordinance, fraud, misrepresentation or any other legal or equitable theory)
arising out of or relating in any way to the sale, condition or performance of
the product or this Limited Warranty.
Agreement to Binding Arbitration and Class Action Waiver. You and LG
agree to resolve any claims between us only by binding arbitration on an
individual basis, unless you opt out as provided below. Any dispute between
you and LG shall not be combined or consolidated with a dispute involving
any other person’s or entity’s product or claim. More specifically, without
limitation of the foregoing, any dispute between you and LG shall not under
any circumstances proceed as part of a class or representative action.
Instead of arbitration, either party may bring an individual action in small
claims court, but that small claims court action may not be brought on a
class or representative basis.
Arbitration Rules and Procedures. To begin arbitration of a claim, either you
or LG must make a written demand for arbitration. The arbitration will be
administered by the American Arbitration Association (AAA) and will be
conducted before a single arbitrator under the AAA’s Consumer Arbitration
Rules that are in effect at the time the arbitration is initiated (referred to
as the “AAA Rules”) and under the procedures set forth in this section. The
AAA Rules are available online at
www.adr.org/consumer. Send a copy of your written demand for arbitration,
as well as a copy of this provision, to the AAA in the manner described
in the AAA Rules. You must also send a copy of your written demand to
LG at LG Electronics, USA, Inc.Attn: Legal Department-Arbitration1000
9
Sylvan AvenueEnglewood Cliffs, NJ 07632. If there is a conflict between
the AAA Rules and the rules set forth in this section, the rules set forth in
this section will govern. This arbitration provision is governed by the Federal
Arbitration Act. Judgment may be entered on the arbitrator’s award in any
court of competent jurisdiction. All issues are for the arbitrator to decide,
except that issues relating to the scope and enforceability of the arbitration
provision and to the arbitrability of the dispute are for the court to decide.
The arbitrator is bound by the terms of this provision.
Governing Law: The law of the state of your residence shall govern this
Limited Warranty and any disputes between us except to the extent that
such law is preempted by or inconsistent with applicable federal law.
Fees/Costs. You do not need to pay any fee to begin an arbitration. Upon
receipt of your written demand for arbitration, LG will promptly pay all
arbitration filing fees to the AAA unless you seek more than $25,000 in
damages, in which case the payment of these fees will be governed by the
AAA Rules. Except as otherwise provided for herein, LG will pay all AAA
filing, administration and arbitrator fees for any arbitration initiated in
accordance with the AAA Rules and this arbitration provision. If you prevail
in the arbitration, LG will pay your reasonable attorneys’ fees and expenses
to the extent required by applicable law. If the arbitrator finds either the
substance of your claim or the relief sought in the demand is frivolous or
brought for an improper purpose (as measured by the standards set forth
in Federal Rule of Civil Procedure 11(b)), then the payment of all arbitration
fees will be governed by the AAA Rules. In such a situation, you agree to
reimburse LG for all monies previously disbursed by it that are otherwise
10
your obligation to pay under the AAA Rules. Except as otherwise provided
for, LG waives any rights it may have to seek attorneys’ fees and expenses
from you if LG prevails in the arbitration.
Hearings and Location. If your claim is for $25,000 or less, you may choose
to have the arbitration conducted solely on the basis of (1) documents
submitted to the arbitrator, (2) through a telephonic hearing, or (3) by an
in-person hearing as established by the AAA Rules. If your claim exceeds
$25,000, the right to a hearing will be determined by the AAA Rules. Any
in-person arbitration hearings will be held at a location within the federal
judicial district in which you reside unless we both agree to another location
or we agree to a telephonic arbitration.
Opt Out. You may opt out of this dispute resolution procedure. If you opt
out, neither you nor LG can require the other to participate in an arbitration
proceeding. To opt out, you must send notice to LG no later than 30
calendar days from the date of the first consumer purchaser’s purchase of
the product by either: (i) sending an e-mail to optout@lge.com, with the
subject line: “Arbitration Opt Out” or (ii) calling 1-800-980-2973.You must
include in the opt out e-mail or provide by telephone: (a) your name and
address; (b) the date on which the product was purchased; (c) the product
model name or model number; and (d) the IMEI or MEID or Serial Number,
as applicable (the IMEI or MEID or Serial Number can be found (i) on the
product box; (ii) on a label on the back of the product beneath the battery,
if the batter is removable;or (iii) from the settings menu via the following
path: Settings General About phone Status).You may only opt out of
the dispute resolution procedure in the manner described above (that is, by
11
e-mail or telephone); no other form of notice will be effective to opt out
of this dispute resolution procedure. Opting out of this dispute resolution
procedure will not affect the coverage of the Limited Warranty in any way,
and you will continue to enjoy the full benefits of the Limited Warranty. If
you keep this product and do not opt out, then you accept all terms and
conditions of the arbitration provision described above.
12
Features you will love ................. 16
Capture+ ..................................................17
Using Capture+ ............................................................17
Viewing the saved memo .......................................18
KnockON ..................................................19
Turning the screen on ...............................................19
Turning the screen off ..............................................19
Knock Code ..............................................20
Setting up the Knock Code feature .................20
Unlocking the screen using the Knock
Code ....................................................................................20
Basics .......................................... 21
Accessories ..............................................22
Phone layout ............................................23
Turning Your Phone On and Off ...............26
Installing the SIM or USIM card and
battery......................................................27
Charging the battery ...............................30
Inserting a memory card ..........................31
Removing the memory card .....................32
Locking and unlocking the device ............32
Changing the screen lock method....................33
Touch screen tips .....................................33
Tap or touch ...................................................................34
Touch and hold..............................................................34
Drag.....................................................................................35
Swipe or slide ................................................................35
Double-tap ...................................................................... 36
Pinch-to-Zoom .............................................................36
Google account setup ..............................37
Creating your Google account ............................37
Signing into your Google account.....................37
Locking and unlocking the device ............38
Changing the screen lock method....................38
Smart Lock......................................................................39
Home screen ............................................39
Getting to Know the Home Screen ................. 40
Returning to recently-used applications ...... 42
Customizing the Home screen ........................... 42
NotiŻcations panel ..................................................... 44
Capturing a screenshot ............................47
On-screen keyboard .................................47
Using the keypad and entering text ................ 47
Entering special characters...................................48
Table of contents
13
Transferring data between a PC and the
device .......................................................49
Transferring data using USB connection ......49
Apps ............................................ 50
Installing or uninstalling apps ..................51
To open the Play Store app ................................... 51
To open a screen with details about
an app ................................................................................ 51
To uninstall applications .......................................... 51
Calls .......................................................... 52
Making a call ..................................................................52
Calling your contacts ................................................ 52
Answering and rejecting a call ............................52
Making a second call ................................................. 53
Viewing your call logs ............................................... 53
Change your call settings ...................................... 54
Contacts ................................................... 55
Searching for a contact ........................................... 55
Adding a new contact .............................................. 55
Favorites contacts ......................................................55
Creating a group ..........................................................56
Messaging ................................................57
Sending a message .................................................... 57
Conversation view ...................................................... 58
Changing your messaging settings..................58
Browser ....................................................59
Using the Browser toolbar ....................................59
Viewing webpages ..................................................... 60
Opening a page ............................................................ 60
Searching the web by voice .................................. 60
Bookmarks ......................................................................60
History ............................................................................... 60
Camera .....................................................61
Taking a photo .............................................................. 61
Auto Mode on the viewŻnder .............................61
Interval shot ................................................................... 63
Burst shot ........................................................................ 63
Gesture shot .................................................................. 64
Multi-point Auto-focus ...........................................65
Once you have taken a photo ..............................65
Recording a video........................................................65
After recording a video ............................................66
Gallery ......................................................67
Viewing pictures ..........................................................67
Editing photos ..............................................................67
Setting wallpaper ........................................................68
Zooming in and out ................................................... 68
Playing a video .............................................................. 68
Deleting photos/videos ........................................... 70
Email ......................................................... 71
Adding an account ..................................................... 71
Working with account folders.............................71
14
Composing and sending email ............................ 71
Changing the Email app general settings .... 72
Deleting an email account ..................................... 72
Music ........................................................73
Playing a song ............................................................... 73
Music player options .................................................74
Clock ......................................................... 76
Alarms ............................................................................... 76
Timer...................................................................................76
World clock ..................................................................... 77
Stopwatch .......................................................................77
Calculator ................................................. 78
Calendar ...................................................78
Voice Recorder .........................................79
Recording a sound or voice ................................... 79
Downloads ................................................79
Google apps..............................................80
Settings ....................................... 82
Access the Settings menu ......................83
Wireless Networks ..................................84
Airplane mode ...............................................................84
Wi-Fi ...................................................................................84
Bluetooth .........................................................................85
Mobile data .....................................................................87
Call ....................................................................................... 87
Printing ..............................................................................88
Mobile networks .........................................................89
VPN ..................................................................................... 89
Emergency alerts ........................................................ 89
Device ....................................................... 90
Sound notiŻcation ................................................. 90
Display ............................................................................... 91
Home screen ..................................................................92
Lock screen .....................................................................92
Storage..............................................................................93
Battery & power saving .......................................... 94
Apps ....................................................................................94
Default message app ................................................ 95
Dual window ..................................................................95
Personal .................................................... 96
Location ............................................................................ 96
Security .............................................................................96
Accounts & sync ..........................................................97
Language & keyboard ............................................... 98
Backup & reset ............................................................. 99
System ....................................................100
Shortcut key ...............................................................100
Date & time .................................................................100
Accessibility ................................................................. 100
About phone ...............................................................102
15
Appendix ................................... 103
Phone software update .........................104
FAQ .........................................................106
Anti-Theft Guide ....................................110
More information ...................................111
Open Source Software Notice
Information ..................................................................111
Trademarks ..................................................................111
For Your Safety ......................... 112
Features you will love
Features you will love
Features you will love 17
Capture+
The Capture+ feature allows you to create memos.
Using Capture+
You can use Capture+ function to easily and efficiently create memos
during a call, with a saved picture or on the current phone screen.
1 Touch and slide the status bar downward and tap .
2 Create a memo using the following options:
Tap to save the memo you've created.
Tap to undo the most recent action.
Tap to redo the most recently deleted action.
Tap to insert text into your memo.
Tap to select the pen type and color.
Tap to use the eraser to erase the pen marks on the memo.
Tap to crop the image of memo.
Tap to select the share or paper style.
Tap to hide or display the toolbar.
Features you will love 18
NOTE
Ţ Please use a fingertip while using the Capture+ feature. Do not use your
fingernail.
3 Tap to save the current memo to the QuickMemo+ or the Gallery.
Viewing the saved memo
Tap > > and select the Capture+ album.
OR
Tap > > and select the desired memo.
Features you will love 19
KnockON
The KnockON feature allows you to double-tap the screen to easily turn it
on or off.
Turning the screen on
1 Double-tap the center of the Lock screen to turn the screen on.
2 Unlock the screen or access any of the available shortcuts or widgets.
Turning the screen off
1 Double-tap an empty area of the Home screen or the Status Bar.
2 The screen will turn off.
NOTE
Ţ Tap on the center area of the screen. If you tap on the bottom or the top area,
the recognition rate may decrease.
Features you will love 20
Knock Code
The Knock Code feature allows you to create your own unlock code using
a combination of knocks on the screen. You can access the Home screen
directly when the screen is off by tapping the same sequence on the
screen.
NOTE
Ţ If you enter the wrong Knock Code 6 times, you will be required to enter to your
Google account login info/backup PIN.
Ţ Use the fingertip instead of finger nail to tap the screen for turning it on or off.
Setting up the Knock Code feature
1 Tap > > > Lock screen > Select screen lock > Knock Code.
2 Tap the squares in a pattern to set your Knock Code. Your Knock Code
pattern can be 3 to 8 taps.
Unlocking the screen using the Knock Code
You can unlock the screen by tapping the Knock Code pattern you already
set, when the screen turns off.
BasicsBasics
Basics 22
Accessories
These accessories are available for use with the your phone.
Ţ Travel Adaptor
Ţ Quick Start Guide
Ţ USB Cable
Ţ Battery
NOTE
Ţ Items described below may be optional.
Ţ Always use genuine LG accessories. The supplied items are designed only for this
device and may not be compatible with other devices.
Ţ The items supplied with the device and any available accessories may vary
depending on the region or service provider.
Basics 23
Phone layout
Front Camera Lens
Proximity Sensor
Earpiece
Charger/USB PortHeadset Jack
Basics 24
Power/Lock Key
Speaker
Rear Camera Lens
Volume Keys
Flash
Power/Lock Key Ţ Turn your phone on/off by pressing and holding
this key.
Ţ Press once to turn the screen on/off.
Basics 25
Volume Keys While the screen is off:
Ţ Press the Volume Up Key twice to launch
Capture+.
Ţ Press the Volume Down Key twice to launch the
Camera.
On the Home screen:
Ţ Control ringer volume.
During a call:
Ţ Control your earpiece volume.
When playing audio/video:
Ţ Control volume continuously.
Basics 26
Turning Your Phone On and Off
Turning your phone on
Press and hold the Power/Lock Key on the back of the phone for a couple
of seconds until the screen turns on.
Turning your phone off
1 Press and hold the Power/Lock Key on the back of the phone until the
Phone options menu appears.
2 Tap Power off in the Phone options menu.
3 Tap OK to confirm that you want to turn off the phone.
Basics 27
Installing the SIM or USIM card and
battery
Insert the SIM or USIM card provided by the mobile telephone service
provider, and the included battery.
1 To remove the back cover, hold the phone firmly in one hand. With your
other hand, lift off the back cover with your thumbnail as shown in the
figure below.
Basics 28
2 Slide the SIM card into the SIM card slot as shown in the figure. Make
sure the gold contact area on the card is facing downward.
WARNING
Ţ Do not insert a memory card into the SIM card slot. If a memory card happens to
be lodged in the SIM card slot, take the device to a LG Service Centre to remove
the memory card.
NOTE
Ţ Only the nanoSIM cards work with the device.
Basics 29
3 Insert the battery.
4 To replace the cover onto the device, align the back cover over the
battery compartment and press it down until it clicks into place .
Basics 30
Charging the battery
Charge the battery before using it for first time. Use the charger to
charge the battery. A computer can also be used to charge the battery by
connecting the phone to it using the USB cable.
WARNING
Ţ Use only LG-approved chargers, batteries and cables. If you use unapproved
chargers, batteries or cables, it may cause battery charging delay. Or this can
cause the battery to explode or damage the device, which are not covered by
the warranty.
The charger connector is located at the bottom of the phone. Insert the
charger and plug it into a power outlet.
NOTE
Ţ Do not open the back cover while your phone is charging.
Basics 31
Inserting a memory card
Your device supports up to a 32GB microSD card. Depending on the
memory card manufacturer and type, some memory cards may not be
compatible with your device.
WARNING
Ţ Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the
data stored in it.
NOTE
Ţ Frequent writing and erasing of data shortens the lifespan of memory cards.
1 Remove the back cover.
2 Insert a memory card with the gold-coloured contacts facing downwards.
3 Replace the back cover.
Basics 32
Removing the memory card
Before removing the memory card, first unmount it for safe removal.
1 Tap > > > Storage > Unmount SD card.
2 Remove the back cover and pull out the memory card.
WARNING
Ţ Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or damage to
the memory card or device. It is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.
Locking and unlocking the device
Pressing the Power/Lock Key turns off the screen and puts the device
into lock mode. The device automatically gets locked if it is not used for a
specified period. This helps to prevent accidental taps and saves battery
power.
To unlock the device, press the Power/Lock Key and swipe the screen in
any direction.
NOTE
Ţ Double-tapping on the screen also can wake up the screen instead of the
Power/Lock Key.
Basics 33
Changing the screen lock method
You can change the way that you lock the screen to prevent others
accessing your personal information.
1 Tap > > > Lock screen > Select screen lock.
2 Select a desired screen lock from None, Swipe, Knock Code, Pattern, PIN
and Password.
Touch screen tips
Here are some tips on how to navigate on your phone.
NOTE
Ţ Do not press too hard; the tap screen is sensitive enough to pick up a light, yet
firm tap.
Ţ Use the tip of your finger to tap the option you want. Be careful not to tap any
other buttons.
Basics 34
Tap or touch
A single finger tap selects items, links, shortcuts and letters on the
on-screen keyboard.
Touch and hold
Touch and hold an item on the screen by tapping it and not lifting your
finger until an action occurs.
Basics 35
Drag
Touch and hold an item for a moment and then, without lifting your finger,
move your finger on the screen until you reach the target position. You can
drag items on the Home screen to reposition them.
Swipe or slide
To swipe or slide, quickly move your finger across the surface of the screen,
without pausing when you first tap it (so you don't drag an item instead).
Basics 36
Double-tap
Double-tap to zoom on a webpage or a map.
Pinch-to-Zoom
Use your index finger and thumb in a pinching or spreading motion to zoom
in or out when using the browser, Maps, or when viewing pictures.
Basics 37
Google account setup
The first time you open a Google application on your phone, you will be
required to sign in with your existing Google account. If you do not have a
Google account, you will be prompted to create one.
Creating your Google account
1 Tap > .
2 Tap > Accounts & sync > Add account > Google > Create a New
Account.
3 Enter your first and last name, then tap Next.
4 Enter a username and tap Next. Your phone will communicate with
Google servers and check for username availability.
5 Enter your password and tap Next.
6 Follow the instructions and enter the required and optional information
about the account. Wait while the server creates your account.
Signing into your Google account
1 Tap > .
2 Tap Accounts & sync > Add account > Google.
3 Enter your email address and tap Next.
4 After signing in, you can use Gmail and take advantage of Google
services on your phone.
Basics 38
5 Once you have set up your Google account, your phone will automatically
synchronise with your Google account on the web (if a data connection
is available).
After signing in, your phone will sync with your Google services, such as
Gmail, Contacts, and Google Calendar. You can also use Maps, download
applications from Play Store, back up your settings to Google servers, and
take advantage of other Google services on your phone.
Locking and unlocking the device
Pressing the Power/Lock Key turns off the screen and puts the device
into lock mode. The device automatically gets locked if it is not used for a
specified period. This helps to prevent accidental taps and saves battery
power.
To unlock the device, press the Power/Lock Key and swipe the screen in any
direction.
Changing the screen lock method
You can change the way that you lock the screen to prevent others
accessing your personal information.
1 Tap > > > Lock screen > Select screen lock.
2 Select a desired screen lock from None, Swipe, Knock Code, Pattern,
PIN and Password.
Basics 39
NOTE
Ţ Create a Google account before setting an unlock pattern and remember the
Backup PIN you created when creating your pattern lock.
Smart Lock
You can use Smart Lock to make unlocking your phone easier. You can set
it to keep your phone unlocked when you have a trusted Bluetooth device
connected to it, when it's in a familiar location like your home or work, or
when it recognizes your face or Trusted voice or On-body detection.
Setting up Smart Lock feature
1 Tap > > > Lock screen > Smart Lock.
2 Before you add any trusted devices, trusted places, or trusted face, you
need to set up a screen lock (Knock Code, Pattern, PIN or Password).
Home screen
The Home screen is the starting point for many applications and functions.
It allows you to add items like app shortcuts and Google widgets to give
you instant access to information and applications. This is the default
canvas and accessible from any menu by tapping .
Basics 40
Getting to Know the Home Screen
Home Touch Buttons
Status Bar
1
Widget
2
Application Icons
3
Location Indicator
4
Quick Button Area
5
6
1Status Bar - Shows the phone's status information, including the time,
signal strength, battery status and notification icons.
2Widget - Widgets are self-contained applications that can be accessed
through the Apps screen or on the Home screen. Unlike a shortcut, the
Widget can function as an on-screen application.
3Application Icons - Tap an icon (application, folder, etc.) to open and
use it.
4Location Indicator - Indicates which Home screen canvas you are
currently viewing.
5Quick Button Area - Provides one-touch access to the function in any
Home screen canvas.
Basics 41
6Home Touch Buttons
Back
Button
Returns to the previous screen. Also closes pop-up
items, such as menus, dialog boxes and the on-screen
keyboard.
Home
Button Return to the Home screen from any screen.
Overview
Button
Displays recently used applications. If you touch and
hold this button, it opens a menu of available options.
To view other Home screen panels
The operating system provides multiple Home screen canvases to provide
more space for adding icons, widgets and more.
Ţ Slide your finger left or right across the Home screen to access
additional canvases.
Basics 42
Returning to recently-used applications
Multitasking is easy with Android; you can keep more than one application
running at the same time. There is no need to quit an application before
opening another. Use and switch between several open applications.
Android manages each application, stopping and starting them as needed
to make sure that idle applications don't consume resources unnecessarily.
1 Tap . A list of recently used applications will be displayed.
2 Tap the application you want to access. This does not stop the previous
app from running in the background. Make sure to tap to back out of an
app after using it.
Ţ To close an app from the recent apps list, swipe the app preview to the
left or right. To clear all apps, tap Clear all.
Customizing the Home screen
You can customize your Home screen by adding apps and widgets and
changing wallpapers.
Adding items on your Home screen
1 Touch and hold the empty part of the Home screen.
2 In the Add Mode menu, select the item you want to add. You then see
this added item on the Home screen.
3 Drag it to the desired location and lift your finger.
Basics 43
NOTE
Ţ To add an application icon to the Home screen from the Apps screen, touch and
hold the application you want to add.
Removing an item from the Home screen
While on the Home screen, touch and hold the icon you want to remove >
drag it to .
Adding an app to the Quick Button Area
From the Apps screen or on the Home screen, touch and hold an
application icon and drag it to the Quick Button Area. Then release it in the
desired location.
Removing an app from the Quick Button Area
Touch and hold the desired Quick Button, drag it to .
NOTE
Ţ The Apps Button cannot be removed.
Customizing app icons on the Home screen
1 Touch and hold an application icon until it unlocks from its current
position, then release it. The editing icon appears in the upper-right
corner of the application.
2 Tap the application icon again and select the desired icon design and size.
3 Tap OK to save the change.
Basics 44
Notifications panel
Notifications alert you to the arrival of new messages, calendar events and
alarms, as well as ongoing events, such as when you are on a call.
Opening the notifications panel
Swipe down from the status bar to open the notifications panel. To close
the notifications panel, swipe the screen upwards or tap .
1
2
3
Quick Settings
Area
Notifications
Clear
1Tap each quick setting button to toggle it on/off. Touch and hold the
desired button to directly access the settings menu for the function. To
see more toggle buttons, swipe left or right. Tap to remove, add or
rearrange quick setting buttons.
2Current notifications are listed, each with a brief description. Tap a
notification to view it.
Basics 45
3Tap to clear all the notifications.
When a notification arrives, its icon appears at the top of the screen. Icons
for pending notifications appear on the left, and system icons, such as
Wi-Fi and battery strength are shown on the right.
Indicator icons on the Status Bar
Indicator icons appear on the status bar at the top of the screen to report
missed calls, new messages, calendar events, device status and more.
Pending
notifications
System
notifications
The icons displayed at the top of the screen provide information about the
status of the device. The icons listed in the table below are some of the
most common ones.
Icon Description Icon Description
No SIM card inserted A song is currently
playing
No network signal
available
No interruptions, not
even alarms
Basics 46
Airplane mode is on Vibrate mode is on
Connected to a Wi-Fi
network Battery fully charged
Wired headset
connected Battery is charging
Call in progress The phone is connected
to a PC via a USB cable
Missed call Downloading data
Bluetooth is on Uploading data
System warning GPS is on
An alarm is set Data is synchronizing
New voicemail available Choose input method
New text or multimedia
message
NOTE
Ţ The icon's location in the status bar may differ according to the function or
service.
Basics 47
Capturing a screenshot
Press and hold the Volume Down Key and the Power/Lock Key at the
same time for 2 seconds to capture a screenshot of the current screen.
To view the captured image, tap the > > > the Screenshots
folder.
On-screen keyboard
You can enter text using the on-screen keyboard. The on-screen keyboard
appears on the screen when you tap an available text entry field.
Using the keypad and entering text
Icon Description
Tap once to capitalize the next letter you type. Double-tap for
all caps.
Tap to go to the keyboard settings. Touch and hold to change
entering text method.
Tap to enter a space.
Tap to create a new line.
Tap to delete the previous character.
Basics 48
Entering special characters
The on-screen keyboard allows you to enter special characters.
For example, to input "á", touch and hold the "a" button until the pop-up
appears and displays related special characters. Without lifting the finger,
drag your finger to the desired special character. Once it's highlighted, lift
your finger.
NOTE
Ţ A symbol at the top right corner of a key indicates that additional characters are
available for that key.
Basics 49
Transferring data between a PC and the
device
You can copy or move data between a PC and the device.
Transferring data using USB connection
1 Connect your device to a PC using the USB cable that came with your
phone.
2 Open the Notifications panel, tap the current connection type, and select
Media`device MTP.
3 A window will pop-up on your PC, allowing you to transfer the desired
data.
NOTE
Ţ The LG Android Platform Driver is required to be installed on your PC to be able
to detect the phone.
Ţ Check the requirements for using Media device MTP.
Items Requirement
OS Microsoft Windows XP SP3, Vista or higher
Window Media Player
version Windows Media Player 10 or higher
AppsApps
Apps 51
Installing or uninstalling apps
Play Store allows you to browse and search for free and paid applications.
To open the Play Store app
Tap > > .
To open a screen with details about an app
At any time while browsing in Play Store, tap an app to open its details
screen.
The App details screen includes a description, ratings, comments, and
related information about the app. From this screen, you can download,
install, uninstall, rate the app, and more.
To uninstall applications
1 Tap > > > Apps.
2 Once all applications appear, scroll to and select the application you want
to uninstall.
3 Tap Uninstall.
Apps 52
Calls
You can enjoy clear calling across the region.
Making a call
1 Tap > .
2 Enter the number using the dialer. To delete a digit, tap .
3 After entering the desired number, tap to place the call.
4 To end the call, tap .
NOTE
Ţ To enter "+" to make international calls, touch and hold .
Calling your contacts
1 Tap > .
2 Scroll through the contact list. You can also enter the contact's name in
the Search field or scroll along the alphabet letters on the right edge of
the screen.
3 In the list that is displayed, tap the contact you want to call.
Answering and rejecting a call
Ţ Swipe in any direction to answer an incoming call.
Ţ Swipe in any direction to decline an incoming call.
Apps 53
NOTE
Ţ Swipe if you want to decline a call and send a message to the caller.
Making a second call
1 During your first call, tap > Add call and enter the number.
2 Tap .
3 Both calls are displayed on the call screen. Your initial call is locked and
put on hold.
4 Tap the displayed number to toggle between calls. Or tap to start a
conference call.
5 To end all calls, tap .
NOTE
Ţ You are charged for each call you make.
Viewing your call logs
1 Tap > > Call logs tab.
2 View a list of all dialed, received and missed calls.
NOTE
Ţ Tap any call log entry to view the date, time and duration of the call.
Ţ Tap > Delete all to delete all of the recorded items.
Apps 54
Change your call settings
You can configure phone call settings, such as call forwarding, as well as
other special features offered by your carrier.
1 Tap > .
2 Tap > Call settings and configure the desired options.
Apps 55
Contacts
You can add contacts on your phone and synchronize them with the
contacts in your Google Account or other accounts that support syncing
contacts.
Searching for a contact
1 Tap > .
2 Tap Search contacts and enter the contact name using the keyboard.
Matches are displayed as you begin to type.
Adding a new contact
1 Tap > .
2 Enter the new contact's number.
3 Tap > Add to Contacts > New contact.
4 If you want to add a picture to the new contact, tap the image icon.
Choose Take photo or Select from Gallery.
5 Enter the desired information for the contact.
6 Tap SAVE.
Favorites contacts
You can classify frequently called contacts as favorites.
Apps 56
Adding a contact to your favorites
1 Tap > .
2 Tap a contact to view its details.
3 Tap the star at the top right of the screen. The star turns yellow.
Removing a contact from your favorites list
1 Tap > > Favorites tab.
2 Choose a contact to view its details.
3 Tap the yellow star at the top right of the screen. The star turns a dark
color and the contact is removed from your favorites.
Creating a group
1 Tap > > Groups tab.
2 Tap > New group.
3 Enter a name for the new group. You can also set a distinct ringtone for
the newly created group.
4 Tap Add members to add contacts to the group and tap ADD.
5 Tap SAVE to save the group.
NOTE
Ţ If you delete a group, the contacts assigned to that group will not be lost. They
will remain in your contact list.
Apps 57
Messaging
Your phone combines text and multimedia messaging into one intuitive,
easy to use menu.
NOTE
Ţ You may be charged for each message you send. Please consult with your
service provider.
Sending a message
1 Tap > > .
2 Tap , then select one or more entries from your Contacts list.
OR
Enter a contact name or contact number into the To field. As you enter
the contact name, matching contacts appear. You can tap a suggested
recipient and add more than one contact.
3 Tap the text field and start entering your message.
4 Tap to open the options menu. Choose from any of the available
options.
5 Tap to attach the file that you want to share with message.
6 Tap Send to send your message.
Apps 58
Conversation view
Messages exchanged with another party are displayed in chronological
order so that you can conveniently see and find your conversations.
Changing your messaging settings
Your phone's messaging settings are predefined to allow you to send
messages immediately. You can change the settings based on your
preferences.
Ţ Tap > > > Settings.
Apps 59
Browser
Use this application to browse the Internet. The Browser gives you a fast,
full-color world of games, music, news, sports, entertainment and much
more, right on your mobile phone.
NOTE
Ţ Additional charges apply when connecting to these services and downloading
content. Check data charges with your network provider.
1 Tap > .
Using the Browser toolbar
Scroll towards the top of the webpage to access the browser toolbar.
Tap to go back one page.
Tap to go forward one page.
Tap to go to the Home page.
Tap to open a new window.
Tap to access your bookmarks.
Apps 60
Viewing webpages
Tap the address field, enter the web address and tap Go on the keyboard.
Opening a page
To open a new page, tap > .
To go to another webpage, tap , scroll up or down, and tap the page to
select it.
Searching the web by voice
In the browser, tap the address field and then tap . When prompted, say
a keyword and select one of the suggested keywords that appear.
NOTE
Ţ This feature may not be available depending on the region or service provider.
Bookmarks
To bookmark the current webpage, tap > Add bookmark > SAVE.
To open a bookmarked webpage, tap and select the desired bookmark.
History
Tap > History to open a list of recently-visited webpages. To clear all of
your history, tap > Yes .
Apps 61
Camera
You can use the camera or camcorder to take and share pictures and
videos.
Ţ Tap > > .
Taking a photo
1 Frame your subject on the screen.
2 A square around the subject indicates that the camera has focused.
3 Tap to take a photo. Your picture will be automatically saved to the
Gallery.
Auto Mode on the viewfinder
16
9
27
8
3
5
4
1Tap to hide/display the camera options on the viewfinder.
Choose from Simple, Auto.
Apps 62
2Allows you to manage the camera's flash.
3Tap to swap between the rear camera lens and the front camera
lens.
4Allows you to select the shot mode for the picture.
5Tap this icon to open the camera settings menu.
6Tap to view the last photo or video you recorded.
7Tap to start recording.
8Tap to take a photo.
9Tap to exit the camera.
Using the advanced settings
In the camera viewfinder, tap to show the advanced options. Tap each
icon to adjust the following camera settings.
Combines photos taken at multiple exposures into one
optimal photo to get a better photo in difficult lighting
situations.
Set the ratio of your picture and the quality of video.
Apps 63
Allows you to take pictures with voice commands. When on,
you just say "Cheese", "Smile", "LG", etc. to take a picture.
Set your camera's timer. This is ideal if you want to be a part
of the picture or video.
Allows you to take better pictures and record better videos by
displaying a grid line for help with alignment.
/
Set the storage location for your pictures and videos. Choose
from IN (internal memory) and SD (memory card). This menu
appears only when the SD card is inserted.
Allows you to learn how a function works. This icon will
provide you with a help guide.
Interval shot
You can take Interval shots from the Auto camera mode using the front
camera lens. Touch and hold to automatically take 4 selfies in a row.
Burst shot
You can take Burst shots from the Auto camera mode using the rear
camera lens. Touch and hold to take a barrage of photos in a row until
the Capture button is released. The viewfinder displays the number of shots
taken. When viewing Burst shots in the Gallery, tap to display each shot
in sequence (similar to a viewing flipbook).
Apps 64
Gesture shot
The Gesture shot feature allows you to take a picture with a hand gesture
using the front camera.
Taking the photos with a gesture
There are two methods for using the Gesture shot feature.
Ţ Raise your hand, with an open palm, until the front camera detects it
and a box appears on the screen. Then close your hand into a fist to
start the timer, allowing you time to get ready.
OR
Ţ Raise your hand, in a clenched fist, until the front camera detects it and
a box appears on the screen. Then unclench your fist to start the timer,
allowing you time to get ready.
OR
Apps 65
Multi-point Auto-focus
When you take a picture, the Multi-point Auto-focus (AF) function
operates automatically and will allow you to see a clear image.
Once you have taken a photo
Tap the image thumbnail on the screen to view the last photo you took.
Tap to edit the photo.
Tap to take another photo immediately.
Tap to open the available sharing options.
Tap to delete the photo.
Tap to access additional options.
Tap to add the photo to your favorites.
Recording a video
1 Tap > > .
2 Frame your subject on the screen.
3 Tap to start recording the video.
4 The length of the recording is displayed on the top of the screen.
Apps 66
NOTE
Ţ Tap to take pictures while recording video.
5 Tap to pause recording video. You can resume recording again by
tapping .
OR
Tap to stop recording. Your video will be automatically saved to the
Gallery.
After recording a video
Tap the video thumbnail on the screen to view the last video you recorded.
Tap to record another video immediately.
Tap to open the available sharing options (such as Messaging or
Bluetooth) to share.
Tap to delete the video.
Tap to access additional options.
Tap to add the video to your favorites
Apps 67
Gallery
The Gallery application presents the pictures and videos in your storage,
including those you've taken with the Camera application and those you
downloaded from the web or other locations.
1 Tap > > .
2 Tap an album to open it and view its contents. (The pictures and videos
in the album are displayed in chronological order.)
3 Tap a picture in an album to view it.
NOTE
Ţ Depending on the software installed, some file formats may not be supported.
Ţ Some files may not play properly due to their encoding.
Viewing pictures
The Gallery displays your pictures in folders. When an application, such as
E-mail, saves a picture, the download folder is automatically created to
contain the picture.
Pictures are displayed by the date they were created. Select a picture to
view it full screen. Scroll left or right to view the next or previous image.
Editing photos
While viewing a photo, tap .
Apps 68
Setting wallpaper
While viewing a photo, tap > Set image as to set the image as wallpaper
or assign it to a contact.
NOTE
Ţ Depending on the software installed, some file formats may not be supported.
Ţ If the file size exceeds the available memory, an error can occur when you open
files.
Zooming in and out
Use one of the following methods to zoom in on an image:
Ţ Double-tap anywhere to zoom in.
Ţ Spread two fingers apart on any place in the picture zoom in. Pinch in
or double-tap the image to zoom out.
Playing a video
1 Tap > > .
2 Select the video you want to watch.
Apps 69
Video options
123
4 5
6 7 8
1 Tap to pause/resume video playback.
2Touch and hold to fast-forward in 3 second increments.
Tap to fast-forward 10 seconds.
3Touch and hold to rewind in 3 second increments. Tap to
rewind 10 seconds.
4Tap to adjust the video volume.
5 Tap to lock/unlock the screen.
6Tap to add the video to your favorites.
7Tap to use QSlide for the Video app.
8Tap to access additional options.
Apps 70
NOTE
Ţ While playing a video, slide the right side of the screen up or down to adjust the
sound.
Ţ While playing a video, slide the left side of the screen up or down to adjust the
brightness.
Ţ While playing a video, slide your finger from left to right (or vice versa) to fast-
forward and rewind.
Deleting photos/videos
Use one of the following methods:
Ţ While in a folder, tap , select the photos/videos and then tap
DELETE.
Ţ While viewing a photo, tap .
Apps 71
Email
You can use the Email application to read email from providers other than
Gmail. TheEmail application supports the following account types: POP3,
IMAP, Microsoft Exchange (for Enterprise users) and other accounts.
• Tap > > .
Adding an account
The first time you open the Email application, a setup wizard opens to help
you add an email account. You can also add your email account using the
Settings menu.
• Tap > Settings > .
Working with account folders
• Tap > Show all folders.
Each account has Inbox, VIP, Sent, Drafts and Show all folders. Depending
on the features supported by your account's service provider, you may have
additional folders.
Composing and sending email
1 Tap .
2 Enter an address for the message's intended recipient. As you enter text,
matching addresses will be offered from your contacts. Separate multiple
addresses with semicolons.
Apps 72
3 Tap the Cc/Bcc field to copy or blind copy to other contacts/email
addresses.
4 Tap the text field and enter your message.
5 Touch and hold the text field to edit selected words. (Bold/Italic/
Underline/Color)
6 Tap to attach the file you want to send with your message.
7 Tap to send the message.
Changing the Email app general settings
Ţ Tap > Settings > General settings.
Deleting an email account
Ţ Tap > Settings > > Remove account > Select the account to
delete > REMOVE > YES.
Apps 73
Music
Your phone has a music player that lets you play all your favorite tracks.
NOTE
Ţ Depending on the software installed, some file formats may not be supported.
Ţ If the file size exceeds the available memory, an error can occur when you open
files.
Ţ Music file copyrights may be protected by international treaties and national
copyright laws. Therefore, it may be necessary to obtain permission or a licence
to reproduce or copy music. In some countries, national laws prohibit private
copying of copyrighted material. Before downloading or copying the file, please
check the national laws of the relevant country concerning the use of such
material.
Playing a song
1 Tap > > .
2 Tap the Songs tab.
3 Select the song you want to play.
4 The following options are available.
Apps 74
Music player options
Tap to pause playback.
Tap to resume playback.
Tap to skip to the next track in the album, playlist or shuffle list.
Touch and hold to fast-forward.
Tap to restart the current track or skip to the previous track in
the album, playlist or shuffle list. Touch and hold to rewind.
Tap to adjust the volume.
Tap to see all song list.
Apps 75
Tap to play the current playlist in shuffle mode (tracks are
played in random order).
Tap to toggle through repeat all songs, repeat current song and
repeat off.
Tap to add the song to your favorites.
Tap to open the current playlist.
Tap to access additional options.
Apps 76
Clock
The Clock app gives you access to the Alarms, Timer, World clock and
Stopwatch functions. Access these functions by tapping the tabs across
the top of the screen or swiping horizontally across the screen.
Ţ Tap > > .
Alarms
The Alarms tab allows you to set alarms.
1 Tap the Alarms tab.
2 Tap to add a new alarm.
3 Adjust the settings as necessary and tap SAVE.
NOTE
Ţ You can also tap an existing alarm to edit it.
Timer
The Timer tab can alert you with an audible signal when a set amount of
time has passed.
1 Tap the Timer tab.
2 Set the desired time on the timer.
3 Tap Start to start the timer.
4 Tap Stop to stop the timer.
Apps 77
World clock
The World clock tab allows you to easily check the current time in other
cities around the world.
1 Tap the World clock tab.
2 Tap and select the desired city.
Stopwatch
The Stopwatch tab allows you to use your phone as a stopwatch.
1 Tap the Stopwatch tab.
2 Tap Start to initiate the stopwatch.
Ţ Tap Lap to record lap times.
3 Tap Stop to stop stopwatch.
Apps 78
Calculator
The Calculator app allows you to perform mathematical calculations using a
standard or scientific calculator.
1 Tap > > .
2 Tap the number buttons to enter numbers.
3 For simple calculations, tap the function you want to perform (+, –, x or
÷) followed by =.
NOTE
Ţ For more complex calculations, tap > Scientific calculator.
Calendar
The Calendar app allows you to track your schedule of events.
1 Tap > > .
2 Tap the date you want to add an event to. Then tap .
Apps 79
Voice Recorder
The Voice Recorder app records audible files for you to use in a variety of
ways.
Recording a sound or voice
1 Tap > > .
2 Tap to begin recording.
3 Tap to end the recording.
4 Tap to pause the recording.
5 Tap to listen to the recording.
NOTE
Ţ Tap to access your recordings. You can listen to your saved recordings.
Downloads
Use this application to see what files have been downloaded through the
applications.
Ţ Tap > > .
Apps 80
Google apps
Google provides entertainment, social network, and business apps. You may
require a Google account to access some apps.
To view more app information, access each app’s help menu.
NOTE
Ţ Some apps may not be available depending on the region or service provider.
Google
Search quickly for items on the Internet or your device.
Chrome
Search for information and browse webpages.
Gmail
Send or receive emails via the Google Mail service.
Maps
Find your location on the map, search for locations, and view location
information for various places.
YouTube
Watch or create videos and share them with others.
Drive
Store your content on the cloud, access it from anywhere, and share it with
others.
Apps 81
Play Music
Discover, listen to, and share music on your device.
Play Movies & TV
Download various content to watch from the Play Store.
Hangouts
Chat with your friends individually or in groups and use images, emoticons,
and video calls while you are chatting.
Photos
Manage photos, albums, and videos that you have saved on the device and
uploaded to Google+.
Google Settings
Configure settings for some features provided by Google.
SettingsSettings
Settings 83
Access the Settings menu
The Settings app allows you to customize and personalize your phone.
Opening the settings app
Ţ Tap > touch and hold > System settings.
OR
Ţ Tap > > .
Settings 84
Wireless Networks
Airplane mode
Allows you to use many of your phone's features, such as games, and
music, when you are in an area where making or receiving calls or data use
is prohibited. When you set your phone to Airplane Mode, it cannot send or
receive any calls or access online data.
On the Settings screen, tap the Airplane mode.
Wi-Fi
You can use high-speed Internet access while within the coverage of the
wireless access point (AP).
On the Settings screen, tap the Wi-Fi.
1 Tap to turn Wi-Fi on and start scanning for available Wi-Fi
networks.
2 Tap a network to connect to it.
Ţ If the network is secured with a lock icon, you will need to enter a
security key or password.
3 The status bar displays icons that indicate Wi-Fi status.
NOTE
Ţ If you are out of the Wi-Fi zone or have set Wi-Fi to Off, the device may
automatically connect to the Web using mobile data, which may incur data
charges.
Settings 85
Bluetooth
Bluetooth is a short-range communications technology that allows you to
connect wirelessly to a number of Bluetooth devices, such as headsets and
hands-free car kits, and Bluetooth-enabled handhelds, computers, printers,
and wireless devices.
NOTE
Ţ LG is not responsible for the loss, interception or misuse of data sent or received
via the Bluetooth feature.
Ţ Always make sure that you share and receive data with devices that are trusted
and properly secured.
Ţ If there are obstacles between the devices, the operating distance may be
reduced.
Ţ Some devices, especially those that are not tested or approved by Bluetooth SIG,
may be incompatible with your device.
Pairing your phone with another Bluetooth device
1 On the Settings screen, tap the Bluetooth.
2 Tap to turn Bluetooth on and start scanning for available Bluetooth
devices.
Ţ If you want to detect the visible devices in range additionally, tap
SEARCH.
3 Choose the device you want to pair with from the list. Once the paring is
successful, your phone connects to the other device.
Settings 86
NOTE
Ţ Pairing between two Bluetooth devices is a one-time process. Once a pairing
has been created, the devices will continue to recognize their partnership and
exchange information.
Ţ Please consult documentation included with Bluetooth device for information on
pairing mode and passcode (typically 0 0 0 0 – four zeroes).
Sending data via Bluetooth
1 Select a file or item, such as a contact or media file.
2 Select the option for sending data via Bluetooth.
3 Search for and pair with a Bluetooth-enabled device.
NOTE
Ţ Due to different specifications and features of other Bluetooth-compatible
devices, display and operations may be different, and functions such as transfer
or exchange may not be possible with all Bluetooth compatible devices.
Receiving data via Bluetooth
1 On the Settings screen, tap the Bluetooth.
2 Tap to turn Bluetooth on.
3 You will receive a request to accept a pairing attempt from the sending
device. Be sure to select ACCEPT.
Settings 87
Mobile data
Displays the data usage and mobile data usage limit.
1 On the Settings screen, tap the Mobile data.
2 Tap to toggle your mobile data connection On or Off. This allows
you to manage your mobile data usage. You can use a Wi-Fi network
connection for data instead.
Call
Allows you to configure various call settings.
On the Settings screen, tap the Call.
Ţ Voicemail – Allows you to select your carrier's voicemail service.
Ţ Fixed dialing numbers – Allows you to manage and compile a list of
numbers that can be called from your phone. You need your PIN2,
which is available from your operator. If activated, only numbers in the
fixed dial list can be called from your phone.
Ţ Caller ID – Allows you to choose how to display your number in
outgoing calls.
Ţ Incoming voice call pop-up – Display incoming voice call popup when
using an app.
Ţ Decline with message – When you want to decline a call, you can
send a quick message using this function. This is useful if you need to
decline a call during a meeting.
Ţ Auto answer – Set the time before a connected hands-free device
automatically answers an incoming call.
Settings 88
Ţ Connection vibration – Vibrates your phone when the other party
answers the call.
Ţ TTY mode – Allows you to activate TTY mode.
Ţ Hearing aids – Allows you to turn on hearing aid compatibility.
Ţ Noise suppression – Suppress background noise on my end during a
call.
Ţ Power key ends call – Allows you to use the Power key to end calls.
Ţ Silence incoming calls – Enable to allow you to flip the device to
silence incoming calls.
Ţ Call duration – Allows you to view the call duration for various types
of calls.
Ţ Sound settings – Allows you to change settings for various sounds on
the device.
Ţ Additional settings – Allows you to change additional calling settings.
Printing
Allows you to print the content of certain screens (such as web pages
displayed in Chrome) to a printer connected to the same Wi-Fi network as
your Android device.
On the Settings screen, tap the Share & connect > Printing.
Settings 89
Printing via wireless printer
1 Select a file or item such as a contact or media file.
2 Select the option for sending data via Bluetooth.
3 Search for and pair with a Bluetooth-enabled device.
NOTE
Ţ Due to different specifications and features of other Bluetooth-compatible
devices, display and operations may be different, and functions such as transfer
or exchange may not be possible with all Bluetooth compatible devices.
Mobile networks
This menu allows you to configure various mobile network settings such as
Mobile data, Data roaming, etc.
On the Settings screen, tap the More > Mobile networks.
VPN
From your phone, you can add, set up, and manage virtual private networks
(VPNs) that allow you to connect and access resources inside a secured
local network, such as your corporate network.
On the Settings screen, tap the More > VPN.
Emergency alerts
If emergency alerts are issued, those alerts will appear on this screen.
On the Settings screen, tap the More > Emergency alerts.
Settings 90
Device
Sound & notification
Allows you to change settings for various sounds on the device.
On the Settings screen, tap the Sounds & notifications.
Ţ Sound profile – Allows you to set your phone's sound profile.
Ţ Volume – Adjust the phone's volume settings to suit your needs and
environment.
Ţ Ringtone – Allows you to set the ringtones for calls. You can also add
and delete ringtones.
Ţ Sound with vibration –
Enable to set the phone to vibrate in addition
to the ringtone when you receive calls.
Ţ Vibration type – Allows you to choose the type of vibration.
Ţ Interruptions – Allows you to set a schedule when to prevent
interruptions from notifications. You can set to allow certain features
to interrupt when Priority only is set.
Ţ Lock screen – Allows you to choose if you want to show or hide
notifications on the lock screen.
Ţ Apps – Allows you to set notifications for individual apps including
preventing them from displaying notifications and setting priority.
Ţ Notification LED - Tap the switch to toggle it On or Off. On activates
the LED light for the notifications you select, in the color you set for
each.
Settings 91
Ţ Notification sound – Allows you to set the notification sound. You can
also add and delete notification sounds.
Ţ Vibrate on tap – Enable to vibrate when tapping the Home touch
buttons and during other UI interactions.
Ţ Sound effects – This menu lets you select whether you hear tones
when tapping numbers on the dial pad, selecting on-screen options,
and more.
Ţ Message/call voice notifications – Allows your device to read out
incoming calls and message events automatically.
Display
Allows you to set other display settings.
On the Settings screen, tap the Display.
Ţ Font type – Select the desired font type.
Ţ Font size – Select the desired font size.
Ţ Brightness – Adjust the screen brightness by using the slider.
Ţ Auto-rotate screen – Set to switch orientation automatically when
you rotate the phone.
Ţ Screen timeout – Set the time delay before the screen automatically
turns off.
Ţ Home touch buttons – Set the Home touch buttons displayed at the
bottom of all screens. Set which buttons are displayed, their position
on the bar and what they look like.
Settings 92
Ţ Daydream – Select the screen saver to be displayed when the phone is
sleeping while docked and/or charging.
Ţ Motion sensor calibration – Allows you to improve the accuracy of the
tilt and speed of the sensor.
Home screen
Allows you to set your home screen settings.
On the Settings screen, tap the Home screen.
Ţ Wallpaper – Sets the wallpaper to use on your Home screen.
Ţ Screen swipe effect – Choose the desired type of effect to display
when you swipe from one Home screen canvas to the next.
Ţ Allow Home screen looping – Enable to allow continuous Home
screen scrolling (loop back to first screen after last screen).
Ţ Help – Displays help information for the Home screen.
Lock screen
Allows you to set your lock screen settings.
On the Settings screen, tap the Lock screen.
Ţ Select screen lock – Allows you to set a screen lock type to secure
your phone.
Ţ Smart Lock – Sets to keep your phone unlocked with trusted device
or a place. If you need more information, please refer to Smart Lock
section in Getting to know your phone.
Settings 93
Ţ Screen swipe effect – Sets the effect used when swiping the lock
screen.
Ţ Wallpaper – Select the wallpaper to display for your lock screen.
Ţ Shortcuts – Allows you to choose the shortcuts available on the lock
screen.
Ţ Contact info for lost phone – Allows you to display the owner
information on the lock screen in case the phone is lost.
Ţ Lock timer – Allows you to set the amount of time before the screen
automatically locks after the screen has timed-out.
Ţ Power button instantly locks – Checkmark to instantly lock the screen
when the Power/Lock Key is pressed. This setting overrides the lock
timer setting.
Storage
You can monitor the used and available internal memory in the device.
On the Settings screen, tap the Storage.
Internal storage
Ţ Total space – Displays the total amount of space and the available
space in your phone’s internal memory in text and with a color-coded
bar graph (unused space is gray). Corresponding apps and the amount
of space they use is listed under each device user.
Settings 94
SD card
Ţ Total space – Displays the total amount of space and the remaining
available space in your memory card.
Ţ Mount/Unmount SD card – Allows you to mount or unmount your SD
card.
Ţ Erase SD card – Allows you to erase all of the data on your SD card.
Battery & power saving
Displays the current battery status including the percentage of remaining
charge and charging state.
On the Settings screen, tap the Battery & power saving.
Ţ Battery usage – Displays the battery usage level and battery use
details. Tap one of the items to see more detailed information.
Ţ Battery percentage on status bar – Checkmark to display the battery
level percentage on the Status Bar next to the Battery icon.
Ţ Battery saver – Tap the Battery Saver switch to toggle it on or off.
Sets the battery charge percent level that automatically turns on
Battery Saver.
Apps
Allows you to view details about the apps installed on your phone, manage
their data, and force them to stop.
On the Settings screen, tap the Apps.
Settings 95
Default message app
This menu allows you to set your default messaging app as desired.
On the Settings screen, tap the Default message app.
Dual window
Allows you to configure the Dual Window feature.
Ţ Auto-open – Checkmark to allow you to tap a link on the full screen or
attachments Al from emails to open Dual window.
Ţ Help – Display tips for using Dual window.
Settings 96
Personal
Location
Turn on location service, your phone determines your approximate location
using Wi-Fi and mobile networks. When you select this option, you're
asked whether you consent to allowing Google to use your location when
providing these services.
On the Settings screen, tap the Location.
Ţ Mode – Sets the how your current location information is determined.
Ţ Recent Loation Request - Displays apps that have recently requested
location information.
Ţ Camera – Enable to tag photos or videos with their locations.
Ţ Google Location History – Allows you to choose your location
information settings as accessed by Google and its products.
Security
Use this menu to configure how to help secure your phone and its data.
On the Settings screen, tap the Security.
Ţ Content lock – Select lock types to lock memos for QuickMemo+.
Ţ Encrypt phone – Allows you to encrypt data on the phone for security.
You will be required to enter a PIN or password to decrypt your phone
each time you power it on.
Settings 97
Ţ Encrypt SD card storage – Encrypt SD card storage and keep data
unavailable for other devices.
Ţ Set up SIM card lock – Sets the PIN to lock your SIM card and allows
you to change the PIN.
Ţ Password typing visible – Enable to briefly show each character of
passwords as you enter them so that you can see what you enter.
Ţ Phone administrators – View or deactivate phone administrators.
Ţ Unknown sources – Allow installation of non-Play Store applications.
Ţ Verify apps – Disallow or warn before installation of apps that may
cause harm.
Ţ Storage type – Displays the current storage type.
Ţ Certificate management – Allows you to manage your security
certificates.
Ţ Trust agents – Select apps to use without unlocking screen.
Ţ Screen pin – You can enable your device to only show a certain app's
screen using screen pin.
Ţ App usage access – Allows you to view usage information of apps on
your phone.
Accounts & sync
Use this menu to add, remove, and manage your Google and other
supported accounts. You also use these settings to control how and
whether all applications send, receive, and sync data on their own schedules
and whether all applications can synchronize user data automatically.
Settings 98
On the Settings screen, tap the Account & sync.
Gmail™, Calendar, and other applications may also have their own
settings to control how they synchronize data; see the sections on those
applications for details.
Ţ Auto-sync data – Enable this option to automatically sync all accounts
you’ve added on your phone.
Ţ ACCOUNTS – Displays all of your added accounts. Tap one to view and/
or manage it.
Ţ ADD ACCOUNT – Tap to add new account.
Language & keyboard
Allows you to change the text input settings.
On the Settings screen, tap the Language & keyboard.
Select the language for the text on your phone and for configuring the
on-screen keyboard, including words that you've added to its dictionary.
Ţ Language – Choose a language to use on your phone.
Ţ Current keyboard – Allows you to select the other keyboard type.
Ţ LG Keyboard – Change the LG Keyboard settings.
Ţ Google voice typing – Enable to select Google voice typing to enter
data. Tap the Settings icon to change the Google voice settings.
Ţ Voice Search – Tap to configure the Voice Search settings.
Ţ Text-to-speech output – Tap to set the preferred engine or general
settings for text-to-speech output.
Ţ Pointer speed – Adjust the pointer speed.
Settings 99
Ţ Reverse buttons – Reverse the mouse buttons to use primary button
on the right.
Backup & reset
Change the settings for managing your settings and data.
On the Settings screen, tap the Backup & reset.
Ţ Back up my data – Back up app data, Wi-Fi passwords, and other
settings to Google servers.
Ţ Backup account – Displays the account that is currently being used to
back up information.
Ţ Automatic restore – When reinstalling an app, restore backed up
settings and data.
Ţ Factory data reset – Reset your settings to the factory default values
and delete all your data. If you reset the phone this way, you are
prompted to re-enter the same information as when you first started
Android.
Settings 100
System
Shortcut key
Get quick access to apps by pressing the Volume Keys twice when the
screen is off or locked.
On the Settings screen, tap the Shortcut key.
Ţ Press and hold both Volume Keys when screen unlocked to open the
Capture+ app.
Ţ Press either Volume key twice when screen locked or off to launch the
Camera app.
Date & time
Set your preferences for how the date and time is displayed.
On the Settings screen, tap the Date & time.
Accessibility
Use the Accessibility settings to configure accessibility plug-ins you have
installed on your phone.
On the Settings screen, tap the Accessibility.
Ţ Vision – Sets options for people with impaired sight.
- TalkBack – Allows you to set up the TalkBack function which assists
people with impaired vision by providing verbal feedback.
- Message/call voice notifications – Enable to allows you to hear
automatic spoken alerts for incoming calls and messages.
Settings 101
- Screen shade – Enable to set the screen to a darker contrast.
- Font size – Sets the font size.
- Touch zoom – Allows you to zoom in and out by triple-tapping the
screen.
- Screen color inversion – Enable to invert the color of the screen and
content.
- Screen color adjustment – Allows you to adjust the color of screen
and content.
- Screen color filter – Allows you to change the colours of screen and
content.
- Power key ends call – Enable so that you can end voice calls by
pressing the Power/Lock Key.
Ţ Hearing – Sets options for people with impaired hearing.
- Captions – Allows you to customize caption settings for those with
hearing impairments.
- Notification LED - Tap the switch to toggle it On or Off. On activates
the LED light for the notifications you select, in the color you set for
each.
- Flash alerts – Enable to set the flash to blink for incoming calls and
notifications.
- Turn off all sounds – Enable to turn off all device sounds.
- Audio type – Sets the audio type.
- Sound balance – Sets the audio route. Move the slider on the slide
bar to set it.
Ţ Motor & cognition – Sets options for people with impaired motor
skills.
Settings 102
- Touch feedback time – Sets the touch feedback time.
- Touch assistant – Show a touch board with easy access to common
actions.
- Screen timeout – Sets the amount of time before the backlight
turns off automatically.
- Touch control areas – Allows you to select an area of the screen to
limit touch activation to just that area of the screen.
Ţ Accessibility features shortcut – Allow you to access selected
features quickly when triple-tapping the Home button.
Ţ Auto-rotate screen – Enable to allow the phone to rotate the screen
depending on the physical phone orientation (portrait or landscape).
Ţ Switch Access – Allows you to interact with your device using one or
more switches that work like keyboard keys. This menu can be helpful
for users with mobility limitations that prevent them from interacting
directly with the your device.
About phone
View legal information, check phone status and software versions, and
perform a software update.
On the Settings screen, tap the About phone.
AppendixAppendix
Appendix 104
Phone software update
LG Mobile phone software update from the Internet
For more information about using this function, please visit
http://www.lg.com/common/index.jsp select your country and language.
This feature allows you to conveniently update the firmware on your phone
to a newer version from the Internet without needing to visit a service
center. This feature will only be available if and when LG makes a newer
firmware version available for your device.
Because the mobile phone firmware update requires the user's full
attention for the duration of the update process, please make sure
you check all instructions and notes that appear at each step before
proceeding. Please note that removing the USB data cable during the
upgrade may seriously damage your mobile phone.
NOTE
Ţ LG reserves the right to make firmware updates available only for selected
models at its own discretion and does not guarantee the availability of the
newer version of the firmware for all handset models.
LG Mobile Phone software update via Over-the-Air (OTA)
This feature allows you to conveniently update your phone's software
to a newer version via OTA, without connecting using a USB data cable.
This feature will only be available if and when LG makes a newer firmware
version available for your device.
Appendix 105
You should first check the software version on your mobile phone: Settings
> About phone > Update Center > Software Update > Update now.
NOTE
Ţ Your personal data from internal phone storage—including information about
your Google account and any other accounts, your system/application data and
settings, any downloaded applications and your DRM licence—might be lost in
the process of updating your phone's software. Therefore, LG recommends that
you backup your personal data before updating your phone's software. LG does
not take responsibility for any loss of personal data.
Ţ This feature depends on your network service provider, region and country.
Appendix 106
FAQ
This chapter lists some problems you might encounter when using your
phone. Some problems require you to call your service provider, but most
are easy to fix yourself.
Message Possible causes Possible corrective measures
SIM card
error
There is no SIM card
in the phone or it is
inserted incorrectly.
Make sure that the SIM card is
correctly inserted.
No network
connection/
Dropped
network
Signal is weak or
you are outside the
carrier network.
Move toward a window or into an
open area. Check the network operator
coverage map.
Operator applied
new services.
Check whether the SIM card is more
than 6~12 months old. If so, change
your SIM or USIM card at your network
provider's nearest branch. Contact your
service provider.
Appendix 107
Message Possible causes Possible corrective measures
Codes do
not match
To change a security
code, must need
to confirm the new
code by re-entering
it. If you forget the code, contact your
service provider.
The two codes you
entered do not
match.
No
applications
can be set
Not supported by
service provider or
registration required.
Contact your service provider.
Downloaded
application
causes a lot
of errors.
Remove the
application.
1 Tap > > .
2 Tap Apps.
3 Tap the app > Uninstall.
Calls not
available
Dialing error New network not authorized.
New SIM card
inserted. Check for new restrictions.
Pre-paid charge limit
reached.
Contact service provider or reset limit
with PIN2.
Appendix 108
Message Possible causes Possible corrective measures
Phone
cannot be
turned on
On/Off key pressed
too briefly.
Press the On/Off key for at least two
seconds.
Battery is not
charged.
Charge battery. Check the charging
indicator on the display.
Charging
error
Battery is not
charged. Charge battery.
Outside temperature
is too hot or cold.
Make sure phone is charging at a
normal temperature.
Contact problem Check the charger and its connection
to the phone.
No voltage Plug the charger into a different outlet.
Charger defective Replace the charger.
Wrong charger Use only original LG accessories.
Number not
allowed.
The Fixed dialling
number function
is on.
Check the Settings menu and turn the
function off.
Appendix 109
Message Possible causes Possible corrective measures
Impossible
to receive/
send SMS &
photos
Memory full
Delete some data, such as applications
or messages from your phone to make
more memory available.
Files do not
open
Unsupported file
format Check the supported file formats.
No sound Vibration mode
Check the settings status in the sound
menu to make sure you are not in
vibration or no interruptions mode.
Hangs up or
freezes
Intermittent
software problem
If the screen freezes or the phone does
not respond when you try to operate
it, remove the battery and reinsert it.
Then power the phone back on.
OR
Try to perform a software update
through the website.
Appendix 110
Anti-Theft Guide
You can set up your device to prevent other people from using it if it's been
reset to factory settings without your permission. For example, if your
device is lost, stolen, or wiped, only someone with your Google account or
screen lock information can use the device.
All you need to make sure your device is protected is:
Ţ Set a screen lock: If your device is lost or stolen but you have a screen
lock set, the device can't be erased using the Settings menu unless
your screen is unlocked.
Ţ Add your Google account on your device: If your device is wiped but
you have your Google account on it, the device can't finish the setup
process until your Google account information is entered again.
After your device is protected, you'll need to either unlock your screen or
enter your Google account password if you need to do a factory reset. This
ensures that you or someone you trust is doing the reset.
NOTE
Ţ Do not forget your Google account and password you had added to your device
prior to performing a factory reset. If you can't provide the account information
during the setup process, you won't be able to use the device at all after
performing the factory reset.
Appendix 111
More information
Open Source Software Notice Information
To obtain the source code under GPL, LGPL, MPL, and other open source
licenses, that is contained in this product, please visit
http://opensource. lge.com.
In addition to the source code, all referred license terms, warranty
disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for
a charge covering the cost of performing such distribution (such as the
cost of media, shipping, and handling) upon email request to opensource@
lge.com. This offer is valid for three (3) years from the date on which you
purchased the product.
Trademarks
Ţ Copyright ©2015 LG Electronics, Inc. All rights reserved. LG and the LG
logo are registered trademarks of LG Group and its related entities.
Ţ Google™, Google Maps™, Gmail™, YouTube™, Hangouts™ and Play
Store™ are trademarks of Google, Inc.
Ţ Bluetooth is a registered trademark of Bluetooth SIG, Inc. worldwide.
Ţ Wi-Fi and the Wi-Fi logo are registered trademarks of the Wi-Fi
Alliance.
Ţ All other trademarks and copyrights are the property of their
respective owners.
For Your SafetyFor Your Safety
For Your Safety 113
The highest SAR value for this model phone when tested for use at the ear
is X.XX W/kg and when worn on the body, as described in this user guide,
is X.XX W/kg (body-worn measurements differ among phone models,
depending upon available accessories and FCC requirements).
While there may be differences between SAR levels of various phones and
at various positions, they all meet the government requirement for safe
exposure.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC RF
emission guidelines.
SAR information on this model phone is on file with the FCC and can be
found under the Display Grant section of http://www. fcc.gov/oet/ea/fccid/
after searching on FCC ID XXXXXX.
Ţ To reduce risk of fire or burns, do not expose to temperature above 45
°C / 113 °F, or dispose of in fire.
Ţ To reduce risk of fire or burns, do not dispose of in fire or water.
Ţ Do not disassemble or open crush, bend or deform, puncture or shred.
Ţ There is a danger of explosion if battery is incorrectly replaced. To
reduce risk of fire or burns, do not disassemble, crush, puncture, short
external contacts, expose to temperature above 45 °C / 113 °F, or
dispose of in fire or water. Keep this product away from excessive
moisture and extreme temperatures. Keep the battery or device dry
and away from water or any liquid as it may cause a short circuit.
Ţ Avoid using your phone near strong electromagnetic sources, such as
microwave ovens, sound speakers, TV and radio.
For Your Safety 114
Ţ Use only original manufacturer-approved accessories, or accessories
that do not contain any metal. Please only use an approved charging
accessory to charge your LG phone. Improper handling of the
Accessory/Charger Port, as well as the use of an incompatible charger,
may cause damage to your phone and void the warranty.
Ţ Only use the approved battery charger. Otherwise, you may cause
serious damage to your phone.
FCC Hearing-Aid Compatibility (HAC) Regulations for
Wireless Devices
On July 10, 2003, the U.S. Federal Communications Commission (FCC)
Report and Order in WT Docket 01-309 modified the exception of wireless
phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to
require digital wireless phones be compatible with hearing-aids. The intent
of the HAC Act is to ensure reasonable access to telecommunications
services for persons with hearing disabilities.
While some wireless phones are used near some hearing devices (hearing
aids and cochlear implants), users may detect a buzzing, humming, or
whining noise. Some hearing devices are more immune than others to this
interference noise, and phones also vary in the amount of interference they
generate.
The wireless telephone industry has developed a rating system for
wireless phones, to assist hearing device users to find phones that may
be compatible with their hearing devices. Not all phones have been rated.
Phones that are rated have the rating on their box or a label located on the
For Your Safety 115
box.
The ratings are not guarantees. Results will vary depending on the user’s
hearing device and hearing loss. If your hearing device happens to be
vulnerable to interference, you may not be able to use a rated phone
successfully. Trying out the phone with your hearing device is the best way
to evaluate it for your personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely
to generate less interference to hearing devices than phones that are not
labeled. M4 is the better/ higher of the two ratings.
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely
to generate less interference to hearing devices than phones that are not
labeled. T4 is the better/ higher of the two ratings.
Hearing devices may also be rated. Your hearing device manufacturer or
hearing health professional may help you find this rating.
Higher ratings mean that the hearing device is relatively immune to
interference noise.
The hearing aid and wireless phone rating values are then added together.
A sum of 5 is considered acceptable for normal use. A sum of 6 is
considered for best use.
In the example to the left, if a hearing aid meets the M2
level rating and the wireless phone meets the M3 level
rating, the sum of the two values equal M5. This should
provide the hearing aid user with “normal usage” while
using their hearing aid with the particular wireless
phone. “Normal usage” in this context is defined as a signal quality that’s
For Your Safety 116
acceptable for normal operation.
The M mark is intended to be synonymous with the U mark. The T mark
is intended to be synonymous with the UT mark. The M and T marks are
recommended by the Alliance for Telecommunications Industries Solutions
(ATIS).
The U and UT marks are referenced in Section 20.19 of the FCC Rules. The
HAC rating and measurement procedure are described in the American
National Standards Institute (ANSI) C63.19 standard. To ensure that the
Hearing Aid Compatibility rating for your phone is maintained, secondary
transmitters such as Bluetooth and WLAN components must be disabled
during a call.
When you’re talking on a cell phone, it’s recommended that you turn the BT
(Bluetooth) or WLAN mode off for HAC.
For information about hearing aids and digital wireless phones
Wireless Phones and Hearing Aid Accessibility
http://www.accesswireless.org/
Gallaudet University, RERC
http://tap.gallaudet.edu/Voice/
FCC Hearing Aid Compatibility and Volume Control
http://www.fcc.gov/cgb/dro/hearing.html
The Hearing Aid Compatibility FCC Order
http://hraunfoss.fcc.gov/edocs_public/attachmatch/FCC-03-168A1.pdf
Hearing Loss Association of America [HLAA]
http://hearingloss.org/content/telephones-and-mobile-devices
Part 15.19 statement
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Part 15.21 statement
Changes or modifications that are not expressly approved by the manufacturer for
compliance could void the user’s authority to operate the equipment.
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
_ Reorient or relocate the receiving antenna.
_ Increase the separation between the equipment and receiver.
_ Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
_ Consult the dealer or an experienced radio/TV technician for help.
Consumer Information on SAR
(Specific Absorption Rate)
This model phone meets the government's requirements for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured
not to exceed the emission limits for exposure to Radio Frequency (RF) energy set by the
Federal Communications Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for
SAR are conducted using standard operating positions specified by the FCC with the phone
transmitting at its highest certified power level in all tested frequency bands. Although SAR
is determined at the highest certified power level, the actual SAR level of the phone while
operating can be well below the maximum value. Because the phone is designed to operate
at multiple power levels to use only the power required to reach the network, in general,
the closer you are to a wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified
to the FCC that it does not exceed the limit established by the government-adopted
requirement for safe exposure. The tests are performed in positions and locations (e.g., at
the ear and worn on the body) as required by the FCC for each model.
While there may be differences between SAR levels of various phones and at various
positions, they all meet the government requirement for safe exposure.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on
this model phone is on file with the FCC and can be found under the Display Grant section
of http://www.fcc.gov/oet/fccid after searching on FCC ID ZNFL81AL.
Body-worn Operation
This device was tested for typical use with the back of the phone kept 0.39 inches (1.0
cm) from the body. To comply with FCC RF exposure requirements, a minimum separation
distance of 0.39 inches (1.0 cm) must be maintained between the user’s body and the
back of the phone. Any belt-clips, holsters, and similar accessories containing metallic
components may not be used. Avoid the use of accessories that cannot maintain 0.39
inches (1.0 cm) distance between the user’s body and the back of the phone and have not
been tested for compliance with FCC RF exposure limits.
HAC statement
This phone has been tested and rated for use with hearing aids for some of the wireless
technologies that it uses. However, there may be some newer wireless technologies used in
this phone that have not been tested yet for use with hearing aids. It is important to try the
different features of this phone thoroughly and in different locations, using your hearing aid
or cochlear implant, to determine if you hear any interfering noise. Consult your service
provider or the manufacturer of this phone for information on hearing aid compatibility. If
you havequestions about return or exchange policies, consult your service provider or phone
retailer.
