User Manual
PRODUCT NAME : Single Band Wi-Fi + MCU Module
MODEL NAME : LCW-006
The information contained herein is the exclusive property of LG and shall
not be distributed, reproduced or disclosed in whole or no in part without
prior written permission of LG.
User Manual
REG. DATE : 2016.11.04
MODEL NAME : LCW-006
REV. NO : v1.00
©2016 All rights reserved.
REV. DATE : 2016.11.04
2. Module Pictures
1. Features
LCW-006 is the module for IEEE 802.11b/g/n wireless LAN + MCU.
LCW-006 is based on Mediatek MT7697D solution.
IEEE 802.11 b/g/n single band WLAN Infrastructure
Size : 20mm x 45mm x 10 mm
Data rates up to 150Mbps PHY rate
SPI interface
Integrated IPv4/IPv6 TCP/IP stack
Integrated Network services such as HTTP, DNS, FTP
Security : WFA, WPA, WPA2, WEP, WAPI, TKIP
Application : Home Appliance
< Top Side w/o shield can > < Bottom Side >
FCC Warning Statement
FCC Part 15.19
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC Part 15.21
Any changes or modifications (including the antennas) to this device that are not expressly approved by the manufacturer
may void the user’s authority to operate the equipment.
This equipment complies with FCC Radiation exposure limits set forth for an uncontrolled environment. This device and its
antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.
Please notice that if the FCC identification number is not visible when the module is installed inside another device, then
the outside of the device into which the module is installed must also display a label referring to the enclosed module.
This exterior label can use wording such as the following: “Contains FCC ID : BEJ-LCW006” any similar wording that
expresses the same meaning may be used.
Manual Information to the End User
The module is limited to OEM installation ONLY.
The OEM integrator is responsible for ensuring that the end-user has no manual instruction to remove or install module.
The module is limited to installation in mobile application;
A separate approval is required for all other operating configurations, including portable configurations with respect to Part
2.1093 and difference antenna configurations.
There is requirement that the grantee provide guidance to the host manufacturer for compliance with Part 15B
requirements.
Please notice that if the IC identification number is not visible when the module is installed inside another device, then the
outside of the device into which the module is installed must also display a label referring to the enclosed module. This
exterior label can use wording such as the following: “Contains IC : 2703N-LCW006” any similar wording that expresses
the same meaning may be used.
L’étiquette d’homologation d’un module d’Innovation, Sciences et Développement économique Canada devra être posée
sur le produit hôte à un endroit bien en vue, en tout temps. En l’absence d’étiquette, le produit hôte doit porter une étiquette
sur laquelle figure le numéro d’homologation du module d’Innovation, Sciences et Développement économique Canada,
précédé du mot « contient », ou d’une formulation similaire allant dans le même sens et qui va comme suit :
Contient IC : 2703N-LCW006 est le numéro d’homologation du module
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF
module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as shown in this manual.
IC Warning Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) L'appareil ne doit pas produire de brouillage, et (2)
L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
IC RF Radiation Exposure Statement : This equipment complies with IC RF Radiation exposure limits set forth for
an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with
any other antenna or transmitter.
RF du IC d'exposition aux radiations: Cet équipement est conforme à l'exposition de la IC rayonnements RF limites
établies pour un environnement non contrôlé.
L’antenne pour ce transmetteur ne doit pas être même endroit avec d’autres émetteur sauf conformément à la IC
procédures de produits Multi-émetteur.
