LG Electronics USA LSP430 Fixed Cellular CDMA Phone User Manual LSP 430E 0302

LG Electronics USA Fixed Cellular CDMA Phone LSP 430E 0302

Users Manual

LSP-430 USER GUIDE
Please read this manual carefully before operating your set.
Retain it for future reference.
LIMITED WARRANTY STATEMENT
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be
free from defects in material and workmanship, according to the following terms and conditions:
(1) The limited warranty for the product extends for ONE (1) year beginning on the data of purchase
of the product.
(2) The limited warranty extends on to the original purchaser of the product and is not assignable or
transferable to any subsequent purchaser/end user.
(3) This warranty is good only to the original purchaser of the product during the warranty period as
long as it is in the U.S., including Alaska, Hawaii, U.S. Territories and Canada.
(4) The external housing and cosmetic parts shall not be covered under these limited warranty terms.
(5) Upon request from LG, the consumer must provide information to reasonably prove the date of
purchase.
(6) The customer shall bear the cost of shipping the product to the Customer Service Department of
LG. LG shall bear the cost of shipping the product back to the consumer after the completion of
service under this limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVER:
(1) Defects or damages resulting from use of the product in other than its normal and customary
manner.
(2) Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to
moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair,
misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the
fault of LG, including damage caused by shipping blown fuses spills of food or liquid.
(3) Breakage or damage to antennas unless caused directly by defects in material or workmanship.
(4) That the Customer Service Department at LG was net notified by consumer of the alleged defect
or malfunction of the product during the applicable limited warranty period.
(5) Products which have had the serial number removed or made illegible.
(6) The limited warranty is in lieu of all other warranties, express or implied either in fact or by
operations law, statutory or otherwise, including, but limited to any implied warranty of
marketability or fitness for a particular use.
(7) Damage resulting from use of non-LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to
normal customer use.
(9) Products operated outside published maximum ratings.
3
(10) Products used or obtained in a rental program.
(11) Consumables (such as fuses).
3. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED
WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED
TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL
NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS
OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, RISING OUT OF THE USE OF,
OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY
APPLICABLE TO THIS PRODUCT. Some states do not allow the exclusive of imitation of incidental
or consequential damages or limitations on how long an implied warranty lasts; so these limitations or
exclusions may not apply to you. This warranty gives you specific legal rights and you may also have
other rights which vary from state to state.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call the following web address:
www.lgeservice.com
8
For Your Safety
Important Information
This user guide contains important information on the use and
operation of this phone. Please read all the information
carefully for optimal performance and to prevent any damage
to or misuse of the phone. Any changes or modifications not
expressly approved in this user guide could void your warranty
for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the
bathroom, swimming pool, etc.
Always store your phone away from heat. Never store your
phone in settings that may expose it to temperatures less than
32°F or greater than 104°F, such as outside during extreme
weather conditions or in your car on a hot day. Exposure to
excessive cold or heat will result in malfunction, damage
and/or catastrophic failure.
Be careful when using your phone near other electronic
devices. RF emissions from your mobile phone may affect
nearby in adequately shielded electronic equipment. You
should consult with manufacturers of any personal medical
devices such as pacemakers and hearing aides to determine if
they are susceptible to interference from your mobile phone.
Turn off your phone in a medical facility or at a gas station.
Never place your phone in a microwave oven as this will
cause the battery to explode.
IMPORTANT! Please read the TIA SAFETY INFORMATION on
page 78 before using your phone.
Safety Information
Read these simple guidelines. Breaking the rules may be
dangerous or illegal. Further detailed information is given in this
user guide.
]Never use an unapproved battery since this could damage
the phone and/or battery and could cause the battery to
explode.
]Never place your phone in a microwave oven as it will
cause the battery to explode.
]Do not dispose of your battery by fire or with hazardous or
flammable materials.
]Make sure that no sharp-edged items come into contact
with the battery. There is a risk of this causing a fire.
]Store the battery in a place out of reach of children.
]Be careful that children do not swallow any parts such as
rubber plugs (earphone, connection parts of the phone,
etc.). This could cause asphyxiation or suffocation.
9
For Your Safety
]Unplug the power cord and charger during lightning storms
to avoid electric shock or fire.
]When riding in a car, do not leave your phone or set up the
hands-free kit near to the air bag. If wireless equipment is
improperly installed and the air bag is activated, you may be
seriously injured.
]Do not use a hand-held phone while driving.
]Do not use the phone in areas where its use is prohibited.
(For example: aircraft).
]Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as a
bathroom.
]Never store your phone in temperatures less than- 4°F or
greater than 122°F.
]Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. There is a
risk of this causing a fire.
]Do not drop, strike, or shake your phone severely. Such
actions may harm the internal circuit boards of the phone.
]Do not use your phone in high explosive areas as the phone
may generate sparks.
]Do not damage the power cord by bending, twisting, pulling,
or heating. Do not use the plug if it is loose as it may cause
a fire or electric shock.
]Do not place any heavy items on the power cord. Do not
allow the power cord to be crimped as it may cause fire or
electric shock.
]Do not handle the phone with wet hands while it is being
charged. It may cause an electric shock or seriously
damage your phone.
]Do not disassemble the phone.
]Do not place or answer calls while charging the phone as it
may short-circuit the phone and/or cause electric shock or
fire.
]Only use the batteries, antennas, and chargers provided by
LG. The warranty will not be applied to products provided by
other suppliers.
]Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in
accidents and consequently invalidate the warranty.
]Do not hold or let the antenna come in contact with your
body during a call.
]An emergency call can be made only within a service area.
For an emergency call, make sure that you are within a
service area and that the phone is turned on.
10
For Your Safety
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of he United
States, with its action in Report and Order FCC 96-326, adopted
an updated safety standard for human exposure to radio
frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with
the safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC guidelines and
these international standards.
CAUTION
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result in
violation of FCC regulations. Do not use the phone with a
damaged antenna. If a damaged antenna comes into contact
with skin, a minor burn may result. Contact your local dealer
for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with
the back of the phone kept 0.79 inches (2.0cm) between the
user’s body and the back of the phone. To comply with FCC RF
exposure requirements, a minimum separation distance of 0.79
inches(2.0cm) must be maintained between the user's body
and the back of the phone. Third-party belt-clips, holsters, and
similar accessories containing metallic components should not
be used. Body-worn accessories that cannot maintain 0.79
inches(2.0cm) separation distance between the user's body
and the back of the phone, and have not been tested for typical
body-worn operations may not comply with FCC RF exposure
limits and should be avoided.
11
For Your Safety
Vehicle Mounted External Antenna
(optional, if available)
A minimum separation distance of 8 inches (20cm) must be
maintained between the user/bystander and the vehicle
mounted external antenna to satisfy FCC RF exposure
requirements. For more information about RF exposure, visit
the FCC website at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC
rules. Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must
accept any interference received, including interference that
may cause undesired operation.
Cautions for Battery
]Do not disassemble.
]Do not short-circuit.
]Do not expose to high temperature: 60°C (140°F).]
]Do not incinerate.
Battery Disposal
]Please dispose of your battery properly or bring to your
local wireless carrier for recycling.
]Do not dispose in fire or with hazardous or flammable
materials.
Adapter (Charger) Cautions
]Using the wrong battery charger could damage your phone
and void your warranty.
]The adapter or battery charger is intended for indoor use
only.
Do not expose the adapter or battery charger to direct sunlight
or use it in places with high humidity, such as the bathroom.
2
Congratulations on your subscription to the
LSP-430 Fixed Wireless Phone. This phone has been
designed to operate on the IS-2000 Air Protocol
over the 800MHz band. And the phone has the
advanced user interface similar to mobile phone.
It has greatly enhanced voice clarity and provides
various advanced features.
KKeeyy pphhoonnee ffeeaattuurreess::
2-line text + 1 Icon line LCD Display. Yellow/Green
LCD backlight.
32 Polyphonic Ring tones: Choose from 10
melodies and 5 bell sounds.
Large Phone Book with 300 entries.
Speed Dialling for up to 300 numbers.
The phone can store up to 30 Missed, 30
Received, 30 Dialled calls, and 30 In Call Memo in
Call History.
3 Way call conferencing.
SMS features.
Last number redial.
Hands free Speaker Phone.
Receiver Off-Hook tone.
Adjustable Ring volume, Key volume, Earpiece
volume, and Speaker volume.
Fast charging battery.
3
Highlights
Highlights
Contents
Contents
1. Introduction 4
1.1 Front View of the Phone 4
1.2 LCD Display 5
1.3 Installation 6
1.4 Installation Steps 9
2. Basic Operation 10
2.1 Making a Call 10
2.2 Messaging 10
2.3 Redialing Last Number 10
2.4 3-way Call Conferencing 11
2.5 Call Wait 11
2.6 Volume Control 11
2.7 Receiving a Call 12
2.8 Memo 12
2.9 Lock Mode 12
2.10 Entering and Editing Information 13
3. Menu Tree 14
3.1 PHONE BOOK 17
3.2 MESSAGES 18
3.3 CALL HISTORY 21
3.4 SOUND 24
3.5 DISPLAY 25
3.6 SETTINGS 26
3.7 ORGANISER 30
4. Speaker Phone 32
5. Troubleshooting 33
6. Important Information 34
6.1 Safety Instruction 34
6.2 Optimal Phone Performance 34
6.3 Care and Service 35
6.4 Safety Information 36
7. General Information 39
7.1 Main Unit 39
7.2 AC/DC Adapter 39
7.3 Battery 40
Limited Warranty Statement 41
Appendix FCC RF Exposure Information 45
LGE Service Center List 46
5
1. Introduction
1.1 Front View of the Phone
Introduction
Menu : Activates Main Menu state.
Clear : Deletes the last digit, or moves previous Menu.
OK : Used to store an entry or to accept a command.
Message : Activates SMS Menu state.
Up Key () : Moves up in the Menu or Volume Up.
Down Key () : Moves down in the Menu or Volume
Down.
END/PWR : Deactivates states, or Power ON/OFF.
Redial/Flash : Activates Redial/Flash state, or views Call
History.
⑨( ) : Activates hands free function.
MIC
‘*’ : Inputs Symbol ‘*’, or makes a phone input ‘space’ during
text entry operation.
‘#’ : Inputs Symbol ‘#’, or makes a phone lock after
long-press.
Attached Antenna.
4
Introduction
Introduction
Introduction
The LCD shows icons on the top of the LCD screen.
Different indicators appear based on the phone's operating mode.
1.2 LCD Display
IIccoonnOOppeerraattiinngg CCoonnddiittiioonn
RSSI indicator: Indicates the signal strength in the service area.
No service: The phone is not receiving any system signal.
In use: Displayed when a call is in progress or the phone is in off-hook state.
Text message: Displayed when a text message is received.
Voice message: Displayed when voice message is received.
Alarm: Displayed when alarm time is set.
Indoming Call Indicator : Displayed when the Incomming Call is received.
Not used.
Battery charge level: Indicates charged battery level.
76
Introduction
You should follow each step carefully as shown below in order to guarantee the proper operation of CDMA Fixed
Wireless Phone.
1.3 Installation
Introduction
Introduction
Introduction
STEP I. Check Components
The following components are supplied Fixed
Wireless Phone.
1. LSP-430 Main Phone with Handset
(Including inner backup battery) -1EA-
2. Dipole Antenna -1EA-
3. AC/DC Power Adapter -1EA-
4. User Guide -1EA-
Please make sure that these components are
present before you begin to install the phone.
If any of the components are missing or damaged,
contact your service provider immediately.
STEP II. Place the Terminal
Place the phone on the stable flat surface area
(desk, table, etc). Serious damage may result if the
phone is dropped. Do not place the phone within 1
meter of heaters or radiators.
This phone is designed for desktop usage. Avoid the
direct exposure to sunlight and dampness.
Read the SAFETY INFORMATION located in the
first part of this document before you lace the
phone.
STEP III. Connect Components
(Please refer to “Installation Steps” in 1.4)
Connect the antenna to the TNC antenna
connector located at the top of the phone.
If you have placed the phone on a flat surface,
position the antenna upright.
Connect the curl cord of the handset to the RJ-11
port located on the left side of the phone.
Connect the AC/DC Adapter cable to the DC input
port located at the top of the phone.
- If it is correct, a beep tone will be heard.
- If it is not correct (Booting fails or beep tone is not
heard), you will have to reconnect the adapter or
reset the battery switch to “on”.
Please observe the following to get better voice
quality.
98
1. Keep away from electrical appliances such as TV,
computer, radio etc.
2. Keep the phone in a high and central location
without any obstructions.
3. Raise the integral antenna of the phone to get
maximum strength as shown in the figure.
STEP IV. Check the LCD Display
After you follow the installation instruction step I to
step III, please check the LCD for normal operation.
If you do not see the status of service, please repeat
the 4th instruction of step III.
Then confirm the status of phone to get the proper
signal strength from the service operator system.
Introduction
Introduction
Introduction
Introduction
Connect basehandset
to the handset
connector.
Turn the antenna
upright.
Connect the antenna
to the TNC connector
(Turn right).
1 2
3 4
END
/PWR
Redial
/Flash
Mic
Press END/PWR
button to operate
initially.
Connect the AC
power supply.
5
1.4 Installation Steps
Please follow the procedure below to install the phone properly.
1110
2. Basic Operation
2.1 Making a Call
You can make a call as follows:
1. Pick up the handset or press button.
2. Listen for dial tone.
3. Enter the phone number with area code if
needed.
4. Wait for the Auto Time-out or Press
button.
5. The call is connected and you may start
conversation.
6. To disconnect the call, replace the handset or
press button.
When the user presses the button
after dialing any desired number, if the user picks
up the handset or presses the button, the
phone makes a call immediately.
2.2 Messaging
You can send or receive a short message. If you want
to send SMS, press button button +
1 ( ) in on-hook state and write message that
you want and send your message. When the message
received in idle state or during a call, you can confirm
your message as follows.
1. Press button + 2 ( ).
2. Press key to confirm desired message.
2.3 Redialing Last Number
You can make a redial to last number, shown in All
Calls.
1. Pick up the handset or press button.
2. Listen for dial tone.
3. Press button.
4. The call is connected and you may start
conversation.
Redial/Flash
OK
InboxMessage
Write
Message
Redial/Flash
Redial/Flash
Basic Operation
Basic Operation
Basic Operation
Basic Operation
5. To disconnect the call, replace the handset or
press button.
You can also dial any of the last 120
(Missed+Received+Dialled+In Call Memo)
numbers stored in All Calls.
2.4 3-way Call Conferencing
You can start tripartite conversation.
MMeetthhoodd 11
1. Enter the phone number of the 2nd party phone
while you are in telephonic conversation with 1st
party.
2. Press button. And press
button again.
MMeetthhoodd 22
1. Press button while you are in
telephonic conversation with 1st party.
2. If you listen to the dialing tone, Press the phone
number of the 2nd party phone.
3. Press button.
And press button again.
This service should be provided by your service
provider.
2.5 Call Wait
While a call is in progress, you may hear two beeps
indicating another incoming call.
When call wait is enabled, you may put the active call
on hold while you answer the other incoming call.
1. Press button, you may start
conversation with called number.
2. Re-press button, you may start
conversation with previous number.
2.6 Volume Control
1. Press button of navigation while in a
call, to adjust speaker volume.
Up/Down
Redial/Flash
Redial/Flash
Redial/Flash
Redial/Flash
Redial/Flash
Redial/Flash
Redial/Flash
Menu. You can lock your phone using the ‘#’ (
:Lock) key, also you can lock your phone manually.
Lock Mode
1. Press ‘#’ button for some time. The phone is
now locked.
2. To unlock, press .
3. Enter lock code. (Default “0000”).
2.10 Entering and Editing
Information
You can edit the phone book and short messages
using various text input mode.
KKeeyy FFuunnccttiioonnss
- Message key : Press to select a character
mode(ABC, abc, Sym1, Sym2) in edit state.
- SPACE key : Press to insert a space.
- Clear key : Press to delete a single space or
character. Press and hold to delete entire words.
IInnppuutt MMooddee
Text Input provides four modes for entering text,
special characters, and punctuation.
- ABC / abc Mode : Use ABC or abc mode to input
text in English.
ABC Mode : All subsequent letters are
capitalized.
abc Mode : All subsequent letters are
lowercase.
- Sym1 / Sym2 Mode : Insert special characters
and punctuation. You may use any of the special
characters. When the special characters are
displayed, you can select the number
corresponding to the character that you want to
input.
- For number entry, first select the key button you
want to input in ABC / abc mode and then press
the key button until the number is displayed.
SPACE
Menu
Basic Operation
Basic Operation
1312
2. Press + 1( ) to prevent
sound from your end during the call. To cancel
Mute, Press again + 1( ).
3. Press + 4( ) during a call and
select Low or High by pressing
button, to adjust MIC volume.
2.7 Receiving a Call
When the bell rings in idle state, you can receive a call
as follows:
1. Pick up the handset or press the button.
2. Start a conversation.
3. To disconnect the call, replace the handset or
press the button.
2.8 Memo
Allow you to store number during the call.
To store number:
1. Press + 2( ).
2. Enter up to 32 numbers using the keypad.
3. Press key to save.
To retrieve an In Call Memo:
1. Press button to see saved
number.
Note: You can store the number by pressing
key.
2.9 Lock Mode
Keeps your phone from unauthorized use. Once the
phone is locked, it is in restricted mode, until the in
lock code is entered. This will allow you to receive
phone calls and still make emergency calls. The lock
code on your phone is “0000” by default.
If you need to modify the lock code, you may modify
it using the within the security
New Lock Code
OK
Redial/Flash
OK
MemoMenu
Up/Down
MIC LevelMenu
Mute/UnmuteMenu
Mute/UnmuteMenu
Basic Operation
Basic Operation
Menu Tree
Menu Tree
14 15
Menu Tree
Menu Tree
1. PHONE
1. Find 1. Address / 2. Name / 3. Number
BOOK 2. Add Number / Name / Address / Secret
3. Erase All Yes / No
1. Write Number / Contents
2. Inbox CALL FORWARD / CALL WAIT / CALL TIMER
3. SMS 8282 1. What's New? / 2. Jokes / 3. News / 4. Astrology /
5. Win Prizes / 6. LifeStyle / 7. More
2. MESSAGES 4. Outbox OK / EDIT
5. Voice Mail For 10 Secounds / For 30 Secounds / Always On / Always off
6. Erase Messages 1. Inbox & Voice / 2. Outbox / 3. All Messages
7. MSG Settings 1. Priority / 2. Delivery ACK / 3. Defer Delivery /
4. Valid Period / 5. Save Sent MSG / 6. Auto Del. Inbox
3.
CALL HISTORY
1. All Call View / Erase / Save Number
2. Missed View / Erase / Save Number
Main Menu
Sub-Menu Setting Value
3. Menu Tree
3. Received View / Erase / Save Number
4. Dialled View / Erase / Save Number
5. In Call Memo View / Erase / Save Number
6. Call Duration 1. Last Dialled / 2. All Dialled / 3. All Calls / 4. Reset
7. Erase History 1. Erase All Call / 2. Erase Missed / 3. Erase Received
4. Erase Dialled / 5. Erase Memo
1. Ring Type Ring / One-Beep / Light
2. Ring Tone 15 ea (Midi 10 + Bell 5)
4. SOUND 3. Ring Volume 4 Steps (1-4)
4. Ear Volume 4 Steps (1-4)
5. Key Volume 5 Steps (0-4)
6. Message Alert 1. Alert Type / 2. Alert Tone / 3. MSG Reminder
1. Banner 1. My Banner / 2. Banner On/Off
5. DISPLAY 2. Clock Type Type-A_AM/PM / Type-A_24Hour /
Type-B_AM/PM / Type-B_24Hour
3. Backlight For 10 Seconds / For 30 Seconds / Always On / Aleays Off
Main Menu
Sub-Menu Setting Value
17
Menu Tree
Menu Tree
3.1 PHONE BOOK
This function allows you to search the phone number
in three way (Address, Name, Number), which you
have stored in the phone book memory.
Up to 300 entries can be listed here.
To store phone number:
1. Enter the area code and phone number (Max. 32
digits) in on-hook state.
2. Press key
3. Enter the name. Refer to the 2.10 Entering and
Editing Information about text input.
4. Enter the desired memory location.
5. The phone will display a message asking you
whether to keep your number as secret or not.
Select or using button
and press key.
You will see a confirmation message and the
status of memory used.
3.1.1 Find
To find phone numbers you have stored in the Phone
Book.
1. Press + 1( ) +
1( ) in on-hook state.
2. Select a desired search Menu.
Address, Name, Number : Enter full or part of
name(number), select .
3. Select desired item.
key : can edit item.
: can delete item.
3.1.2 Add
You can save up to 300 entries in your LSP-430
phonebook.
1. Press + 1( ) + 2( )
in on-hook state.
AddPHONE BOOK
MENU
Message key
OK
OK
FIND
PHONE BOOKMENU
OK
Up/DownYesNo
OK
16
Menu Tree
Menu Tree
1. Phone 1. Auto Time-Out / 2. Speed Dialing / 3. DTMF Length /
4. Version / 5. My Number
6. SETTINGS 2. Calling 1. Call Divert / 2. Call Waiting / 3. Call Timer
3. Security 1. Lock Phone / 2. Emergency No / 3. New Lock Code
4. Restrict Call / 5. Hot Line / 6. Hot Line Time
7. ORGANISER 1. Alarm 1. Set Time / 2. Set Ringer
Main Menu
Sub-Menu Setting Value
1918
2. Enter the information (Number, Name, Memory
Location).
3.1.3 Erase All
You may erase all phonebook items.
1. Press + 1( ) +
3( ) in on-hook state.
2. Select and press key.
3.2 MESSAGES
Text messaging, page and voice mailbox become
available as soon as the power is on.
You may access the above type of messages using the
Message key. The phone can store up to 50 messages
in each Inbox and Outbox.
If you press Key, SMS Menu is activated.
At any point of time, to return to the initial screen,
press button and to return to the
previous screen, press button.
In the list of Inbox, all sorts of the icon have the
meaning as follows:
!: Unread message
V : Read message
Press + 2( ) in on=hook state to
access messages. In Inbox, the meaning of (5/37)
beside Inbox is that 5 out of 37 messages are unread.
3.2.1 Write
This function allows you to compose and send
message.
1. Press + 1( ) in on-hook state.
2. Enter phone number or press to
search from phone book or call history.
3. Write messages. Refer to the 2.10 Entering and
Editing Information about text input.
4. Press key to send message.
OK
Message
Write
Message
MessageMenu
Clear
END/PWR
Message
OKYes/No
Erase All
PHONE BOOK
Menu
Menu Tree
Menu Tree
Menu Tree
Menu Tree
3.2.2 Inbox
Received messages are stored here.
1. Press + 2( ) + in onhook
state.
2. To view desired message, select .
3. To delete desired message, select
key.
4. Press to reply, forward, erase a message
or save the sender’s number in the phone-book.
Select 1. , 2. , 3. ,
or 4. using button.
3.2.3 SMS 8282
Exciting SMS-based Infotainment services such as
News, Jokes, Astrology etc are available to TATA
subscribers. Using the SMS 8282 services, the user
will be able to access interesting information on
common subjects through SMS. User needs to send
Keyword in specified format to 8282 to access these
services.
1. Press + 3( ) in on-hook
state.
2. You may select from seven items
( 1. What’s New? / 2. Jokes / 3. News / 4. Astrology
/ 5. Win Prizes / 6. Lifestyle / 7. More )
3. You may select the number corresponding to
the item that you want to send in subsequent-
menu.
3.2.4 Outbox
All your successfully sent messages are saved here.
1. Press + 4( ) in on-hook
state.
2. To delete desired message, select
key.
3. To view or edit desired message, select
key.
OK
Message
Outbox
Message
SMS8282
Message
Up/DownErase
Save NumberForwardReply
Menu
Message
OK
Inbox
Message
2120
3.2.5 Voice Mail
Voice Mail notifications indicate the number of new
voice messages in your mailbox.
Only the most recent voice mail notification will be
stored in your phone, previous message will be
overwritten.
1. Press + 5( ) in on-hook
state.
2. Pick up the handset or press button to
make a call back your voice mailbox if the number
of the voice mailbox is provided by the telecom
service company’s system.
3.2.6 Erase Messages
This function allows you to erase all messages.
1. To delete all received and voice messages, Press
+ 6( ) +
1( ) in on-hook state.
2. To delete all sending messages, Press
+ 6( ) + 2( ) in on-
hook state.
3. To delete all messages, Press +
6( ) + 3( ) in
on-hook state.
3.2.7 MSG Settings
PPrriioorriittyy
1. Press + 7( ) +
1( ) in on-hook state.
2. You may select from four options (Normal /
Interactive / Urgent / Emergency).
DDeelliivveerryy AACCKK
1. Press + 7( ) +
2( ) in on-hook state.
2. Select or .
OffOn
Delivery ACK
MSG Settings
Message
Priority
MSG Settings
Message
All MessagesErase Messages
Message
OutboxErase Messages
Message
Inbox & Voice
Erase Messages
Message
Voice Mail
Message
Menu Tree
Menu Tree
Menu Tree
Menu Tree
DDeeffeerr DDeelliivveerryy
1. Press + 7( ) +
3( ) in on-hook state.
2. Select one of the following.
(IImmmmeeddiiaattee//AAfftteerr 3300 MMiinn..//AAfftteerr 11 HHoouurr
//AAfftteerr 22 HHoouurrss//AAfftteerr 1122 HHoouurrss//AAfftteerr 11
DDaayy//AAfftteerr 22 DDaayyss)
VVaalliidd PPeerriioodd
1. Press + 7( ) +
4( ) in on-hook state.
2. Select one of the following.
(DDeeffaauulltt//3300 MMiinnuutteess//11 HHoouurr//
22 HHoouurrss//1122 HHoouurrss//11 DDaayy//22 DDaayyss)
SSaavvee SSeenntt MMSSGG
1. Press + 7( ) +
5( ) in on-hook state.
2. Select or .
AAuuttoo DDeell.. IInnbbooxx
1. Press + 7( ) +
2( ) in on-hook state.
2. Select or .
3.3 CALL HISTORY
The phone can store up to 30 Missed, 30 Received,
30 Dialled calls, and 30 In Call Memo in Call History.
When you press the button, all calls are displayed. In
the list of all calls, all sorts of the icons have the
meaning as follows :
- Received :
- Dialled :
- Missed : !
- In call Memo :
- Call Waiting :
- Call Conferencing :
OffOn
Auto Del. Inbox
MSG Settings
Message
OffOn
Save Sent MSG
MSG Settings
Message
Valid Period
MSG Settings
Message
Defer Delivery
MSG Settings
Message
C
2322
3.3.1 All Call
[In on-hook state]
1. Press + 3( ) +
1( ) or button.
2. Press button to select a number or
name in the Call history list.
3. To view desired item, press key.
4. To erase desired number, press key.
5. After you press key, press key
to see more information and press key to
save the number in the phone
book.
3.3.2 Missed
1. Press + 3( ) +
2( ) in on-hook state.
2. Press button to select a number or
name in the missed call list.
3. To view desired item, press key.
4. To erase missed call, press key.
5. After you press key, press key
to see more information and press key to
save the number in the phone book.
3.3.3 Received
1. Press + 3( ) +
3( ) in on-hook state.
2. Press button to select a number or
name in the received call list.
3. To view desired item, press key.
4. To erase received call, press key.
5. After you press key, press key
to see more information and press key to
save the number in the phone book.
OK
MessageOK
Message
OK
Up/Down
Received
CALL HISTORYMenu
OK
Message
OK
Message
OK
Up/Down
Missed
CALL HISTORYMenu
OK
MessageOK
Message
OK
Up/Down
Redial/FlashAll Call
CALL HISTORYMenu
Menu Tree
Menu Tree
Menu Tree
Menu Tree
3.3.4 Dialled
1. Press + 3( ) +
4( ) in on-hook state.
2. Press button to select a number or
name in the dialled call list.
3. To view desired item, press key.
4. To erase dialled number, press key.
5. After you press key, press
key to see more information and press key
to save the number in the phone book.
3.3.5 In Call Memo
1. Press + 3( ) +
5( ) in on-hook state.
2. Press button to select desired item
in the In Call Memo list.
3. To view desired item, press key.
4. To erase In Call Memo, press key.
5. After you press key, press
key to see more information and press key
to save the number in the phone book.
3.3.6 Call Duration
LLaasstt DDiiaalllleedd
You may confirm last dialed call duration.
1. Press + 3( ) +
6( ) + 1( ) in on-hook
state.
AAllll DDiiaalllleedd
You may confirm all dialed call duration.
1. Press + 3( ) +
6( ) + 2( ) in on-hook
state.
All DialledCall Duration
CALL HISTORY
Menu
Last DialledCall Duration
CALL HISTORY
Menu
OK
MessageOK
Message
OK
Up/Down
In Call Memo
CALL HISTORY
Menu
OK
MessageOK
Message
OK
Up/Down
Dialled
CALL HISTORYMenu
2524
AAllll CCaallllss
You may confirm all calls duration.
1. Press + 3( ) +
6( ) + 3( ) in on-hook
state.
RReesseett
You may erase all calls duration.
1. Press + 3( ) +
6( ) + 4( ) in on-hook
state.
3.3.7 Erase History
You may erase all history from five options (1: Erase
All Call, 2: Erase Missed, 3: Erase Received, 4: Erase
Dialled, 5: Erase Memo).
1. Press + 3( ) +
6( ) in on-hook state.
2. Select history that you want to erase and press
key.
3.4 SOUND
This menu let you choose your phone’s sound
settings(volume and ring type) to your environment.
3.4.1 Ring Type
1. Press + 4( ) +
1( ) in on-hook state.
2. Select one of the following.
(RRiinngg // OOnnee--BBeeeepp // LLiigghhtt)
3.4.2 Ring Tone
1. Press + 4( ) + 2( )
in on-hook state.
2. Select from Bell / Melody.
Ring ToneSOUNDMenu
RING TYPE
SOUNDMenu
OK
Erase History
CALL HISTORYMenu
ResetCall Duration
CALL HISTORY
Menu
All CallsCall Duration
CALL HISTORY
Menu
Menu Tree
Menu Tree
Menu Tree
Menu Tree
3.4.3 Ring Volume
1. Press + 4( ) + 3( )
in on-hook state.
2. Change using key.
3.4.4 Ear Volume
1. Press + 4( ) + 4( )
in on-hook state.
2. Change using key.
3.4.5 Key Volume
1. Press + 4( ) + 5( )
in on-hook state.
2. Change using key.
3.4.6 Speaker Volume
1. Press + 4( ) +
6( ) in on-hook state.
2. Change using key.
3.4.7 Message Alert
1. Press + 4( ) +
7( ) in on-hook state.
2. Select from Alert Type(RRiinngg//OOnnee--BBeeeepp//
LLiigghhtt//OOffff) / Alert Tone(SSMMSS AAllaarrmm 11~55) /
MSG Reminder(OOnnccee//EEvveerryy 22 MMiinn//OOffff).
3.5 DISPLAY
Lets you personalize your phone’s display by selection
of various display setting like banner, clock type, and
backlight.
Message Alert
SOUNDMenu
Up/Down
Speaker Volume
SOUNDMenu
Up/Down
Key VolumeSOUNDMenu
Up/Down
Ear VolumeSOUNDMenu
Up/Down
Ring VolumeSOUNDMenu
2726
3.5.1 Banner
Allow you to choose the settings of the LCD banner.
1. If you want to edit banner, press +
5( ) + 1( ) + 1( )
+ key in on-hook state.
2. If you want to activate or deactivate the banner,
press + 5( ) + 1( ) +
2( ) in on-hook state.
And select from or .
3.5.2 Clock Type
You can select time format for your phone.
1. Press + 5( ) + 2( )
in on-hook state.
2. Select from TTyyppee--AA__AAMM//PPMM, TTyyppee--
AA__2244HHoouurr, TTyyppee--BB__AAMM//PPMM, or TTyyppee--
BB__2244HHoouurr.
3.5.3 Backlight
Allows you to choose the settings of the LCD
backlight.
1. Press + 5( ) + 3( )
in on-hook state.
2. Select among AAllwwaayyss OOffff/ FFoorr 1100 SSeeccoonnddss
/ FFoorr 3300 SSeeccoonnddss/ AAllwwaayyss OOnn.
3.6 SETTINGS
3.6.1 Phone
AAuuttoo TTiimmee--OOuutt
Setting the length of time the phone waits before
automatically dialing a number. You can select this
duration to be between 2 and 9 seconds.
1. Press + 6( ) + 1( ) +
1( ) in on-hook state.
2. Press button to select Auto Time
Out between (2~9 Sec.).
3. Press key to select.
OK
Up/Down
Auto Time-Out
PhoneSETTINGSMenu
BacklightDISPLAYMenu
Clock TypeDISPLAYMenu
OffOn
Banner On/Off
BannerDISPLAYMenu
OK
My BannerBannerDISPLAY
Menu
Menu Tree
Menu Tree
Menu Tree
Menu Tree
SSppeeeedd DDiiaalliinngg
This function allows you to make a call faster by
just pressing a corresponding number. Up to 300
memory locations can be assigned for speed dial.
To speed dialing press the memory number
(1 through 300) corresponding to the appropriate
memory location and hold for a few seconds.
This function can be used when the speed
dialing is set to enable.
1. Press + 6( ) + 1( ) +
2( ) in on-hook state.
2. Press button to select Enable or
Disable.
3. Press key to save and exit.
DDTTMMFF LLeennggtthh
This function allows you to the setting of Key beep
playback length. Possible settings are SShhoorrttand
LLoonngg.
1. Press + 6( ) + 1( ) +
3( ) in on-hook state.
2. Press button to select SShhoorrttor
LLoonngg.
3. Press key to select.
VVeerrssiioonn
You can confirm your phone S/W version.
1. Press + 6( ) + 1( ) +
4( ) in on-hook state.
2. To confirm next page, press key and
press key to exit.
MMyy NNuummbbeerr
You can confirm and edit your phone number.
1. Press + 6( ) + 1( ) +
5( ) in on-hook state.
2. To modify your phone number, press key.
Enter the phone number, and press key to
save and exit.
OK
OK
My Number
PhoneSETTINGSMenu
OK
Message
Version
PhoneSETTINGSMenu
OK
Up/Down
DTMF Length
PhoneSETTINGSMenu
OK
Up/Down
Speed Dialing
PhoneSETTINGSMenu
2928
3.6.2 Calling
CCaallll DDiivveerrtt
Call Divert lets you forward your incoming calls to
another number.
1. Press + 6( ) + 2( ) +
1( ) in on-hook state.
2. Select from AAllll VVooiiccee CCaallll/ IIff BBuussyy/ IIff NNoott
AAnnsswweerrdd/ DDiissaabbllee AAllll. Disable All deactivates
the already activated call divert option.
3. Select EEnnaabblleeor DDiissaabbllee. If you are select
, enter another phone number and press
key.
You would need to call “121” to get this service
activated.
CCaallll WWaaiittiinngg
While a call is in progress, you may hear two beeps
indication another incoming call.
When call wait is enabled, you can put the activate
call on hold while you answer the other incoming
call.
1. Press + 6( ) + 2( ) +
2( ) in on-hook state.
2. Select EEnnaabblleeor DDiissaabbllee.
You would need to call “121” to get this service
activated.
CCaallll TTiimmeerr
This function allows you to select call timer
indication.
1. Press + 6( ) + 2( ) +
3( ) in on-hook state.
2. Press button to select EEnnaabblleeor
DDiissaabbllee.
3. Press key to save and exit.
OK
Up/Down
Call Timer
CallingSETTINGSMenu
Call Waiting
CallingSETTINGSMenu
OK
Enable
Call Divert
CallingSETTINGSMenu
Menu Tree
Menu Tree
Menu Tree
Menu Tree
3.6.2 Calling
1. Press + 6( ) + 3( )
in on-hook state.
2. Enter password. (Default “0000”)
LLoocckk PPhhoonnee
1. Press + 6( ) + 3( )
+ 1( ) in on-hook state.
2. Press button to select EEnnaabblleeor
DDiissaabblleeand press key.
EEmmeerrggeennccyy NNoo
Emergency number can store up to three numbers.
(Default 100, 101, 102)
1. Press + 6( ) + 3( )
+ 2( ) in on-hook state.
2. To edit a number, press key.
NNeeww LLoocckk CCooddee
New Lock Code allows you to enter a new four-digit
lock code.
1. Press + 6( ) + 3( )
+ 3( ) in on-hook state.
2. Enter the new four-digit lock code that you want
and press key.
3. Verify new lock code and press key.
RReessttrriicctt CCaallll
You can restrict your outgoing calls including numbers
/ numbers beginning with specified digit in the Black
List.
For example: If “9” is stored in the Black List, all number
beginning with “9” cannot be called. However if “92” is
stored in White List, you can call numbers beginning
with “92” successfully.
1. Press + 6( ) + 3( )
+ 4( ) in on-hook state.
Restrict Call
SecuritySETTINGSMenu
OK
OK
New Lock Code
SecuritySETTINGSMenu
OK
Emergency No
SecuritySETTINGSMenu
OK
Up/Down
Lock Phone
SecuritySETTINGSMenu
SecuritySETTINGSMenu
3130
2. Select among NNoo RReessttrriiccttiioonn, RReessttrriiccttiioonnor
EEmmeerrggeennccyy OOnnllyyand press key.
3. If RReessttrriiccttiioonnis selected,
• Enter the numbers / starting digit of specific
numbers to be restricted in the BBllaacckk LLiisstt.
• Enter the number / starting digits of the
numbers to be allowed in the WWhhiittee LLiisstt.
• Press key to save and press CClleeaarror
EENNDD//PPWWRRkey to exit.
4. If EEmmeerrggeennccyy OOnnllyyis selected, your phone is
enabled for only emergency numbers.
(Default 110000,, 110011,, 110022)
HHoott LLiinnee
Hot Line automatically calls to registered number by
passing setup time in off-hook state.
1. Press + 6( ) + 3( )
+ 5( ) in on-hook state.
2. Select EEnnaabblleeor DDiissaabblleeand press key.
3. If EEnnaabblleeis selected, press key and enter
the hotline number.
HHoott LLiinnee TTiimmee
1. Press + 6( ) + 3( )
+ 6( ) in on-hook state.
2. Press button to select Hot line
connection time (2~9 Sec.).
3. Press key to select.
3.7 ORGANISER
3.7.1 Alarm
SSeett TTiimmee
This function allows you to set alarm time.
1. Press + 7( ) + 1( ) +
1( ) in on-hook state.
2. Press button to select from off, once
or always and press key.
OK
Up/Down
Set Time
AlarmORGANISERMenu
OK
Up/Down
Hot Line Time
SecuritySETTINGSMenu
OK
OK
Hot Line
SecuritySETTINGSMenu
OK
OK
Menu Tree
Menu Tree
Menu Tree
Menu Tree
3. Press key to enter alarm time and press
key to select AM or PM.
4. Press key to save and exit.
SSeett RRiinnggeerr
This function allows you to select ringer for alarm
alert.
1. Press + 7( ) + 1( ) +
1( ) in on-hook state.
2. Press button to select from Alarm
Ring 1~5.
3. Press key to save and exit.
OK
Up/Down
Set Ringer
AlarmORGANISERMenu
OK
Message
OK
33
4. Speaker Phone
This function is a convenient feature, which enables
you to make a call using the SSppeeaakkeerr PPhhoonnee()
button in on-hook state.
Troubleshooting
Troubleshooting
32
Speaker Phone
Speaker Phone
5. Troubleshooting
Please check the following items before contacting service center.
Item Remedy
Phone doesn’t operate at all.
• Check that the phone is installed correctly.
• Check that the battery is fully charged.
• Check that the power is on.
Because of noise and cross talking,
call status is bad.
Keep away from electrical application such as TV, computer,
radio and so on.
When I press button to call, can’t
hear the dial tone.
Check that phone cord or power is connected correctly.
Phone does not switch on.
Check that the battery is fully charged and correctly
connected to the phone.
Calls cannot be received.
Check incoming calls may be barred.
Emergency calls cannot be made.
Check that the antenna symbol is displayed- Move to the
coverage area and operate your phone when the antenna
symbol is displayed.
Battery fails to charge.
Ensure that adapter is approved LSP-430 adapter and
ON/OFF switch is on.
Bell sound isn’t heard.
If bell sound is low, please adjust the volume level.
3534
6. Important Information
6.1 Safety Instruction
WARNING / CAUTION
To reduce the risk of fire or electric shock, do not
expose this unit to rain or moisture. Do not use this
unit in swimming pools or other water bodies.
6.2 Optimal Phone Performance
Do not hold the antenna when operating the unit,
or operate the unit when someone is within four
inches (ten centimeters) of the antenna. Both cases
affect the call quality and may cause the phone to
operate at a higher power level than required.
For the best call quality, keep the antenna free from
obstructions and position the antenna upright.
Do not use the unit if the antenna is damaged. Get
the damaged antenna replaced through a qualified
technician. Use only a manufacturer-approved
antenna.
Non-approved antennas, modifications or
attachments may impair call quality and damage
the unit.
RF (Radio Frequency) energy may affect improperly
installed or inadequately shielded personal medical
devices such as pace-makers or hospital monitors.
Consult the manufacturer of any personal medical
devices to determine whether they are adequately
shielded from external RF energy. Turn your unit
OFF in health care centers if any regulations posted
in the area instruct you to do so. Hospitals or
health care centers may be using equipment that
may be sensitive to external RF energy.
If this unit causes harmful interference to radio or
television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Place the radio or television farther away from the
unit.
Important Information
Important Information
Important Information
Important Information
- Connect the equipment to an outlet on a circuit
different from that to which the unit is presently
connected.
- Consult the Authorized LGE Dealer for assistance
of an experienced radio/TV technician.
Use battery, antenna and AC power supply
provided by LGE. Using spares made by any other
manufacturer may invalidate the warranty.
Only authorized personnel should service the unit
and its accessories. Faulty installation or service can
be dangerous and may invalidate the warranty.
Do not use the unit in any designated “no cellular
phone use” area.
Avoid using the unit in high temperature or
humidity.
Avoid spilling any liquid on the unit. If the unit gets
wet, turn the power off immediately and remove the
backup battery and AC power supply. If the unit
doesn’t work, please contact service provider
immediately.
Avoid shock or impact.
We recommend you to charge the backup battery
before initial use. The backup battery may be
discharged during delivery.
6.3 Care and Service
Before cleaning, always unplug the unit from the wall
outlet and remove the antenna (or disconnect the
antenna cable). Do not use liquid or aerosol cleaners;
use a damp cloth for cleaning.
If the unit doesn’t work, do not attempt to
disassemble it; contact the phone service agent for
assistance.
If any of the following conditions exist, unplug the unit
from the wall plug, remove the battery and call a
qualified technician.
The power supply cord is damaged or frayed.
Liquid has spilled into the unit.
The unit has been exposed to rain or water.
The unit has been dropped or damaged.
The unit does not function normally even after
following the operating instructions.
6.4 Safety Information
3736
Important Information
Important Information
WWAARRNNIINNGG
For safety, use only an adapter
approved by LG.
LG does not bear responsibility
for any faults that may arise due
to non- conformation to this
guide.
Do not, in any way, cause a
short-circuit. It may start a fire or
the unit may explode causing
injury.
Do not create a sudden impact
on the battery by throwing it. Do
not dispose off batteries by
putting them in a fire. They may
explode or catch fire due to the
electrolyte within.
CCAAUUTTIIOONN
Do not use the unit with a car
battery. It may cause electric
shock, fire, breakdown or
transformation.
Avoid using the unit in high
temperature or humidity. Avoid
spilling any liquid on this unit. If
the unit gets wet, turn the
power off immediately and
remove the backup battery and
AC power supply.
Keep the unit dry. Submersion,
humidity and liquids containing
minerals may corrode internal
electronic circuits.
Do not store or use the unit in
dusty or dirty areas as this can
damage the moving parts.
Do not store the unit in hot
areas. High temperatures can
shorten the life of electronic
devices, damage batteries, and
Important Information
Important Information
warp or melt certain plastics.
Do not store the unit in cold
areas. When the unit warms up to
its normal operating
temperature, moisture can form
inside the unit, which can damage
the internal electronic circuit
boards.
Do not attempt to open it.
Non-expert handling of the device
could damage it. It may cause fire,
electric shock and breakdown.
Consult your authorized LG
dealer for assistance.
Do not drop, knock or shake the
unit. Rough handling may break
the internal circuit boards.
Do not use harsh chemicals,
cleaning solvents or strong
detergents to clean the unit.
Wipe it with a soft cloth that has
been slightly dampened in a mild
soap and water solution.
Do not paint the unit. Paint can
clog the device's moving parts
and prevent proper functioning.
During lightning, do not touch
the power plug or the phone
line. It may result in an electric
shock or death.
Do not install the unit under
direct sunlight or on an uneven
surface.
Before using the plug, check the
available power voltage.
Inaccurate power voltage may
cause fire and damage.
Input Voltage: 100-240V.
Do not plug many power cords
into one outlet. It may cause fire
or electric shock.
3938
General Information
General Information
Do not remodel the power cord
or disassemble it. If the power
cord or plug is impaired, do not
use it. It may cause fire or electric
shock.
Do not install the unit in an ill-
ventilated place. It may cause fire
or a breakdown.
Do not touch the plug with wet
hands. When disconnecting the
power cord of any accessory,
grasp and pull out the plug itself
and not the cord. It may cause
fire or electric shock.
Do not put heavy objects on the
power cord. Do not bend the
power cord too much. It may
cause fire or electric shock.
Use only an LG-approved battery
or adapter. If not, it may cause an
explosion or result in a short-
circuit. LG does not bear any
responsibility for the damage.
When you disconnect the power
cord of any accessory, grasp and
pull the plug itself and not the
cord. It may cause the adapter to
breakdown.
Important Information
Important Information
7. General Information
7.1 Main Unit
IItteemmLLSSPP--443300
Tx Frequency Digital: 824 ~ 849 MHz
Rx Frequency Digital: 869 ~ 894 MHz
Channel Bandwidth 1.25 MHz
Tx Power Digital: LOWER: 0.2W ~ UPPER:1W
Rx Sensitivity -104 ~ -25dBm
Size (mm) 177.5(W) X 159.5(D) X 69.2(H) (with handset)
Weight (gms) 614 gram (with Ni-MH Battery)
Operating Temperature -10 ~50
C
7.2
AC/DC Adapter
IItteemmSSMMPPSS TTyyppee DDeessccrriippttiioonn
Rated Input Voltage AC 100 ~240V
Operating Input Voltage AC 80 ~420V
Rated Input Frequency 50 / 60Hz
Operating Input Frequency 47 ~63Hz
Rated Output Voltage, Current 12V(DC), 0.5A/5V(DC), 1A
4140
Limited Warranty Statement
7.3
Battery
IItteemm DDeessccrriippttiioonn
Capacity 3.6V Ni-Mh / 1,00mAh(3.6V Li-ion/1,400mAh)
Talk time / Standby time 4 Hours / 120Hours (2.5Hours/80Hours)
Charging time duration 3.5 Hours
Limited Warranty Statement
General Information
General Information
Limited Warranty Statement
LG ELECTRONICS Inc. represents and
warrants that this subscriber unit and its
accessories (‘PRODUCT’) is free from defects
in material and workmanship.
This warranty is subject to the following terms
and conditions;
1. This warranty of the PRODUCT extends for
a period of 12 months commencing from
the date of purchase or 15 months from
the date of manufacture whichever is less,
except for the battery, for which the
warranty is 6 months from the date of
purchase or 9 months from the date of
manufacture whichever is less.
2. During the warranty period, LG
ELECTRONICS Inc. or its authorized service
network will repair or replace, at LG
ELECTRONICS Inc.’s option, the
PRODUCT or any relevant parts thereof in
the event that the PRODUCT is found to
be defective.
The repaired PRODUCT or the
Product/part provided as a replacement for
a defective PRODUCT/part, shall be free
from defects. The END USER/consumer
purchaser of the PRODUCT or his/her
assignee (‘CONSUMER’) shall not be
charged (whether for parts, labour or
otherwise) for the repair or replacement of
a defective PRODUCT during the warranty
period. All replaced parts, boards or
equipment shall become the property of LG
ELECTRONICS Inc.
3. The warranty in respect of a repaired or
replaced PRODUCT/part shall extend for
4342
Limited Warranty Statement
the remaining warranty period of the
repaired PRODUCT or replacement thereof
to the CONSUMER.
4. Upon request from LG ELECTRONICS Inc.,
the CONSUMER may be required to
provide the purchase receipt or other
documentation or information in respect of
the date and place of purchase.
5. The CONSUMER shall have no coverage or
benefits under this warranty in the event
that any of the following conditions are
applicable:
(a) The PRODUCT has been subject to
abnormal use or conditions, improper
storage, exposure to excessive moisture or
dampness, exposure to excessive
temperatures, unauthorized modifications,
unauthorized repair (including but not
limited to use of unauthorized spare parts
in repairs), abuse, accident, Acts of God,
spills of food or liquids, improper
installation and breakage or damage to
antennae (otherwise than by reason of any
defects in material or workmanship).
(b) LG ELECTRONICS Inc. has not been
notified by the CONSUMER of the defects
of the PRODUCT during the applicable
warranty period.
(c) The PRODUCT serial number code or the
accessory date code has been removed,
defaced or altered.
(d) The PRODUCT has been used with or
connected to an accessory (i) not
supplied by LG ELECTRONICS Inc. or its
affiliates, (ii) not fit for use with the
PRODUCT or (iii) used otherwise than in
Limited Warranty Statement
Limited Warranty Statement
Limited Warranty Statement
the manner intended.
(e) The seals of the PRODUCT’S battery
enclosure have been broken or show
evidence of tampering or the PRODUCT’S
battery has been used in equipment other
than that for which it has been specified
usable by LG ECLECTRONICS Inc.
(f) All plastic surfaces and all other externally
exposed parts that are scratched or
damages due to normal customer use.
(g) Breakage or damage to antenna unless
caused by defects in material or
workmanship.
6. In order to derive benefits of this warranty
in respect of any defects in the PRODUCT,
the CONSUMER shall ship the PRODUCTS
or part thereof at its cost to the authorized
service center of LG ELECTRONICS Inc. LG
ELECTRONICS Inc. shall bear the cost of
shipping the PRODUCT or part thereof
back to the CONSUMER after the
completion of the service under this limited
warranty.
NO OTHER EXPRESS WARRANTY IS
APPLICABLE TO THIS PRODUCT. THE
DURATION OF ANY IMPLIED
WARRANTIES, INCLUDING THE IMPLIED
WARRANTY OF MARKETABILITY OR
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE OR USE IS LIMITED
TO THE DURATION OF THE EXPRESS
WARRANTY HEREIN. LG ELECTRONICS
Inc. SHALL NOT BE LIABLE FOR THE LOSS
OF USE OF THE PRODUCT,
INCONVENIECE, LOSS OR ANY OTHER
CONSEQUENTIAL DAMAGE, ARISING
4544
OUT OF THE USE OF, OR INABILITY OF
USE, OF THIS PRODUCT OR FOR BREACH
OF ANY EXPRESS OR IMPLIED
WARRANTY, INCLUDING THE IMPLIED
WARRANTY OF MARKETABILTY OR
MERCHANTABILITY OR FITNESS
PPLICABLE TO THIS PRODUCT.
7. It is hereby expressly clarified that all
warranties (express or implied) in respect
of the PRODUCT are provided by LG
ELECTRONICS Inc. alone.
Appendix FCC RF Exposure Information
Appendix FCC RF Exposure Information
Limited Warranty Statement
Limited Warranty Statement
AAppppeennddiixx FFCCCC RRFF EExxppoossuurree
IInnffoorrmmaattiioonn
WWAARRNNIINNGG!!
The antenna used for this transmitter must
not exceed 3.0dBi and must be installed to
provide a minimum separation distance of 20
cm from all persons.
CCAAUUTTIIOONN
Use only the supplied and approved antenna.
Use of unauthorized antennas or
modifications could impair call quality,
damage the phone, void your warranty and/or
result in violation of FCC regulations.
Do not use the phone with a damaged
antenna. If a damaged antenna comes into
contact with skin, a minor burn may result.
Contact your local dealer for a replacement of
antenna.
FFCCCC PPaarrtt 1155 CCllaassss BB CCoommpplliiaannccee
This device and its accessories comply with
part 15 of FCC rules.
Operation is subject to the following two
conditions:
(1) This device and its accessories may not
cause harmful interference, and (2) this
device and its accessories must accept any
interference received, including interference
that may cause undesired operation.
47
LGE Service Center List
46
LGE Service Center List
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
1Andhra Pradesh Guntur Vasavi Associates Door no 6-20-4, Swarnalok complex, 4/1 Arandal Pet, Mr. Satyam 0863-2233678,
Guntur-522003 9848105789,
09394155554
2Andhra Pradesh Hydrabad Sri Varun Electronics D.No 5-8-344/1, " DHAN BHAGYA ESTATE ", Chirag Ali Lane, Abids, Mr. Raghavendra 040-55781999,
Next to Raghava Ratna Towers, Hyderabad- 500 001 040-55253888,
040-56878822,
09391001463
3Andhra Pradesh Hydrabad JVR Infotech Pvt Ltd Shop No 8, Vanijya Vihar, Nalanda Building, EV Ramakanth 040-24161848,
Dilsukh Nagar Main Road, Hydrabad-500060 040-55109604,
040-56524157,
09391131067,
040-36060606
4Andhra Pradesh Hydrabad S V Electronics Shop No. 41, Nilagiri Block, Aditya Enclave, Mr. Vankteshwara 040-55754477/
Ameerpet Main Road, Hydrabad-500038 Rao 55343030
5Andhra Pradesh Hydrabad Reliable G-8, 3-6-561, AALTO'S A & M Trade Centre, Mr. Mahesh Heda 04030913251,
Communication HIMAYATNAGAR, HYDERABAD - 500029 09346320705,
09849251173
6Andhra Pradesh Hydrabad Shweta Shop No.9, Ground Floor, Pavani Ansuya Complex, Mr. Sandeep 040-55918841,
Communciations Opp. Huda Complex, Tarnaka, Hyderabad Heda 040-55918842,
09346698606
7Andhra Pradesh Kurnool R K LG CDMA #40-37-J1, Opp. Indian Bank, Near Balaji Hotel, Kurnool- 518002. Mr.Paraveen 08518-220201,
Krishna 09393810688
8Andhra Pradesh Nellore Siri Enterprises Opp. Archana Thearter, A C Centre, Nellore PIN-524001 Mr. Paraveen 09398309571,
09347000000
9Andhra Pradesh Rajamund Siri Infotech Police Welfare Complex, City Hospitals Junction, Mr. Raghvendra 0883-2421567,
-hary Danvai Pet Main Road, Rajhamundry-533103 09397925799
10 Andhra Secundr Shweta # 1-7-69/1 & 2, OPP Aditya Delux Hotel, Near Paradaise circle Mr. Jagdish 040-55334180,
Pradesh -abad Computers Sarojini Devi Road, Secunderabad - 500003 040-27721076,
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
09396532358,
09391041673
11 Andhra Pradesh Tirupathi CMT Computer 18-1-624 VV Mahal Road, OPP HDFC BANK, Mr. K Vasu Naidu 0877-5561979,
Services Tirupathi, PIN-517501 09393620209
12 Andhra Pradesh Vijaywada K L Computer 39-9-46 SVS Temple Street, Labbipet, Mr. Kartik 0866-5520461,
House Vijaywada PIN- 520 010 5671461,
09392105222
13 Andhra Pradesh Visakhapa GVS G5, Ground Floor, Backside of Sangam-Sarat Theatre, Mr. Satish Kumar 0891-2598610,
-tnam Enterprises 1st Lane, Dwarka Nagar, Visakhapatnam - 530 016. 9394206074
14 Andhra Warrangal S S Marketers 6-1-73/1,Sai Bhavan, Sridevi Theatre Road, Hanamkonda, Mr. L.Srinivas 0870-2552223,
Pradesh Warrangal-506001 Rao 09390100708
15 Andhra Kakinada
Delta Infotech
Pradesh Door No. 6-1-29, Opp. Swami Vivekananda Park, Mr. Shivanand 0884-5593533
Jawahar Street, Surya Rao Pet, Kakinada - 533001 9346846009
16 Bihar
Patna Company
Infotek Trading 1st floor, City Palace, New Dak Bunglow Road, Patna-800001 Sanjay Chowbey 0612-2227166
17 Bihar Patna Competent Shop 1, Hotel Lalitha Complex, East Bowring Canal Road, Mohit Ahluwalia 9334022706
Mobile Service Patna
18 Delhi Delhi Comhard Systems D-30, 31, First floor, Near Hotel Shipra, Mr. Ravi Kant 011-30955887,
Main Vikas Marg, Lakshmi Nagar Gupta 9818867678
19 Delhi Delhi Innovative Telecom 305, Aggarwal Millenium Tower, Netaji Subash Place, Mr. Manoj Garg 011-55154343,
Pitam Pura, Delhi-110088 9811682453,
011-30925753
20 Delhi Delhi Sagar Technologies W-8, First Floor, Main Patel Road, West Patel Nagar, Mr. Deepak / 9810320170,
New Delhi - 110008 Mr. Amit 011-55433100
21 Delhi Delhi Sagar J-39, Central Mkt, Lajpat Nagar-II, New Delhi-110024 Mr. Prabhat 011- 55425644,
Technologies 011-55425645
22 Delhi Delhi Ucom Technologies 45, 1st Flr, Corner Mrkt, Malviya Nagar, New Delhi - 110017 Bhuwan Chandra 011-26675900 ,
Pvt Ltd. 55655382,
09313088818
23 Delhi Delhi Nice Telecommunica 15/23,First Floor, DDA Complex, Nangal raya, Anurag 011-28521044,
-tion D Block, Janakpuri, Delhi - 110046 9810778310
4948
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
24 Delhi Delhi Telecom Touch Tone B-52, First Floor, Kalkaji, New Delhi Ashish Dey 011-30939031
25 Delhi Delhi Cube Engineers and A-65, Naraina Industrial Area, Atul Gupta 09312224103,
Consultants Pvt Ltd Phase-1, New Delhi 011-55450272,
51411623
26 Delhi Delhi Comhard Systems B-120, Hardev Puri, 100 Feet Main Road, Near MTNL Office, Mr. Ravi Kant 011-39572430,
Nathu Colony Chowk, Shahdra, New Delhi - 110 093. Gupta 011-39572427
27 Delhi Delhi R K Communications 2516 Hudson Lines, Kingsway Camp-Nr. Kamla Nagar , New Delhi
Mr. Pradeep Aggarwal
011-39508861
28 Delhi Delhi Arham Infotech 1/1, Regal Building, Near Malik Sweets, Connaught Place,
Mr. Anil Surana
9350286361
Services New Delhi - 110 001. 9350286361
29 Gujarat Ahmedabad
Visual Enterprises
104, Saarthak Complex, behind Urja House, Swastik Char Rasta, Vallabh Patel 079-26463305,
Navrangpura, Ahmedabad-380009 09376171851
30 Gujarat Ahmedabad Silicon Valley F/6,Silver lake, Jagabhai Park, Rambaug Road, Rajesh Patel 079-5430634,
Maninagar, Ahmedabad-380008 9824025430
31 Gujarat Ahmedabad Mishree 75,Management Enclave, Opp. Indraprastha Mitesh Patel 9327037582,
Communication Bungalows, Vastrapur, Ahmedabad. 079-55314224,
9327800611
32 Gujarat Ahmedabad
A Com Technologies
Shop No-40, 1st Floor, Shubh Complex, Near Rajasthan Hospital, Vijay.S.Gohel 9824544230,
Camp Road, Shahibaug, Ahmedabad-380004 079-30940560
33 Gujarat Bhavnagar Teletext Gold G/8,Radheshyam Complex,Radha Mandir,Vaghavadi Nilesh Bagadia 0278-2415545,
Road,Bhavnagar-364001 9824497766
34 Gujarat Gandhinagar Creative Shop No 102, Suman City, Sector 11, Gandhinagar-382011 K.J.Barot 079-23226241,
Communications 9825059590
35 Gujarat Jamnagar Sudarshan 3, Prerna Building, Cricket Bunglow-3, Indira Nagar, Jamnagar Amit Unadkat 0288-2552696,
Infosys 9824478203
36 Gujarat Rajkot Roopang infocare
Vinod Nivas, 4, Sardarnagar(West), Nr Astron Cinema, Rajkot-360001
Kalpesh Rugani 0281-2464485,
09374103622,
9824068880
37 Gujarat Surat Excel Solutions G-48, Ascon Plaza, Anand Mahal Road, Adajan Surat-395009 Nitesh Jain 0261-5544500,
09327344500,
9825399870
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
38 Gujarat Surat Omsai Services 37,Golden Point, Near Science Laboratory, Dharmesh Patel 0261-5593716,
Ring Road, Surat -3940003 9374710610,
9825406129
39 Gujarat Vadodra
Aashnik Infotech
F 50,National Plaza, R.C.Dutt Road, Alkapuri, Vadodara-390005 Aashish Parmar 0265-3112123,
3090969,
9327230793
40 Gujarat Vapi Klassik Statino 116,Bhanudarshan Co-Op Society, Koparli Road, Avishek Suhasaria 0260-3092363,
Products Near Gunjan Cinema, GIDC, Vapi 9377000911
41 Haryana Ambala Bee Ess Aar 92-93, Gandhi market, Ambala Cantt-133001 Rajiv Gupta 0171-2641234,
Communication 9416021234
42 Haryana Faridabad Hi-Tech 105, Sector 10, Faridabad-121006 Rahul Jindal 0129-2223422,
Communication 9810456663
43 Haryana Gurgaon Signature B-100 A, South City -1, Opposite - Huda Gymkhana Raj Kumar Garg 0124-3956565,
Communications Club - Gurgaon 122001 0124-5102709
44 Haryana Karnal Mass Communication 7, Dayal Singh Colony, Kunj Pura Road, Ms Pinki 0184-3090717,
Karnal-132001 09896354205
45 Haryana Panipat INS Telecom 2,Bishan Sarup Colony, Opp Bus Stand, Near Hotel Deep, Panipat Sachdeva 0180-3091860,
Jagdeep 5005360,
9812072860
46 Haryana Rohtak
Telecentre
Shakti Market, Civil Hospital Road,
Mr. Madaan 01262-247242,
Near Chhotu Ram Chowk, Rohtak-124001 9896243092,
09355671666
47 Haryana Sonipat
Teleworld
Ground Floor, Main Market, Main Railway Road, Vipin Dua 1303090889
Opp. Old Civil Hospital, Sonipat - 138001.
48 Haryana Yamunanagar Manish Shop No.3, Sharma Colony, Near Mahindra Petrol Bunk, Vinod Kumar 9355327374
Communications Yamunanagar - 135005 Mittal
49 Jharkhand Jamshedpur Tirupati Teletech Chakravarti Compound, Near Hotel Castel, Abhijeet 09334800350
Contractors area, Bistupur, Jamshedpur-831001 Mukherjee
50 Jharkhand Ranchi Satya Systems 158, Opp Hotel Palace, Kadru, Ranchi-834002 Amit Rastogi 0651-2341361,
& Solutions 9835167667
5150
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
51 Karnataka Bangalore Meenakshi #129, Lalbagh Main Road, Bangalore-560027 Mr. Ramesh. 080-56992943,
Electronics 30617345,
09341210375,
51146822
52 Karnataka Bangalore Optima Mobile 24/2, Rajkumar Road, Near Subramanyanagar Police Station, Unni Krishnan 080-23131953,
Services 1st Block, Rajajinagar, Bangalore - 560 010. 080-57722205,
09341266656
53 Karnataka Bangalore Optima Mobile B-3, Mallikaarjun Complex, Opp R T Nagar Police Prasad 8030610202
Services Station, 80 Feet Road, R T Nagar, Bangalore-560032
54 Karnataka Bangalore Pranav infocom 91/92, Hemachandra complex, Near VGP Show room, S.V.Sirish 080-56697937,
4th block, jayanagar, Bangalore-560011 26552551
55 Karnataka Bangalore Pranav infocom 267/1,1st Main Road, 6th Cross, Behind Shanti S.V.Sirish 80-56969937,
Sagar, Domlur Layout, Bangalore-560071 51256309
56 Karnataka Bangalore Ascent No:113, St Johns Church road, Bangalore - 5 Naveen 080-30914856
Communication
57 Karnataka Belgaum Hello India Telecom G-4, Maratha Mandir Complex, Khanapur Road, Sanjay 9845327531,
Near Railway Flyover, Belgaum - 590 001. 09341101800
58 Karnataka Hubli Networld shop no : B6, Laxmi complex, Court circle, Hubli- 580020 Mr. Mahendar 0836-3090671,
98452-54251,
0836-3090671
59 Karnataka Mangalore Innovative Infocom 15-10-537/11, Jayavarma Centre, Mallikatte Circle, Sebastin 0824-56632441
Kadri, Mangalore - 575002. Fernades
60 Karnataka Mysore K.K.Marketing, 1432/9, Tribhuvan Towers, opp Vetenary Hospital, Mr. Karunakaran. 09342115003,
Dewan's Road, Dhanwantri Road Cross, Mysore -570001 09342120789
61 Karnataka Gulbarga Aishwaraya G-15, G.R. Complex, Opp Mini Vidhan Soudha Mallikarjun 9342356000,
Communication Main Road, Gulbarga 9342355116
62 Kerala Ernakulam Zenicon Infocom(P) 2nd floor, Tharian's Building, opp. Ship Yard, M.G. Road, Jaimon Joseph 0484-2359511,
limited Ernakulam-682015 9349271511
63 Kerala Irinjalkuda Akbar Mobiles 376-44, Near St. Josephs college junction, Mr. Sebastian 0480-830796
Irinjalakuda-680121
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
64 Kerala Karunaga pally Supreme Enterprises Opp to KSRTC Bus stand, Karunagapally-690518 Mr. Ratish 0476-2620282
65 Kerala Kollam Digital Infosystems MC-3087, New Block, Bishop Jeromi Nagar, Johnson 0474-2760647,
Chinnakada, Kollem-691001 Lawrence 9846007059
66 Kerala Kottayam SVM NSS Builbing, Near Pallippurathukavu Temple, Kodimapha, Rajesh K S 0481-2565303,
Technologies Kottayam - 686 002 9847310123
67 Kerala Kozhikode Domain Domain Infosystems, 2nd Floor, Darussalam Complex, Mukundan 0495-2722222
Infosystems Mavoor Road, Kozhikode - 673 004
68 Kerala Manjeri Integrated Computer Royal Tower, TB Road, Manjeri - 676121 Mr. Thomas 0483-3099686
Systems Chacko
69 Kerala Mavellikarr Ettutharayl Ettutharayil complex, K P Road, Kayamkulam-690502 Anu T cheriyan 0479-2441760,
Agency 09388900025
70 Kerala Pallakad Akbar Mobiles N.S. Towers, Kalamandapam junction, Suresh 0491-2529829,
Palakkad - 678 001 9847086446
71 Kerala Thiruva Appolo TC 20/2392, Kalpalayam, Karamana P.O., Thiruvananthapuram Santosh 0471-2340523
nanthapuram Systems - 695 002.
72 Kerala Trichur Akbar Mobiles Kadarathodh Building, North Bus stand, Trichur - 680 001 Sojan 0487-2323424
73 Madhya Pradesh Bhopal Neha Sales F-104, Anmol Tower, E-5/14, Commercial Zone, Ashok Hirwani 0755-5277247
Corporation Arera Colony, Bhopal-462016 2424088,
9826072327
74 Madhya Pradesh Gwalior Computer Clinic Global Appartments, City Centre, Opp Income Tax Office, Rishi Sharma 9329302200
Gwalior.
75 Madhya Pradesh Indore Neha Sales Shop No.18, Ground Floor, Johari Palace, Ashok Hirwani 0731-5091833,
Corporation M.G.Road, Indore - 452001 9826072327
76 Madhya Pradesh Jabalpur S M Shopee 846, Chattarpur Bhavan, Nr. Ashoka Hotel, Wright Town, Vikas Jain 0761-5063183
Jabalpur,Pin 482002
77 Chattisgarh Raipur Cybernet B-2, 1st Floor, Garchaz Complex, Jail Road, Raipur - 492001 Anand Singh 9826132918
Systems 9826132918
78 Madhya Pradesh Ujjain Galaxy Computers & 43/2, Varruchi Marg, Opp Madhav Nagar Police Amitabh 9893003099
Communication Staion, Freeganj, Ujjain Chhajhlani
79 Maharashtra Amravati Scorpio Services Shop No. 84, Ground Floor, GulshanTowers, Nr. Panchasheel Cinema, Mr. Pramod 0721-2567302,
5352
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
Amrawati, Pin-444601 09370151826,
9422156874
80 Maharashtra Aurangabad Unique Shop no.108/B, Behind Sajawat Handloom, Tapdiya Super Market, Mr. Mahesh 0240-2356447,
Teletmatics Nirala Bazar, Aurangabad-431001 9823007730,
09325210364
81 Maharashtra Chinchwad Ritz Shop No 22, Gawde Kunal garden, Pimpri-Chinchwad Link Mr. Reyaz 020-7485613,
(Pimpri) Communication Road, Chinchwad, Pune-411033 020-30961900,
09890339777
82 Maha rashtra Jalgaon Saranag B-288, Golani Market, Jalgaon Mr. 982331703
Services P.M.Waghanna
83 Maha rashtra Kohlapur SMS Services S5, Diwan Tower, Opp. Nutan Marathi School, Prakash Patil 0231-2541120,
Near Mirajkar Tikkty, Kolhapur, Pin -416005. 9823026120
84 Maha rashtra Margoa Comlink Ground Floor, Shop No.i, Garden view building, Sunil 09326105629,
Synergies India Next to UTI Bank, Near Margao Municipal 9822101522,
Pvt Limited. Garden, Margao-403601 09326105637
85 Maha rashtra Nagpur Spectrum Shop No.2, Dharampeth Towers, West High Court (WHC) Sonali 0712-3095700
Marketing Road, Dharampeth, Nagpur - 440010 5618186,
2527823
86 Maha rashtra Nasik MOBS SHOP NO. 12, FIRST FLOOR, KAPOTE-MEHER' MARKET, Girish Bhangre 0253-5623613,
Associates RENUKA NAGAR, WADALA NAKA, DAWRKA, NASIK - 422 001. 09370291070,
09371531078
87 Maha rashtra Panjim Comlink Shop No. 5, Dr Atmaram Borkar Road, Next to RIL Mutual Fund, Sunil 9326105629
Synergies India Pvt Ltd Panjim, Goa-403001
88 Maha rashtra Pune Digital Shop No. 5, Indulal Complex, Besides Kaka Halvai, A Ahmed 020-4012921,
Concepts LBS Marg, Navi Peth, Pune-411030 09371029798
89 Maha rashtra Pune Mobile World G-25, AKSHAY COMPLEX, DHOLE PATIL ROAD, PUNE-411 001 Pawan Mantri 098230 93335
90 Maha rashtra Sangli Ramesh Opp. Kanya Purohit prashala, Rajwada, Sangli-416416 Suresh Shegane 0233-2327601,
Electronics 9823085176,
09372107601
91 Maha rashtra Solapur Jawaharlal 184, Gold Finch Peth, nr Hotel Ritesh, Solapur - 413007. Prasanna J 0217-2725030,
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
Radio Service Chavan 9422458830,
9823317081
92 Mumbai Kalyan Vintech SHOP- 14, GROUND FLR, ARCHIES APARTMENT, Pawan 09322877555
Solutions OAK BAUG,KALYAN-421301
93 Mumbai Vasai E-Link Shop No.5, Type C, Bldg no.5/6, Shanti Vihar,
Kamlesh
022-28552087,
Solutions Mira Road -E, Pin Code : 401107. 09323182084
94 Mumbai Mumbai Asbolute A007, Vishal Shopping Centre, Next to Vishal Hall, Arun 022 39544800,
Networks Near Station, M.V.Road, Andheri (E), Mumbai - 400 069 9322252390
95 Mumbai Mumbai Bombay Telecom 211, 212, Navjeewan Commercial Society. Building No:3., Tejinder Singh 9323900612,
Services
Second Floor, Above Hasmukh Tea, Mumbai Central (E), Mumbai: 400004.
Kalha
96 Mumbai Mumbai
Sai Tele Services
A-110, Satyam Commercial Complex,M.G.Road, Ghatkoper (E), Mr. Suresh Kotle 022-56299540 ,
Mumbai - 400 077. 39533603,
9820188338
97 Mumbai Mumbai Creative Solutions SHOP NO 6 AMBIKA COOPERATIVE HOUSING SOCIETY, JAWAHAR Anand 022-28769003,
NAGAR ROAD NO 2 NEAR RAILWAY CROSSING, GOREGAON 022-39533603,
WEST, MUMBAI 400062 9820188338
98 Mumbai Mumbai LG Service Centre Third Floor, Trade World,Kamala Mills Compound, Rajib Saha 022-24947375,
Senapati Bapat Marg, Lower Parel, Mumbai-400013 09323190401
99 Mumbai Thane Vinay Technologies Shop no 3, Minal Chhaya Aptt, Muncipal Corporation Road, Vinod Jakotiya 022-25304960,
Pvt Ltd Panch Pakhadi, Thane (W) - 400601 9821068231,
09322213342
100 Mumbai Navi
Hello World
Shop No 53,GF, Welfare Chambers, Sector-17, Vashi, Mahesh 022-27657705,
Mumbai Mumbai-400703 09322641396
101 Mumbai
Khar(W) Telecom
Komplex 1,Satguru Shopping Center, IIIrd road, Khar(W), Mumbai Mr. Mohammad 022-26461917,
Corporation 09323395024
102 Mumbai Panvel Oceanic Tele System Shop No.10, Prajapati Arcade,Sector 15, New Panvel (E), Shailash Bobade 022-56104542,
Dist. Raigad. 09322217221
103 Orissa Bhubneshwar S.A.INFOSYS 291.Bomikhal, Opp.Akamra cinema hall, Bhubaneswar-751010 Sarabjeet Singh
0674-2573113/ 4
104 Orissa Cuttack O.A. INFOTECH Behind Govt Bus Stand, Badambadi, Cuttack -753012 Manas Mahapatro 0671-2312613
105 Punjab Amritsar Bajaj 87, G Floor, Nehru Complex, Lawrence Road, Suman Bajaj 09356024827,
5554
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
Telecommunication Amritsar-143001 9814650314,
0183-3958859
106 Punjab Barnala Unique Infotech Mittal Street, Near M C Office, Barnala-148101 Pankaj Goyal 01679- 238007
107 Punjab Bathinda Lalli's Lalli's 1139-A, First Floor, Amrik Singh Road, Ashok Kakria 0164- 2239500
Gallery Nr Gole Diggi, Bhatinda-151005 2236337,
9814222310
108 Punjab Chandigarh Vignesh Services
S.C.O- 189-90, Sec- 34,Chandigarh
Mukesh Arya 0172-3018028,
09316134655
109 Punjab Hoshiarpur Kuldip's Dhobian Wali Gali, Phagwara Road, Hoshiarpur-146001 Kuldip 01882-226906,
Mobile Care 9815073906
110 Punjab Jallandhar Mobile Center Shop No-7, Gobind Market, Jogesh Diwan 0181-3092666,
Opp-Beri Hospital, Nakodar Road, Jalandhar. 9814029696,
9815314060
111 Punjab Ludhiana Shahi Shop No.5, 4X International, 583 L, Model Town, Amit Shahi 0161-3944190
Communication Ludhiana
112 Punjab Malerkotla Prime Opp. Main gate, Govt College, MalerKotla-148023 Rohit Bansal / 01675-253899,
Infocomm Raj Verma 9814040066,
01675-331979
113 Punjab Moga
Super
Pawan Market, Opp shankar Batteries, Court Road, Moga-142001 Jai Deep Mehta 9356314398
Communication
114 Punjab Patiala Image Services 84, First Floor, Leela Bhawan, Patiala-147001 Rohit Bansal 0175-2222796,
9815761262
115 Rajasthan Jaipur
Kamakshi Telecom
105,1st floor,Paradise, C-61(A), Sarojini Marg, Rahul Bhargav 0141-2365575,
C-Scheme, Jaipur-302001 09314512863
116 Rajasthan Jaipur Alpha Infotech F-1, First Floor, Krishna Mall, Lakshmi Mandir Crossing, Shatrughan 0141-5106777,
Systems Tonk Road, Jaipur-302015 Mangal 09314717171
0141-3099724
117 Rajasthan Jodhpur Omega UG/4, Adeshwar Tower, Main Chopasani Road, Pratap Singh 0291-3091214,
Electronics Opp.Gehlot Watch Co, Jodhpur-342003 09314717171
118 Rajasthan Kota Cyber 26, Ground floor, Kalawati Paliwal market, Shyam 0744-2398153,
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
Infosystems Gumanpura, Kota-324007 Maheshwari 09352603354,
09352620153
119 Rajasthan Udaipur Ficusa 13, Darshanpura, Opp. M.B. Commerce College Gate, Virendra Ranka 0294-2410002,
Enterprises Nr Computer Zone, Udaipur-313002 2413002,
09314410002
120 Tamilnadu Chennai Unicare Infocomm 73, Nutech Plaza, Shop no G-3, G Floor, Arcot Road, Kodambakkam, R M Rajesh / 044-24724666,
Services Chennai - 600 024. Kartik 9841036466
121 Tamilnadu Chennai GS Systems 547/352, F M Towers, Mount Road, Nandanam, Kanirajan 044-24330889,
Chennai-6000035 9884160010
122 Tamilnadu Chennai U Com Technologies Shop#3, Door # 24, New #30, Balfour Apartments, Shyam 044-52174656 ,
Pvt. Ltd. Balfour Road, Kilpauk. Chennai - 600 010. 52175115,
9884187800
123 Tamilnadu Chennai Escomm Systems No 57-7, Arunodaya Apartments Next to Hotel Sindhoori, Mrs N S Vijaysri 044-30901688,
India P Ltd Near by Everest Bus Stop, Ponnamalai High Road, Chennai-600003 25612212
124 Tamilnadu Chennai
Genesis 63/3, First main road, Gandhi Nagar, Adyar, Chennai-600020
Mr. Suresh 044-24401188
Communication
125 Tamilnadu Coimbatore Fast Track Sudera Complex, 354B, 100 Feet Road, COIMBATORE - 641012 Anand Prakash 0422-2490577,
9843080040,
09363100080
126 Tamilnadu Cuddlore Kasturi NO: 37 (2C) BHARATHI ROAD, CUDDALORE. Mr. Raghupati 04142-220183
Cellular Service 607 001, CUDDALORE DISTRICT, TAMIL NADU.
127 Tamilnadu Erode JANS Electronics 148, Mettur Road, Opposite shakti vinayak temple, Dana Complex, M Kanan 0424-2258526,
Erode-638011 9443263508
128 Tamilnadu Madurai Devaa Electronics No.4, Thirumakulam North Street, Near Ayyappan koil, Guna 0452-5360995,
Thhallakulam, Madurai-625002 0452-2526179,
09344107995
129 Tamilnadu Pondicherry Digital Logistics 126/2, Perumal Koil Street (Bharathi Street Cutting), G Singaravelu 9843093348,
Pondicherry-605001 09345455351,
0413-5210148
5756
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
130 Tamilnadu Salem Global Care Service Sixer Complex, 121/19A, Sarada College Road, Vasudev Nayak 0427-3090535
Next to Abi Medical Centre, Salem - 636007
131 Tamilnadu Thanjavur Z M Electronics 33, New Municipal Shopping Complex, Opp LIC, Gandhi Ziauddin 04362-272595,
ji road, Thanjavur-613001 09360313254
132 Tamilnadu Tirunevelli Classic 39, Trivendrum Road, Opposite Kalimark, Welcome Complex, Erkins 0462-2575801
Electronic Palayamkottai, Tirunilveli-627002
133 Tamilnadu Tirupur Shri Vasavi # 155-303, Mangalam Road, Karuvam palayam, MR.U.B. 0421-3091438,
Electronics Tirupur -641604 Bala Murali 98422-74300,
09363005560
134 Tamilnadu Trichy S K Electronics Raj Complex, 9/A EVR Road, Puthur, Trichy- 620017 Krishnan 0431-2771946,
9843178104,
09345101502
135 Tamilnadu Vellore Matha
4, S.L.N Plaza, Opposite Odai Pilliar Koil,
Gunaa Shekhar 0416-2240800
Communication Gandhinagar, Vellor - 632006
136 Uttar pradesh Agra NSC Computers
Shop No G-124, Block No- 29, Sanjay Place,
Rajiv Singhal 0562-2520032,
Agra - 282 002 09319111350
137 Uttar pradesh Agra Space Consultancy & UG 1 & 2, & Opp. Jaihind Hotel, Merchant Chamber, Tanviir 9358311202
Services Sadar Bazar, Agra-282001.
138 Uttar pradesh Aligarh A V Computer G-1, Ganpati Plaza, Jha Compund, Vaibhav 0571-2506148,
Services Marris Rd, Aligarh-202001 9412274391
139 Uttar pradesh Allahbad B. P. G-11, Indira Bhawan, Ground Floor, Civil Lines, Ms Naina Pandey 0532-2608088
Electronics Allahbad-211001
140 Uttar pradesh Bareilly Sapan Infotech G - 64 A Kunwar Complex, Near Gupta Watch Co, Sanjeev Singh 9359102467
116 Civil Lines,Bareilly
141 Uttar pradesh Dehradun Krishna Shop No 15A, Meedo Plaza, Rajpur Road, Vinod 0135 3090895,
Communication Dehradun, Uttaranchal-248001 09358112922,
09358119696
142 Uttar pradesh Ghaziabad Concessionair C-83, Rajnagar District Center (RDC), Ghaziabad Arun Sharma 0120-3092011
Documentation
India Pvt Ltd(CDIL)
LGE Service Center List
LGE Service Center List
SSrrCCiirrcclleeCCiittyy NNaammeeAASSCCss AAddddrreessss PPeerrssoonnCCoonnttaacctt PPhhoonnee
143 Uttar pradesh Gorakhpur Eternal Electronics Shop No.11, Pandey Complex, 33, Kasya Road, Ram Pratap 0551-2204520
Opp DIG Bunglow, Gorakhpur -273001
144 Uttar pradesh Kanpur AR Infotech 111/402, Ashok Nagar, Kanpur Pin 208012 Manoj Shukla 0512 3111662,
9839068734,
0512-3093011
145 Uttar pradesh Lucknow NET COM 3 way road, City Point, Opp Krishi Bhawan, Kawaljeet 0522-3094222
Lucknow-226024
146 Uttar pradesh Meerut Systech Computers F-124/125 Ist floor Ganga Plaza, Begum Bridge Road, Vineet Goyal 0121-2691167,
Meerut-250002 09358416631
147 Uttar pradesh Muzaffarnagar Jai Computer Shop No. 4, 1st Floor, Roorkee road, Near Shiv Chowk, Manohar Singh 0131-2635483,
Services Central Bank Mkt, Muzaffarnagar-251001 9412110215
148 Uttar pradesh Noida M R Telecom J-45, First Floor, Sector-18, NOIDA-201301 Kailash Aggarwal 0120-2591440,
9871197801
149 Uttar pradesh Saharanpur Maharaj Near Maharaja Palace, Delhi Road, Pankaj Malhotra 0132-2720881,
Communications Saharanpur-247001 09358311202
150 Uttar pradesh Varanasi Shivam Mobile Shop No.5, B37/115-B-1 Baradari Complex, Rishi Mohan 0542-2363296,
Distributers Rathyatra Crossing, Varansi Pin 221010 9839241004
151 W Bengal Assansol Sky Computer Islam Market, Nuruddin Road, Assansol-713301 Syed Arshad Ali 0341- 2207719,
& Telecom 9832160886
152 W Bengal Burdwan San Infosys Tikonia Bus Stand, Central Mkt, GT Road, Sanjit Debnath 0342-3090265,
Burdawan-713101 9832192170
153 W Bengal Calcutta Benma P-168/1 CIT Road, Scheme VIIM, Arun Surana 033-30943176
Infosol Pvt Ltd. KOLKATA 700 067
154 W Bengal Calcutta JP Computers 5B Ekdalia Place, Kolkata - 700019 Somim Kabir 033-24401923
155 W Bengal Calcutta Jaksom Block-A, Shop-1, Ambika Vihar, 1/1 Harduttrai Chamaria P.Mukherjee 033- 30950383
Engineering Pvt Ltd Road, Howrah- 711001
156 W Bengal Calcutta Skylink 8/1A, Little Russel Street, Calcutta-700071 H R Molla 033-30903814,
033-32091037
157 W Bengal Durgapur Tech International Red Cross Road, City Centre, Durgapur-713216 Amitava Banerjee 0343-2546893,
9434002244
58
Licensed by QUALCOMM Incorporated under one or more of the following Patents:
U.S, Patent No. 4,901,307 U.S, Patent No. 5,056,109 U.S, Patent No. 5,099,204
U.S, Patent No. 5,101,501 U.S, Patent No. 5,103,459 U.S, Patent No. 5,107,225
LGE CDMA Fixed Wireless Phone LSP-430
LGE CDMA Fixed Wireless Phone LSP-430
P/N : MMBB MAR/2007/ISSUE 1.0
PRINTED IN KOREA

Navigation menu
