Users Manual
Some of contents in this manual may differ
from your phone depending on the software of
the phone or your service provider.
ME830d USER GUIDE
ENGLISH
ME830d
P/N : MMBB0226101(1.0) H
Part 15.21 statement
" Change or Modifications that are not expressly approved by the manufacturer could void
the user's authority to operate the equipment. "
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. if this
equipment does cause harmful interference or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help.
LIMITED WARRANTY STATEMENT
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be
free from defects in material and workmanship, according to the following terms and conditions:
(1) The limited warranty for the product extends for ONE (1) year beginning on the data of purchase
of the product.
(2) The limited warranty extends on to the original purchaser of the product and is not assignable or
transferable to any subsequent purchaser/end user.
(3) This warranty is good only to the original purchaser of the product during the warranty period as
long as it is in the U.S., including Alaska, Hawaii, U.S. Territories and Canada.
(4) The external housing and cosmetic parts shall not be covered under these limited warranty terms.
(5) Upon request from LG, the consumer must provide information to reasonably prove the date of
purchase.
(6) The customer shall bear the cost of shipping the product to the Customer Service Department of
LG. LG shall bear the cost of shipping the product back to the consumer after the completion of
service under this limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVER:
(1) Defects or damages resulting from use of the product in other than its normal and customary
manner.
(2) Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to
moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair,
misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the
fault of LG, including damage caused by shipping blown fuses spills of food or liquid.
(3) Breakage or damage to antennas unless caused directly by defects in material or workmanship.
(4) That the Customer Service Department at LG was net notified by consumer of the alleged defect
or malfunction of the product during the applicable limited warranty period.
(5) Products which have had the serial number removed or made illegible.
(6) The limited warranty is in lieu of all other warranties, express or implied either in fact or by
operations law, statutory or otherwise, including, but limited to any implied warranty of
marketability or fitness for a particular use.
(7) Damage resulting from use of non-LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to
normal customer use.
(9) Products operated outside published maximum ratings.
3
(10) Products used or obtained in a rental program.
(11) Consumables (such as fuses).
3. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED
WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED
TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL
NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS
OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, RISING OUT OF THE USE OF,
OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY
APPLICABLE TO THIS PRODUCT. Some states do not allow the exclusive of imitation of incidental
or consequential damages or limitations on how long an implied warranty lasts; so these limitations or
exclusions may not apply to you. This warranty gives you specific legal rights and you may also have
other rights which vary from state to state.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call the following web address:
www.lgeservice.com
8
For Your Safety
Important Information
This user guide contains important information on the use and
operation of this phone. Please read all the information
carefully for optimal performance and to prevent any damage
to or misuse of the phone. Any changes or modifications not
expressly approved in this user guide could void your warranty
for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the
bathroom, swimming pool, etc.
Always store your phone away from heat. Never store your
phone in settings that may expose it to temperatures less than
32°F or greater than 104°F, such as outside during extreme
weather conditions or in your car on a hot day. Exposure to
excessive cold or heat will result in malfunction, damage
and/or catastrophic failure.
Be careful when using your phone near other electronic
devices. RF emissions from your mobile phone may affect
nearby in adequately shielded electronic equipment. You
should consult with manufacturers of any personal medical
devices such as pacemakers and hearing aides to determine if
they are susceptible to interference from your mobile phone.
Turn off your phone in a medical facility or at a gas station.
Never place your phone in a microwave oven as this will
cause the battery to explode.
IMPORTANT! Please read the TIA SAFETY INFORMATION on
page 78 before using your phone.
Safety Information
Read these simple guidelines. Breaking the rules may be
dangerous or illegal. Further detailed information is given in this
user guide.
]Never use an unapproved battery since this could damage
the phone and/or battery and could cause the battery to
explode.
]Never place your phone in a microwave oven as it will
cause the battery to explode.
]Do not dispose of your battery by fire or with hazardous or
flammable materials.
]Make sure that no sharp-edged items come into contact
with the battery. There is a risk of this causing a fire.
]Store the battery in a place out of reach of children.
]Be careful that children do not swallow any parts such as
rubber plugs (earphone, connection parts of the phone,
etc.). This could cause asphyxiation or suffocation.
9
For Your Safety
]Unplug the power cord and charger during lightning storms
to avoid electric shock or fire.
]When riding in a car, do not leave your phone or set up the
hands-free kit near to the air bag. If wireless equipment is
improperly installed and the air bag is activated, you may be
seriously injured.
]Do not use a hand-held phone while driving.
]Do not use the phone in areas where its use is prohibited.
(For example: aircraft).
]Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as a
bathroom.
]Never store your phone in temperatures less than- 4°F or
greater than 122°F.
]Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. There is a
risk of this causing a fire.
]Do not drop, strike, or shake your phone severely. Such
actions may harm the internal circuit boards of the phone.
]Do not use your phone in high explosive areas as the phone
may generate sparks.
]Do not damage the power cord by bending, twisting, pulling,
or heating. Do not use the plug if it is loose as it may cause
a fire or electric shock.
]Do not place any heavy items on the power cord. Do not
allow the power cord to be crimped as it may cause fire or
electric shock.
]Do not handle the phone with wet hands while it is being
charged. It may cause an electric shock or seriously
damage your phone.
]Do not disassemble the phone.
]Do not place or answer calls while charging the phone as it
may short-circuit the phone and/or cause electric shock or
fire.
]Only use the batteries, antennas, and chargers provided by
LG. The warranty will not be applied to products provided by
other suppliers.
]Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in
accidents and consequently invalidate the warranty.
]Do not hold or let the antenna come in contact with your
body during a call.
]An emergency call can be made only within a service area.
For an emergency call, make sure that you are within a
service area and that the phone is turned on.
10
For Your Safety
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of he United
States, with its action in Report and Order FCC 96-326, adopted
an updated safety standard for human exposure to radio
frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with
the safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC guidelines and
these international standards.
CAUTION
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result in
violation of FCC regulations. Do not use the phone with a
damaged antenna. If a damaged antenna comes into contact
with skin, a minor burn may result. Contact your local dealer
for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with
the back of the phone kept 0.6 inches (2.0cm) between the
user’s body and the back of the phone. To comply with FCC RF
exposure requirements, a minimum separation distance of 0.6
inches(2.0cm) must be maintained between the user's body
and the back of the phone. Third-party belt-clips, holsters, and
similar accessories containing metallic components should not
be used. Body-worn accessories that cannot maintain 0.6
inches(2.0cm) separation distance between the user's body
and the back of the phone, and have not been tested for typical
body-worn operations may not comply with FCC RF exposure
limits and should be avoided.
11
For Your Safety
Vehicle Mounted External Antenna
(optional, if available)
A minimum separation distance of 8 inches (20cm) must be
maintained between the user/bystander and the vehicle
mounted external antenna to satisfy FCC RF exposure
requirements. For more information about RF exposure, visit
the FCC website at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC
rules. Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must
accept any interference received, including interference that
may cause undesired operation.
Cautions for Battery
]Do not disassemble.
]Do not short-circuit.
]Do not expose to high temperature: 60°C (140°F).]
]Do not incinerate.
Battery Disposal
]Please dispose of your battery properly or bring to your
local wireless carrier for recycling.
]Do not dispose in fire or with hazardous or flammable
materials.
Adapter (Charger) Cautions
]Using the wrong battery charger could damage your phone
and void your warranty.
]The adapter or battery charger is intended for indoor use
only.
Do not expose the adapter or battery charger to direct sunlight
or use it in places with high humidity, such as the bathroom.
Menu Tree
Menu Tree
31
1. Browser
1.1 Home
1.2 Bookmarks
1.3 Go to URL
1.4 Settings
2. Call history
2.1 All calls
2.2 Missed calls
2.3 Dialled calls
2.4 Received calls
2.5 Call duration
2.6 Call costs
2.7 Data information
3. Tools
3.1 Favourites
3.2 Alarm clock
3.3 Calendar
3.4 Calculator
3.5 Memo
3.6 Stop watch
3.7
Unit converter
3.8 World time
3.9 SIM services
4. Multimedia
4.1 Camera
4.2 Video camera
4.3 MP3 player
4.4 Radio
4.5 Voice recorder
5. Messaging
5.1 New message
5.2 Inbox
5.3 Email box
5.4 Drafts
5.5 Outbox
5.6 Sent
5.7 Voicemail
5.8 Info message
5.9 Templates
5.0 Settings
Menu Tree
32
Menu Tree
6. My stuff
6.1 Videos
6.2 Images
6.3 Sounds
6.4 Others
6.5 Games & Apps
6.6 External memory
7. Profiles
7.1 General
7.2 Silent
7.3 Vibrate only
7.4 Outdoor
7.5 Headset
8. Contacts
8.1 Search
8.2 Add new
8.3 Caller groups
8.4 Speed dial
8.5 Own number
8.6 My business card
8.7 Settings
9. Settings
9.1 Date & Time
9.2 Power saving
9.3 Display
9.4 Language
9.5 Connectivity
9.6 Flight mode
9.7 Calling
9.8 Security
9.9 Memory status
9.0 Reset default
Browser
You can access various WAP (Wireless
Application Protocol) services such as
banking, news, weather reports and flight
information. These services are specially
designed for mobile phones and they are
maintained by WAP service providers.
Check the availability of WAP services, pricing
and tariffs with your network operator and/or
the service provider whose service you wish to
use. Service providers will also give you
instructions on how to use their services.
Once connected, the homepage is displayed.
The content depends on the service provider.
To exit the browser at any time, press the
() key.
Navigating with the WAP browser
You can surf the Internet using either the
phone keys or the WAP browser menu.
Using the phone keys
When surfing the Internet, the phone keys
function differently to phone mode.
Using the WAP browser menu
There are various menu options available
when surfing the Mobile Web.
Home Menu 1.1
Connects to a homepage. The homepage will
be the site which is defined in the activated
profile. It will be defined by the service
provider if you have not defined it in the
activated profile.
Browser
33
Key Description
Scrolls each line of the
content area
Returns to the previous
page
Selects options and
confirms actions
Note
]The WAP browser menus may vary,
depending on your browser version.
Browser
34
Browser
Bookmarks Menu 1.2
This menu allows you to store the URL of
favourite web pages for easy access at a later
time.
To create a bookmark
1. Press the left soft key [Options].
2. Scroll to Add new and press the OK key.
3. After entering the desired URL press the
OK key. Add a title and press the OK key
again.
After selecting a desired bookmark, the
following options are available.
]Connect: Connects to the selected
bookmark.
]Add new: Select this to create a new
bookmark.
]Edit: You can edit the URL and/or the title
of the selected bookmark.
]Delete: Deletes the selected bookmark.
]Delete all: Deletes all the bookmarks.
Go to URL Menu 1.3
You can connect directly to the site you want.
After entering a specific URL, press the OK
key.
Settings Menu 1.4
You can set the profile, cache, cookie and
security related to Internet service.
WAP profiles (Menu 1.4.1)
A profile is the network information used to
connect to the Internet.
There are default profiles for some operators,
stored in the phone memory. It’s impossible
to rename default profiles.
Each profile has submenus as follows:
]Activate: Activates the selected profile.
]Settings: Use this to edit and change WAP
settings for the selected profile.
Browser
35
- Homepage: This setting allows you to
enter the address (URL) of a site you want
to use as homepage. You do not need to
type http:// at the front of each URL as
the WAP Browser will automatically add it.
- Gateway settings: IP Adress/Port
Number: You need to enter IP adress or
Port number that you want.
- Connection type: This setting allows you
to select the type among HTTP and HTTP
with proxy and WAP.
- Network profile: You can select the
relevant network profile.
]Rename: You can change the profile name.
]Add new: You can add a new profile.
]Delete: Deletes the selected profile from
the list.
]Delete all: Deletes all profiles from the list.
Cache (Menu 1.4.2)
The information or services you have
accessed are saved in the cache memory of
the phone.
Clear cache (Menu 1.4.3)
Removes all context saved in cache.
Security certificates (Menu 1.4.4)
A list of the available certificates is shown.
]Authority: You can see the list of authority
certificates that have been stored in your
phone.
]Personal: You can see the list of personal
certificates that have been stored in your
phone.
WAP Information (Menu 1.4.5)
Note
]A cache is a buffer memory, which is
used to save data temporarily.
Call history
36
Call history
You can check the record of missed, dialled,
and received calls only if the network
supports the Calling Line Identification (CLI)
within the service area.
The number and name (if available) are
displayed together with the date and time at
which the call was made. You can also view
call times.
All calls Menu 2.1
You can view all lists of outgoing or incoming
calls.
Missed calls Menu 2.2
This option lets you view the last 50
unanswered calls.
You can also:
]View the number if available and call it.
]Enter a name for the number and save it in
your contacts.
]Send a message to this number.
]Delete the call from the list.
Dialled calls Menu 2.3
This option lets you view the last 50
outgoing calls (called or attempted).
You can also:
]View the number if available and call it.
]Enter a name for the number and save it in
your contacts.
]Send a message to this number.
]Delete the call from the list.
Received calls Menu 2.4
This option lets you view the last 50 incoming
calls.
You can also:
]View the number if available and call it.
]Enter a name for the number and save it in
your contacts.
]Send a message to this number.
]Delete the call from the list.
Call history
37
Call duration Menu 2.5
Allows you to view the duration of your
incoming and outgoing calls. You can also
reset the call times. The following timers are
available:
]Last call: Length of the last call.
]Dialled calls: Length of the outgoing calls.
]Received calls: Length of the incoming
calls.
]All calls: Total length of all calls made and
incoming calls since the timer was last reset.
Call costs Menu 2.6
Allows you to check the cost of your Last call,
All calls and Cost setting. To reset the cost,
you need to enter the PIN2 code.
Data information Menu 2.7
You can check the amount of data transferred
over the network through the GPRS
information option. In addition, you can also
view how much time you are online.
Data time (Menu 2.7.1)
You can check the duration of Last session
and All sessions. You can also Reset the call
timers.
Data volume (Menu 2.7.2)
You can check the Sent, Received or All data
volumes and Reset.
Tools
38
Tools
Favourites Menu 3.1
This option allows you to add your own
favourites to the list already provided. Once
you create your own menu, you can access
the desired function quickly in the idle screen
by pressing the up navigation key.
Alarm clock Menu 3.2
You can set the alarm clock to go off at a
specified time.
1. Select On and enter the alarm time you
want.
2. Select the repeat period: Once, Mon-Fri,
Mon-Sat, Sat-Wed, Sat-Thu and Everyday.
3. Select the alarm tone you want and
press [Set].
Calendar Menu 3.3
When you enter this menu a Calendar will show
up. On top of the screen there are sections for
date. Whenever you change the date, the
calendar will be updated according to the date.
And square cursor will be used to locate the
certain day. If you see under bar on the
calendar, it means that there is a schedule or
memo that day. This function helps to remind
you of your schedule and memo. The phone
will sound an alarm tone if you set this for the
note. To change the day, month, and year:
In the scheduler mode, press left soft key
[Options] as follows;
View (Menu 3.3.1)
Edit (Menu 3.3.2)
When one or more schedule is set, you can
edit the selected schedule.
Send via Bluetooth
(Menu 3.3.3)
You can send the selected schedule via
Note
]Radio is already preset in favourites.
Key Description
Yearly
Monthly
Weekly
Daily
Tools
Bluetooth. Prior to sending, the Bluetooth
connection should be made first.
Delete (Menu 3.3.4)
New schedule (Menu 3.3.5)
Allows you to add new schedule and memo
for the chosen day. You can store up to 100
notes. Input the subject and then press left
soft key [OK]. You enter the
appropriate information in the follow section;
Time, Repeat and Alarm.
Calendar (Menu 3.3.6)
Jump back to the calendar screen.
Go to date (Menu 3.3.7)
You can go the chosen date directly.
Alert tone (Menu 3.3.8)
You can set the alarm tone of each chosen
date.
View all schedules (Menu 3.3.9)
View all schedules and memo for the chosen
day. Use to browse through the note
lists. If you set alarm for the note, the alarm
icon is displayed. If you want to view the note
in detail, press left soft key [Select].
Press left soft key [Options] to delete,
edit the note you selected.
Delete past (Menu 3.3.0)
You can delete the past schedules.
Delete all (Menu 3.3.*)
You can delete all scheduled items.
Calculator Menu 3.4
This contains the standard functions such as +,
–, x, ÷ : Addition, Subtraction,
Multiplication, and Division. Furthermore, you
can use the various functions of the calculator
such as +/-, sin, cos, tan, log, ln, exp, sqrt,
deg, rad.
1. Input the numbers by pressing numeric
keys.
2. Use a navigation key to select a sign for
calculation.
3. Then input the numbers.
39
Tools
40
Tools
4. Press key to view the result.
5. To input a decimal, press key. If you
press key, you can enter ‘( )’ .
6. To end Calculator, press the right soft key
[Back].
Memo Menu 3.5
1. Select the Memo by pressing the left soft
key [OK].
2. If the entry is empty, press the left soft key
[New].
3. Input the memo and then press left soft
key [OK].
Stop watch Menu 3.6
1. Press [Start] to take time and record the
lap time by pressing [Lap].
2. Press [Stop] to ascertain the record of lap
time.
3. Press [Reset] to default condition.
Unit converter Menu 3.7
This converts any measurement into a unit
you want. There are 4 types that can be
converted into units:
Area, Length, Weight and Volume.
1. You can select one of four unit types by
pressing [OK] key.
2. Select the unit you want to convert by
pressing and . It's impossible to
input "-" symbol in unit converter.
3. Select the standard value by using , .
World time Menu 3.8
You can view clocks of the world’s major cities.
1. Select the city belonging to the time zone
by pressing , , , key.
2. ou can set the current time to the city time
you select by pressing the left soft key
[Set].
SIM services Menu 3.9
This menu depends on SIM and the network
services.
Note
]If you want to change the text input
mode, press the in order.
Multimedia
Multimedia
41
You can enjoy multimedia functions such as
camera, voice recorder, and MP3 for your fun
and entertainment.
Camera Menu 4.1
To take a picture with slide opened
1. Select Camera. If you want to access this
menu directly, press and hold
momentarily.
2. Focus on the subject to capture the image,
and then press the key.
3. If you want to save it, press the key. To
send the picture by MMS select the left
soft key (Send). To delete the picture
without saving press the right soft
key (Delete).
Select the left soft key for more
options.
]Mode: Allows you to choose between
Single shot or to take Multi shot photos
successively.
• Multi shot/ Single shot
]Metering: Determines the lighting based
on a selected part of the subject. You can
select from Centered and Combined to
establish the best lighting.
]Auto focus: Automatically adjusts the
focus for a clear, sharp image with a single
press of a button. You can select Macro for
close up shots.
]White balance: Allows you to change the
settings according to the enviroment.
]Quality: Allows you to set the image
quality from Super fine/Fine/Normal.
Note
]When the status of the battery indicates
low, you may not be able to use the
Camera or Multimedia functions.
]While using the Multimedia function, the
battery status is changeable.
Note
]You can adjust the zoom and brightness
by pressing the navigation keys.
]Delay timer: Allows you to select the delay
time (10 seconds, 5 seconds, 3 seconds,
Off). Then the phone takes a photo after
the specified time.
]Size: Allows you to set the image size to
one of (1600x1200), (1280x960),
(640x480), (320x240).
]Shutter tone: You can select from a choice
of different sounds, or you can turn the
sound off.
]Save to: You can select a storage location:
External or Phone.
]Flash: Adds additional light when you take
a photo in dark surroundings. You can also
turn the flash On/ Off by pressing the
key while in the camera mode.
]Image effect: 4 settings are available:
Negation, Mono, Sepia, and Colour.
]Night mode: On/Off Set to On for better
pictures in poor lighting conditions.
Video camera Menu 4.2
1. Select Video camera menu.
2. Press the key to start recording. A
timer will be displayed while recording is in
progress.
3. To stop recording press the left soft
key (Stop).
4. When recording is completed, you have a
choice of 3 options: Send by MMS by
pressing the left soft key (Send), Save
by pressing the key, or Delete by
pressing the right soft key (Delete).
5. You can also amend the brightness, size,
quality and other settings by pressing the
left soft key (Options) before you
start to record. Video camera settings menu
is similar to the Photo camera settings,
except following items:
]Recording time: You may select recording
time from the list: Unlimited, 90 Minutes,
30 Minutes, 5 Minutes and 1 Minute.
]Size: You may select following resolution:
128x96, 176x144.
Multimedia
42
Multimedia
Note
]When you are in camera mode, and
there’s no action for a while, the phone
will automatically exit to idle mode.
Multimedia
43
6. You can view the videos by pressing the
right soft key (Album).
MP3 player Menu 4.3
The ME830d features an integrated MP3
player. You can enjoy listening to MP3 music
files on your phone using a compatible
headset or via the internal loudspeaker.
The music player supports:
]MPEG-1 Layer III, MPEG-2 Layer III,
MPEG-2.5 Layer III: Sampling frequency
up from 8KHz to 48KHz. Bit rate up to
320Kbps, stereo.
]AAC: ADIF, ADTS formats (Sampling
frequency from 8KHz to 48KHz)
]AAC+: V1: (Bit rate 16-128 kbps)
V2 : (Bit rate 16-48 kbps)
(Sampling frequency from 8KHz to
48KHz)
]MP4: Sampling frequency up from 8KHz to
48KHz, Bit rate up to 320Kbps, stereo.
You can transfer MP3 files from a compatible
PC to the memory in your phone using the
Mass Storage. When you connect the phone
to a PC using the USB cable (supplied in the
box), the phone will be recognised as a
removable disk through windows explorer.
After you copy songs to the removable disk
you should execute the safe removal of
hardware from your PC.
Note
]Because of the small dimension of the
speaker, in some cases the audio may be
distorted, especially at maximum volume
and when there is an excess of bass
sounds. Therefore, we recommend you to
use the stereo headset in order to
appreciate the high quality of your music.
Note
]The ME830d doesn’t support the
variable bit rates of all mentioned file
types. Therefore, you can’t change the
file from MP3 format to AAC.
The following screen is displayed when playing
MP3 files.
1. Press MP3 menu, and then select MP3
player.
2. Press the left soft key [Options] to
access the following menus.
]Pause: You can pause the music
temporarily.
]View Playlist: You can select the music you
want to listen to from the playlist.
]Set as Ringtone: You can set the current
MP3 file as your ringtone.
]Settings: Set the way you view and listen to
your music. Please see the Settings part
below for detailed information.
Multimedia
44
Multimedia
Note
]You should copy MP3 files to My
media\Music folder. If you copy to
another folder, you won't be able to play
the MP3 files.
]Supported operating systems: Windows
98 SE, Windows ME, Windows 2000, and
Windows XP.
Note
]In a case where an invalid file is included
in the playlist, an error message will pop
up and then it will go back to the prior
screen.
Progressive bar
Volume level
Player skin
File name
Running time
Status of the
music controller
Stereo/
Playmode/
Shuffle/Hold
Repeat
Play all
Repeat all
Repeat one
Multimedia
45
Playlist
This menu allows you to view the complete
play list. You can move to the track by
pressing the navigation key. In addition, if you
select the option menu, you can delete the
file or view its information.
Settings
]Equalizer
You can set the sound to different
environments depending on the type of
music you are listening to. This phone
supports ten preset equalizer settings.
When you enter this menu, you can select
the most suitable setting from the list.
]Play mode
This menu allows to set the play mode: Play
all, Repeat all, Repeat one.
]Set shuffle
If you select On, the tracks will be played
at random.
]Visual effect
Change the visual effect on the display
when the music is playing.
Radio Menu 4.4
The ME830d features a built-in FM radio. The
stereo headset must be plugged in to enable
you to listen to the radio because the headset
acts as the FM antenna.
Note
]Most music is copyright protected by
international treaties and national
copyright laws. It may be necessary to
obtain permission or a license to
reproduce or copy music. In some
countries national law prohibits private
copying of copyrighted material. Please
check the national legislation of the
applicable country concerning the use of
such material.
Frequency
display
Volume level
Preset
channel
stations
1. Search the desired radio station using the
left/right navigation keys.
Key operations
2. You can preset channels by using the Auto
scan feature or Edit in the Options menu.
3. After presetting radio channels, you can
listen to other channel by pressing the
corresponding number key (short press).
4. You can access the following option menus
by pressing the left soft key [Options].
]Edit: Edit channel presets individually. Enter
the frequency, or scan using the navigation
keys. Save by pressing OK.
]Auto scan: Select this to automatically
scan through available stations. When it
finds a station you can decide if you want
to save it as as one of the 10 presets.
]Reset all channels: Cancels all preset
channels.
]Listen via speaker: You can listen to the
radio through the internal built-in speaker.
You will still need the headset plugged in to
act as the antenna.
Voice recorder Menu 4.5
You can record voice memo. The following
[Options] menus are available.
]Storage
You can choose Phone or External memory.
]Recording mode
You can choose General mode of unlimited
recording or MMS mode of recording up to
30 seconds.
Multimedia
46
Multimedia
Scans downward/ upward
to the next receivable
radio station.
Increases/Decreases the
volume level
Left/Right
navigation keys
Up/Down
navigation keys
Note
]To improve the radio reception, extend
the headset cord which functions as the
FM antenna.
Multimedia
47
Record
1. Press OK to start recording. Once
recording is started, the message Recording
and the counter is displayed.
2. If you want to pause or resume recording,
press left soft key or OK key.
3. If you want to finish recording, press right
soft key [Stop].
Album
You can view the Sounds folder which lists all
sound files saved in the memory.
New message Menu 5.1
This menu includes functions related to SMS
(Short Message Service), MMS (Multimedia
Message Service), Email, voice mail, as well as
the network’s service messages.
Text (Menu 5.1.1)
You can write and edit text messages
1. Enter the New message menu by pressing
the left soft key [OK].
The following [Options] menus are available.
Options
]Send to: Sends text messages.
1. Enter numbers of recipient. Also, you can
select Options and choose from Contacts,
or Recent messages to send a text
message.
2. Press key to add more recipients.
3. Once the numbers have been entered,
press the left soft key to send the
message. All messages will automatically be
saved in the outbox folder, even after a
sending failure.
]Insert
• Symbol: You can add special characters.
• Image: You can insert the default graphics
or other available graphics in My Folder
that are available for short messages.
• Sound: You can insert sounds that are
available for short messages.
• Default image: You can insert basic
animations.
• Default sound: You can insert sound
effects.
• Text template: You can insert preset text
templates already set in the phone.
• Contact: You can insert phone numbers
or e-mail addresses from the address
book.
• Business card: You can add your
signature to the message.
]Save to drafts: Stores messages in Drafts.
]T9 languages: T9 is set to off by default.
Here you can turn it on, and also select the
language.
]New T9 word: Enter a new T9 word.
]Clear text: You can clear the text.
Messaging
48
Messaging
Messaging
49
]Exit: If you press Exit whilst writing a
message, you will be taken back to the
message menu. The message you have
written is not saved.
Multimedia (Menu 5.1.2)
You can write and edit multimedia messages.
You can check the message file size in the
upper right hand corner of the display when
creating a new message.
1. Enter the New message menu by pressing
the left soft key [OK].
2. If you want to write a new message, select
Multimedia.
3. You can create a new message or choose
one of the text templates already made.
The maximum available file size that can be
inserted to an MMS-message - is 300 kb.
Options
]Send to: You can send multimedia
messages to multiple recipients and set
priorities for your message.
]Insert: You can add symbols, images,
videos, sounds, new slides, text templates,
contacts, business card, and others.
]Preview: You can preview multimedia
messages you have created.
]Save: You can save multimedia messages To
drafts or As template.
]Edit subject: Allows you to modify the
multimedia message you have chosen..
]Remove media
]Slide duration: You can set the duration of
slides by the second.
Note
]The ME830d supports EMS release 5
and is able to send colour pictures,
sounds, text styles, etc.. The other party
may not receive pictures, sounds or text
styles you sent properly if their phone
does not support such options. Note
]All messages will be automatically saved
in the outbox folder, even after a sending
failure.
]T9 languages: Select the language for T9
input mode. You can also activate or -
deactivate T9 input mode.
]New T9 word: Enter a new T9 word.
]Exit: You can get back to the Message
menu.
Email (Menu 5.1.3)
To send/receive an email, you should set up
the email account details. Refer to Email on
page 50 first.
1. You can input up to 20 email addresses in
the To and Cc field.
Tip: To input "@", press the and
select "@".
2. Key in the subject of the mail and press
OK.
3. After writing an email message, press the
left soft key [Options]. You can
access the following option menus.
]Send: Sends the email message.
]Send to: You can edit recipients.
]Insert
]Attachment: You can attach a file with this
menu.
]Preview: You can preview the email.
]Save to drafts: Select this to save the
message in Drafts.
]Edit subject: You can edit the subject.
]T9 languages: Select the language for T9
input mode. You can also activate or
deactivate the T9 input mode.
]New T9 word: Enter a new T9 word.
]Clear text: You can clear text while writing
the message.
]Exit:
If you select this while writing the
message, you can exit from writing the
message and go back to the previous screen.
The message you have written is not stored.
]Contacts: You can go to the phonebook.
Messaging
50
Messaging
Note
]If you select a picture with a large file size
(200K for example) on writing
multimedia message, the loading duration
will take around 10 seconds.
Furthermore, you can’t activate any keys
during the loading time. After about 10
seconds, you should be able to write the
message.
Messaging
51
]Edit email: You can edit the email body.
Inbox Menu 5.2
You will be alerted when you have received a
message. They will be stored in the Inbox.
In the Inbox you can identify each message by
icons. For details see the icon directive.
If the phone shows ‘No space for SIM
message’, you have to delete some SIM
messages from the Inbox. If the phone
displays ‘No space for message’, you can make
space in each repository by deleting
messages, media and applications.
❇SIM message
SIM message means that the message is
exceptionally stored in the SIM card. You
can move this message to the phone.
For notified multimedia messages, you have to
Note
]For each e-mail account you may save up
to 40 messages (totally 200 for five
accounts). In Inbox folder you may save
not more than 20 messages. Drafts and
Outbox folders - 5 messages, and in Sent
folder up to 10 messages. In case Drafts,
Outbox or Sent folder is full, and you try
to save a new message to one of these
folders, the oldest saved message will be
automatically deleted.
]The maximum size for one sent message is
300 kb with attachments, and the
maximum size for one received message is
300 kb. In case you receive a message
with more than 5 attachments, only 5 of
them will be received. Some attachments
may display incorrectly.
Icon Icon directive
Multimedia message
Short message
SIM message
Read multimedia message
Read text message
Push message
Notified multimedia message
wait for downloading and processing of the
message.
To read a message, select one of the
messages by pressing the left soft key
[Options] .
]View: You can view the received messages.
]Delete: You can delete the current
message.
]Reply: You can reply to the sender.
]Forward: You can forward the selected
message to another party.
]Return call: You can call back the sender.
]View information: You can view
information about received messages;
Sender’s address, Subject (only for
Multimedia message), Message date &
time, Message type, Message size.
]Multi delete: You can select multiple
messages to delete by ticking boxes.
]Delete all: You can delete all messages.
Email box Menu 5.3
When you access this menu, you can either
connect to your remote mailbox to retrieve
your new email messages, or you can view the
previously retrieved email messages without
logging into the email server.
You can check the saved emails, drafts,
outbox, and sent emails. In the Inbox, up to
20 emails can be stored. (Outbox and Drafts
stores up to 5, Sent stores up to 10)
Drafts Menu 5.4
Using this menu, you can preset up to five
multimedia messages that you use most
frequently. This menu shows the preset
multimedia message list.
The following options are available.
]View: You can see the multimedia
messages.
]Edit: Modifies the massage you choose.
]Delete: Deletes the message you choose.
]Information: Displays the information of
the selected draft.
]Multi delete: Deletes selected drafts at one
time.
]Delete all: Deletes all of the messages in
the folder.
Messaging
52
Messaging
Messaging
53
Outbox Menu 5.5
This menu allows to view the message which is
about to be sent or has failed to send.
After sending the message successfully, the
message will be moved to sent folder.
]View: You can view the message.
]Delete: You can delete the message.
]Resend: You can resend the message.
]Edit: You can edit the message.
]View information: You can check the
information of each message.
]Multi delete: Deletes selected drafts at one
time.
]Delete all: You can delete all the messages
in the outbox.
Sent Menu 5.6
This menu allows you to view the messages
which have been sent. You can check the time
and the contents of the message.
Voicemail Menu 5.7
Once this menu has been selected, simply
press the left soft key [OK] to listen to
voicemail. You can also hold down the
key in standby mode to listen to voicemail.
Info message Menu 5.8
(Dependent on network and subscription)
Info service messages are text messages
delivered by the network to mobile phones.
Icon Icon directive
MMS Unsent
Waiting to be sent
Sending MMS
Note
]When you receive a voicemail, your
phone will display an icon and you will
hear an alert. Please check with your
network provider for details of their
service in order to configure the handset
correctly.
They provide general information such as
weather reports, traffic news, taxis,
pharmacies, and stock prices.
Each type of information has a specific
number assigned to it. Contact your service
provider for more information on this service.
When you have received an info service
message, you will see a popup message to
show you that you have received a message
or the info service message is directly
displayed.
To view the message again, follow the
sequence shown below;
Read (Menu 5.8.1)
1. When you have received an info service
message and select Read to view the
message, it will be displayed on the screen.
You can read another message by scrolling
, or [Next].
2. The message will be shown until another
message is selected.
Topics (Menu 5.8.2)
(Dependent on network and subscription)
]View list: You can see Info service message
numbers which you added. If you press
[Options], you can edit and delete
the info message category which you
added.
]Active list: You can select info service
message numbers in the active list. If you
activate an info service number, you can
receive messages sent from the number.
Templates Menu 5.9
Text (Menu 5.9.1)
You have 6 text templates as below;
Messaging
54
Messaging
• Please call me back.
• I’m late. I will be there at
• Where are you now?
• I'm on the way.
• Urgent! Please contact.
• I love you
Messaging
55
Multimedia (Menu 5.9.2)
After you have saved a new template, you can
use the following options.
]Save: Allows you to save the multimedia
message.
]Insert: You can add photos, images,
sounds, contacts, symbol, text templates
and my business card.
]Preview: Preview your multimedia message.
]Edit subject: Allows you to modify the
multimedia message you have chosen.
]Slide duration: You can set the duration of
slides by the second.
]T9 languages: Select the desired language
for T9 input mode. You can also activate or
deactivate T9 input mode.
]New T9 word: Enter a new T9 word.
]Exit: Will take you back to the Message
menu.
]Delete all: Allows you to delete all
multimedia messages.
Settings Menu 5.0
Text message (Menu 5.0.1)
(Dependant on network)
]Message types: Text, Voice, Fax, Paging,
X.400, E-mail, ERMES Usually, the type
of message is set to Text. You can convert
your text into alternative formats. Contact
your service provider for the availability of
this function.
]Validity period: This network service allows
you to set how long your text messages will
be stored at the message centre.
]Delivery report: If you set to Yes, you can
check whether your message is sent
successfully.
]Reply charging: When a message is sent, it
allows the recipients to reply and charge
the cost of the reply to your telephone bill.
]Message centre number: If you want to
send a text message, you can view the
address of SMS centre through this menu.
]Bearer setting: Select GSM preferred/
GPRS preferred/ GSM only/ GPRS only.
Mulitimedia message (Menu 5.0.2)
]Subject: You can enter multimedia
messages subject when this menu is set to
On.
]Slide duration: You can set the duration of
slides by the second.
]Priority: You can set the priority of the
message you choose.
]Validity period: This network service allows
you to set how long your text messages will
be stored at the message centre.
]Delivery report: If it is set to Ye s in this
menu, you can check whether your message
is sent successfully. This feature is
dependant on the network.
]Read report: You can check if your
message is read by the recipient. This
feature is dependent on the network.
]Auto download: If you select On, you will
receive multimedia messages automatically.
If you select Off, you will receive only a
notification message in the inbox and then
you can check this notification. If you select
Home network only, you will receive
multimedia messages only when you are
registered to your home network (not
roaming).
]Network profile: If you select the
multimedia message server, you can set the
URL for the multimedia message server.
]Permitted message type
Personal: Personal message.
Advertisements: Commercial message.
Information: Necessary information.
Email (Menu 5.0.3)
This menu allows you to edit, delete or add
email accounts.
]View: You can view the account details.
]New account: You can set up to 5 email
accounts by selecting the New account
menu. Using the Edit menu, you can set the
following values.
]Set as default
]Edit
- Account name: Account name.
- Email address: Enter the email address
Messaging
56
Messaging
Messaging
57
given to you by your service provider.
- My name: You can make your nickname.
- Incoming mail server: Enter the POP3
address and Port number that receives
your email.
- User name: Enter your email ID.
- Password: Enter your email password.
- Outgoing mail server: Enter the SMTP
address and Port number that sends
your email.
- Maximum receive size: View the
Maximum size that you can receive mails.
- Save to server: Select Yes to leave the
messages on the server.
- Insert signature: Select Yes to attach
your signature to your email messages.
]Advanced settings
- Reply email address: Email address that
you want to receive the reply.
- Incoming port number: Allows you to
edit the POP3 port number.
- Outgoing port number: Allows you to
edit the SMTP port number.
- Outgoing mail authentication: When
you send the mail, you can set the
authentication.
- Outgoing server ID/PW: Enter the ID
and password for sending your email.
]Delete: Deletes the selected account from
the list.
]Delete all: You can delete all accounts from
the list.
- Access point: Allows you to select the
access point from the list.
]Network profile: You can edit the network
profiles.
]Signature: You can make your signature.
Voicemail number (Menu 5.0.4)
You can receive voicemail if your network
service provider supports this feature. When a
new voicemail is received, a symbol will be
displayed on the screen. Please check with
your network service provider for details of
their service in order to configure the phone
accordingly.
Push message (Menu 5.0.5)
You can set the option whether you will
receive the message or not.
Info message (Menu 5.0.6)
(Dependent on network)
]Receive
Yes : If you select this menu, your phone
will receive Info service messages.
No: If you select this menu, your phone
will not receive Info service messages any
more.
]Alerts
Yes : Your phone will beep when you have
received Info service messages.
No: Your phone will not beep even if you
have received an info service message.
]Language
You can select the language you want by
pressing [On/Off]. Then, the info service
message will be shown in the language
that you selected.
Messaging
58
Messaging
My stuff
My stuff
59
Videos Menu 6.1
Shows the list of 3GP files in My
media/Videos in the Multimedia memory.
Supported files types are .3gp files that are
encoded with MPEG4, h.263 video-codecs
and AMR audio-codecs.
]Play: You can play the video file when
pressing the [OK] key or selecting the Play
menu in the Options menu.
]Send via: Send the selected file to another
device via Multimedia, Email or Bluetooth.
]Copy to external memory: Copy the
selected file to the same folder in
Multimedia memory/External memory.
]Move to external memory: Move the
selected file to the same folder in
Multimedia memory/External memory.
]Rename: Change the file name of the
selected file. The maximum length of
characters is 200. You can not change the
extension of file.
]Delete: Delete a file.
]Delete all: Delete all files in the list.
]Information: Show the file information.
Note
]You may send files via Bluetooth only if
they are stored in the phone memory,
not on the memory card. To send a file
from the external memory, copy it to
internal phone memory first.
Warning
]If you remove external memory during
data transfer it will cause serious damage
to your phone.
Note
]You can’t use the following characters: *,
/,\, :, |, <, >, ?, %, ".
My stuff
60
My stuff
Images Menu 6.2
Show the list of JPG files in My media/Photos
in the Multimedia memory.
]View: You can see the JPG file when
pressing the [OK] key or selecting the View
menu in the Option menu.
]Set as wallpaper: Set the selected file as
wallpaper.
]Send via Multimedia/Email/Bluetooth:
Send the selected file to another device via
email if the file size is less than 300Kbytes.
Send the selected file to another device via
Bluetooth.
]Print via Bluetooth: Print the selected file
via a Bluetooth compliant printer.
]Slide show: View the pictures in that folder
as a slide show.
]Copy to external memory: Copy the
selected file to the same folder in
Multimedia memory/External memory.
]Move to external memory: Move the
selected file to the same folder in
Multimedia memory/External memory.
]Rename: Change the file name of the
selected file. The maximum length of
characters is 200. You can not change the
extension of file.
]Delete: Delete a file.
]Delete all: Delete all files in the list
]Information: Show the file information.
]View by list: Toggle the view into list view.
Sounds Menu 6.3
Show the list of MP3, MP4, AAC files in My
media/Music in Multimedia memory.
]Play: You can play the MP3 file when
pressing the [OK] key or selecting the Play
menu in the Option menu.
]Set as ringtone: You can set the selected
song as your ringtone.
]Send via: Send the selected file to another
device via MMS, EMAIL or Bluetooth.
My stuff
61
]Copy to external memory: Copy the
selected file to the same folder in
Multimedia memory/External memory.
]Move to external memory: Move the
selected file to the same folder in
Multimedia memory/External memory.
]Rename: Change the file name of selected
file. The maximum length of characters is
200. You can not change the extension of
file.
]Delete: Delete a file.
]Delete all: Delete all files in the list
]Information: Show the file information.
Others Menu 6.4
Show the list of files in My media\Others in
the Multimedia memory.
]Send via Bluetooth: Send the selected file
to another device via Bluetooth.
Note
]You may send files via Bluetooth only if
they are stored in the phone memory,
not on the memory card. To send files
from the external memory you must first
copy it to the internal phone memory.
Note
]You may send files via Bluetooth only if
they are stored in the phone memory,
not on the memory card. To send files
from the external memory you must first
copy it to the internal phone memory.
]When you connect the phone with a PC
via Bluetooth, you can both send and
receive files to the Music and Video
folders. You can copy any file type to
the Others. You can only receive files
from the Photos, Sounds, and Images
folders. You can only view or play files in
the Others folder if the file types are
supported. When connecting with a PC
via USB cable you will only see the
following folders in the internal memory:
Images, Sounds, Videos, and Others. You
can see all folders in the external
memory.
My stuff
62
My stuff
Games & Apps Menu 6.5
In this menu, you can manage the Java
applications installed in your phone. You can
play or delete downloaded applications, or set
the connect options.
External memory Menu 6.6
This menu allows you to view Videos, Photos,
Music, Text, Images, Sounds and Others in
memory card.
If the external memory is not available, a pop
up message “Please insert external memory” is
displayed.
Note
]The SIM card must be installed in order
for the phone to be recognised as a
removeable disk.
New Fantastic LG
]The ME830d works as a mass storage
device. If you connect the USB cable,
you can use the phone as a Removable
Disk. You can download MP3 files,
photos, videos, text files etc. this gives
you fast access from the PC to phone, by
just connecting the USB cable.
Note
]MASS STORAGE function will only work
when the phone is in idle mode.
]DO NOT remove the cable while you are
downloading files. After you download
the files, you need to click “Safely
Remove Hardware” on the PC and
then disconnect the cable.
]When you copy a file to the removable
disk, you can see a message on the
display “transferring”. It means MASS
STORAGE is working and data is being
transferred. While “transferring”, do not
disconnect the cable. If you disconnect
the cable while “transferring”, data will be
lost or corrupted and possibly damage
the phone.
]If you receive a call when using as MASS
STORAGE the call will be rejected, but
after you remove the cable you will be
able to see the missed call.
Profiles
Profiles
63
In Profiles, you can adjust and customise the
phone tones for different events,
environments, or caller groups.
There are five preset profiles: General, Silent,
Vibrate only, Outdoor and Headset.
Each profile can be personalised. Press the
left soft key [Menu] and select Profiles using
up/down navigation keys.
Activate (Menu 7.X.1)
1. A list of profiles is displayed.
2. In the Profiles list, scroll to the profile you
want to activate and press the left soft key
[OK].
3. Then, select Activate.
Personalise (Menu 7.X.2)
Scroll to the desired profile in the Profile list.
After pressing the left soft key or the
[OK] key, select Personalise. The profile
setting option opens. Set the options as
required.
]Call alert type: Set the alert type for
incoming calls.
]Ring tone: Select the desired ring tone
from the list.
]Ring volume: Set the volume of the ringing
tone.
]Message alert type: Set the alert type for
messages.
]Message tone: Select the alert tone for
messages.
]Keypad tone: Select the desired keypad
tone.
]Keypad volume: Set the volume of keypad
tone.
]Slide tone: Allows to set the slide tone for
the environment.
]Effect sound volume: Set the volume of
the effect sound.
]Power on/off volume: Set the volume of
tone when switching the phone on/off.
Search Menu 8.1
1. Select Search by press the left soft key
[OK].
2. Enter the name that you want to search.
3. If you want to edit, delete, copy an entry,
or to add the voice to one, select left soft
key [Options]. The following menu
will be displayed.
]Details: You can view the details of
contacts.
]Edit: You can edit the name, number,
group, character and picture by using the
navigation key.
]Send via Bluetooth: You can send the
data of phone book to devices which is
compatible with Bluetooth through
Bluetooth connection.
]New message: After you have found the
number you want, you can send a
text/multimedia message to the selected
number.
]Copy to handset: You can copy an entry
from SIM to phone or from phone to SIM.
]Delete: You can delete an entry.
Add new Menu 8.2
You can add phonebook entry by using this
function. Phone memory capacity is 1000
entries. SIM card memory capacity depends
on the service provider. The number of
characters is a SIM dependent feature.
1. Select Add new by pressing the left soft
key [OK].
2. nter the following information.
a. Press [OK] to input a name.
b. Press [Save], then you can input
a mobile, home, office, fax numbers.
Contacts
64
Contacts
Note
]Instant searching is available by inputting
the initial letter of the name or number
you want to search.
Note
]Maximum stored name and number
length depends on SIM-card type.
Contacts
c. You can set a group for the entry by
pressing , .
d. You can set a character and a picture
for the entry by pressing , .
e. Enter additional information as
necessary including Memo and press
save.
Caller groups Menu 8.3
You can list up to 20 members per one
group. There are 7 groups you can make
lists to.
]Member list: Shows the group members
you have selected.
]Group ringtone: Allows you to specify ring
tone for the group members’ call.
]Group icon: Allows you to select the icon
dependent on Group.
]Add member: You can add group
members. Each group should not exceed 20
numbers.
]Remove member: You can remove a
member from the Group member list. The
name and the number will still remain in
phonebook.
]Rename: You can change a group name.
]Remove all: You can delete all the
members in the group.
Speed dial Menu 8.4
You can assign any of the keys through
with a Name list entry.
You can call directly by long pressing the
relevant key.
1. Open the phonebook first by pressing the
Right soft key [Contacts] in standby
mode.
2. Scroll to Speed dial, press the left soft key
[Ok].
3. If you want to add Speed dial, select
(Empty). Then, you can search the name in
phonebook.
4. Select an allocated name by Speed dial,
and choose Change or Delete to edit the
name. In addition, you can make a call or
write a message by this number.
65
]Group icon: Allows you to select the icon
dependent on Group.
Contacts
66
Contacts
Own number
(SIM dependent) Menu 8.5
You can save and check your own number in
the SIM card.
My business card Menu 8.6
This option allows you to create your own
business card featuring name and a mobile
phone number. To create a new business card,
press the left soft key [Options] and
enter the information into the fields.
Settings Menu 8.7
1. Press the right soft key [Contacts]
in standby mode.
2. Scroll to Settings, then press the left soft
key [OK].
]Default memory
Scroll to highlight Default memory, and
then press the left soft key [OK].
- If you select Always ask, when adding
entry, the phone will ask where to store.
- If you select SIM or Handset, the phone
will store an entry to SIM or Handset.
]View options
Scroll to highlight View options, and then
press the left soft key [OK].
- Name only: Set the phonebook list with
displaying only name.
- With photo: Set the phonebook list
with the information of character or
picture.
]Copy/Move all
You can copy/move entries from SIM card
memory to Handset memory and vice
versa.
1. Open the Phonebook first by pressing
the right soft key [Contacts] in
standby mode.
2. Scroll to Copy/Move all, and then
press the left soft key [OK] to
enter this menu.
- SIM to handset: You can copy the entry
from SIM Card to Phone memory.
Contacts
67
- Handset to SIM: You can copy the
entry from Phone memory to SIM Card.
]Clear contacts
You can delete all the entries in the SIM
and Handset. This function requires the
Security code.
1. Press the right soft key
[Contacts] in standby mode and select
Delete all, press [OK].
2. Then select a memory to erase.
3. Enter security code and Press the left
soft key [OK] or the right soft
key [Back].
]Service dial number
Use this function to access a particular list
of services provided by your network
operator (if supported by the SIM card).
Date & Time Menu 9.1
You can set functions relating to the date and
time.
Set date (Menu 9.1.1)
You can enter the current date.
Date format (Menu 9.1.2)
You can set the Date format such as
YYYY/MM/DD, DD/MM/YYYY,
MM/DD/YYYY.
(D: Day / M: Month / Y: Year)
Set time (Menu 9.1.3)
You can enter the current time.
Time format (Menu 9.1.4)
Your can set the time format between 24
hours and 12 hours.
Power saving Menu 9.2
If you set On, you can save power when you
don’t use the phone.
Display Menu 9.3
Wallpaper (Menu 9.3.1)
You can select the background pictures in
standby mode.
Default
You can select a picture or an animation
of wallpaper by pressing , , ,
.
My folder
You can select a picture or an animation
as wallpaper.
Menu style (Menu 9.3.2)
Your phone provides you with 2 menu styles.
Set the menu style by scrolling and pressing
the left soft key [OK].
Settings
68
Settings
Settings
Dialing Style (Menu 9.3.3)
You can choose your dialing style as Beads
style or Digital style.
Standby text (Menu 9.3.4)
If you select On, you can edit the text which
is displayed in standby mode.
Backlight time (Menu 9.3.5)
You can set the light-up duration of the
display.
Brightness (Menu 9.3.6)
You can set the brightness of LCD: 100%,
80%, 60%, 40%
Network name (Menu 9.3.7)
If this function is activated, the network name
will be displayed on main LCD.
Home screen shortcut (Menu 9.3.8)
You can set your home screen shortcut.
On/Off
Language Menu 9.4
You can change the language for the display
texts in your phone. This change will also
affect the Language Input mode.
Connectivity Menu 9.5
Bluetooth (Menu 9.5.1)
Bluetooth
®
functionality enables compatible
mobile devices, peripherals and computers
that are in close proximity to communicate
directly with each other without wires. This
handset supports built-in Bluetooth
connectivity, which makes it possible to
connect them with compatible Bluetooth
headsets, computer applications and so on.
69
Settings
70
Settings
]Set Bluetooth
You can activate or cancel the Bluetooth
function.
]Paired devices/Handsfree devices
You can view all devices which your
ME830d is already paired to. If you enter
Paired devices or Handsfree devices menu,
you access the options:
- Add new: Allows to search new
Bluetooth devices and add them to your
phone’s list of paired devices. When you
select Add new your handset will start to
search for Bluetooth devices within
range. Once the device you wish to pair
appears on the list press the right soft
key [Stop]. Scroll to the desired device
and press the left soft key [Pair]. You will
then be asked to enter a passcode. The
passcode can be any code you wish to
use (the same passcode must be used
by both devices) or is one that is
predetermined by the manufacturer of
the device you are trying to pair with.
Please check the User Manual of the
Note
]When you receive data from another
Bluetooth device, the phone requests
confirmation. After confirming the
transfer, the file will be copied on to your
phone.
]Depending on the file type, it will be
stored in the following folders:
- MP3 (.mp3, mp4, aac): Music folder.
- Video (.3GP): Video folder.
- Phonebook contacts (.VCF):
Phonebook.
- Other files (.*.*): File storage folder.
- Calendar (.VCS): Calendar
]Supported
Bluetooth
software
(
Bluetooth
stacks) for DUN:
Recommended drivers WidComm
Bluetooth for Windows 1.4 and 3.0
]Print via Bluetooth: It is available in
printers which support Basic Printing
Profile. You can print with "Send via
Bluetooth" menu for the printers which
support Object Push Profile. If the file
size is the more than each of 500KB
(Animated GIF file) 200KB(others), the
popup message is displayed “Not
supported”.
Settings
device you are initiating the pair with to
see if it already has a predetermined
passcode in place.
- Assign name: Allows you to change the
name of the paired Bluetooth device and
how it is displayed on the handset.
- Set as authorised/Set as
unauthorized: Allows you to set an
authorised connection between each
Bluetooth device. For example if you
regularly use a Bluetooth headset with
your phone then setting the connection
as authorised will mean the headset will
automatically connect to the handset
each time the headset is powered on.
- All services:Allows to view all services
which are supported by Bluetooth
device..
- Delete: Allows to delete a paired
Bluetooth device.
]Settings
- My handset’s visibility: This indicates
whether or not your handset will be
visible to other Bluetooth devices.
- My handset’s name: You can set the
name of Bluetooth device. The default
name is LG ME830d.
]Supported services
Displays a list of Bluetooth services the
handset supports.
- Headset
- Handsfree
- File transfer
- Image printing
- Dial-up networking
- Business card transfer
- Browsing other services
- Serial port device
Network selection (Menu 9.5.2)
You can select a network which will be
registered either automatically or manually.
Usually, the network selection is set to
Automatic.
71
Settings
72
Settings
]Automatic
If you select Automatic mode, the phone
will automatically search for and select a
network for you. Once you have selected
“Automatic”, the phone will be set to
“Automatic” even though the power is off
and on.
]Manual
The phone will find the list of available
networks and show you them. Then you
can select the network which you want to
use if this network has a roaming
agreement with your home network
operator. The phone let you select
another network if the phone fails to
access the selected network.
]Preferred
You can set a list of preferred networks
and the phone attempts to register with
first, before attempting to register to any
other networks. This list is set from the
phone’s predefined list of known networks.
GPRS attach (Menu 9.5.3)
You can set GPRS service depending on
various situations.
]Switch on
If you select this menu, the phone is
automatically registered to a GPRS
network when you switch the phone on.
Starting a WAP or PC dial-up application
created the connection between phone
and network and data transfer is possible.
When you end the application, GPRS
connection is ended but the registration
to the GPRS network remains.
]When needed
If you select this menu, the GPRS
connection is established when you
connect a WAP service and closed when
you end the WAP connection.
Network profile (Menu 9.5.4)
]Data connections
- Bearer: You can set the bearer data
service.
Settings
1 Data/2 GPRS
- Data settings: Appears only if you select
Data Settings as a Bearer/service.
Dial number: Enter the telephone
number to dial to access your WAP
gateway.
User ID: The users identity for your
dial-up server (and NOT the WAP
gateway).
Password: The password required by
your dial-up server (and NOT the WAP
gateway) to identify you.
Call type: Select the type of data call :
Analogue of Digital (ISDN).
Linger time: You need to enter timeout
period. After entering that, the WAP
navigation service will be unavailable if
any data is not input or transferred.
Call speed: The speed of your data
connection; 9600 or 14400 ( Depends
on Operator)
- GPRS settings: The service settings are
only available when GPRS is chosen as a
bearer service.
APN: Input the APN of the GPRS.
User ID: The users identify for your
APN server.
Password: The password required by
your APN server.
- Proxy settings
Proxy: Activates or cancels proxy.
IP address: Input the IP address of the
Proxy server you access.
Port: Input the Proxy Port.
- DNS settings
Primary server: Input the IP address of
the primary DNS server you access.
Secondary server: Input the IP address
of the secondary DNS server you
access.
73
Settings
74
Settings
USB connection mode (Menu 9.5.5)
Allows you to set a mode for USB connection.
Select Data service if you want to use it with
the PC data kit. For Mass storage function,
refer to the page 62.
Flight mode Menu 9.6
You can use many of your phone's features
when you are in an airplane or in any other
area where making or receiving calls or data is
prohibited.
Calling Menu 9.7
You can set the menu relevant to a call by
pressing [OK] in the Setting menu.
Call divert (Menu 9.7.1)
The Call divert service allows you to divert
incoming voice calls, fax calls, and data calls to
another number. For details, contact your
service provider.
]All voice calls: Diverts all voice calls
unconditionally.
]If busy: Diverts voice calls when the phone
is in use.
]If no reply: Diverts voice calls which you
do not answer.
]If out of reach: Diverts voice calls when
the phone is switched off or out of
coverage.
]All data calls: Diverts to a number with a
PC connection unconditionally.
]All fax calls: Diverts to a number with a fax
connection unconditionally.
]Cancel all: Cancels all call divert service.
The submenus
Call divert menus have the submenus shown
below.
]Activate: Activates the corresponding
service.
- To voice mail centre: Forwards to
message centre. This function does not
apply to All data calls and All fax calls
menus.
- To other number: Input the number for
call diverting.
Settings
- To favourite number: You can check
recent five diverted numbers.
]Cancel: Deactivate the corresponding
service.
]View status: View the status of the
corresponding service.
Answer mode (Menu 9.7.2)
]Slide up: Simply slide open the phone to
answer the call. (set as default)
]Any key: press any key to answer the call
except for the End key and the right soft
key.
]Send key only: the Send key must be used
to answer the call.
Send my number (Menu 9.7.3)
(Network and subscription dependent)
]Set by network: If you select this, you can
send your phone number depending on two
line service such as line 1 or line 2.
]On: You can send your phone number to
another party. Your phone number will be
shown on the receiver’s phone.
]Off: Your phone number will not be shown.
Call waiting
(Network Service) (Menu 9.7.4)
]Activate: If you select Activate, you can
accept a waiting (receiving) call.
]Cancel: If you select Cancel, you cannot
recognize the waiting (receiving) call.
]View status: Shows the status of Call
waiting.
Minute minder (Menu 9.7.5)
If you select On, you can check the call
duration by beep sound every minute during a
call.
Auto redial (Menu 9.7.6)
]On: When this function is activated, the
phone will automatically try to redial in the
case of failure to connect a call.
]Off: Your phone will not make any attempts
to redial when the original call has not
connected.
75
Settings
76
Settings
Send DTMF (Menu 9.7.7)
You can send touch tones during an active call
to control your voice mailbox or other
automated phone services.
Security Menu 9.8
PIN code request (Menu 9.8.1)
In this menu, you can set the phone to ask for
the PIN code of your SIM card when the
phone is switched on.
If this function is activated, you’ll be
requested to enter the PIN code.
1. Select PIN code request in the Security
menu, and then press [OK].
2. Set Enable/Disable.
3. If you want to change the setting, you need
to enter PIN code when you switch on the
phone.
4. If you enter wrong PIN code more than 3
times, the phone will lock out. If the PIN is
blocked, you will need to key in PUK code
5. You can enter your PUK code up to 10
times. If you put wrong PUK code more
than 10 times, you can not unlock your
phone. You will need to contact your
service provider.
Handset lock (Menu 9.8.2)
You can use security code to avoid
unauthorized use of the phone. Whenever
you switch on the phone, the phone will
request security code if you set phone lock to
when swith on. If you set phone lock to
when SIM changed your phone will request
security code only when you change your SIM
card.
Touchpad lock (Menu 9.8.3)
You can lock the touchpad of your phone
keeping you from using touchpad sensitivity
unnecessarily.
Note
]The default security code for this phone
is 0000.
Settings
Call barring (Menu 9.8.4)
The Call barring service prevents your phone
from making or receiving certain category of
calls. This function requires the call Network
password. You can view the following
submenus.
]All outgoing calls: The barring service for
all outgoing calls.
]Outgoing international: The barring
service for all outgoing international calls.
]Outgoing international when roaming:
The barring service for all international
outgoing calls except home network.
]All incoming: The barring service for all
incoming calls.
]Incoming when roaming: The barring
service for all incoming calls when roaming.
]Cancel all: You can cancel all barring
services.
]Change password: You can change the
password or Call Barring Service.
The submenus:
- Activate
Allows to request the network to set call
restriction on.
- Cancel
Set the selected call restriction off.
- View status
View the status whether the calls are
barred or not.
Fixed dial number(FDN)(Menu 9.8.5)
(SIM dependent)
You can restrict your outgoing calls to
selected phone numbers.
The numbers are protected by your PIN2
code.
]On: You can restrict your outgoing calls to
selected phone numbers.
]Off: You can cancel fixed dialling function.
]Number list: You can view the number list
saved as Fixed dial number.
77
Settings
78
Settings
Change codes (Menu 9.8.6)
PIN is an abbreviation of Personal
Identification Number to prevent use by
unauthorized person.
You can change the access codes: Security
code, PIN code, PIN2 code.
1. If you want to change the Security
code/PIN/PIN2 code input your original
code, and then press [OK].
2. Input new Security code/PIN/PIN2 code
and verify them.
Memory status Menu 9.9
You can check free space and memory usage
of each repository, Internal memory,
Multimedia memory and External memory.
You can go to each repository menu.
Reset default Menu 9.0
You can initialize all factory defaults. You need
Security code to activate this function.
Accessories
Accessories
79
Standard Battery
Travel Adapter
This charger allows
you to charge the
battery while away
from home or your office.
Data cable/CD
You can connect
your phone to PC
to exchange the data
between them.
Hands free
earmicrophone
and music player
controller combo
]
Stereo headset
]
Controller:
Answer & End button, music player
control, volume control, Hold button
and microphone.
There are a variety of accessories available for your mobile phone. You can select these according
to your personal communication requirements.
Note
]Always use genuine LG accessories.
]Failure to do this may invalidate your
warranty.
]Accessories may be different in different
regions; please check with our regional
service company or agent for further
enquiries.
General
Product name : ME830d
System : GSM 900 / DCS 1800 /
PCS 1900
Ambient Temperatures
Max : +55°C (normal),
+45°C (battery charging)
Min : -10°C
Technical data
80
Technical data
850
