LG Electronics USA MIB2 MIB2 ENTRY User Manual 1

LG Electronics USA MIB2 ENTRY 1

User Manual 1

CONFIDENTIAL
not for distribution
CONFIDENTIAL
not for distribution
Composition Touch, Composition
Colour
Radio
Composition Touch, Composition Colour:
Radio
Stand: 21.08.2013
Englisch: 11.2013
Artikel-Nr.: 142.5R6.RCT.20

1425R6RCT20
L40SE2
CONFIDENTIAL
not for distribution
CONFIDENTIAL
not for distribution
Description of symbols
Refers to a section within a chapter that
contains important information and safety
notes that should always be observed.
Indicates that the section is continued on
the next page.
Indicates the end of a section.
Indicates situations in which the vehicle
must be stopped as quickly as possible.
® Indicates a registered trademark. Howev-
er, the absence of this symbol does not
constitute a waiver of the rights concern-
ing any term.
⇒  Symbols like these refer you to warnings
within the same section or on a given
page. They draw your attention to possi-
ble risks of accident or injury and explain
how they can be avoided.
⇒ 
⇒ 
⇒  Cross reference to information about pos-
sible damage to your vehicle within the
same section or on a given page.
DANGER
Texts with this symbol indicate dangerous
situations which will lead to fatal or severe in-
juries if you do not observe the warning.
WARNING
Texts with this symbol indicate dangerous
situations which could lead to fatal or severe
injuries if you do not observe the warning.
CAUTION
Texts with this symbol indicate dangerous
situations which could lead to slight or se-
vere injuries if you do not observe the warn-
ing.
NOTICE
Texts with this symbol indicate situations
which could cause damage to the vehicle or ve-
hicle equipment if you do not observe the
warning.
Texts with this symbol contain additional in-
formation on the protection of the environ-
ment.
Texts with this symbol contain additional in-
formation.
Volkswagen AG works continuously to develop and
further improve all models. Please understand that
we must therefore reserve the right to alter any
part of the vehicle and its equipment or technical
specifications at any time. The data provided con-
cerning scope of delivery, appearance, perform-
ance, dimensions, weights, fuel consumption,
standards and vehicle functions are all correct at
the time of going to print. Some of the equipment
described might not yet be available in a particular
vehicle (information can be provided by your local
Volkswagen dealership), and some equipment may
not be available in certain countries. No legal com-
mitment may be inferred from the information, illus-
trations or descriptions in this manual.
No part of this manual may be reprinted, repro-
duced or translated without the written permission
of Volkswagen AG.
All rights under the laws of copyright are expressly
reserved by Volkswagen AG. Subject to alteration
and amendment.
Printed in Germany.
© Volkswagen AG 2013
This paper was bleached without the use of
chlorine.
FCC Compliance Statement [Level 4]
<North America>
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turn-ing the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution:
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the users authority to operate
the equipment.
<Canada>
This Class B digital apparatus complies with Canadian ICES-003 To prevent radio
interference to the licensed service, this device is intended to be operated indoors and away
from windows to provide maximum shielding. Equipment (or its transmit antenna) that is
installed outdoors is subject to licensing.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 «Pour
empêcher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit
être utilisé à l'intérieur et devrait être placé loin des fenêtres afin de fournir un écran de
blindage maximal. Si le matériel (ou son antenne d'émission) est installé à l'extérieur, il doit
faire l'objet d'une licence.»
Operation is subject to the following two conditions :
(1) This device may not cause Interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
MODEL L40SE2
Dimensions (mm)
W219.1
Dimensions (mm)
H118.5
Dimensions (mm)
D208.7
Weight (KG) 1.48
Power Requirement 9V~18V
Power Consumption 25W * 4CH
PRODUCT SPECIFICATION
Bluetooth Specification
Standard Bluetooth Version 2.1
Frequency Range 2400 ~ 2483.5 MHz
Output Power (Max.) +4 dBm Max.
