TempConfidential_User Manual-Part I
Model Name : 15Z970
2Introduction / Important Safety Precautions
Introduction / Important Safety Precautions
Using LG Easy Guide, LG Troubleshooting
LG Electronics Inc. provides LG Easy Guide (User's Guide) and LG Troubleshooting (Troubleshooting
Guide) to users for their easy and convenient use of the product.
•Press [
], select [LG Software], and run [LG Easy Guide] or [LG Troubleshooting].
ENGLISH
Introduction / Important Safety Precautions 3
Information/Precautions Before Using
Before reading LG Easy Guide, first check the following information.
•This LG Easy Guide has been written for the Windows 10 operating system.
•The screen and menu configurations may differ from this manual depending on the status of the
Windows update.
•Representative images are used in LG Easy Guide. Product purchased may differ in appearance and
color.
•LG Easy Guide includes instruction about optional products. There may be information about
products you did not purchase.
•The contents of LG Easy Guide are subject to change without prior notice.
•Use, duplication, or reproduction of any part of LG Easy Guide without prior permission from LG
Electronics Inc. is strictly prohibited.
•LG Electronics Inc. does not provide warranty for data loss. In order to minimize damage from data
loss, please make backup copies of important data.
•The optical disk drive (DVD, CD-ROM, etc.) is optional and may not be provided upon purchasing the
product.
•Manufacturers and installers cannot provide services related to human safety as this wireless device
may cause radio interference.
Safety Precaution Notations
The below symbols are to inform you of dangers and safety concerns that you must be aware of. Read
the symbol-indicated instructions with caution to avoid any possible mishap.
WARNING
Appears in the case of noncompliance with the instruction that may cause serious physical
damage or fatal injuries.
CAUTION
Appears in the case of noncompliance with the instruction that may cause minor damage to the
body or the machine.
Text Notations
The symbols below are used to display information required to use the product. Familiarize yourself
with the instructions marked by the symbols to ensure proper operation of the product.
ENGLISH
4Introduction / Important Safety Precautions
TIP
Indicates that the following information is added to help the user utilize the machine more
conveniently.
OPTION
The Option symbol indicates that the concerned device is not included in the product package
and thus has to be purchased separately, or the device may not be applied to the user's machine
depending on model type.
Manufacturer and Copyright
Microsoft™, MS™, WinPE™, and Windows®are the registered trademarks of Microsoft Corporation™.
USB Type-C™and USB-C™are the trademarks of USB Implementers Forum.
Thunderbolt™is a trademark of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
Manufacturer and Copyright represent the logo and trademark of the manufacturer, and bear no
relationship to the functions supported by the product.
LG logo is a registered trademark of LG Electronics, inc.
SD™logo is a registered trademark of Secure Digital™Corporation.
xD™logo is a registered trademark of FUJIFILM™Co., ltd.
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS
Licensing Limited. DTS, the Symbol, & DTS and the Symbol together, DTS-HD, Play-Fi,
Headphone:X, DTS:X, the DTS Headphone:X logo, and the DTS:X logo are registered
trademarks or trademarks of DTS, Inc. in the United States and/or other countries. ¡§Ï
DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo
are trademarks or registered trademarks of HDMI Licensing LLC in the United States
and other countries.
The SuperSpeed USB Trident logo is a registered trademark of USB Implementers
Forum, Inc.
LG Easy Guide may contain undetectable errors despite our dedicated efforts to provide users with
reliable information. We ask for your understanding.
The illustrated figures in LG Easy Guide may differ in appearance with the actual products.
Unauthorized reproduction or duplication of any part of LG Easy Guide is strictly prohibited.
ENGLISH
Introduction / Important Safety Precautions 5
LG Electronics Inc. reserves the right to modify any part of this manual for quality purposes, without
prior notice.
Copyright (C) 2016 LG Electronics Inc. Digitalmate Co., LTD
Country of Origin China
Manufacturer LG Electronics Inc.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is
contained in this product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright
notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the
cost of performing such distribution (such as the cost of media, shipping and handling) upon email
request to opensource@lge.com. This offer is valid for three (3) years from the date on which you
purchased the product.
System Protection Feature
If the system becomes too hot, the system protection feature automatically stops recharging the
battery and switches to hibernate mode or turns the power off.
The PC system may not be reactivated until it cools down enough.
Information on Hard Drive / Memory Capacity
Information on Hard Drive (HDD, SSD, eMMC) Capacity
The hard drive capacity shown by Windows is lower than that stated by the hard drive manufacturer
due to a difference in calculation.
Manufacturer Hard drive manufacturers use a decimal definition of 1 KB = 1,000 Bytes.
100 GB Storage Device (HDD, SSD, eMMC): 100,000 MB / 1,000 Bytes = 100
GB
Windows Windows use the binary definition of 1 KB = 1,024 Bytes.
100 GB Storage Device (HDD, SSD, eMMC): 100,000 MB / 1,024 Bytes =
97.6 GB
RAM Capacity
RAM capacity shown by Windows may be lower than the actual capacity because the PC uses shared
memory for BIOS and the integrated graphics card.
ENGLISH
6Introduction / Important Safety Precautions
Due to BIOS using shared memory, 1,024 MB RAM may be reported as 1,022 MB or slightly less.
If the PC has integrated graphics card, 1,024 MB RAM may be reported as 1,022 MB or less than
1,000 MB.
CMOS Backup Battery
The CMOS backup battery of the main board ensures that the system setup (BIOS) does not disappear
even if the power is disconnected.
The CMOS backup battery is an expendable component.
CMOS backup battery may not be available depending on the model.
CAUTION
•To replace the CMOS backup battery, visit the LG Electronics Service Center.
•The computer may be damaged if an incompatible battery is used.
•The product warranty is not applied to failure or breakdown caused by willful damage by
the user.
Adjusting Volume (headset and speakers)
Check the volume before listening to music.
CAUTION
•Before using the headset, check if the volume is too high.
•Do not use the headset too long.
ENGLISH
Introduction / Important Safety Precautions 7
Important Safety Precautions
Please use the machine in the proper environment to extend the machine's lifespan. Use the machine
in a safe and stable place.
The warranty does not cover any damage resulting from reckless use or use in undesirable
environments.
ENGLISH
8Introduction / Important Safety Precautions
Product Installation/Usage Precautions
CAUTION
Place the machine in a safe place so it does not fall.
•If dropped, the machine may be damaged or cause an injury.
Use the product in a clean, dust-free environment.
•Otherwise, the system may not function properly.
Do not place any objects within 15 cm of the PC.
•Lack of ventilation may overheat the PC from inside and put users at risk of
burn injuries.
Do not store or use the PC near a magnetic object (i.e. a bag with a
magnetic object, a diary, a wallet, a memo board, high-powered speakers, a
bracelet, or etc.).
•Otherwise, the storage device (HDD, SSD, eMMC) and the system may be
damaged, and the system may fail to operate properly.
Do not use the PC on a bag with magnetic objects attached to it.
•Otherwise, the storage device and the system may be damaged, and the
system may fail to operate properly.
Operate the product where there is no electromagnetic interference.
•Keep a proper distance between the PC and electronic appliances such as
radios or speakers that generate strong magnetic fields.
•Otherwise, data may be lost from the storage device (HDD, SSD, eMMC) or
the LCD color may be damaged.
Do not connect a key-phone line to a wired LAN port.
•A fire may occur or the product may get damaged.
If the LCD screen is damaged, do not touch LCD with your hands.
•Contact the service center as it may cause an injury.
Do not leave any objects such as a pen between the keypad and the LCD.
•You might break the LCD by unwittingly closing it with a foreign object
remaining on the pad.
Do not press or scratch the LCD with a sharp object.
•It may cause impairment.
ENGLISH
Introduction / Important Safety Precautions 9
Ensure the power is off before shutting the LCD.
•The product may catch fire, be broken or deformed due to temperature rise.
Do not impose excessive force on the LCD screen or drop it.
•You may break the LCD glass panel.
Do not forcibly open the LCD screen with one hand.
•External impact may be inflicted on the machine.
To clean the LCD screen, use designated agents and soft cloth and rub the
screen in one direction.
•Too much force may damage the LCD screen.
When handling PC parts, follow the instructions in the manual.
•Otherwise, the product may get damaged.
Install a vaccine program on your PC and do not download illegal programs
nor access any corruptive web site such as those pushing pornographic
contents.
•The system may be infected and impaired.
Do not insert devices other than designated ones in the ports.
•Otherwise, the product may get damaged.
Do not press the eject button while the optical disk drive (CD/DVD/Blu-ray)
is running.
•An error may occur or the disc may be ejected, causing injury.
Do not use a damaged optical disc (CD/DVD/Blu-ray).
•Otherwise, the product may get damaged or cause physical injury.
Avoid using a wireless LAN connection within the 5 m radius of a microwave
or plasma lamp. If you have to use wireless LAN and a plasma bulb within
the range, do so between channels 11 and 13.
•The transmission rate may drop even if the connection is made.
ENGLISH
10 Introduction / Important Safety Precautions
Turn off the PC if you are not going to use it for an extended period of time.
•It may overheat the battery.
Make sure that the memory cover is securely closed before turning on the
PC.
•Do not use the machine when the memory cover is open. It may damage the
machine.
Please use parts certified by LG Electronics, Inc.
•Otherwise, a fire or product damage may occur.
If there is a problem with peripheral devices, contact the device
manufacturer.
•The product may get damaged.
Handle devices and parts of the machine with care.
•The product may get damaged.
Do not drop any part or device of the machine while disassembling it.
•If dropped, it may be damaged and cause an injury.
ENGLISH
Introduction / Important Safety Precautions 11
WARNING
Dispose of the desiccating agent and plastic wrap properly.
•The desiccating agent and plastic wrap may cause suffocation.
Do not use the machine in damp places like a laundry room or bathroom.
•Moisture may cause a glitch or electric shock.
•Please use the machine within the appropriate temperature range (10 °C to
35 °C) and humidity range (20% RH to 80% RH).
Clean the PC with a proper agent and dry it completely before using it again.
•If the PC is wet while used, an electric shock or fire may occur.
When lightning flashes in your area, disconnect the power, wired LAN and
other connections.
•An electric shock or fire may occur.
Do not leave a cup or other containers filled with watery substance near the
PC.
•In the case that liquid goes inside the PC, a fire or electric shock may occur.
If you have dropped or damaged the PC, disconnect the power and contact
the local service center for a safety check.
•If a damaged PC is used continuously, an electric shock or fire may occur.
Do not put a lit candle or live cigarette on the PC.
•A fire may occur.
If you detect or smell smoke from the PC, stop use immediately and
disconnect the power source before contacting your local service center.
•A fire may occur.
As the AC adapter can be hot, do not touch it with bare skin while using it.
•Extended period of exposure may cause burn.
The bottom of the PC gets hot when the system is in operation. Do not
touch or put it on your lap.
•Extended period of exposure may cause burn.
Do not play the PC games excessively.
•Playing a PC game for an extended period of time may cause a mental
disorder. It may also inflict physical impairments on the elderly and children.
ENGLISH
12 Introduction / Important Safety Precautions
Do not put your finger or an object into PC ports.
•An injury or electric shock may occur.
Ask one of our engineers to run a safety check after your computer has been
repaired.
•Otherwise, an electric shock or fire may occur.
For minors, we recommend a program that blocks access to illegal or
pornographic web sites.
•Minors' exposure to adult-only contents may inflict psychological instability or
even trauma on them. Take an extra precaution for your children if the whole
family is using this machine.
Keep the machine away from heat-emitting devices such as a heater.
•The product may get deformed or catch on fire.
Prevent children from thrusting their finger into the optical disk drive (CD/
DVD/Blu-ray) tray.
•The finger may be stuck in the tray and injured.
Do not block the ventilation hole with any object.
•Otherwise, an electric shock may occur.
When upgrading your PC, turn off the power and disconnect the power
cable, battery, and LAN.
•There is a risk of electric shock or fire and the product may be damaged.
When you upgrade the PC, ensure that children will not swallow any parts
including bolts.
•If a child swallowed a nut, he or she may get suffocated.
•In that case, see the doctor immediately.
Do not disassemble or modify the machine arbitrarily.
•There is a risk of electric shock and the product may be no longer covered by
the warranty.
ENGLISH
Introduction / Important Safety Precautions 13
If you dissemble the PC, connect the power after reassembly is done.
•There is a risk of electric shock or product damage, if you touch the
disassembled PC.
Do not put in metal items such as coins, hair pin or other irons or
inflammables such as paper or matches. Especially, ensure that children will
not do so.
•There is a risk of product damage, fire, or electric shock.
•If any foreign substance gets in the product, unplug the product and contact
the local service center.
Product Storage/Transportation Precautions
CAUTION
Before carrying the machine, turn off the power and disconnect all the
cables.
•Otherwise, you may trip over the wire, damaging the PC and sustaining an
injury.
Do not carry the machine with the LCD open.
•Otherwise, the product may get damaged.
Protect the machine from any shock while carrying it.
•System damage or an injury may result.
Carry the product in a bag designed for it.
•Carrying it in another type of bag may result in product damage.
Do not put any heavy object on the PC.
•There is the risk of malfunction. If the object were to fall, it may cause an
injury or damage the machine.
ENGLISH
14 Introduction / Important Safety Precautions
WARNING
During air travel, follow the directions of flight attendants.
•Using the PC during flight may cause an aircraft accident.
When leaving the machine in a car, avoid exposure to direct sunlight.
•The product may get deformed or caught on fire due to a temperature rise.
Do not put any heavy object on the power cable and AC adapter, and avoid
damage from impacts.
•A malfunction or fire may occur.
Do not leave the powered-on PC in a space without enough ventilation (i.e.
bags) for an extended or repeated time.
•The battery may overheat and cause a fire.
ENGLISH
Introduction / Important Safety Precautions 15
Battery and AC Adapter Precautions
WARNING
When the PC is not used for an extended period of time, keep the battery
level at 50 %.
•Do not leave the product with discharged battery for an extended period of
time. It may damage the battery.
Charge the battery only with the provided instrument.
•Otherwise, the battery may be damaged presenting a risk of fire.
Do not throw or disassemble the battery.
•The resulting damage may cause an injury, explosion, or fire.
Use batteries certified and acknowledged by LG Electronics Inc.
•Otherwise, an explosion or fire may occur.
Prevent the battery from being in contact with any metallic object like a car
ignition key or a paper clip.
•Otherwise, this may cause damage to the battery, a fire or burn due to
overheat in the battery.
Keep the battery away from heat.
•Otherwise, an explosion or fire may occur.
Do not short-circuit the battery.
•Otherwise, it may explode.
Do not dispose of a spent or backup (standby) battery arbitrarily.
•It may explode or cause a fire.
•Disposal methods may differ by country and region. Dispose of spent batteries
in accordance with the laws and safety rules of the country and region you
reside in.
ENGLISH
16 Introduction / Important Safety Precautions
If you find leakage or smell bad odor from the battery, remove the battery
and contact the local service center.
•It may explode or cause a fire.
Do not store in places with temperatures above 60 °C and high humidity (in
cars or saunas).
•It may explode or cause a fire.
Keep the battery out of the reach of children or pets.
•If damaged, it may cause an injury.
Keep the battery from being pierced by a sharp object or chewed by pets.
•It may explode or cause a fire.
Do not put the battery in water.
•Otherwise, the battery may be damaged or explode.
Do not use the PC on top of carpet, blanket or bed. Also, do not put the
adapter under the blanket.
•This may cause a malfunction, fire or burn due to overheat in the PC and
adapter.
Read the battery usage precautions carefully before use.
•Keep the battery at room temperature. LG Easy GuideRefer to the Tip. Using a
Battery in the installation guide to store the battery properly.
Connect the power plug properly by pushing it to the end.
•If a contact failure occurs, it may cause product damage or fire.
ENGLISH
Introduction / Important Safety Precautions 17
Do not bend the power cable for AC adapter too much or get stamped by a
sharp object.
•The wires inside the cable may break and cause electric shock or fire.
Do not use loose plugs or damaged power cords.
•An electric shock or fire may occur.
Do not touch the power cord with your hands wet.
•Otherwise, an electric shock may occur.
Pull the plug, not the cord, to disconnect the AC adapter and power jack.
•Otherwise, a fire or product damage may occur.
Operate the product at the proper voltage.
•Excessive voltage may result in damage on the product, electric shock or fire.
Use power outlets with an earth pin installed and proper supply of rated
electricity.
•An electric leakage may cause an electric shock or fire.
•The shape of the power cord and outlet may differ by country and region.
In the case of strange noise from the cord or plug, disconnect the power
cord from the outlet immediately and contact the service center.
•A fire or electric shock may occur.
Use the power supply/adapter provided with the product and never
disassemble the product.
•Using a different product or disassembling it may cause an electric shock or
fire.
Always keep the AC adapter and power outlet clean.
•A fire may occur.
Keep children and pets from damaging the power cord.
•It may cause a fire or an electric shock.
ENGLISH
18 Introduction / Important Safety Precautions
Disconnect the PC completely before cleaning it.
•Otherwise, an electric shock or impairment may occur.
If the power/AC adapter or the product is soaked, disconnect the battery,
power/AC adapter, and all other lines before contacting the local service
center.
•An electric shock or fire may occur.
Ensure that the battery pack is locked to the machine after installation.
•Otherwise, the battery may be damaged.
ENGLISH
Introduction / Important Safety Precautions 19
Other Safety Precautions
CAUTION
Handle the machine with care to prevent loss of data from the storage
device (HDD, SSD, eMMC).
•Since the storage device is fragile, you need to back up your important data
frequently.
•The manufacturer is not responsible for any storage device data loss caused by
a user's mistake.
Damage to the storage device (HDD, SSD, eMMC) and data loss may occur
when:
•External shocks are inflicted on the machine while disassembling or installing it.
•The machine is reset (i.e. restarted) or turned on again after a power outage
while the storage device is operating.
•The PC is infected with a virus, tainting the data irrecoverably.
•Abrupt turning-off of the PC can damage the PC.
•If the product is moved, shaken or exposed to external shock while the storage
device is running, file damage or bad sectors may occur.
To minimize data loss resulting from storage device damage (HDD, SSD,
eMMC), frequently back up important data.
•The manufacturer is not responsible for any data loss.
We do not refund or replace a product that malfunctions due to the
installation or use of an operating system other than the one provided by LG
Electronics Inc.
•Some software applications may not work properly in other operating systems.
Such malfunctions are not covered by the warranty.
ENGLISH
20 Introduction / Important Safety Precautions
ENERGY STAR®
ENERGY STAR®
ENERGY STAR®Specifications
•LG Electronics Inc. participates in ENERGY STAR®and the energy efficiency of this
product complies with the specifications of ENERGY STAR®.
•ENERGY STAR®is a set of regulations that encourages manufacturers of
electronic devices to create more energy efficient products.
•The energy consumption of this product was decreased along with the cost. Also,
it helps preserve natural resources.
•This PC includes a feature that turns into (Sleep) mode when it is not used for up
to 30 minutes.
•To leave sleep mode, click a mouse button or press any key on the keyboard.
ENGLISH
Introduction / Important Safety Precautions 21
Product Specifications
PC Specifications
Display 39.6 cm IPS LCD or Touch LCD
The display resolution may differ by model.
CPU Intel®Core™i7 / i5 / i3 or Intel®Pentium®processor
The CPU differs depending on model type and cannot be replaced by the user.
GPU Intel®HD Graphics 620 or Intel®HD Graphics 610
The GPU differs depending on model type and cannot be replaced by the user.
When processing large graphic data, it utilizes dynamically allocated system
memory. The size of the allocated memory depends on the system memory size.
System
Memory DDR4 SODIMM
The maximum capacity of the main board is 16 GB.
Memory of 3 GB or more is supported only in a 64-bit O/S.
Memory size may differ depending on the model. The user must not arbitrarily
replace the memory.
Storage Device M.2 SSD (2280)
SSD capacity may differ depending on the model.
Bluetooth Bluetooth 4.1
If you connect to Bluetooth device and wireless LAN at the same time, the system
may become slow.
In order to use Bluetooth 4.1, the device you want to connect to should support
Bluetooth 4.1.
Wireless LAN Intel®8265D2W
Qualcomm QCNFA324A
The WLAN card may differ depending on model. The user must not arbitrarily
replace the WLAN card.
Manufacturers and installers cannot provide services related to human safety
as this wireless device may cause radio interference.
Webcam HD Webcam
LAN 10/100 Megabit or Gigabit
To use a wired LAN, you need to have a LAN adapter installed separately.
The performance of the provided adapter depends on the model.
Product
Weight Approx. 1090 g (based on a large capacity battery) / Approx. 990 g (based on a
standard battery)
The weight may differ depending on the model.
The product dimensions and specifications differ by model type and cannot be replaced by the
user.
ENGLISH
22 Introduction / Important Safety Precautions
Power Supply and Environments
AC Adapter (Free Voltage) Power Capacity: 40 W
Input: AC 100 V to 240 V, 1.0 A - 1.1 A 50 / 60 Hz
Output: DC 19 V, 2.1 A (40 W)
Battery Lithium Ion battery
Charging Hours: 3.0 hours
Charging hours may be longer if the battery is not used for a long
time or the system is on.
When temperature is outside the operating temperature
specification, the battery may not be charged or charging hours
may be longer.
Operating temperature may be different from the actual room
temperature.
Operating and Storage
Conditions Operating Temperature: 10 °C to 35 °C
Operating Humidity: 20 % RH to 80 % RH
Storage Temperature: - 5 °C to 40 °C
Storage Humidity: 5 % RH to 90 % RH
Power Consumption
Power consumption of this product during operation standby, sleep mode, and manual off modes
may differ depending on the product specifications and the adapter type. Even when the system
is turned off, it consumes a minute amount of power, if supplied. To cut off the power supply
completely, disconnect the power cord from the power outlet.
ENGLISH
Using Windows 10 23
Using Windows 10
Start Menu
A New Start Menu
The Start menu in Windows 10 has been changed so you can use Windows quickly and easily.
Press the [ ] button in the lower-left corner of the screen to display the Start menu.
TIP
Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
ENGLISH
24 Using Windows 10
1Expand: Displays the names of all menu items.
2User Account: Displays the current user's information.You can use functions such as Change
Account Settings, Lock or Logout.
3Settings: You can set up the system including the network settings.
4Power: Sleep, System Shutdown, and Restart menus are available.
5App List: Displays the app list.
6App Tile: Apps added to the Start menu are displayed in tile format.
7Start Button: Opens or closes the Start menu.
8Windows Search: Searches for the text entered by the user in My Items (system) or the Internet.
9Add/Toggle Desktops: You can add and use multiple desktops.
10 Action Center: You can view the system-related notification messages and change PC settings.
TIP
•Press [ ] + [X], and then the [ ] button pop-up menu appears.You can use the
pop-up menu to easily access the shortcuts for Control Panel, Explorer, Search, System
Shutdown, and the desktop environment.
ENGLISH
Using Windows 10 25
Desktop Apps and Windows Apps
The Desktop apps remain unchanged from the previous Windows apps, but Windows apps have been
changed to include various functions.
The Windows apps provide easy-to-use menus according to the window size and a variety of
convenient functions such as Update and Alarm.
ENGLISH
26 Using Windows 10
Using Apps
Running and Exiting Apps
Run apps that were not added to the Start menu or apps that were installed on the system using the
following method:
1Press the [
] button and select and run the app you want from the app list.
TIP
Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
2To exit an app, press the [ ] button on the top of the app screen.
Deleting Apps
You can delete apps from the Start menu tiles or the app list.
TIP
The basic Windows apps that are required may not be deleted.
ENGLISH
Using Windows 10 27
1Press the [
] button to display the Start menu.
TIP
Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
ENGLISH
28 Using Windows 10
2Go to the Start menu app tiles or the app list and right-click the app you wish to delete.
ENGLISH
Using Windows 10 29
3When the pop-up menu appears, select [Uninstall].
TIP
If you are deleting a desktop app, the Programs and Features window appears. Right-click
the app you wish to delete and press the Uninstall/Change button.
ENGLISH
30 Using Windows 10
4When prompted to confirm the deletion, click the [Uninstall] button to delete the app.
Adding Apps to Start Menu/Taskbar
You can add frequently used apps on the Start menu and taskbar for easy and quick access.
ENGLISH
Using Windows 10 31
1Press the [
] button to display the Start menu.
TIP
Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
ENGLISH
32 Using Windows 10
2Right-click the app you want from the app list, and then click [Pin to Start] or [More] >[Pin to
Taskbar].
3The selected app is added to the Start menu or taskbar.
ENGLISH
Using Windows 10 33
Toggling and Adding Apps/Desktops
In Windows 10, you can toggle the running apps easily and quickly, and add desktops to use them like
multiple PCs.
TIP
For an app that does not allow multitasking, you may be switched to the desktop where the app
was executed, or you may have an error message.
1In the taskbar, press [ ].
ENGLISH
34 Using Windows 10
2The screen to switch between apps and desktops appears and the running apps are displayed in
the preview.
TIP
Press the [ ] button of an app in the preview to exit the app.
ENGLISH
Using Windows 10 35
3Click the [New desktop] tile.
4[Desktop 1] and [Desktop 2] are created.
TIP
Two desktops are provided by default and you can add more if necessary.
ENGLISH
36 Using Windows 10
5Select an app in the preview or desktop.
6The screen is toggled to the selected app or desktop.
ENGLISH
Using Windows 10 37
TIP
Press the [ ] button in the app preview to exit the app.
In the desktop preview, press the [ ] button to delete the desktop and move running apps
to another desktop.
ENGLISH
38 Using Windows 10
Using Shortcut Keys
Use the shortcut keys to quickly toggle between apps and desktops.
Shortcut Keys Comments
[Alt] + [Tab] Hold down the [Alt] key and press the [Tab] key to view the running apps
in the preview.
Press [Tab] repeatedly to select the app you wish to switch to and then
release the [Alt] key.
[Alt] + [Ctrl] + [Tab] The running apps on the screen are displayed in the preview.
Select and switch to an app.
[
] + Tab If the desktop toggling screen appears, select an app or desktop you wish
to switch to.
ENGLISH
Using Windows 10 39
Splitting the App Screen
In Windows 10, you can easily adjust window sizes and split windows if necessary.
TIP
Some apps that cannot adjust the window size do not support the screen split.
ENGLISH
40 Using Windows 10
Full Screen
1Drag and drop an app to the top end of the screen to change the app to the full screen size.
2Drag and drop the app again to a different location to return to its original size.
ENGLISH
Using Windows 10 41
Screen Split into Two
1Drag and drop an app to the right end or left end to reduce the size by half.
TIP
The screen is split according to the guideline.
ENGLISH
42 Using Windows 10
2Select a running app displayed in the preview on the split screen.
3Drag and drop the app again to a different location to return to its original size.
ENGLISH
Using Windows 10 43
Screen Split into Four
1Drag and drop an app to the left corner to reduce the app to 1/4 size of the screen.
TIP
The screen is split according to the guideline.
ENGLISH
44 Using Windows 10
2You can use this method to place up to four apps on the screen.
3Drag and drop the app again to a different location to return to its original size.
ENGLISH
Using Windows 10 45
Using the Store
You can purchase apps or get free apps from Windows Store.
TIP
If a local account is being used, a window to switch to a Microsoft account appears while using
Windows Store. Follow the instructions on the screen to switch the local account to a Microsoft
account.
You can also do so by selecting [Start menu] > [Account] > [Change Account Settings].
If you switch to a Microsoft account, your PC settings (background, user settings, etc.) may be
changed to the previous settings.
1Press the [ ] button to move to the Start menu and select the [Store] tile.
TIP
Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
ENGLISH
46 Using Windows 10
2On the Store screen, select a category or app of your choice.
3On the app details screen, select [Get] or [Buy].
4App installation starts in a moment.
ENGLISH
Using Windows 10 47
5You can see the installed app in the app list on the Start menu.
ENGLISH
48 Using Windows 10
Switching to Tablet Mode
If you are using Windows on a tablet PC, you can easily switch to the tablet mode.
1Press the Action Center [
] icon on the right side of the taskbar.
ENGLISH
Using Windows 10 49
2Select [Tablet mode] to switch Windows to tablet mode.
3Select [Tablet mode] again to deactivate the mode.
ENGLISH
50 Using Windows 10
Unlocking the Screen
If the PC is not used for an extended period, it goes into a locked state.
When the PC is used again, a lock screen appears for security purposes and may be unlocked by using
the following method.
1From the lock screen, press any key on the keyboard or drag up while you click and hold the mouse
button.
2When the login window appears, enter the password and click [Enter].
(If no password is set, press the login button to immediately unlock the screen.)
ENGLISH
Using Windows 10 51
Setting the PC
Windows 10 supports various functions so that the user can change the PC setting easily and quickly.
Using Action Center
You can use the Action Center to easily change the settings for tablet mode, display, media connection
and network settings.
The functions supported by the Action Center may differ depending on the model.
1Press the Action Center [
] icon on the right side of the taskbar.
ENGLISH
52 Using Windows 10
2Change the PC settings as needed.
TIP
If the tile does not appear, press the [Expand] menu.
3To change the detailed settings of the PC, press the [All Settings] tile.
ENGLISH
Using Windows 10 53
Using the Start Menu
1Press the [
] button and select the Settings menu.
2When the screen for PC's detailed settings appears, select and change the settings as needed.
ENGLISH
54 Using Windows 10
Windows Shutdown Option
In Windows 10, you can use the Windows shutdown option by following these steps:
1Click the [
] button and select the [Power] menu.
TIP
Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
2Select a Windows shutdown option.
TIP
On the Desktop screen, press [Alt] + [F4] to use the Windows shutdown option.
(Pressing [Alt] + [F4] on a running app may end the app.)
ENGLISH
Using the PC 55
Using the PC
Using an AC Adapter and a Battery
Connect the AC adapter to power and charge the product.
TIP
The power cable and the AC adapter type may differ per model type and country and there
is no difference in functionality.
This product has a built-in battery pack.
The internal battery should not be arbitrarily disassembled or replaced. Arbitrarily
disassembling the product may void the warranty.
If you need to disassemble or replace the battery, please visit the designated LG Electronics
Service Center.
We charge a fee for removing or replacing the battery.
Using an AC Adapter
An AC adapter of 100 V - 240 V can be used.
1Connect the AC adapter to a power outlet.
2Connect the AC adapter to the PC.
3Adjust the LCD to the most comfortable angle.
4Press the PC's power button to turn on the system.
CAUTION
Do not leave a liquid container on the PC.
•The system may be short-circuited and damaged.
ENGLISH
56 Using the PC
WARNING
Please use an AC adapter certified by LG Electronics Inc.
•Uncertified batteries may explode.
•It may cause a problem in battery charging or system operation.
When you use an AC adapter, follow the below directions.
•60 °C or more high-humidity spaces, for example, inside cars or saunas, should be avoided
when you use or store it.
•Do not disassemble or modify the AC adapter.
•Do not twist the AC adapter plug.
•When you connect the AC adapter, do not forcefully push the plug.
Checking the Battery State
1Connect the AC adapter to the power port in the PC.
ENGLISH
Using the PC 57
2Open the LCD and check the charging state.
When the AC adapter lamp is blinking, charge it fully with the AC adapter before using it.
CAUTION
Use batteries certified and acknowledged by LG Electronics Inc.
•Uncertified batteries may explode.
ENGLISH
58 Using the PC
WARNING
The battery may explode due to excessive heat, causing fire. For a safe and efficient use of
battery, follow the below directions.
•Do not short-circuit the battery.
•Keep the battery out of reach of children.
•A visible swelling of the battery pack indicates a possible danger. When this occurs, contact
your local vendor or service center immediately.
•Use only a certified and designated recharger.
•Keep the battery pack away from heat. (Never put it in a microwave.)
•Do not leave inside a car under the summer heat.
•Do not leave or use at a hot and humid place like a sauna.
•Do not use the machine placed on a heating blanket or other heat reserving materials.
•Do not leave the machine turned on inside a closed space.
•Make sure that the power ports are not touched by any metallic objects like a key, coin,
necklace, and watch.
•Use only a lithium secondary battery certified and guaranteed by mobile device
manufactures.
•Do not disassemble or modify the battery. Do not compress or pierce the battery.
•Do not apply shock to the battery. For example, do not drop the battery from a high place.
•Keep the room temperature between -5 °C and 40 °C. Do not expose the PC to heat
hotter than 60 °C.
•Keep the machine dry.
•Do not discard the battery arbitrarily as you are requested to follow the local procedure
for discarding the battery.
•Before using this machine, read this guide carefully.
ENGLISH
Using the PC 59
TIP
When the PC is not used for an extended period of time, refer to the following:
•Check the battery charge level on a regular basis and keep it at 50 %. This allows you to
extend the battery life.
•If the battery is left fully charged for an extended period of time, the battery capacity and
battery running time may be reduced.
•If the battery is left fully discharged for an extended period of time, it may become over-
discharged and cannot be charged again.
For more efficient use of the battery, read the following carefully.
•The battery runs low naturally even if it is kept unused.
•To increase battery lifespan, use the battery for a while before charging it rather than
keeping the battery completely charged.
•If you don't use the product for a long time with the battery completely charged, the
battery lifespan may decrease.
The battery capacity may change due to chemical reactions during charge and discharge.
•The system checks the charge status of LG batteries frequently, and then calculates and
indicates the actual battery duration on the current system setup.
•The battery is wearable goods and thus the life span may become shorter with use.The
battery running time may also become shorter accordingly.
•When the battery is fully charged, the machine stops recharging. It resumes recharging
when the battery charge rate drops below 95%. This feature secures the safe and efficient
use of the battery.
•When the temperature of the battery drops below 10 °C, it is charged in a low current to
protect the battery cells. In this case, charging time may stretch to up to 32 hours.
If you use the system at a low temperature, refer to the following:
•The battery capacity may be reduced depending on the chemical characteristics of the
battery and the system may not be turned on after it freezes or it is turned off.
•If the system freezes or if it is not turned on, connect the AC adapter to the system and
charge the battery fully before use.
•If there is any error in the indication of the battery capacity, charge and discharge the
battery two or three times at room temperature to return to the normal operation.
ENGLISH
60 Using the PC
Operation Status Lamps
1AC Adapter Lamp
•On: The AC adapter is connected.
•Off: The AC adapter is not connected.
If you try to turn on the system that has entered the Hibernates mode or been turned off
after a low-battery alarm, the system will not be turned on but the lamp will blink three
times. If this is the case, connect the AC adapter and charge the battery sufficiently before
using it.
2Storage Device (HDD, SSD, eMMC) Indicator Lamp
•When the PC accesses the storage device, the indicator lamp turns on.
Do not turn off the power forcibly while the storage device indicator lamp is on or blinking.
Otherwise, the disk or its data may get damaged.
3Power Lamp
•On: The system is on and running by the AC adapter or battery.
•Off: When the system is turned off or in Hibernate mode
•Blinking: The system is in the standby mode.
ENGLISH
Using the PC 61
4Caps Lock Lamp
•On: When the Caps Lock is activated
•Off: When the Caps Lock is deactivated
5Touchpad Lamp
•On: When the touchpad is activated
•Off: When the touchpad is deactivated
6Webcam Operation Status Lamp
•On: When the webcam is operating
•Off: When the webcam is not operating
7Reader Mode Lamp
•On: When the Reader Mode is activated
•Off: When the Reader Mode is deactivated
ENGLISH
62 Using the PC
Keyboard
The keyboard allows the user to input data or give commands.
The keyboard may differ in appearance and color depending on your country.
CAUTION
•Spilling a watery substance like coffee or juice on the keyboard may cause a fault,
malfunction, or electric shock.
•The keys may not work properly when you use several keys at the same time while playing
a PC game. (Please change the key combination settings according to the combinations
necessary for the game play.)
Using Hot Keys
You can use the hot keys shown below to use the PC conveniently.
Fn + F1 Executes LG Control Center
Fn + F2 Decreases LCD brightness, which can have eleven different levels.
Fn + F3 Increases LCD brightness, which can have eleven different levels.
Fn + F4 Runs the mode defined in Windows Sleep Mode. (Example: Standby Mode,
Hibernate Mode)
Fn + F5 When the [Fn] + [F5] keys are pressed, the mode switches in the order of
Touchpad Off (touchpad is not enabled), Touchpad Auto (touchpad is not enabled
when an external USB mouse is inserted), Touchpad On (touchpad is enabled).
Initialization takes 1 to 2 seconds. It is recommended to use after the initialization.
Fn + F6 Airplane Mode ON/OFF (Wireless LAN, Bluetooth OFF/ON)
Fn + F7 Switches between monitor and projector.
Fn + F8 Its function differs depending on the model. It performs one of the following
functions:
Switches to the [ ] Keyboard Lighting Mode.
Runs the [ ] Audio Manager.
Fn + F9 Switches to the Reader Mode.
Fn + F10 Mute
Fn + F11 Turns down the volume.
Fn + F12 Turns up the volume.
ENGLISH
Using the PC 63
Fn + Prt Sc Works as the [Scr Lk] (Scroll Lock) key.
Fn + Ctrl Works as the [Pop-up Window] key.
Fn + ◀Works as the [Home] key.
Fn + ▶Works as the [End] key.
Fn + ▲Works as the [Page Up] key.
Fn + ▼Works as the [Page Down] key.
Shortcut Keys
TIP
•To change the input mode temporarily, you can press the [Shift] key together with the
letter you want to enter. By doing so, you can enter an uppercase letter when the Caps
Lock key is not pressed and a lowercase letter when it is pressed.
To use Windows more conveniently, remember the following Windows key combinations:
•+ R
Displays an input window for program execution.
•+ Tab
Displays the running desktop in the preview.
•+ M
Minimizes the current window.
ENGLISH
64 Using the PC
Keyboard Backlight
You can set the Keyboard Backlight function to use the product in a dark environment.
The figures herein are subject to change without prior notice.
OPTION
This only applies to the products that have the Keyboard Backlight function.
Configuring Keyboard Backlight
TIP
You can use hot keys to use the Keyboard Backlight function more conveniently.
•Each time you press the [Fn] + [F8] keys, the status changes to KBD Backlight Off,KBD
Backlight Low, and then KBD Backlight High in the specified order.
1Select the [ ] button > [LG Software] to run [LG Control Center].
2On the LG Control Center screen, select the [System Settings] menu.
ENGLISH
Using the PC 65
3Go to Keyboard Backlight and select your desired options.
ENGLISH
66 Using the PC
Adjusting Screen Brightness and Volume
LG PC allows you to use the hot keys to easily adjust the screen brightness and volume.
TIP
According to the model type, a button for volume control (mute, volume up / down, DTS, etc.)
may be available.
Function Hot Keys Comments
Screen
Bright-
ness
[Fn] + [F2], [F3] Press the [F2] key to darken the screen or the [F3] key to
brighten it.
Press the Action Center [ ] icon on the right side of
taskbar to run the Action Center. Click the [Brightness] tile
to adjust the screen brightness.
Volume [Fn] + [F11], [F12] Press the [F11] key to lower the volume or [F12] key to
increase the volume.
Press the [ ] icon on the right side of the taskbar to
adjust the volume.
Mute [Fn] + [F10] Press the button to turn on or off the mute feature.
Press the [ ] icon on the right side of the taskbar to
mute the sound.
ENGLISH
Using the PC 67
Using the Touchpad
The built-in touchpad provides the same functionality as an external mouse.You can use the touchpad
and USB mouse simultaneously.
For best performance, it is recommended to use the driver provided by the touchpad
manufacturer.
The driver provided by the touchpad manufacturer is preinstalled when you purchase this product.
You can reinstall the driver through LG Update Center.
The touchpad scroll feature is not supported in the model that supports the gesture feature.
1Touchpad
•Moves the cursor.
2Scrolling area
3Left button
•Use to select or execute programs.
4Right button
•Functions as the right button of a mouse in most cases. However, the usage may differ
depending on programs.
Moving the Cursor (Pointer) on the Screen
Place a finger on the touchpad and glide the finger.
ENGLISH
68 Using the PC
Click (Select)
Press and release the left button swiftly with a finger. (Or tap the touchpad once.)
Do this, for example, to select a menu or icon and to place the cursor to type on a word processor file.
Double-click (Execute)
Press the left button twice consecutively and release the button. (Or tap the touchpad twice.)
Do this, for example, to run a program after selecting its execution file (or icon).
ENGLISH
Using the PC 69
CAUTION
Notes on Using the Touchpad
•Do not use a sharp object such as a pen on the pad nor peel the cover. It may cause an
impairment.
•Do not place more than one finger, and do not use while wearing a glove or when the
hand is wet.The Touchpad will not work properly. Oil or dirt at the fingertip can also cause
an impairment.
•The touchpad is sensitive. Do not impose excessive force or maintain an uncomfortable
position. Otherwise, it may result in a finger or wrist injury.
Right button
Press and release the right button swiftly.
Functions as the right button of a mouse, but the usage may differ depending on programs.
ENGLISH
70 Using the PC
Drag & Drop
To drag, click and hold an icon, and move it to another location.
To drop, release the dragged icon in the location you want.
To move a file icon to another folder or to Recycle Bin, place the cursor (or the pointer) on the icon,
press and hold the left button, and glide another finger on the touchpad until the icon reaches the
aimed location. After reaching the destination, release the left button.
1Drag
•Glide one finger on the pad with another finger pressing and holding the left button.
2Drop
•Release the left button to drop it into the Recycle Bin. (By using this, you can drop a file into the
Recycle Bin at will.)
ClickLock
When activated, this feature allows you to drag/scroll without pressing and holding the left button.
ENGLISH
Using the PC 71
1Click the [
] button and select the [Settings] menu.
TIP
Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
ENGLISH
72 Using the PC
2When the [Settings] screen appears, select [Devices].
3Select [Mouse & touchpad] > [Additional mouse options].
ENGLISH
Using the PC 73
4When [Mouse Properties] screen appears, select [Turn on ClickLock].
5Press [Settings] to set the time for the ClickLock.
ENGLISH
74 Using the PC
6Press the left button of the touchpad and release it to change the button into the pressed state.
7Move on the touchpad to use the drag/scroll feature.
8Press the left mouse button to turn off the ClickLock.
Touchpad Gesture
The touchpad gesture feature allows you to use Windows programs more easily by utilizing multi-
touch functions.
Windows 10 Touchpad Gestures allow you to use the PC more easily.
The touchpad gesture feature may not be supported in some models.
ENGLISH
Using the PC 75
•Place two fingers on the touchpad and move up/down/left/right to scroll the screen.
(It operates only on an app or screen which scrolling is available.)
•Place two fingers on the touchpad and widen or narrow them to zoom out or in.
ENGLISH
76 Using the PC
Setting Touchpad
You can change the touchpad features or enable/disable the gesture feature.
The figures herein may differ by language selection and are subject to change without prior
notice.
1On the desktop taskbar, double-click the touchpad settings icon.
ENGLISH
Using the PC 77
2When the following screen appears, change the settings and click [OK].
ENGLISH
78 Using the PC
Using Touch Panel
Use the touch panel for a faster and more convenient use of the PC. All gestures provided by Windows
10 can be used.
For more details about the Windows 10 gestures, refer to Windows help.
OPTION
This applies only to models equipped with a touch panel.
Basic Usage
1Touching Once: Touch the panel once to use as left mouse button.
ENGLISH
Using the PC 79
2Touching Twice: Touch the panel twice to use as double-click.
3Drag: After touching the start point, finger movement can be used instead of the mouse.
ENGLISH
80 Using the PC
4Touching Longer: Touch the panel for a longer time to use as right mouse button.
ENGLISH
