LG Electronics USA PBSC510 Bluetooth Speaker User Manual 11 PBS C510

LG Electronics MobileComm USA, Inc. Bluetooth Speaker 11 PBS C510

11 User Manual_PBS-C510

Rev 1.0 US
All rights reserved. LG Electronics Inc., 2015
Please read all information carefully prior to using the PBS-C510 in order to prevent
product damage and to enjoy the best performance.
WARNING:
This product contains chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Call (800) 243-0000 for more information. Wash hands after handling.
English
PBS-C510 User Manual
2
ENG
Description of Part
NFC
Bluetooth®
Play/Pause
Volume
Up
LED
Lighting
Volume
Down
Mood LED
Play Next
EQ
Play
Previous
Charging LEDCharging Port
Included in the Package
USB Charging
Cable
User ManualPBS-C510
Bluetooth Speaker
NOTE: Actual product design may differ from images shown in this manual.
3
ENG
How to Use
Power On/Off
Power On
Press the top of the speaker to power on the product.
Î
Power Off
If you press the top of the speaker while it is powered on, the power will
be turned off.
Î
Charging
1. Connect the USB adapter and USB charging cable.
2. Open the USB cover, then plug the USB charging cable (as shown
below) into the speaker’s charging port.
3. Plug the charger into an electrical outlet.
Low Battery
y A low battery alert will play once per minute.
y If the battery is not charged, the Speaker will power off.
Battery Status Alert
y Press and hold the button for 2 seconds to check the battery status
of the speaker.
Battery Status Low
(Under 80%) Medium
(Above 80%) High
(Fully Charged)
Charging LED
Indicator Red light Violet light Blue light
4
ENG
Button Description
Button Description Button duration
Play / Pause Short touch
Volume Up Short touch
Volume Down Short touch
Display Battery Status Long touch (2 secs)
Play Next Short touch
Play Previous Short touch
Equalization Mode Changes Short touch
Enter Pairing Mode Long touch (2 secs)
Change the Mood LED light.
Default J Always On J Off Short touch
+ Dual Play Inquire Long touch (2 secs)
+ Change to Dual play Long touch (2 secs)
+
or
+
End the Dual Play Long touch (2 secs)
+ Connect with TV Sync Long touch (2 secs)
+ + Reset the Speaker Long touch (5 secs)
Pairing
7RXVHWKHVSHDNHU\RXPXVW¿UVWSDLULWZLWK\RXUPRELOHGHYLFH
Easy Pairing
1. Push the power button to the on position. The speaker will enter
pairing mode.
2. When the speaker enters pairing mode, the LED light will blink
twice every 2 seconds. Pairing mode is active for 10 minutes.
3. With your mobile device, scan for and select the Bluetooth speaker.
4. If prompted, enter a password to pair the devices.
Manual Pairing (use when pairing with a second mobile
device or re-pairing with a previously paired device)
1. Push the power button to the on position.
2. Touch and hold the h button.
3. Repeat step 2 through 4 of Easy Pairing.
NFC
Bluetooth connection is available through NFC.
In order to use this feature, you need to activate NFC on your mobile
device. (The Read/Write item should be checked on the NFC menu on
your mobile device.)
1. Bring your mobile device close to the LG logo on the top of the
speaker.
2. Select “Yes” from the pop-up window to pair and connect the
mobile device and speaker.
3. Once connected via NFC, bringing your mobile device close to the
LG logo (NFC) on the speaker will disabled the connection.
NOTE:
y Once the speaker and a device have been paired, the next time the
speaker is powered on it will automatically try to reconnect with the
last device it was paired with.
y If the speaker cannot connect to a previously paired device within
20 minutes, it will automatically power off.
5
ENG
Advanced Multipoint
The speaker can be connected to two devices at the same time.
Pairing with Two Devices
1. Pair the speaker with the Bluetooth-enabled mobile device you
want to use as your secondary device (see Pairing instructions).
2. Once paired, power off the speaker.
3. Pair and connect the speaker with your other Bluetooth-enabled
mobile device. This will be your primary device.
NOTE:
y When the speaker is connected to two mobile devices at the same
time (Multipoint), the speaker will work with the primary mobile device.
y If the speaker fails to connect to the primary mobile device through
Easy Pairing, it will enter Pairing mode.
Auto Reconnect
If in range of each other when the speaker is powered on, the speaker
and the primary mobile device will automatically reconnect.
The secondary mobile device will need to be manually connected
by selecting LG PBS-C510 from the available devices listed in the
Bluetooth menu.
Out of Range
If the paired devices are separated by a range of 33 feet (10 meters)
or more, the speaker and paired mobile device(s) will disconnect,
and the speaker will alert you.
If the speaker and paired mobile device do not automatically reconnect
ZKHQWKH\DUHEDFNZLWKLQWKHUHTXLUHGUDQJHEULHÀ\SUHVVh on the
speaker to manually reconnect.
When connected to multiple devices, the paired device that is not in use
will disconnect when out of range.
Dual Play (Optional)
You can enjoy stereo sound using two PBS-C510 products.
8VLQJWKH3DLULQJLQVWUXFWLRQVSDLU\RXUPRELOHGHYLFHZLWKWKH¿UVW
speaker A.
2. Press the h button and the button of speaker B at the same
time for about 2 seconds.
3. Press the h button and the button of speaker A at the same
time for about 2 seconds. The LED lighting will blink once every
2 seconds.
4. The two speakers will connect in about 5 to 10 seconds, and you
can begin to play music with stereo sound.
NOTE:
y With Dual Play, you can adjust the volume of both speakers at the
same time.
y To disable the Dual Play connection, press the h button and the
button (or button) at the same time for about 2 seconds.
y Dual Play is support on Android or IOS devices.
Equalizer Mode Change
PBS-C510 speakers have three types of preset Equalizer modes.
%ULHÀ\WRXFKWKH(4EXWWRQRQWKHWRSRIWKHVSHDNHU:KHQ\RXSUHVV
the EQ button, the EQ settings will be applied in the order as follows:
EQ Mode LED Blinking
Bass Boost Mode
(Low-Band Boost
, Default
)
1
Treble Boost (High-Band Boost) 2
Power Boost Mode (Full-Band Boost) 3
6
ENG
Reset the Speaker Setting
You can reset speaker settings such as the paired device list, volume
level, equalizer mode, and mood LED as well as restore settings to
default.
Press the
h
button and N button at the same time for about 5 seconds.
NOTE:
y Reset the speaker to clear the speaker memory.
y It cannot be reset while playing music.
LG Sound Sync
LG Sound Sync enables you to control some functions of this unit
by your LG TV remote control. Controllable functions are volume up,
volume down, and mute. Make sure that your TV has LG Sound Sync
logo as shown above.
1. Set up the sound output of your TV.
TV setting menu Î [Sound] Î [TV Sound output] Î [LG Sound
Sync (Wireless)]
NOTE:
y The setting method of LG Sound Sync may differ depending on the
TV. Refer to your TV manual.
2. Press the
h
button and N button at the same time for about
2 seconds.
3. When in pairing mode, select the LG TV in the available devices list
to connect the LG PBS-C510.
When Using the Product
Bluetooth
y
You can connect up to two Bluetooth devices simultaneously.
y Multi-pairing connection (Advanced Multipoint) is only available with Android™ or iOS
devices. (Multi-pairing connection may not be available with some devices due to their
VSHFL¿FDWLRQV
y If two Bluetooth devices are connected using multi-pairing, you can play and control
music by selecting one of the connected devices.
y When two mobile devices are connected to a speaker, each mobile device’s volume
operates independently of the other device’s volume.
Dual Play
y During Dual Play, you can only connect your mobile device to one of the Bluetooth
speakers (speaker A or speaker B).
y Dual Play is only available with PBS-C510 speakers for use with Android and iOS
devices. Dual Play is not available on other Music Flow series or other smart audio
products.
y Multi-pairing (Advanced Multipoint) is not available during Dual Play.
y :KHQ'XDO3OD\LVFRQQHFWHGWKHIXQFWLRQFDQQRWEHFKDQJHGZLWKRXW¿UVW
disconnecting from the paired mobile device. Once disconnected, the function can
be changed or another mobile device can be pair with the PBS-C510.
y When the speakers are in the process of connecting with Dual Play, the speakers
will not be visible to other Bluetooth-enabled mobile devices.
LG Sound Sync
y This product recognizes input signals such as Bluetooth and LG sound sync and
automatically changes the mode according to the signals.
Energy Saving Features
y If the speaker cannot connect to a Bluetooth-enabled device within 20 minutes, it will
automatically power off to save energy.
y If the speaker powers off to save energy, to power it on again you will need to press
the top of speaker twice—once to complete the powering off and a second time to
power it on.
7
ENG
Troubleshooting
Does Not Power On
y The battery is discharged. Charge the battery.
Muted or Distorted Sound
y The volume of this product or smart device may be set up to minimum. Adjust the
volume of this product or the smart device the speaker is paired with.
y If the volume of the connected device is set up to maximum, the sound may be
distorted. Reduce the volume of the connected device.
y If you use this product for purposes other than playing music, it may not work
properly or the sound quality may decrease.
Bluetooth Pairing Failed
Bluetooth pairing may not work properly depending on the types of Bluetooth devices
or environments.
y Ensure Bluetooth is on.
y Deactivate Bluetooth on the Bluetooth-enabled device you are trying to pair with, and
then reactivate Bluetooth to try to pair again.
y Remove obstacles between this product and the Bluetooth-enabled device you are
trying to pair with.
y Ensure that the device you want to pair with isn’t already paired with another
Bluetooth-enabled device. If it is, disable the unwanted connection.
LG Sound Sync Failed
y If the connection fails, check this product and your TV for their power and modes.
y If you turn off the TV and turn it on again, you will need to set up the LG sound sync
connection again.
Product Not Properly Working
y If this product works improperly, power it off and then back on again.
y If the battery has been completely discharged, Bluetooth information may be deleted.
Always maintain a charge to better ensure Bluetooth information is saved.
y When this product’s power is off, the previous settings/mode may not be saved.
Reconnect settings/mode using the instructions for this product.
y Do not use this product where temperature and humidity are too high or too low.
y Please contact LG Electronics Customer Service Center if you are still having issues
with this product.
Precautions
y Do not drop the device.
y Do not modify, repair, or disassemble.
y Do not expose directly to water, alcohol, benzene, etc., for cleaning.
y 'RQRWH[SRVHGLUHFWO\WRÀDPPDEOHV
y 'RQRWSODFHRUNHHSWKHGHYLFHQHDUÀDPPDEOHV
y Keep the device away from excessive humidity and dust.
y Do not place heavy objects on the device.
y Only charge the speaker with an original LG charger, rated current higher than 1.2A,
otherwise the product may be damaged. If you use a charger rated under 1.2A, it
may cause damage to the device or cause the device to not charge.
y &KDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\UHVSRQVLEOHIRU
compliance could void the user’s authority to operate the equipment.
y Risk of damage or explosion if incorrect battery is used.
y Dispose of used batteries according to the instructions.
y If you have an implanted medical device, consult with a doctor prior to using this
product.
8
ENG
Additional Information
Radio frequency exposure
This Bluetooth Stereo Speaker PBS-C510 is a radio transmitter and receiver. When
in operation it communicates with a Bluetooth-equipped mobile device by receiving
DQGWUDQVPLWWLQJUDGLRIUHTXHQF\5)HOHFWURPDJQHWLF¿HOGVPLFURZDYHVLQWKH
frequency range 2.4 to 2.4835 GHz. Your Bluetooth speaker is designed to operate in
compliance with the RF exposure guidelines and limits set by national authorities and
international health agencies when used with any compatible LG Electronics mobile
device.
Potentially explosive atmosphere
Power off your electronic device when in any area with a potentially explosive
atmosphere. Although this is uncommon, your electronic device could generate
VSDUNV6SDUNVLQVXFKDUHDVFRXOGFDXVHDQH[SORVLRQRU¿UHUHVXOWLQJLQERGLO\
injury or even death. Areas with a potentially explosive atmosphere are often, but not
always, clearly marked.
Battery information
A rechargeable battery has a long service life if treated properly. A new battery or one
WKDWKDVQRWEHHQXVHGIRUDORQJSHULRGRIWLPHFRXOGKDYHUHGXFHGFDSDFLW\WKH¿UVW
few times it is used. Do not expose the battery to extreme temperatures, never above
+60°C (+140°F) or below -10°C (14°F). For maximum battery capacity, use the battery
at room temperature. If the battery is used in low temperatures, the battery capacity
will be reduced. The battery can only be charged in temperatures between +10°C
(+50°F) and +45°C (+113°F). For your safety, do not remove the battery incorporated
with the product. If you need to replace the battery, take it to the nearest authorized
LG Electronics service point or dealer for assistance.
Recycling the battery in your
Bluetooth
speaker
The battery in your Bluetooth speaker must be disposed of properly and should never
be placed in municipal waste. The LG Electronics service partner who removes the
battery will dispose of it according to local regulations.
Conditions
y The warranty is valid only if the original receipt issued to the original purchaser by
the dealer, specifying the date of purchase and serial number, is presented with
the product to be repaired or replaced. LG Electronics reserves the right to refuse
warranty service if this information has been removed or changed after the original
purchase of the product from the dealer.
y If LG Electronics repairs or replaces the product, the repaired or replaced product
shall be warranted for the remaining time of the original warranty period or for ninety
(90) days from the date of repair, whichever is longer. Repair or replacement may
involve the use of functionally equivalent reconditioned units. Replaced parts or
components will become the property of LG Electronics.
y This warranty does not cover any failure of the product due to normal wear and
tear, or due to misuse, including but not limited to use in other than the normal and
customary manner, in accordance with instructions for use and maintenance of the
product. Nor does this warranty cover any failure of the product due to accident,
PRGL¿FDWLRQRUDGMXVWPHQWDFWVRI*RGRUGDPDJHUHVXOWLQJIURPOLTXLG
y This warranty does not cover product failures due to improper repair installations,
PRGL¿FDWLRQVRUVHUYLFHSHUIRUPHGE\DQRQ/*(OHFWURQLFVDXWKRUL]HGSHUVRQ
Tampering with any of the seals on the product will void the warranty.
y THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR ORAL,
OTHER THAN THIS PRINTING INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY.
IN NO EVENT SHALL LG ELECTRONICS OR ITS VENDORS BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER,
INCLUDING BUT NOT LIMITED TO LOST PROFITS OR COMMERCIAL LOSS, TO
THE FULL EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.
y Some countries/states do not allow the exclusion or limitation of incidental or
consequential damages, or limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to you. The warranty provided
does not affect the consumer’s statutory rights under applicable national legislation
in force, nor the consumer’s rights against the dealer arising from their sales/
purchase contract.
Limited Warranty
Subject to the conditions of this Limited Warranty, LG Electronics warrants this product
to be free from defects in design, material and workmanship at the time of its original
purchase by a consumer, and for a subsequent period of one (1) year. Should
your product need warranty service, please return it to the dealer from whom it
was purchased or contact your local LG Electronics contact center to get further
information.
9
ENG
Important Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
7KLVOLJKWQLQJÀDVKZLWKDUURZKHDGV\PEROZLWKLQDQHTXLODWHUDOWULDQJOH
is intended to alert the user to the presence of uninsulated dangerous
YROWDJHZLWKLQWKHSURGXFW¶VHQFORVXUHWKDWPD\EHRIVXI¿FLHQW
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.
WARNING:
y 7RSUHYHQW¿UHRUHOHFWULFVKRFNKD]DUGGRQRWH[SRVHWKLVSURGXFWWRUDLQRU
moisture.
y 7KHEDWWHU\SDFNVKDOOQRWEHH[SRVHGWRH[FHVVLYHKHDWVXFKDVVXQVKLQH¿UHRU
the like.
y 'RQRWLQVWDOOWKLVHTXLSPHQWLQDFRQ¿QHGVSDFHVXFKDVDERRNFDVHRUVLPLODUXQLW
y This unit contains magnets which can be harmful to some kind of object
(Ex: Magnetic card, Pacemaker etc.).
CAUTION:
y Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions. Slots and openings in the cabinet are provided for ventilation and to
ensure reliable operation of the product and to protect it from over heating. The
openings shall be never be blocked by placing the product on a bed, sofa, rug or
other similar surface. This product shall not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
y The apparatus should not be exposed to water (dripping or splashing) and no objects
¿OOHGZLWKOLTXLGVVXFKDVYDVHVVKRXOGEHSODFHGRQWKHDSSDUDWXV
y 1RQDNHGÀDPHVRXUFHVVXFKDVOLJKWHGFDQGOHVVKRXOGEHSODFHGRQWKH
apparatus.
y Internal lithium battery in the unit should not be replaced by user because of danger
of explosion if battery is incorrectly replaced, and must be replaced with the same
type battery by expert.
y Only use the AC adapter supplied by LGE , Rated current 1.2A. Do not use a power
supply from another device or another manufacturer. Using any other power cable or
power supply may cause damage to the device and void your warranty.
y 7RDYRLG¿UHRUHOHFWULFVKRFNGRQRWRSHQWKHXQLW&RQWDFWWRTXDOL¿HGSHUVRQQHO
only.
y Do not leave the unit in a place near the heating appliances or subject to direct
sunlight, moisture, or mechanical shock.
y To clean the unit, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft
cloth lightly moistened with a mild detergent solution. Do not use strong solvents
such as alcohol, benzine, or thinner, as these might damage the surface of the unit.
y Do not use volatile liquids such as insecticide spray near the unit. Wiping with strong
pressure may damage the surface. Do not leave rubber or plastic products in contact
with the unit for a long period of time.
y Do not place the unit over the vehicle’s air bag. When the air bag deploys, it may
UHVXOWLQLQMXU\%HIRUHXVLQJLQWKHFDU¿[WKHXQLW
y Do not use the hands-free function while driving a car.
y Do not leave the unit on an unstable place such as high shelves. It may fall down
because of the vibration of the sound.
y Do not use high voltage products around this product (ex. Electrical swatter). This
product may malfunction due to electrical shock.
CAUTION when using this product in environments of low humidity
y It may cause static electricity in environments of low humidity.
y It is recommended to use this product after touching any metal object which
conducts electricity.
CAUTION concerning the power cord
y Most appliances recommend they be placed upon a dedicated circuit; That is, a
single outlet circuit which powers only that appliance and has no additional outlets or
EUDQFKFLUFXLWV&KHFNWKHVSHFL¿FDWLRQSDJHRIWKLVPDQXDOWREHFHUWDLQ
y Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or damaged or cracked wire insulation are
GDQJHURXV$Q\RIWKHVHFRQGLWLRQVFRXOGUHVXOWLQHOHFWULFVKRFNRU¿UH
y Periodically examine the cord of your appliance, and if its appearance indicates
damage or deterioration, unplug it, discontinue use of the appliance, and have
the cord replaced with an exact replacement part by an authorized service center.
Protect the power cord from physical or mechanical abuse, such as being twisted,
kinked, pinched, closed in a door, or walked upon.
y Pay particular attention to plugs, wall outlets, and the point where the cord exits the
appliance.
y To disconnect power from the mains, pull out the mains cord plug. When installing
the product, ensure that the plug is easily accessible.
y This device is equipped with a portable battery or accumulator.
y Replace the battery pack only with a genuine replacement battery pack from LG or
an authorized LG dealer. LG cannot warrant the safety and compatibility or assure
the operability of batteries from other manufacturers for use in operating this product.
Keep battery pack clean and dry.
y The battery needs to be charged before use.
y Always use the correct LG charger, rated current higher than 1.2A, and refer to the
manufacturer’s instructions or equipment manual for proper charging instructions.
y To prevent contamination of the environment and bring on possible threat to human
and animal health, the old battery or the battery put it in the appropriate container at
designated collection points.
10
ENG
y Do not dispose of batteries or battery together with other waste. It is recommended
that you use local, free reimbursement systems batteries and accumulators.
y 7KHEDWWHU\VKDOOQRWEHH[SRVHGWRH[FHVVLYHKHDWVXFKDVVXQVKLQH¿UHRUWKHOLNH
NOTICE:)RUVDIHW\LQIRUPDWLRQLQFOXGLQJSURGXFWLGHQWL¿FDWLRQDQGVXSSO\UDWLQJV
please refer to the main label on the bottom of the apparatus.
Avoiding hearing damage
Permanent hearing loss may occur if you use your speaker at a high volume.
Set the volume to a safe level. Over time you can become accustomed to a higher
volume that may sound normal but can be damaging to your hearing.
,I\RXH[SHULHQFHULQJLQJLQ\RXUHDUVRUPXIÀHGVSHHFKUHGXFHWKHVRXQGYROXPH
and have your hearing checked. The louder the volume, the less time is required
before your hearing could be affected.
Hearing experts suggest that to protect your hearing:
/LPLWWKHDPRXQWRIWLPH\RXXVHWKHVSHDNHUDWKLJKYROXPH
$YRLGLQFUHDVLQJWKHYROXPHWREORFNRXWQRLV\VXUURXQGLQJV
Using speakers safely
%HFDUHIXODQGDWWHQWLYHZKLOHGULYLQJ6WRSXVLQJWKLVGHYLFHLI\RX¿QGLWGLVUXSWLYH
or distracting while operating any type of vehicle or performing any other activity that
requires your full attention.
Part 15.19 statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Part15.21 statement
&KDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHPDQXIDFWXUHURUSDUW\
responsible) for compliance could void the user’s authority to operate the equipment.
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference or television reception, which can be
determined by powering the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
RF Exposure
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
IMPORTANT NOTE:
To comply with the FCC RF exposure compliance requirements, no change to the
antenna or the device is permitted. Any change to the antenna or the device could
result in the device exceeding the RF exposure requirements and void user’s authority
to operate the device.
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
FCC ID: ZNFPBSC510
11
3URGXFW6SHFL¿FDWLRQV
Power
Power - 5 V / 1.2 A (AC adapter)
- Built-in rechargeable battery
Power consumption 2 W (typical volume)
Size ĭ[PP
Weight 580 g
Working temperature 5°C – 35°C
Working humidity 5% – 60%
External port Micro USB port for battery charging
Communication Bluetooth
Amp :ȍN+]:ȍN+]
- THD: Within 10%
Speaker - Type: Built-in type
,PSHGDQFH:RRIHUȍIXOOUDQJHȍ
- Rated power input: 12 W
Battery
- Battery capacity: 5200 mAh
- Operating time: Approx. 20 hours
(Based on 30% volume, 1 kHz signal signal with a fully
charged battery)
- Charging time: Less than 5.5 hours. The operating time
can be varied depending on the conditions of the battery
or operation.
Wireless Bluetooth Speaker
Company name LG Electronics Inc.
Equipment name
(model name) 6SHFL¿FORZSRZHUZLUHOHVVGHYLFH3%6&
Manufacturer /
Manufacturing country LG Electronics Inc. / Korea
Bluetooth version 6SHDNHU$'3SUR¿OHV
y 3URGXFWGHVLJQVDQGVSHFL¿FDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWSULRUQRWLFH
y As this wireless device may cause electromagnetic interference, safety or medical
services will not be provided.
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed unit and its enclosed
accessories will be free from defects in material and workmanship, according to
the following terms and conditions:
(1) The limited warranty for the product extends for TWELVE (12) MONTHS
beginning on the date of purchase of the product with valid proof of purchase,
or absent valid proof of purchase, FIFTEEN (15) MONTHS from date of
manufacture as determined by the unit’s manufacture date code.
(2) The limited warranty extends only to the original purchaser of the product and
is not assignable or transferable to any subsequent purchaser/end user.
(3) This warranty is good only to the original purchaser of the product during
the warranty period as long as it is in the U.S, including Alaska, Hawaii, U.S.
Territories and Canada.
(4) The external housing and cosmetic parts shall be free of defects at the time
of shipment and, therefore, shall not be covered under these limited warranty
terms.
(5) Upon request from LG, the consumer must provide information to reasonably
prove the date of purchase.
(6) The customer shall bear the cost of shipping the product to the Customer
Service Department of LG. LG shall bear the cost of shipping the product back
to the consumer after the completion of service under this limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVERS:
(1) Defects or damages resulting from use of the product in other than its normal
and customary manner.
(2) Defects or damages from abnormal use, abnormal conditions, improper
storage, exposure to moisture or dampness, unauthorized modi¿ cations,
unauthorized connections, unauthorized repair, misuse, neglect, abuse,
accident, alteration, improper installation, or other acts which are not the
fault of LG, including damage caused by shipping, blown fuses, spills of food
or liquid.
(3) Breakage or damage to antennas unless caused directly by defects in material
or workmanship.
(4) Alleged product defects or malfunction of which the Customer Service
Department at LG was not noti¿ ed by consumer during the applicable limited
warranty period.
LIMITED WARRANTY STATEMENT
(5) Products which have had the serial number removed or made illegible.
(6) This limited warranty is in lieu of all other warranties, express or implied either
in fact or by operations of law, statutory or otherwise, including, but not limited
to any implied warranty of marketability or ¿ tness for a particular use.
(7) Damage resulting from use of non-LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are scratched or
damaged due to normal customer use.
(9) Products operated outside published maximum ratings.
(10) Products used or obtained in a rental program.
(11) Consumables (such as fuses).
3. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE DURATION OF
ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MARKETABILITY OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY
HEREIN. LG SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE
PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT
OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO
USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY
OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
APPLICABLE TO THIS PRODUCT.
Some states do not allow the exclusive limitation of incidental or consequential
damages or limitations on how long an implied warranty lasts; so these limitations
or exclusions may not apply to you. This warranty gives you speci¿ c legal rights
and you may also have other rights which vary from state to state.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call or fax to the following telephone numbers
from anywhere in the continental United States:
Tel. 1-800-793-8896 or Fax. 1-800-448-4026
Or visit http://us.lgservice.com. Correspondence may also be mailed to:
LG Electronics Service- Mobile Handsets
P.O. Box 240007, Huntsville, AL 35824
DO NOT RETURN YOUR PRODUCT TO THE ABOVE
ADDRESS. Please call or write for the location of the LG authorized service
center nearest you and for the procedures for obtaining warranty
claims.

Navigation menu
