LG Electronics USA PH4 Portable Bluetooth Speaker User Manual
LG Electronics USA Portable Bluetooth Speaker Users Manual
User Manual
2
Power Power On / Off ...................... Hold
Bluetooth
To pair your mobile device, select LG PH4 (xx) from
device list.
When successfully Paired, Bluetooth LED will turn on.
Playback
Controls
Play / Pause ......................... Press
Forward Skip ........................ Press X2
Backward Skip ...................... Press X3
Handsfree Receive / Disconnect ................ Press
Mood LED
light On / Blink / Off .......................Press
Bass Standard / Power Boost .............
Press
AC Adapter
(Not supplied)
White : Full Charged
Red : Charging
Orange : Low Battery
Portable input
ENGLISH
3
Specification
Power Supply:
- 5 V 0 1.8 A (AC Adapter)
- Built-in rechargeable battery
Power consumption:
-6 W
Dimensions (W x H x D):
Approx. 66 mm X 175 mm X 80 mm
Net Weight: Approx. 0.53 kg
Operating Temperature: 5 °C to 35 °C
Operating Humidity: 5 % to 60 %
Splash-proof : IPX4
(Protected rain or splashing water.)
Battery Life:
Approx. 10 hours
(
Varies by volume level and audio content.)
y
change without notice.
Important Notice
yFully charge the device before using for
yIt is recommended that you use the
5 V AC adapter (more than 1.8 A) with
this unit.
yPress and hold the button for more
than 1 second to turn on or off the unit.
yBluetooth connection using the TV, PC or
dongle is not supported.
yResetting
In case that the unit freezes due to
malfunction, press the RESET hole using
For more information, download the online owner’s manual. http://www.lg.com
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that
this device does not cause harmful interference (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation.If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC ID: BEJ-PH4
