LG Electronics USA PJ2 PORTABLE BLUETOOTH SPEAKER User Manual
LG Electronics USA PORTABLE BLUETOOTH SPEAKER
User Manual
SIMPLE MANUAL
PORTABLE BLUETOOTH
SPEAKER
MODELS
PJ2/PJ2B
2
AC Adapter
(Not supplied)
Green Off : Full Charged
Red : Charging
Red (Blink) : Low Battery
Portable input
RESET hole
ENGLISH
Specification
Power Supply:
- 5 V 0 1.8 A (AC Adapter)
- Built-in rechargeable battery
Power consumption:
- 6 W
Dimensions (W x H x D):
Approx. 81.5 mm X 89.2 mm X 81.5 mm
Operating Temperature: 5 °C to 35 °C
Operating Humidity: 5 % to 60 %
Splash-proof : IPX4
(Protected rain or splashing water.)
Battery Life:
Approx. 5 hours
(
Varies by volume level and audio content.)
yDesign and specications are subject to
change without notice.
For more information, download the online owner’s manual. http://www.lg.com
Power Power On / Off ......................... Press
Bluetooth
To pair your mobile device, select LG PJs (xx) from device list.
(Bluetooth LED: Blink ON)
Ready to pair another device ............ H o l d
Playback
Controls
Play / Pause ............................ Press
Forward Skip ........................... Press X 2
Backward Skip ......................... Press X 3
Handsfree Receive / Disconnect ................... Press
3
Specification
Power Supply:
- 5 V 0 1.8 A (AC Adapter)
- Built-in rechargeable battery
Power consumption:
- 6 W
Dimensions (W x H x D):
Approx. 81.5 mm X 89.2 mm X 81.5 mm
Operating Temperature: 5 °C to 35 °C
Operating Humidity: 5 % to 60 %
Splash-proof : IPX4
(Protected rain or splashing water.)
Battery Life:
Approx. 5 hours
(
Varies by volume level and audio content.)
yDesign and specications are subject to
change without notice.
Important Notice
yFully charge the device before using for
the rst time.
yIt is recommended that you use the
5 V AC adapter (more than 1.8 A) with
this unit.
yBluetooth connection using the TV, PC or
dongle is not supported.
yResetting
In case that the unit freezes due to
malfunction, press the RESET hole using
an object like a thin pin.
For more information, download the online owner’s manual. http://www.lg.com
Power Power On / Off ......................... Press
Bluetooth
To pair your mobile device, select LG PJs (xx) from device list.
(Bluetooth LED: Blink ON)
Ready to pair another device ............ H o l d
Playback
Controls
Play / Pause ............................ Press
Forward Skip ........................... Press X 2
Backward Skip ......................... Press X 3
Handsfree Receive / Disconnect ................... Press
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by
the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio
or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit
different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV
technician for help.
The device has been evaluated to meet general RF exposu
re requirement. The device can be used in portable
exposure condition without restriction.
FCC ID: BEJ-PJ2
