Users Manual

User Guide MFLXXXXXXX (1.0)
This booklet is made from 98% post-consumer recycled paper.
This booklet is printed with soy ink. Printed in Mexico
User Guide
Guía del
Usuario
US991
&RS\ULJKW/*(OHFWURQLFV,QF$OOULJKWVUHVHUYHG
/*DQGWKH/*ORJRDUHUHJLVWHUHGWUDGHPDUNVRI/*&RUS
$OORWKHUWUDGHPDUNVDUHWKHSURSHUW\RIWKHLUUHVSHFWLYH
RZQHUV
1
Important Customer Information
Before you begin
Before reading this user guide and getting started, please review the
separate Product Safety and Warranty Information guide for important
product safety and warranty information about your device.
2
Important Customer Information...............................................1
Table of Contents .......................................................................2
The Basics ...................................................................................5
Phone Overview .................................................................................................... 5
Help ....................................................................................................................... 8
Setting Up Your Phone ........................................................................................ 8
Removing the Battery and SIM Card ................................................................10
Inserting and Removing a Memory Card ..........................................................12
Charging the Phone ............................................................................................13
Optimizing Battery Life ......................................................................................14
Turning the Phone On and Off ..........................................................................16
Phone’s Status Icons ..........................................................................................21
Getting to Know the Home Screen ..................................................................23
Touchscreen ........................................................................................................ 29
Hardware key control mode .............................................................................36
Apps: How to View, Open, and Switch ............................................................. 37
Working with Menus ..........................................................................................43
Managing Notifications .....................................................................................44
Searching Your Phone and the Web ................................................................. 47
Setting your Lock screen ...................................................................................50
Guest Mode ........................................................................................................55
Customizing the Home Screen .........................................................................56
Connecting to Networks and Devices ................................... 58
Connecting to Mobile Networks .......................................................................58
Connecting to Wi-Fi Networks ......................................................................... 59
USB Connection ..................................................................................................61
SmartShare .......................................................................................................... 61
Calls .......................................................................................... 63
Placing and Ending Calls ..................................................................................63
Answering or Rejecting Calls ............................................................................66
Working With the Recent Tab ...........................................................................68
Calling Your Contacts......................................................................................... 70
Options During a Call .........................................................................................71
Managing Multiple Calls .................................................................................... 72
Listening to Your Voicemail ............................................................................... 73
Table of Contents
3
Table of Contents
Web ........................................................................................... 75
Chrome ................................................................................................................ 75
Communication ....................................................................... 87
Contacts .............................................................................................................. 87
Messaging ........................................................................................................... 94
Email ................................................................................................................... 101
Voicemail ............................................................................................................107
Gmail ................................................................................................................. 108
Hangouts ............................................................................................................ 115
Entertainment ..........................................................................118
Camera and Video ............................................................................................. 118
Gallery ................................................................................................................127
Play Store .......................................................................................................... 130
Music ................................................................................................................. 132
YouTube™ ...........................................................................................................137
Tools ......................................................................................... 139
Dual window ...................................................................................................... 139
QuickMemo+ .................................................................................................... 140
QSlide ................................................................................................................ 142
QuickRemote .................................................................................................... 144
Calendar .............................................................................................................147
Calculator .......................................................................................................... 152
Clock .................................................................................................................. 153
Maps .................................................................................................................. 158
Weather ............................................................................................................. 159
Voice Mate ......................................................................................................... 161
Voice Command ............................................................................................... 162
Voice Search ..................................................................................................... 162
Voice Recorder ................................................................................................. 162
File Manager ..................................................................................................... 164
Tasks .................................................................................................................. 166
4Table of Contents
Settings ................................................................................... 167
Safety .......................................................................................198
Consumer Information About Radio Frequency Emissions ......................... 201
Consumer Information on SAR .................................................................... 205
FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices 206
Caution:
Avoid potential hearing loss. .......................................................................... 208
TIA Safety Information ................................................................................... 209
Safety Information ........................................................................................... 213
FDA Consumer Update ....................................................................................217
Laser Safety Statement .................................................................................. 229
Specifications ........................................................................230
FAQ ..........................................................................................231
LIMITED WARRANTY STATEMENT ...................................238
Index .......................................................................................242
5
The Basics
Phone Overview
Front View
Proximity
Sensor
QuickTap Bar
Back Key
Home Key
Recent Apps Key
Home Screen
Earpiece
Front Camera
Notification
LED
NOTES All screen shots in this guide are simulated. Actual displays may vary.
Instructions to perform tasks in this guide are based on the default settings and may
change depending on the mode and software version on your phone.
1. Proximity Sensor Senses proximity toward other objects (such as your
head) so that tap commands are not accidentally activated (during a call
or when carried inside a pocket.
It also employs an ambient sensor which measures the surrounding light
and adjusts the LCD brightness to provide a vivid screen.
NOTE Don't block the sensor or near the sensor to avoid problems with the touchscreen.
2. Notification LED Flashes to alert you for notifications (e.g., incoming
call, new text message, screen unlock, etc.).
3. Front Camera Use to take pictures and record videos of yourself. You
can also use this for video chatting. Keep it clean for optimal
performance.
4. QuickTap Bar Provides icons for quick, one-touch access to the
Applications screen and the apps you use most often.
NOTE You can change the icons in the QuickTap bar to suit your needs. To reposition, add, or
remove an icon, see page 24.
6The Basics
5. Back Key Tap this Touch Key (in the Touch Keys bar) to return to the
previous screen or close pop-up items (such as menus, dialog boxes,
and the on-screen keyboard). Touch and hold it to access the Dual
window function which allows you to use two apps at the same time.
6. Home Key Tap this Touch Key (in the Touch Keys bar) to return to the
Home screen (or your default Home screen panel from any of the Home
screen extension panels). Touch and hold it to access Google Now.
7. Recent Apps Key Tap this Touch Key (in the Touch Keys bar) to display
recently used apps. Touch and hold this key to open an Options menu
with options that affect the current screen or app. This only applies
when available, depending on the screen or app.
8. Home Screen Displays all of the items needed to operate your phone
including icons for app access, widgets, and the Status Bar (with status
icons) allowing simple touch access to all of its functions and features.
WARNING! Placing a heavy object on the phone or sitting on it can damage the LCD and
touchscreen functions.
9. Earpiece Lets you hear callers and automated prompts.
Rear View
Rear Camera
LED Flash
Volume Keys
Power/Lock Key
Laser Detection
Auto-focus
NFC Touch Point
Speaker
10. Rear Camera Use to take photos and record videos. Keep it clean for
optimal performance.
7
The Basics
11. Laser Detection Auto-focus Detects the distance between the rear
camera lens and nearby objects using laser technology. This feature
helps the camera to focus quickly and accurately at short or long
distances.
NOTE Don't cover the Proximity Sensor and Laser Detection Auto-focus with a protection film,
pouch, or protection case not authorized by LG as they may cause the device to
malfunction.
12. Power/Lock Key Press to turn off the screen backlight and lock the
screen, or turn the screen backlight back on. Press and hold to turn the
phone on/off, restart it, activate/deactivate Airplane mode, and change
the sound settings.
13. NFC Touch Point Tap the back of your phone to an NFC tag or another
NFC compatible device in this location to transfer data between them.
14. Speaker Use to listen to audio (e.g., music, videos, sound clips,
speakerphone, etc.) from the rear speaker instead of the earpiece.
15. Volume Keys Press to adjust the ringer, the media volumes, or the
in-call volume during a call.
TIPS With the screen backlight off (asleep), you can press and hold the Volume Down Key
to activate the Camera app.
With the screen backlight off (asleep), you can press and hold the Volume Up Key
to access the QuickMemo+ app.
16. LED Flash Brightens up the captured image or recorded video when
you turn on the flash.
Top and Bottom View
USB/Charger
Port
Microphone
3.5mm
Headset Jack
17. 3.5mm Headset Jack Allows you to plug in an optional headset for
convenient, hands-free conversations. You can also plug in headphones
to listen to music.
8The Basics
18. Microphone Transmits your voice to the other caller. It's also used for
voice-activated functions.
19. USB/Charger Port Allows you to connect the phone and the USB Cable
for use with the Charger Adapter, or other compatible accessories.
NOTE You may purchase a separate fast data cable from LG to enjoy higher data transfer speed
with compatible devices (e.g., laptop).
Help
The Help app allows you to quickly and conveniently view information
about your phone, including how-to videos, Icon glossary, etc.
To access Help, from the Home screen, tap the Apps icon >
the Apps
tab (if necessary) > Help .
Setting Up Your Phone
Step 1. Remove the Back Cover
Insert your fingernail into the slot located on the lower left of the back
cover and lift the cover up gently.
9
The Basics
Step 2. Insert the Battery
Insert the battery in its compartment, making sure to align the gold
contacts. Press down gently to secure the battery.
Step 3. Replace the Back Cover
Place the cover over the back of the phone, then press down along the
edges to secure the cover.
Step 4. Charge the Phone
Before turning on your phone, fully charge the battery. Be sure to use the
USB Cable and Charger Adapter that came with your phone. Correctly
orient the USB Cable plug before inserting it in the USB/Charger Port to
avoid damage to your phone. See Charging the phone on pages 13 and 14
for more information.
10 The Basics
NOTE It’s important to fully charge the battery before initial use of the phone to maximize the
battery's lifetime.
Removing the Battery and SIM Card
Removing the battery
1.
Insert your fingernail into the slot located on the lower left of the back cover
and lift the cover up gently.
2. Use the fingertip cutout at the bottom of the battery compartment to lift the
battery out.
11
The Basics
SIM card/SD card slot location
SIM Slot
MicroSD Slot
Removing the SIM card
The SIM card is pre-installed in your smartphone. If you need to replace
your SIM card, refer to the following instructions.
1. Turn the phone off, then remove the back cover and the battery (as
demonstrated in the previous instructions).
2. Locate the slot for the SIM card (the lower of the two slots above the
upper-right corner of the battery compartment) and gently slide the SIM
card out to remove it.
CAUTION If a microSD card is inserted in your phone, please remove it from the upper slot
before trying to remove the SIM card.
12 The Basics
Inserting and Removing a Memory Card
Inserting a microSD card
1. Remove the back cover (as demonstrated in the
previous instructions) and locate the dual slot
just above the upper-right corner of the battery
compartment. (microSD is inscribed near the
slot opening.)
2. Position the microSD card (sold separately) with
the label side facing up and the gold contacts
toward the slot, then carefully slide it into the
upper slot until it's secured in place.
NOTE The microSD card can be easily damaged by improper operation. Please be careful when
inserting, removing, or handling it.
To remove the microSD card
1. Unmount the microSD card.
From the Home screen, touch and hold the
Recent Apps Key (in the Touch Keys bar)
> Settings > Storage > Unmount SD card.
2. Remove the back cover and locate the microSD
card slot (as demonstrated in the previous
instructions).
3. Carefully pull the microSD card out to remove it.
To unmount the microSD card
It’s important to unmount the microSD card prior to removing it from the
phone to avoid damage to it or the data saved on the card.
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar).
2. Tap Settings > Storage.
3. Tap Unmount SD card.
13
The Basics
Charging the Phone
Your phone comes with a USB Cable and a Charger Adapter which connect
together to charge your phone. Correctly orient the USB Cable plug before
inserting it in the USB/Charger Port to avoid damaging your phone.
NOTE Please only use an approved charging accessory to charge your LG phone. Improper
handling of the USB/Charger Port, as well as the use of an incompatible charger, may
cause damage to your phone and void the warranty.
1. Correctly orient the USB Cable with the Charger Adapter, and connect
them. As shown below, both the USB logo on the USB Cable and the LG
logo on the adapter will face toward you.
USB Cable Charger Adapter
2. The USB/Charger Port is located at the bottom of the phone. Correctly
orient the cable's plug with the port before plugging it in. As shown
below, the USB logo on the cable will face upward.
3. Plug the Charger Adapter into an electrical outlet to begin charging.
Charging with the USB Cable
NOTE
Make sure to correctly orient the cable's
plug with the port before plugging it in.
When the phone is facing upward, the USB
logo on the cable will also face upward.
USB Cable
You can use your computer to charge your phone. To be able to charge with
the USB Cable, you need to have the necessary USB drivers installed on
your PC first. Connect one end of the USB Cable to the USB/Charger Port
on your phone (as shown above) and connect the other end to a USB port
14 The Basics
on your PC. It’s best to use the rear USB port when connecting to a desktop
PC. The USB hub should be powered by an external power source.
NOTE You may experience a slower charging rate when charging from your computer.
Optimizing Battery Life
You can extend your battery’s life between charges by turning off features
that run in the background. You can also monitor how apps and system
resources consume battery power.
Tips to extend the life of your battery
Reduce the screen brightness and set a shorter screen timeout.
Turn off radio communications (such as Wi-Fi, Bluetooth, GPS, etc.) that
you're not actively using. (Note that the GPS receiver is only turned on
when you’re using an app that makes use of it.)
Turn off automatic syncing for Gmail, Calendar, Contacts, and other apps
if you don’t need it.
Use the Battery saver feature (accessed in the Settings menu) to control
data activity, Wi-Fi connection, Bluetooth connection, and power used for
the device such as screen brightness and notification light.
NOTES Allowing other devices to use your device's hotspot connection will drain your battery
more quickly.
If you accidently press the Power/Lock Key while the phone is in your pocket, the
proximity sensor prevents the screen from turning on in order to save battery power.
To check the battery charge level
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Battery.
The battery level (as a percentage of fully charged) and the battery status
(Charging or Discharging) is displayed at the top of the screen.
Checkmark the Battery percentage on status bar checkbox to display
the percentage of remaining battery charge on the Status Bar next to the
battery icon.
Tap Battery saver to view and/or modify your Battery saver settings.
15
The Basics
To monitor and control what uses the battery
The Battery use screen allows you to see which apps are consuming the
most battery power. Information on this screen allows you to identify
downloaded apps you may want to turn off when not being used, so you
can get the most out of your battery power.
From the Home screen,
touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings
> About phone > Battery > Battery use.
OR
From the Home screen, touch and hold the
Recent Apps Key (in the
Touch Keys bar) > Settings
> Battery, then tap the Battery icon (at the
top of the screen).
The top of the Battery use screen displays a usage graph and below it,
battery usage times. It lists all of the apps or services using battery power
from the greatest amount of energy used to the least amount.
Tap an app or service in the Battery use screen to see the details about
its power consumption, including either how long since last connected
to a power source or how long you were last running on battery power.
Different apps or services offer different kinds of information, and they
may even include options to modify the settings so you can reduce
power consumption by that app (or stop running the app).
Battery saver mode
Battery saver mode changes certain settings to conserve battery power
until you can recharge your phone. If you turn Battery saver mode On, it
will automatically activate when the battery charge level drops to the level
you set. If Battery saver mode is off, you’ll be prompted to turn on Battery
saver mode when the battery reaches low levels.
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings
> Battery >
Battery saver.
From the Battery saver screen, tap Turn Battery saver on (at the top of
the screen) to set the phone to activate Battery saver mode immediately,
when the charge drops to 10%, 20%, 30%, or 50%. If you turn off
16 The Basics
Battery saver mode, when the battery charge becomes low, a
notification prompts you to turn it on.
From the Battery saver screen, checkmark the saving items you want,
including Auto-sync, Wi-Fi, Bluetooth, Vibrate on tap, Brightness, Screen
timeout, and Notification light.
After you modify the Battery saver settings to your preferences, tap the
switch (at the upper-right corner of the screen) to toggle it On (blue)
or Off (gray).
Turning the Phone On and Off
Turning the phone on
Press and hold the Power/Lock Key on the back of the phone for a
couple of seconds until the screen turns on.
Turning the phone off
1. Press and hold the Power/Lock Key on the back of the phone until
the Phone options menu appears.
2. Tap Power off in the Phone options menu.
3. Tap OK to confirm that you want to turn off the phone.
Turning the screen on using the Knock Code feature
If your Lock screen unlock sequence is set to a Knock Code, tap your
Knock Code on the darkened screen to automatically turn the screen on
and unlock it at the same time.
TIP When the screen is in time-out and a Knock Code is set, pressing the Power/Lock Key
(on the back of the phone) displays the Lock screen (e.g., to check the time). You can
tap your Knock Code to unlock the screen or turn the screen back off by pressing the
Power/Lock Key again (or double-tap the Status Bar).
NOTES Entering the incorrect Knock Code 10 times will perform a factory reset on your device
and you will lose all of your information. You will be warned on the 9th failed attempt.
Use a fingertip instead of a fingernail to tap the screen to turn the screen on.
If Knock Code isn't your unlock sequence, the Knock Code feature isn't activated, and
you can use the KnockON feature by double-tapping the screen.
17
The Basics
Turning the screen on using the KnockON feature
The KnockON feature allows you to double-tap the screen to easily turn the
screen on or off.
Quickly double-tap the center of the dark touchscreen to turn the screen
on.
Quickly double-tap the Status Bar, an empty area on the Home screen,
or the Lock screen to turn the screen off.
NOTES When turning the screen on (using the KnockON feature or your Knock Code), avoid
covering the proximity sensor. Doing so will not allow you to turn the screen on.
While Knock Code is in use, double-tapping the screen while it's off will turn it on
and display the Knock Code grid to allow you to enter your Knock Code.
Setting up the Knock Code feature
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Lock screen settings.
2. Tap Select screen lock > Knock Code.
3. Tap the squares in a pattern (from 3 to 8 taps) to set your Knock Code,
then tap Done, enter it again, then Confirm.
18 The Basics
To unlock the phone
If you don’t use the phone for a while, the screen and backlight will turn off
to conserve battery power. To unlock the phone’s default Lock screen:
1. Turn the screen on.
Press the Power/Lock Key (on the back of the phone). The default
Lock screen will appear.
NOTE Avoid covering the proximity sensor when turning the screen on. Doing so, immediately
turns the screen off.
OR
Quickly double-tap the center of the screen (KnockON).
NOTE If you set up a Knock Code in the Screen lock setting, you can tap your sequence to turn
the screen on and unlock the screen at the same time.
2. From the center of the screen, swipe in any direction
to unlock it.
To use a shortcut, swipe the shortcut icon (at the
bottom of the screen) in any direction. The screen
will unlock and launch the app.
NOTE The default Lock screen simply locks the screen to prevent
unintentional actions. For more security to guard against
unauthorized use, you can set an unlock requirement (such as
a knock code, pattern, PIN, password, or face recognition) that
will need to be entered to unlock it.
To turn the phone sounds off
If you’re in a place where your phone sounds may disturb others, you can
quickly silence your phone from the Home screen.
From the Home screen, press and hold the Power/Lock Key (on
the back of the phone), then tap the Silent mode icon .
NOTE Only one mode can be selected at a time. The currently activated mode (Silent ,
Vibration , or Sounds ) is underlined in blue. Tap any of the sounds mode icons to
switch to that mode.
OR
19
The Basics
Press the Volume Down Key on the back of the phone (when the
screen is not in time-out) until vibration is set, then press it again to turn
all sounds off.
OR
Open the Notifications panel and tap the Sound icon until is displayed.
Your Google Account
You must sign into a Google Account to use Gmail, Hangouts, Google
Calendar, and other Google apps; to download apps from Play Store; to
back up your settings to Google servers; and to take advantage of other
Google services on your phone.
IMPORTANT
If you don’t sign into a Google Account during setup, you're prompted to sign in or to
create a Google Account the first time you start an app that requires one, such as Gmail
or Play Store.
When you sign in, you’re prompted to enter your username and password using the
on-screen keyboard.
After you sign in, your contacts, Gmail messages, Calendar events, and other
information from these apps and services on the web are synchronized with your
phone.
If you have an enterprise account through your company or other organization, your IT
department may have special instructions on how to sign in to that account.
Setting up your Google Account
If you use Setup Wizard to set up your Google Account, it guides you
through the following steps.
1. At the Google Account setup screen, tap Ye s if you already have a
Google Account, or tap No if you want to create a new account.
2. Enter your username and password (or any other necessary information
if creating an account), then tap the Continue icon (at the lower-right
corner of the screen). Tap OK to agree to your Google Account terms
and conditions.
NOTE Tap the Back Key (in the Touch Keys bar) to close the on-screen keyboard.
20 The Basics
3. On the Google Services screen, checkmark the services you want to use
(Backup & Restore, Location, and Communication), then tap the
Continue icon (at the lower-right corner of the screen).
Your Gmail, Google Contacts, and Google Calendar events will all be
synchronized with your phone automatically.
NOTE This is automatic for the first Google Account you add. When adding additional Google
Accounts, you have to select which options to synchronize.
4. Set up your payment information by tapping Add credit or debit card,
Enable Verizon Wireless billing, and Redeem. After entering all of the
information you want to include, tap Continue or Not Now (at the
bottom of the screen).
5. Confirm your setup checklist choices on the Setup Wizard Summary
screen, then tap Done.
You can use the area below to record your Google Account information for
future reference.
Username:___________________________________________@gmail.com
Password:____________________________________________
21
The Basics
Phones Status Icons
The Status Bar appears at the top of every screen. It displays icons
indicating that you’ve received notifications (on the left) and icons indicating
the phone’s status (on the right), along with the current time.
Notification icons Status icons
If you have more notifications than can fit in the Status Bar, the More
notifications icon is displayed as an indicator to open the Notifications
panel to view them all.
The following icons may appear in the Status Bar.
Call icons
In call Missed call
Speakerphone is on Microphone is muted
Sound icons
Silent mode is activated Vibrate mode is activated
Music is playing
Network icons
3G connection 3G in use
4G LTE connection 4G LTE in use
Wi-Fi connection Signal strength
No signal Roaming
Network Extender No SIM card
Unknown SIM card Airplane mode is activated
GPS is on App update available
App update successful Downloading
Uploading Download successful
22 The Basics
Emergency Alert
Connectivity icons
Syncing Problem with sign-in or sync
Mobile Hotspot is on USB connected
Mobile Broadband connection Bluetooth connection
Bluetooth is on Bluetooth headset full
battery
Bluetooth headset low
battery NFC is on
Headset is connected Headset with microphone is
connected
Internal storage is full
Email and Messaging icons
New email New Gmail message
New message New Message+ message
New voicemail Email not sent
Message not sent New Hangouts message
Calendar and Alarm icons
Alarm is set Upcoming event
Battery icons
Full battery Charging battery
Low battery Empty battery
Not Charging
Other icons
More notifications available Screenshot captured
23
The Basics
Getting to Know the Home Screen
The Home screen is your starting point to access all of the features on your
phone using simple motions on the touchscreen. It’s comprised of multiple
panels (swipe horizontally to switch). You can customize all of your Home
screen panels with app shortcuts, icons, widgets, and other features.
Status Bar
Shows device status
information, including the
time, signal strength, battery
status, and notification icons.
App Icon
Tap an icon (app, widget,
folder, etc.) to open and use
it.
QuickTap Bar
Icons that provide easy,
one-touch access to the
functions used most often.
Apps Icon
Tap here to open the Applications
screen to view all of your installed
apps.
Touch Keys
Displayed on all screens, these keys
allow you to easily navigate within
the device software.
QuickTap bar icons
The QuickTap bar is located on all of your Home screen panels (at the
bottom of the screen in portrait view) to allow quick and easy navigation to
the apps you use most often. The following five icons are included in the
QuickTap bar.
: Opens the Phone app which displays the dialpad so you can dial a
number not stored in your phone’s memory. It also provides additional
tabs at the top of the screen to access your Recent calls, Contacts,
Favorites, and Groups.
: Opens the Contacts app which displays the names and numbers stored in
your phone's memory. It also provides additional tabs at the top of the
screen to access the dialpad, your Recent calls, Favorites, and Groups.
: Opens the Applications screen which displays phone options and
apps. It also provides a Widget tab, a Search icon , and a Menu
options icon at the top of the screen.
: Opens the Chrome app to browse the web.
: Opens the Message+ app so you can send and view text and
multimedia messages.
24 The Basics
Modifying the QuickTap bar icons
You can modify the icons in the QuickTap bar to suit your needs.
Rearrange: Touch and hold the icon to move, then drag it to another
position in the QuickTap bar.
Add: Open the Applications screen, then drag the icon you want onto
the QuickTap bar.
Delete: Touch and hold the icon to delete, then drag it to the Remove
icon that appears at the top of the screen.
Touch Keys
The Touch Keys are displayed in a bar at the bottom of all of the screens to
provide easy navigation within the device software.
NOTE The Touch Keys are displayed along the right side of the screen when the phone is held
in horizontal mode. If you don't see the keys, drag upward from the bottom of the
screen, or drag to the left in horizontal mode, to redisplay them.
Back Key: Tap to back up one step at a time and close on-screen items
such as pop-up messages, the on-screen keyboard, etc. Touch and
hold the Back Key to activate Dual window mode which allows you to
open two apps at the same time.
Home Key: Tap to immediately return to the Home screen. Touch and
hold to access Google Now.
Recent Apps Key: Tap to display the apps you recently used. Touch
and hold to access available options for the current screen or app.
Modifying the Touch Key bar
You can change which keys are displayed in the Touch Keys bar, as well as
how they’re displayed.
1. From the Home screen, touch and hold the Recent Apps Key (in the
QuickTap bar) > Settings > Display > Home touch buttons.
2. Select the modification you want to change.
Tap Button combination to select which Touch Keys you want in the
bar and their location within the bar. Choose from the Back Key, the
25
The Basics
Home Key, the Recent Apps Key, the Notifications Key, the
QuickMemo+ Key, the QSlide Key, and the Dual Window Key.
Tap Color to set the key color. Choose from White, White Gradation,
Black, and Black Gradation.
Checkmark the Transparent background checkbox to make the bar
background transparent.
Tap Hide Home touch buttons to hide the Touch Keys on the apps
you select. To access the Touch Key bar from those apps, swipe
upward from the bottom of the touchscreen to temporarily redisplay
them.
To return to the Home screen
Tap the Home Key (in the Touch Keys bar) at any time, from any app.
To view other Home screen panels
Swipe (or flick) your finger left or right across the Home screen. The
Home screen is comprised of four sliding panels, but you can add up to
eight panels to allow more space for icons, widgets, shortcuts, and other
items.
Home Screen Panel Indicator
The white line dot (above the QuickTap bar) indicates the current Home screen panel.
Tap any of the Home screen panel indicator dots (above the QuickTap
bar) to immediately jump to that panel.
26 The Basics
Pinch in on the Home screen to display the mini panel view, then tap the
Home screen panel you want to access.
Tap here to set the
default Home screen.
Tap here to add
another panel.
Full Screen View Mini Panel View
Mini panel view
Mini panel view allows direct access to any of the Home screen panels and
also allows you to manage them. You can add, delete, and rearrange the
panel order as well as set the default Home screen panel.
Pinch in on any of the Home screen panels to change from full screen view
to mini panel view. From mini panel view you have the following options:
To go directly to any panel, simply tap the one you want.
To add another panel, tap the Add panel icon .
To delete a panel, touch and hold the panel to delete, drag it to the
Remove bar at the top of the screen, then lift your finger.
To rearrange your panels, touch and hold the panel to move, drag it on
top of the panel position where you want it, then lift your finger. The
moved panel takes that position and the remaining panels shift
accordingly.
To set another panel as the default Home screen, tap at the upper-
right corner of the mini panel you want to be your default Home screen
panel.
NOTE Changing the default Home screen panel does not change its position with the other
panels.
27
The Basics
Hiding items on the Home screen
Place two fingers on the screen, then spread them apart to hide the items
on your Home screen so that only your wallpaper and the Status Bar are
displayed. To redisplay your normal Home screen with all of its icons and
widgets, pinch in on the screen or tap the Back Key (in the Touch Keys
bar).
NOTE The device automatically reverts to the normal Home screen view after screen timeout.
Using Dual View
Dual view allows you to easily add items to any of the Home screen panels.
Touch and hold an empty spot on a Home screen panel to view your Home
screen on top and selections (Apps tab, Widgets tab, or Wallpapers tab) on
the bottom. Flick sideways to scroll through the Home screen panels to
display the panel you want. At the bottom of the screen, tap the type of
item you want to add (Apps, Widgets, or Wallpapers), then flick sideways
to scroll through the available choices. Simply tap the item you want to
automatically add it to the panel viewed at the top of the screen.
NOTE The QuickTap Bar icons are not accessible while in Dual view.
To return to the full screen view, tap the Back Key (in the Touch Keys
bar) or tap one of the Home screen panels.
NOTE The device automatically reverts to full screen view after screen timeout.
Home screen version
EasyHome is a more simplified version of the Home screen that you can
choose to use on your phone.
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Key bar) > Home screen settings > Select Home > EasyHome.
The EasyHome setting displays the Home screen like a remote control
device. The main part of the screen is the dialpad to allow you to make
calls, but it also has icons to access the Camera app, the Gallery app, the
Contacts app, the Settings app, the Message+ app, the Chrome app, the
Apps screen icon, and the Add icon that allows you to select an app of your
choice for that position. The Weather widget is displayed at the top of the
28 The Basics
screen. The EasyHome Home screen has two panels. Slide the screen to
the left to access it and add additional icons for easy access.
To change back to the Android Home screen
From the EasyHome screen, tap the Apps screen icon > the Settings
icon > Home screen > Select Home > Home.
Global access
The Global access function provides a shortcut to the Voice Mate, Google
Now, and QuickMemo+ features from any screen. Global access is
activated by dragging your finger upward from the Touch Keys bar (at the
bottom of the touchscreen). As you drag, the Voice Mate icon , the
Google Now icon and the QuickMemo+ icon appear on a white arc.
Position your finger over the Global access icon you want to use, then let
go to launch it.
NOTE Drag horizontally from the right side of the Touch Keys bar on to the screen when in
landscape view.
TIP When activating Global access, it may be easier to start dragging from below the Touch
Keys bar to avoid touching and activating a Touch Key on the bar.
29
The Basics
Touchscreen
Your touchscreen provides an excellent way to interact with and use your
Android™ phone. With the touch of your finger, you can download and use
available apps, make menu selections, and access data saved to your
phone.
The following terms are used for describing the different available actions
using the touchscreen:
Touch or tap A single finger touch selects items. For example, tap an
icon (e.g., an app, widget, or folder), tap words (e.g., menu selection or to
answer an on-screen question), or touch letters and numbers to type.
NOTE Don't press too hard on the touchscreen. It's sensitive enough to detect a light, firm tap.
Touch and hold Touch and hold an item on the screen by touching it and
not lifting your finger until an action occurs. For example, to open a
Context menu for editing a contact, touch and hold a contact entry until
the menu pops up.
Drag Touch and hold an item for a moment and then, without lifting your
finger, move your finger on the screen until you reach the target position.
For example, you can drag items on the Home screen to reposition them.
Swipe, slide, or flick Move your finger quickly across the surface of the
screen, without pausing when you first touch it (so you don’t drag an item
instead). For example, you can browse through the different Home
screens by swiping from left to right (and vise versa), slide the screen up
or down to scroll a list, or remove an app from the Recent apps screen by
flicking its graphic off the screen.
Double-tap Tap the screen twice quickly to zoom, highlight text, or turn
the screen on/off. For example, quickly double-tap a section of a web
page to zoom that section to fit the width of the screen and control the
zoom in Maps and in other apps. Double-tap a word to highlight it.
Double-tap can also activate the KnockON feature to turn the touchscreen
on or off.
NOTE The Accessibility settings shortcuts and Touch zoom accessibility features use a
triple-tap. Double-tap also activates a new event in the Calendar app.
30 The Basics
Pinch-to-zoom Use your index finger and thumb in a pinch motion (to
zoom out) or spread motion (to zoom in) when using Chrome, a map,
photos, the rear camera lens, the Contacts list, the Favorites list, the
Groups list, the Messaging list, and a music list. Spread apart to make
screen information larger (easier to see and read), or pinch together to
view more area and information. The pinch gesture also changes the
Home screen. Pinch in on the Home screen to change to mini panel view,
then spread apart to return to the normal Home screen view. Spread apart
on the normal Home screen to hide all of your Home screen items, then
pinch in to redisplay them.
Rotate the screen From many apps and menus, the orientation of the
screen adjusts to the phone’s physical orientation by rotating the screen.
You can deactivate this function in the Display settings menu.
Rotate the phone sideways for
landscape orientation.
Rotate the phone upright for portrait
orientation.
Capturing the screen Press and hold the Volume Down Key
and the
Power/Lock Key on the back of the phone at the same time to capture
the current image on the screen. The captured image is saved in the
Screenshots folder of the Gallery.
NOTE You cannot capture an image from some videos and apps.
The Smart screen feature
The Smart screen feature keeps the phone from activating screen time-out
when it detects your eyes looking at the screen. When you turn this feature
on, you can set a shorter screen time-out to conserve your battery power,
31
The Basics
but still allow you to view a screen for a longer period of time without
having to touch it to keep it activated.
To turn this feature on, from the Home screen, touch and hold the Recent
Apps Key (in the Touch Keys bar) > Settings > Display > checkmark
the Smart screen checkbox.
NOTES The following situations may prevent these features from functioning properly.
When the phone is in the dark or against bright light.
When the camera lens can’t detect the location of your eyes.
When the front camera is used at the same time with other apps.
Text Input Methods
The on-screen keyboard displays automatically on the screen when you
need to enter text. To manually display the on-screen keyboard, simply tap
a text field where you want to enter text.
Touch and hold to enter text
by voice and handwriting or
or access the clip tray and
keyboard settings.
Selection Box
Tap a displayed item, or
swipe upward, to insert it in
the text field.
Toggles between 123/SYM
mode and ABC mode.
Modifying your LG keyboard characteristics
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Language & input > the Settings icon
(next to LG Keyboard) > Keyboard height and layout.
The Bottom row keys setting allows you to select the default keys on
either side of the Space Key.
The Extend keyboard setting displays numeric keys on the top row of
the keyboard.
32 The Basics
The Keyboard height setting allows you to change the size ratio
between the keyboard and screen.
The Keyboard theme setting allows you to choose a theme for your
keyboard.
The Split keyboard setting allows you to split the keyboard in half by
spreading two fingers to the left and right.
The One-handed operation setting allows you to swipe the keyboard
left or right to adjust the position of the LG keyboard.
Typing tips
Enter other
characters
Tap the Numbers/Symbols Key to display
the numbers and symbols keyboard. Tap the
Arrow Keys on the left side of the
keyboard to view additional symbols. From the
Numbers/Symbols keyboard, you can also tap
the Graphics Key to enter graphics into your
text. To enter foreign characters, touch and hold
the associated key to display a pop-up of
character choices (e.g., the “a” key also includes
an accent mark “á”), drag your finger to the
character you want, then lift your finger.
Enter one capital
letter
Tap the Shift Key to capitalize the next letter.
The key changes to .
Enter all capital
letters
Double-tap the Shift Key to set caps lock.
The key changes to . Tap again to revert to
lowercase.
Highlight text
Double-tap a word to highlight it. To highlight a
range of text, double-tap a word, then drag the
blue highlight markers to highlight the text you
want.
Cut or copy selected
text
Highlight the desired text, then tap Cut, Copy, or
Select all in the action box above the highlighted
text.
Paste cut or
copied text
Tap the location where you want to paste the
text, then tap the marker . Tap Paste in the
action box that appears.
33
The Basics
Delete a character Tap the Delete Key .
Entering text by
voice or handwriting
Touch and hold the Settings Key then drag
your finger to the Voice input icon or the
Handwriting icon (in the pop-up that appears).
Accessing the Clip
Tray and keyboard
settings
Touch and hold the Settings Key then drag
your finger to the Clip Tray icon (in the pop-up
that appears).
Text input settings
To change your text input settings and see the dictionary of terms you’ve
used, from the Home screen, touch and hold the Recent Apps Key (in
the Touch Keys bar) > Settings > Language & input. The following options
are available in the KEYBOARD & INPUT METHODS section.
Default - Designates the default keyboard to use when entering text.
LG Keyboard - Tap the Settings icon (on the right side of the screen)
to change the following settings.
MY KEYBOARD
Input language and keyboard layout: Sets the keyboard language
and keyboard layout. This is where you can select multiple languages
for your keyboard input.
Keyboard height and layout: Sets certain characteristics for your
keyboard to help you enter text more easily.
Bottom row keys: Sets the keys on either side of the Space Key.
Choose from the Voice input Key , the Handwriting Key , the
Clip Tray Key , and the Symbols Key (you can even
designate the default symbol).
Extended keyboard: Checkmark to show the numeric keys on the
top row of the keyboard.
Keyboard height: Sets the the height of the keyboard to show
more (or less) of the screen to make typing easier.
34 The Basics
Keyboard theme: Sets the keyboard theme. Choose White or
Black.
Split keyboard: Checkmark to split the screen when you spread
two fingers on the on-screen keyboard in landscape view.
One-handed operation: Checkmark to allow you to position the LG
keyboard on the left or right side of the screen so that it’s easier to
type with just one hand.
SMART INPUT
Path input: Checkmark to enter a word by drawing a path through all
of the letters.
Show word suggestions: Checkmark to show words through text
prediction.
Auto-correction: Sets the level of auto-correction. Choose from Off,
Mild, Moderate, and Aggresive.
Update word suggestions: Update to get more word suggestions
using Swipe Connect.
Additional settings
EFFECTS
Vibrate on keypress: Checkmark to provide a vibration when you
tap the keyboard keys.
Sound on keypress: Checkmark to provide a sound when you tap
the keyboard keys.
Pop-up on keypress: Checkmark to display a bubble with each
character as you type.
INPUT TOOLS
Auto-capitalization: Capitalize the first word of each sentence
automatically.
Auto-punctuation: Automatically inserts a period when the space
key is double-tapped.
35
The Basics
Spell checker: Checkmark to show spelling errors.
Clear word suggestion history: Clear history of words suggested
based on your input.
Personal dictionary: Add words to your word suggestions.
HANDWRITING
Languages: Downloads your preferred handwriting language.
Pentype and color: Sets the pen type and color.
Help: Displays LG Keyboard information for various LG keyboard
features.
Google voice typing: Checkmark to select Google voice typing to enter
text. Tap the Settings icon to change the Google voice typing settings.
Choose input languages: Allows you to select the languages to support
with Google voice typing.
GENERAL
Block offensive words: Checkmark to hide recognized offensive text.
Offline speech recognition: Enables voice input while offline.
Voice Search: Sets voice search options.
Language: Sets the Google search by voice language.
“Ok Google” Detection: Turn this feature On to start the Google
Search app simply by saying “OK Google”.
Speech output: Sets when to use speech output. Choose from On,
Hands-free only, and Off. To turn on speech output only when you’ve
got a headset attached to your phone, select Hands-free only.
Block offensive words: Checkmark to hide offensive voice results.
Offline speech recognition: Sets one or more additional languages for
speech recognition when you don’t have a network connection.
Bluetooth headset: Checkmark to record audio through a connected
Bluetooth headset.
36 The Basics
Text-to-speech output: Sets the preferred speech engine and speech
rate (very slow to very fast). Also plays a short demonstration of speech
synthesis and displays the language status.
MOUSE/TRACKPAD
Pointer speed: Sets the pointer speed.
Languages
You can set only one default language for your phone, but you can set
multiple languages used for the on-screen keyboard.
To change the default language
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Language & input > Language > tap the
language you want.
To add additional languages for your keyboard
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Language & input. Tap the Settings icon
(to the right of LG Keyboard), tap Input language and keyboard
layout, then checkmark the languages you want the keyboard to be able
to use.
Hardware key control mode
If your phone display is damaged or broken, you can answer an incoming
call, or turn off an alarm using the hardware keys on the back of the phone.
Answer a call: Press both Volume Keys at the same time.
Stop an alarm: When an alarm rings, press and hold either of the
Volume Keys to stop the alarm. Press either Volume Key once to
snooze the alarm.
To activate Hardware key control mode
1. Turn your phone off.
37
The Basics
2. Press and hold the Power/Lock Key and both of the Volume Keys
(on the back of the phone) at the same time for more than 6 seconds to
enter Hardware key control mode.
3. Press the Volume Keys to scroll to Mode ON, Mode OFF, or Cancel,
then press the Power/Lock Key to confirm.
NOTE If you use your phone with a broken display glass, your phone may incur additional
damage or cause injury. Make sure to visit an LG authorized service center to get your
phone repaired.
Apps: How to View, Open, and Switch
All of the apps on your phone, including any apps that you downloaded and
installed from Play Store or other sources, are grouped together on the
Applications screen, which you access from your Home screen. If you have
more apps than can fit on the Applications screen, you can slide the screen
left or right to view more.
Home screen
Applications screen
Tap an app icon to open
the app.
Tap these to select Apps,
Widgets, Search, or Edit.
Tap to open the
Applications screen.
Slide the screen left or
right to bring more icons
into view.
38 The Basics
Opening and Closing the Applications screen
Opening the Applications screen
It’s easy to access the Applications screen no matter what feature you’re
currently using. Simply tap the
Home Key
(in the Touch Keys bar), then
tap
the Apps icon
(in the QuickTap bar).
Closing the Applications screen
To manually close the Applications screen, tap the Home Key or the
Back Key (in the Touch Keys bar).
NOTE The Applications screen closes automatically when you tap an icon to open its app.
Dragging an icon onto your Home screen also closes the Applications screen
automatically.
Customizing the Applications screen
Your phone includes a wide variety of apps and you can download even
more apps to your phone. You can customize these items on the
Applications screen for faster, more convenient access to the apps you use
most often.
Applications screen options
You can change the look of your Applications screen.
1. From the Home screen, tap the Apps icon
(in the QuickTap bar), then
tap the Apps tab, if necessary.
2. Tap the Menu icon (at the upper-right corner of the screen) to access
the following Applications screen options:
View apps by: Tap to sort your apps either in alphabetical order, by
downloaded date, or user customized.
Show small/large icons: Tap to change the app icons to either small
or large, then tap Yes to set your choice.
Hide/Show apps: Tap to set which app icons will be displayed in your
Applications screen. Checkmark the icons you want to hide, then tap
the Checkmark icon (at the upper-right corner of the screen).
39
The Basics
Edit/Uninstall apps: Tap to view app information, move apps on the
screen, or uninstall apps from the Application screen. Tap an app icon
to view its information, then tap the Uninstall button, if you want to
uninstall it.
Home screen settings: Tap to access the Home screen settings
menu.
Rearranging the Applications screen icons
You can rearrange the order of the icons on the Applications screen to
provide more convenient access to the apps you use the most.
1. From the Home screen, tap the Apps icon (in the QuickTap bar), then
tap the Apps tab, if necessary.
2. Tap the Menu icon (at the upper-right corner of the screen), tap Edit/
Uninstall apps. The Menu icon changes to a checkmark .
3. Touch and hold the app icon you want to move, drag it to its new
position, then lift your finger. The remaining icons shift to the right.
NOTE If you drag the app icon onto another app icon, it creates a folder with both of the apps in
it.
4. Tap the Checkmark icon (at the upper-right corner of the screen) to
save and exit.
Checking App information
To view an app’s detail information from the Applications screen:
1. From the Home screen, tap the Apps icon (in the QuickTap bar).
2. Tap the Apps tab (if necessary), then tap the Menu icon (at the
upper-right corner of the screen) and tap Edit/Uninstall apps.
3. Tap any of the app icons to display an information dialog box, then tap
OK to close it.
4. Tap the Back Key (in the Touch Keys bar) to return to the Applications
screen to exit.
NOTE Access the Widget tab, then tap Uninstall to display an information dialog box for a
widget you select.
40 The Basics
Opening and Switching Apps
Multi-tasking is easy with Android™ because you can use and switch
among several open apps. Android™ manages each app, stopping and
starting them as needed, to ensure that idle apps don’t consume resources
unnecessarily.
Opening an app
Open an app simply by tapping its icon on the screen.
TIP You can customize your Home screen with the app icons you use most often. Apps are
located on the Applications screen, but you can copy any app icon to your Home screen
for faster, more convenient access. No matter where the icon is, on the Applications
screen or your Home screen, just tap it to open and use it.
Opening multiple apps
1. Tap an app icon to open it.
2. Tap the Home Key (in the Touch Keys bar).
NOTE If the app icon you want is on your Home screen, simply tap the icon to open and use it.
3. Tap the Apps icon (in the QuickTap bar).
4. Tap the Apps tab (if necessary), then tap the icon for the other app you
want to open.
Switching between multiple apps
1. Tap the Recent Apps Key (in the Touch Keys bar). A screen opens
and displays a scrolling list of all of the apps that are currently open.
2. Tap the app you want to use or tap the Back Key (in the Touch Keys
bar) to return to the current screen.
Tap an app to use it.
Flick an app icon to the right or left to
close the app and remove it from the list.
Swipe up or down to
view the entire list of
open apps.
41
The Basics
NOTE Navigation in the Recent apps screen depends on the device orientation. When held
sideways, swipe left and right to view the entire list. Flick an app icon up or down off the
screen to close the app and remove it from the list.
Adding items to the Home screen
Customize your Home screen with the apps you use most often.
Applications screen
1. From the Home screen, tap the Apps icon (in the QuickTap bar), then
tap the Apps tab, if necessary.
NOTE You can tap the Widgets tab (at at the top of the screen) to place a widget on the Home
screen.
2. Touch and hold the icon you want to add to your Home screen. The
Applications screen closes and the Home screen is displayed.
3. Drag the icon to where you want it on the screen, then lift your finger.
Dual view
1. Touch and hold an empty spot on any of the Home screen panels to
view your Home screen on top and the selection tabs (Apps tab,
Widgets tab, or Wallpapers tab) on the bottom.
2. Flick sideways to scroll through the Home screen panels to display the
panel you want.
3. Tap the tab for the type of item you want to add (Apps, Widgets, or
Wallpapers) at the bottom of the screen, then flick sideways to scroll
through the available choices.
4. Tap the item you want to automatically add it to the panel viewed at the
top of the screen.
NOTE You can also manually drag it to the Home screen location you want.
Moving apps to other Home screen panels
You can place app icons on any of the Home screen panels. Touch and hold,
then drag the icon to the left or right edge of the screen to advance to the
other panels before lifting your finger.
42 The Basics
Customizing an app icon on your Home screen
You can create your own custom app icon(s) using the images in your
Gallery. Your customized app icon(s) are only applied to icons on your Home
screen. The Applications screen is not affected.
Touch, hold, release,
then tap an icon to
edit it.
Customize Icon ScreenHome Screen
1. Touch and hold the icon you want to customize, then release the icon.
An editing icon appears at the upper-right corner of the app icon.
NOTE If an icon you placed can be resized, you'll see a blue box around the icon after you
touch, hold and release it. Drag the edges of the box to resize it.
2. Tap the app icon (while the edit icon is still displayed).
3. Tap the icon design you want from the available icon choices, then tap
OK.
OR
Tap the Add new icon (at the top of the screen), set the size for the
icon, then tap OK. Select the image you want to use for the app, crop
the image (if necessary), then tap OK.
NOTE Your custom photo icons are saved so you can easily select them for any of your icon
images. Tap the Delete icon (at the upper-right corner of the screen) to remove any of
your custom photo icons.
Changing an icon into a widget
Some app icons can be changed into a convenient widget to use on your
Home screen.
43
The Basics
1. Touch and hold the icon you want to customize, then release the icon.
A blue frame appears around the icon if it can be resized and changed
into a widget (if it can’t, only the Edit icon is displayed).
2. Drag the corners of the frame to make it larger and change it into a
widget.
Touch, hold, and release the widget again to change the size of the
widget, if necessary.
You can also change it back into a normal icon by dragging the corners
of the resizing frame back in.
Working with Menus
Options menus
Options menus contain tools that apply to the activities of the current
screen or app, not to any specific item on the screen. To open the available
Options menu, tap the Menu icon (at the upper-right corner of the
screen). To open the Options menu on the Home screen, touch and hold
the Recent Apps Key (in the Touch Keys bar at the bottom of the screen).
Context menus
Context menus contain options that apply to a specific item on the screen.
To open a Context menu, touch and hold an item on the screen. Not all
items have Context menus. If you touch and hold an item that has no
Context menu, nothing will happen.
When you touch and
hold certain items on
a screen, a Context
menu opens.
44 The Basics
Managing Notifications
Notification icons report the arrival of new messages, calendar events,
alarms, as well as ongoing events, such as when you’re in a call.
When you receive a notification, the notification icon will be displayed in the
Status Bar. You can open the Notifications panel to view a list of all of your
recent notifications. Depending on your settings, you may hear a
notification sound, and/or see a notification light (at the upper-left corner of
the phone), and/or the phone may vibrate.
To open the Notifications panel
Touch and drag the Status Bar to the bottom of the screen.
The Notifications panel displays a list of your current notifications, organized
into ongoing and event-based notifications. It also includes a Quick Settings
icon bar (at the top of the panel) to allow you to quickly and easily change
commonly used settings.
NOTE You can also access the complete Settings menu from this panel by tapping the Settings
icon (at the upper-right corner of the screen).
Tap a notification to open it.
Quick Settings Bar
Flick right or left to scroll
through the list and tap an
icon to change its setting.
Settings menu icon
Clear Button
Tap here to clear your list of
event-based notifications.
Home screen Notifications Panel
To respond to a notification
1. Open the Notifications panel. Your current notifications are listed in the
panel, each with a brief description.
2. Tap a notification to view it.
45
The Basics
The Notifications panel will close and the app that corresponds to your
selection will open. For example, new voicemail notifications dial your
voicemail box and Gmail notifications open the Gmail app so you can
read your new messages.
To clear all notifications
1. Open the Notifications panel.
2. Tap the Clear button (on the right side of the screen).
All event-based notifications will be cleared; ongoing notifications will
remain in the list.
To close the Notifications panel
Touch and drag the handle at the bottom of the Notifications
panel to the top of the screen, flick the Notifications panel handle upward,
or just tap the Back Key (in the Touch Keys bar).
The panel will also close when you touch a notification.
NOTE When you open the Notifications panel from the Lock screen, the Touch Keys bar is not
displayed at the bottom of the screen. Drag or flick the handle upward to close it.
Quick settings on the Notifications panel
The top of the Notifications panel includes a Quick settings bar. The icons in
this bar provide a quick, convenient way to change settings without
accessing any apps. If you set more than five icons on the bar, swipe left
and right to scroll through the list.
Using the Quick settings icons
Tap any of the Quick settings icons to toggle through the available settings:
QuickMemo+ starts the QuickMemo+ app.
QuickRemote bar displayed . QuickRemote bar hidden .
Sound On , Vibrate , or Silent .
Bluetooth On or Bluetooth Off .
Wi-Fi On or Wi-Fi Off .
Location On or Location Off .
46 The Basics
Rotation screen On or Rotation screen Off .
Airplane mode On or Airplane mode Off .
Quiet mode On or Quiet mode Off .
Screen timeout 30 seconds , 5 minutes or 15 minutes .
Battery saver On or Battery saver Off .
Mobile Data On or Data Off .
Miracast On or Miracast Off .
NFC On or NFC Off .
QSlide Apps Bar displayed or QSlide Apps Bar hidden .
Sync On or Sync Off .
Hotspot On or Hotspot Off .
SmartShareBeam On or SmartShareBeam Off .
Voice Mate starts the Voice Mate app.
LED On or LED Off .
Tap the Settings icon (at the upper-right corner of the screen) to access
the complete Settings menu.
Customizing the Quick settings bar icons
You can set the order of the icons displayed in the Quick settings bar as
well as which icons are displayed.
1. Open the Notifications panel, then tap the Edit icon (at the right side
of the Quick settings bar).
Drag one of the icon handles at the right side of the screen to
move its icon to another position in the Quick settings bar.
Checkmark each of the items you want to appear in the Quick
settings bar.
NOTE Changing the checkmarks reorganizes the icons in the Quick settings bar.
2. Tap the Back Key (in the Touch Keys bar) to return to the
Notifications panel.
47
The Basics
QSlide apps on the Notifications panel
You can choose to display QSlide apps in a bar on the Notifications panel
below the Quick settings bar. These icons provide a quick, convenient way
to multi-task on the same screen (similar to picture-in-picture on a TV).
QSlide displays a small app window on the screen that can be moved,
resized, or made transparent.
Tap any of the QSlide apps in the bar to activate it. You can open up to two
QSlide windows at a time. For more information on using QSlide, see
pages 142-144.
Customizing the QSlide bar apps
You can set the order of the apps displayed in the QSlide bar, as well as
which apps are displayed.
1. Open the Notifications panel, then tap the QSlide icon to display the icon
bar (if necessary).
2. Tap the Edit icon on the far right of the QSlide apps bar.
Drag one of the icon handles at the right side of the screen to
move its icon to another position in the QSlide apps bar.
Checkmark the QSlide apps you want to display and remove the
checkmark for the ones you want to remove.
3. Tap the Back Key (in the Touch Keys bar) to return to the
Notifications panel.
Searching Your Phone and the Web
You can search for information on your phone and on the web using the
Google search app.
Some apps, such as Gmail, Contacts, and Chrome, have the ability to
search for contents within those specific apps.
You can conduct the search by typing in the search terms or saying what
you’re looking for. As you enter text, the search app can provide
suggestions so you don’t necessarily have to type out your full request.
48 The Basics
Phone and Web search using text entry
1. Tap the Google Search Widget on the Home
screen.
Google Now opens automatically and you can use the on-screen
keyboard to search.
Voice Search
Tap here to search by voice.
Search Box
Tap here to type your search request.
2. Enter the text you’re searching for in the search box.
As you type, search results from your
phone, previous search terms, and
web search suggestions appear. Tap
an item to activate that search result.
3. Tap the Search Key on the on-screen keyboard to search for the text
you entered in the search box.
49
The Basics
Google Search Options menu
Tap the Menu icon at the lower-right corner of the screen (close the
keyboard, if necessary) to access Settings, Help & feedback.
Search preference settings
You can use the Search preference settings to configure some aspects of
web search (for example, whether it makes suggestions below the search
box as you type) and what phone features you want to include in your
searches. To access these settings:
1. From the Search app, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings.
2. Tap Phone search.
3. Tap an item to checkmark and enable it (or remove the checkmark) to
set your search preferences, then tap the Back Key (in the Touch
Keys bar) to exit.
Text Link
Text Link recommends apps related to text in messages or other text
you’ve selected. It connects directly to the Calendar, Contacts, Phone,
Messaging, Email, Web, Maps, YouTube, Calculator, and more.
To use Text Link:
Tap a message bubble with the Link icon .
Highlight text on a webpage or in an email and select Text Link in the
pop-up.
Highlight text on a webpage, then tap Share and select Text Link.
NOTES If your phone's language is set to English or Korean, Text Link performs more functions
than in other language settings.
Overly long sentences are subject to limitations.
Arithmetic operators (such as +, -, * and /) start the Calculator.
If Text Link is not linked to an app, the Browser can be used for searching.
50 The Basics
Locking Your Phone
You can lock the touchscreen to prevent unintentional gesture actions, as
well as lock the phone to guard against unauthorized use.
The default Lock screen
The default Lock screen is Swipe which protects against unintentional
touchscreen actions. The Lock screen is activated when the screen
times-out from inactivity. Press the Power/Lock Key (on the back of the
phone) to illuminate the screen. The Swipe default Lock screen is
displayed, but you can still conveniently check the date, time, and Status
Bar icons. You can drag the Status Bar down to open and use the
Notifications Panel without unlocking the screen. In addition, you can also
quickly access five shortcut apps (the Phone app , the Message+(VZW)
app , the QuickMemo+ app , the Chrome app , and the Camera app
) without unlocking the screen first. Simply swipe an icon upward to
open and use it.
Changing the shortcut icons on the default Lock screen
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Lock screen settings.
2. Tap Shortcuts.
3. Tap one of the icons at the bottom of the screen, then tap the app you
want to replace it with.
4. Tap Save (at the bottom of the screen) to save these settings.
Setting your Lock screen
There are several Lock screen types allowing you to lock your phone so
that only you can unlock it to make calls, access your data, buy apps, and
prevent unauthorized use.
Setting a Screen Lock for the First Time
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Lock screen settings.
51
The Basics
2. Tap Select screen lock.
3. Tap None, Swipe, Face Unlock, Knock Code, Pattern, PIN, or
Password.
None: No Lock screen is enabled so the screen will never be locked
from use.
Swipe: A swipe motion in any direction on the touchscreen will unlock
the screen. This is the default Lock screen that simply guards against
unintentional actions.
Face Unlock: Unlocks the screen using face recognition. The phone
captures your image to identify you. Keep in mind that Face Unlock is
less secure than a pattern, PIN, or password because it uses generalized
shape and dimension to verify your face.
Knock Code: Unlocks the screen using a tapping a sequence on the
screen's 2x2 grid. (When the screen is in time-out, the 2x2 grid is
invisible, but the grid is displayed on the Knock Code Lock screen.) The
first time you set a Knock code, you'll see a tutorial with instructions on
how to create it. Tap a sequence on the 2x2 grid (from 3 to 8 taps), then
tap Done. Tap your sequence again and tap Confirm.
NOTE You're prompted to create a Backup PIN as a safety measure in case you forget your
Knock code unlock sequence.
Pattern: Unlocks the screen using a pattern you draw with your finger.
The first time you set an unlock pattern, you'll see a tutorial with
instructions on how to create it. Read the tutorial, then tap Next. Draw
your pattern (connect at least 4 dots) and tap Continue. Then redraw
your pattern and tap Confirm.
NOTE You're prompted to create a Backup PIN as a safety measure in case you forget your
unlock pattern sequence.
PIN Unlocks the screen with a number sequence. Enter a PIN (at least 4
digits) and tap Continue. Reenter your PIN and tap OK to confirm it.
Password Unlocks the screen with an alphanumeric sequence. Enter a
password (at least 4 characters) and tap Continue. Re-enter your
password and tap OK to confirm it.
52 The Basics
From then on, any time you want to unlock the screen, you'll need to
perform the unlock action you set (swipe, face recognition, knock code,
pattern, knock code, PIN, or password) to gain access to it.
Disabling a Screen Lock
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Lock screen settings.
2. Tap Select screen lock.
3. Confirm your unlock information (if necessary).
4. Tap None.
Changing Your Screen Lock
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Lock screen settings.
2. Tap Select screen lock.
3. Confirm your unlock information (if necessary).
4. Tap the desired screen lock option.
5. You’re prompted to enter your screen lock.
6. If necessary, enter a Backup PIN and tap Continue. Then confirm your
Backup PIN and tap OK.
NOTES If you've set up a Microsoft Exchange account, you might only be able to use a
password.
 After 5 unsuccessful attempts to unlock your phone, you're prompted to enter a
text phrase to confirm that you're trying to unlock your phone.
 You have 10 opportunities to enter your unlock sequence. After 10 unsuccessful
attempts, your phone will automatically perform a factory data reset and all of your
personal files will be erased. You will be warned after the 9th unsuccessful attempt.
If you can't remember your unlock sequence, after 5 attempts, tap the Forgot
button (at the lower-right corner of the screen), then you can unlock the phone using
your Google Account (if you activated it on the phone) or your Backup PIN that you
created when you set up the screen lock sequence.
- Enter your Google Account username and password, then tap Sign in.
- Enter your Backup PIN, tap Done (at the lower-right corner of the keypad) or then
tap OK (below your Backup PIN entry).
53
The Basics
Security lock timer
If a security lock is enabled, you can set the delay time after the screen
darkens due to inactivity before the screen automatically locks and requires
you to enter your unlock sequence.
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Lock screen settings.
2. Tap Security lock timer, then tap the setting you want to use.
Power button instantly locks
If a security lock is enabled, checkmark the Power button instantly locks
checkbox to override the Security lock timer setting and lock the screen as
soon as you press the Power/Lock Key (on the back of the phone).
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Lock screen settings.
2. Checkmark the Power button instantly locks checkbox.
The Lock screen wallpaper
You can set the Lock screen wallpaper separately from your Home screen
wallpaper.
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Lock screen settings.
2. Tap Wallpaper.
Tap Gallery to select an image from your Gallery.
Tap Wallpaper gallery to select one of the available wallpaper images.
Additional Lock screen settings
All of the Security locks include the following settings: Select screen lock,
Screen swipe effect, Wallpaper, Widgets, Missed calls & new messages,
Shortcuts, Contact info for lost phone, Security lock timer, and Power
button instantly locks.
54 The Basics
There are additional Lock screen settings depending on which Security lock
you set. The following are the variable settings for each Lock screen:
Swipe also includes Weather animation.
Face Unlock also includes Improve face matching and Liveness check.
Knock Code also includes Weather animation.
Pattern also includes Pattern effect, Hidden pattern, Make pattern
visible, and Weather animation.
PIN also includes Hidden PIN, Random PIN entry, and Weather
animation.
Password also includes Hidden password and Weather animation.
System recovery
If you forget your unlock sequence and backup PIN, you’ll have to perform
a Factory data reset on System recovery menu to gain access to your
phone.
WARNING Performing a Factory data reset deletes all of your user data, which includes pictures,
videos, and music saved to your internal memory. Please make sure to back up your
information prior to performing a hard reset.
1. Turn the phone off.
2. Press and hold the following keys (on the back of the phone) at the
same time: Volume Down Key + Power/Lock Key for
approximately 10 seconds.
3. Release both of the keys when the System recovery screen is displayed.
4. The following options are displayed: Continue Power up, Safe mode,
Factory data reset, Wipe cache, and Power down. Press a Volume Key
to scroll to the desired option, then press the Power/Lock Key to
confirm.
NOTE Highlight Continue Power up to simply restart your phone without performing a hard
reset.
5. If you choose Factory data reset, press either of the Volume Keys (on
the Factory data reset screen) to highlight Yes, (or No to exit) then press
the Power/Lock Key (on the back of the phone) to confirm.
55
The Basics
6. Your phone will perform a hard reset and erase all personal data from the
phone's memory.
Guest Mode
Use Guest mode when you let someone else use your phone. They’ll only
be able to use the apps that you’ve selected. Once you set it up, you can
easily put your phone in Guest mode by accessing the Lock screen and
drawing the guest pattern that you set, which is different from your normal
unlock pattern. It also supports Knock Code, PIN, and Password.
NOTE Guests can also use apps that your selected apps are linked to.
Setting up Guest mode
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Guest mode.
2. Tap Lock screen type, then set the screen lock you want to use to put
your device in Guest mode.
If your Lock screen isn’t set to an unlock sequence, you’ll be
prompted to enter an unlock sequence for yourself before you’re
prompted to enter an unlock sequence for your Guest mode.
3. Tap Allowed app to view which apps can be accessed in Guest mode.
Checkmark the apps that you want to allow to be accessed in Guest
mode.
Remove checkmarks from the apps to hide in Guest mode.
Tap the Back Key (in the Touch Keys bar) when all of the
checkboxes are set as you want.
4. Tap the Guest mode switch (in the upper-right corner of the screen)
to turn it on (or off).
Using Guest mode
After you’ve set up and enabled Guest mode, lock the screen, then access
the Lock screen (press the Power/Lock Key on the back of the phone or
use the KnockON feature). Enter your Guest mode screen lock. The Guest
56 The Basics
mode Home screen is displayed with only the apps you’ve selected for
guest access. To exit Guest mode, simply access the Lock screen again
and enter your normal unlock screen lock.
Customizing the Home Screen
You can personalize your Home screen by adding app icons, shortcuts,
widgets, and other items to any Home screen panel. You can also change
the wallpaper.
To add an item to the Home screen
1. Touch and hold an empty spot on the Home screen panel where you
want to add the item. The screen changes to Dual view (your Home
screen panels on top and the Applications screen on the bottom).
NOTE If the panel you've selected is full, make space by deleting or moving items, or switch to
another panel where there is space for new items.
2. The Apps, Widgets, and Wallpapers category tabs are displayed at the
bottom of the screen. Tap the one that corresponds to the item you
want to add.
Item List
Touch and hold an icon, then drag it
onto the panel where you want it.
Category Tabs
Tap one of the item categories you want
to add to a Home screen panel.
Slide the screen right or left to view
different Home screen panels.
3. Swipe left and right to scroll through the available choices in the
category tab you selected. Touch and hold the item you want, then drag
it onto the Home screen panel, or simply tap it to automatically place it
on the panel.
57
The Basics
To move an item on the Home screen
1. Touch and hold the item.
2. Drag the item to a new location on the screen.
Pause at the left or right edge of the screen to drag the item onto the
next available Home screen panel.
3. When the item is where you want it, lift your finger.
To remove an item from the Home screen
1. Touch and hold the item.
2. Drag the item to the Remove icon
at the top of the screen.
3. When the Remove icon changes to , lift your finger.
To change the look of your Home screen
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Home screen settings to access the following settings
to personalize your Home screen.
Select Home: Sets the type of Home screen layout. Choose Home
(standard Android layout) or EasyHome (simplified version for users less
familiar with Android navigation).
Smart Bulletin: Tap the Smart Bulletin switch to toggle it On or Off.
On adds an additional Home screen panel that displays customized
information, such as LG Health and Smart Tips to display that
information on the Smart Bulletin screen.
Wallpaper: Sets the wallpaper. Choose from Gallery, Live Wallpapers,
Multi-photo, Photos and Wallpaper gallery.
Screen swipe effect: Sets how the items on the Home screen panels
slide from one to the next. Choose from Slide, Breeze, Accordion,
Panorama, Carousel, Layer, and Domino.
Allow Home screen looping: Checkmark so that the Home screen
panels rotate continuously (first screen redisplays after the last screen).
Allow apps list looping: Checkmark so that the Application screen
panels rotate continuously (first screen redisplays after the last screen).
Help: Tap to view help information about customizing the Home screen.
58 Connecting to Networks and Devices
Connecting to Mobile Networks
When you buy your phone and sign up for service, your phone is configured
to use your provider’s mobile networks for voice calls and for transmitting
data.
Different locations may have different mobile networks available.
Initially, your phone is configured to use the fastest mobile network
available for data. You can also configure your phone to access a different
set of networks entirely, or to behave in specific ways when roaming.
The following icons in the Status Bar indicate which kind of data network
you’re connected to and the network signal strength.
Connected to the 4G network (LTE).
Connected to the EVDO network (EVDO revA).
Signal strength - the more bars that are lit, the stronger the
wireless signal.
Connected to another wireless service provider’s network
(roaming).
When connected to slower networks, you may want to postpone using
your phone for data-intensive tasks until you’re connected to a faster
network again or find a Wi-Fi network to connect to.
To disable data when roaming
You can prevent your phone from transmitting data over other carriers’
mobile networks when you leave an area that’s covered by your carrier’s
networks. You can still transmit data with a Wi-Fi connection when Global
data roaming access is restricted. This is useful for controlling expenses if
your cell plan doesn’t include data roaming.
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > More... > Mobile networks > Global data
roaming access.
2. Tap how you want to restrict global data roaming. Choose from Deny
data roaming access, Allow access only for this trip, and Allow access
for all trips.
59
Connecting to Networks and Devices
Connecting to Wi-Fi Networks
Wi-Fi is a wireless networking technology that can provide Internet access
at distances of up to 100 meters, depending on the Wi-Fi router and your
surroundings.
To use Wi-Fi on your phone, you must connect to a wireless access point.
Some access points are open and you can simply connect to them. Others
are hidden or implement other security features, so you must configure
your phone so it can connect to them.
Turn off Wi-Fi when you’re not using it, to extend the life of your battery.
The following Status Bar icon indicates your Wi-Fi status.
Connected to a Wi-Fi network (waves indicate connection
strength).
When you connect to a Wi-Fi network, the phone obtains a network
address and other information it needs from the network, using the DHCP
protocol. To configure the phone with a static IP address and other
advanced settings, from the Wi-Fi settings screen, touch and hold the
connected network. Tap Modify network in the Context menu that appears,
then checkmark the Show advanced options checkbox.
To turn Wi-Fi on and connect to a Wi-Fi network
1. From the Home screen, ttouch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Wi-Fi.
If the Wi-Fi switch is off (gray icon), tap it to turn on Wi-Fi (On
turns blue), your phone scans for available Wi-Fi networks.
2. Tap a network, then tap Connect to connect to it.
If the network is open, you can connect to the network directly by
tapping the network name.
If the network is secured, you’ll be prompted to enter a password
(Ask your network administrator for details).
When you’re connected to a network, you can tap the network name
in the Wi-Fi settings screen for details about the speed, security,
address, and related settings.
60 Connecting to Networks and Devices
To add a Wi-Fi network
You can add a Wi-Fi network so the phone will remember it, along with any
security credentials, and connect to it automatically when it’s in range. You
can also add a Wi-Fi network manually if it doesn’t broadcast its name
(SSID) or if you want to add a Wi-Fi network when you’re out of its range.
To add a secured network, you need to contact the network’s administrator
to obtain the password or other required security credentials.
1. Turn on Wi-Fi, if it’s not already on, then tap Wi-Fi in the Settings menu.
2. From the Wi-Fi screen, tap the Menu icon (at the upper-right corner of
the screen), then tap Add network.
3. Enter the Wi-Fi name (SSID) of the network.
4. If the network is secured, tap Security and tap the type of security
deployed on the network.
Enter the required passwords and security
credentials.
5. Tap Connect to save the information.
The phone will connect to the wireless network (if it's currently within
range). Any credentials that you entered are saved, so you're connected
automatically when you come within range of this network.
To forget a Wi-Fi network
You can make the phone forget about the details of a Wi-Fi network that
you added. For example, if you don’t want the phone to connect to it
automatically or if it’s a network that you no longer use.
1. Turn on Wi-Fi, if it’s not already on, then tap Wi-Fi in the Settings menu.
2. In the Wi-Fi screen, touch and hold the name of the network that you
want to forget.
3. Tap Forget network in the Context menu that appears.
61
Connecting to Networks and Devices
USB Connection
USB connection is a feature that allows your phone to connect to a PC
using a USB Cable.
To select a USB mode for a connection
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings
> Storage > the Menu icon (at the
upper-right corner of the screen) > USB PC connection.
2. Tap Media sync (MTP) or Camera (PTP) to connect to the PC.
NOTE The MTP driver may not be installed on your PC by default. The driver is dependent on
the PC's versions of Windows® and Windows Media Player (WMP).
Using the Status Bar to change the connection mode setting
The Status Bar displays the USB connection icon, when connected via
USB.
When connected via USB, the current USB connection mode also appears
on the Notifications panel. Tap the connection setting to display a screen
where you can change the USB connection mode.
SmartShare
You can use the SmartShare function to conveniently view photos and play
videos (the Gallery app) and listen to music (the Music app).
To enjoy SmartShare
You can stream multimedia content on your phone to another device and
also send files to it.
Play: You can stream your content via TV, Bluetooth speaker, etc.
Beam: You can send your content to Bluetooth devices or SmartShare
Beam-supported LG phones.
NOTE SmartShare requires both Wi-Fi and Bluetooth networks, so when you access
SmartShare, they'll turn on automatically.
62 Connecting to Networks and Devices
1. Access the app that has the content you want to use with SmartShare,
then tap the SmartShare icon , the Share icon , or the Menu icon
(at the upper-right corner of the screen) > SmartShare.
2. Tap Play or Beam.
3. Select the DLNA connected device you want to use. Tap Rescan to find
the device or tap Add device, if necessary.
To enjoy content from nearby devices on your phone
You can play content saved to nearby devices on your phone. Your nearby
devices must be supported by the DLNA function.
To set nearby devices
1. Ensure that your phone and the nearby devices are connected to the
same Wi-Fi network.
2. Set the DLNA device to enable sharing.
63
Calls
Placing and Ending Calls
The Phone app allows you to dial phone numbers manually or make calls
from your phone’s memory. Manually dial calls using the Dial tab. Dial from
your phone’s memory using the Recent calls tab, the Contacts tab, the
Favorites tab, or the Groups tab.
To open the Phone app
From the Home screen, tap the Phone icon (in the QuickTap bar).
Phone app tabs
The Phone app tabs (Dial, Recent, Contacts, Favorites, and Groups) are at
the top of the screen.
Moving between the Phone app tabs
Tap any of the Phone app tabs (Dial, Recent, Contacts, Favorites, and
Groups) at the top of the screen to view that tab. You can also flick
horizontally on the screen to scroll to the other tabs. The current tab is
displayed in white.
Modifying the Phone app tabs
You can rearrange the order of the Phone app tabs and/or delete the
Favorites and Groups tabs.
1. From the Home screen, tap the Phone icon (in the QuickTap bar).
2. Tap the Menu icon (at the upper-right corner of the screen), then tap
Edit tabs.
Drag a tab handle to move it to the position where you want it in
the list.
Tap the Favorites or Groups checkbox (checkmark displays the tab,
no checkmark deletes it from the Phone app tabs bar).
3. When you're finished making changes, tap Save (at the bottom of the
screen).
64 Calls
To place a call by dialing
1. From the Home screen, tap the Phone icon (in the QuickTap bar) to
open the Dial tab of the Phone app.
Touch and hold to enter
the plus ( + ) symbol to dial an
international number.
Delete Key
Tap here to delete incorrect
number(s) (appears after you
begin entering numbers).
Call Key
Tap here to dial the number that
you entered manually.
Dial Tab
Displays the diapad.
Voice Dialer Key
Tap here to dial by saying the
number.
Message Key
Tap here to send a message to
the number that you entered.
Voicemail Key
Tap here to access your
voicemail feature.
2. Use the dialpad to enter the number you want to call.
If you enter a wrong number, tap the Delete Key to erase digits
one by one.
To erase the entire number, touch and hold the Delete Key .
To dial an international number, touch and hold to enter the plus ( + )
symbol. Then enter the international prefix for the country, followed by the
full phone number.
3. Tap the Call Key (on the dialpad) to dial the number that you entered.
Press the Volume Keys (on the back of the phone) to adjust the call
volume.
Use the on-screen buttons to enter additional numbers, place the call
on hold to take another incoming call, add another call, use the
speakerphone, end the call, and other options.
You can use other phone features while the call is underway. If you
open another app, the Call icon appears in the Status Bar for the
duration of the call.
NOTE If you opened other apps while on a call, you'll need to return to the Call screen to end
the call. To return to the Call screen, you can tap the Home Key (in the Touch Keys
65
Calls
bar), then tap the Phone icon (in the QuickTap bar), ortap the Contact's name or
number (at the upper-left corner of the Home screen). You can also drag the Status Bar
down and tap the Call icon on the Notifications panel.
You can make High Definition Voice and Video Calls with this phone when
you add Advanced Calling to your line.
Visit VerizonWireless.com/AdvancedCalling to learn how.
To end a call
Simply tap the End button on the Call screen to end the call.
If you accessed other device functions while the call was in progress, there
are several ways to return to the Call screen to end the call.
Tap the Home Key (in the Touch Keys bar), tap the Phone icon (in
the QuickTap bar), then tap the End button on the Call screen.
Tap the Home Key (in the Touch Keys bar), tap the Call icon (at the
upper-left corner of the Home screen), then tap the End button on
the Call screen.
Drag the Status Bar down, then tap the End call button on the Status
Bar.
NOTE You can also press the Power/Lock Key (on the back of the phone) to end the call, if
you activated this feature in the Call settings menu.
Calling numbers in your phone’s memory
You can place calls using information stored in your phone. Anywhere you
see a Call icon next to a number, tap it to automatically dial it.
Speed dialing
If you set up Speed dials in the Contacts app, you can dial a number by
simply touching and holding the Speed dial number on the dialpad.
From the Home screen, tap the Phone icon (in the QuickTap bar),
then touch and hold the Speed dial number.
Direct dialing
A Direct dial widget is like a speed dial button on your Home screen. Tap it
to automatically call the number you set (for example, your home phone
number).
66 Calls
To place a Direct dial widget on your Home screen
1. Touch and hold an empty area on your Home screen.
2. Tap the Widgets tab (at the bottom of the screen) > Direct dial.
3. Tap the contact in your Contacts list.
TIP You can change the look of each Direct dial widget for easy identification. Touch, hold,
and release the Direct Dial widget, then tap it. Select a theme icon or a photo icon, then
tap OK.
Answering or Rejecting Calls
When you receive a phone call, the Incoming call screen opens with the
caller ID and any additional information about the caller that you’ve saved in
the Contacts list. All incoming calls are recorded in the Recent tab.
To answer a call
If the screen is unlocked, simply tap the Answer icon .
If the screen is locked, swipe the Answer icon in any direction to
answer the call.
If you were already on a call, tap the Answer icon which places the
first call on hold and connects the new call.
NOTE To silence the incoming call ringer, press either of the Volume Keys (on the back of the
phone).
Swipe the Answer
icon in any direction
to answer the call.
Unlocked Screen Locked Screen
Tap the Answer icon
to answer the call.
67
Calls
To ignore a call and divert it to voicemail
If the screen is unlocked, simply tap the Ignore icon .
If the screen is locked, swipe the Ignore icon in any direction to
ignore the call.
The caller is sent directly to your voicemail box to leave a message.
Tap the Ignore
with message
icon to send a
quick message
to the caller
and forward
them to your
voicemail.
Unlocked Screen Locked Screen
Tap the Ignore icon to ignore
the call and send the caller
directly to your voicemail box
to leave a message.
Swipe the Ignore with message icon in
any direction to send a quick message to
the caller and forward them to your
voicemail.
Swipe the Ignore
icon in any direction
to ignore the call.
NOTE To silence the ringer, press either of the Volume Keys (on the back of the phone).
To ignore a call and send a text message
To display the Ignore with message option on the incoming call screen,
enable it in the Settings menu.
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Call > checkmark the Allow ignore with
message checkbox.
If the screen is unlocked, tap the Ignore with message icon .
If the screen is locked, swipe the Ignore with message icon in any
direction.
Tap the text message you want to send in place of answering the call.
NOTE This feature can only be used to send a message to another mobile phone. It's not
applicable to incoming landline calls.
68 Calls
Working With the Recent Tab
The Recent tab records all of the calls you’ve dialed, received, or missed. It
offers a convenient way to redial a number, return a call, or add a number to
your Contacts.
To open the Recent tab
From the Home screen, tap the Phone icon (in the QuickTap bar),
then tap the Recent tab (at the top of the screen).
The Recent tab lists your calls chronologically by phone number. The
number in parenthesis indicates the number of calls recorded for that
phone number.
Recent Tab
Tap to display the
history of all of your
calls. Call Icon
Tap here to call this
phone number.
Viewing call entry details
Open the Recent tab, then tap an entry to view all of the entries for that
phone number. Calls are listed chronologically and each one includes the
call type (received , dialed , and missed ), the date, and the time of
the call.
Filtering your list of calls
To view a specific call list, from the Recent tab, tap the Menu icon (at
the upper-right corner of the screen), then tap Filter. Tap the call type you
want to view.
69
Calls
Tap the Back Key (in the Touch Keys bar) to return to the Recent tab
screen.
To dial a number in the Recent tab
From the Recent tab, tap the Call icon at the right of the call entry.
From the Recent tab, tap the image to the left of the call entry to view all
of the contact's numbers saved in your phone’s memory. Tap a phone
number to dial it.
TIP You can edit a phone number in the Recent tab before you place the call (e.g., to insert an
area code when you're traveling). Touch and hold the entry, then tap Edit number before
call in the Context menu. Edit the number as necessary, then tap the Call Key on
the keypad.
To add a number from the Recent tab to your Contacts
1. Open the Recent tab, then touch and hold the call entry.
2. Tap Add to Contacts in the Context menu.
3. Tap New contact or Update contact and save it as necessary.
Clearing your Recent calls
You can delete the entire list of Recent calls at once or selectively delete
entries.
1. Open the Recent tab.
2. Tap the Menu icon (at the upper-right corner of the screen).
Tap Clear to select entries to remove from the list. Checkmark the
entries to delete, tap Clear, then Yes.
Tap Clear all to remove all of the entries from the list. Tap Ye s to
confirm you want to Clear (at the bottom of the screen), the entire list.
NOTE You can also select a specific number to be deleted. Touch and hold an entry in the
Recent list to open its Context menu. Tap Clear all logs of this number, then tap Yes to
confirm.
70 Calls
Calling Your Contacts
Instead of manually dialing phone numbers using the dialpad, you can use
your Contacts list to dial quickly and easily. You can also quickly call a
contact using Quick Contact or Direct dial icons that you placed on your
Home screen.
If you have contacts on the web, they’re synchronized with your phone
when you first synchronize with your Google™ Account.
To call a contact
1. From the Home screen, tap the Contacts icon (in the QuickTap bar).
2. Tap the contact you want to call.
3. Tap the contact’s phone number you want to call.
To call a favorite contact
1. From the Home screen, tap the Contacts icon (in the QuickTap bar),
then tap the Favorites tab (at the top of the screen).
2. Tap the contact you want to call.
3. Tap the contact’s phone number you want to call.
Instant List
Instant list is displayed on the Dial tab to help you use the information
stored in your phone without needing to search for it first. Once you begin
entering numbers, Instant list displays entries from your Contacts list or
Recent calls that match the sequence you entered.
Sequence matches
Your phone searches for the entered sequence anywhere in the number;
beginning, end, or anywhere in-between. The matching number sequence
is displayed within the number in blue text. The name and type of number
(i.e., Mobile, Work, etc.) associated with the number you entered is
displayed above the dialpad. When there are multiple matches, the Instant
list displays the number of matches in your phone's memory. Tap the
Instant list icon on the right side of the screen to view the entire list of
matching entries. Tap Cancel (at the bottom of the list) to close the list.
71
Calls
Selecting an Instant list entry
Tap an entry in the Instant list to insert it on the dialpad and tap the Call Key
(on the dialpad) to dial it.
Options During a Call
Bluetooth Button
Tap here to switch between a
Bluetooth device and the phone.
The button is blue when the call
is using a Bluetooth device. The
button is gray when there's no
Bluetooth device available.
Mute Button
Tap here to mute the microphone
during a call. The button is blue
when the microphone is muted.
Speaker Button
Tap here to turn the speakerphone
on or off. The button is blue when
it's on.
To mute the microphone
Tap the Mute button on the Call screen.
The button is blue when the microphone is muted.
When viewing the Call screen, you can unmute the microphone by
tapping the Mute button again.
The microphone is unmuted automatically when the call ends.
To turn the speakerphone on or off
Tap the Speaker button on the Call screen.
The button is blue when the speakerphone is on.
When viewing the Call screen, you can turn the speakerphone off by
tapping the Speaker button again.
The speakerphone is turned off automatically when the call ends.
WARNING!
To avoid damage to your hearing, don't hold the phone against your ear when the
speakerphone is turned on.
72 Calls
To switch between a Bluetooth headset and the phone
When a Bluetooth headset is paired and connected to your phone, you can
conduct calls on the headset for hands-free conversation. During a call, you
can opt to use the Bluetooth headset or just the phone.
When using the Bluetooth headset during a call, the Ongoing Call
notification icon is blue in the Status Bar (the icon is green when using the
phone).
Tap the Bluetooth button on the Call screen to switch the call from
the phone to the Bluetooth device, or vice versa.
Managing Multiple Calls
Contact your wireless service provider to find out which call services are
supported.
To switch between current calls
Tap the Swap calls button on the Call screen.
The current call will be placed on hold and you'll be connected with the
other call.
Swap Calls Button
Tap here to switch
between your active calls.
To set up a conference call
Contact your wireless service provider to find out whether they support
conference calls and how many participants you can include.
73
Calls
1. Place a call to the first participant.
2. When you’re connected, tap the Add call button on the Call screen.
3. Enter a phone number on the dialpad.
Use the Phone app tabs (at the top of the screen) to select a saved
number.
OR
Use the keys on the dialpad to manually enter a number.
4. Tap the Call Key (on the dialpad) to place the call.
5. After you’re connected, tap the Merge calls button (on the Call
screen). The participant is added to the conference call.
Merge Calls Button
Tap here to merge the separate
calls into a conference call.
Speaker Button
Tap here to turn the
speakerphone on (or off).
The button is blue when the
speakerphone is on.
Dialpad Button
Tap here to dial another number to
participate in the conference call.
Bluetooth Button
Tap here to switch between a
Bluetooth device and the phone. The
button is blue when the call is using a
Bluetooth device. The button is gray
when there's no Bluetooth device
available.
Mute Button
Tap here to mute the microphone during a call.
The button is blue when the microphone is muted.
Listening to Your Voicemail
When you have a new voicemail message, the Voicemail notification icon
appears in the Status Bar. If you haven’t set up your voicemail number,
or if you need to change it, you can do that in the Call settings.
To listen to your Voicemail
Open the Notifications panel and tap New voicemail.
OR
74 Calls
Tap the Voicemail icon on the Home screen.
OR
From the Home screen, tap the Phone icon (in the QuickTap bar),
then tap the Voicemail Key (on the dialpad).
To set up your Voicemail
Typically, your carrier’s voicemail system guides you through the process of
listening to and managing your voicemail. The first time you call your
voicemail, it also guides you through the process of recording greetings,
setting a password, etc.
1. From the Home screen, tap the Phone icon (in the QuickTap bar).
2. Tap the Voicemail Key (on the dialpad) to dial your voice mailbox.
3. Follow the setup tutorial.
Enter a password.
Record a voice signature and greetings for your voice mailbox.
Airplane mode
Some locations may require you to turn off your phone’s wireless connections
by placing your phone in Airplane mode.
Press and hold the Power/Lock Key (on the back of the phone), then
tap Turn on Airplane mode in the Phone Options menu that appears.
OR
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > the Airplane mode switch (on the right
side of the screen).
OR
Drag the Status Bar downward, then tap Airplane mode (in the Quick
settings bar at the top of the screen).
NOTE Each of these access methods toggle the setting on or off.
75
Web
Chrome
The Chrome app allows you to access the Internet from your phone.
Access and selections within this feature are dependent upon your service
provider. For specific information on Internet access through your phone,
contact your service provider.
NOTES You may incur additional charges for accessing the web and downloading media. For
details, contact your service provider.
Chrome may differ from this user guide due to updates via Play Store.
Browse web pages
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Chrome or tap Chrome (in the QuickTap
bar) on the Home screen.
2. Tap the URL input field to access a specific web page. Enter the web
address (URL) of the web page, then tap (on the on-screen keyboard).
3. Tap the Menu icon (at the upper-right corner of the screen) to access
the Chrome Options menu.
URL Input Field
(address bar)
Tap here to enter a web
address for the webpage
you want to access.
Open Tabs Icon
Tap here to view your open
webpage tabs.
Search the web
When you begin entering text in the URL input field suggestions appear
below the address. Each address suggestion displays one of the following
icons:
The Search icon appears next to searches.
76 Web
The Bookmark icon appears next to bookmarked sites.
The History icon appears next to sites from your browsing history.
The Globe icon appears next to related sites.
You can set the default search engine for the address bar by tapping the
Menu icon (at the upper-right corner of the screen) > Settings >
Search engine.
Search within a webpage
1. From the webpage you want to search, tap the Menu icon (at the
upper-right corner of the screen), then tap Find in page.
2. Type the text you’re looking for in the find bar at the top of the screen.
Matches are highlighted on the page (the current match in orange and
the remaining matches in yellow).
The find bar displays the total number of matches. Tap the up and
down arrows (to the right of the find bar) to go to each match.
Found matches are also indicated in the scroll column along the right
side of the screen. Tap any of the highlights to jump directly to that
match.
Sign in to Chrome
When you sign in to Chrome with your Google Account, you can take
advantage of several time-saving services:
Sync lets you access your Chrome bookmarks, browsing history, and
open tabs from other devices where you’re also signed in.
Chrome to Mobile lets you send webpages from your computer to your
phone with one click.
Auto sign-in helps you sign in to Google services with a touch of a
button. No need to type your username and password.
Browse with tabs
Your phone displays webpages in a tab format allowing you to browse
several webpages simultaneously. Create multiple tabs for the sites you
77
Web
want, then tap the Open tabs icon (at the top right of the screen) to
quickly and easily access them.
Create a new tab
From the Chrome app, tap the Menu icon (at the upper-right corner of
the screen), then tap New tab.
The New Tab page
The following options are available when you create a new tab. These
options, located at the bottom of the screen, help you open the page that
you want quickly.
Most Visited Snapshots of the webpages that you visit the most are
shown here. Just tap a snapshot to visit the site using the new tab you
created. Touch and hold a snapshot to open a Context menu to access
Open in new tab, Open in incognito tab, or Remove.
Bookmarks Icons for sites that you’ve bookmarked are listed here.
Tap a bookmark icon to visit the site using the new tab you created.
Touch and hold a bookmark to open a Context menu to access Open in
new tab, Open in incognito tab, Edit bookmark, and Delete bookmark.
Other devices Chrome tabs that are opened on other devices are
shown here. Tap a page icon to open the same tab on your phone. You
must be signed in to Chrome to sync your open tabs across your
devices.
NOTE When you edit items in the Most Visited and Bookmarks options, it can take up to 15
seconds for open tabs to refresh on other devices.
Working with tabs
Open an Incognito tab (browse in private)
From the Chrome app, tap the Menu icon (at the upper-right corner of
the screen), then tap New incognito tab. When browsing in incognito
mode, your browsing history, cookies, and cache are automatically cleared
once you’ve closed all of your incognito tabs. You still have access to your
usual bookmarks and omnibox predictions. Changes that you’ve made to
your bookmarks are saved.
78 Web
Switch in and out of Incognito mode
1. From the Chrome app, tap the Open tabs icon (at the top right of the
screen).
2. Drag from right to left to bring Incognito tabs to the front.
Drag from left to right to return to your standard browsing tabs.
Switch to another tab
1. From the Chrome app, tap the Open tabs icon (at the top right of the
screen).
2. Your open tabs are stacked vertically. Scroll up or down, then tap the tab
that you want to switch to.
You can also swipe to switch tabs. While viewing an open tab:
Swipe horizontally (left or right) across the toolbar (at the top of the
tab) to quickly switch tabs.
Close your tabs
Close a single tab: Tap the Open tabs icon then tap the X in the
upper-right corner of the tab that you want to close. You can also swipe
the tab to the left or right off of the screen to close it.
Close Incognito tabs: Tap the Open tabs icon . From the stacked
Incognito tabs view, tap the Menu icon (at the upper-right corner of
the screen), then tap Close incognito tabs.
Close all tabs: Tap the Open tabs icon , tap the Menu icon (at the
upper-right corner of the screen), then tap Close all tabs.
NOTE Closing the Chrome app (or even turning the phone off) will not close your open tabs.
Your tabs remain open until you close them.
Download files
1. Touch and hold a download link.
2. Tap Save link in the Context menu that appears.
79
Web
To view downloaded files:
From the Applications screen, tap the Apps tab (if necessary) >
Tools folder
> Downloads .
To open a downloaded file, tap it.
To view earlier downloads, tap the heading date you want to view.
To share downloads, tap the Share icon (at the upper-right corner of
the screen), checkmark the ones to share, then tap Share (at the bottom
of the screen), then choose a sharing method from the list. Complete
the sharing steps as necessary.
To delete downloads, tap the Delete icon (at the top of the screen),
checkmark the ones to delete, tap Delete (at the bottom of the screen),
then Yes to confirm.
To switch the download file sort criteria, tap Date, Name, or Size (at the
upper-left corner of the screen).
To clear files from your download history, tap the List icon (at the top
of the screen) > checkmark the entries to clear, tap Clear, then Yes to
confirm.
Using bookmarks
Bookmarks let you revisit your favorite webpages with one touch.
Create a bookmark
1. While viewing the page you want to set as a Favorite, tap the Menu icon
(at the upper-right corner of the screen), then tap the Favorites icon
(at the top of the Options menu).
2. Edit the bookmark’s name and address, if necessary.
3. By default it will be saved to your mobile bookmarks folder. Tap the
Folder field to change the location (or create a new folder for it).
4. Tap Save (at the bottom of the screen) to save the bookmark.
80 Web
Open a bookmark
1. From the Chrome app, tap the Menu icon (at the upper-right corner of
the screen), then tap Bookmarks (or open a new tab and tap the Favorites
icon at the bottom of the screen).
2. Tap the bookmark you want to visit.
NOTE If you don't see the bookmark, tap the folder you saved it in, or tap the filepath (at the
top of the screen) to access the folder where it was saved.
Edit or delete bookmark
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen), then tap Bookmarks (or open a new tab and tap the
Favorites icon at the bottom of the screen).
2. Touch and hold the bookmark you want to edit or delete.
Tap Edit bookmark. Once you’re finished editing, tap Save.
Tap Delete bookmark.
TIP Sign in to Chrome to sync your bookmarks to your Google Account. Then you can
access them from any device.
Add a webpage to your Home screen
Save time by adding webpages you use frequently to your Home screen as
shortcuts.
1. From the Chrome app, access the webpage you want to add as a
shortcut.
2. Tap the Menu icon (at the upper-right corner of the screen).
3. Tap Add to homescreen.
Chrome Settings
To access the settings specific to the Chrome app:
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen).
2. Tap Settings.
3. Tap the setting you want.
81
Web
BASICS
Google account
All of your Google accounts are displayed. Tap one to set settings that only
apply to that specific account.
1. From the Chrome app, tap the Menu icon (at the upper-right corner of
the screen) > Settings.
2. Tap a Google account to change its settings.
Tap Sync to turn sync on or off, set the items to sync, and Reset Sync
(at the bottom of the screen).
Checkmark the Chrome to Mobile checkbox to send webpages from
your computer to your mobile device(s).
Checkmark the Auto sign-in checkbox to sign in to Google sites
automatically.
Tap Disconnect Google Account (at the bottom of the screen).
Search engine
Sets your default search engine for searching the Internet.
1. From the Chrome app, tap the Menu icon (at the upper-right corner of
the screen) > Settings > Search engine.
2. Tap the search engine you want to use.
Autofill forms
Use the autofill feature to fill in web forms with a single tap.
Enable or disable autofill
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen) > Settings > Autofill forms.
2. Tap the Autofill forms switch (at the top of the screen) to toggle it
On (blue) or Off (gray).
82 Web
Manage your autofill entries
From the Chrome app, tap the Menu icon (at the upper-right corner of
the screen) > Settings > Autofill forms.
Tap Add profile to add your personal information such as company,
address, etc.
Tap Add credit card to add a new credit card.
Edit an entry by tapping the profile in the list. Tap Save at the bottom of
the screen when you’ve finished updating.
Delete an entry by tapping the profile in the list. Tap Delete (at the
bottom of the screen) to remove the entry.
NOTE Access the Privacy setting to clear your autofill entries.
Save passwords
You can let Chrome remember your passwords for the sites you use.
Enable or disable saving passwords
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen) > Settings > Save passwords.
2. Tap the Save passwords switch (at the top of the screen) to
toggle it On (blue) or Off (gray).
Manage password prompts
If you enable Chrome to save your passwords, you’ll get a prompt every
time when you sign in to a new website.
Tap Yes if you want Chrome to remember your sign-in credentials for
that site. Chrome will automatically complete the sign-in fields for you
when you visit the website again.
Tap Never if you don’t want Chrome to save your username and
password for the website you accessed.
83
Web
Change password setting sites
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen) > Settings > Save passwords.
2. Tap the site that you want to remove from the list.
Tap a site in the Saved Passwords list to move it to the Never saved
list.
Tap a site in the Never saved list to move it to the Saved Passwords
list.
3. Tap Delete.
Home page
Sets your default home page.
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen) > Settings > Home page.
2. Tap the Home page switch (at the top of the screen) to toggle it
On (blue) or Off (gray).
ADVANCED
Privacy
Set your search privacy settings
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen)> Settings > Privacy.
2. Configure your privacy settings as necessary.
Clear your browsing data
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen)> Settings > Privacy.
2. Tap CLEAR BROWSING DATA (at the bottom of the screen).
3. Checkmark the items you want to clear, then tap Clear.
84 Web
Accessibility
Adjust text size on webpages
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen)> Settings > Accessibility.
2. Drag the Text scaling slider along the bar to adjust the text size scaling.
The Preview box displays how text will appear on webpages.
Force enable zoom
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen)> Settings > Accessibility.
2. Checkmark the Force enable zoom checkbox to override a site's zoom
functionality and allow zooming in or out.
Manage Content settings
Adjust the type of content that websites can show and the information
they can use to enhance your web experience.
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen)> Settings.
2. Tap Content settings.
Accept cookies: Checkmark to enable websites to store small files on
your phone in order to save your preferences on websites or keep you
signed in. Remove the checkmark to prevent webpages from storing
cookies on your mobile device.
Enable JavaScript: Checkmark to enable JavaScript. Many web
developers use JavaScript to make their websites more interactive.
Sites may function correctly only if they can run JavaScript on your
mobile device.
Block pop-ups: Checkmark to prevent websites from showing
additional windows automatically.
Protected content: Tap to change this setting. Tap the switch (at the
top of the screen) to toggle it On or Off. On allows websites to be
able to authenticate your device to ensure it’s authorized to play
85
Web
premium protected videos. You can also reset your device credentials
from this setting.
Google translate: Tap to change this setting. Tap the switch (at the
top of the screen) to toggle it On or Off. On allows Google to translate
pages written in other languages using Google translate. You can also
reset your translate settings from this setting.
Location settings: Tap to set your location access used by websites.
Website settings: Tap to clear location permissions or local data
stored on your phone for a specific site.
Preload webpages
Chrome helps you open webpages faster by predicting where you might go
next on the page. The browser preloads the page’s data in the background,
so the page can open immediately if you tap its link. Keep in mind this
feature may use a large amount of data on your phone, but you can always
control when Chrome uses this feature:
1. From the Chrome app, tap the Menu icon (at the upper-right corner
of the screen)> Settings > Bandwidth management.
2. Tap Preload webpages.
3. Select an option:
Always: Chrome will preload webpages no matter how you’re
connected (e.g., mobile data, Wi-Fi, etc.).
Only on Wi-Fi: Chrome will preload webpages only if you’re not using
mobile data.
Never: Chrome won’t preload webpages.
Reduce data usage
1. From the Chrome app, tap the Menu icon (at the upper-right corner of
the screen) > Settings > Bandwidth management.
2. Tap Reduce data usage.
86 Web
3. Tap the Switch icon (in the upper-right corner of the screen) to
toggle it On or Off. On compresses pages you visit before downloading
them and enables Chrome’s Safe Browsing system to protect you from
phishing, malware, and harmful downloads.
NOTE SSL and Incognito pages will not be compressed before downloading. This feature may
interfere with access to premium data services provided by your carrier.
About Chrome
Allows you to view the Application version, Operating system, Blink
version, JavaScript version, Executable path, Profile path, and Legal
information.
1. From the Chrome app, tap the Menu icon (at the upper-right corner of
the screen) > Settings > About Chrome.
87
Communication
Contacts
The Contacts app allows you to store names, phone numbers, and other
information in your phone’s memory. Entries are listed alphabetically. You
can scroll through the list, or tap the Favorites tab or Groups tab (at the top
of the screen).
Use the Contacts app to add, view, and communicate with your friends,
acquaintances, and associates.
To open your Contacts app
From the Home screen, tap
the Contacts icon
(in the QuickTap bar).
NOTE You can also tap the Contacts tab (at the top of the screen) from the Phone app.
If you have a new phone and haven’t added any contacts yet, the Contacts
app will display hints on how to start adding contacts to your phone.
Contacts list
When you open the Contacts app, your contacts list is displayed. The
alphabet is displayed vertically along the right side of the screen with a blue
bar that indicates where you are in the list.
In case of Emergency contacts is displayed above your list of contacts. Add
up to 5 emergency entries from your contacts list. These are entries that
someone can contact on your behalf in the event of an emergency,
whether or not the phone is locked.
To add ICE entries
1. From the Home screen, tap the Contacts icon (in the QuickTap bar).
2. Tap In Case of Emergency contacts (at the top of the screen).
3. Tap the Add entry icon (in the lower-left corner of the screen).
4. Checkmark the entry (or entries) to add to your ICE list, then tap Done
(at the bottom of the screen).
88 Communication
ICE Information
In addition to your emergency contacts, you can enter personal information
about you (such as medical record number, allergies, medications, special
instructions, etc.) that can be accessed in case of an emergency. To add
your personal information:
1. From the emergency contacts screen, tap the Information icon (at
the bottom center of the screen).
2. Tap the Add icon (at the upper-right corner of the screen), enter your
information, then tap Save (at the bottom of the screen).
To search for a contact
1. From the Home screen, tap the Contacts icon (in the QuickTap bar).
2. Tap the Search contacts box and enter the contact name using the
keyboard.
Searching your online contacts simultaneously
You can search for your contacts simultaneously from all of your online
accounts.
To set your phone to search simultaneously, open the Contacts app, tap the
Menu icon (at the upper-right corner of the screen) > Settings >
checkmark the Online search checkbox.
To open a list of your favorite contacts
Open the Contacts app and tap the Favorites tab (at the top of the
screen).
Favorites lists the contacts you’ve designated as your favorites (at the
top of the screen) and entries you’ve contacted frequently (at the bottom
of the screen). While viewing the Favorites tab, tap the Menu icon (at
the upper-right corner of the screen) then tap Grid view (or List view) to
change how your favorites are displayed.
89
Communication
To open your groups list
Open the Contacts app and tap the Groups tab (at the top of the
screen).
Groups displays your contacts by category (at the top of the screen) and
your accounts (at the bottom of the screen).
Resizing the entries
While viewing your Contacts (contacts list, favorites list, or groups), place
two fingers on the screen, then spread them apart to increase the size of
the entries for easier viewing. Pinch in to decrease the size and see more
entries on the screen.
To view details about a contact
1. Open the Contacts app.
2. Tap the contact whose details you want to view.
3. The information you entered for the contact is displayed. The following
options are available (depending on the types of information saved).
The Dial icon places a call to the number.
The Message icon starts a message.
The Email icon starts an email.
Tap the
Menu icon (at the upper-right corner of the screen)
to
access the following menu options: Delete, Share, Join, Export, Add
to Home screen, and All calls to voice mail.
90 Communication
Adding Contacts
You can add contacts on your phone and synchronize them with the
contacts in your Google™ Account, Microsoft Exchange account, or other
accounts that support syncing contacts.
Since your contacts can come from a variety of sources, the Contacts app
attempts to join new information with existing similar contact entries, to
create a single entry. You can also manage that process manually by joining
or splitting entries.
To add a new contact
1. Open the Contacts app.
2. Tap the New contact icon (to the right of the search box).
3. If you have more than one account with contacts, select the account
where you want to save the contact by tapping the Accounts field (at the
top of the screen).
NOTE To change the account later, edit the entry, tap the account (at the top of the screen),
then tap the account you want it assigned to.
4. Enter the contact’s name.
5. Tap a category of contact information, such as phone number or email
address, to enter that kind of information about your contact.
Tap a category’s Add new icon to add more than one entry for that
category. For example, in the phone number category, enter a work
number and add a home number. Tap the label field to the right of the
entered information to open a drop-down menu of preset labels. For
example, HOME or WORK for a phone number.
Tap Add another field (at the bottom of the screen), to add
additional fields including Phonetic name, Organization, IM, Notes,
Nickname, Website, and Events.
6. Personalize the contact entry.
Set a ringtone to identify calls from this contact.
91
Communication
Set the color of the notification LED (located at the upper-left corner
of your phone) to identify notifications from this contact.
Tap the Picture frame icon to select a picture to identify the name
in your list of contacts and in other apps.
NOTE You can also set the color of the notification LED for the contact.
7. When you’re finished, tap Save.
Editing a Contacts entry
1. Open the Contacts app, then tap the contact entry you want to edit.
2. Tap the Edit icon (at the top of the screen).
3. Edit the entry as needed, then tap Save (at the bottom of the screen).
Favorites Contacts
The Favorites tab contains a short list of the contacts you communicate
with most often.
Adding or removing contacts in your Favorites list
1. Open the Contacts app, then tap a contact to view its details.
2. Tap the star at the top right of the screen.
A gold-colored star indicates a Favorite.
A gray-colored star indicates a normal contact.
Contacts Options menu
From the Contacts app, tap the Menu icon (at the upper-right corner of
the screen) to access the Options menus:
From the Contacts tab: Cloud, Delete, Share, Send message, Send
email, Speed dial, Manage contacts (Copy contacts, Import/Export,
Join Contacts), Edit tabs, and Settings.
From the Favorites tab: Add favorites, Remove favorites, Share, Send
message, Send email, List/Grid view, Hide frequents, Edit tabs, and
Settings.
92 Communication
From the Groups tab: New group, Delete, Share, Change order, Edit
tabs, and Settings.
Joining and separating contacts
When you have two or more entries for the same contact, you can join
them into a single entry. You can also separate contacts that were joined.
1. Open the Contacts app, then tap the contact entry you want to join with
another entry.
2. Tap the Menu icon (at the upper-right corner of the screen).
3. Tap Join.
4. Tap a suggested entry (at the top of the screen).
Once entries have been joined, Separate is included in the Options menu
to allow you to separate the joined entries.
1. Open the Contacts app, then tap the contact entry you want to separate.
2. Tap the Menu icon (at the upper-right corner of the screen).
3. Tap Separate.
4. Tap Ye s (in the dialog box).
Setting Speed Dial
1. Open the Contacts app, then tap the Menu icon (at the upper-right
corner of the screen).
2. Tap Speed dial.
3. Tap the speed dial number to assign.
4. Tap the Contact entry.
Setting Speed Dial for contact entries with multiple saved numbers
When you use the Menu icon (at the upper-right corner of the screen) to
set a speed dial, the default number is automatically selected. If you
choose the same entry for a speed dial again, the next saved number is
automatically set for the speed dial.
93
Communication
The Speed dial icon in the contact entry allows you to set speed dials
for selected phone numbers.
1. From the contact entry (either when creating it or while editing it later),
tap the Speed dial icon to the right of the phone number you want to
set with a speed dial.
2. Tap the speed dial number to assign to it.
3. Tap Save (at the bottom of the screen).
Transfer type
When you want to send your contacts entries, you can combine them all
into one file or you can send separate vCard files.
To set the transfer type, from the Contacts app, tap the Menu icon (at
the upper-right corner of the screen) > Settings > Transfer type.
Send as one file: This setting combines all of your contacts into one file.
It allows a faster transfer, but some devices can't receive contact
information sent using this option.
Send separately: This setting sends each contact as a separate vCard
file. It allows all devices to receive your files.
Communicating With Your Contacts
The Contacts app shares information with many other apps allowing you to
quickly and easily initiate communication with your saved entries.
General communication
1. Tap a contact to view the entry details (from the Contacts tab, the
Favorites tab, the Groups tab, or the Recent tab).
2. Tap the icon corresponding to the type of communication you want to
start.
The Dial icon places a call to the number.
The Message icon starts a message.
The Email icon starts an email.
94 Communication
NOTE The communication icons displayed depend on the types of information you've saved for
the contact.
Quick Contact for Android
1. Tap a contact to view the entry details (from the Contacts tab, the
Favorites tab, the Groups tab, or the Recent tab).
2. Tap the contact’s picture on the left side of the entry to display the Quick
Contact icons.
3. Tap the icon corresponding to the type of communication you want to
start (the Dial icon , the Messages icon , the Email icon ).
NOTE The icons displayed depend on the types of information you've saved for the contact.
Messaging
Three apps are preloaded on your phone that allow you to send messages.
The Messaging app , the Message+ app , and the Hangouts app .
You can set any of these as your default messaging app.
To open the Messaging app
From the Home screen, tap the Apps icon
(in the QuickTap bar) > the
Apps tab (if necessary) >
Messaging .
NOTE You must set the Messaging app as the default messaging app in order to use it. From
the Home screen, tap the Apps icon > Settings > More... > Default message
app > Messaging.
Using the Messaging app
To use the Messaging features, open the Messaging app, tap the
information box (at the top of the screen) to set it as your default
messaging app, then tap OK.
Tap the New message icon (at the top right of the screen) to start a
new text or multimedia message.
Tap here to create a new message.
95
Communication
Tap an existing message thread to open it.
NOTE Pinch in (or spread apart) on your list of messages to resize it for easier viewing or
navigation.
To delete a message thread from the Messaging window
1. Touch and hold the message thread.
2. Tap Delete in the Context menu that opens.
3. Tap Ye s to confirm you want to delete the message thread.
To send a text message
1. Open the Messaging app (set it as your default messaging app, if
necessary), then tap the New message icon (at the top right of the
screen).
2. Enter the recipient(s) in the To box.
Tap the Contacts icon (to the right of the To box), then select one
or more entries from your Contacts list.
Enter a name or number, then select a suggestion from your Contacts
list (displayed below the To box).
Enter a number manually for phone numbers not in your Contacts list.
3. Tap the text field, then enter your message.
A character counter is displayed to the right of the message field to let
you know how many more characters you can type and also the number
of pages in the message.
Contacts icon
Tap here to enter the recipient(s) by
selecting from entries in your
Contacts.
To field
Tap here to enter the
recipient(s) manually.
QSlide icon
Tap here to open the
Messaging app in a
QSlide window.
Message field
Tap here to enter
your message.
Attachment icon
Tap here to add an attachment to
your message.
Character counter
Displays the number of characters
entered and the amount remaining.
96 Communication
If you tap the Back Key (in the Touch Keys bar) while composing a
message, it’s automatically saved as a draft. The Draft icon on the
right side of the message thread indicates a pending draft message to
the recipient. Tap the message to resume composing it.
4. Tap the Send button (on the right side of the screen) to send the
message.
Your message is displayed and responses appear in the same window,
creating a message thread with that contact.
To create and send a multimedia message
1. Open the Messaging app (set it as your default messaging app, if
necessary), then tap the New message icon (at the top right of the
screen).
2. Enter the recipient(s) in the To field.
Tap the Contacts icon (to the right of the To field), then select one
or more entries from your Contacts list.
Enter a name, number, or email address, then select a suggestion
from your Contacts list (displayed below the To field).
Enter a number or email address manually.
3. Tap the text field, then enter your message.
4. Tap the Menu icon (at the upper-right corner of the screen) > Add
subject to add a message subject.
The subject text appears above the body text in bold letters.
5. Tap the Attachment icon to open a dialog box where you can choose
the type of media file to attach to the message.
Tap Picture to select a picture from your Gallery.
Tap Take photo to take a photo and attach it.
Tap Video to select a video from your Gallery.
Tap Record video to record a video and attach it.
Tap Audio to select an audio file.
97
Communication
Tap Record voice to record an audio message and attach it.
Tap Location to select a map location to send.
Tap Contact to select either vCard or text to attach.
Tap Schedule to select an event to send.
Tap Slide to assemble up to 10 items (photos, videos, audio, and/or
text) to attach to your message.
Tap Draw to draw and attach an image like QuickMemo+.
NOTE To delete an attachment, simply tap the Delete icon on the attached file.
6. Tap the Send MMS button (on the right side of the screen) to send the
message.
To send a group message
1. Open the Messaging app (set it as your default messaging app, if
necessary), then tap the New message icon (at the top right of the
screen).
2. Add the recipients, as necessary (from your Contacts or manual entry).
3. Select how the message will be sent, by Group Conversation or
Individual Messages.
Tap the Group Conversation button (below the recipients) to allow all
of the recipients to be viewed by each other so they can respond to
you and the group. The message is sent as a multimedia message
(MMS).
Tap the Individual Messages button (below the recipients) so that
none of the recipients can see the other recipients (similar to BCC).
Each individual can only respond to your message.
NOTE Tap the Help icon (on the right side of the screen) to view information regarding
using these buttons.
4. Complete the message as necessary, then tap the Send to all button (on
the right side of the screen).
98 Communication
Using Direct message
A Direct message widget is like a speed dial button to send a message. If
you placed a Direct message widget on your Home screen, simply tap the
contact’s Direct message widget to automatically start a message to that
contact.
Receiving and viewing messages
If you’re working in a message window, messages that you receive from
that contact are displayed. Otherwise, you receive a new message
notification and a new message icon appears in the Status Bar. When
you tap the new message notification, the Message screen opens where
you can reply to the message. If the New message pop-up setting is
activated, you’ll receive a pop-up notification on the current screen which
you can use to directly reply.
If the Auto-retrieve setting isn’t checkmarked, tap Download (at the bottom
of the screen) to view the full message.
If the message contains a media file, tap the Play button to view, watch, or
listen to it. Touch and hold the media file to open a Context menu with
additional options.
To respond to messages you receive
While viewing the received message, tap the text field at the bottom of the
screen, complete your response as necessary, then tap the Send button
(on the right side of the text field).
Changing Messaging Settings
To change the Messaging settings, open the Messaging app, tap the
Menu icon (at the upper-right corner of the screen) > Settings.
Storage
Delete old messages: Checkmark to allow the phone to delete older
messages in a thread when the Text message limit or Multimedia
message limit is reached. No checkmark keeps all messages.
99
Communication
Text message limit: Tap to set the number of text messages to save per
thread.
Multimedia message limit: Tap to set the number of multimedia messages
to save per thread.
Attachment storage: Sets where to store your attachments. Choose
Internal storage or SD card.
Text message
Delivery reports: Checkmark to allow your phone to receive delivery
reports for the messages you send.
Manage SIM card messages: Tap to manage messages stored on your
SIM card.
Multimedia message
Delivery reports: Checkmark to allow your phone to receive delivery
reports for the multimedia messages you send.
Allow delivery reports: Checkmark to send a delivery report when it’s
requested.
Auto-retrieve: Remove the checkmark from to download only the heading
of multimedia messages, so you can manually download the whole
message when you’re ready. This is useful for controlling how much data
you download.
Roaming auto-retrieve: Checkmark to automatically retrieve messages
while roaming.
Priority: Tap to set your multimedia message priority. Choose from Low,
Normal, and High.
Group Conversation
Group Conversation: Checkmark to allow everyone to reply to everyone in
the group conversation.
Help: Information for group conversation settings.
100 Communication
Conversation theme
Sets how your conversations are displayed. Tap the Wallpaper tab to
choose the conversation background. Choose from the 6 options provided,
a photo from your Gallery, or take a picture to use. Tap the Bubble tab to
choose the conversation style. Choose from the 6 options provided.
Notification
Notifications: Checkmark to allow your phone to receive a notification in
the Status Bar whenever you receive a new message.
New message pop-up: Checkmark to show a pop-up when new messages
are received which allows you to directly respond in the pop-up window.
Preview: Checkmark to preview message contents when a new message
is received.
Notification sound: Tap to select the ringtone to sound when you receive a
new message notification.
Vibrate: Tap to set when the phone will vibrate for a new message
notification. Choose from Always, While in vibrate only mode, and Never.
Repeat alert: Tap to set how often the phone will repeat the alert for unread
messages. Choose from Every 2 min, Every 5 min, and Never.
Send message with Enter key
Tap to set when the Enter Key (on the on-screen keyboard) will send
your composed message. Choose from Always, When connecting to
Bluetooth keyboard only, and Never.
NOTE To restore all of the settings back to their default values, tap the Menu icon (in the
upper-right corner of the screen) to access Restore default settings.
Text Link display
Checkmark to view Text Link icons that indicate apps related to the
message content.
101
Communication
Email
The Email app allows you to read email from services other than Gmail™.
The following account types are supported: Microsoft Exchange, Windows
Live Hotmail, Yahoo! Mail, Gmail, AOL Mail, Verizon, and other accounts.
Email icons
Email Setup Wizard: Yahoo Email Setup Wizard: Microsoft
Exchange
Email Setup Wizard: AOL Email Setup Wizard: Other
Email Setup Wizard:
Outlook.com Mail message received
Email Setup Wizard:
Verizon.net
Mail message sending or
receiving failed
To open the Email app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Email or tap the Email icon directly from
the Home screen.
The first time you open the Email app, a setup wizard opens to help you
add an email account. After the initial setup, the Email app displays the
contents of your Inbox.
The Accounts list
The Accounts list displays all of your email accounts.
Open the Email app. Tap the Accounts List icon (at the top of the
screen) to display a drop-down list of all of your email accounts.
Each account in the Accounts list displays the number of unread mail.
Tap an account to view its Inbox.
The account from which you send email by default is indicated by a red
vertical line on the left side of the account when viewing your combined
accounts.
102 Communication
NOTE While viewing the combined list of your email messages, default email account
messages are indicated by a vertical red line along the left side of the list.
Using the Email app
Tap the Compose icon (at the upper-right corner of the screen) to
compose a new message.
Tap the Accounts List icon (at the top of the screen) to switch
between your email accounts.
Tap the Select all icon (at the upper-left corner of the screen) to select
all of your messages. Then you can tap Mark as read/unread, Move to,
or Delete (at the bottom of the screen).
Tap the checkbox next to a message, then you can tap Mark as unread,
Move to, or Delete (at the bottom of the screen).
Tap the Favorite icon next to an email message to designate it as an
important or favorite message.
Touch and hold an email entry to open a Context menu to access Reply,
Reply all, Forward, Delete, Move to, and Mark as unread (read
messages have a gray background).
Tap the Menu icon (at the upper-right corner of the screen) to open
the Options menu to access QSlide, Refresh, Folders, Sort by,
Downloads, and Settings.
Tap the QSlide icon (at the top of the screen) to open the Email app in
a QSlide window.
Message search
Tap the Search icon
(at the top of the screen), enter the text you’re
looking for, then tap the Search icon on the on-screen keyboard.
Reading Your Email
You can read your email from the Inbox, or from other folders within each
individual account. Tap a message entry to open it.
NOTE If you enable the Auto-rotate screen setting, the Email app is displayed in a split-screen
format when the phone is held horizontally. Your Inbox (or any other selected folder) is
103
Communication
displayed on the left side of the screen. Tap an email to open and display its contents on
the right side of the screen.
To read an email
1. Open the Email app, then tap the Accounts list icon (at the top of the
screen).
2. Tap an account to display that account’s Inbox.
Tap the Menu icon (at the upper-right corner of the screen), then
tap Folders. The account’s folder list is displayed. Tap one to change
folders.
NOTE When new email arrives, a notification appears in the Status Bar. Drag the Notifications
panel downward and tap the email notification.
Email settings
Open the Email app, tap the Menu icon (at the upper-right corner of the
screen), then tap Settings.
General settings
Set default account: Tap to select which email account to designate as
your default account.
Select download storage: Tap to set download storage location to
Internal storage or SD card.
Email preview: Tap to set how many lines of email text to download on
your phone as a preview.
Conversation view: Checkmark to view email messages sent or
received with the same subject in one thread.
Split view: Checkmark to display your email list on the left and an open
email message on the right when the phone is held in landscape
orientation.
Load linked images: Tap to select when you want to load linked images.
Ask before deleting: Checkmark if you want to be asked before deleting
email.
Auto-advance: Tap to select which screen to display after deleting or
moving emails.
104 Communication
Resize image: Tap to select the default size for an image attached while
composing.
VIP settings: Tap to set Notifications, Sound, and Vibrate for VIP lists.
Trusted certificates: Tap to view the list of trusted certificates that you
added.
ACCOUNTS
Tap an account to access settings specific to that email account including:
DISPLAY NAMES
Account name: Tap to change the name to easily identify the account.
Your name: Tap to change your name displayed with your sent email.
Use signature: Checkmark to send a signature with your email from
this account.
Signature: Tap to change the signature sent with your email from this
account.
SYNC, SEND & RECEIVE
Update schedule: Tap to choose the schedule for updating email.
Folders to sync (for Exchange accounts): Tap to select which folders
you want to sync.
Days to sync email: Tap to select how many days you want to sync
email for.
Message format (for Exchange accounts): Tap to set which format
you want to receive email in.
Message size limit: Tap to set the maximum message size your
phone will receive and display automatically. To view a message that
exceeds the limit you set, tap Load full message at the bottom of the
Inbox screen.
Delete from server: Tap to set when to delete files from the server.
File size to download over Wi-Fi: Tap to select the size limit for
downloading files over Wi-Fi.
Accounts: Tap to access your accounts and sync information.
105
Communication
Calendar events to sync (for Exchange accounts): Tap to select how
long you want to sync your Exchange Calendar events.
Always Cc/Bcc me: Tap to automatically insert your mail address in
the Cc field or the Bcc field (or select Off) when you compose an
email.
Out of office settings (for Exchange accounts): Tap to configure your
out of office message.
Security settings: Tap to set digital signatures and encryption to
secure your email.
Corporate directory (for Exchange accounts): Tap to search for
recipients using the Exchange account's online directory.
Server policy (for Exchange accounts): Tap to view the current server
policy.
NOTIFICATIONS SETTINGS
Notifications: Checkmark to display new email notifications.
Notifications sound: Tap to set the sound when you receive a new email
notification.
Vibrate: Tap to set when the phone will vibrate for a new email
notification.
SERVER SETTINGS
Exchange server settings (for Exchange accounts): Tap to manually
change your Exchange server settings.
Incoming server settings: Tap to view and/or modify your incoming
server settings.
Outgoing server settings: Tap to view and/or modify your outgoing
server settings.
REMOVE ACCOUNT
Remove account: Tap to remove the account.
106 Communication
To add an account
From the Email app, tap the Menu icon (at the upper-right corner of
the screen) > Settings > Add account. Then, configure the new email
account settings as necessary.
107
Communication
Voicemail
The Voicemail app allows the management of voicemail directly from the
phone rather than accessing voicemail via traditional methods.
Voicemail can display a list of your messages allowing you to choose which
message(s) to listen to or delete, without having to dial into your mailbox
and listen to voice instructions or prior messages.
To be able to use Voicemail
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Verizon folder > Voice Mail or tap Voice
Mail directly on the Home screen.
NOTE Listening to voicemail and setting up your voicemail service depends on subscription to
the visual mail service. When you tap the Voicemail Key on the dialpad, and you've
subscribed to the visual mail service, the Visual Voicemail app will be launched. If you're
not subscribed, you'll be dialed into your traditional voicemail box.
2. The first time you access the Voicemail app, you'll have to subscribe to
the Visual Voicemail service to be able to use it.
3. After subscription to the Visual Voicemail service, you'll be prompted to
enter the password. To change the password, call voicemail (dial *86).
4. After entering the password, your voicemail entries will be displayed in
your Inbox.
While viewing the voicemail list, you can select an entry (see step 5). For
additional options, tap the Menu icon (at the upper-right corner of the
screen).The following options are available: Search, Save, Set as heard,
Play all unheard, Sort by, Saved Voice Mail, Refresh, Settings,
Subscribe to Premium, and End Premium Free Trial.
5. Tap a voicemail entry to listen to it. Then you can tap Call back, Save,
Delete, or Speaker.
6. If you decide to reply with a voicemail or forward it, record a message.
The buttons at the bottom of the screen allow you to record, stop,
re-record, or cancel the message.
108 Communication
Gmail
When you open the Gmail app, the most recent conversations are
displayed at the top of your Inbox list. All of your conversations are
displayed in your Inbox unless you delete, archive, or filter them.
To open the Gmail app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Google folder > Gmail or tap Google folder
> Gmail on the Home screen.
Your Gmail Inbox
The current Google Account is displayed in the header at the top of the
Inbox. If you have more than one account, you can switch accounts to view
the messages in each Inbox.
Conversations with new messages are displayed with bold subject lines. To
read a message in a conversation, tap its subject line text.
A gray background indicates a read message.
indicates that you were copied on this message.
indicates that this message was sent directly to you.
The letter icon (or contact photo) next to a Gmail message allows you to
select it and choose an action from the icons at the top of the screen.
The Favorite icon next to a Gmail message allows you to designate it as
a favorite message.
Gmail Inbox icons
Use the following icons (in the header at the top of the screen) while
viewing your Gmail Inbox:
Accounts and labels: Tap to change to another account or label.
Compose: Tap to begin a new Gmail message.
Search: Tap to search within your Gmail messages.
Menu options: Tap to access Refresh and Label settings.
NOTE You can also drag the screen downward to refresh and check for new email.
109
Communication
Message search
Tap the Search icon (in the Inbox header at the top of the screen), enter
the text you’re looking for, then tap the Search icon on the on-screen
keyboard.
Adding another Google Account
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Add account > Google. Enter your Google
Account information, as necessary.
To switch accounts
Gmail displays conversations and messages from one Google Account at a
time. If you set up more than one Google Account on your phone, you can
easily switch between them.
From your Gmail Inbox, tap the current account (at the upper-left corner
of the Inbox header), then tap the account that contains the email you
want to read.
NOTE The number to the right of the selected Google Account indicates the number of unread
messages you have in that account.
Gmail Inbox
Accounts
Tap here to open a
list of account
choices and
account labels.
110 Communication
Navigating in the Gmail app
While viewing your Inbox:
Swipe the screen up and down to scroll through your list of messages.
Tap the Compose icon (in the header at the top of the screen) to
start a new Gmail message.
Tap the Search icon (in the header at the top of the screen) to search
within the Gmail app.
Swipe a Gmail message off the screen to the left or right to quickly and
easily archive the message. Tap Undo to restore it to your Inbox.
Tap the letter icon (or contact photo) to the left of one or more
messages, then tap the Delete icon (at the top of the screen) to
delete the selected messages.
Tap the letter icon (or contact photo) to the left of one or more
messages, then tap the Menu icon (at the upper-right corner of the
screen) to select Move to, Change labels, Add star, Mark important,
Mute, Report spam, or Report phishing.
While viewing a message, swipe the screen left and right to scroll through
all of your messages and use the icons in the header at the top of the
screen:
Tap the Gmail icon to return to your Gmail Inbox.
Tap the Delete icon to move the email to the trash folder.
Tap the Unread icon to return the message to an unread state.
Tap the Change labels icon to view another label.
Tap the Menu options icon to access Move to Inbox, Mark
important (or not important), Print all, Report spam, Report phishing,
Settings, Send feedback, and Help.
If you’re viewing a message or another label, tap the Back Key (in the
Touch Keys bar) until you return to your Inbox.
111
Communication
Reading Your Messages
From your Gmail Inbox, tap a conversation that contains the message you
want to read.
The conversation opens to the first new (unread) message, or to the first
starred message, if you’ve previously starred a message in the
conversation.
Tap the Contact's
picture to open
Quick Contact.
Tap to set labels
for the message to
help organize your
messages.
Gmail Inbox Header
Gmail Message Header
While viewing a message, you can tap the message action icons on the
Gmail Inbox header or the message header to access the following options:
Gmail Inbox header icons
The Gmail Inbox header icons include the Gmail Inbox icon , the Archive
icon , the Delete icon , the Read/Unread icon , and the Menu
options icon .
Gmail message header icons
Tap the Contact’s picture to open the Quick Contact options.
Tap the Favorite icon to mark it as a favorite.
Tap the Reply icon to reply to the sender.
Tap the Menu options icon to reply to all, forward the message, or
print the message.
112 Communication
To reread a message
When you open a conversation, messages that you’ve already read are
minimized into a tab that indicates the number of hidden messages.
1. From your Gmail Inbox, tap the conversation you want to view.
2. Tap the contact name to open that message.
While reading a message you can tap the Unread icon (in the Gmail
Inbox header at the top of the screen) to return a read message to the
unread state. For example, to remind yourself to read it again later.
Composing and Sending a Message
You can compose and send a message to people or groups with Gmail
addresses or other email addresses.
To compose and send a message
1. From the Home screen, tap
Google folder
> Gmail > the
Compose icon (in the Gmail Inbox header at the top of the screen).
NOTE If you set up more than one Google Account on your phone and want to send the
message from a different Google Account, tap the current Google Account (at the top of
the screen), then tap the account you want to use.
2. Enter a recipient’s address.
As you enter text, matching addresses are offered from your Contacts
list. You can tap a suggested address or continue entering text to enter a
new one.
3. Tap the Menu icon (at the upper-right corner of the screen), then tap
Add Cc/Bcc to copy (normal or blind copy) recipients, if necessary.
4. Enter a subject for the message in the Subject field.
5. Enter your email text in the Compose email field (below the Subject).
6. Tap the Menu icon (at the upper-right corner of the screen), then tap
Attach file if you want to add an attachment to your Gmail message.
7. Tap the Send icon (at the top of the screen) to send your message.
NOTE If you aren't ready to send the message, tap the Menu icon (at the upper-right corner
of the screen), then tap Save draft.
113
Communication
Replying to or Forwarding a Message
Continue an email conversation by replying to a message or by forwarding
it without changing the Subject text. Change the Subject text to start a new
conversation.
NOTE The conversation text and previous messages are also included in your reply (or
forwarded) message.
To reply to or forward a message
1. Open the message you want to reply to or forward.
2. On the message header, tap the Reply icon or tap the Menu icon ,
then tap Reply all or Forward.
Add others to an ongoing conversation by replying to all and then
adding the new person’s address(es) to the reply.
3. Compose your Gmail message as necessary.
4. Tap the Send icon (at the top right corner of the screen) to send your
Gmail message.
NOTE You can change the message action after you've started the message. Simply tap the
current action (at the top left of the message header), then tap the one you want. For
example, if you chose Reply but decide you want to Reply all instead.
Gmail account settings
1. From the Home screen,
Google folder
> Gmail
> the Accounts &
Labels icon (at the upper-left corner of the screen).
2. Tap Settings.
3. Tap General settings to change the following settings for all accounts.
Archive & delete actions: Sets if you want to display only the archive
option, only the delete option, or both options.
Swipe to archive: Checkmark to archive a conversation when you
swipe it.
Sender image: Checkmark to display the sender’s image to beside
the name in the conversation list.
114 Communication
Reply all: Checkmark to make Reply all the default message action.
Auto-fit messages: Checkmark to shrink the messages to fit the
screen and allow zooming.
Auto-advance: Sets which conversation list is viewed after archive or
deletion. Choose from Newer, Older and Conversation list.
Message actions: Sets when to show the action icons on the
message header. Choose from Always show, Only show in portrait,
and Don’t show.
Confirm before deleting: Checkmark to ask to confirm before
deleting a message.
Confirm before archiving: Checkmark to ask to confirm before
archiving a message.
Confirm before sending: Checkmark to ask to confirm before sending
a message.
Changing specific Gmail account settings
1. From the Home screen, tap Google folder > Gmail > the
Accounts & Labels icon (at the upper-left corner of the screen) >
Settings.
2. Tap a Gmail account to change the following settings for that specific
account.
Inbox type: Sets your Inbox type. Choose Default Inbox or Priority
Inbox.
Inbox categories: Sets where specific types of messages (e.g.,
messages from your social networks or promotional offers, etc.) are
stored into Inbox categories.
Notifications: Checkmark to display notifications for new gmail
messages.
Inbox sound & vibrate: Sets synchronization settings and notification
settings.
115
Communication
Signature: Sets the signature you want to include with every outgoing
email from this account.
Vacation responder: Sets up an automatic email to respond with
when you are out of the office (or otherwise unavailable). Tap the
switch to turn it on, enter the dates for the responder, and enter the
subject/message.
Sync Gmail: Checkmark to automatically sync your account.
Days of mail to sync: Sets how many days of email you want to sync.
Manage labels: Sets the sync and notification settings for each of
your labels.
Download attachments: Checkmark to automatically download
attachments to recent messages via Wi-Fi.
Images: Sets when to show images included in your Gmail
messages. Choose Always show or Ask before showing.
Hangouts
Use the Hangouts app to have real-time text conversations with your
friends.
To Open the Hangouts app
From the Home screen, tap Google folder
> Hangouts .
To sign out of Hangouts
From your chatting list, tap the Menu icon (at the upper-right corner of
the screen) > Settings > tap your account > Sign out.
Chatting with Friends
1. From the Home screen, tap Google folder
> Hangouts .
2. Tap the New icon to view the contacts from all of the Google
Accounts you've added (at the top of the screen), followed by People
you hangout with, Suggested people, and Other contacts (at the
bottom of the screen).
116 Communication
Tap the name of the person in your contacts list. If your friend is not
yet on Hangouts, your friend will receive an SMS inviting them to
Hangouts.
OR
Tap the text field to enter a name, email, number, or circle.
3. Tap the message box (at the bottom of the screen), then enter your
message.
NOTE Before you enter the text for your message, you can tap the Attach icon (to the right
of the message) to attach a photo, video, or location.
4. Tap the Send Icon (on the right side of the message).
NOTE You can tap the call icon (at the top of the screen) to call the friend, or tap the video
icon to start a video chat with your friend.
Hangouts chatting list
Touch and hold a friend’s name in the chat screen, then you can use the
following options (at the top of the screen).
Tap to turn notifications from that friend off (or on )
Tap to archive the conversation.
Tap to delete the conversation.
Chatting list Options menu
From the chatting list, tap the Menu icon (at the upper-right corner of the
screen) to access its Options menu that includes Set mood, Invites,
Snooze notifications, Archived Hangouts, Settings, and Help & feedback.
Switching between the chatting list and a chat screen
From a chat screen, swipe right to view the chatting list. From the chatting
list, swipe left to view the currently selected chat.
Blocking your Friends
To block a friend from exchanging messages with you, tap the friend in
the chatting list. Tap the Menu icon (at the upper-right corner of the
117
Communication
screen) > People & options. Tap the block icon next to the friend's
name, then tap Block.
To remove a friend from the blocked list, from the chatting list, tap the
Menu icon (at the upper-right corner of the screen). Tap Archived
Hangouts, then tap the blocked friend. Tap Unblock at the top of the
screen.
NOTE You can also unblock a friend from Blocked people in the Hangouts settings menu.
Hangouts Option menu
From the chatting list, tap the Menu icon (at the upper-right corner of
the screen) to choose from Set mood..., Invites, Snooze notifications,
Archived Hangouts, Settings, and Help & feedback.
While chatting, tap the Menu icon (at the upper-right corner of the
screen) > choose from People & options, New group Hangout, Turn
history off, Archive, Delete, and Help & feedback.
Hangouts Settings
From the chatting list, tap the Menu icon (at the upper-right corner of the
screen) > Settings.
Tap your account to access the following settings: Profile photo, Share
your status, Hangouts notifications & invites, Video calls, Customize
invites, Google+ profile, Phone number confirmed, Blocked people,
Sign out, and Improve Hangouts.
Tap SMS to access the following settings: SMS enabled, Import SMS,
Notifications, Sound, Vibrate, Group messaging, Delete old messages,
Delivery reports, Auto retrieve MMS, and Roaming auto-retrieve.
118 Entertainment
Camera and Video
You can use the Camera app to take and share pictures and videos. Your
phone comes with a 13 megapixel camera that lets you capture sharp
pictures and videos. It has many state-of-the-art features such as laser
auto-focus, dual camera mode, still photo capture while recording video,
and much more. These features will allow you to easily and creatively
capture your world.
NOTE Be sure to clean the protective lens cover with a microfiber cloth before taking pictures.
A lens cover with smudges from fingers can cause blurry pictures with a "halo" effect.
To open the Camera app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Camera .
OR
Tap Camera from the Home screen.
OR
With the backlight off, touch and hold the Volume Down Key (on the
back of the phone).
TIP If you’ve set your phone to use the Swipe unlock method, from the Lock screen, simply
press the Power/Lock Key (on the back of the phone), then drag the Camera icon
upward to open the Camera app.
Getting to know the viewfinder
Lens Swap – Tap to swap between the rear camera lens and the front camera lens.
Video Capture Button – Tap to start recording a video.
Capture Button – Tap to take a photo.
Back – Tap to close the selected menu or exit the
Camera app.
Gallery – Tap to access your Gallery.
Flash – Tap to turn the flash On , Off , or set it to Auto .
Options – Tap to display and hide the camera options on the screen.
Settings – Tap to adjust the camera and video settings.
Mode – Tap to set how the shot will be taken: Auto, Magic focus, Panorama, or Dual.
119
Entertainment
Taking Pictures
Taking pictures with your phone’s built-in camera is as simple as choosing a
subject, pointing the lens, and tapping a button icon. When you take a
picture, the Multi-point Auto-focus (AF) function operates automatically to
allow you to see a clear image.
To take a picture:
1. From the Home screen, tap Camera .
2. Frame your subject on the screen.
A square around the subject indicates that the camera has focused.
Place two fingers on the screen and spread them apart to zoom in (a
zoom bar indicates the zoom level) and pinch in to zoom back out.
3. Tap the Capture button , if available. Otherwise, tap the subject to take
the picture. Your picture will be automatically saved to the Gallery.
NOTE The captured image retains the orientation in which it was taken. If you hold the phone
both vertically and horizontally to take pictures, you'll need to rotate the phone to view
full screen images in the Gallery app.
TIP While viewing a photo, you can tap the Menu icon (at the upper-right corner of the
screen), then tap Rotate right/left to manually change its orientation.
Record Videos
In addition to taking pictures, you can record, view, and send videos with
your phone’s built-in video camera.
1. From the Home screen, tap Camera .
2. Frame your subject on the screen.
3. Tap the Video Capture button to start recording the video.
The length of the recording is displayed at the upper-left corner of the
screen.
You can tap the Capture button to take pictures while you’re
recording video.
120 Entertainment
You can use the pinch gesture to use the dynamic zoom feature while
you’re recording video. Spread your fingers on the screen to zoom in
and pinch to zoom back out.
You can tap the Pause button to pause your video recording. Then,
resume your recording by tapping the Record button .
4. Tap the Stop button to stop recording. Your video will be
automatically saved to the Gallery.
Camera and Video Settings
Open the Camera app, tap the Menu icon , then tap each of the
following icons to adjust the settings to your preferences.
NOTE Some settings will display an information pop-up the first time you select icon.
Flash : Tap to turn the flash On , Off , or set it to Auto .
Lens swap : Tap to swap between the rear camera lens and the front
camera lens.
Mode : Tap to set the capture mode. Choose from Auto, Magic
focus, Panorama, and Dual.
Auto: Captures an auto photo shot.
Magic focus: Allows you to change the focus after taking a photo.
After taking the photo, tap the focus icon (in the upper-right corner
of the screen), then tap where you want to sharpen the focus.
Panorama: Creates a wide photo of a panoramic view. Hold the
phone, tap the Capture button to start and slowly sweep the camera
across the scene.
Dual: Captures a photo or records a video using both the front and rear
camera lens at the same time. Touch and hold the small image
window to resize or move it.
Settings : Tap to adjust the following camera and video settings.
Dynamic tone (HDR): Combines photos taken at multiple exposures
into one optimal photo to get a better photo in tricky lighting situations.
121
Entertainment
Image size: Sets the file size of your picture. Choose from 13M
4160x3120, W10M 4160x2340, 9M 3120x3120, and 3M 2048x1536.
Also sets the file size of your video. Choose from UHD 3840x2160,
FHD 1920x1080, HD 1280x720, and 120HD Slow Motion.
Voice shutter: Allows you to take pictures with voice commands.
When On, you just say "Cheese", "Smile", "Whiskey", "Kimchi", or "LG"
to take a picture. Choose from On or Off .
Timer: Sets your camera's timer. This is ideal if you want to be a part
of the picture. Choose from Off , 3 seconds , or 10 seconds .
Grid: Sets an overlay grid on the viewfinder to help you take better
pictures by allowing you to align your subject with the horizontal or
vertical lines. Choose from On or Off .
Storage: Sets the storage location for your pictures. Choose IN
(internal memory) or SD (memory card).
Help: Displays a quick guide so you can learn how each camera
function works.
Gesture shot
The Gesture shot feature allows you to take a picture with a hand gesture
using the front camera.
To take a photo with a gesture
1. Activate the front camera lens.
2. Raise your hand, with an open palm, until the front camera detects it (a
box appears on the screen).
3. Make a fist to start a countdown before the shot is taken (allowing you
time to position yourself).
122 Entertainment
Super Zooming
You can change the zoom level for your photos using the pinch-to-zoom
feature. Spread your fingers on the screen to zoom in and pinch in to zoom
back out.
Super Zoom gives you the ability to zoom up to 8 times the normal view.
This feature operates automatically while zooming in and out.
NOTE Use a steady hand. The Super Zoom feature does not work with some functions.
Objects can be overlapped when taking a picture of fast-moving subjects.
View Your Pictures
The Gallery is where you can access the Gallery of stored camera images.
You can view them in a slideshow, share them with your friends, as well as
delete and edit them.
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery .
2. Select an album and tap an image to view your picture.
Gallery Options
The Gallery app presents all of the pictures and videos stored in your
phone, including those you’ve taken with the Camera app and those you
downloaded from the web or other locations.
If you have Picasa web albums associated with your phone’s Google
Accounts, you’ll also see your Picasa web albums in your Gallery.
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery to view the images stored your
phone’s internal memory and on a MicroSD card (external storage).
Drag left or right to view more albums.
2. Tap an album to open it and view its contents. (The pictures and videos
in the album are displayed in chronological order.)
123
Entertainment
3. Tap a picture in an album to view it.
While viewing an album the following icons are displayed at the top of
the screen:
Camera: Opens the Camera.
Share: Allows you to select one (or more) photos to share. Tap
Share (at the bottom of the screen) to open the available sharing
options (such as Messaging or Bluetooth).
Delete: Allows you to select one (or more) photos to delete. Tap
Delete (at the bottom of the screen) to delete the selected
picture(s).
Menu: Opens the albums Options menu which includes Move,
Copy, Make collage, Lock, Slideshow, Rotate left, and Rotate right.
Tap a picture in an album then tap the Menu icon (at the upper-
right corner of the screen) to open its Options menu which includes
the following options: SmartShare, Set image as, Move, Copy, Copy
to Clip Tray, Lock, Slideshow, Rotate left, Rotate right, Crop, Add
location, Rename, Print, and Details.
Tap a picture in an album, then tap the Favorite icon
(at the top left
of the picture) to mark it as a favorite.
Tap the Back Key (in the Touch Keys bar) to return to the previous
screen.
124 Entertainment
Assign Pictures
After taking a picture, assign it as a picture ID for a Contacts entry or as the
background image (wallpaper) for your Home screen or Lock screen.
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery .
2. Tap an album and tap an image to view it.
3. With the picture displayed, tap the Menu icon (at the upper-right
corner of the screen) > Set image as.
4. Select an option.
Contact photo to assign the picture to a Contact entry as a picture ID.
Tap an entry from Contacts, crop the image, then tap Done (at the
bottom-left corner of the screen) to assign the picture.
Wallpaper to assign the picture as a background image, crop the
image and tap SET WALLPAPER to assign the picture.
Lock screen wallpaper to assign the picture as a background image
for your Lock screen.
Home screen wallpaper to assign the picture as a background image,
crop the image and tap OK to assign the picture.
Dual Feature
The Dual feature allows you to take a picture or record video with the front
and rear camera lens at the same time. A smaller image window overlays
the main image (similar to picture-in-picture). You can resize and move the
overlay image window, as well as swap the lens for either view.
1. From the Home screen, tap Camera .
2. Tap the Mode icon > the Dual icon .
Drag the overlay window to move it where you want it on the screen.
Touch and hold the overlay window to resize it.
Tap the overlay window to switch its lens.
Tap the Capture button to take a dual photo.
125
Entertainment
Tap the Video capture button to record video, then tap the Stop
button to stop dual recording.
Video Options
The Gallery is where you can access your Gallery of stored video images.
You can view them, share them with your friends, as well as delete and
edit them.
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery to view the videos stored in your
phone’s internal memory, microSD card (external memory), or albums
connected to your Google Account (e.g., Picasa).
Scroll left or right to view more albums.
2. Tap an album to open it and view its contents. (The pictures and videos
in the album are displayed in chronological order.)
3. Tap a video to view it.
Tap the screen to display the playback controls (rewind, pause, play,
and fast-forward) and timeline bar.
To share a video
1. Open an album to view its contents, then tap the Share icon (at the
top of the Gallery screen).
2. Checkmark the video(s) you want to share, tap Share (at the bottom of
the screen), select how to share the file(s), then complete as necessary.
126 Entertainment
To delete a video
1. Open an album to view its contents, then tap the Delete icon (at the
top of the Gallery screen).
2. Checkmark the video(s) you want to delete, tap Delete (at the bottom of
the screen), then tap Yes to confirm.
Play a Video
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery to view videos stored in your
phone’s internal memory, microSD card (external memory), or albums
connected to your Google Account (e.g., Picasa).
Scroll left or right to view more albums.
2. Tap an album to open it and view its contents. (The pictures and videos
in the album are displayed in chronological order.)
3. Tap a video in an album to play it.
Tap the video while it’s playing to view the playback controls.
While playing a video, tap the timeline to jump to that part of the
video. While playing a video, press the Volume Keys (on the back of
the phone) to adjust the volume.
While playing a video, tap the timeline to preview that part of the
video, then tap the preview to jump to it.
While playing a video, press the Volume Keys (on the back of the
phone) to adjust the volume.
NOTE The recording retains the orientation in which it was taken. If you hold the phone both
vertically and horizontally to take pictures and record video, you'll need to rotate the
phone to view full screen images in the Gallery app.
Live Zoom
Live Zoom allows you to zoom in or zoom out on a portion of a video while
it’s being played to make the desired section appear larger or smaller.
While viewing a video, use your index finger and thumb in a pinching or
spreading motion on the touchscreen to zoom in or out.
127
Entertainment
NOTE You don't need to press too hard; the touchscreen is sensitive enough to pick up a light,
but firm touch.
Dual Play
Dual Play connects two devices using a wired (Slimport-HDMI) cable or a
wireless connection (Miracast) allowing you to view content on a different
screen. The connectable device can be a TV or a monitor supported by an
HDMI cable or Miracast. Viewable content can come from the Gallery app
however not all videos are supported by Dual Play.
To start Dual Play, tap the Home Key (in the Touch Key bar) once when
the two devices are connected and their displays are a different status (i.e.
the monitor is playing a video and your phone’s video app is displaying an
empty screen).
NOTE Dual Play operates at 1280X720 or higher display resolution.
Gallery
Open the Gallery app to view albums of your pictures and videos.
To open the Gallery app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery .
Viewing your albums
The Gallery app presents all of the pictures and videos stored in your
phone, including those you’ve taken with the Camera app and those you
downloaded from the web or other locations. When another app saves a
picture, it automatically creates a download folder to contain the picture
(e.g., capturing a screen shot creates the Screenshot folder).
128 Entertainment
Tap an album to open it and view its contents.
Tap a picture or video in an album to view it.
Tap the Menu icon (at the upper-right corner of the screen) to open
the Options menu to access Cloud, New Album, Delete, Hide/Show
album, Settings, and Help.
Tap the Camera icon to return to the Camera app.
Tap Albums (in the upper-left corner of the screen) to open the Gallery
menu to access Albums, Favorites, Videos, All files, and Nearby
devices.
To share an album
You can share the entire contents of one or more albums or individual
images or videos from an album.
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery .
2. Touch and hold the desired album, tap Share, select the app to use to
share your images, then complete the sending method as necessary.
Working with photos
Use the Gallery app to view pictures that you’ve taken with the Camera app
or that you’ve downloaded.
To view and browse photos
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery .
2. Open an album and tap a picture.
3. Tap the screen to display the icon bar (at the top of the screen) and the
Touch Keys bar (at the bottom of the screen). The following options are
available.
Tap the Menu icon (at the upper-right corner of the screen) to open
the Options menu to access SmareShare, Set image as, Move,
129
Entertainment
Copy, Copy to Clip Tray, Lock, Slideshow, Rotate left, Rotate right,
Crop, Add/Remove location, Rename, Print, or Details.
Tap the Delete icon , then tap Ye s to delete the picture.
Tap the Share icon , tap the sharing method, then complete as
necessary.
Tap the Camera icon to switch to camera mode.
Tap the Edit icon to open the editing screen which allows you to
change the picture (such as cropping, rotating, tuning, adding effects,
and more).
Tap the Favorites icon to set the picture to your Favorites folder.
Share Icon
Tap here to share the photo using the
method you select.
Delete Icon
Tap here to delete the photo.
Camera Mode Icon
Tap here to change
to camera mode.
Edit Icon
Tap here to edit
your picture.
Gallery Icon
Tap here to return
to your Gallery.
Swipe horizontally to scroll
through the photos in the current
album.
Swipe here to quickly scroll through
the images in the album, then tap
the one you want to view.
130 Entertainment
Play Store
Play Store allows you to browse and search for free and paid apps.
To open the Play Store app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Play Store or tap Play Store on the
Home screen.
To get help with Play Store
Play Store Help web pages are available from all of the Play Store screens.
Tap (at the upper-left corner of the screen), then tap Help.
The Chrome app opens to the Play Store Help page, with links to many
help topics.
To open a screen with details about an app
At any time while browsing in Play Store, tap an app to open its details
screen.
The App details screens include a description, ratings, reviews,
comments, and related information about the app. From this screen, you
can download, install, uninstall, rate the app, and more.
The following icons are available at the top of the App details screen:
- Returns to the Play Store homepage.
- Allows you to search for apps.
- Adds the app to your wishlist.
- Allows you to share the App details information using the available
sharing choices.
Downloading and Installing Apps
When you find an app you want, you can download and install it on your
phone.
131
Entertainment
To download and install an app
NOTE Before you can download a paid app, you must set up a billing arrangement.
Price/Install button
Indicates the cost or
install for free apps.
1. From the Home screen, tap Play Store .
2. Tap a category from the homepage or tap the Search icon (at the
upper-right corner of the screen) to search for an app.
3. Tap the app you want to open its details screen.
4. Tap INSTALL or the Price button to download the app.
5. If you agree with the app's access requirements, tap ACCEPT.
6. The app will be downloaded and installed.
Play Store menu options
The Play Store menu icon (at the upper-left corner of the screen) accesses
the Play Store Options menu. The options vary depending on the screen in
which it was accessed. Options can include: Store home, My apps, My
wishlist, Redeem, Settings, and Help.
Your Wishlist
While viewing an app (or music, games, etc.), tap the Wishlist icon (at
the top of the screen) to add it to your wishlist for future reference.
132 Entertainment
Play Store settings
Tap the Play Store menu icon > Settings to access Notifications, Auto-
update apps, Add icon to Home screen, Clear search history, Content
filtering, and Require password for purchases. You can also view the open
source licenses and build versions.
Music
Transferring Music Files to Your Phone
The Music app plays audio files that are stored in your phone’s memory.
Copy audio files from your computer onto your phone before you open the
Music app.
NOTE The LG USB driver needs to be installed on your PC before connecting your phone to
transfer music.
To copy music files into your phone
1. Connect the phone to your computer with a USB Cable. If the default
connection mode is not set to Media sync (MTP), open the Notifications
panel and tap USB connected > Media sync (MTP). Your computer will
prompt you with different actions to take. Choose to open the folder to
view files.
2. Use the computer to copy music and other audio files into the folder that
you created on the phone.
3. To disconnect your phone, open the Notifications panel and tap USB
connected > Charge phone. Then disconnect the USB Cable from the
phone.
Access the Music app
From the Home screen, tap the Apps icon (in the QuickTap Bar) > the
Apps tab (if necessary) > Music .
Your Music Library
The Music Library displays your music organized in music category tabs
that include Songs, Albums, Artists, and Genres. To access Favorites,
133
Entertainment
Playlists, Folders, and Nearby devices, tap at the top left corner of the
screen.
The Music tabs are listed at the top of the screen. Flick sideways on the
screen to scroll and select one.
Tap Music library (at the upper-left corner of the screen) to open the
Music menu that includes Favorites, Playlists, Folders, and Nearby
devices.
Your songs and artists items are listed in alphabetical order within the
tab. An alphabetical search directory is displayed along the right side of
the screen. Slide your finger along it to quickly access specific letter
entries.
Tap a song or playlist to play it.
The Music Player bar is displayed at the bottom of the screen and the
current song is displayed to its left.
Tap the Menu icon (at the upper-right corner of the screen) to open
the Music Options menu that includes Cloud, Select to play, Add to
playlist, Shuffle all, Delete, Share, Settings, and Help.
To search
From the Music Library screen, tap the Search icon (at the top right of
the screen). Enter text in the search box. Matches are displayed below the
search box for you to select.
To delete a song
Touch and hold a song in the Music Library list. In the Context menu that
opens, tap Delete, then tap Yes.
Playing Music
You can listen to music using the phone’s built-in speaker, through a wired
headset, or through a wireless Bluetooth stereo headset that supports the
A2DP profile.
134 Entertainment
To play music
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Music .
2. Select a music category tab at the top of the Music Library screen.
3. Tap the song you want to play.
Music Player Control Icons
Tap here to restart, pause,
play, or skip.
Audio Effects Icon
Tap here to apply audio
effects to the song.
Volume Icon
Tap here the adjust the
Music Player volume.
Playback Screen
NOTE While viewing a list of tracks in an album, tap the Menu icon (at the upper-right
corner of the screen), then tap Shuffle all to play all of the songs in the album in a
shuffled order.
To return to the Playback screen
From a Music playlist screen, tap the currently playing song at the
bottom of the screen.
From any other app, open the Notifications panel and tap the ongoing
music notification.
135
Entertainment
To control playback
The Playback screen contains several icons that you can tap to control the
playback of songs, albums, and playlists:
Tap to pause playback.
Tap to resume playback.
Tap to skip to the next track in the album, playlist, or shuffle. Touch and hold to fast
forward.
Tap to restart the current track or skip to the previous track in the album, playlist, or
shuffle. Touch and hold to rewind.
Tap to display the Volume slider bar, then adjust the playback volume on the bar.
Tap to set audio effects.
Tap to open the Options menu. Choose from Search, Add to playlist, Delete, Share,
Set as ringtone, Music video, Details, Settings, and Help.
Tap to open the current playlist.
Tap to add the song to your favorites.
Tap to play the current playlist in shuffle mode (tracks are played in random order).
Tap to toggle through the repeat modes. Choose from Repeating all songs ,
Repeating current song , and Repeat off .
Tap to share your music via the SmartShare function.
To control playback volume
In addition to the techniques for setting media volume in the Sounds
settings, you can control the volume of music in the Music app.
Press the phone’s up/down Volume Keys (on the back of the phone).
The current media volume is displayed on a slider bar. Continue pressing
the Volume Keys to set the volume you want.
Tap the Volume icon (at the lower-left corner of the Playback screen).
The current media volume is displayed on a slider bar. Drag the button
on the bar to set the volume you want.
136 Entertainment
To stop music playback and exit the Music Player
Slide the Status Bar down to display the Music notification. Then swipe the
Music notification to the left or right.
To use a song as a ringtone
You can use a song as your phone ringtone, in place of one of the ringtones
that come with the phone.
Touch and hold a song in the Music Library list. In the Context menu that
opens, tap Set as ringtone, then tap Phone ringtone or Contact
ringtone.
OR
On the Playback screen, tap the Menu icon (at the upper-right corner
of the screen), tap Set as ringtone, then tap Phone ringtone or Contact
ringtone.
Working with Playlists
You can create playlists to organize your music files into sets of songs,
which you can play in the order you set or in a shuffle.
To create a playlist
1. From the Music Library, tap Music (in the upper-left corner of the
screen), then tap Playlists.
2. Tap the Menu icon (at the upper-right corner of the screen), then tap
New playlist.
3. Enter a name for the playlist and tap OK.
4. Select the songs you want to add to a playlist, then tap Add (at the
lower-right corner of the screen). The new playlist is added to the Playlist
tab.
To add a song to a playlist
1. From the Music Library, touch and hold the song you want to add to a
playlist.
137
Entertainment
2. In the context menu that opens, tap Add to playlist, then tap the name
of the playlist you want to add it to.
To remove a song from a playlist
1. Open a playlist.
2. Touch and hold the song you want to remove, then tap Remove from
playlist in the Context menu that appears.
To delete a playlist
1. Open the Playlists library.
2. Touch and hold the playlist, then tap Delete in the Context menu that
appears.
3. Tap Ye s to confirm.
To rename a playlist
1. Open the Playlists library.
2. Touch and hold the playlist, then tap Rename in the Context menu that
appears.
3. Enter a name, then tap OK.
To delete multiple songs
Open the Music Library screen, tap the Songs tab, tap the Menu icon
(at the upper-right corner of the screen), then tap Delete. Checkmark
each of the songs you want to delete, tap Delete (at the bottom of the
screen), then tap Yes to confirm.
NOTE Tap the Menu icon (at the upper-right corner of the screen) from another Music tab to
delete one or more of the items in that selected tab.
YouTube™
Opening YouTube and Watching Videos
You can browse, search for, view, upload, and rank YouTube videos on your
phone with the YouTube app.
138 Entertainment
To open the YouTube app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > YouTube .
Search for and tap a video to watch it.
Tap the Menu icon (at the upper-right corner of the screen) for the
YouTube Options menu (Settings, Send feedback, Help, and Sign in/
out).
Tap the YouTube icon (at the upper-left corner of the screen) to
toggle between What to Watch and other YouTube options.
To search for videos
1. Tap the Search icon (at the top of the main YouTube screen).
2. Enter the text to search for or tap the Microphone icon to search by
voice.
3. Tap a suggestion below the search box or tap the Search Key on the
keyboard.
4. Scroll through the search results and tap a video to watch it.
YouTube menu options
The YouTube menu icon (at the upper-left corner of the screen)
accesses YouTube options including: current account, What to Watch,
My Subscriptions, Uploads, History, Watch Later, Browse channels,
and Best of YouTube.
The Menu icon (at the upper-right corner of the screen) accesses
Settings, Send feedback, Help, and Sign in/out.
139
Tools
Dual window
The Dual Window feature splits the screen to enable multi-tasking, drag
and drop interaction, auto-linking and recently used apps.
To activate the Dual window function
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings > Dual window.
2. Tap the Dual window switch (at the top of the screen) to toggle it On
or Off.
Checkmark the Split view checkbox to automatically open the Dual
window function when you tap a link on the full screen or tap an email
attachment.
Using the Dual window function
1. Touch and hold the Back Key (in the Touch Keys bar) to split the
screen.
2. Tap the app icon you want to use. The first app you tap opens in a
window at the top of the screen. The second app opens in the bottom
window.
3. Tap a window to select and use it.
A blue box appears around the selected window with a blue semi-
circle handle between the windows.
Drag the blue handle to change the window sizes (one larger and one
smaller).
4. Tap the blue handle to access the Dual window options.
Tap the Swap icon to switch (flip) the app positions.
Tap the View app list icon to redisplay the apps list so you can
change the app for the selected window.
Tap the Open full screen icon to open the selected app in full
screen. Drag the blue handle (up or down depending on the selected
window) to return to Dual window.
Tap the Close icon to close the selected window.
140 Tools
QuickMemo+
The QuickMemo+ feature allows you to create memos and capture screen
shots. You can use QuickMemo+ to easily and efficiently create memos
during a call, with a saved picture, or on the current phone screen.
To create a QuickMemo+
Drag the Status Bar downward, then tap the QuickMemo+ icon in
the Quick Settings bar.
2. Use the memo options
at the top of the screen
(e.g., pen type and
color) to create your
memo.
3. When your memo is complete,
tap the Save icon (in the
toolbar at the top of the screen)
to save it to your Gallery or
QuickMemo+.
1. Drag the Status Bar
downward then tap the
QuickMemo+ icon .
NOTE Please use a fingertip (not your fingernail or any other rigid object) while using the
QuickMemo+ feature to avoid scratching your phone's touchscreen.
Capturing a screen shot for your QuickMemo+
1. Access the screen you want to capture (for example, access the Maps
app to capture a street location to help with directions).
2. Drag the Status Bar down, then tap the QuickMemo+ icon on the
Quick Settings Bar.
3. Use the toolbar options (at the top of the screen) to create your memo
on the captured screen.
4. Tap the Save icon (in the upper-right corner of the screen), then select
to save it in the QuickMemo+ folder in the Gallery app.
141
Using QuickMemo+ toolbar options
The QuickMemo+ toolbar options (at the top of the screen) allow you to
easily create memos. Tap the memo options bar tab to access the
QuickMemo+ toolbar icons, and tap it again to hide them.
Undo: Tap to undo the most recent action.
Redo: Tap to redo the most recently deleted action.
Create: Tap to type text in your QuickMemo+ file.
Pen: Tap to select the pen type and color. Tap the memo background
to close the pen selection.
Erase: Tap to use the eraser to erase pen marks from the memo.
Save: Tap to save the memo you’ve created to your Gallery or
QuickMemo+.
Menu: Tap to access additional options.
QuickMemo+ Menu Options
From the QuickMemo+ screen, tap the Menu icon (at the upper-right
corner of the screen) to access Share and Paper style.
Tap Share, then compete the sharing method as necessary to share your
QuickMemo+.
Tap Paper style to set the paper background for your memo, then tap
OK.
To Exit the QuickMemo+ feature
Tap the Back Key (in the Touch Keys bar) to exit the QuickMemo+
feature.
Viewing saved QuickMemos
QuickMemos are saved in the Gallery app or QuickMemo+ app.
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Gallery , then tap the QuickMemo+ album.
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > QuickMemo+ , then tap the your memo.
142 Tools
Capturing a screen shot
To capture a screen shot without the QuickMemo feature, press both the
Power/Lock Key (on the back of the phone) and the Volume Down Key
(on the back of the phone) at the same time. The captured image is
automatically saved in the Gallery app in the Screenshots folder.
QSlide
The QSlide function enables an overlay window on your phone’s display for
easy multitasking. QSlide displays a small app window on the screen that
can be moved, resized, or made transparent. QSlide windows can be
opened from the QSlide apps bar on the Notifications panel, or directly
from the apps that support the QSlide function.
QSlide icons on the Notifications panel
QSlide app icons are displayed in a bar on the Notifications panel below the
Quick settings bar. These icons provide a quick, convenient way to multi-
task on the same screen (similar to picture-in-picture on a TV).
OR
143
Tools
Tap to exit the QSlide function and view the app in full screen.
Slide to adjust the transparency.
Tap to exit the QSlide function.
NOTE The QSlide function can support up to two windows at the same time.
To open a QSlide window
Open the Notifications panel, tap QSlide , then tap the desired app in the
QSlide apps bar.
OR
While using an app that supports QSlide, tap the QSlide icon .
Using QSlide
The QSlide function opens the associated app in a window in the
foreground, allowing you to access other apps in the background. It’s
displayed continuously on the screen until you close it.
Drag the QSlide title bar to move it on the screen.
Drag the bottom right corner of the QSlide window to resize it.
Move the circle on the slider bar to the left to make it transparent.
This will allow you to interact with items underneath the transparent
QSlide window. Move the slider back to the right to use the QSlide
window again.
Tap the QSlide icon (at the upper-left corner of the title bar) to open
the app in full screen view. To go back to QSlide view, tap the QSlide
icon (at the top of the screen).
Tap the Close icon (at the upper-right corner of the title bar) to close
the QSlide window.
Customizing the QSlide apps bar icons
You can set the order of the icons displayed in the QSlide apps bar, as well
as which icons are displayed.
144 Tools
1. Open the Notifications panel and swipe to the left on the QSlide apps
bar (if necessary), then tap the Edit icon .
Drag one of the icon handles at the right side of the screen to
move its icon to another position in the QSlide apps bar.
Checkmark the icons you want to display and remove the checkmark
for the ones you want to remove.
2. Tap the Back Key (in the Touch Keys bar) to return to the
Notifications panel.
QuickRemote
QuickRemote turns your phone into a Universal Remote for your home TV,
set top box, and audio system. You can set up and display up to four
remotes.
NOTE QuickRemote may not be available for some devices.
To open the QuickRemote app and set up your QuickRemote
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > QuickRemote .
2. Tap the room displayed at the upper-left corner of the screen to select its
location.
Choose from Livingroom, Bedroom, Kitchen, Den, and Office.
145
Tools
3. Tap the Add icon (at the top right of the screen).
4. Tap the device you want to set for the remote, then tap the name of the
device’s manufacturer.
Use the letters along the right side of the screen to jump directly to
that letter in the list.
5. Continue your remote set up by following the on-screen instructions to
configure the device.
NOTE It's important to point the IR sensor on your phone directly at the device you are
configuring.
Set up from the Notifications panel
You can also perform the initial set up of your QuickRemote from the
Notifications panel. Swipe the Status Bar downward, tap the QuickRemote
icon (in the Quick Settings bar, if necessary), tap ADD REMOTE in the
dialog box, then continue set up as necessary.
After initial setup, to set up additional devices from the Notifications panel,
tap the Full-screen icon (at the lower-right corner of the remote display),
then tap the Add icon (at the top right of the QuickRemote screen).
Using QuickRemote
1. Swipe the Status Bar downward, then tap the QuickRemote icon (in
the Quick Settings bar, if necessary) to open a QuickRemote bar with all
of the remotes you set up.
2. Select the remote you want by tapping the remote name at the top of
the QuickRemote bar.
3. Tap the buttons on the displayed remote.
NOTES Tap the full-screen icon (at the lower-right corner of the remote display) to view the
QuickRemote in full screen.
When adding a remote control for a TV, QuickRemote could use the INPUT button to
configure the appropriate remote control. When configuring the INPUT button, the
input source for the TV could be changed. To reset the input source of your TV, tap the
INPUT button on the QuickRemote several times (depending on the number of devices
connected to the TV).
146 Tools
QuickRemote options
You can edit your QuickRemote bar by tapping the Edit icon (at the top
right of the QuickRemote bar. Drag a remote handle to move it to
another position on the bar.
To access the QuickRemote Options menu, tap the Menu icon (at the
upper-right corner of the screen) to select Magic Remote setting, Edit
remote name, Learn remote, Move remote, Delete remote, Settings, and
Help. Tap the Back Key (in the Touch Keys bar) to exit the Options
menu.
Customizable remote
You can create your own personalized universal remote and choose where
to place all of the buttons.
1. From the Home screen tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > QuickRemote .
2. Tap the Add icon (at the top right of the screen) > Customizable
remote.
3. Enter the Remote name, then tap OK.
4. Swipe to the left and right and place the buttons you want on the
remote in the desired locations, then tap Next (at the bottom of the
screen).
5. Program your customized remote using your original remote.
Face the IR sensors toward each other, about 4 inches apart.
Tap the button (on your customized remote) to learned.
147
Tools
Press and hold the corresponding button (on your original remote) for
two seconds.
Using the Magic Remote feature
Magic Remote controls the TV using a Touchpad and Smart Text (keyboard).
Magic Remote is compatible only with LG Smart TVs released in 2012 and
after.
1. Select the remote you want, then tap the Menu icon (at the upper-
right corner of the screen) > Magic Remote setting.
2. Tap the Supported models button and check whether your TV supports
this feature.
3. Connect your phone and LG Smart TV to the same Wi-Fi network.
4. Select the device and enter the certificate number in your phone.
Touchpad: Moves the TV pointer with the touchpad.
Smart Text: Provides a keypad when typing text.
Calendar
Viewing Your Calendar and Events
The Calendar app allows you to track your schedule of events (that you
created or that you’ve been invited to), organized by day, week, month,
year, or agenda.
When you first set up your phone, you configured it to use an existing
Google Account or you created a new account. The first time you open the
Calendar app on your phone, it displays any existing calendar events from
your Google Account on the web.
To open the Calendar app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Calendar .
148 Tools
Events from each account you’ve added to your phone and configured to
synchronize calendars is displayed in your Calendar.
Events from each calendar account are displayed in a different color.
To change your calendar view
No matter where you are in the Calendar app, you can easily switch
calendar views. Simply tap the upper left corner of the Calendar title bar to
display a drop-down menu of calendar views. Tap Day, Week, Month, Year,
or Agenda. You can also select View Tasks and change accounts.
Calendar title bar icons
Tap the QSlide icon to open the Month calendar view in a QSlide
window.
Tap the Current date icon to immediately jump back to the current
date in the calendar you’re viewing.
Tap the Add icon to add a new event to any of your accounts.
QSlide for the Calendar app
You can view your Month calendar in a QSlide window allowing you to
easily check dates, obligations, etc. while using other apps at the same
time.
1. Open the Calendar app.
2. Tap the QSlide icon (at the top of the screen) to display the Month
calendar in a QSlide window.
Swipe up and down to scroll through the months. Tap the calendar
icon (in the title bar) to quickly return to the current date.
Tap a date to view the events for that day in your Day calendar.
Drag the bottom right corner of the QSlide window to resize it.
Drag the title bar to move the QSlide window on the screen.
149
Tools
To move the QSlide window to the background, move the
transparency slider to the left (move it back to the right to
bring it back to the front).
To return to the Calendar app, tap the QSlide icon (at the upper-left
corner of the QSlide title bar).
To close the QSlide window, tap the (at the upper-right corner of
the title bar).
Adding an event to your calendar
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Calendar .
2. Tap the date (in the upper-left corner of the screen), then tap the
calendar view that you want to use.
3. Choose the date to create a new calendar event.
Tap the Add icon (at the top of the screen) from any of the
calendar views, and manually enter the event date.
OR
Double-tap the date from the Day, Week, or Month calendar view to
automatically enter the event date.
NOTE From the Day, Week, or Month calendar view, you can touch and hold the date to quickly
save an event.
4. Tap the necessary fields to enter the event details.
Event name identifies the event.
Graphic (to the right of the event name) sets an image to easily
identify the event in your Calendar.
Location identifies where the event takes place.
From Date/Time sets when the event starts.
To Date/Time sets when the event ends.
All day identifies it as an all-day event.
150 Tools
Time zone sets which time zone to use for the event.
Repeat sets if the event will repeat.
Repeat until sets when to stop displaying the event in your Calendar.
Guests identifies who is invited to the event.
Description indicates additional detailed information or notes about
the event.
Reminders sets the reminder notification for the event.
Show me as sets your Google status during the event.
Privacy sets the event as Calendar default, private, or public.
5. Tap Save (at the bottom of the screen) to save the event in the calendar.
Viewing Event Details
You can view more information about an event in a number of ways,
depending on the current calendar view.
To view information about an event
Days with saved calendar event(s) are indicated with text and color within
the selected calendar.
In Day, Week, or Agenda view, tap an event to view its details.
In Month view, tap a day to display the event(s) in a pop-up dialog box.
Tap an event to view its details.
Delete Icon
Tap here to delete the event.
Menu Icon
Tap here to access Choose
event color, Copy, Share, and
Add to Tasks.
Edit Icon
Tap here to edit the event.
Tap here to go back
to Calendar view.
151
Tools
While viewing an event’s Details view:
Tap the Reminders fields to change the reminder settings, tap Add
reminder to add another reminder, or tap the Remove reminder icon
(to the right of the reminder) to remove the reminder.
If you have permission to change the event, you can tap the Edit icon (at
the top of the screen) to edit the event or tap the Delete icon (at the top
of the screen) to delete the event.
To share an event, from the event’s details screen, tap the Menu icon (at
the top right corner of the screen), then tap Share in the Options menu.
Choose the method for sharing and complete as necessary.
Calendar Options menu
Tap the Menu icon (at the upper-right corner of the screen) to access the
Options menu.
From the Calendar app, the Options menu includes: Go to date, Search,
Sync now, Calendars to sync, Delete, and Settings.
From the Event details screen, the Options menu includes: Choose
event color, Copy, Share, and Add to Tasks.
152 Tools
Calculator
The Calculator app allows you to perform mathematical calculations using a
standard calculator or a scientific calculator.
To open and use the Calculator
From the Home screen, tap
the Apps icon
(in the QuickTap bar) > the
Apps tab (if necessary) > Tools folder > Calculator .
Basic calculator Scientific calculator
QSlide Icon
Tap here to display
the Calculator in a
QSlide window.
Tap the calculator keys to enter numbers and arithmetic operators on the
calculator’s display, just like you would use a normal calculator.
Tap the Delete Key to delete the last number or operator you entered.
Tap the Clear Key to clear the calculator’s display.
Tap anywhere within the calculator’s display to place the cursor within
the calculation.
Touch and hold the calculator’s display to open a Context menu where
you can copy what you’ve entered to use it in other apps. The context
menu can include: Select all, Copy, Cut, Paste, Clip Tray, and Text Link.
To open the Scientific calculator, tap the Menu icon (at the upper-right
corner of the screen), then tap Scientific calculator. To return to the
Basic calculator, tap the Menu icon (at the upper-right corner of the
screen), then tap Basic calculator.
153
Tools
Tap the Menu icon (at the upper-right corner of the screen) >
Calculation history to view your previous calculations. You can tap an
entry to calculate it again or edit it.
Tap the QSlide icon (at the top right of the screen) to use the
Calculator in a QSlide window.
Calculator settings
Access the Calculator app, tap the Menu icon (at the upper-right corner
of the screen) > Settings. You can set Vibrate on tap, Parenthesis color,
Operator color, and Answer color.
QSlide for the Calculator app
The QSlide function displays the calculator panel in a moveable window in
the foreground while allowing you to access other phone features in the
background.
Touch and hold the Calculator QSlide title bar to move it.
Drag the bottom right corner of the QSlide window to resize it.
Tap the QSlide icon (at the upper-left corner of the title bar) to return
to the Calculator app.
Drag the circle on the transparency bar to the left to make the QSlide
calculator window transparent allowing you to access the screen
functions underneath it. Drag it back to the right to use the QSlide
window again.
Tap the Close icon (at the upper-right corner of the title bar) to close
the Calculator QSlide window.
Clock
You use the Clock app to access the Alarms, Timer, World clock, and
Stopwatch functions. Access these functions by tapping the tabs across
the top of the screen, or swiping horizontally across the screen.
154 Tools
To open the Clock app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Clock .
TIP You can also tap the Clock widget (at the upper-right corner of the Home screen) to open
the Clock app.
Setting and Activating Alarms
The Alarms tab allows you to set varying alarm clocks. You can set an alarm
by modifying an existing alarm or by adding a new one. After you’ve
created one or more alarms, you can easily activate or deactivate an alarm
by tapping its Alarm icon to toggle it on (blue) or off (gray).
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Clock .
2. Tap the Alarms tab (at the top of the screen), if necessary.
3. Tap the New alarm icon (at the top of the screen) to add a new alarm,
tap an alarm time to modify that alarm, or tap a current alarm icon (on
the right side of the screen) to activate an existing alarm (blue indicates
it’s set).
To set an alarm
1. Open the Clock app, then access the Alarms tab.
NOTE The first time you access your alarms, an alarm image is displayed in the middle of the
screen. Tap it to set up your first alarm.
2. Tap the New alarm icon (at the top right of the screen) to create an
alarm, or tap an existing alarm to modify and set it.
Existing Alarm
Tap here to modify
this alarm's settings.
Set Alarm ScreenAlarms Screen
155
Tools
3. Scroll the time wheel to set the alarm time (Hour and Minute) and the
time of day (AM or PM).
4. Tap the day(s) when you want the alarm to sound in the Repeat field. If
you don’t tap the Repeat setting, the alarm sounds only the one day you
set it.
5. Tap Snooze duration to set the amount of time to wait before sounding
the alarm again if it's not dismissed. You can set the alarm to ring
repeatedly from 5 minutes up to 1 hour.
6. Tap Vibration to checkmark the setting and have the phone vibrate, in
addition to playing the alarm sound.
7. Tap Alarm sound to set the sound notification. Tap Alarm tone or
Music, select the sound for the alarm, then tap OK. The ringtone plays
briefly when you select it.
8. Slide the button on the Alarm volume slider to the right to increase the
alarm volume and to the left to decrease it. The alarm sound plays to
help you determine the volume you want.
9. Tap Auto app starter to set the app you want to automatically open
when you stop the alarm, then tap OK.
10. Tap Puzzle lock to checkmark the setting, which requires you to wake
up enough to solve a simple puzzle to dismiss the alarm.
11. Tap Memo to enter information about the alarm. For example, to
identify when to use it (e.g., class day).
12. When you’re finished, tap
Save (at the bottom of the screen) to save
and activate the alarm.
Alarm Settings
To access the Alarm settings, from the Alarms tab, tap the Menu icon
(at the upper-right corner of the screen), then tap Settings. The Alarm
settings include Alarm in silent mode, Volume button behavior, and
Puzzle lock.
156 Tools
When the alarm sounds
Tap Dismiss or, if set, use the gesture feature of simply turning the
phone over to stop the alarm.
Tap Snooze to stop the alarm for the snooze duration you set.
NOTE If Puzzle lock is set to On, using the gesture feature of turning the phone over will
snooze the alarm instead of turning it off.
Setting the Timer
The Timer tab can be used to alert you with an audible signal when a set
amount of time has passed.
1. Open the Clock app, then select the Timer tab.
2. Set the time on the digital timer. Tap the Hour, Minute, and/or Second
field(s) then enter the numbers as necessary.
NOTE If you don't need to change the Timer settings, just tap the green Start button on the
time keypad to start the timer immediately.
3. Tap the Menu icon (at the upper-right corner of the screen) >
Settings to set Vibration, Alert sound, and Alert volume for the timer.
4. Tap
the green Start button (at the bottom of the screen)
to begin the time
countdown.
5. Once the alarm sounds, tap
the red Stop button
(at the bottom of the
screen) to stop the timer.
Setting the World Clock
The World clock tab allows you to set up a list of cities to easily check
current times in other time zones with a quick glance.
1. Open the Clock app, then select the World clock tab.
2. Tap the New City icon (at the upper-right corner of the screen), search
through the available cities, then tap the one you want.
NOTE The first time you access the World clock tab, a globe image is displayed in the middle
of the screen. Tap it to add the first city to your list.
157
Tools
Managing the World Clock Cities
Tap the New City icon (at the upper-right corner of the screen) to
select another city for your list.
Tap the Delete icon (at the top of the screen) to select one or more
cities to delete from your list.
Touch and hold an entry in the list to open a Context menu to select Set
daylight saving or Delete.
Using the Stopwatch
The Stopwatch tab allows you to use your phone as a Stopwatch.
1. Open the Clock app, then select the Stopwatch tab.
2. Tap the green Start button (at the bottom of the screen)
to start timing
and tap the red Stop button to stop the time.
You can use the Lap function by tapping the Lap button to record
multiple milestone times within the same timing session.
3. Tap the Reset button to reset the Stopwatch or
tap the green Resume
button
to continue monitoring time.
158 Tools
Maps
The Maps app allows you to find places and get directions.
To open the Maps app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Maps .
Current Location
Tap here to show your current
location on the map.
Local Icon
Tap here to find types of places
near your location.
Maps Menu
Tap here to access Traffic,
Public transit, Bicycling,
Satellite, Terrain, Google Earch,
Settings, Help, Send feedback,
and Tips and Tricks.
My Profile
Tap here to access Reviews,
Saved places, Recently accessed
places, and Offline maps.
Directions Icon
Tap here to get directions to a
destination.
Search Icon
Tap here to open the keyboard to
enter your search.
Maps navigation
Tap the Maps menu (at the lower-left side of the screen) to access
Traffic, Public transit, Bicycling, Satellite, Terrain, Google Earth,
Settings, Help, Send feedback, and Tips and Tricks.
Drag across the screen to move across a displayed map.
Pinch-to-zoom to zoom in or out of the map view.
Maps icons
Tap to open the keyboard to enter your search request.
Red markers indicate search matches.
Tap a marker to open a dialog box that contains a label and additional
location information. You can save the location as a favorite, share the
location, and save the map to use offline.
159
Tools
Tap to get directions to a destination.
Use the starting point to insert My location or select from recent Map
history.
Get directions by Car , Transit , Cycling , or Walking .
Tap the estimated time (at the bottom of the screen) to view the
directions in text format (instead of map view).
Once starting and destination points are entered, you can tap the
reverse icon (on the right side of the screen] to reverse the
directions.
Tap to find types of places near your location.
Tap to access map layers, Settings, Help, Send feedback, and Tips and
Tricks.
Tap to display your current location on the map.
Weather
The Weather app provides a summary of local weather, weather forecasts,
and other city information. Place a Weather widget on your Home screen
for a summary of your local weather and access the Weather app for more
detailed information.
NOTE The Weather widget on your Home screen allows you to quickly view information for
each city in your City list.
To add and use the Weather widget
From the Home screen, tap the Apps icon > the Widgets tab (at the top
of the screen), then touch and hold the desired Weather widget to pick it
up and place it on one of the Home screens.
NOTE There’s a large and a small Weather widget. The following applies to the large Weather
widget.
Tap the Weather widget to access the Weather app.
Tap the Weather widget, then tap the New city icon to add cities to
your list.
160 Tools
Swipe right or left to scroll through the weather information for each of
the cities in your list.
Tap the Refresh icon (at the lower-right corner of the screen or
widget) to update the current weather.
Tap the City list icon (at the top of the Weather app screen) to view
your City list.
To add a city or update your current location
Open the Weather app, then tap the Add icon (at the top of the screen).
Enter a location in the Search city box, then tap the city you want to add.
Tap Current location (at the top of the screen) to update your current
location.
Managing your City list
From the Weather app, tap the Menu icon (at the upper-right corner of
the screen) > Settings > Edit city list.
NOTE You can also access your City list by tapping the City list icon (at the top of the
Weather app screen).
Tap the Add icon (at the top right of the screen) to add another city.
Tap the Delete icon (at the top of the City list screen) to delete a city
from your list.
Touch and drag a city’s handle icon (on the right side of the screen)
to move that city to a new position in your city list. This affects the order
viewed when you swipe horizontally in the Weather app through your
cities.
Changing Weather settings
From the Weather app, tap the Menu icon (at the upper-right corner of
the screen) > Settings.
Data & Synchronization: Update interval.
General Settings: Edit city list, Temperature unit, and Wind speed unit.
161
Tools
Voice Mate
You can ask Voice Mate to perform phone functions using your voice, such
as calling a contact, setting alarms, or searching the web. You can say
“help” to help you get started.
NOTE The Voice Command app and the Voice Search app will also perform phone functions
from your verbal command.
To open the Voice Mate app
From any screen, drag your finger upward from the Touch Keys bar.
When you see the Global access arc, move your finger over the Voice
Mate icon , then lift your finger.
Using the Voice Mate app
1. Open the Voice Mate app.
2. The Speak icon (at the bottom of the screen) illuminates. Say what
you want it to do for you.
If you say “Call Rachel”, Voice Mate will call your contact Rachel.
NOTE Voice Mate confirms found match requests before executing it. To skip confirmation for
exact matches (name or number), access the Voice Mate settings and checkmark Skip
confirmation.
Voice Mate Icons
The following Voice Mate icons are displayed at the bottom of the screen:
Tap to display the Voice Mate user guide with help and examples.
Tap to say a voice command to execute.
Tap to type a command to execute.
Voice Mate settings
To access the Voice Mate settings, activate Voice Mate, then tap the
Settings icon (in the upper-right corner of the screen). Voice Mate
settings include Skip confirmation, Voice feedback, Save events to, Voice
activation, Button vibration, Voice launch command, Voice launch when
charging, Voice launch on Lock screen, and Skip Lock screen.
162 Tools
NOTES When the language setting for Voice Mate is not the same as the default language
setting on your phone, some commands such as launching apps may not work.
  When entering text, you can only use letters or numbers.
  Voice Mate recognizes your speech better when you speak slowly.
Voice Command
You can use the Voice Command app to perform phone functions using
your voice.
To open the Voice Command app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
App tab (if necessary) >
Tools folder
> Voice Command .
Voice Search
You can also use the Voice Search app to perform phone functions using
your voice.
To open the Voice Command app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
App tab (if necessary) > Google folder > Voice Search .
Voice Recorder
The Voice Recorder app records audible files for you to use in a variety of
ways. Use them to simply remind you about something you don’t want to
forget (like a grocery list) or record sound effects that you can attach to a
message.
Record a Voice Memo
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) >
Tools folder
> Voice Recorder .
2. Tap the Record button (at the bottom center of the screen) to start
recording.
3. Speak into the microphone.
163
Tools
4. When you’re finished, tap the Stop button (at the bottom right of the
screen).
The recording is automatically saved to your recordings list.
Recording Mode Icon
Tap here to change the
recording mode (file size).
Storage Icon
Tap here to select where
to save your recording.
Record Button
Tap here to start recording
a voice memo.
List Button
Tap here to view a list of
your recordings.
Voice Record Screen
New Recording Icon
Tap here to record a new
voice memo.
Recording Bar
Displays the recording
playback.
Bookmark Icon
Tap here to bookmark a
spot within your voice
memo.
Trim Icon
Tap here to trim the
recording.
Play Button
Tap here to play (or
pause) your recording.
Volume Button
Tap here to control the
volume.
Tap here to listen to this
voice memo.
Recorded Voice
Memo Screen
Play a Voice Memo
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) >
Tools folder
> Voice Recorder .
2. Tap the List button (at the bottom of the Voice Record screen).
3. Tap the voice memo you want to play.
164 Tools
4. Use the following options (at the bottom of the screen) while listening to
a voice memo.
Tap the Pause button to pause the recording.
Tap the Stop button to end the playback and return to the List
screen.
Tap the Volume button to increase or decrease the volume.
Tap on the slider recording bar to listen to a specific part of the
recording.
Tap the Bookmark icon to mark a place within the recording so you
can jump directly to that spot when you play the recording.
Tap the Trim icon to trim away segments at the beginning or end
of the recording.
Managing your Voice memos
From the Voice Recorder list screen:
Tap the Share icon (at the top of the screen) to share the voice
memo using the available choices.
Tap the Delete icon (at the top of the screen) to select the voice
memo(s) you want to delete.
Touch and hold a voice memo to open a context memo to select Share,
Delete, Rename, Trim, or Details.
File Manager
Use the File Manager app to manage your folders and files stored in your
phone.
File Manager makes it easy to view and manage your files. Simply tap a file
type (All files, Music files, Image files, Video files, Document files, or Cloud
storage), then tap on the necessary folders to find your files.
165
Tools
To open the File Manager app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) >
Tools folder
> File Manager .
File Manager Options
Open the File Manager app, tap All files, then tap the Internal storage
folder to access to the following File Manager options (at the bottom of the
screen):
: Allows you to create a new folder.
: Allows you to move files and folders to another folder.
: Allows you to copy files and folders to another folder.
: Allows you to delete files and folders.
Tap the Menu icon (in the bottom action bar) to access the following
options.
Sort by: Allows you to sort files and folders by Name, Size, Date, or
Type.
View by: Allows you to display your files as a List or in a Grid.
Share: Allows you to select files to share with others.
Zip: Allows you to select files and folders to compress into a .zip file.
Show/Hide hidden files: Allows you to show hidden files or hide them.
Exit: Exits the File Manager app.
Searching in File Manager
Open the File Manager app, tap All files, then tap the Search icon (in
the upper-right corner of the File Manager screen) to search for your files or
information.
QSlide for the File Manager app
While viewing All Files, tap the QSlide icon (at the top of the File
Manager screen) to open File Manager in a QSlide window.
166 Tools
Tasks
The Tasks app can be synchronized with your MS Exchange account. You
can create a task, revise it, and delete it using your phone, or from MS
Outlook or MS Office Outlook Web Access.
To synchronize MS Exchange
1. From the Home screen, touch and hold the Recent Apps Key
(in the
Touch Keys bar) > Settings > Add account (under the Accounts section).
2. Tap Microsoft Exchange, then sign-in using your email address and
password.
3. Checkmark the Sync task checkbox.
To add Tasks
1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > Calendar > Calendar Menu icon > View
Tasks.
2. Tap the Add new task icon (at the top of the screen).
3. Enter the Subject, Due date, Description, Repeat, and Reminder.
4. Tap Save.
Tasks options
While viewing your Tasks screen, tap the Menu icon (at the upper-right
corner of the screen) to access the following:
Sync now Tap to sync your Microsoft Exchange account tasks.
Sort by Tap to select Due date, Priority, or Creation order.
Delete Tap to select tasks to delete.
View completed tasks Tap to view your list of completed tasks.
Lists to display Tap to select which lists to display.
Settings Tap to change your Tasks settings including Notifications,
Notification sound, Vibrate, Pop-up notification, and Accounts.
167
Settings
Settings
The Settings app contains most of the tools for customizing and configuring
your phone. All of the settings in the Settings app are described in this
section. For settings specific to the Chrome app, see the Chrome section
and for settings specific to your Google Account, see the Gmail section.
To open the Settings app
From the Home screen, tap the Apps icon (in the QuickTap bar) > the
Apps tab (if necessary) > the Settings icon .
OR
From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings.
Viewing Settings categories
The settings are grouped into categories.
List view displays each category (5) in capital letters followed by its
related settings. Scroll up and down through the screen.
Tab view displays each category (4) in tabs (at the top of the screen) that
include its related settings. Swipe to the left or right to switch between
tabs or tap a tab to select it.
1. From the Home screen, touch and hold the Recent Apps Key (in the
Touch Keys bar) > Settings.
2. Tap the Menu icon (at the upper-right corner of the screen) > Switch
to tab view (or Switch to list view).
NOTE Instructions to perform tasks in this guide are based on the default List view setting.
168 Settings
WIRELESS & NETWORKS
The Wireless and Networks category allows you to configure and manage
your device’s wireless radio communications.
Airplane mode
Tap the Airplane mode switch to toggle it On or Off. On disables all
wireless connections.
Wi-Fi
Tap the Wi-Fi switch to toggle it On or Off. On connects to a Wi-Fi
network (from your list of available, detected networks). Tap Wi-Fi to
access the following settings to manage your Wi-Fi connection(s):
Show Wi-Fi pop-up: Checkmark to be notified when a Wi-Fi network is
in range when you launch an app.
WI-FI NETWORKS
The list of all of the Wi-Fi networks that are within access range. Tap one
to access it.
Tap the Menu icon (at the upper-right corner of the Wi-Fi menu screen)
to access the following options.
Connect by WPS button: Information to connect to a secured Wi-Fi
network with a WPS button.
Connect by WPS PIN: Information to connect to a secured Wi-Fi network
with a WPS PIN.
Add network: Tap to enter a Wi-Fi name (SSID), choose the Security and
enter the Password to manually add Wi-Fi networks.
Wi-Fi Direct: Allows direct connection with Wi-Fi devices without any
access point.
Advanced Wi-Fi: Accesses the following advanced Wi-Fi settings.
Wi-Fi notifications: Checkmark to notify if Wi-Fi networks are available
nearby or when your device is connected to a Wi-Fi network.
169
Settings
Avoid unstable connections: Checkmark to disconnect the Wi-Fi router
automatically when the Internet is unavailable.
Manage networks: Allows you to specify the order in which your Wi-Fi
networks will be detected.
Sort list by: Sets how your Wi-Fi networks are listed. Choose Signal
strength or Alphabetical order.
Keep Wi-Fi on when screen is off: Sets the Wi-Fi status when the
screen is off. Choose from Yes, Only when plugged in, and No.
Allow Wi-Fi scanning: Checkmark to let Google's location service and
other apps scan for networks, even when Wi-Fi is off.
Wi-Fi signal weak: Checkmark to disconnect Wi-Fi automatically when
the Wi-Fi signal is weak.
Battery saving for Wi-Fi: Checkmark to minimize battery usage when
Wi-Fi is on.
Install certificates: Allows you to install certificates from storage.
MAC address: Displays your phone's MAC address (which may need to
be entered in the router to connect to some wireless networks with
MAC filters).
IP address: Displays your phone's IP address.
Help: Displays information about the Wi-Fi features and settings.
NOTE Tap Search (at the bottom of the screen) to search for in-range Wi-Fi networks.
Bluetooth
Tap the Bluetooth switch
to toggle it On or Off. On allows you to pair
and connect with other Bluetooth devices. Turn it on and tap Bluetooth to
use and manage your Bluetooth devices.
4G LTE: Checkmark to allow other Bluetooth devices to see your
phone for pairing and connection.
AVAILABLE DEVICES
The list of all of the available in-range Bluetooth devices.
170 Settings
Tap the Menu icon (at the upper-right corner of the screen) in the
Bluetooth menu to access the following options.
Edit phone name: Changes your phone name for easy identification
when pairing and connecting. Enter your new phone name, then tap
Save.
Visibility timeout: Sets the amount of time other Bluetooth devices can
see your phone for pairing and connection.
Show received files: Displays a list of your Bluetooth received files.
Turn on/off Audio channel mode: Allows you to use your phone as a
Bluetooth speaker or headset. If connection is not good, pair this phone
on the other Bluetooth device once more and try again. Tap to turn on or
off audio channel mode.
Help: Displays information about Bluetooth features.
NOTE Tap Search for devices (at the bottom of the screen) to search for in-range Bluetooth
devices.
Mobile data
Tap the Mobile data switch to toggle it On or Off. Off disconnects you
from the mobile network so you can't use the Internet unless you use a
Wi-Fi connection. This allows you to manage your mobile data usage. Tap
Mobile data to access the following settings to manage your mobile data
usage:
Limit mobile data usage Checkmark to limit your mobile data. Your mobile
data connection will be disabled when you reach the limit you set. Set your
data usage limit by dragging the red line on the graph provided.
Alert me about data usage Checkmark to allow your phone to alert you
when your mobile data usage reaches the warning amount you set. Set
your warning amount by dragging the orange line on the graph provided.
Data usage cycle: Displays your current data usage cycle. Tap the date
to change the cycle date.
Data usage graph: Displays your data usage on a graph.
Data usage applications: Apps are displayed with their data usage on a
bar graph. Tap one to see more detailed information.
171
Settings
Tap the Menu icon (at the upper-right corner of the mobile data
screen) to access the following advanced options.
Display in MB/GB: Displays data usage using MB or GB.
Data roaming Checkmark to allow you to use a mobile data connection
when you're roaming outside your home network area.
Restrict background data: Checkmark to disable syncing in the
background while using a mobile network.
Auto-sync data: Checkmark to set the phone to sync contact, calendar,
email, bookmark, and social network image data automatically.
Show Wi-Fi usage: Displays a Wi-Fi tab (at the top of the screen) to
display your Wi-Fi usage information.
Mobile hotspots: Displays a list to select and use another device's
mobile network as a mobile hotspot for mobile data usage. Turn on Wi-Fi
and search for mobile hotspots, if necessary. Apps can be restricted
from using these networks when in the background. Apps may also
warn before using these networks for large downloads.
Help: Displays information about Mobile data features.
Call
Voice mail: Sets up your standard voicemail settings.
Service: Changes your voicemail service. The default is My carrier.
Setup: Changes your voicemail access (e.g., the number that dials your
voicemail service).
Notification sound: Sets the sound for new voicemail notification(s).
Vibrate: Sets the vibrate mode for new voicemail notifications. Choose
from Always, While in vibrate only mode, and Never.
OUTGOING CALL
Auto retry: Sets the amount of time to wait before automatically
redialing a call that failed to connect. Choose from Off, 10 sec, 30 sec,
and 60 sec.
172 Settings
Assisted dialing: Configures the Assisted dialing options when you're
traveling outside of your home country.
INCOMING CALL
Incoming voice call pop-up: Checkmark to display an an incoming call
pop-up when an app is in use. Use the pop-up to Answer, Ignore, or
Ignore with message.
Allow ignore with message: Checkmark to enable the Ignore with
message icon on the Incoming Call screen which allows you to ignore
an incoming call and respond to the caller with a specified Quick text
message instead. Tap the Settings icon to manage your Quick text
messages. Tap the New icon
to create a new quick message, tap a
message to edit it, or tap the Delete icon
to delete a message.
Privacy keeper: Sets whether the phone displays the caller's
information when you receive a call. Choose from Hide all info., Show
number only, and Show caller info.
ONGOING CALL
Show dialpad: Sets which types of calls will automatically display the
dialpad. Choose from Voicemail / Toll-Free, All calls, and Customized
number.
TTY mode: Sets the TTY mode to communicate with other TTY devices.
Hearing aids: Checkmark to turn on hearing aid compatibility.
Voice enhancement: Checkmark to enhance voice clarity in noisy
environments, allowing you to hear more clearly.
END CALL
Power key ends call: Checkmark to allow you to end voice calls by
pressing the Power/Lock Key (on the back of the phone) instead of
returning to the Call screen to end the call.
OTHERS
DTMF tones: Sets the length of the DTMF tones. Choose Normal or
Long.
173
Settings
CDMA CALL SETTINGS
Call forwarding: Enables and disables call forwarding. Choose Turn on
call forwarding (and enter the phone number as necessary) or Turn off
call forwarding.
Voice privacy: Checkmark to enable enhanced privacy mode.
Auto answer: Sets the time before a connected hands-free device
automatically answers an incoming call. Choose from Off, 1 sec, 3 sec,
and 5 sec.
GSM CALL SETTINGS
Connection vibration: Checkmark to vibrate when the other party
answers the call.
Call forwarding: Tap to set call forwarding options.
Call barring: Tap to lock incoming and/or outgoing international calls.
Call duration: Tap to check call duration(s).
Additional settings: Tap to set additional settings.
Share & connect
DATA/MEDIA SHARE
NFC: Tap the NFC switch to toggle it On or Off. On allows you to
send or receive files simply by bringing your phone and another data-
compatible device together (typically within 20 mm of each other) at the
NFC touchpoint. NFC (Near Field Communication) establishes radio
communication between smartphones and similar devices. NFC will be
turned off automatically when airplane mode activated. Tap NFC to
access the following settings:
Show NFC Security alerts: Checkmark to display a permission alert
when another device tries to send you information via NFC.
Only every 30 days: Checkmark to show NFC security alerts only
every 30 days.
Read/Peer to Peer: Checkmark to display a confirmation alert when
receiving a contact or URL via NFC.
174 Settings
Connection handover: Checkmark to display a confirmation alert
when pairing devices via NFC.
NFC sound in call: Checkmark to play the NFC alert sound even while
you're on a call.
Tap & pay: When NFC is turned on, you can use the Tap & pay
feature to pay for items just by touching your phone to a reader at a
register. If your phone doesn’t have a default app, you can browse
Google Play Store for other payment apps.
Android Beam: Tap the Android Beam switch to toggle it On or Off.
On allows you to beam app content or files to other mobile devices by
holding them close together. Tap Android Beam to view information on
how to use this feature.
SmartShare Beam: Allows you to receive multimedia content via
SmartShare Beam from another LG phone or tablet.
4G LTE: Allows you to change your phone name for
easy identification when connecting with other devices.
Storage: Opens a dialog box to set your storage. Choose Internal
storage or SD card.
Auto-accept requests: Checkmark to automatically accept
SmartShare Beam requests.
Timeout: Opens a dialog box to set the amount of time before the
SmartShare Beam feature automatically turns off when not in use.
Choose from 5 minutes, 10 minutes, 15 minutes, and Never.
File transfer history: Displays your file transfer history.
Help: Displays help information for the SmartShare Beam feature.
Media server: Tap to share media content with nearby device via DLNA.
NOTE Tap the Menu icon (at the upper-right corner of the the Media server screen) to
access Use DLNA feature.
Content sharing: Checkmark to allow nearby devices to access
content on your phone.
175
Settings
YOUR PHONE
4G LTE: Tap 4G LTE to edit your phone name for
Bluetooth, Wi-Fi Direct, etc., then tap Save. Tap the Image icon to
set your phone image.
Content to share: Sets the types of content your phone is allowed to
share. Checkmark Photos, Videos, or/and Music.
Receive content: Checkmark to allow nearby devices to send content
to your phone.
NEARBY DEVICES
Sharing request: Sets when to accept sharing requests from nearby
devices. Choose Always allow or Always ask.
Allowed devices: Displays nearby devices that can access your
phone.
Not-allowed devices: Displays nearby devices that can't access your
phone.
SCREEN SHARE
Miracast: Tap the Miracast switch to toggle it On or Off. On allows you
to wirelessly mirror your phone screen and sound onto a Miracast dongle
or TV. Tap Miracast to access your list of available devices. Tap Search for
devices or Help (at the bottom of the screen) to refresh the device list or
view help information.
More... (Wireless & networks)
TETHERING
Tethering allows you to connect other devices to your phone's internet
connection and select your connection method.
Mobile Broadband Connect: Tap the Mobile Broadband Connect
switch to toggle it On or Off. On allows you to share your phone's
mobile data connection using a USB connection. This setting is grayed-
out if not connected via USB.
176 Settings
Mobile Hotspot: Tap the Mobile Hotspot switch to toggle it On or
Off. On allows you to use your device as a Mobile Hotspot for other
devices to use your mobile network connection. Tap Mobile Hotspot to
manage access to your mobile hotspot.
Set Up: Sets the SSID and key for your mobile hotspot.
Manage connections: Sets the device(s) allowed to use your hotspot
connection.
Connected devices are listed at the bottom of the screen.
NOTE Tap the Menu icon (at the upper-right corner of the screen), then tap Advanced to
access additional settings including Power Management. Tap Help to display Mobile
Hotspot help information.
Bluetooth tethering: Tap the Bluetooth tethering switch to toggle it
On or Off. On shares the phone's internet connection with other
Bluetooth devices.
Help: Displays information regarding mobile broadband connection,
mobile hotspot, and Bluetooth tethering.
NETWORK
Mobile networks: Sets up options for data roaming, networks, and APNs
(Access Point Names).
Mobile data: Checkmark to enable data access over the mobile
network.
Global data roaming access: Sets up your data services while
roaming. Choose from Deny data roaming access, Allow access only
for this trip, and Allow access for all trips.
System select: Sets your network mode and CDMA roaming mode.
Network mode: Sets the network mode. Choose from Global,
LTE/CDMA, and LTE/GSM/UMTS.
LTE/GSM/UMTS settings: Sets the network submode and network
operators.
Network type and strength: Displays the current network type and
the signal strength.
177
Settings
Access point names: Sets up APN for data service. Tap an APN in the
list, tap the APN name, edit it as necessary, then tap the Menu icon
(at the upper-right corner of the screen), then tap Save or Discard.
Roaming state: Displays your current roaming state.
Default message app: Sets your default messaging app. Choose from
Messaging, Hangouts, and Message+.
VPN: Sets up and manages Virtual Private Networks (VPNs).
Basic VPN: Set your phone to use the built-in Android VPN client
supporting basic features.
LG VPN: Sets your phone to use an advanced LG VPN client
supporting full IP Security features and interoperability. You can add an
LG VPN network or select from your list of VPN connections.
NOTE Tap the Menu icon
(at the upper-right corner of the screen) to access additional
settings. From the Basic VPN setting, it accesses Always on VPN and from the LG VPN
screen it access Import certificates, Settings, and About.
DEVICE
The Device category allows you to configure and manage the general
device functions such as sound and display options.
Sound
BASIC
Silent mode: Sets the Silent mode to Off, Vibrate, or On.
Volumes: Sets individual volume levels for phone Ringtone, Notification
sound, Touch feedback & system, and Music, video, games, and other
media. Move the slider button on each volume bar to set its volume.
Vibrate strength: Allows you to set the vibration strength for calls,
notifications, and touch feedback.
Quiet mode: Tap the Turn Quiet mode switch to toggle it On or Off.
Tap Quiet mode to set up your Quiet mode. You can schedule Quiet
mode to activate automatically and designate exceptions to your Quiet
mode.
178 Settings
Sound profile: Sets the sound level for your Quiet mode. Choose
Silent or Vibrate only.
Set time: Sets when to activate Quiet mode. Choose Always on or
Schedule. If you tap Schedule, you can set the days and times to
automatically turn Quiet mode on.
FEATURES
Block notification light: Checkmark to turn notifications light off.
Block alarms: Checkmark to turn the screen off and turn off all
alarm sound.
Block incoming calls: Checkmark to block all incoming calls.
Incoming call settings: Tap to send auto-reply message for blocked
calls and select contacts from whom to allow calls.
Help: Displays Quiet mode help information.
RINGTONES & VIBRATIONS
Ringtone: Sets the ringtone for calls. You can also add a ringtone by
tapping the New icon (at the upper-right corner of the screen).
Notification sound: Sets the sound for notifications. You can also add a
notification sound by tapping the New icon (at the upper-right corner
of the screen).
Ringtone with vibration: Checkmark to set the phone to vibrate in
addition to the ringtone when you receive calls.
Vibration type: Sets the incoming call vibration options. Choose from
Long Lasting, Rapid, Short repeated, Standard, and Ticktock. Tap the
New icon (at the upper-right corner of the screen) to create your own
vibration pattern.
ADVANCED SETTINGS
Vibrate on tap: Checkmark to vibrate when you touch the screen (e.g.,
touch keys and make selections).
Sound effects: Tap to set dial pad touch tones, touch sounds, screen
lock sound, sound when roaming, or emergency tone.
179
Settings
Dial pad touch tones: Checkmark to play tones when you use dial
pad.
Touch sounds: Checkmark to play a sound when you make screen
selections.
Screen lock sound: Checkmark to play a sound when you lock and
unlock the screen.
Sound when roaming: Checkmark to play a sound when roaming.
Emergency tone: Sets the behavior when an emerency call is placed.
Choose from Off, Alert, and Vibrate.
Message/call voice notifications: Tap the Message/call voice
notifications switch to toggle it On or Off. On allows your phone to
automatically read your incoming calls and/or messages out loud.
Checkmark Calls for caller information, Messages for sender information,
and Read messages for message content. You can also set the readout
language.
Display
SCREEN
Brightness: Adjusts the brightness of the screen. For best battery
performance, use the dimmest comfortable brightness.
Screen timeout: Sets the amount of time before the screen turns off
due to inactivity.
Screen-off effect: Sets the effect seen when you turn off the screen.
Choose from Retro TV, Black hole, and Fade out.
Auto-rotate screen: Checkmark to set the phone to automatically rotate
the screen based on the phone orientation (portrait or landscape).
Daydream: Tap the Daydream switch to toggle it On or Off. On
allows the set screensaver to be displayed when the phone is sleeping
while docked and/or charging. Choose Clock or Google Photos.
FONT
Font type: Sets the type of font used for the phone and menus.
Font size: Sets the size of the font displayed in the phone and menus.
180 Settings
ADVANCED SETTINGS
Smart screen: Checkmark to keep the screen from timing-out when the
phone detects your eyes looking at the screen.
Home touch buttons: Sets the Touch Keys displayed at the bottom of all
of the screens. Set which ones are displayed, their position on the bar,
and what they look like. Select Button combination, Color, Transparent
background, and Hide Home touch buttons.
Notification light: Tap the switch to toggle it On or Off. On will
activate the LED light for the notifications you checkmark.
Home screen
Select Home: Sets the layout of the Home screen. Choose Home
(standard Android layout) or EasyHome (simplified version for users less
familiar with Android navigation).
Smart bulletin: Tap the Smart bulletin switch to toggle it On or Off.
On displays an additional Home screen panel with customized
information. Choose if you want to display LG Health and Smart Tips.
SCREEN
Wallpaper: Sets the wallpaper to use on your Home screen. Select it
from Gallery, Live Wallpapers, Multi-photo, Photos, or Wallpaper
gallery.
Screen swipe effect: Sets the effect when you swipe to change screens.
Choose from Slide, Breeze, Accordion, Panorama, Carousel, Layer,
and Domino.
Allow Home screen looping: Checkmark to allow continuous Home
screen scrolling (loop back to first screen after the last screen).
Allow apps list looping: Checkmark to allow continuous Application
screen scrolling (loop back to first screen after the last screen).
TIPS
Help: Displays information regarding the Home screen items and
functions.
181
Settings
Lock screen
SCREEN SECURITY
Select screen lock: Sets how to secure your phone from unintentional
and/or unauthorized use. Choose from None, Swipe, Face Unlock,
Knock Code, Pattern, PIN, and Password.
Screen swipe effect: Sets the screen swipe effect options. Choose from
Light particle, Vector circle, Mosaic, and Soda.
CUSTOMIZE
Wallpaper: Sets your Lock screen wallpaper. Select it from Gallery or
Wallpaper gallery.
Widgets: Checkmark to show widgets on your Lock screen. To add
widgets to the Lock screen, swipe the Lock screen to the right.
Missed calls & new messages: Checkmark to display notifications for
missed calls and new messages on the Lock screen.
Shortcuts: Allows you to change the shortcuts at the bottom of the
Swipe Lock screen.
Weather animation: Checkmark to show weather animation for your
current location or primary city set in Weather based on auto data
updates.
Contact info for lost phone: Tap to show contact info on the Lock screen
in the event the phone is lost.
LOCK TIME
Security lock timer: Sets the amount of time before the screen
automatically locks after the screen backlight turns off (times-out due to
inactivity).
Power button instantly locks: Checkmark to instantly lock the screen
when the Power/Lock Key is pressed. This setting overrides the
Security lock timer setting.
The Security lock settings depend on the Lock type. The following
settings may also be displayed.
182 Settings
Hidden pattern: Checkmark to display the unlock dot pattern when (and
where) you tap the Lock screen.
Make pattern visible: Checkmark to make your pattern visible while
drawing it.
Hidden PIN: Checkmark to display the keypad when you tap the Lock
screen.
Random PIN entry: Sets the keypad to random numbers so that
someone watching cannot detect your PIN from your hand movements.
Hidden password: Checkmark to display the keyboard when you tap the
Lock screen.
Improve face matching: Sets a more precise detection for face
matching.
Liveness check: Checkmark to require you to blink during face matching
detection (to guard against using a photo of you).
Gestures
Answer an incoming call: Checkmark to enable you to bring the phone
to your ear to automatically answer the incoming call.
Fade out ringtone: Checkmark to enable you to pick up the phone from
a flat surface to fade out the incoming call ringtone.
Silence incoming calls: Checkmark to enable you to flip the phone to
silence the incoming call ringtone.
Snooze or stop alarm: Checkmark to enable you to simply flip the phone
to snooze or stop the alarm.
Pause video: Checkmark to enable you to simply flip the phone to pause
the currently playing video.
Help: Opens a help guide on how to use the Gestures features of your
device.
SENSOR
Motion sensor calibration: Allows you to improve the accuracy of the tilt
and speed of the sensor.
183
Settings
One-handed operation
Dial keypad: Checkmark to enable you to move the dial keypad to the
right or left side of the touchscreen. Simply tap the arrow to move it to
one side or the other.
LG keyboard: Checkmark to enable you to move the keyboard to the
right or left side of the touchscreen. Simply tap the arrow to move it to
one side or the other.
Lock screen: Checkmark to enable you to move the PIN Lock screen
keypad to the right or left side of the touchscreen. Simply tap the arrow
to move it to one side or the other.
Help: Displays information regarding one-handed operation.
Storage
Use the Storage menu to monitor the used and available space in your
phone.
INTERNAL STORAGE
Total space: Displays the total amount of space in the phone’s memory.
It’s listed in Gigabytes and also on a colored bar graph with a color-
coordinated list of the apps as well as the amount of space they use.
Remaining memory space is gray-colored.
SD CARD
Total space: Displays the total amount of your external memory.
Available: Displays the amount of space available in your external
memory.
Mount/Unmount SD card: Allows your phone to recognize your
microSD card and release it to safely remove your microSD card.
Erase SD card: Erases all of the data stored on your microSD card.
NOTE Tap the Menu icon (at the upper-right corner of the Storage screen) to access Display
in MB (or GB) and USB PC connection.
184 Settings
Battery
BATTERY INFORMATION
The Battery charge information is displayed on a battery graphic along
with the percentage of the remaining charge and its status.
Touch the Battery charge icon to display the Battery use screen to see the
battery usage level and battery use details. It displays which components
and apps are using the most battery power. Tap one of the entries to see
more detailed information.
Battery percentage on status bar: Checkmark to display the battery level
percentage on the Status Bar next to the battery icon.
Battery saver
Tap the Battery saver switch to toggle it On or Off. Tap Battery saver
to access the following settings:
Turn Battery saver on: Sets the battery charge percent level that will
automatically turn on Battery saver. Choose from Immediately, 10%
battery, 20% battery, 30% battery, and 50% battery.
BATTERY SAVING ITEMS
Auto-sync: Checkmark to turn off Auto-sync when Battery saver is
activated.
Wi-Fi: Checkmark to turn Wi-Fi off when data is not being used while
Battery saver is activated.
Bluetooth: Checkmark to turn Bluetooth off when not connected
while Battery saver is activated.
Vibrate on tap: Checkmark to turn off touch feedback when Battery
saver is activated.
Brightness: Checkmark to reduce the screen brightness when Battery
saver is activated. Tap the Settings icon to change the setting.
Screen timeout: Checkmark to reduce the screen timeout when
Battery saver is activated. Tap the Settings icon to change the
setting.
185
Settings
Notification light: Checkmark to turn off the LED light for notifications
when Battery saver is activated.
Help: Displays tips for using the Battery saver function.
Smart cleaning
This menu shows the space in use and free space in your phone. Tap
(at the upper-right corner of the screen), then tap Settings to set the
notification interval and idle time period. Tap a folder, then tap Clean (at
the bottom of the screen) to clear the files in that folder to optimize space.
Application manager
Use the Application manager menu to view details about the apps installed on
your phone, manage their data, and force them to stop.
Swipe left and right to select one of the three tabs across the top of the screen
to view detailed information for DOWNLOADED, ON SD CARD, RUNNING,
and ALL apps. Tap an entry to view more information, tap Stop (or Force stop),
then OK to stop an app from running.
Dual window
Split view: Checkmark to automatically open the Dual window feature
when you tap a link on the full screen or tap an email attachment
(images only).
Help: Displays help information about using the Dual window feature.
PERSONAL
The Personal category allows you to configure and manage your personal
information.
Guest mode
Use Guest mode when you let someone else use your phone. They’ll only be
able to use the apps that you’ve selected. Once you set it up, you can easily
put your phone in Guest mode by drawing a specified guest screen lock on the
Lock screen that you set, which is different from your normal screen lock.
186 Settings
Guest mode: Tap the switch (at the upper-right corner of the screen) to
toggle Guest mode On or Off. On allows you to put your phone in Guest
mode from the Lock screen.
HOME SCREEN
Allowed app: Tap to select the apps available in Guest mode.
Wallpaper: Sets the background (wallpaper) for your Guest mode Lock
screen.
LOCK SCREEN
Lock screen type: Tap to create the screen lock sequence for Guest
mode.
Help: Displays information regarding Guest mode.
Location
Use the Location access menu to set your preferences for using and
sharing your location when you search for information and use location-
based apps, such as Maps.
Tap the Location switch (at the upper-right corner of the screen) to
enable sharing of your location.
E911 Location: E911 Location cannot be turned off on any mobile celluar
phone.
Mode: Tap location mode to choose from High accuracy (GPS and
networks), Battery saving (Networks only), and Device sensors only
(GPS only).
RECENT LOCATION REQUEST
Displays information about apps that have requested your location
information.
LOCATION SERVICES
Camera: Checkmark to tag photos or videos with their locations.
Google Location Reporting: Allows Google to periodically store and use
your phone's most recent location data in connection with your Google
Account.
187
Settings
Security
Use the Security menu to configure how to help secure your phone and its
data.
Content lock
Select lock types to lock files in the Gallery app. Choose Password or
Pattern.
ENCRYPTION
Encrypt phone: Allows you to encrypt data on the phone for security.
Each time you turn on your phone, a PIN or password will be required to
decrypt your data.
Encrypt SD card storage: Allows you to encrypt or decrypt external SD
card data. Encrypted data is not accessible to other devices.
SIM CARD LOCK
Set up SIM card lock: Sets the PIN to lock your SIM card and allows you
to change the PIN.
PASSWORDS
Password typing visible: Checkmark to briefly show each character of
the password as you type so that you can see what you enter.
PHONE ADMINISTRATION
Phone administrators: Displays the list of administrators, allowing you
to deactivate device administrators.
Unknown sources: Checkmark to allow installation of non-Play Store
apps.
Verify apps: Checkmark to disallow or warn before installation of apps
that may cause harm to your phone.
Notification access: Checkmark to enable the Lock screen to read your
notifications.
CREDENTIAL STORAGE
Storage type: Displays the current storage type for credentials (e.g.,
Hardware-backed).
188 Settings
Trusted credentials: Allows apps to access your phone’s encrypted store
of secure certificates, related passwords, and other credentials. The
screen has a System tab and a User tab. Credential storage is used to
establish some kinds of VPN and Wi-Fi connections. This setting is
dimmed if you haven't set a password to secure your credential storage.
Install from storage
:
Allows you to install a secure certificate from
storage.
Clear credentials: Deletes all secure certificates and related credentials
and erases the secure storage’s own password. You’re prompted to
confirm you want to clear this data.
Language & input
Use the Language & input menu to select the language for the text on y
our phone and for configuring the on-screen keyboard. You can also
manage your language dictionary for personal words that you’ve added.
Language: Sets the language to use on your device.
KEYBOARD & INPUT METHODS
Default: Sets the default on-screen keyboard to use when entering text.
LG Keyboard: Checkmark to select the LG Keyboard to enter data. Tap the
Settings icon to change the following settings:
MY KEYBOARD
Input language and keyboard layout: Sets the keyboard language
and layout (QWERTY and Phone).
Keyboard height and layout: Allows you to adjust various height and
layout options for you keyboard to make it easier to use.
Bottom row keys: Sets the default keys to display on either side of
the Space Key (on the bottom row of the keyboard). Choose Voice
input, Handwriting, Settings, Clip Tray, and Symbols.
Extended keyboard: Checkmark to display the numeric keys on the
top row.
Keyboard height: Sets the height of the keyboard in comparison to
the screen you’re typing on.
189
Settings
Keyboard theme: Sets the Keyboard theme. Choose White or
Black.
Split keyboard: Checkmark to split the keyboard by spreading your
two fingers (only when in landscape orientation).
One-handed operation: Checkmark to be able to position the
keyboard on the left or right side of the screen for easy one-handed
operation.
SMART INPUT
Path input: Checkmark to enter a word by drawing a path through all
of the letters.
Show word suggestion: Checkmark to show words through text
prediction.
Auto correction: Choose from Off, Mild, Moderate, and Aggressive.
Update word suggestions: Uses Swype Connect to provide more
word suggestions. To use this feature, accept the Agreement Rights.
Additional settings: Sets advanced settings including checkboxes to
enable Vibrate on keypress, Sound on keypress, Pop-up on
keypress, Auto-capitalization, Auto-punctuation, and Spell checker,
In addition, you can access Clear word suggestion history, Personal
dictionary, Languages, and Pen type and color.
Help: Displays additional keyboard help information.
Google voice typing: Checkmark to select Google voice typing to enter
data. Tap the Settings icon to change the Google voice settings.
Choose input languages: Sets the languages supported with Google
voice typing.
GENERAL
Block offensive words: Checkmark to hide recognized offensive text.
Offline speech recognition: Enables voice input while offline.
190 Settings
SPEECH
Voice Search: Sets voice search options.
Language: Sets the Google search by voice language.
“Ok Google” Detection: Tap the switch (at the top of the screen) to
toggle this setting On or Off. On enables you to start the Google
Search app simply by saying “OK Google”.
Speech output: Sets when to use speech output. Choose from On,
Hands-free Only, and Off. To turn on speech output only when you’ve
got a headset attached to your phone, select Hands-free only.
Block offensive words: Checkmark to hide offensive voice results.
Offline speech recognition: Sets one or more additional languages for
speech recognition when you don’t have a network connection.
Bluetooth headset: Checkmark to record audio through a connected
Bluetooth headset.
Text-to-speech output: Sets the preferred speech engine and speech
rate (very slow to very fast). Also plays a short demonstration of speech
synthesis and displays the language status.
MOUSE/TRACKPAD
Pointer speed: Sets the pointer speed on a slide bar.
Backup & reset
This menu allows you to back up and/or erase your data.
BACKUP & RESTORE
Back up my data: Checkmark to backup app data, Wi-Fi passwords, and
other settings to Google servers.
Backup account: Sets the account to backup.
Automatic restore: Checkmark to allow the phone to automatically
restore backed up settings and data when an app is reinstalled on the
phone.
191
Settings
LG BACKUP
LG Backup service: Allows you to backup and restore your phone's data.
You can also schedule backups.
PERSONAL DATA
Factory data reset: Allows you to erase all of the data on the phone.
Read the warning, then tap Reset phone at the bottom of the screen,
then tap Erase everything to confirm.
Reset settings: Tap to restore the default system settings.
ACCOUNTS
Google: Manages your Google Account(s).
ACCOUNTS: Displays your Google Account(s).
PRIVACY
Search: Displays your sign-in account information and allows you to
manage your search settings including turning on Google Now, your
phone search settings, your voice search settings, your accounts and
privacy settings, and access to help & feedback.
Location: Allows you to activate your location setting by tapping (at
the top of the screen). Also displays Recent location requests and
Location services regarding how apps can access and use your
location.
Google+: Displays your Google+ settings.
Ads: Displays your advertising ID, allows you to reset your advertising
ID, Opt out checkbox, and information about Google ads in apps on
your phone.
Add account: Allows you to add accounts to your phone.
192 Settings
SYSTEM
The System category allows you to view your phone’s system information,
as well as manage various system settings.
Shortcut key
Tap the Shortcut key switch (at the upper-right corner of the screen) to
toggle it On or Off. On allows quick access to apps by pressing and holding
the Volume Keys (on the back of the phone) when the screen is off or
locked. Press and hold the Volume Up Key to access QuickMemo+. Press
and hold the Volume Down Key access the Camera app.
Date & time
Automatic date & time: Checkmark to use the network-provided date and
time.
Automatic time zone: Checkmark to use the network-provided time zone.
Set date: Tap to manually set the date to use for your phone. This setting is
grayed-out when the Automatic date & time setting is checkmarked.
Set time: Tap to manually set the time to use for your phone. This
setting is grayed-out when the Automatic date & time setting is
checkmarked.
Select time zone: Tap to select select a time zone other than the one
provided by the network. This setting is grayed-out when the Automatic
time zone setting is checkmarked.
Use 24-hour format: Checkmark to display the time using the 24-hour
time format (for example, 13:00 instead of 1:00 pm).
Select date format: Sets the format for displaying dates.
193
Settings
Accessibility
Improves accessibility for users who have impaired vision, hearing, or
reduced dexterity.
VISION
TalkBack: Tap the TalkBack switch (at the upper-right corner of the
screen) to toggle it On or Off. On allows you to set up the TalkBack
function which assists people with impaired vision by providing verbal
feedback. Tap Settings (at the bottom of the screen) to adjust the
TalkBack settings.
When TalkBack is turned on, the touchscreen settings require the user
to first tap an item they want to select, and then double tap the item
again in order to access this feature.
NOTE Passwords can be heard as they are entered when headsets are connected to the phone
unless settings are changed to read passwords aloud without a headset.
Font size: Sets the font size. Choose from Minimum, Small, Medium,
Large, Very large, and Maximum.
Invert color: Checkmark to invert the screen color contrast for people
with difficulty perceiving colors.
Color adjustment: Tap the Color adjustment switch (at the upper-
right corner of the screen) to toggle it On or Off. On allows you to adjust
contrast and hue by dragging your finger across the screen.
Touch zoom: Tap the Touch zoom switch (at the upper-right corner of
the screen) to toggle it On or Off. On allows you to zoom in and out by
triple-tapping the screen.
Message/call Voice notifications: Tap the Voice notifications switch
(at the upper-right corner of the screen) to toggle it On or Off. On allows
you to hear automatic spoken alerts for incoming calls and messages.
READ OUT LOUD
Calls: Checkmark to read caller information out loud.
Messages: Checkmark to read sender information out loud.
Read messages: Checkmark to read messages out loud.
194 Settings
LANGUAGE
Message/call voice notifications Language: Tap to set Text-to-speech
output. Choose Google Text-to-speech or LG TTS+. If you choose
Google Text-to-speech, tap the Settings icon to set Language
and Settings for Google Text-to-speech Engine, and Install voice
data. If you choose LG TTS+, tap the Settings icon to set
Language and Settings for LG TTS+.
Speech rate: Sets the speech rate. Choose from Very slow, Slow,
Normal, Fast, and Very fast.
Listen to an example: Tap to play a short demonstration of
Text-to-speech.
Default language status: English (United States) is fully supported.
Lower screen brightness: Checkmark to dim the screen's backlight for a
darker contrast.
Accessibility shortcut: Tap the Accessibility shortcut switch (at the
upper-right corner of the screen) to open Accessibility quickly on any
screen.
Text-to-speech output: Tap to customize text-to-speech (TTS) settings.
HEARING
Audio type: Sets the audio type. Choose Mono or Stereo.
Sound balance: Routes the sound through both the right and left
channel when a headset is connected. To manually set the audio route,
move the slider on the sound balance slide bar to set it.
Notification LED: Tap the Notification LED switch (at the upper-right
corner of the screen) to toggle it On or Off. On activates the LED light
for incoming calls and notifications.
Flash alerts: Checkmark to allow a flash to blink for incoming calls and
notifications.
Call reject message: Checkmark to send a message customized for
those with hearing impairments when a call is rejected.
Turn off all sounds: Checkmark to turn off all sounds.
195
Settings
Captions: Tap the Captions switch (at the upper-right corner of the
screen) to toggle it On or Off. On customizes caption settings for those
with hearing impairments. Set Language, Font size, and Caption style.
PHYSICAL AND MOTOR
Touch feedback time: Sets the touch feedback. Choose from Short,
Medium, and Long.
Universal touch: Tap the Universal touch switch to toggle it On or
Off. On allows you to replace the hardware keys with a Universal touch
board that is displayed on the touchscreen. Tap the Universal touch
icon to be able to tap its Power button, Home button, Volume down
button, Volume up button, and the more button (Screen capture button,
Settings button, and Pinch button). Draw a "C" ("call") on the board to
automatically display the Dial tab. Draw an "M" on the board to
automatically display the Messaging app. Draw a "W" ("web") on the
board to automatically launch the Chrome app. Draw an "S" ("Settings")
on the board to automatically display the settings app. Draw an "L" ("Lock
screen") on the board to go directly to the Lock screen.
Screen timeout: Sets the screen timeout. Choose from 15 seconds, 30
seconds, 1 minute, 2 minutes, 5 minutes, 10 minutes,
15 minutes, 30 minutes, and Keep screen turned on.
RECOGNITION
Touch control areas: Tap the Touch control areas switch (at the
upper-right corner of the screen) to toggle it On or Off. On allows you to
select an area of the screen to limit touch control. Press the Volume
Down Key and tap the Home Key at the same time to activate and
deactivate this feature.
SYSTEM
Auto-rotate screen: Checkmark to allow the phone to rotate the screen
depending on the phone orientation (portrait or landscape).
Password voice confimation: Checkmark so that your phone can read
passwords you enter.
Power key ends call: Checkmark so that you can end voice calls by
pressing the Power/Lock Key (on the back of the phone). When
196 Settings
enabled, pressing the Power/Lock Key during a call does not lock the
screen.
Accessibility settings shortcut: Sets quick, easy access to selected
features when you triple-tap the Home Key (in the Touch Keys bar).
Choose from Off, Show all, TalkBack, Invert colors, Universal touch,
and Accessibility settings.
One-touch input: Checkmark to enable one-touch input. It allows each
finger touch to enter letter or character on the LG keyboard.
SERVICES
Displays the list of accessibility services installed on your phone.
QuickCircle case
Select apps: Sets the apps that can be used directly in the case’s window
without opening the case.
Auto-unlock screen: Checkmark to automatically unlock the screen when
you open the case and the screen lock is set to swipe.
Help: Displays QuickCircle case information.
Printing
Cloud Print: Tap the Cloud Print switch (at the top of the screen) to
toggle it On or Off. On searches for printers and allows you to select a
printer via the Cloud feature.
About phone
This menu allows you to manage your software updates and view various
information relating to your device.
Phone name: Tap to edit your phone name.
Network: Displays your Network, Network type and strength, Service
state, Roaming state, Mobile network state, and IP address.
Status: Displays your phone number, IMEI, IMEISV, IMS registration
status, ICCID, and Last factory data reset.
197
Settings
Battery: Displays Battery status, Battery level, and Battery use.
Hardware information: Displays Model number, Hardware version, Up
time, Lifetime calls, Warranty Date Code, Wi-Fi MAC address, and
Bluetooth address.
Software information: Displays Android version, Baseband version, Kernel
version, Build number, Software version, and Software status.
Legal information: Displays open source licenses and Google legal
information.
Patent information: Displays LG patent information.
System updates
Check system update status: Tap to check system update status.
Check for new system update: Tap to check for new system update.
198 Safety
WARNING: This product contains chemicals known to the State of
California to cause cancer and birth defects or reproductive harm.
Call (800) 243-0000 for more information.
Wash hands after handling.
HAC
This phone has been tested and rated for use with hearing aids for some of
the wireless technologies that it uses. However, there may be some newer
wireless technologies used in this phone that have not been tested yet for
use with hearing aids. It is important to try the different features of this
phone thoroughly and in different locations, using your hearing aid or
cochlear implant, to determine if you hear any interfering noise. Consult
your service provider or the manufacturer of this phone for information on
hearing aid compatibility. If you have questions about return or exchange
policies, consult your service provider or phone retailer.
Any changes or modifications not expressly approved in this user guide
could void your warranty for this equipment. Use only the supplied antenna.
Use of unauthorized antennas (or modifications to the antenna) could impair
call quality, damage the phone, void your warranty and/or violate FCC
regulations.
Don’t use the phone with a damaged antenna. A damaged antenna could
cause a minor skin burn. Contact your local dealer for a replacement
antenna
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications Commission (FCC) of the
United States, with its action in Report and Order FCC 96-326, adopted an
updated safety standard for human exposure to Radio Frequency (RF)
electromagnetic energy emitted by FCC regulated transmitters. Those
guidelines are consistent with the safety standard previously set by both
U.S. and international standards bodies. The design of this phone complies
with the FCC guidelines and these international standards.
199
Safety
Body-worn Operation
This device was tested for typical body-worn operations with the back of
the phone kept 0.39inches (1cm) between the user’s body and the back of
the phone. To comply with FCC RF exposure requirements, a minimum
separation distance of 0.39 inches (1cm) must be maintained between the
user’s body and the back of the phone. Third-party belt-clips, holsters, and
similar accessories containing metallic components may not be used.
Body-worn accessories that cannot maintain 0.39 inches (1cm) separation
distance between the user’s body and the back of the phone, and have not
been tested for typical body-worn operations may not comply with FCC RF
exposure limits and should be avoided.
Caution
Use only the supplied antenna. Use of unauthorized antennas (or
modifications to the antenna) could impair call quality, damage the phone,
void your warranty and/or violate FCC regulations.
Don’t use the phone with a damaged antenna. A damaged antenna could
cause a minor skin burn. Contact your local dealer for a replacement
antenna.
Part 15.19 statement
This device complies with part15 of FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Part 15.21 statement
Changes or modifications that are not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
200 Safety
residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The phone by LG operates on Verizon’s 4G LTE network, based on Long
Term Evolution (LTE) technology and Mobile Broadband 4G networks in the
United States*. Now you can connect easily at high speeds to the Internet,
your corporate Intranet, and your email while you’re away from the office.
* Service not available everywhere. Visit website
(verizonwireless.com/4G) for a complete list of available areas.
* Information subject to change.
Wi-Fi Caution
This device is capable of operating in 802.11a/n/ac mode. For 802.11a/n/ac
devices operating in the frequency range of 5.15 - 5.25 GHz, they are
restricted for indoor operations to reduce any potential harmful interference
for Mobiles Satellite Services (MSS) in the US.
Wi-Fi Access Points that are capable of allowing your device to operate in
802.11a/n/ac mode(5.15 - 5.25 GHz band) are optimized for indoor use only.
If your Wi-Fi network is capable of operating in this mode, please restrict
your Wi-Fi use indoors to not violate federal regulations to protect Mobile
Satellite Services.
201
Safety
Consumer Information About Radio Frequency
Emissions
Your wireless phone, which contains a radio transmitter and receiver,
emits radio frequency energy during use. The following consumer
information addresses commonly asked questions about the health
effects of wireless phones.
Are wireless phones safe?
Scientific research on the subject of wireless phones and radio frequency
(“RF”) energy has been conducted worldwide for many years, and
continues. In the United States, the Food and Drug Administration (“FDA”)
and the Federal Communications Commission (“FCC”) set policies and
procedures for wireless phones. The FDA issued a website publication on
health issues related to cell phone usage where it states, “The scientific
community at large … believes that the weight of scientific evidence does
not show an association between exposure to radiofrequency (RF) from cell
phones and adverse health outcomes. Still the scientific community does
recommend conducting additional research to address gaps in knowledge.
That research is being conducted around the world and the FDA continues
to monitor developments in this field. You can access the joint FDA/FCC
website at http://www.fda.gov (under “c”in the subject index, select Cell
Phones > Research). You can also contact the FDA toll-free at (888)
463-6332 or (888) INFO-FDA. In June 2000, the FDA entered into a
cooperative research and development agreement through which additional
scientific research is being conducted. The FCC issued its own website
publication stating that “there is no scientific evidence that proves that
wireless phone usage can lead to cancer or a variety of other problems,
including headaches, dizziness or memory loss.” This publication is
available at http://www.fcc.gov/cgb/ cellular.html or through the FCC at
(888) 225-5322 or (888) CALL-FCC.
What does “SAR” mean?
In 1996, the FCC, working with the FDA, the U.S. Environmental Protection
Agency, and other agencies, established RF exposure safety guidelines for
wireless phones in the United States. Before a wireless phone model is
202 Safety
available for sale to the public, it must be tested by the manufacturer and
certified to the FCC that it does not exceed limits established by the FCC.
One of these limits is expressed as a Specific Absorption Rate, or “SAR.”
SAR is a measure of the rate of absorption of RF energy in the body. Tests
for SAR are conducted with the phone transmitting at its highest power
level in all tested frequency bands. Since 1996, the FCC has required that
the SAR of handheld wireless phones not exceed 1.6 watts per kilogram,
averaged over one gram of tissue.
Although the SAR is determined at the highest power level, the actual SAR
value of a wireless phone while operating can be less than the reported
SAR value. This is because the SAR value may vary from call to call,
depending on factors such as proximity to a cell site, the proximity of the
phone to the body while in use, and the use of hands-free devices. For
more information about SARs, see the FCC’s OET Bulletins 56 and 65 at
http://www.fcc.gov/Bureaus/Engineering_Technology/Documents/bulletins
or visit the Cellular Telecommunications Industry Association website at
http://www.ctia.org/consumer_info/index.cfm/AID/10371. You may also
wish to contact the manufacturer of your phone.
Can I minimize my RF exposure?
If you are concerned about RF, there are several simple steps you can take
to minimize your RF exposure. You can, of course, reduce your talk time.
You can place more distance between your body and the source of the RF,
as the exposure level drops off dramatically with distance. The FDA/FCC
website states that “hands-free kits can be used with wireless phones for
convenience and comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source of the RF
emissions, will not be placed against the head. On the other hand, if the
phone is mounted against the waist or other part of the body during use,
then that part of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety requirements regardless
of whether they are used against the head or against the body. Either
configuration should result in compliance with the safety limit.” Also, if you
use your wireless phone while in a car, you can use a phone with an
antenna on the outside of the vehicle. You should also read and follow your
203
Safety
wireless phone manufacturer’s instructions for the safe operation of your
phone.
Do wireless phones pose any special risks to children?
The FDA/FCC website states that “the scientific evidence does not show a
danger to users of wireless communication devices, including children.”
The FDA/FCC website further states that “some groups sponsored by
other national governments have advised that children be discouraged from
using wireless phones at all”. For example, the Stewart Report from the
United Kingdom [“UK”] made such a recommendation in December 2000.
In this report a group of independent experts noted that no evidence exists
that using a cell phone causes brain tumors or other ill effects. [The UK’s]
recommendation to limit cell phone use by children was strictly
precautionary; it was not based on scientific evidence that any health
hazard exists. A copy of the UK’s leaflet is available at http://www.dh.gov.uk
(search “mobile”), or you can write to: NRPB, Chilton, Didcot, Oxon OX11
ORQ, United Kingdom. Copies of the UK’s annual reports on mobile phones
and RF are available online at www.iegmp.org.uk and http://www.hpa.org.
uk/radiation/ (search “mobile”). Parents who wish to reduce their children’s
RF exposure may choose to restrict their children’s wireless phone use.
Where can I get further information about RF emissions?
For further information, see the following additional resources (websites
current as of April 2005):
U.S. Food and Drug Administration
FDA Consumer magazine November-December 2000
Telephone: (888) INFO-FDA
http://www.fda.gov (Under “c” in the subject index, select Cell Phones >
Research.)
U.S. Federal Communications Commission
445 12th Street, S.W. Washington, D.C. 20554
Telephone: (888) 225-5322
http://www.fcc.gov/oet/rfsafety
204 Safety
Independent Expert Group on Mobile Phones
http://www.iegmp.org.uk
Royal Society of Canada Expert Panels on Potential Health Risks of Radio
Frequency Fields from Wireless Telecommunication Devices
283 Sparks Street Ottawa, Ontario K1R 7X9 Canada
Telephone: (613) 991-6990
http://www.rsc.ca/index.php?page=Expert_Panels_RF&Lang_id=120
World Health Organization
Avenue Appia 20 1211 Geneva 27 Switzerland
Telephone: 011 41 22 791 21 11
http://www.who.int/mediacentre/factsheets/fs193/en/
International Commission on Non-Ionizing Radiation Protection
c/o Bundesamt fur Strahlenschutz Ingolstaedter Landstr. 1 85764
Oberschleissheim Germany
Telephone: 011 49 1888 333 2156
http://www.icnirp.de
American National Standards Institute
1819 L Street, N.W., 6th Floor Washington, D.C. 20036
Telephone: (202) 293-8020
http://www.ansi.org
National Council on Radiation Protection and Measurements
7910 Woodmont Avenue, Suite 800 Bethesda, MD 20814-3095
Telephone: (301) 657-2652
http://www.ncrponline.org
Engineering in Medicine and Biology Society, Committee on Man and
Radiation (COMAR) of the Institute of Electrical and Electronics Engineers
http://ewh.ieee.org/soc/embs/comar/
205
Safety
Consumer Information on SAR
(Specific Absorption Rate)
This model phone meets the government’s requirements for exposure to
radio waves. Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits for exposure
to Radio Frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on standards that were
developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies. The standards include a
substantial safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using
standard operating positions specified by the FCC with the phone
transmitting at its highest certified power level in all tested frequency
bands. Although SAR is determined at the highest certified power level, the
actual SAR level of the phone while operating can be well below the
maximum value. Because the phone is designed to operate at multiple
power levels to use only the power required to reach the network, in
general, the closer you are to a wireless base station antenna, the lower
the power output.
Before a phone model is available for sale to the public, it must be tested
and certified to the FCC that it does not exceed the limit established by the
government-adopted requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the ear and worn on the body)
as required by the FCC for each model.
206 Safety
The FCC has granted an Equipment Authorization for this model phone with
all reported SAR levels evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model phone is on file with
the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/ea/fccid after searching on FCC ID ZNFUS991.
Additional information on Specific Absorption Rates (SAR) can be found on
the Cellular Telecommunications Industry Association (CTIA) website at
http://www.ctia.org/.
* In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in
measurements.
FCC Hearing-Aid Compatibility (HAC) Regulations
for Wireless Devices
On July 10, 2003, the U.S. Federal Communications Commission (FCC)
Report and Order in WT Docket 01-309 modified the exception of wireless
phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to
require digital wireless phones be compatible with hearing-aids. The intent
of the HAC Act is to ensure reasonable access to telecommunications
services for persons with hearing disabilities.
While some wireless phones are used near some hearing devices (hearing
aids and cochlear implants), users may detect a buzzing, humming, or
whining noise. Some hearing devices are more immune than others to this
interference noise, and phones also vary in the amount of interference they
generate.
The wireless telephone industry has developed a rating system for wireless
phones, to assist hearing device users to find phones that may be
compatible with their hearing devices. Not all phones have been rated.
207
Safety
Phones that are rated have the rating on their box or a label located on the
box.
The ratings are not guarantees. Results will vary depending on the user’s
hearing device and hearing loss. If your hearing device happens to be
vulnerable to interference, you may not be able to use a rated phone
successfully. Trying out the phone with your hearing device is the best way
to evaluate it for your personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely
to generate less interference to hearing devices than phones that are not
labeled. M4 is the better/higher of the two ratings.
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to
generate less interference to hearing devices than phones that are not
labeled. T4 is the better/ higher of the two ratings.
Hearing devices may also be rated. Your hearing device manufacturer or
hearing health professional may help you find this rating. Higher ratings
mean that the hearing device is relatively immune to interference noise.
The hearing aid and wireless phone rating values are then added together.
A sum of 5 is considered acceptable for normal use. A sum of 6 is
considered for best use.
In the above example, if a hearing aid meets the M2 level rating and the
wireless phone meets the M3 level rating, the sum of the two values equal
M5. This should provide the hearing aid user with “normal usage” while
using their hearing aid with the particular wireless phone. “Normal usage”
in this context is defined as a signal quality that’s acceptable for normal
operation.
The M mark is intended to be synonymous with the U mark. The T mark is
intended to be synonymous with the UT mark. The M and T marks are
recommended by the Alliance for Telecommunications Industries Solutions
208 Safety
(ATIS). The U and UT marks are referenced in Section 20.19 of the FCC
Rules. The HAC rating and measurement procedure are described in the
American National Standards Institute (ANSI) C63.19 standard.
To ensure that the Hearing Aid Compatibility rating for your phone is
maintained, secondary transmitters such as Bluetooth and WLAN
components must be disabled during a call.
For information about hearing aids and digital wireless phones:
Wireless Phones and Hearing Aid Accessibility
http://www.accesswireless.org/
Gallaudet University, RERC
http://tap.gallaudet.edu/Voice/
FCC Hearing Aid Compatibility and Volume Control
http://www.fcc.gov/cgb/dro/hearing.html
The Hearing Aid Compatibility FCC Order
http://hraunfoss.fcc.gov/edocs_public/attachmatch/FCC-03-168A1.pdf
Hearing Loss Association of America [HLAA]
http://hearingloss.org/content/telephones-and-mobile-devices
This device has been shown to be HAC compatible for CDMA, GSM,
LTE, and UMTS. Hearing Aid Compatibility = M3/T3.
Caution:
Avoid potential hearing loss.
Prolonged exposure to loud sounds (including music) is the most common
cause of preventable hearing loss. Some scientific research suggests that
using portable audio devices, such as portable music players and cellular
telephones, at high volume settings for long durations may lead to
permanent noise-induced hearing loss. This includes the use of
headphones (including headsets, earbuds and Bluetooth® or other wireless
devices). Exposure to very loud sound has also been associated in some
209
Safety
studies with tinnitus (a ringing in the ear), hypersensitivity to sound and
distorted hearing. Individual susceptibility to noise-induced hearing loss and
other potential hearing problems varies.
The amount of sound produced by a portable audio device varies depending
on the nature of the sound, the device, the device settings and the
headphones. You should follow some commonsense recommendations
when using any portable audio device:
Set the volume in a quiet environment and select the lowest volume at
which you can hear adequately.
When using headphones, turn the volume down if you cannot hear the
people speaking near you or if the person sitting next to you can hear
what you are listening to.
Do not turn the volume up to block out noisy surroundings. If you choose
to listen to your portable device in a noisy environment, use noise-
cancelling headphones to block out background environmental noise.
Limit the amount of time you listen. As the volume increases, less time is
required before your hearing could be affected.
Avoid using headphones after exposure to extremely loud noises, such as
concerts, that might cause temporary hearing loss. Temporary hearing
loss might cause unsafe volumes to sound normal.
Do not listen at any volume that causes you discomfort. If you experience
ringing in your ears, hear muffled speech or experience any temporary
hearing difficulty after listening to your portable audio device, discontinue
use and consult your doctor.
TIA Safety Information
The following is the complete TIA Safety Information for wireless handheld
phones.
Exposure to Radio Frequency Signal
Your wireless handheld portable phone is a low power radio transmitter and
receiver. When ON, it receives and sends out Radio Frequency (RF) signals.
210 Safety
In August, 1996, the Federal Communications Commissions (FCC) adopted
RF exposure guidelines with safety levels for handheld wireless phones.
Those guidelines are consistent with the safety standards previously set by
both U.S. and international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986)
ICNIRP (1996)
* American National Standards Institute; National Council on Radiation
Protection and Measurements; International Commission on Non-Ionizing
Radiation Protection.
Those standards were based on comprehensive and periodic evaluations
of the relevant scientific literature. For example, over 120 scientists,
engineers, and physicians from universities, government health agencies,
and industry reviewed the available body of research to develop the ANSI
Standard (C95.1).
The design of your phone complies with the FCC guidelines (and those
standards)
Antenna Care
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the phone and may
violate FCC regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you would any other telephone
with the antenna pointed up and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
Don’t touch the antenna unnecessarily when the phone is in use. Contact
with the antenna affects call quality and may cause the phone to operate at
a higher power level than otherwise needed.
211
Safety
Electronic Devices
Most modern electronic equipment is shielded from RF signals. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6) inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers:
Should ALWAYS keep the phone more than six (6) inches from their
pacemaker when the phone is turned ON;
Should not carry the phone in a breast pocket;
Should use the ear opposite the pacemaker to minimize the potential for
interference;
Should turn the phone OFF immediately if there is any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your service provider
(or call the customer service line to discuss alternatives).
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if it is adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
information.
212 Safety
Health Care Facilities
Turn your phone OFF in health care facilities when any regulations posted in
these areas instruct you to do so. Hospitals or health care facilities may use
equipment that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also consult the
manufacturer of any equipment that has been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so require.
Aircraft
FCC regulations prohibit using your phone while in the air. Switch OFF your
phone before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF when in
a “blasting area” or in areas posted: “Turn off two-way radio”. Obey all
signs and instructions.
Potentially Explosive Atmosphere
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always
marked clearly. Potential areas may include: fueling areas (such as gasoline
stations); below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles (such as grain,
dust, or metal powders); and any other area where you would normally be
advised to turn off your vehicle engine.
213
Safety
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects, including either
installed or portable wireless equipment, in the area over the air bag or in
the air bag deployment area. If in-vehicle wireless equipment is improperly
installed and the air bag inflates, serious injury could result.
Safety Information
Please read and observe the following information for safe and proper use
of your phone and to prevent damage.
Caution
Violation of the instructions may cause minor or serious damage to
the product.
Do not disassemble or open crush, bend or deform, puncture or shred.
Do not modify or remanufacture, attempt to insert foreign objects into the
battery, immerse or expose to water or other liquids, expose to fire,
explosion or other hazard.
Only use the battery for the system for which it is specified.
Only use the battery with a charging system that has been qualified with
the system per CTIA Certification Requirements for Battery System
Compliance to IEEE1725. Use of an unqualified battery or charger may
present a risk of fire, explosion, leakage, or other hazard.
Do not short circuit a battery or allow metallic conductive objects to
contact battery terminals.
Replace the battery only with another battery that has been qualified with
the system per this standard, IEEE-Std-1725. Use of an unqualified
battery may present a risk of fire, explosion, leakage or other hazard.
Only authorized service providers shall replace battery (If the battery is
non-user replaceable).
Promptly dispose of used batteries in accordance with local regulations.
Battery usage by children should be supervised.
214 Safety
Avoid dropping the phone or battery. If the phone or battery is dropped,
especially on a hard surface, and the user suspects damage, take it to a
service center for inspection.
Improper battery use may result in a fire, explosion or other hazard.
Charger and Adapter Safety
The charger and adapter are intended for indoor use only.
Insert the battery charger vertically into the wall power socket.
Only use the LG-approved battery charger. Otherwise, you may cause
serious damage to your phone.
Use the correct adapter for your phone when using the battery charger
abroad.
Battery Information and Care
Always unplug the charger from the wall socket after the phone is fully
charged to save unnecessary power consumption of the charger.
Please read the manual for the specified charger to learn how to charge
it.
Do not damage the power cord by bending, twisting, or heating. Do not
use the plug if it is loose as it may cause electric shock or fire.
Do not place any heavy items on the power cord. Do not allow the power
cord to be crimped as it may cause electric shock or fire.
Unplug the power cord prior to cleaning your phone, and clean the power
plug pin when it’s dirty. When using the power plug, ensure that it’s firmly
connected. If not, it may cause excessive heat or fire. If you put your
phone in a pocket or bag without covering the receptacle of the phone
(power plug pin), metallic articles (such as a coin, paperclip or pen) may
short-circuit the phone. Always cover the receptacle when not in use.
Recharge the battery after long periods of non-use to maximize battery
life. Battery life will vary due to usage pattern and environmental
conditions.
215
Safety
Please use only an approved charging accessory to charge your LG
phone. Improper handling of the charging port, as well as the use of an
incompatible charger, may cause damage to your phone and void the
warranty.
The charging temperature range is regulated between 32°F (0°C) and
113°F (45°C). Do not charge the battery outside of the recommended
temperature range. Charging outside this range might cause excessive
heat generation, serious battery damage, and deterioration of battery’s
characteristics and cycle life.
Do not use or leave the phone in direct sunlight or in a car heated by
sunshine. The battery may generate excessive heat, smoke, or flame. It
also might cause deterioration of battery’s characteristics or cycle life.
If skin or clothing is smeared with liquid from the battery, wash with fresh
water. It may cause the skin inflammation.
Please take your phone to an authorized service center immediately if this
occurs.
Do not handle the phone with wet hands while charging. It may cause an
electric shock or seriously damage your phone.
Do not place or answer calls while charging the phone as it may short-
circuit the phone and/or cause electric shock or fire.
The charger and adapter are intended for indoor use only.
Insert the battery charger horizontally into the wall power socket.
Talking on your phone for an extended period of time may reduce call
quality due to heat generated during use.
Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or
detergents to clean your phone as this could cause a fire.
Do not place or answer calls while charging the phone as it may short-
circuit the phone and/or cause electric shock or fire.
216 Safety
Explosion, Shock, and Fire Hazards
Do not put your phone in a place subject to excessive dust and keep the
minimum required distance between the power cord and heat sources.
Unplug the power cord prior to cleaning your phone, and clean the power
plug pin when it’s dirty.
When using the power plug, ensure that it’s firmly connected. If not, it
may cause excessive heat or fire.
If you put your phone in a pocket or bag without covering the receptacle
of the phone (power plug pin), metallic articles (such as a coin, paperclip
or pen) may short-circuit the phone and may cause an explosion. Always
cover the receptacle when not in use.
General Notice
Do not place items containing magnetic components such as a credit
card, phone card, bank book, or subway ticket near your phone. The
magnetism of the phone may damage the data stored in the magnetic
strip.
Talking on your phone for a long period of time may reduce call quality
due to heat generated during use.
When the phone is not used for a long period time, store it in a safe place
with the power cord unplugged.
Using the phone in proximity to receiving equipment (i.e., TV or radio)
may cause interference to the phone.
Do not use the phone if the antenna is damaged. If a damaged antenna
contacts skin, it may cause a slight burn. Please contact an LG Authorized
Service Center to replace the damaged antenna.
Do not immerse your phone in water, liquid, or expose to high humidity. If
the phone is expose to liquid, turn it off immediately and bring it to an LG
Authorized Service Center.
Do not paint your phone.
217
Safety
The data saved in your phone might be deleted due to careless use,
repair of the phone, or upgrade of the software. Please backup your
important phone numbers (Ringtones, text messages, voice messages,
pictures, and videos could also be deleted.) The manufacturer is not liable
for damage due to the loss of data.
When you use the phone in public places, set the ringtone to vibration so
you don’t disturb others.
Do not turn your phone on or off when putting it to your ear.
Use accessories, such as earphones and headsets, with caution. Ensure
that cables are tucked away safely.
FDA Consumer Update
The U.S. Food and Drug Administration’s Center for Devices
and Radiological Health Consumer Update on Mobile Phones:
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems
are associated with using wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones emit low levels of
Radio Frequency (RF) energy in the microwave range while being used.
They also emit very low levels of RF when in standby mode. Whereas high
levels of RF can produce health effects (by heating tissue), exposure to low
level RF that does not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures have not found any
biological effects. Some studies have suggested that some biological
effects may occur, but such findings have not been confirmed by additional
research. In some cases, other researchers have had difficulty in
reproducing those studies, or in determining the reasons for inconsistent
results.
2. What is the FDA's role concerning the safety of wireless phones?
Under the law, the FDA does not review the safety of radiation-emitting
consumer products such as wireless phones before they can be sold, as it
does with new drugs or medical devices. However, the agency has
218 Safety
authority to take action if wireless phones are shown to emit Radio
Frequency (RF) energy at a level that is hazardous to the user. In such a
case, the FDA could require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace, or recall the phones so
that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions,
the FDA has urged the wireless phone industry to take a number of steps,
including the following:
Support needed research into possible biological effects of RF of the type
emitted by wireless phones;
Design wireless phones in a way that minimizes any RF exposure to the
user that is not necessary for device function; and
Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
The FDA belongs to an interagency working group of the federal agencies
that have responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies belong to
this working group:
National Institute for Occupational Safety and Health
Environmental Protection Agency
Occupational Safety and Health Administration
National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency working
group activities, as well.
The FDA shares regulatory responsibilities for wireless phones with the
Federal Communications Commission (FCC). All phones that are sold in the
United States must comply with FCC safety guidelines that limit RF
exposure. The FCC relies on the FDA and other health agencies for safety
questions about wireless phones.
219
Safety
The FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the
wireless phones themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than those they can
get from wireless phones. Base stations are thus not the subject of the
safety questions discussed in this document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to handheld wireless phones with
built-in antennas, often called “cell”, “mobile”, or “PCS” phones. These
types of wireless phones can expose the user to measurable Radio
Frequency (RF) energy because of the short distance between the phone
and the user’s head.
These RF exposures are limited by FCC safety guidelines that were
developed with the advice of the FDA and other federal health and safety
agencies. When the phone is located at greater distances from the user,
the exposure to RF is drastically lower because a person’s RF exposure
decreases rapidly with increasing distance from the source. The so-called
“cordless phones,” which have a base unit connected to the telephone
wiring in a house, typically operate at far lower power levels, and thus
produce RF exposures far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many
studies have suffered from flaws in their research methods. Animal
experiments investigating the effects of Radio Frequency (RF) energy
exposures characteristic of wireless phones have yielded conflicting results
that often cannot be repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However, many of the studies
that showed increased tumor development used animals that had been
genetically engineered or treated with cancer-causing chemicals so as to be
pre-disposed to develop cancer in the absence of RF exposure. Other
studies exposed the animals to RF for up to 22 hours per day. These
conditions are not similar to the conditions under which people use
220 Safety
wireless phones, so we do not know with certainty what the results of
such studies mean for human health. Three large epidemiology studies
have been published since December 2000. Between them, the studies
investigated any possible association between the use of wireless phones
and primary brain cancer, glioma, meningioma, or acoustic neuroma,
tumors of the brain or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful health effects from
wireless phone RF exposures. However, none of the studies can answer
questions about long-term exposures, since the average period of phone
use in these studies was around three years.
5. What research is needed to decide whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people
actually using wireless phones would provide some of the data that are
needed. Lifetime animal exposure studies could be completed in a few
years. However, very large numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one exists. Epidemiological
studies can provide data that is directly applicable to human populations,
but ten or more years follow-up may be needed to provide answers about
some health effects, such as cancer. This is because the interval between
the time of exposure to a cancer-causing agent and the time tumors
develop — if they do — may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones. Many factors affect
this measurement, such as the angle at which the phone is held, or which
model of phone is used.
6. What is the FDA doing to find out more about the possible health
effects of wireless phone RF?
The FDA is working with the U.S. National Toxicology Program and with
groups of investigators around the world to ensure that high priority animal
studies are conducted to address important questions about the effects of
exposure to Radio Frequency (RF) energy.
221
Safety
The FDA has been a leading participant in the World Health Organization
International Electro Magnetic Fields (EMF) Project since its inception in
1996. An influential result of this work has been the development of a
detailed agenda of research needs that has driven the establishment of
new research programs around the world. The project has also helped
develop a series of public information documents on EMF issues.
The FDA and the Cellular Telecommunications & Internet Association (CTIA)
have a formal Cooperative Research And Development Agreement
(CRADA) to do research on wireless phone safety. The FDA provides the
scientific oversight, obtaining input from experts in government, industry,
and academic organizations. CTIA-funded research is conducted through
contracts with independent investigators. The initial research will include
both laboratory studies and studies of wireless phone users. The CRADA
will also include a broad assessment of additional research needs in the
context of the latest research developments around the world.
7. How can I find out how much Radio Frequency energy exposure I can
get by using my wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit Radio Frequency
(RF) energy exposures. The FCC established these guidelines in
consultation with the FDA and the other federal health and safety agencies.
The FCC limit for RF exposure from wireless phones is set at a Specific
Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit
is consistent with the safety standards developed by the Institute of
Electrical and Electronic Engineering (IEEE) and the National Council on
Radiation Protection and Measurement. The exposure limit takes into
consideration the body’s ability to remove heat from the tissues that absorb
energy from the wireless phone and is set well below levels known to have
effects. Manufacturers of wireless phones must report the RF exposure
level for each model of phone to the FCC. The FCC website (http://www.
fcc.gov/oet/rfsafety) gives directions for locating the FCC identification
number on your phone so you can find your phone’s RF exposure level in
the online listing.
222 Safety
8. What has the FDA done to measure the Radio Frequency energy
coming from wireless phones?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a
technical standard for measuring the Radio Frequency (RF) energy
exposure from wireless phones and other wireless handsets with the
participation and leadership of FDA scientists and engineers. The standard,
“Recommended Practice for Determining the Spatial-Peak Specific
Absorption Rate (SAR) in the Human Body Due to Wireless
Communications Devices: Experimental Techniques”, sets forth the first
consistent test methodology for measuring the rate at which RF is
deposited in the heads of wireless phone users. The test method uses a
tissue-simulating model of the human head. Standardized SAR test
methodology is expected to greatly improve the consistency of
measurements made at different laboratories on the same phone. SAR is
the measurement of the amount of energy absorbed in tissue, either by the
whole body or a small part of the body. It is measured in watts/kg (or
milliwatts/g) of matter. This measurement is used to determine whether a
wireless phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to Radio Frequency
energy from my wireless phone?
If there is a risk from these products — and at this point we do not know
that there is — it is probably very small. But if you are concerned about
avoiding even potential risks, you can take a few simple steps to minimize
your exposure to Radio Frequency (RF) energy. Since time is a key factor in
how much exposure a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure. If you must conduct
extended conversations by wireless phone every day, you could place more
distance between your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example, you could use a
headset and carry the wireless phone away from your body or use a
wireless phone connected to a remote antenna. Again, the scientific data
does not demonstrate that wireless phones are harmful. But if you are
concerned about the RF exposure from these products, you can use
223
Safety
measures like those described above to reduce your RF exposure from
wireless phone use.
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless
phones, including children and teenagers. If you want to take steps to
lower exposure to Radio Frequency (RF) energy, the measures described
above would apply to children and teenagers using wireless phones.
Reducing the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF exposure.
Some groups sponsored by other national governments have advised that
children be discouraged from using wireless phones at all. For example, the
government in the United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was strictly
precautionary; it was not based on scientific evidence that any health
hazard exists.
11. What about wireless phone interference with medical equipment?
Radio Frequency (RF) energy from wireless phones can interact with some
electronic devices. For this reason, the FDA helped develop a detailed test
method to measure Electro Magnetic Interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless telephones. This test
method is now part of a standard sponsored by the Association for the
Advancement of Medical Instrumentation (AAMI). The final draft, a joint
effort by the FDA, medical device manufacturers, and many other groups,
was completed in late 2000. This standard will allow manufacturers to
ensure that cardiac pacemakers and defibrillators are safe from wireless
phone EMI.
The FDA has tested hearing aids for interference from handheld wireless
phones and helped develop a voluntary standard sponsored by the Institute
of Electrical and Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids and wireless
phones so that no interference occurs when a person uses a “compatible”
224 Safety
phone and a “compatible” hearing aid at the same time. This standard was
approved by the IEEE in 2000.
The FDA continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful interference be
found to occur, the FDA will conduct testing to assess the interference and
work to resolve the problem.
12. Where can I find additional information?
For additional information, please refer to the following resources:
FDA web page on wireless phones
(http://www.fda.gov/cellphones/)
Federal Communications Commission (FCC) RF Safety Program
(http://www.fcc.gov/oet/rfsafety)
International Commission on Non-lonizing Radiation Protection
(http://www.icnirp.de)
World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
National Radiological Protection Board (UK)
(http://www.hpa.org.uk/radiation/)
Driving
Check the laws and regulations on the use of wireless phones in the areas
where you drive and always obey them. Also, if using your phone while
driving, please observe the following:
Give full attention to driving -- driving safely is your first responsibility;
Use hands-free operation, if available;
Pull off the road and park before making or answering a call if driving
conditions or the law require it.
225
Safety
10 Driver Safety Tips
Your wireless phone gives you the powerful ability to communicate by
voice almost anywhere, anytime. An important responsibility accompanies
the benefits of wireless phones, one that every user must uphold.
When operating a car, driving is your first responsibility. When using your
wireless phone behind the wheel of a car, practice good common sense
and remember the following tips:
1. Get to know your wireless phone and its features such as speed dial
and redial. Carefully read your instruction manual and learn to take
advantage of valuable features most phones offer, including automatic
redial and memory. Also, work to memorize the phone keypad so you
can use the speed dial function without taking your attention off the
road.
2. When available, use a hands-free device. A number of hands-free
wireless phone accessories are readily available today. Whether you
choose an installed mounted device for your wireless phone or a
speaker phone accessory, take advantage of these devices if available
to you.
3. Make sure you place your wireless phone within easy reach and where
you can reach it without removing your eyes from the road. If you get
an incoming call at an inconvenient time, if possible, let your voicemail
answer it for you.
4. Suspend conversations during hazardous driving conditions or
situations. Let the person you are speaking with know you are driving; if
necessary, suspend the call in heavy traffic or hazardous weather
conditions. Rain, sleet, snow, and ice can be hazardous, but so is heavy
traffic. As a driver, your first responsibility is to pay attention to the road.
5. Don’t take notes or look up phone numbers while driving. If you are
reading an address book or business card, or writing a “to-do” list while
driving a car, you are not watching where you are going. It is common
sense. Do not get caught in a dangerous situation because you are
reading or writing and not paying attention to the road or nearby
vehicles.
226 Safety
6. Dial sensibly and assess the traffic; if possible, place calls when you are
not moving or before pulling into traffic. Try to plan your calls before you
begin your trip or attempt to coincide your calls with times you may be
stopped at a stop sign, red light, or otherwise stationary. But if you need
to dial while driving, follow this simple tip -- dial only a few numbers,
check the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that may be
distracting. Stressful or emotional conversations and driving do not mix;
they are distracting and even dangerous when you are behind the
wheel of a car. Make people you are talking with aware you are driving
and if necessary, suspend conversations which have the potential to
divert your attention from the road.
8. Use your wireless phone to call for help. Your wireless phone is one of
the greatest tools you can own to protect yourself and your family in
dangerous situations -- with your phone at your side, help is only three
numbers away. Dial 911 or other local emergency number in the case of
fire, traffic accident, road hazard, or medical emergency. Remember, it’s
a free call on your wireless phone!
9. Use your wireless phone to help others in emergencies. Your wireless
phone provides you a perfect opportunity to be a “Good Samaritan” in
your community. If you see an auto accident, crime in progress or other
serious emergency where lives are in danger, call 911 or other local
emergency number, as you would want others to do for you.
10. Call roadside assistance or a special wireless non-emergency assistance
number when necessary. Certain situations you encounter while driving
may require attention, but are not urgent enough to merit a call for
emergency services. But you can still use your wireless phone to lend a
hand. If you see a broken-down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic accident where no one appears
injured or a vehicle you know to be stolen, call roadside assistance or
other special non-emergency wireless number
The above tips are meant as general guidelines. Before deciding to use
your mobile device while operating a vehicle, it is recommended that you
consult your applicable jurisdiction’s local laws or other regulations
regarding such use. Such laws or other regulations may prohibit or
227
Safety
otherwise restrict the manner in which a driver may use his or her phone
while operating a vehicle.
Cautions
The user interface of Google apps (Google Search, Google Maps,
Navigation, etc.) can vary depending on its software version.
Locations are inaccurate when GPS and Wi-Fi are not set.
With the Android operating system, some available Play Store apps only
operate correctly with phones that have a specific screen resolution.
Please be advised that some of the apps on Play Store may not be
available for your phone due to an LCD resolution requirement that
doesn't match your phone. In addition, please be aware that third party
apps with programming defects may cause issues with your phone,
including lock ups and resets.
All of the phone's contents, including content which you create or
download, will be deleted after a Factory Reset.
Use your phone in temperatures between 0ºC and 40ºC, if possible.
Exposing your phone to extremely low or high temperatures may result
in damage, malfunction, or even explosion.
There is risk of explosion if the battery is replaced with an incorrect type.
Dispose of used batteries according to the manufacturer’s instructions.
Please recycle when possible. Don't dispose as household waste.
Wi-Fi (WLAN)
This equipment may be operated in all European countries.
The 5150 - 5350 MHz band is restricted to indoor use only.
To prevent possible hearing damage, don’t listen at high
volume levels for long periods.
228 Safety
DECLARATION OF CONFORMITY
Hereby, LG Electronics declares that this LGVS986 product is in
compliance with the essential requirements and other relevant provisions
of Directive 1999/5/EC. A copy of the Declaration of Conformity can be
found at http://www.lg.com/global/declaration
Exposure to radio frequency energy
Radio wave exposure and Specific Absorption Rate (SAR) information.
This mobile phone model LGVS986 has been designed to comply with
applicable safety requirements for exposure to radio waves. These
requirements are based on scientific guidelines that include safety margins
designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines employ a unit of measurement
known as the Specific Absorption Rate (SAR). Tests for SAR are
conducted using standardised methods with the phone transmitting at
its highest certified power level in all used frequency bands.
While there may be differences between the SAR levels of various LG
phone models, they're all designed to meet the relevant guidelines for
exposure to radio waves.
The SAR limit recommended by the International Commission on
Non-Ionizing Radiation Protection (ICNIRP) is 2 W/kg averaged over 10g
of tissue.
This device meets RF exposure guidelines when used either in the
normal use position against the ear or when positioned at least 1.5 cm
away from the body. When a carry case, belt clip or holder is used for
bodyworn operation, it shouldn't contain metal and should position the
product at least 1.5 cm away from your body. In order to transmit data
files or messages, this device requires a quality connection to the
network. In some cases, transmission of data files or messages may be
delayed until such a connection is available. Ensure the above separation
distance instructions are followed until the transmission is completed.
229
Safety
Laser Safety Statement
CDRH Compliance
THIS PRODUCT COMPLIES WITH APPLICABLE REQUIREMENT OF
THE DHHS PERFORMANCE STANDARD FOR LASER PRODUCT, 21
CFR SUBCHAPTER J.
Caution!
This product employs a laser system. To ensure proper use of this
product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an
authorized service center.
Use of controls, adjustments, or the performance of procedures other
than those specified herein may result in hazardous radiation
exposure.
To prevent direct exposure to laser beam, do not try to open the
enclosure or make direct contact with the laser.
Instructions for Wireless Charger
Be sure to use a wireless charger that is genuine or compatibility-
certified (by WPC Qi standards).
(Wireless charger is sold separately.)
230 Specifications
DivX HD
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified® device that
has passed rigorous testing to verify that it plays DivX video. Visit divx.com
for more information and software tools to convert your files into DivX
videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to www.vod.divx.com for more information on how to
complete your registration.
DivX Certified® to play DivX® video up to HD 720p, including premium
content. DivX®, DivX Certified® and associated logos are trademarks of
Rovi Corporation or its subsidiaries and are used under license.
Dolby Digital Plus License notice
Manufactured under license from Dolby Laboratories. Dolby
and the double-D symbol are trademarks of Dolby Laboratories.
Reproduced with permission of Yahoo. © 2014 Yahoo. YAHOO! and the
YAHOO! logo are registered trademarks of Yahoo.
Notice: Open Source Software
To obtain the source code under GPL, LGPL, MPL, and other open
source licenses, that is contained in this product, please visit
http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty
disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for
a charge covering the cost of performing such distribution (such as the
cost of media, shipping, and handling) upon email request to
opensource@lge.com. This offer is valid for three (3) years from the date
on which you purchased the product.
231
FAQ
Please check to see if any issues you’ve encountered with your phone are
described in this section, before taking the phone in for service or calling a
service representative.
CATEGORY
SUB-CATEGORY QUESTION ANSWER
Bluetooth Bluetooth
Devices
What are the
functions available via
Bluetooth?
Stereo/Mono Headset, Car Kit, and FTP
connections are available. When your
phone is connected to another phone
via Bluetooth, you can receive Contacts
data.
Bluetooth Bluetooth
Headset
If my Bluetooth
headset is connected,
can I listen to my
music through my
3.5mm wired
headphones?
When a Bluetooth headset is
connected, all system sounds are
played over the headset. As a result,
you won't be able to listen to music
through your wired headphones.
Data Contacts Backup How can I back up
Contacts?
The Contacts data can be synchronized
between your phone and Gmail™.
Data Synchronization
Is it possible to set up
one-way-sync with
Gmail?
Only two-way synchronization is
available.
Data Synchronization
Is it possible to
synchronize all of the
Email folders?
All of your Email folders are
synchronized. From the Email app, tap
the Menu icon (at the the upper-right
corner of the screen), then tap Folders
to view them.
Data Synchronization
Is it possible to
transfer Contacts data
from a feature phone
to an Android™
phone?
Yes, if your contacts can be extracted
into a .CSV file.
How to transfer:
1. Create “.CSV” file with the contacts
on your current phone (you may be
able to use the PC suite software
provided by LGE).
2. Log into Gmail with your PC.
3. Click Contacts.
4. Click Import.
5. Attach the “.CSV” file.
6. Your contacts will then be
synchronized between your Android
phone and Gmail.
232 FAQ
CATEGORY
SUB-CATEGORY QUESTION ANSWER
Google™
Service Gmail Log-In
Should I have to log
into Gmail whenever I
want to access
Gmail?
Once you log into Gmail, you don’t
need to log into Gmail again.
Google
Service Google Account Is it possible to filter
emails?
No, email filtering is not supported via
the phone.
Phone
Function YouTube™ Is it possible to play
YouTube videos?
Yes, YouTube videos are supported but
may have to be viewed through the
YouTube app (instead of the Chrome
app).
Phone
Function Email
What happens when I
access another app
while writing an
email?
Your email is automatically saved as a
draft when you access another app. It's
still displayed when you return to Email,
until you close the Email app. When
you open the Email app again, from
your Inbox, tap the Menu icon (at
the the upper-right corner of the
screen) > Folders > Drafts to access it.
Phone
Function Ringtone
Is there a file size
limitation for when I
want to use an .MP3
file as a ringtone?
There's no file size limitation.
Phone
Function Navigation
Is it possible to install
another navigation
app on my phone?
Any app that's available on Play Store
and is compatible with the hardware
can be installed and used.
Phone
Function Synchronization
Is it possible to
synchronize my
contacts from all of
my email accounts?
Only Gmail and MS Exchange server
(Company Email Server) contacts can
be synchronized.
233
FAQ
CATEGORY
SUB-CATEGORY QUESTION ANSWER
Phone
Function Wait and Pause
Why don't my phone
numbers with Wait
and Pause work?
If you transferred a contact with the
Wait and Pause functions saved into
the number, you'll need to re-save each
number to use these features.
To re-save numbers with Wait and
Pause
1. From the Home screen, tap the
Phone icon (in the QuickTap bar).
2. Dial the number, then tap the Menu
icon (at the the upper-right corner
of the screen).
3. Tap Add 2-sec pause or Add wait,
enter the remaining numbers, then
tap Update contact to save the
number for the Contact.
Phone
Function Security
What are the phone’s
security functions?
You can set the phone to require the
entry of an unlock sequence (face
recognition, Knock Code, pattern, PIN,
or password) before the phone can be
accessed or used.
Phone
Function Unlock Pattern
What should I do if I
forget my Unlock
Pattern?
After attempting the Unlock Pattern 5
times, you can tap the Forgot button
(at the bottom of the screen) and use
your Google Account information or
Backup PIN to unlock your phone.
Phone
Function Unlock Pattern How do I create the
Unlock Pattern?
1. From the Home screen, touch and
hold the Recent Apps Key (in the
Touch Keys bar).
2. Tap Lock screen settings.
3. Tap Select screen lock.
4. Tap Pattern. The first time you do
this, a short tutorial about creating an
unlock pattern appears.
5. Set up by drawing your pattern once,
tap Continue, draw it again, then tap
Confirm.
234 FAQ
CATEGORY
SUB-CATEGORY QUESTION ANSWER
Phone
Function Speed Dial Is Speed Dialing
supported?
Yes. You can set Speed Dials as well as
save a contact directly on your Home
screen.
To set a Speed Dial:
1. Open the Contacts app.
2. Tap the Menu icon (at the
upper-right corner of the screen) >
Speed dial.
3. Tap the speed dial location and select
the desired contact.
NOTE You can also tap the Speed dial
icon next to the number when you
create or edit the contact entry.
To set a Direct Dial shortcut to your
Home screen:
1. Touch and hold an empty area on
your Home screen.
2. Tap the Widgets tab > Direct dial.
3. Tap the contact in your Contacts list.
Phone
Function Memory Will I know when my
memory is full? Yes, you'll receive a notification.
Phone
Function
Language
Support
Is it possible to
change the language?
The phone has multi-lingual capabilities.
To change the language:
1. From the Home screen, touch and
hold the Recent Apps Key (in the
Touch Keys bar) > Settings.
2. Tap Language & input > Language.
3. Tap the desired language.
NOTE To set multiple languages for
your on-screen keyboard, from the
Language & input screen, tap the
Settings icon (next to LG Keyboard),
tap Input language and keyboard
layout, then checkmark the languages
you want to be able to type.
Phone
Function
Language
Support
Which languages are
supported when
using Play Store?
The Play Store app supports English
and Spanish. Third party apps may not
support all languages.
235
FAQ
CATEGORY
SUB-CATEGORY QUESTION ANSWER
Phone
Function VPN How do I set up a
VPN?
VPN access configuration is different
according to each company. To
configure VPN access from your phone,
you must obtain the details from your
company’s network administrator.
Phone
Function Screen Time Out
My screen turns off
after only 30 seconds.
How can I change the
amount of time for
the backlight to turn
off?
1. From the Home screen, touch and
hold the Recent Apps Key (in the
Touch Keys bar).
2. Tap Settings > Display > Screen
timeout.
3. Tap the preferred screen backlight
timeout time.
NOTE You can also turn on the Smart
screen feature to keep the screen from
turning off when the phone detects
your eyes looking at the screen. From
the Settings menu, tap Display, then
checkmark Smart screen.
Phone
Function Wi-Fi and 4G
When Wi-Fi and 4G
are both available,
which service will my
phone use?
When using data, your phone may
default to the Wi-Fi connection (if Wi-Fi
connectivity on your phone is set to
On). However, there will be no
notification when your phone switches
from one to the other.
To know which data connection is
being used, check the 4G or Wi-Fi
icon in the Status Bar at the top of
your screen.
Phone
Function Home Screen
Is it possible to
remove an app from
the Home screen?
Yes. Just touch and hold the icon until
the Remove bar appears at the top of
the screen. Then, without lifting your
finger, drag the icon to the Remove bar,
then lift your finger.
236 FAQ
CATEGORY
SUB-CATEGORY QUESTION ANSWER
Phone
Function Application
I downloaded an app
and it causes a lot of
errors. How do I
remove it?
1. From the Home screen, touch and
hold the Recent Apps Key (in the
Touch Keys bar).
2. Tap Settings > Application manager.
3. Tap the app > Uninstall.
Phone
Function Ringtones Can I use music files
for my ringtones?
Yes. After saving a music file as a
ringtone, you can use it anywhere you
can set ringtones as an alert.
Touch and hold a song in a library list. In
the Context menu that opens, tap Set
as ringtone.
Phone
Function Alarm
Will my alarm be
audible or will it go off
if the phone is turned
off?
No, that functionality isn't supported.
Phone
Function Alarm
If my ringer volume is
set to Off or Vibrate,
will I hear my alarm?
Your alarm is programmed to be audible
even in these scenarios.
Phone
Spec
Battery Time
What is the maximum
amount of time my
phone’s battery will
last before I need to
recharge it?
Talk time: Approx. 1117 mins
Standby: Approx. 17.3 days
Band
Which wireless bands
are supported by the
phone?
Your phone is able to operate on the
800MHz and 1900MHz bands.
237
FAQ
CATEGORY
SUB-CATEGORY QUESTION ANSWER
Recovery
Solution
Factory Reset
How can I perform a
factory reset if I can’t
access the phone’s
Settings menu?
How to perform a factory reset:
1. Turn the phone off.
2. Press and hold the following keys (on
the back of the phone) at the same
time: Volume Down Key +
Power/Lock Key for
approximately 10 seconds.
3. Release both of the keys when the
System recovery screen is displayed.
4. The following options are displayed:
Continue Power up, Safe mode,
Factory data reset, Wipe cache, and
Power down. Press a Volume Key
to scroll to the desired option, then
press the Power/Lock Key to
confirm.
NOTE Highlight Continue Power
up to simply restart your phone
without performing a hard reset.
5. If you choose Factory data reset,
press either of the Volume Keys
(on the Factory data reset screen) to
highlight Yes , (or No to exit) then
press the Power/Lock Key (on
the back of the phone) to confirm.
6. Your phone will perform a hard reset
and erase all personal data from the
phone’s memory.
Attention:
If a factory reset is performed, all
installed apps and user data will be
erased. Please remember to back up
any important data before performing a
factory reset.
Power Reset
The phone is
locked-up and does
not function. How can
I reset it?
In the case of a malfunction or lock up
error, press and hold the Power/Lock
Key (on the back of the phone) for 8
seconds to reset the phone.
To power off, press and hold the
Power/Lock Key for 2 seconds
longer.
238 LIMITED WARRANTY STATEMENT
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed subscriber unit and its
enclosed accessories will be free from defects in material and
workmanship, according to the following terms and conditions:
(1) The limited warranty for the product extends for TWELVE (12) MONTHS
beginning on the date of purchase of the product with valid proof of
purchase, or absent valid proof of purchase, FIFTEEN (15) MONTHS
from date of manufacture as determined by the unit’s manufacture date
code.
(2) The limited warranty extends only to the original purchaser of the
product and is not assignable or transferable to any subsequent
purchaser/end user.
(3) This warranty is good only to the original purchaser of the product during
the warranty period as long as it is in the U.S., including Alaska, Hawaii,
U.S. Territories and Canada.
(4) The external housing and cosmetic parts shall be free of defects at the
time of shipment and, therefore, shall not be covered under these
limited warranty terms.
(5) Upon request from LG, the consumer must provide information to
reasonably prove the date of purchase.
(6) The customer shall bear the cost of shipping the product to the
Customer Service Department of LG. LG shall bear the cost of shipping
the product back to the consumer after the completion of service under
this limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVER:
(1) Defects or damages resulting from use of the product in other than its
normal and customary manner.
(2) Defects or damages from abnormal use, abnormal conditions, improper
storage, exposure to moisture or dampness, unauthorized modifications,
unauthorized connections, unauthorized repair, misuse, neglect, abuse,
accident, alteration, improper installation, or other acts which are not the
fault of LG, including damage caused by shipping, blown fuses, spills of
food or liquid.
(3) Breakage or damage to antennas unless caused directly by defects in
material or workmanship.
(4) That the Customer Service Department at LG was not notified by
consumer of the alleged defect or malfunction of the product during the
applicable limited warranty period.
239
LIMITED WARRANTY STATEMENT
(5) Products which have had the serial number removed or made illegible.
(6) This limited warranty is in lieu of all other warranties, express or implied
either in fact or by operations of law, statutory or otherwise, including,
but not limited to any implied warranty of marketability or fitness for a
particular use.
(7) Damage resulting from use of non LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are
scratched or damaged due to normal customer use.
(9) Products operated outside published maximum ratings.
(10) Products used or obtained in a rental program.
(11) Consumables (such as fuses).
3. WHAT LG WILL DO:
LG will, at its sole option, either repair, replace or refund the purchase price
of any unit that does not conform to this limited warranty. LG may choose
at its option to use functionally equivalent re-conditioned, refurbished or
new units or parts or any units. In addition, LG will not re-install or back-up
any data, applications or software that you have added to your phone. It is
therefore recommended that you back-up any such data or information
prior to sending the unit to LG to avoid the permanent loss of such
information.
4. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE DURATION OF
ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS
WARRANTY HEREIN. LG SHALL NOT BE LIABLE FOR THE LOSS OF THE
USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER
DAMAGES, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE
OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED
WARRANTY OF MARKETABILITY APPLICABLE TO THIS PRODUCT.
240 LIMITED WARRANTY STATEMENT
Some states do not allow the exclusive limitation of incidental or
consequential damages or limitations on how long an implied warranty
lasts; so these limitations or exclusions may not apply to you. This warranty
gives you specific legal rights and you may also have other rights which
vary from state to state.
5. HOW TO GET WARRANTY SERVICE:
If you experience any problems with either the Bluetooth headset or the
mobile handset, in each case as may be covered by this limited warranty,
you need only return the affected device. For example, if a problem exists
with the Bluetooth headset, please DO NOT return your mobile handset
with the headset. Likewise, if a problem exists with the mobile handset,
please DO NOT return the Bluetooth Headset with the handset.
To obtain warranty service, please call or fax to the following telephone
numbers from anywhere in the continental United States:
Tel. 1-800-793-8896 or Fax. 1-800-448-4026
Or visit http://us.lgservice.com. Correspondence may also be mailed to:
LG Electronics Service- Mobile Handsets, P.O. Box 240007, Huntsville, AL
35824
DO NOT RETURN YOUR PRODUCT TO THE ABOVE ADDRESS.
Please call or write for the location of the LG authorized service center
nearest you and for the procedures for obtaining warranty claims.
241
LIMITED WARRANTY STATEMENT
7.11 Warranty Laws
The following laws govern warranties that arise in retail sales of
consumer goods:
The California Song-Beverly Consumer Warranty Act [CC §§1790
et seq],
The California Uniform Commercial Code, Division Two [Com C
§§2101 et seq], and
The federal Magnuson-Moss Warranty Federal Trade Commission
Improvement Act [15 USC §§2301 et seq; 16 CFR Parts 701– 703].
A typical Magnuson-Moss Act warranty is a written promise that
the product is free of defects or a written promise to refund, repair,
or replace defective goods. [See 15 USC §2301(6).] Remedies
include damages for failing to honor a written warranty or service
contract or for violating disclosure provisions. [See 15 USC
§2310(d).] Except for some labeling and disclosure requirements,
the federal Act does not preempt state law. [See 15 USC §2311.]
The Consumer Warranty Act does not affect the rights and obligations
of parties under the state Uniform Commercial Code, except the
provisions of the Act prevail over provisions of the Commercial Code
when they conflict. [CC §1790.3.]
For purposes of small claims actions, this course will focus on rights
and duties under the state laws.
242 Index
Numbers
10 Driver Safety Tips 225
A
Adding an event to your
calendar 149
Adding Contacts 90
Answering or Rejecting Calls
66
Apps: How to View, Open,
and Switch 37
Avoid potential hearing loss.
208
B
Browse with tabs 76
C
Calculator 152
Calendar 147
Calling Your Contacts 70
Calls 63
Camera and Video 118
Changing Messaging
Settings 98
Charge the Phone 9
Charging the Phone 13
Chrome 75
Chrome Settings 80
Clock 153
Communicating With Your
Contacts 93
Communication 87
Composing and Sending a
Message 112
Connecting to Mobile
Networks 58
Connecting to Networks and
Devices 58
Connecting to Wi-Fi
Networks 59
Consumer Information
About Radio Frequency
Emissions 201
Consumer Information on
SAR 205
Contacts 87
Customizing the Home
Screen 56
D
Download files 78
Downloading and Installing
Apps 130
Driving 224
Dual Feature 124
Dual Play 127
Dual window 139
E
Email 101
Entertainment 118
F
FAQ 231
Favorites Contacts 91
FCC Hearing-Aid
Compatibility (HAC)
Regulations for Wireless
Devices 206
FDA Consumer Update 217
File Manager 164
G
Gallery 127
Gesture shot 121
Getting to Know the Home
Screen 23
Global access 28
Gmail 108
Guest Mode 55
H
Hangouts 115
Hardware key control mode
36
Help 8
Home screen version 27
I
Important Customer
Information 1
Inserting and Removing the
Memory Card 12
Insert the Battery 9
L
Languages 36
Laser Safety Statement 229
LIMITED WARRANTY
STATEMENT 238
Listening to Your Voicemail
73
243
Index
Live Zoom 126
Locking Your Phone 50
M
Managing Multiple Calls 72
Managing Notifications 44
Maps 158
Messaging 94
Mini panel view 26
Music 132
O
Opening Email and the
Accounts Screen 101
Opening YouTube and
Watching Videos 137
Optimizing Battery Life 14
Options During a Call 71
P
Phone Overview 5
Phone’s Status Icons 21
Placing and Ending Calls 63
Playing Music 133
Play Store 130
Q
QSlide 142
QSlide apps on the
Notifications panel 47
QSlide icons on the
Notifications panel 142
QuickMemo+ 140
QuickRemote 144
R
Reading Your Messages
102, 111
Record Videos 119
Remove the Back Cover 8
Removing the Battery and
SIM Card 10
Replace the Back Cover 9
Replying to or Forwarding a
Message 113
S
Safety 198
Safety Information 213
Searching Your Phone and
the Web 47
Setting and Activating
Alarms 154
Settings 167
Setting the Timer 156
Setting the World Clock 156
Setting up your Google
Account 19
Setting Up Your Phone 8
Setting your Lock screen 50
Specifications 230
Super Zooming 122
T
Table of Contents 2
Taking Pictures 119
Tasks 166
Text Input Methods 31
The Basics 5
TIA Safety Information 209
Tools 139
Touchscreen 29
Transferring Music Files to
Your Phone 132
Turning the Phone On and
Off 16
U
USB Connection 61
Using bookmarks 79
Using SmartShare 61
Using the Magic Remote
feature 147
Using the Stopwatch 157
V
Viewing Event Details 150
Viewing Your Calendar and
Events 147
Voice Command 162
Voice Mail 107
Voice Mate 161
Voice Recorder 162
Voice Search 162
W
Weather 159
Web 75
WIRELESS & NETWORKS
168
Working with Menus 43
Working with photos 128
Working with Playlists 136
244 Index
Working with tabs 77
Working With the Recent
Tab 68
Writing Your Messages 103
Y
YouTube™ 137

Navigation menu
