LG Innotek REBETZ27A2 Electronic Shelf Label User Manual Users manual

Users manual

2.7” Graphic type Integrated ESL

User Manual

Model

REBE-MZ27A

REBE-TZ27A

Remote controller device provides customer with several functions as below

Updating new purchase image on Tag.

Deleting purchase image on Tag

Loading saved image on Tag

Waking Tag up from sleep mode

Registration : Updating new purchase information on Tag

Release : Deleting purchase information on Tag and

turning Tag factory reset

Next Page : Loading saved image on Tag

Keep Alive : Waking Tag up from sleep mode

1. ESL Explanation

Display Area

2. Tag Status

Deep Sleep Mode

Connected with Gateway

Disconnected with Gateway

Image Download Failed

Battery discharge (The battery needs to be replaced)
