OWNER’S MANUAL
LED LCD TV / LCD TV
LED LCD TV MODELS LCD TV MODELS
32LS3400
32LS3410
42LS3400
22LS3500
26LS3500
32LS3500
32LS3450
42LS3450
22LS3510
26LS3510
32LS3510
32CS460
32CS461
42CS530
32CS560
37CS560
42CS560
ENGLISH
2IMPORTANT SAFETY INSTRUCTIONS
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
TO QUALIFIED SERVICE PERSONNEL.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
Do not use this apparatus near water.
Short-circuit
Breaker
Power Supply
Clean only with a dry cloth.
Short-circuit
Breaker
Power Supply
Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
Short-circuit
Breaker
Power Supply
Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Short-circuit
Breaker
Power Supply
Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet (Can differ by country).
Short-circuit
Breaker
Power Supply
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance
of your product.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Short-circuit
Breaker
Power Supply
WARNING: This product contains chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm.
Wash hands after handling.
ENGLISH
3
IMPORTANT SAFETY INSTRUCTIONS
Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
Short-circuit
Breaker
Power Supply
Only use attachments/accessories specified
by the manufacturer.
Short-circuit
Breaker
Power Supply
Use only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Short-circuit
Breaker
Power Supply
Unplug this apparatus during lightning
storms or when unused for long periods of
time.
Short-circuit
Breaker
Power Supply
Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Short-circuit
Breaker
Power Supply
Do not stick metal objects or any other
conductive material into the power cord. Do
not touch the end of the power cord while it
is plugged in.
Keep the packing anti-moisture material or
vinyl packing out of the reach of children.
Anti-moisture material is harmful if
swallowed. If swallowed by mistake, force
the patient to vomit and visit the nearest
hospital. Additionally, vinyl packing can
cause suffocation. Keep it out of the reach of
children.
CAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be
placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that
appliance and has no additional outlets or
branch circuits. Check the specification page
of this owner’s manual to be certain. Do not
connect too many appliances to the same
AC power outlet as this could result in fire or
electric shock. Do not overload wall outlets.
Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and
if its appearance indicates damage or
deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced
with an exact replacement part by an
authorized service. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where
the cord exits the appliance. Do not move
the TV with the power cord plugged in. Do
not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord
to unplug the TV.
Short-circuit
Breaker
Power Supply
ENGLISH
4IMPORTANT SAFETY INSTRUCTIONS
Warning - To reduce the risk of fire or
electrical shock, do not expose this product
to rain, moisture or other liquids. Do not
touch the TV with wet hands. Do not install
this product near flammable objects such
as gasoline or candles, or expose the TV to
direct air conditioning.
Short-circuit
Breaker
Power Supply
Do not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus
(e.g. on shelves above the unit).
Short-circuit
Breaker
Power Supply
Grounding
(Except for devices which are not grounded.)
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
Short-circuit
Breaker
Power Supply
DISCONNECTING DEVICE FROM THE MAIN
POWER
Mains plug is the disconnecting device. The
plug must remain readily operable.
As long as this unit is connected to the AC
wall outlet, it is not disconnected from the
AC power source even if the unit is turned
off.
Do not attempt to modify this product in any
way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this
product.
ANTENNAS Outdoor antenna grounding
(Can differ by country):
If an outdoor antenna is installed, follow
the precautions below. An outdoor antenna
system should not be located in the vicinity
of overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur. Be sure the
antenna system is grounded so as to provide
some protection against voltage surges
and built-up static charges. Section 810 of
the National Electrical Code (NEC) in the
U.S.A. provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
Short-circuit
Breaker
Power Supply
NEC: National Electrical Code
Ground Clamp
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Electric Service
Equipment
Ground Clamp
ENGLISH
5
IMPORTANT SAFETY INSTRUCTIONS
Cleaning
When cleaning, unplug the power cord and
wipe gently with a soft cloth to prevent
scratching. Do not spray water or other
liquids directly on the TV as electric shock
may occur. Do not clean with chemicals
such as alcohol, thinners or benzine.
Moving
Make sure the product is turned off,
unplugged and all cables have been
removed. It may take 2 or more people to
carry larger TVs. Do not press or put stress
on the front panel of the TV.
Ventilation
Install your TV where there is proper
ventilation. Do not install in a confined
space such as a bookcase. Do not cover the
product with cloth or other materials while
plugged. Do not install in excessively dusty
places.
If you smell smoke or other odors coming
from the TV, unplug the power cord and
contact an authorized service center.
Do not press strongly upon the panel with a
hand or a sharp object such as a nail, pencil
or pen, or make a scratch on it.
Keep the product away from direct sunlight.
Short-circuit
Breaker
Power Supply
Never touch this apparatus or antenna during
a thunder or lightning storm.
When mounting a TV on the wall, make sure
not to install the TV by hanging the power
and signal cables on the back of the TV.
Do not allow an impact shock or any objects
to fall into the product, and do not drop
anything onto the screen.
Dot Defect
The Plasma or LCD panel is a high
technology product with resolution of two
million to six million pixels. In a very few
cases, you could see fine dots on the screen
while you’re viewing the TV. Those dots
are deactivated pixels and do not affect the
performance and reliability of the TV.
Generated Sound
“Cracking” noise: A cracking noise that
occurs when watching or turning off the TV
is generated by plastic thermal contraction
due to temperature and humidity. This noise
is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-
speed switching circuit, which supplies a
large amount of current to operate a product.
It varies depending on the product.
This generated sound does not affect the
performance and reliability of the product.
Take care not to touch the ventilation
openings. When watching the TV for a long
period, the ventilation openings may become
hot. This does not affect the performance of
the product or cause defects in the product.
If the TV feels cold to the touch, there may
be a small “flicker” when it is turned on. This
is normal, there is nothing wrong with TV.
Some minute dot defects may be visible on
the screen, appearing as tiny red, green, or
blue spots. However, they have no adverse
effect on the TV’s performance. Avoid
touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary
distortion effects on the screen.
ENGLISH
6IMPORTANT SAFETY INSTRUCTIONS
DISPOSAL (Hg lamp only used in LCD TVs)
The fluorescent lamp used in this product contains
a small amount of mercury. Do not dispose of this
product with general household waste. Disposal of
this product must be carried out in accordance to
the regulations of your local authority.
Preventing “Image burn” or “Burn-in” on your TV screen
If a fixed image displays on the TV screen
for a long period of time, it will be imprinted
and become a permanent disfigurement on
the screen. This is “image burn” or “burn-in”
and not covered by the warranty.
If the aspect ratio of the TV is set to 4:3 for
a long period of time, image burn may occur
on the letterboxed area of the screen.
Avoid displaying a fixed image on the TV
screen for a long period of time (2 or more
hours for LCD, 1 or more hours for the
Plasma TV) to prevent image burn.
ENGLISH
7
IMPORTANT SAFETY INSTRUCTIONS
Additional information of the
manual
Viewing the owner's manual
The owner’s manual in PDF file format is supplied
on the enclosed CD. Install the Adobe Acrobat
Reader to view the owner’s manual on your PC.
1 Insert the supplied CD.
The web page appears automatically.
2 Click Owner’s Manual on the web page.
3 View the owner’s manual.
If the web page does not appear
automatically, access My computer and
then click LG and index.html to view the
owner’s manual.
NOTE
For USA and Canada
FCC NOTICE
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and the receiver.
- Connect the equipment to an outlet on
a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/
TV technician for help.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference and (2) this device must accept any
interference received, including interference that
may cause undesired operation of the device.
Any changes or modifications in construction of
this device which are not expressly approved by
the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV
system installer’s attention to Article 820-40 of
the National Electric Code (U.S.A.). The code
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall
be connected to the grounding system of the
building, as close to the point of the cable entry
as practical.
ENGLISH
8TABLE OF CONTENTS
TABLE OF CONTENTS
2 IMPORTANT SAFETY INSTRUCTIONS
7 Additional information of the manual
8 TABLE OF CONTENTS
9 INSTALLATION PROCEDURE
9 ASSEMBLING AND PREPARING
9 Unpacking
15 Parts and buttons
18 Lifting and moving the TV
19 Setting up the TV
19 - Attaching the stand
25 - Mounting on a table
27 - Mounting on a wall
28 - Tidying cables
29 MAKING CONNECTIONS
29 Connecting to an antenna or cable
30 Connecting to a HD receiver, DVD, or VCR
player
30 - HDMI Connection
31 - Component Connection
32 - Composite Connection
33 Connecting to a PC
33 - HDMI Connection
34 Connecting to a USB
35 REMOTE CONTROL
37 WATCHING TV
37 Connecting to the AC/DC adapter
37 Turning the TV on for the first time
38 TROUBLESHOOTING
39 OPEN SOURCE SOFTWARE NOTICE
40 SPECIFICATIONS
Image shown may differ from your TV.
Your TV’s OSD (On Screen Display) may
differ slightly from that shown in this
manual.
The available menus and options may differ
from the input source or product model that
you are using.
New features may be added to this TV in
the future.
NOTE
ENGLISH
9
ASSEMBLING AND PREPARING
INSTALLATION PROCEDURE
1 Open the package and make sure all the accessories are included.
2 Attach the stand to the TV set.
3 Connect an external device to the TV set.
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
The items supplied with your product may vary depending on the model.
Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39
inches) thick and 18 mm (0.7 inches) width.
Use an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit
into your TV's USB port.
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
NOTE
Do not use any unapproved items to ensure the safety and product life span.
Any damages or injuries by using unapproved items are not covered by the warranty.
In case of some model, the thin film on screen is a part of TV, So don’t take it off.
CAUTION
ENGLISH
10 ASSEMBLING AND PREPARING
For CS460, CS461, LS3400, LS3410 series
Remote control,
Batteries (AAA)
(See p.35)
Owner’s manual,
CD manual
Polishing cloth
(Depending on model)
Use this to remove dust
from the cabinet.
Stand Body
(See p.19)
Stand Base
(See p.19)
Stand Screws
8 EA, M4 x 20
(See p.19)
Protection cover Desk-mount Screw
(See p.25)
Power Cord
ENGLISH
11
ASSEMBLING AND PREPARING
For LS3450 series
Remote control,
Batteries (AAA)
(See p.35)
Owner’s manual,
CD manual
Polishing cloth
(Depending on model)
Use this to remove dust
from the cabinet.
(for 32LS3450) (for 42LS3450)
Stand Body / Stand Base
(See p.20)
Stand Body / Stand Base
(See p.21)
Desk-mount Screw
(See p.25)
(for 32LS3450) (for 42LS3450)
Stand Screws
2 EA, P4 x 16
4 EA, M4 x 20
(See p.20)
Stand Screws
4 EA, P4 x 16
4 EA, M4 x 14
(See p.21)
Power Cord
(for 32LS3450)
Protection cover Cable holder
(See p.28)
ENGLISH
12 ASSEMBLING AND PREPARING
For CS530, CS560 series
Remote control,
Batteries (AAA)
(See p.35)
Owner’s manual,
CD manual
Polishing cloth
(Depending on model)
Use this to remove dust
from the cabinet.
Stand Body
(See p.22)
Stand Base
(See p.22)
Stand Screws
8 EA, M4 x 20
(See p.22)
(For 42CS530, 32/42CS560)
Protection cover Desk-mount Screw
(See p.25)
Power Cord
(For 37CS560)
Power Cord
ENGLISH
13
ASSEMBLING AND PREPARING
For 22/26LS3500, 22/26LS3510
Remote control,
Batteries (AAA)
(See p.35)
Owner’s manual,
CD manual
Polishing cloth
(Depending on model)
Use this to remove dust
from the cabinet.
(For 22LS3500, 22LS3510)
Stand Body
(See p.23)
Stand Base
(See p.23)
Stand Screws
2 EA, P4 x 16
(See p.23)
(For 26LS3500, 26LS3510)
Stand Screws
2 EA, M4 x 14
(See p.23)
Cable holder
(See p.28)
Power Cord
AC/DC Adapter
ENGLISH
14 ASSEMBLING AND PREPARING
For 32LS3500, 32LS3510
Remote control,
Batteries (AAA)
(See p.35)
Owner’s manual,
CD manual
Polishing cloth
(Depending on model)
Use this to remove dust
from the cabinet.
Stand Body
(See p.24)
Stand Base
(See p.24)
Stand Screws
4 EA, P4 x 16
4 EA, M4 x 14
(See p.24)
Desk-mount Screw
(See p.25)
Cable holder
(See p.28)
Power Cord
ENGLISH
15
ASSEMBLING AND PREPARING
Parts and buttons
For CS460, CS461, CS530, CS560, LS3400, LS3410 series
Touch button2Description
ꔰ / ITurns the power on or off.
INPUT Changes the input source.
SETTINGS Accesses the main menus, or saves your input and exits the menus.
OK ⊙Selects the highlighted menu option or confirms an input.
- + Adjusts the volume level.
v ^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
OK
SETTINGS
INPUT
OK
SETTINGS
INPUT
Screen
Speakers
Touch buttons2
Power indicator
Remote control and
Intelligent sensors1
For CS460, CS461,
LS3400, LS3410 series
For CS530,
CS560 series
ENGLISH
16 ASSEMBLING AND PREPARING
OK
INPUT
SETTINGS
SETTINGS
INPUT
OK
Screen
For LS3450 series
Touch button2Description
ꔰ Turns the power on or off.
INPUT
H
Changes the input source.
SETTINGS SAccesses the main menus, or saves your input and exits the menus.
OK
H
Selects the highlighted menu option or confirms an input.
- + Adjusts the volume level.
v ^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
buttons
Power indicator
Remote control and
intelligent sensors1
Speakers
ENGLISH
17
ASSEMBLING AND PREPARING
For LS3500, LS3510 series
Touch button2Description
ꔰ / ITurns the power on or off.
INPUT Changes the input source.
SETTINGS Accesses the main menus, or saves your input and exits the menus.
OK ⊙Selects the highlighted menu option or confirms an input.
- + Adjusts the volume level.
v ^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
OK
SETTINGS
INPUT
Screen
Speakers
Touch buttons2
Power indicator
Remote control and
Intelligent sensors1
ENGLISH
18 ASSEMBLING AND PREPARING
Lifting and moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for safe transportation regardless of
its type and size.
Avoid touching the screen at all times, as
this may result in damage to the screen.
CAUTION
It is recommended to move the TV in the
box or packing material that the TV originally
came in.
Before moving or lifting the TV, disconnect
the power cord and all cables.
When holding the TV, the screen should face
away from you to avoid damage.
Hold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
When transporting a large TV, there should
be at least 2 people.
When transporting the TV by hand, hold the
TV as shown in the following illustration.
When transporting the TV, do not expose the
TV to jolts or excessive vibration.
When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
ENGLISH
19
ASSEMBLING AND PREPARING
Setting up the TV
Put your TV on a pedestal stand and mount the TV on a table or wall.
Attaching the stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
For CS460, CS461, LS3400, LS3410 series
1
4 EA
M4 x 20
Stand Body
Stand Base
Front
3
M4 x 20
4 EA
2
When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
CAUTION
Make sure that the screws are fastened
completely. (If they are not fastened
securely enough, the TV may tilt forward
after being installed.)
Do not fasten the screws with too much
force; otherwise they may be worn out and
get loosened.
CAUTION
Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
NOTE
ENGLISH
20 ASSEMBLING AND PREPARING
For 32LS3450
1
P4 x 16
2EA
Stand Body
Stand Base
3
M4 x 20
4 EA
2
When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
CAUTION
Make sure that the screws are fastened
completely. (If they are not fastened
securely enough, the TV may tilt forward
after being installed.)
Do not fasten the screws with too much
force; otherwise they may be worn out and
get loosened.
CAUTION
ENGLISH
21
ASSEMBLING AND PREPARING
For 42LS3450
1
3
2
When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
CAUTION
Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
NOTE
Make sure that the screws are fastened
completely. (If they are not fastened
securely enough, the TV may tilt forward
after being installed.)
Do not fasten the screws with too much
force; otherwise they may be worn out and
get loosened.
CAUTION
Stand Base
Stand Body
P4 x 16
4EA
M4 x 14
4EA
ENGLISH
22 ASSEMBLING AND PREPARING
For CS530, CS560 series
1
Stand Body
Stand Base
Front
4 EA
M4 x 20
3
M4 x 20
4 EA
2
When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
CAUTION
Make sure that the screws are fastened
completely. (If they are not fastened
securely enough, the TV may tilt forward
after being installed.)
Do not fasten the screws with too much
force; otherwise they may be worn out and
get loosened.
CAUTION
Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
NOTE
ENGLISH
23
ASSEMBLING AND PREPARING
For 22/26LS3500, 22/26LS3510
1
Stand Body
Stand Base
3
(For 22LS3500,
22LS3510)
P4 x 16
2 EA
(For 26LS3500,
26LS3510)
M4 x 14
2 EA
Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
NOTE
Make sure that the screws are fastened
completely. (If they are not fastened
securely enough, the TV may tilt forward
after being installed.)
Do not fasten the screws with too much
force; otherwise they may be worn out and
get loosened.
CAUTION
2
When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
CAUTION
ENGLISH
24 ASSEMBLING AND PREPARING
For 32LS3500, 32LS3510
1
Stand Base
Front
4 EA
P4 x 16
Stand Body
3
M4 x 14
4 EA
2
When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
CAUTION
Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
NOTE
Make sure that the screws are fastened
completely. (If they are not fastened
securely enough, the TV may tilt forward
after being installed.)
Do not fasten the screws with too much
force; otherwise they may be worn out and
get loosened.
CAUTION
ENGLISH
25
ASSEMBLING AND PREPARING
Mounting on a table
1 Lift and tilt the TV into its upright position on a
table.
- Leave a 10 cm (4 inch) (minimum) space from
the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
(4 inches)
2 Connect the power cord to a wall outlet.
Do not place the TV near or on sources
of heat, as this may result in fire or other
damage.
CAUTION
Adjusting the angle of the TV to suit view
(Depending on model)
Swivel 20 degrees to the left or right and adjust
the angle of the TV to suit your view.
2020
When adjusting the angle of the TV,
watch out for your fingers.
- Personal injury may occur if hands or
fingers are pinched. If the product is
tilted too much, it may fall, causing
damage or injury.
CAUTION
Securing the TV to a table
(For 32CS460, 32CS461, 42CS530,
32/37/42CS560, 32/42LS3400, 32LS3410,
32/42LS3450, 32LS3500, 32LS3510)
Fix the TV to a table to prevent from tilting
forward, damage, and potential injury.
Mount the TV on a table, and then insert and
tighten the supplied screw on the rear of the
stand.
To prevent TV from falling over, the TV
should be securely attached to the floor/
wall per installation instructions. Tipping,
shaking, or rocking the TV may cause injury.
WARNING
ENGLISH
26 ASSEMBLING AND PREPARING
Using the Kensington security system (optional)
(For 32CS460, 32CS461, 42CS530,
32/37/42CS560, 22/26LS3500, 22/26LS3510)
The Kensington security system connector is
located at the rear of the TV. For more information
of installation and using, refer to the manual
provided with the Kensington security system or
visit http://www.kensington.com.
Connect the Kensington security system cable
between the TV and a table.
The Kensington security system is optional.
You can obtain additional accessories from
your local dealer.
NOTE
Securing the TV to a wall (optional)
(Depending on model)
1 Insert and tighten the eye-bolts, or TV brackets
and bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2 Mount the wall brackets with the bolts to the
wall.
Match the location of the wall bracket and the
eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly
with a sturdy rope.
Make sure to keep the rope horizontal with the
flat surface.
Make sure that children do not climb on or
hang on the TV.
CAUTION
Use a platform or cabinet that is strong and
large enough to support the TV securely.
Brackets, bolts and ropes are optional. You
can obtain additional accessories from your
local dealer.
NOTE
ENGLISH
27
ASSEMBLING AND PREPARING
Mounting on a wall
Attach an optional wall mount bracket at the rear
of the TV carefully and install the wall mount
bracket on a solid wall perpendicular to the
floor. When you attach the TV to other building
materials, please contact qualified personnel.
We recommend that you use an LG brand wall
mount when mounting the TV to a wall.
10 cm
10 cm
10 cm
10 cm
(4 inches)
Make sure to use screws and wall mounts that
meet the VESA standard. Standard dimensions for
the wall mount kits are described in the following
table.
Model 22/26LS3500
22/26LS3510
32CS460
32CS461
32CS560
32LS3400
32LS3410
32LS3450
32LS3500
32LS3510
VESA 100 x 100 200 x 100
Standard screw M4 M4
Number of screws 4 4
Wall mount bracket
(optional)
LSW100B LSW100B
Model 42CS530
37/42CS560
42LS3400
42LS3450
VESA 200 x 200
Standard screw M6
Number of screws 4
Wall mount bracket
(optional)
LSW200BX LSW220BX
Disconnect the power first, and then move
or install the TV. Otherwise electric shock
may occur.
If you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and
contact the local dealer or qualified
personnel.
Do not over tighten the screws as this may
cause damage to the TV and void your
warranty.
Use the screws and wall mounts that meet
the VESA standard. Any damages or injuries
by misuse or using an improper accessory
are not covered by the warranty.
CAUTION
Use the screws that are listed on the VESA
standard screw specifications.
The wall mount kit includes an installation
manual and necessary parts.
The wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
The length of screws may differ depending
on the wall mount. Make sure to use the
proper length.
For more information, refer to the manual
supplied with the wall mount.
NOTE
ENGLISH
28 ASSEMBLING AND PREPARING
Tidying cables
For CS460, CS461, CS530, CS560, LS3400, LS3410
1 Gather and bind the cables with the cable
management clip.
2 Fix the cable management clip firmly to the TV.
Cable management clip
1 Gather and bind the cables with the cable
holder.
For 22/26LS3500, 22/26LS3510
Cable holder
For 32LS3500, 32LS3510, 32/42LS3450
Cable holder
Do not move the TV by holding the cable
holder and power cord holder, as the cable
holders may break, and injuries and damage
to the TV may occur.
CAUTION
ENGLISH
29
MAKING CONNECTIONS
MAKING CONNECTIONS
Connect various external devices to the TV and switch input modes to select an external device.
For more information of external device’s connection, refer to the manual provided with each device.
Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC,
gaming devices, and other external devices.
If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input
cable to the TV through a DVD recorder or VCR. For more information of recording, refer to the
manual provided with the connected device.
The external device connection may differ from the model.
Connect external devices to the TV regardless of the order of the TV port.
NOTE
Connecting to an antenna or cable
ANTENNA/
CABLE IN
VHF Antenna
UHF Antenna
Antenna
Terminal
Coaxial (75Ω)
Make sure not to bend the copper wire of
the RF cable.
Copper wire
Complete all connections between devices,
and then connect the power cord to the
power outlet to prevent damage to your TV.
CAUTION
Use a signal splitter to use more than 2 TVs.
Visit http://lgknowledgebase.com for more
information about the antenna and cable
connection. Search for antenna.
NOTE
ENGLISH
30 MAKING CONNECTIONS
Connecting to a HD receiver, DVD, or VCR player
Connect a HD receiver, DVD, or VCR player to the TV and select an appropriate input mode.
HDMI Connection
HDMI is the best way to connect a device.
Transmits the digital video and audio signals from an external device to the TV. Connect the external device
and the TV with the HDMI cable as shown in the following illustration.
Use the latest High Speed HDMI™ Cable with CEC (Customer Electronics Control) function.
High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
NOTE
DVD / Blu-Ray / HD Cable Box / HD STB
2
1
IN
Choose any HDMI input port to connect.
It does not matter which port you use.
HDMI
(*Not Provided)
ENGLISH
31
MAKING CONNECTIONS
VIDEO
Y
PBPR
RL
VIDEO AUDIO
L/MONO AUDIO
COMPONENT IN
AV IN
R
AUDIO
VIDEO
L R
DVD / Blu-Ray / HD Cable Box
GREEN
GREEN
BLUE
BLUE
RED
RED
WHITE
WHITE
RED
RED
(*Not Provided)
(*Not Provided)
Component Connection
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the component cable as shown in the following illustration.
If cables are installed incorrectly, it could case the image to display in black and white or with
distorted color.
Check to ensure the cable are matched with the corresponding color connection.
NOTE
ENGLISH
32 MAKING CONNECTIONS
Composite Connection
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the composite cable as shown in the following illustration.
If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the
TV.
NOTE
VIDEO
MONO
( )
AUDIOL R
VIDEO
Y
P
B
P
R
RL
V
IDE
O
AU
DI
O
L/MONO AUDIO
COMPONENT IN
AV IN
R
YELLOW
BLUE
BLUE
YELLOW
RED
RED
(*Not Provided)
VCR / DVD / Blu-Ray / HD Cable Box
ENGLISH
33
MAKING CONNECTIONS
Connecting to a PC
It is recommended to use the TV with the HDMI connection for the best image quality.
Depending on the graphics card, DOS mode may not work if a HDMI to DVI Cable is in use.
In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or
brightness. If noise is present, change the PC output to another resolution, change the refresh rate
to another rate or adjust the brightness and contrast on the PICTURE menu until the picture is clear.
The synchronization input form for Horizontal and Vertical frequencies is separate.
Depending on the graphics card, some resolution settings may not allow the image to be positioned
on the screen properly.
NOTE
HDMI Connection
PC
2
1
IN
Choose any HDMI input port to connect.
It does not matter which port you use.
HDMI
(*Not Provided)
ENGLISH
34 MAKING CONNECTIONS
Connecting to a USB
Connect a USB storage device such as a USB flash memory, external hard drive, or a USB memory card
reader to the TV.
USB IN
ENGLISH
35
REMOTE CONTROL
REMOTE CONTROL
The descriptions in this manual are based on the buttons on the remote control.
Please read this manual carefully and use the TV correctly.
To replace batteries, open the battery cover, replace batteries (1.5 V AAA)
matching the and ends to the label inside the compartment, and close the
battery cover. To remove the batteries, perform the installation actions in reverse.
Do not mix old and new batteries, as this may damage the remote control.
CAUTION
Make sure to point the remote control toward at the remote control sensor on the TV.
POWER
TV
ENERGY
SAVING
AV MODE INFO
LIST
SETTINGS
OK
Q.MENU
EXIT
P
A
G
E
MUTE
FAV
CHVOL
FLASHBK
RATIO INPUT
ꕯ
POWER
Turns the TV on or off.
ꕊ ENERGY SAVING
Adjusts the brightness of the screen to reduce energy
consumption.
TV
Returns to the last TV channel.
AV MODE
Selects an AV mode.
INFO
Views the information of the current program and screen.
RATIO
Resizes an image.
INPUT
Rotates through inputs.
Also switches the TV on from standby.
Number button
Enters numbers.
LIST
Accesses the saved channel list.
- (Dash)
Inserts a dash between numbers such as 2-1 and 2-2.
FLASHBK
Alternates between the two last channels selected (pressing
repeatedly).
ENGLISH
36 REMOTE CONTROL
POWER
TV
ENERGY
SAVING
AV MODE INFO
LIST
SETTINGS
OK
Q.MENU
EXIT
P
A
G
E
MUTE
FAV
CHVOL
FLASHBK
RATIO INPUT
ꕯ
SETTINGS
Accesses the main menu.
Q.MENU
Accesses the quick menu.
Navigation buttons (up/down/left/right)
Scrolls through menus or options.
OK ꔉ
Selects menus or options and confirms your input.
ꕣ (BACK)
Returns to the previous level.
EXIT ꕯ
Clears all on-screen displays and returns to TV viewing.
VOL
Adjusts the volume level.
FAV
Accesses your favorite channel list.
Accesses the AV devices connected to the TV;
Opens the SIMPLINK menu.
MUTE
Mutes all sounds.
CH
Scrolls through the saved channels.
PAGE
Moves to the previous or next screen.
Color buttons
These access special functions in some menus.
Control buttons
Controls the SIMPLINK compatible devices (USB,SIMPLINK).
Not functional.
ENGLISH
37
WATCHING TV
WATCHING TV
Connecting to the AC/DC
adapter
(For 22/26LS3500, 22/26LS3510)
1 Connect the AC/DC adapter plug to the power
input jack on the TV.
2 Connect the power cord to the AC/DC adapter
first, then plug the power cord into the wall
power outlet.
Please be sure to connect the TV to the AC/
DC power adapter before connecting the
TV’s power plug to a wall power outlet.
CAUTION
Turning the TV on for the first
time
When you turn the TV on for the first time, the
Initial setting screen appears. Select a language
and customize the basic settings.
1 Connect the power cord to a power outlet.
The Power indicator turns red and the TV
switches to Standby mode.
2 In Standby mode, press the power button on
the remote control to turn the TV on.
The Initial setting screen appears if you turn
the TV on for the first time.
You can also access Initial Setting by
accessing OPTION in the main menu.
NOTE
3 Follow the on-screen instructions to customize
your TV settings according to your preferences.
Language Selects a language to
display.
Mode Setting Selects Home Use for
the home environment.
Time Setting Selects the time zone
and daylight saving.
Auto Tuning Scans and saves available
channels automatically.
To display images in the best quality for
your home environment, select Home
Use.
Store Demo is suitable for the retail
environment.
If you select Store Demo, any customized
settings will switch back to the default
settings of Store Demo in 5 minutes.
NOTE
4 When the basic settings are complete,
press OK.
If you do not complete the Initial setting,
it will appear whenever the TV turns on.
Disconnect the power cord from the
power outlet when you do not use the TV
for a long period of time.
NOTE
5 To turn the TV off, press the power button on
the remote control.
ENGLISH
38 TROUBLESHOOTING
TROUBLESHOOTING
General
Problem Solution
Cannot control the TV with the
remote control.
Check the remote control sensor on the product and try again.
Check if there is any obstacle between the product and the remote control.
Check if the batteries are still working and properly installed ( to , to ).
No image display and no sound is
produced.
Check if the product is turned on.
Check if the power cord is connected to a wall outlet.
Check if there is a problem in the wall outlet by connecting other products.
Image appears slowly when the TV
turns on.
The image is muted during the product startup process. This is normal. If the
image does not appear in a few minutes, unplug the TV for 30 seconds and try
again. If the image still does not appear, contact the authorized service center
in your local area.
Cannot connect external devices. Refer to the "Connection Overview" and connect an external device.
The TV turns off suddenly. Check the power control settings. The power supply may be interrupted.
Check if the Auto sleep feature is activated in the Time settings.
Refer to the "Sleep Timer".
If there is no signal while the TV is on, the TV will turn off automatically after
15 minutes of inactivity. (Depending on model)
Audio
Problem Solution
No sound is produced while images
are displaying.
Press VOL + or - button.
Check if the sound is muted by pressing MUTE.
Scroll to other channels. There may a problem with the broadcast.
Check if the TV Speaker feature is activated in the menu option.
No output from one of the speakers Adjust Balance in the menu option.
Unusual sound from inside the TV is
produced.
A change in ambient humidity or temperature may result in an unusual noise
when the product turns on or off. There is no problem with your product.
ENGLISH
39
TROUBLESHOOTING
Video
Problem Solution
An image displays in black and
white or the color quality is poor.
Adjust the color setting in the menu option.
Keep a sufficient distance between this product and other electronic products.
Scroll to other channels. There may a problem with the broadcast.
Horizontal or vertical bars appears
or images blur
Check if there are local interferences such as an electrical appliance or power
tool.
Lines or streaks appear on images Check the antenna or aim the antenna to the proper direction.
Afterimages (ghosts) appear when
the product turns off
Pixels may have been damaged from a fixed image displayed for a long time
(image burn). Use a screen saver to prevent the pixel damage on the screen.
The power is on but the screen
appears extremely dark.
Adjust the brightness and contrast in the menu option.
“No Signal” appears on the screen. Check if the signal cable is connected between the TV and products properly.
Check the selected input source by pressing INPUT.
Black spots appear on the screen. Several pixels in red, green, white, or black may appear on the screen that can
attribute to the characteristics of the panel.
This is normal.
The display offset is wrong. Adjust the position setting in the Picture menu.
Check if the video card resolution and frequency are supported by the product.
If the frequency is out of range, set to the recommended resolution using the
display settings on the external device.
Thin lines appear in the background
of the screen.
Check the video cable connections.
The reception on some channels is
poor
Scroll to other channels. There may a problem with the broadcast.
The station signal may be weak. Aim the antenna to the proper direction.
Check if there is local interferences such as an electrical appliance or power
tool.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of media, shipping and handling) upon email request to
opensource@lge.com. This offer is valid for three (3) years from the date on which you purchased the
product.
ENGLISH
40 SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
External Antenna Impedance 75 Ω
Environment
condition
Operating Temperature 0 - 40 °C
Operating Humidity Less than 80 %
Storage Temperature -20 - 60 °C
Storage Humidity Less than 85 %
MODELS
32CS460
(32CS460-UC)
32CS461
(32CS461-UA)
Dimensions
(W x H x D)
With stand 794.0 x 565.0 x 207.0 mm
(31.2 x 22.2 x 8.1 inch)
Without stand 794.0 x 504.0 x 73.5 mm
(31.2 x 19.8 x 2.8 inch)
Weight With stand 9.0 kg (19.8 lbs)
Without stand 8.0 kg (17.6 lbs)
Current Value / Power consumption 1.1 A / 110 W
Power requirement AC100 - 240 V ~ 50/60 Hz
MODELS 42CS530
(42CS530-UB)
32CS560
(32CS560-UE)
Dimensions
(W x H x D)
With stand 1019.0 x 698.0 x 265.0 mm
(40.1 x 27.4 x 10.4 inch)
795.0 x 568.0 x 207.0 mm
(31.2 x 22.3 x 8.1 inch)
Without stand 1019.0 x 631.0 x 76.5 mm
(40.1 x 24.8 x 3.0 inch)
795.0 x 504.0 x 73.5 mm
(31.2 x 19.8 x 2.8 inch)
Weight With stand 15.1 kg (33.2 lbs) 9.2 kg (20.2 lbs)
Without stand 13.4 kg (29.5 lbs) 8.1 kg (17.8 lbs)
Current Value / Power consumption 1.7 A / 170 W 1.2 A / 120 W
Power requirement AC100 - 240 V ~ 50/60 Hz AC100 - 240 V ~ 50/60 Hz
MODELS 37CS560
(37CS560-UE)
42CS560
(42CS560-UE)
Dimensions
(W x H x D)
With stand 913.0 x 639.0 x 265.0 mm
(35.9 x 25.1 x 10.4 inch)
1019.0 x 698.0 x 265.0 mm
(40.1 x 27.4 x 10.4 inch)
Without stand 913.0 x 571.0 x 77.4 mm
(35.9 x 22.4 x 3.0 inch)
1019.0 x 631.0 x 76.5 mm
(40.1 x 24.8 x 3.0 inch)
Weight With stand 12.8 kg (28.2 lbs) 15.1 kg (33.2 lbs)
Without stand 11.1 kg (24.4 lbs) 13.4 kg (29.5 lbs)
Current Value / Power consumption 1.6 A / 160 W 1.7 A / 170 W
Power requirement AC100 - 240 V ~ 50/60 Hz AC100 - 240 V ~ 50/60 Hz
ENGLISH
41
SPECIFICATIONS
MODELS
32LS3400
(32LS3400-UA) 42LS3400
(42LS3400-UA)
32LS3410
(32LS3410-UB)
Dimensions
(W x H x D)
With stand 795.0 x 566.0 x 207.0 mm
(31.2 x 22.2 x 8.1 inch)
1018.0 x 696.0 x 261.0 mm
(40.0 x 27.4 x 10.2 inch)
Without stand 795.0 x 504.0 x 73.5 mm
(31.2 x 19.8 x 2.8 inch)
1018.0 x 629.0 x 76.5 mm
(40.0 x 24.7 x 3.0 inch)
Weight With stand 9.1 kg (20.0 lbs) 14.7 kg (32.4 lbs)
Without stand 8.1 kg (17.8 lbs) 13.1 kg (28.8 lbs)
Current Value / Power consumption 1.0 A / 70 W 1.2 A / 120 W
Power requirement AC100 - 240 V ~ 50/60 Hz AC100 - 240 V ~ 50/60 Hz
MODELS 32LS3450
(32LS3450-UA)
42LS3450
(42LS3450-UA)
Dimensions
(W x H x D)
With stand 738.0 x 501.0 x 185.0 mm
(29.0 x 19.7 x 7.3 inch)
972.0 x 635.0 x 212.0 mm
(38.2 x 25.0 x 8.3 inch)
Without stand 738.0 x 438.0 x 86.0 mm
(29.0 x 17.2 x 3.4 inch)
972.0 x 571.0 x 86.0mm
(38.2 x 22.4 x 3.4 inch)
Weight With stand 7.5 kg (16.5 lbs) 11.8 kg (26.0 lbs)
Without stand 6.9 kg (15.2 lbs) 10.7 kg (23.5 lbs)
Current Value / Power consumption 0.9 A / 60 W 1.2 A / 120 W
Power requirement AC100 - 240 V ~ 50/60 Hz AC100 - 240 V ~ 50/60 Hz
MODELS
22LS3500
(22LS3500-UD)
26LS3500
(26LS3500-UD)
22LS3510
(22LS3510-UA)
26LS3510
(26LS3510-UA)
Dimensions
(W x H x D)
With stand 523.0 x 376.0 x 140.0 mm
(20.5 x 14.8 x 5.4 inch)
627.0 x 442.0 x 162.0 mm
(24.6 x 17.4 x 6.3 inch)
Without stand 523.0 x 339.0 x 31.6 mm
(20.5 x 13.3 x 1.2 inch)
627.0 x 402.0 x 30.1 mm
(24.6 x 15.8 x 1.1 inch)
Weight With stand 3.5 kg (7.7 lbs) 4.5 kg (9.9 lbs)
Without stand 3.2 kg (7.0 lbs) 4.2 kg (9.2 lbs)
Power requirement 24 V , 1.4 A 24 V , 1.8 A
Adapter (DC Power) In: AC 100 - 240 V ~ 50/60 Hz
Out: DC 24 V, 2.7 A or 2.71 A
MODELS
32LS3500
(32LS3500-UD)
32LS3510
(32LS3510-UA)
Dimensions
(W x H x D)
With stand 755.0 x 530.0 x 239.0 mm
(29.7 x 20.8 x 9.4 inch)
Without stand 755.0 x 479.0 x 45.8 mm
(29.7 x 18.8 x 1.8 inch)
Weight With stand 9.1 kg (20.0 lbs)
Without stand 8.3 kg (18.2 lbs)
Current Value / Power consumption 0.6 A / 60 W
Power requirement AC100 - 240 V ~ 50/60 Hz
ENGLISH
42 SPECIFICATIONS
HDMI (PC) supported mode
Resolution Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
640 x 350 31.468 70.09
720 x 400 31.469 70.08
640 x 480 31.469 59.94
800 x 600 37.879 60.31
1024 x 768 48.363 60.00
1360 x 768 47.712 60.015
1152 x 864 54.348 60.053
1280 x 1024 63.981 60.02
1920 x 1080 67.50 60.00
For 42CS460, 32/42CS560, 42LS3400, 42LS3450
HDMI (DTV) supported mode
Resolution Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
720 x 480p 31.47
31.50
59.94
60.00
1280 x 720p 44.96
45.00
59.94
60.00
1920 x 1080i 33.72
33.75
59.94
60.00
1920 x 1080p
26.97
27.00
33.71
33.75
67.432
67.50
23.976
24.00
29.97
30.00
59.94
60.00
Component port connecting information
Component ports on the TV Y PBPR
Video output ports
on DVD player
Y PBPR
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
Component supported mode
Resolution Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
720 x 480i 15.73
15.73
59.94
60.00
720 x 480p 31.47
31.50
59.94
60.00
1280 x 720p 44.96
45.00
59.94
60.00
1920 x 1080i 33.72
33.75
59.94
60.00
1920 x 1080p
26.97
27.00
33.71
33.75
67.432
67.50
23.976
24.00
29.97
30.00
59.94
60.00
CHILD SAFETY:
It Makes A Difference How and Where
You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product,
please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and
larger flat panel displays are popular purchases. However, flat panel
displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers,
bookcases, shelves, desks, speakers, chests or carts may fall over and
cause injury.
THIS MANUFACURER CARES!
The consumer electronics industry is committed to making home
entertainment enjoyable and safe.
TUNE INTO SAFETY
One size does NOT fit all. Follow the manufacturer’s
recommendations for the safe installation and use of your flat panel
display.
Carefully read and understand all enclosed instructions for proper use
of this product.
Don’t allow children to climb on or play with furniture and television
sets.
Don’t allow place flat panel displays on furniture that can easily be
used as steps, such as a chest of drawers.
Remember that children can become excited while watching
a program, especially on a “larger than life” flat panel display.
Care should be taken to place or install the display where it cannot be
pushed, pulled over, or knocked down.
Care should be taken to route all cords and cables connected to the
flat panel display so that they cannot be pulled or grabbed by curious
children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT
YOUR FLAT PANEL DISPLAY, ALWAYS:
Use a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory
(such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount
manufacturers.
If you have any doubts about your ability to safely install your flat
panel display, contact your retailer about professional installation.
Make sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with steel studs or old cinder block construction.
If you are unsure, contact a professional installer.
A minimum of two people are required for installation.
Flat panel displays can be heavy
The model and serial number of the TV is
located on the back and/or one side of the TV.
Record it below should you ever need service.
MODEL
SERIAL
The extended owner’s manuals that contain
information on the advanced features of this LG
TV are located on the CD-ROM provided in an
electronic version.
To read these files, you will need to use the personal
computer (PC) equipped with a CD-ROM drive.
LG Customer Information Center
For inquires or comments, visit www.lg.com or call;
1-800-243-0000 USA, Consumer User
1-888-865-3026 USA, Commercial User
1-888-542-2623 CANADA
Register your product Online!
www.lg.com
(For LS3400, LS3410, LS3450, LS3500 series USA, Canada, Mexico)
This product qualifies for ENERGY STAR in the
“factory default (Home Use)” setting.
Changing the factory default settings or enabling
other features may increase power consumption
that could exceed the limits necessary to quality for
ENERGY STAR.
