www.lgsolutions.comP/NO : MFL67694902 (1305-REV01)
32LP645H
39LP645H
42LP645H
47LP645H
55LP645H
60LP645H
32LP620H
39LP620H
42LP620H
Please read this manual carefully before operating
your set and retain it for future reference.
QUICK REFERENCE GUIDE
LED TV*
* LG LED TV applies LCD screen with LED backlights.
ENGLISH
2IMPORTANT SAFETY INSTRUCTIONS
Do not use this apparatus near water.
Short-circuit
Breaker
Power Supply
Clean only with a dry cloth.
Short-circuit
Breaker
Power Supply
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Short-circuit
Breaker
Power Supply
Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Short-circuit
Breaker
Power Supply
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet (Can differ by
country).
Short-circuit
Breaker
Power Supply
Do not press strongly upon the panel with a hand or
a sharp object such as a nail, pencil or pen, or make
a scratch on it.
Short-circuit
Breaker
Power Supply
WARNING: This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your
product.
Short-circuit
Breaker
Power Supply
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED SERVICE PERSONNEL.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of
uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE AND ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
WARNING
If you ignore the warning message, you may be
seriously injured or there is a possibility of accident
or death.
CAUTION
If you ignore the caution message, you may be
slightly injured or the product may be damaged.
NOTE
The note helps you understand and use the product
safely. Please read the note carefully before using
the product.
ENGLISH
3
IMPORTANT SAFETY INSTRUCTIONS
Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
Short-circuit
Breaker
Power Supply
Only use attachments/accessories specified by the
manufacturer.
Short-circuit
Breaker
Power Supply
Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
Unplug this apparatus during lightning storms or
when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Do not stick metal objects or any other conductive
material into the power cord. Do not touch the end
of the power cord while it is plugged in.
Keep the packing anti-moisture material or vinyl
packing out of the reach of children. Anti-moisture
material is harmful if swallowed. If swallowed
by mistake, force the patient to vomit and visit
the nearest hospital. Additionally, vinyl packing
can cause suffocation. Keep it out of the reach of
children.
CAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be placed upon a
dedicated circuit; that is, a single outlet circuit which
powers only that appliance and has no additional
outlets or branch circuits. Check the specification
page of this owner’s manual to be certain. Do
not connect too many appliances to the same AC
power outlet as this could result in fire or electric
shock. Do not overload wall outlets. Overloaded
wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or damaged or
cracked wire insulation are dangerous. Any of these
conditions could result in electric shock or fire.
Periodically examine the cord of your appliance, and
if its appearance indicates damage or deterioration,
unplug it, discontinue use of the appliance, and have
the cord replaced with an exact replacement part
by an authorized service. Protect the power cord
from physical or mechanical abuse, such as being
twisted, kinked, pinched, closed in a door, or walked
upon. Pay particular attention to plugs, wall outlets,
and the point where the cord exits the appliance. Do
not move the TV with the power cord plugged in.
Do not use a damaged or loose power cord. Be sure
do grasp the plug when unplugging the power cord.
Do not pull on the power cord to unplug the TV.
Short-circuit
Breaker
Power Supply
Warning - To reduce the risk of fire or electrical
shock, do not expose this product to rain, moisture
or other liquids. Do not touch the TV with wet
hands. Do not install this product near flammable
objects such as gasoline or candles, or expose the
TV to direct air conditioning.
Short-circuit
Breaker
Power Supply
Do not expose to dripping or splashing and do not
place objects filled with liquids, such as vases, cups,
etc. on or over the apparatus (e.g. on shelves above
the unit).
Short-circuit
Breaker
Power Supply
ENGLISH
4IMPORTANT SAFETY INSTRUCTIONS
Grounding
(Except for devices which are not grounded.)
Ensure that you connect the earth ground wire to
prevent possible electric shock (i.e. a TV with a
three-prong grounded AC plug must be connected
to a three-prong grounded AC outlet). If grounding
methods are not possible, have a qualified
electrician install a separate circuit breaker. Do not
try to ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
Short-circuit
Breaker
Power Supply
As long as this unit is connected to the AC wall
outlet, it is not disconnected from the AC power
source even if the unit is turned off.
Do not attempt to modify this product in any way
without written authorization from LG Electronics.
Unauthorized modification could void the user’s
authority to operate this product.
Outdoor Antenna Grounding (Can differ by country):
If an outdoor antenna is installed, follow the
precautions below. An outdoor antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power circuits,
or where it can come in contact with such power
lines or circuits as death or serious injury can occur.
Be sure the antenna system is grounded so as to
provide some protection against voltage surges
and built-up static charges. Section 810 of the
National Electrical Code (NEC) in the U.S.A. provides
information with respect to proper grounding of the
mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
Short-circuit
Breaker
Power Supply
Ground Clamp
Grounding Conductor
(NEC Section 810-21)
Antenna Lead in Wire
Electric Service
Equipment
Antenna Discharge Unit
(NEC Section 810-20)
Ground Clamp
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
NEC: National Electrical Code
Cleaning
When cleaning, unplug the power cord and wipe
gently with a soft cloth to prevent scratching. Do
not spray water or other liquids directly on the TV
as electric shock may occur. Do not clean with
chemicals such as alcohol, thinners or benzine.
Moving
Make sure the product is turned off, unplugged
and all cables have been removed. It may take 2 or
more people to carry larger TVs. Do not press or put
stress on the front panel of the TV.
Ventilation
Install your TV where there is proper ventilation. Do
not install in a confined space such as a bookcase.
Do not cover the product with cloth or other
materials while plugged. Do not install in excessively
dusty places.
If you smell smoke or other odors coming from
the TV, unplug the power cord and contact an
authorized service center.
Keep the product away from direct sunlight.
Never touch this apparatus or antenna during a
thunder or lightning storm.
When mounting a TV on the wall, make sure not
to install the TV by hanging the power and signal
cables on the back of the TV.
Do not allow an impact shock or any objects to fall
into the product, and do not drop anything onto the
screen.
Disconnecting the Main Power
The power outlet used with this device must remain
easily accessible.
Store the accessories (battery, etc.) in a safe
location out of the reach of children.
This apparatus use batteries. In your community
there might be regulations that require you
to dispose of these batteries properly due to
environmental considerations. Please contact your
local authorities for disposal or recycling information.
Do not dispose of batteries in a fire.
Do not short circuit, disassemble or allow the
batteries to overheat.
ENGLISH
5
IMPORTANT SAFETY INSTRUCTIONS
Dot Defect
The Plasma or LCD panel is a high technology
product with resolution of two million to six million
pixels. In a very few cases, you could see fine dots
on the screen while you’re viewing the TV. Those
dots are deactivated pixels and do not affect the
performance and reliability of the TV.
Generated Sound
“Cracking” noise: A cracking noise that occurs
when watching or turning off the TV is generated by
plastic thermal contraction due to temperature and
humidity. This noise is common for products where
thermal deformation is required.
Electrical circuit humming/panel buzzing: A low level
noise is generated from a high-speed switching
circuit, which supplies a large amount of current
to operate a product. It varies depending on the
product.
This generated sound does not affect the
performance and reliability of the product.
Take care not to touch the ventilation openings.
When watching the TV for a long period, the
ventilation openings may become hot. This does
not affect the performance of the product or cause
defects in the product.
If the TV feels cold to the touch, there may be a
small “flicker” when it is turned on. This is normal,
there is nothing wrong with TV. Some minute dot
defects may be visible on the screen, appearing as
tiny red, green, or blue spots. However, they have
no adverse effect on the TV’s performance. Avoid
touching the LCD screen or holding your finger(s)
against it for long periods of time. Doing so may
produce some temporary distortion effects on the
screen.
Preventing “Image burn” or “Burn-in” on your TV
screen
If a fixed image displays on the TV screen for a long
period of time, it will be imprinted and become a
permanent disfigurement on the screen. This is
“image burn” or “burn-in” and not covered by the
warranty.
If the aspect ratio of the TV is set to 4:3 for a
long period of time, image burn may occur on the
letterboxed area of the screen.
Avoid displaying a fixed image on the TV screen for
a long period of time (2 or more hours for LCD, 1
or more hours for the Plasma TV) to prevent image
burn.
For USA and Canada
FCC NOTICE
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and the receiver.
- Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference
and (2) this device must accept any interference
received, including interference that may cause
undesired operation of the device.
Any changes or modifications in construction of
this device which are not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the National
Electric Code (U.S.A.). The code provides guidelines
for proper grounding and, in particular, specifies
that the cable ground shall be connected to the
grounding system of the building, as close to the
point of the cable entry as practical.
ENGLISH
6LICENSES / OPEN SOURCE SOFTWARE NOTICE
LICENSES
Supported licenses may differ by model. For more information about licenses, visit ‘www.lg.com’.
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI Licensing LLC in the United States and other
countries.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi
Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.com for
more information and software tools to convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to
play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate
the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on
how to complete your registration.
“DivX Certified® to play DivX® video up to HD 1080p, including premium content.”
“DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its
subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274”
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product,
please visit ‘http://opensource.lge.com’.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for
download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such
distribution (such as the cost of media, shipping and handling) upon email request to ‘opensource@lge.com’. This offer
is valid for three (3) years from the date on which you purchased the product.
ENGLISH
7
TABLE OF CONTENTS
2 IMPORTANT SAFETY INSTRUCTIONS
6 LICENSES
6 OPEN SOURCE SOFTWARE NOTICE
7 TABLE OF CONTENTS
8 INSTALLATION PROCEdURE
8 ASSEMBLING ANd PREPARING
8 Unpacking
10 Parts and buttons
12 Lifting and moving the TV
13 Setting up the TV
13 - Attaching the stand
15 - Mounting on a table
18 - Mounting on a wall
19 - External speaker out
19 - Tidying cables
20 Making Connections
21 REMOTE CONTROL
23 SPECIFICATIONS
26 TROUBLESHOOTING
27 IR COdES
TABLE OF CONTENTS
Image shown may differ from your TV.
Your TV’s OSD (On Screen Display) may differ
slightly from that shown in this manual.
The available menus and options may differ from
the input source or product model that you are
using.
New features may be added to this TV in the
future.
NOTE
ENGLISH
8INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING
INSTALLATION PROCEdURE
1 Open the package and make sure all the accessories are included.
2 Attach the stand to the TV set.
3 Connect an external device to the TV set.
ASSEMBLING ANd PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the dealer where you
purchased your product. The illustrations in this manual may differ from the actual product and item.
Do not use any unapproved items to ensure the safety and product life span.
Any damages or injuries by using unapproved items are not covered by the warranty.
Some models appear to have a thin film on the screen. It is actually part of the screen, do not remove it.
CAUTION
The items supplied with your product may vary depending on the model.
Product specifications or contents of this manual may be changed without prior notice due to upgrade of product
functions.
For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39 inches) thick
and 18 mm (0.7 inches) width.
Use an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit into your TV’s
USB port.
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
NOTE
FREEZE
RATIO
L/R SELECT
ENTER
BACK EXIT
Q.MENU
INFO
MENU
CHVOL
P
A
G
E
FAV
3D
MUTE
1 2 3
4 5 6
7 8
0
9
MARK
LIST
FLASHBK
ENERGY
SAVING
TV
AV MODE
INPUT
Remote Control, Batteries (AAA)
(See p. 21)
Quick Reference Guide Power Cord
ENGLISH
9
ASSEMBLING AND PREPARING
(For 32/39/42/47LP645H,
32/39/42LP620H)
(For 55/60LP645H)
Stand Body, Stand Base
(See p. 13)
Stand Body, Stand Base
(See p. 14) Desk-Mount Screw
(See p. 15)
(For 32/39/42/47LP645H,
32/39/42LP620H)
(For 55LP645H) (For 60LP645H)
Stand Screws
4 EA, M4 x 20
4 EA, M4 x 16
(See p. 13)
Stand Screws
7 EA, M4 x 14
(See p. 14)
Stand Screws
3 EA, P5 x 25
4 EA, M4 x 14
(See p. 14)
(For 32/39/42/47LP645H,
32/39/42LP620H)
(For 32/39/42/47LP645H,
32/39/42LP620H)
(For 32/39/42/47LP645H,
32/39/42LP620H)
Screws for Stand Fixing
2 EA
(See p. 17)
Nuts for Stand Fixing
2 EA
(See p. 17)
Washers for Stand Fixing
2 EA
(See p. 17)
Torx Plus
Star-Head Screw
2 EA
(
See p. 13, 14
)
Power Cord Holder and Screw
(See p. 19)
Cable Holder
(See p. 19)
ENGLISH
10 ASSEMBLING AND PREPARING
Parts and buttons
Button Description
/ ( / ) Scrolls through the saved channels.
/ ( / ) Adjusts the volume level.
(OK ) Selects the highlighted menu option or confirms an input.
(SETTINGS)Accesses the main menus, or saves your input and exits the menus.
(INPUT )Changes the input source.
( ) Turns the power on or off.
GAME CONTROL
2
1
/ DVI IN
RS-232C IN
(SERVICE ONLY)
RGB IN (PC)
SPEAKER OUT
LINE OUT
ANTENNA/
CABLE IN
OPTICAL
AUDIO OUT
AV IN
VIDEO
L/MONO
-AUDIO-
R
L R
AUDIO IN (RGB DVI)
RESET
UPDATE
RJP
PTC SERVICE
(SERVICE ONLY)
/ M.P.I.
GAME CONTROL
TV-LINK
CFG
USB IN
IN 3
Buttons
Screen
Speakers
Power Indicator
Remote Control Sensor
Rear Connection Panel
Side Connection
Panel
For LP645H series
ENGLISH
11
ASSEMBLING AND PREPARING
Button Description
/ ( / ) Scrolls through the saved channels.
/ ( / ) Adjusts the volume level.
(OK ) Selects the highlighted menu option or confirms an input.
(SETTINGS)Accesses the main menus, or saves your input and exits the menus.
(INPUT )Changes the input source.
( ) Turns the power on or off.
GAME CONTROL
2
1
/ DVI IN
RS-232C IN
(SERVICE ONLY)
RGB IN (PC)
SPEAKER OUT
LINE OUT
ANTENNA/
CABLE IN
OPTICAL
AUDIO OUT
AV IN
VIDEO
L/MONO
-AUDIO-
R
L R
AUDIO IN (RGB DVI)
RESET
UPDATE
RJP
PTC SERVICE
(SERVICE ONLY)
M.P.I
USB IN
IN 3
Buttons
Screen
Speakers
Power Indicator
Remote Control Sensor
Rear Connection Panel
Side Connection
Panel
For LP620H series
ENGLISH
12 ASSEMBLING AND PREPARING
Lifting and moving the TV
When moving or lifting the TV, read the following to
prevent the TV from being scratched or damaged and for
safe transportation regardless of its type and size.
Avoid touching the screen at all times, as this may
result in damage to the screen.
CAUTION
It is recommended to move the TV in the box or
packing material that the TV originally came in.
Before moving or lifting the TV, disconnect the
power cord and all cables.
When holding the TV, the screen should face away
from you to avoid damage.
Hold the top and bottom of the TV frame firmly.
Make sure not to hold the transparent part, speaker,
or speaker grill area.
When transporting a large TV, there should be at
least 2 people.
When transporting the TV by hand, hold the TV as
shown in the following illustration.
When transporting the TV, do not expose the TV to
jolts or excessive vibration.
When transporting the TV, keep the TV upright,
never turn the TV on its side or tilt towards the left
or right.
ENGLISH
13
ASSEMBLING AND PREPARING
2
3
or
Tighten the two of these four screws and the two
Torx plus star head screws
(provided as parts of the TV) to secure the TV.
Tighten the two Torx plus star head screws with a
star head driver bit (not provided as parts of the TV).
2 EA
ὤ㨴㥄
 
wyv{lj{pvuGjv}ly
2 EA
M4 x 16
4 EA
Setting up the TV
You can mount your TV to a wall or attach the stand if you wish to place the TV on an entertainment center
or other furniture.
Attaching the stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to
protect the screen from scratches.
Make sure that the screws are fastened tightly. (If they are not fastened securely enough, the TV may tilt forward
after being installed.)
Do not tighten the screws with too much force; otherwise they may be damaged and come loose later.
CAUTION
Make sure to hold the stand when attaching it to the TV to prevent the stand or TV from falling.
Remove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.
NOTE
Stand Body
Stand Base
Front
14 EA
M4 x 20
(For 32/39/42/47LP645H, 32/39/42LP620H)
ENGLISH
14 ASSEMBLING AND PREPARING
3
2
(For 55/60LP645H)
Stand Body
Stand Base
Front
1
3 EA
M4 x 14
(For 55LP645H)
(For 60LP645H)
3 EA
P5 x 25
or
Tighten the two of these four screws and the two
Torx plus star head screws
(provided as parts of the TV) to secure the TV.
Tighten the two Torx plus star head screws with a
star head driver bit (not provided as parts of the TV).
2 EA
ὤ㨴㥄
 
wyv{lj{pvuGjv}ly
2 EA
4 EA
M4 x 14
ENGLISH
15
ASSEMBLING AND PREPARING
Mounting on a table
1 Lift and tilt the TV into its upright position on a table.
- Leave a 10 cm (4 inches) (minimum) space from
the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
(4 inches)
2 Connect the power cord to a wall outlet.
Do not place the TV near or on sources of heat, as
this may result in fire or other damage.
CAUTION
Securing the TV to a table
Fix the TV to a table to prevent from tilting forward,
damage, and potential injury.
Mount the TV on a table, and then insert and tighten the
supplied screw on the rear of the stand.
To prevent TV from falling over, the TV should be
securely attached to the floor/wall per installation
instructions. Tipping, shaking, or rocking the TV
may cause injury.
WARNING
Make sure that children do not climb on or hang on
the TV.
CAUTION
Using the Kensington security system (optional)
The Kensington security system connector is located at
the rear of the TV.
For more information of installation and using, refer
to the manual provided with the Kensington security
system or visit http://www.kensington.com.
Connect the Kensington security system cable between
the TV and a table.
The Kensington security system is optional. You
can obtain additional accessories from your local
dealer.
NOTE
ENGLISH
16 ASSEMBLING AND PREPARING
Adjusting the angle of the TV to suit view
(For 32/39/42/47LP645H, 32/39/42LP620H)
The swivel angle is adjustable. The default swivel angle
is 20°. Attaching a screw to the A position on the bottom
of the stand will allow a swivel angle range of 45°.
Attaching a screw to the B position will allow a swivel
angle range of 90°.
20˚20˚
A
B
C
Only one swivel screw is included and attached
to position C.
NOTE
When adjusting the angle of the TV, watch out
for your fingers.
- Personal injury may occur if hands or fingers are
pinched. If the product is tilted too much, it may
fall, causing damage or injury.
Removing the swivel fixing screw will allow the
set to rotate 360°.
CAUTION
(For 55LP645H)
Swivel 90 degrees to the left or right and adjust the
angle of the TV to suit your view.
90˚90˚
When adjusting the angle of the TV, watch out
for your fingers.
- Personal injury may occur if hands or fingers are
pinched. If the product is tilted too much, it may
fall, causing damage or injury.
CAUTION
ENGLISH
17
ASSEMBLING AND PREPARING
Attaching the TV to a desk
(Depending on model)
The TV should be attached to a desk so it cannot be
pulled in a forward/backward direction, potentially
causing injury or damaging the product.
TYPE 1
4-Screws
(Not provided as parts of the product)
Desk
Stand
NOTE
Screw: M5 x L (*L: Table depth + 8~10 mm)
ex) Table depth: 15mm, Screw: M5 x 25
TYPE 2
2-Screws, 2-Washers, 2-Nuts
(provided as parts of the product)
Desk
Stand
Securing the TV to a wall (optional)
(Depending on model)
1 Insert and tighten the eye-bolts, or TV brackets and
bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts position,
remove the bolts first.
2 Mount the wall brackets with the bolts to the wall.
Match the location of the wall bracket and the eye-
bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly with
a sturdy rope.
Make sure to keep the rope horizontal with the flat
surface.
Make sure that children do not climb on or hang on
the TV.
CAUTION
Use a platform or cabinet that is strong and large
enough to support the TV securely.
Brackets, bolts and ropes are optional. You can
obtain additional accessories from your local dealer.
NOTE
ENGLISH
18 ASSEMBLING AND PREPARING
Mounting on a wall
An optional wall mount can be used with your LG
Television. Consult with your local dealer for a wall
mount that supports the VESA standard used by your
TV model. Carefully attach the wall mount bracket at the
rear of the TV. Install the wall mount bracket on a solid
wall perpendicular to the floor. If you are attaching the
TV to other building materials, please contact qualified
personnel to install the wall mount. Detailed instructions
will be included with the wall mount. We recommend
that you use an LG brand wall mount.
10 cm
10 cm
10 cm
10 cm
(4 inches)
Make sure to use screws and wall mounts that meet the
VESA standard. Standard dimensions for the wall mount
kits are described in the following table.
Model 32LP645H
32LP620H
39LP645H
39LP620H
42LP645H
42LP620H
VESA (A x B)
A
B
200 x 100 200 x 200
Standard screw M4 M6
Number of screws 4 4
Wall mount bracket
(optional)
LSW130B LSW230B
Model 47LP645H
55LP645H
60LP645H
VESA (A x B)
A
B
400 x 400
Standard screw M6
Number of screws 4
Wall mount bracket
(optional)
LSW430B
Disconnect the power before moving or installing
the TV. Otherwise electric shock may occur.
If you install the TV on a ceiling or slanted wall, it
may fall and result in severe injury.
Use an authorized LG wall mount and contact the
local dealer or qualified personnel.
Do not over tighten the screws as this may cause
damage to the TV and void your warranty.
Use the screws and wall mounts that meet the
VESA standard. Any damages or injuries by misuse
or using an improper accessory are not covered by
the warranty.
CAUTION
The wall mount bracket is optional. You can obtain
additional accessories from your local dealer.
Use the screws that are listed in the VESA
standard screw specifications.
The wall mount kit includes an installation manual
and necessary parts.
The length of screws may differ depending on the
wall mount. Make sure to use the proper length.
For more information, refer to the manual supplied
with the wall mount.
NOTE
ENGLISH
19
ASSEMBLING AND PREPARING
External speaker out
(This section uses illustrations of LP645H series.)
Connect the external speaker.
G
AME
CO
NTR
OL
2
1
/
DVI I
N
RS
-2
3
2
C
IN
(
SERVICE ONLY
)
R
G
B IN (P
C
)
SPEAKER OUT
LINE OUT
ANTENNA/
C
ABLE IN
O
PTICAL
AUDIO OUT
AV
IN
VIDE
O
L
/M
O
N
O
-
AUDI
O
-
R
L
R
AUDI
O
IN
(
R
G
B DVI
)
RE
S
E
T
U
PDAT
E
RJP
PT
C
S
ERVI
C
E
(S
ERVI
C
E
O
NLY)
/
M.P.I.
TV
-L
INK
C
F
G
R
GND
L
GND
Make sure that the external speaker should be
connected with TV under power-off state.
Use external speaker with SE type (3 pin).
NOTE
Tidying cables
1 Install the power cord holder and power cord. It will
help prevent the power cable from being removed
by accident.
2 Gather and bind the cables with the cable holder.
For 32/39/42LP645H, 32/39/42LP620H
Power Cord Holder
and Screw
Cable Holder
For 47/55/60LP645H
Power Cord Holder
and Screw
Cable Holder
Do not move the TV by holding the cable holder
and power cord holder, as the cable holders may
break, and injuries and damage to the TV may
occur.
CAUTION
ENGLISH
20 ASSEMBLING AND PREPARING
5*%2873&
$8',2287
VIDEO
MONO
( )
AUDIOL R
AV IN
VIDEO
L/MONO
-AUDIO-
R
L R
AUDIO IN (RGB DVI)
AV IN
VIDEO
L/MONO
-AUDIO-
R
L R
AUDIO IN (RGB DVI)
RGB IN (PC)
Making Connections
Image shown may differ from your TV.
Connect the external devices.
or
PC
dVd / Blu-Ray / Hd Cable Box / VCR
(Not provided)
(Not provided)
(Not provided)
YELLOW
YELLOW
WHITE WHITE
WHITE
RED RED
RED
ENGLISH
21
REMOTE CONTROL
REMOTE CONTROL
Below is a description of the remote control. Your remote control may look slightly different.
To install batteries, open the battery cover, insert batteries (1.5 V AAA) matching the and
ends to the label inside the compartment, and close the battery cover. To remove the batteries,
perform the installation actions in reverse.
This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote sensor.
CH
1 2 3
4 5 6
7 8
0
9
P
A
G
E
Q.MENU
INPUT
CHAR/NUM
FLASHBK
EXIT
OK
GUIDE
PORTAL
TV DVD
MARK
CC
TIMER
MUTE
INFO
PIP PIPCH+ PIPCH
-
SWAP
PIP
INPUT
SAP
MENU
SETTINGS
abc def
ghi jkl mno
pqrs tuv wxyz
.,;@
DELETE
ENTER
VOL
(POWER)
Turns the TV on or off.
Q. MENU
Not functional
TV
Selects the remote’s operating mode: TV.
DVD
Selects the remote’s operating mode: DVD.
INPUT
Rotates through inputs.
MARK
Not functional
Number button
Enters numbers. Also supports characters.
— (DASH)
Selects a program number for multiple program channels such as 2-1, 2-2, etc.
FLASHBK
Tunes to the last channel or input viewed.
VOL
Adjusts the volume level.
CHAR/NUM
Switches between Letter and Number input modes.
CC
Selects a closed caption.
TIMER
Turns the TV off in a set amount of time.
DELETE
Deletes letters and numbers.
MUTE
Mutes all sounds.
^
CH
v
Scrolls through the saved channels.
PAGE
Moves to the previous or next screen.
Do not mix old and new batteries, as this may damage the remote control.
CAUTION
ENGLISH
22 REMOTE CONTROL
CH
1 2 3
4 5 6
7 8
0
9
P
A
G
E
Q.MENU
INPUT
CHAR/NUM
FLASHBK
EXIT
OK
GUIDE
PORTAL
TV DVD
MARK
CC
TIMER
MUTE
INFO
PIP PIPCH+ PIPCH
-
SWAP
PIP
INPUT
SAP
MENU
SETTINGS
abc def
ghi jkl mno
pqrs tuv wxyz
.,;@
DELETE
ENTER
VOL
Color buttons ( : Red, : Green, : Yellow, : Blue )
These access special functions in some menus.
VCR/DVD/USB control buttons ( , , , , )
Controls video cassette recorders or DVD players or USB.
Accesses the AV devices connected to the TV;
Opens the SIMPLINK menu.
PIP
Not functional
PIP CH +/-
Not functional
SWAP
Not functional
PIP INPUT
Not functional
SAP
Analog mode: Selects MTS sound (Mono, Stereo or SAP)
DTV mode: Changes the audio language.
PORTAL
Displays and removes Pro:Centric Application.
INFO
Views the information list of the Pro:Centric Application.
GUIDE
Displays and removes the electronic program guide.
Navigation buttons (up/down/left/right)
Scrolls through menus or options.
OK/ENTER ꔉ
Selects menus or options and confirms your input.
ꕣ (BACK)
Returns to the previous level.
MENU/SETTINGS
Accesses the main menu.
EXIT ꕯ
Clears all on-screen displays and returns to TV viewing.
ENGLISH
23
SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Power requirement AC 100 - 240 V ~ 50 / 60 Hz
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
External Antenna Impedance 75 Ω
Environment
condition
Operating Temperature 0 °C ~ 40 °C (32 °F ~ 104 °F)
Operating Humidity Less than 80 %
Storage Temperature -20 °C ~ 60 °C (-4 °F ~ 140 °F)
Storage Humidity Less than 85 %
MODELS 32LP645H
(32LP645H-UH)
32LP620H
(32LP620H-UH)
Dimensions
(W x H x D)
With stand 738 x 496 x 226 (mm)
29.0 x 19.5 x 8.9 (inch)
Without stand
738 x 449 x 79 (mm)
29.0 x 17.7 x 3.1 (inch)
Weight With stand 8.9 kg (19.6 lbs)
Without stand 6.4 kg (14.1 lbs)
Current Value / Power consumption 1.3 A / 80 W
MODELS 39LP645H
(39LP645H-UH)
39LP620H
(39LP620H--UH)
Dimensions
(W x H x D)
With stand 894 x 583 x 283 (mm)
35.2 x 23.0 x 11.1 (inch)
Without stand 894 x 537 x 79 (mm)
35.2 x 21.1 x 3.1 (inch)
Weight With stand 12.3 kg (27.1 lbs)
Without stand 8.6 kg (18.9 lbs)
Current Value / Power consumption 1.5 A / 100 W
MODELS 42LP645H
(42LP645H-UH)
42LP620H
(42LP620H--UH)
Dimensions
(W x H x D)
With stand 968 x 625 x 283 (mm)
38.1 x 24.6 x 11.1 (inch)
Without stand
968 x 579 x 79 (mm)
38.1 x 22.8 x 3.1 (inch)
Weight With stand 13.3 kg (29.3 lbs)
Without stand 9.6 kg (21.2 lbs)
Current Value / Power consumption 1.6 A / 110 W
ENGLISH
24 SPECIFICATIONS
MODELS 47LP645H
(47LP645H-UH)
Dimensions
(W x H x D)
With stand 1,080 x 688 x 282.4 (mm)
42.5 x 27.1 x 11.1 (inch)
Without stand 1,080 x 642 x 80.5 (mm)
42.5 x 25.3 x 3.2 (inch)
Weight With stand 16.7 kg (36.8 lbs)
Without stand 13.4 kg (29.5 lbs)
Current Value / Power consumption 1.3 A / 130 W
MODELS 55LP645H
(55LP645H-UH)
Dimensions
(W x H x D)
With stand 1,250 x 790 x 297 (mm)
49.2 x 31.1 x 11.6 (inch)
Without stand 1,250 x 737 x 79.1 (mm)
49.2 x 29.0 x 3.1 (inch)
Weight With stand 21.3kg (46.9 lbs)
Without stand 19.1 (42.1 lbs)
Current Value / Power consumption 1.6 A / 160 W
MODELS 60LP645H
(60LP645H-UA)
Dimensions
(W x H x D)
With stand 1,359 x 852 x 297 (mm)
53.5 x 33.5 x 11.6 (inch)
Without stand 1,359 x 799 x 67.2 (mm)
53.5 x 31.4 x 2.6 (inch)
Weight With stand 26.3 kg (57.9 lbs)
Without stand 24.2 kg (53.3 lbs)
Current Value / Power consumption 2.0 A / 200 W
ENGLISH
25
SPECIFICATIONS
HDMI (DTV) supported mode
Resolution Horizontal
Frequency (kHz)
Vertical Frequency
(Hz)
720 x 480p 31.47 59.94
31.50 60.00
1280 x 720p 44.96 59.94
45.00 60.00
1920 x 1080i 33.72 59.94
33.75 60.00
1920 x 1080p
26.97 23.976
27.00 24.00
33.71 29.97
33.75 30.00
67.432 59.94
67.50 60.00
RGB (PC), HDMI (PC) supported mode
Resolution Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
720 x 400 31.46 70.08
640 x 480 31.46 59.94
800 x 600 37.87 60.31
1024 x 768 48.36 60.00
1360 x 768 47.71 60.01
1280 x 1024 63.98 60.02
1920 x 1080 67.50 60.00
Except 32LP645H, 32LP620H
ENGLISH
26 TROUBLESHOOTING
TROUBLESHOOTING
General
Problem Solution
Cannot control the TV with the remote
control.
Check the remote control sensor on the product and try again.
Check if there is any obstacle between the product and the remote control.
Check if the batteries are still working and properly installed ( to , to ).
No image display and no sound is
produced.
Check if the product is turned on.
Check if the power cord is connected to a wall outlet.
Check if there is a problem in the wall outlet by connecting other products.
Image appears slowly when the TV
turns on.
The image is muted during the product startup process. This is normal. If the image does not
appear in a few minutes, unplug the TV for 30 seconds and try again. If the image still does
not appear, contact the authorized service center in your local area.
Cannot connect external devices. Refer to the “Connection Overview” and connect an external device.
The TV turns off suddenly. Check the power control settings. The power supply may be interrupted.
Check if the Auto sleep feature is activated in the Time settings.
Refer to the “Sleep Timer”.
Audio
Problem Solution
No sound is produced while images are
displaying.
Press VOL + or - button.
Check if the sound is muted by pressing MUTE.
Scroll to other channels. There may a problem with the broadcast.
Check if the TV Speaker feature is activated in the menu option.
No output from one of the speakers Adjust Balance in the menu option.
Unusual sound from inside the TV is
produced.
A change in ambient humidity or temperature may result in an unusual noise when the
product turns on or off. There is no problem with your product.
Video
Problem Solution
An image displays in black and white or
the color quality is poor.
Adjust the color setting in the menu option.
Keep a sufficient distance between this product and other electronic products.
Scroll to other channels. There may a problem with the broadcast.
Horizontal or vertical bars appears or
images blur
Check if there are local interferences such as an electrical appliance or power tool.
Lines or streaks appear on images Check the antenna or aim the antenna to the proper direction.
Afterimages (ghosts) appear when the
product turns off
Pixels may have been damaged from a fixed image displayed for a long time (image burn).
Use a screen saver to prevent the pixel damage on the screen.
The power is on but the screen appears
extremely dark.
Adjust the brightness and contrast in the menu option.
“No Signal” appears on the screen. Check if the signal cable is connected between the TV and products properly.
Check the selected input source by pressing INPUT.
Black spots appear on the screen. Several pixels in red, green, white, or black may appear on the screen that can attribute to
the characteristics of the panel.
This is normal.
The display offset is wrong. Adjust the position setting in the Picture menu.
Check if the video card resolution and frequency are supported by the product. If the
frequency is out of range, set to the recommended resolution using the display settings on
the external device.
Thin lines appear in the background of
the screen.
Check the video cable connections.
The reception on some channels is
poor
Scroll to other channels. There may a problem with the broadcast.
The station signal may be weak. Aim the antenna to the proper direction.
Check if there is local interferences such as an electrical appliance or power tool.
ENGLISH
27
IR CODES
IR COdES
(Depending on model)
Code
(Hexa) Function Note
08 (POWER) Remote control Button (Power On/Off)
0B INPUT Remote control Button
0F TV Remote control Button
10-19 Number Key 0-9 Remote control Button
4C - (DASH) Remote control Button
1A FLASHBK Remote control Button
02 VOL + Remote control Button
03 VOL - Remote control Button
09 MUTE / DELETE Remote control Button
00 CH
^ /
PAGE
^
Remote control Button
01 CH
v /
PAGE
v
Remote control Button
43 SETTINGS / MENU Remote control Button
45 Q.MENU Remote control Button
28 ꕣ (BACK) Remote control Button
AA INFO Remote control Button
5B EXIT Remote control Button
44 OK / ENTER Remote control Button
40
^
Remote control Button
41
v
Remote control Button
07
<
Remote control Button
06
>
Remote control Button
C1 RED Remote control Button
C0 GREEN Remote control Button
C2 YELLOW Remote control Button
C3 BLUE Remote control Button
B1 ꕗRemote control Button
B0 ►Remote control Button
BA ꕘRemote control Button
8E ►► Remote control Button
8F ◄◄ Remote control Button
7E SIMPLINK Remote control Button
60 PIP Remote control Button
71 PIP CH + Remote control Button
72 PIP CH - Remote control Button
63 SWAP Remote control Button
61 PIP INPUT Remote control Button
0A SAP Remote control Button
0E TIMER Remote control Button
39 CC / CHAR/NUM Remote control Button
1E MARK Remote control Button
0C PORTAL Remote control Button
AB GUIDE Remote control Button
Congratulations on your purchase! As you enjoy your new product,
please keep these safety tips in mind:
THE ISSUE
• The home theater entertainment experience is a growing trend and
larger flat panel displays are popular purchases. However, flat panel
displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
• Flat panel displays that are inappropriately situated on dressers,
bookcases, shelves, desks, speakers, chests or carts may fall over
and cause injury.
THIS MANUFACURER CARES!
• The consumer electronics industry is committed to making home
entertainment enjoyable and safe.
TUNE INTO SAFETY
• One size does NOT fit all. Follow the manufacturer’s
recommendations for the safe installation and use of your flat panel
display.
• Carefully read and understand all enclosed instructions for proper
use of this product.
• Don’t allow children to climb on or play with furniture and television
sets.
• Don’t allow place flat panel displays on furniture that can easily be
used as steps, such as a chest of drawers.
• Remember that children can become excited while watching a
program, especially on a “larger than life” flat panel display.
Care should be taken to place or install the display where it cannot
be pushed, pulled over, or knocked down.
• Care should be taken to route all cords and cables connected to the
flat panel display so that they cannot be pulled or grabbed by curious
children.
WALL MOUNTING: IF YOU DECIDE TO WALL
MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
• Use a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory
(such as UL, CSA, ETL).
• Follow all instructions supplied by the display and wall mount
manufacturers.
• If you have any doubts about your ability to safely install your flat
panel display, contact your retailer about professional installation.
• Make sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted to
walls with steel studs or old cinder block construction.
If you are unsure, contact a professional installer.
• A minimum of two people are required for installation.
Flat panel displays can be heavy.
CHILD SAFETY:
It Makes A Difference How and Where
You Use Your Flat Panel Display
The model and serial number of the TV is located
on the back and one side of the TV.
Record it below should you ever need service.
MODEL
SERIAL
Pro:Centric is a trademark of LG Electronics U.S.A., Inc. Pro:Idiom is
a registered trademark of Zenith Electronics LLC. b-LAN is a trademark
of LodgeNet Interactive Corporation. All other trademarks or registered
trademarks are the property of their respective owners.
LG Customer Information Center
For inquires or comments, visit www.lg.com or call:
1-888-865-3026
1-888-542-2623
USA, Commercial User
CANADA
This product qualifies for ENERGY STAR in the
“factory default (Home Use)” setting.
Changing the factory default settings or enabling
other features may increase power consumption
that could exceed the limits necessary to quality
for ENERGY STAR.

Navigation menu
