FEATURES

•TruMotion 120Hz

•Full HD 1080p Resolution

•100,000:1 Dynamic Contrast Ratio

•Picture Wizard II

(Easy Picture Calibration)

•Smart Energy Saving

•Intelligent Sensor

•AV Mode II

(Cinema, Sports, Game)

•Clear Voice II

•ISFccc® Ready

•24P Real Cinema

•USB 2.0 (JPEG & MP3)

•3 HDMI™ V.1.3 w/Deep Color

•SIMPLINK™ Connectivity

• Dolby® Digital 5.1 Decoder

• Infinite Sound

Double the detail. This stunning picture is the

reason you wanted HDTV in the first place. With

almost double the pixel resolution, Full HD 1080p

gives it superior picture quality over standard HDTV.

You’ll see details and colors like never before.

Get easy self-calibration with on-screen

reference points for key picture quality elements

such as black level, color, tint, sharpness and

backlight levels. Take the guesswork out of picture

adjustments with this simple-to-use feature.

Less blur. More action. TruMotion 120Hz

technology lets you see sports, video games and

high-speed action with virtually no motion blur.

Now your TV can keep up with your fast- moving

entertainment.

Is it a TV? Or something better?

This is a Full HD television anyone would be happy with, at almost any

budget. It’s great for sports and fast action offering technologies that

make the LD520 something better.

LCD TV

55LD520

55” CLass

54.6” diagonal

HIGHLIGHTs

TruMotion 120Hz

Full HD 1080p Resolution

100,000:1 Dynamic Contrast Ratio

PANEL SPECIFICATION

Screen Size 55” Class (54.6” diagonal)

Resolution 1920 x 1080p

Brightness (cd/m2) TBD

Dynamic Contrast Ratio 100,000:1

Viewing Angle 178º/178º

Response Time (GTG) 2.4ms

TruMotion 120Hz •

Life Span (Typical) 60,000 hrs

VIDEO

Built-In Tuner ATSC/NTSC/Clear QAM

XD® Engine •

Aspect Ratio 16:9

Aspect Ratio Correction 6 Modes

Just Scan (1:1 Pixel Matching)

HDMI™ 1080p/1080i/720p

Component 1080p/1080i/720p

RF 1080i/720p

Color Temperature Control 3 Modes

24p Real Cinema (5:5/2:2 Pulldown) •

3:2 Pulldown •

Picture Reset •

AV Mode II •

Picture Mode 8 Modes

ISFccc® Ready •

Intelligent Sensor Mode •

x.v.Color •

DTV Signal Strength Indicator •

AUDIO

Mono/Stereo/Dual (MTS/SAP) •

Audio Output Power (Watts - THD 10%) 20W (10W x 2)

Speaker System Details 1 Way 2 Speakers

Dolby® Digital Decoder •

Surround System Infinite Sound

Bass/Treble/Balance Controls •

Clear Voice II •

Auto Volume Leveler II •

EZ Sound Mode 5 Modes

SPECIAL FEATURES

Picture Wizard II •

Backlight Control •

Smart Energy Saving •

1080p Source Input

HDMI™ 60p/30p/24p

Component 60p/30p/24p

RGB 60p (WXGA)

A/ V Input Navigation •

Input Labeling •

Quick View (Flashback) •

Parental Control w/V-Chip •

Key Lock •

Closed Caption •

SPECIAL FEATURES (CONTINUED)

SIMPLINK™ (HDMI CEC) •

CONVENIENCE FEATURES

Language 4 (English/Spanish/French/Korean)

Auto Tuning/Programming •

Channel Add/Delete •

Favorite Channel Programming •

Auto/Manual Clock •

On/Off Timer •

Sleep Timer •

Auto Off/Auto Sleep (When no video is present) •

AUDIO/VIDEO INPUTS/OUTPUTS

RF In (Antenna/Cable) 1 (rear)

AV In 1 (rear) 1 (side)

Component Video In (Y, Pb, Pr) + Audio 1 (rear)

Digital Audio Out (Optical) 1 (rear)

HDMI™/HDCP Input (V.1.3 w/Deep Color) 2 (rear) 1 (side)

RGB In (D-Sub 15pin) - PC 1 (rear)

PC Audio Input 1 (rear)

RS-232c In (Control/Service) 1 (rear)

USB 2.0 (JPEG, MP3) 1 (side)

Headphone Out 1 (side)

CAbINET/ACCESSORIES

Cabinet Color Glossy Black/Black Smog

Swivel Stand (Degrees) +20º/-20º

VESA® Compliant (WxH) • (400mm x 400mm)

Remote Control 1 (Unified)

POwER

Voltage, Hz 100V ~ 240V, 50/60Hz

On Mode (Average) TBD

Standby Mode <0.1W

DImENSIONS & wEIghT

TV Without Stand (WxHxD) 53.4” x 32.9” x 4.3”

TV With Stand (WxHxD) 53.4” x 35.5” x 16.7”

Shipping Dimensions (WxHxD) 57.3” x 40.2” x 21.3”

TV Without Stand Weight 72.5 lbs

TV With Stand Weight 80.2 lbs

Shipping Weight 97.4 lbs

wARRANTY/UPC

Limited Warranty 1 Year Parts & Labor

UPC 719192177178

REmOTE/INPUT/OUTPUTS (REAR/SIDE)

LGusa.com

LG Electronics U.S.A., Inc.

1000 Sylvan Avenue Englewood Cliffs, NJ 07632

Customer Service and Technical Support: (800) 243-0000

LCD TV

55LD520

Design, features and specifications are subject to change without notice. Non-

metric weights and measurements are approximate.
