Dazzling LED picture quality, limitless
entertainment access and apps straight from
the Internet to your TV with LG Smart TV. If
you’re looking for an outstanding TV that’s
going to take your entertainment to the
next level, you’ve found it with the LM6200
Series.
LED LCD CINEMA 3D SMART TV
LM6200 SERIES
65LM6200
55LM6200
47LM6200
42LM6200
32LM6200
WANT AN LED CINEMA 3D SMART TV WITH MORE? UPGRADE TO THE
LM6700 SERIES FEATURING LED+ & CINEMA SCREEN DESIGN >>
Want to experience the immersive 3D
experience of the movie theater at home?
With LG Cinema 3D technology you can.
Enjoy amazing 3D effects, comfortable,
lightweight glasses, 2D to 3D content
conversion, 3D depth control and a clear
picture from virtually any angle.
1
A revolutionary, easy way to access limitless
content, thousands of movies, customizable
apps, videos and browse the web all set up
in a simple to use interface. That’s what you
get with an LG Smart TV experience, the next
generation in entertainment organized within
a simple to navigate platform.
2
Works like magic. Selecting features on your
TV is as easy as the wave of your hand or
using the wheel option to scroll up and down
through menu selections. TV remote clicking
is soon to be a thing of the past.
CINEMA 3D
• Comfortable 3D Glasses
(6 Pairs Included)
• 3D Depth Control
• 2D to 3D Conversion
• Dual Play Gaming
• 3D Zone
SMART TV
• Magic Remote
• Home Dashboard
• Smart Share
- Intel® Wireless Display (WiDi)
- Network File Browser
- Wi-Fi Screen Share
PICTURE QUALITY
• Edge LED
• Full HD 1080p Resolution
• Triple XD Engine
• TruMotion 120Hz
• Resolution Upscaler
DESIGN
• Slim & Narrow
• Ribbon Stand
PANEL SPECIFICATIONS
Screen Size Class (diagonal) 65LM6200 65" Class (64.5" diagonal)
55LM6200 55" Class (54.6" diagonal)
47LM6200 47" Class (46.9" diagonal)
42LM6200 42" Class (42.0" diagonal)
32LM6200 32" Class (31.5" diagonal)
Resolution 1920 x 1080p
BLU Type Edge LED
Response Time TruMotion 120Hz
Dynamic Contrast Ratio
6,000,000:1
BROADCASTING SYSTEM
Analog •
Digital ATSC/NTSC/Clear QAM (1 Tuner)
VIDEO
Triple XD Engine •
Resolution Upscaler (Plus/Basic) • (Basic)
Picture Mode 7 Modes (Intelligent Sensor/Vivid/Standard/Cinema/
Game/ISF Expert 1/ISF Expert 2)
Picture Wizard II •
Aspect Ratio 6 Modes (16:9/Just Scan/Set by Program/4:3/
Cinema Zoom 1/Zoom)
Just Scan (1:1 Pixel Matching) HDMI 1080p/1080i/720p
0% OverScan Component 1080p/1080i/720p
RF 1080p/1080i/720p
AV Mode (Picture & Sound) 3 Modes (Cinema/Game/Off)
AUDIO
Mono/Stereo/Dual (MTS/SAP) •
Dolby Digital Decoder •
Speaker System 1 Way 2 Speakers
Audio Output (Watts - THD 10%) 10W + 10W
Virtual Surround •
Clear Voice II •
Sound Mode 7 Modes (Standard/Music/Cinema/Sport/
Game/Vivid/User Setting
Sound Optimizer 3 Modes (Low/Medium/High)
Mute (Normal/2 Level) • (Normal)
3D FEATURES
3D Type FPR (Passive)
3D Format Auto Correction •
3D to 2D •
2D to 3D •
3D Depth Control (3D & 2D to 3D)
20 Levels
3D Viewpoint Control (3D & 2D to 3D)
20 Levels
3D Image Correction •
3D Sound Zooming •
Dual Play Capable • (AG-F310DP glasses required and sold seperately)
SMART TV FEATURES
Home Dashboard 2.0 •
App Store •
Premium Content Providers •
Full Web Browser •
Social Center
•
Search & Recommendation
•
3D World (3D Content Streaming) •
Smart Phone Remote Support •
CONNECTIVITY
Wi-Fi Ready / Built-in • (Built-in)
WiFi Direct
•
Media Link •
DLNA (Movie/Photo/Music) •
Windows 7 Certified •
Intel® Wireless Display (WiDi) •
SIMPLINK (HDMI CEC) •
SPECIAL FEATURES
Intelligent Sensor •
Smart Energy Saving • (Backlight Control + Intelligent Sensor)
Input Labeling •
Quick View (Flashback) •
Closed Caption •
CONVENIENCE FEATURES
Languages 4 (English/Spanish/French/Korean)
Auto Tuning/Programming •
Channel Add/Delete •
Favorite Channel Programming •
Auto/Manual Clock •
On/Off Timer •
Sleep Timer •
Auto Off/Auto Sleep •
AV INPUTS/OUTPUTS
RF In (Antenna/Cable) 1 (Rear)
AV In 1 (Rear)
Component Video In 1 (Rear)
(Y, Pb, Pr) + Audio
Digital Audio Out (Optical) 1 (Rear)
HDMI™/HDCP Input 4 (Side)
RGB In (D-Sub 15 Pin) - PC 1 (Rear)
PC Audio Input 1 (Rear)
USB 2.0 3 (Side)
LAN 1 (Rear)
CABINET / ACCESSORIES
Swivel (Right/Left) 10º/10º (65LM6200 = 20º/20º)
VESA Compatible • 400mm x 400mm (32LM6200 = 200mm x 200mm)
Magic Remote • (3 mode)
3D Glasses 6 Pairs Included
POWER
ENERGY STAR® Qualified 65LM6200 -
55LM6200 •
47LM6200 •
42LM6200 •
32LM6200 •
Power Supply (Voltage, Hz) 100V ~ 240V, 50/60Hz
Power Consumption, On Mode 65LM6200 270W
55LM6200 150W
47LM6200 120W
42LM6200 100W
32LM6200 80W
Standby Mode Less than 0.3W
DIMENSIONS / WEIGHT
TV without Stand (WxHxD) 65LM6200 60.6" x 36.4" x 1.5"
55LM6200 49.7" x 29.7" x 1.4"
47LM6200 42.9" x 25.8" x 1.4"
42LM6200 38.5" x 23.3" x 1.3"
32LM6200 29.8" x 18.2" x 1.4"
TV with Stand (WxHxD) 65LM6200 60.6" x 39.1" x 13.9"
55LM6200 49.7" x 32.7" x 13.0"
47LM6200 42.9" x 28.4" x 10.4"
42LM6200 38.5" x 26.3" x 10.3"
32LM6200 29.8" x 18.2" x 8.8"
Shipping Dimensions (WxHxD) 65LM6200 73.2" x 41.7" x 9.8"
55LM6200 61.8" x 34.6" x 7.5"
47LM6200 52.0" x 31.9" x 5.3"
42LM6200 47.1" x 30.3" x 5.2"
32LM6200 39.2" x 24" x 5.5"
TV without Stand Weight 65LM6200 89.5 lbs
55LM6200 48.3 lbs
47LM6200 34.4 lbs
42LM6200 28.9 lbs
32LM6200 18.7 lbs
TV with Stand Weight 65LM6200 100.9 lbs
55LM6200 56.7 lbs
47LM6200 39.2 lbs
42LM6200 33.7 lbs
32LM6200 22.5 lbs
Shipping Weight 65LM6200 120.2 lbs
55LM6200 69.2 lbs
47LM6200 47.2 lbs
42LM6200 41.2 lbs
32LM6200 28.9 lbs
WARRANTY / UPC
Limited Warranty 1 Year Parts & Labor
UPC 65LM6200 719192583726
55LM6200 719192583740
47LM6200 719192583757
42LM6200 719192583764
32LM6200 719192585175
LG Electronics U.S.A., Inc.
1000 Sylvan Avenue Englewood Cliffs, NJ 07632
Customer Service and Technical Support: (800) 243-0000
LG.com
LED LCD CINEMA 3D SMART TV
LM6200 SERIES
1 For a small percentage of the population, the viewing of stereoscopic 3D video technology may cause
discomfort such as headaches, dizziness or nausea. If you experience any symptoms, discontinue using
the 3D functionality and contact your health care provider. 6 pairs of 3D glasses included. Additional 3D
glasses sold separately.
2 Wireless Internet connection & certain subscriptions required and sold separately. Content and services
vary by product and are subject to change without notice.
Screen images simulated. Design, features and specifications are subject to
change without notice. Non-metric weights and measurements are approximate.
© 2012 LG Electronics USA, Inc. All rights reserved. “LG Life’s Good” is a
registered trademark of LG Corp. All other product and brand names are
trademarks or registered trademarks of their respective companies. 04/09/12
