Get Full HD 1080p picture quality
and TruMotion 120Hz with the
LS4600 LED TV.
LED LCD TV
LS4600 SERIES
55LS4600
47LS4600
You won’t believe your eyes. Tired of dark
scenes or dull colors? LG’s LED technology
provides a slim profile and delivers amazing
brightness, clarity and color detail, as well
as greater energy efficiency compared to
conventional LCD TVs.
Double the detail. This stunning picture is the
reason you wanted HDTV in the first place.
With almost double the pixel resolution, Full
HD 1080p gives it superior picture quality
over standard HDTV. You’ll see details and
colors like never before.
Less blur. More action. TruMotion 120Hz
technology lets you see sports, video games
and high-speed action with virtually no
motion blur. Now your TV can keep up with
your fast- moving entertainment.
KEY FEATURES
• Edge LED
• Full HD 1080p Resolution
• Triple XD Engine
• TruMotion 120Hz
• Smart Energy Saving
• Intelligent Sensor
• Clear Voice II
• Picture Wizard II
DESIGN
• Slim & Narrow
WANT AN LCD LED TV WITH MORE? UPGRADE TO THE LS5700
SERIES FEATURING LG SMART TV TECHNOLOGY >>
PANEL SPECIFICATIONS
Screen Size Class (diagonal) 55LS4600 55" Class (54.6" diagonal)
47LS4600 47" Class (46.9" diagonal)
Resolution 1920 x 1080p
BLU Type Edge LED
Response Time TruMotion 120Hz
Dynamic Contrast Ratio
4,000,000:1
BROADCASTING SYSTEM
Analog •
Digital ATSC/NTSC/Clear QAM (1 Tuner)
VIDEO
Triple XD Engine •
Picture Mode 8 Modes (Intelligent Sensor/Vivid/Standard/Cinema/
Game/Sports/ISF Expert 1/ISF Expert 2)
Picture Wizard II •
Aspect Ratio 6 Modes (16:9/Just Scan/Set by Program/4:3/
Cinema Zoom/Zoom)
Just Scan (1:1 Pixel Matching) HDMI 1080p/1080i/720p
0% OverScan Component 1080p/1080i/720p
RF 1080p/1080i/720p
AV Mode (Picture & Sound) 4 Modes (Cinema/Game/Sport/Off)
AUDIO
Mono/Stereo/Dual (MTS/SAP) •
Dolby Digital Decoder •
Speaker System 1 Way 2 Speakers
Audio Output (Watts - THD 10%) 10W + 10W
Virtual Surround •
Clear Voice II •
Sound Mode 5 Modes (Standard/Music/Cinema/Sport/Game)
Mute (Normal/2 Level) • (Normal)
CONNECTIVITY
DLNA (Movie/Photo/Music) •
SIMPLINK (HDMI CEC) •
SPECIAL FEATURES
Intelligent Sensor •
Smart Energy Saving • (Backlight Control + Intelligent Sensor)
Input Labeling •
Quick View (Flashback) •
Closed Caption •
CONVENIENCE FEATURES
Languages 4 (English/Spanish/French/Korean)
Auto Tuning/Programming •
Channel Add/Delete •
Favorite Channel Programming •
Auto/Manual Clock •
On/Off Timer •
Sleep Timer •
Auto Off/Auto Sleep •
RF In (Antenna/Cable) 1 (Rear)
AV In 1 (Rear)
AV INPUTS/OUTPUTS
Component Video In 2 (Rear)
(Y, Pb, Pr) + Audio
Digital Audio Out (Optical) 1 (Rear)
HDMI™/HDCP Input 3 (2 Rear/1 Side)
RGB In (D-Sub 15 Pin) - PC 1 (Rear)
PC Audio Input 1 (Rear)
USB 2.0 1 (Side)
LAN 1 (Rear)
CABINET / ACCESSORIES
Swivel (Right/Left) 20º/20º
VESA Compatible • 400mm x 400mm
Remote Control Standard
POWER
ENERGY STAR® Qualified •
Power Supply (Voltage, Hz) 100V ~ 240V, 50/60Hz
Power Consumption 55L S4 600 69.1W
47LS4600 58W
Standby Mode 0.15W
DIMENSIONS / WEIGHT
TV without Stand (WxHxD) 55LS4600 49.7" x 29.7" x 1.4"
47LS4600 42.9" x 25.8" x 1.4"
TV with Stand (WxHxD) 55LS4600 49.7" x 32.4" x 12.4"
47LS4600 42.9" x 28.4" x 10.6"
Shipping Dimensions (WxHxD) 55LS4600 61.8" x 34.7" x 7.5"
47LS4600 52.0" x 31.9" x 5.3"
TV without Stand Weight 55LS4600 48.3 lbs
47LS4600 37.9 lbs
TV with Stand Weight 55LS4600 56.2 lbs
47LS4600 43.4 lbs
Shipping Weight 55LS4600 68.8 lbs
47LS4600 54.2 lbs
WARRANTY / UPC
Limited Warranty 1 Year Parts & Labor
UPC 55LS4600 719192585270
47LS4600 719192585249
LG Electronics U.S.A., Inc.
1000 Sylvan Avenue Englewood Cliffs, NJ 07632
Customer Service and Technical Support: (800) 243-0000
LG.com
LED LCD TV
LS4600 SERIES
Design, features and specifications are subject to change without notice. Non-
metric weights and measurements are approximate.
