User Guide

This is a 「User Guide」 installed on the TV.

The contents of this guide are subject to change without prior notice for quality

improvement.

GP4

enga



Displays information about the current program and/or current time, etc.

1 Move the pointer of the Magic remote control to the top of the TV screen.

2 Click the activated channel banner area.

3 The program details will be displayed at the bottom of the TV screen.

✎ Image shown may differ from your TV.

Program name Detailed program information

(for digital broadcast)

Current time

DOWN

Prev./Next Ch. Change Watch

 



GP4

enga

 

    

1 MovetothedesiredchannelonWheel(OK)button.Channelisselected.

2 PressSetasFavorite.

3 Selectthedesiredfavoritechannelgroup.

4 SelectEnter.Favoriteisset.

 

 

Channellistwillappear.Selectthedesiredpresetfavoritechannelfrom

FavoriteListAtoD.

GP4

enga

 

 

Automatically tunes the channels.

✎ Channels are not registered properly unless the antenna/cable is connected

correctly.

✎ Auto Tuning only sets channels that are currently broadcasting.

✎ If Lock System is turned on, a pop-up window will appear asking for

password.

GP4

enga

 

 

Adjusts channels manually and saves the results.

For digital broadcasting, signal strength, etc. can be checked.

GP4

enga

 

 

Edits the saved channels.

Set as favorite, block/unblock and Add/Delete etc. the selected channel.

GP4

enga

SMART ➾ Settings ➙ PICTURE ➙ Aspect Ratio

Selects the screen aspect ratio.

16:9 Resizes the image ratio to fit a 16:9 screen.

Just Scan

Displays high-quality image without loss.

✎ In DTV/HDMI/Component (over 720p) mode, Just Scan is

available.

Set by

Program

Depending on the input signal, screen aspect ratio changes to 4:3

or 16:9.

4:3 Resizes the image ratio to fit 4:3 screen.

Zoom Resizes the image to fit the screen width. The top and bottom

parts of the image may be cut off.

Cinema

Zoom

Formats an image to the cinemascope ratio (2.35:1) and zooms in

on the ratio.

GP4

enga

✎ While viewing an external device, these cases may result in image burn:

- a video with stationary caption (such as network name)

- 4 : 3 aspect ratio mode for an extended period

Take caution when using these functions.

✎ Available picture size may differ depending on the input signal.

✎ The screen aspect ratios on HDMI-PC input are available in 4:3 and 16:9 only.

✎ [For models supporting 2160p] When a 2160p signal is input or your PC

resolution is set to 3840 x 2160, the Aspect Ratio is set to Just Scan.

GP4

enga

SMART ➾ Settings ➙ PICTURE ➙ Energy Saving

Reduces power consumption by adjusting screen brightness.

Auto

[Depending on model]

TV sensor detects the ambient lighting and automatically

adjusts the screen brightness.

Off Turns off the Energy Saving mode.

Minimum/

Medium/

Maximum

Applies the pre-set Energy Saving mode.

Screen Off

Screen is turned off and only sound is played.

Press any button except Power button on the remote

control to turn the screen back on.

GP4

enga

SMART ➾ Quick Menu ➙ AV Mode

Views the TV with the best picture / audio optimized for different AV modes.

Off Views with the value set at the picture / sound menu.

Cinema Optimizes picture and audio settings for movies.

Game Optimizes picture and audio settings for games.

GP4

eng

 

  

Use the remote control and follow the instructions of the Picture Wizard to

calibrate and adjust for optimum picture quality without expensive pattern

devices or help from a specialist.

Follow the instructions to obtain the optimum picture quality.

GP4

eng

 

  

Selects the picture mode optimized for the viewing environment or the program.

Vivid Heightens contrast, brightness and sharpness to

display vivid images.

Standard Displays images in standard levels of contrast,

brightness and sharpness.

Eco The Energy Saver feature changes settings on the TV

to reduce power consumption.

Cinema / Game Displays the optimum picture for movie, game.

GP4

eng ꕋ Expert

Menu for adjusting picture quality that allows experts

and amateurs to enjoy the best TV viewing. This menu

is ISF-certified and provided for picture tuning experts.

(ISF logo can only be used on ISF-certified TV units.)

ISFccc : Imaging Science Foundation Certified

Calibration Control

✎ Depending on the input signal, the available range of picture modes may

differ.

✎ ꕋ Expert mode is for picture tuning professionals to control and fine-tune

using a specific image. For normal images, the effects may not be dramatic.

GP4

eng

 

  



First select a Picture Mode of your choice.

Backlight Adjusts the display brightness by varying the brightness of

the LCD panel.

Contrast Adjusts the difference between bright and dark regions of the

screen.

Brightness Adjusts the overall screen brightness.

Sharpness Adjusts the sharpness of the borders between bright and

dark.

GP4

eng

Color Adjusts the colors on the screen darker or lighter.

Tint Adjusts the red/green color balance.

Color Temp. Adjusts the overall tone of colors to warm or cool.

✎ Depending on the input signal or other picture settings, the range of detailed

items for adjustment may differ.

GP4

eng

 

 



Calibrates the screen for each picture mode or adjusts picture settings for a

special screen.

First select a Picture Mode of your choice.

Dynamic Contrast Adjusts the contrast to the optimal level according to the

brightness of the image.

Dynamic Color Adjusts colors for more natural-looking colors.

GP4

eng Preferred Color

Skin Color : Skin color spectrum can be separately set to

implement the skin color as defined by the user.

Grass Color : Natural color spectrum (meadows, hills, etc.)

can be separately set.

Sky Color : Sky color is set separately.

Super Resolution Provides a crystal-clear picture by improving the details in

areas where the picture is blurry or unclear.

Gamma Sets the gradation curve according to the output of the

picture signal in relation to the input signal.

Colour Gamut Selects the range of colors that can be expressed.

Edge Enhancer Shows clearer and distinctive yet natural edges of the

video.

xvYCC [Depending on model] Expresses richer colors.

GP4

eng

Color Filter Filters a specific color spectrum in RGB colours to fine-tune

colour saturation and hue accurately.

Expert Pattern Patterns used for expert adjustment.

White Balance

Adjusts the overall tone of the screen as desired.

In Expert mode, detailed fine-tuning can be set via the

Method / Pattern etc.

Color

Management

System

This is a function used by experts when they adjust colors

using a test pattern of six colours (Red / Green / Blue /

Cyan / Magenta / Yellow) without affecting other color

areas. For normal images, adjustments may not result in

noticeable color changes.

✎ Depending on input signal or other picture settings, the range of detailed

items for adjustment may differ.

GP4

eng

 

 

Adjusts detailed setting for images.

Noise Reduction Reduces screen noise in the video.

MPEG Noise

Reduction Reduces noise caused by compressing digital video.

Black Level

Adjusts the brightness or darkness of the screen to suit the

black level of the picture input using the degree of darkness

(black level) of the screen.

Real Cinema Optimizes the screen for movie viewing.

GP4

eng

Eye Care [Depending on model]

Adjusts screen brightness to prevent eye glare.

Motion Eye Care

[Depending on model]

Saves power consumption by adjusting the brightness

corresponding to the movement of the image on the

screen.

✎ It does not work while watching 3D images.

✎ Depending on input signal or other picture settings, the range of detailed

items for adjustment may differ.

GP4

eng

 

  

Resets values customized by the user.

Each picture mode is reset. Select the picture mode you wish to reset.

GP4

enga

 

  

Optimizes TV audio to the selected sound mode.

Standard Suitable for all types of video.

Music/Cinema/

Sport/Game

[Depending on model]

Sets audio optimized for a specific genre.

User Setting Adjusts the volume to the desired level using the User

EQ.

GP4

enga

 

  

Sets Sound Mode at User Setting first.

100 Hz / 300 Hz / 1 kHz/

3 kHz / 10 kHz Sets EQ by manually adjusting sound bands.

Reset Resets previously changed equalizer value.

GP4

eng

 

 

Provides optimized sound adjusted for each content type.

✎ If the Smart Sound Mode function is enabled, Sound Mode, Virtual Surround

Plus, and Clear Voice II are automatically adjusted.

GP4

eng

 

 

LG’s proprietary audio processing technology allows 5.1 channel-like surround

sound from two speakers.

✎ If Clear Voice ll is set to ON, Virtual Surround plus will not be chosen.

 

 

Boosts voice clarity.

GP4

eng

 

 

Sets various modes for volume control.

Auto Volume

Sets Auto Volume to On. The volume varies from channel to

channel and program to program. When clicking through the

channels, the volume is adjusted automatically to maintain

the same level.

Volume Control

Using a single volume curve may result in an inaudible or

loud sound depending on the environment. Adjusts volume

levels depending on the time of day (day/night).

GP4

eng

 

 

Synchronizes video and audio directly when they do not match.

If you set AV Sync. Adjust to ON, you can adjust the sound output (TV speakers

or SPDIF) to match the video.

TV Speaker

[Depending on model]

Adjusts the synchronization of the sound from the TV's internal

speakers.

The + and - buttons allow the viewer to synchronize the audio

with the video.

GP4

eng External

Speaker

Adjusts how the sound is synced to external speakers, such as

an external speaker connected to the digital audio output port,

LG audio device and headphone.

The + and - buttons allow the viewer to synchronize the audio

with the video.

✎ LG audio device is supported only for models with the

optical digital port.

Bypass

Outputs broadcasting signals or the audio of an external

device without audio delay. Audio may be output before video

as it takes time to process video input into the TV.

GP4

eng

 

[Depending on model]

 

 

[Depending upon model]

Allows the user to select the Headphone or External Speaker (Audio Out) menu

depending on the device connected.

 

[Depending on model]

Adjusts left/right audio balance.

GP4

eng

 

[Depending on model]

Allows optimized sound for custom TV installation.

Normal General sound mode.

Wall Mount Type Optimizes sound for a wall-mounted TV.

Stand Type Optimizes sound for a stand-mounted TV.

GP4

eng

❐To use the TV’s speakers

[Depending on model]

SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ TV Speaker

Sound is output through the TV speaker.

❐To use External Speakers

SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ External Speaker

(Optical/HDMI ARC)

[Available only for models with an optical or HDMI (ARC) port]

Sound is output through the speaker connected to the optical port.

✎SimpLink is supported.

GP4

eng

❐To use Digital Sound Out

SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ External

Speaker(Optical/HDMI ARC) ➙ Digital Sound Out

Sets up Digital Sound Output.

Item Sound Input Digital Sound output

Auto

MPEG PCM

Dolby Digital Dolby Digital

Dolby Digital Plus Dolby Digital

PCM All PCM

GP4

eng

❐To connect and use an LG audio device

LG audio device allows you to enjoy rich powerful sound.

❌Wired Connection

SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ LG Sound Sync

(Optical)

Connect an LG audio device with the logo to the optical digital audio output port.

✎Available only on models with an optical digital port.

❌Wireless Connection

SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ LG Sound Sync

(Wireless)

An LG audio device with the logo can be connected wirelessly.

GP4

eng

✎You can use the TV remote control to adjust the volume of the connected

device.

✎When connecting wirelessly, attach the dongle and connect it if the model

needs the Magic Remote Control dongle. (AN-MR400, sold separately)

✎For a wireless connection, if the device fails to connect, check the device

power and make sure the LG Audio device is set up properly.

GP4

eng

✎When you select LG Sound Sync (Wireless), devices available for connection

are searched and one of searched devices is automatically connected. When

a device is connected, its name is shown.

✎If two or more devices are detected, the first detected device is connected

first. To view more detected devices to connect, press the Show More button.

✎When LG Sound Sync (Wireless) is active and you turn on the TV, it will

search and try to connect the device which recently connected.

GP4

eng

❐To connect and use a Bluetooth headset

SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ LG Sound Sync

(Wireless)

Sound output is through the Bluetooth headset.

✎The devices that can be connected are:

LG BTS1, LG HBS-700, LG HBS-730, LG HBS-800

(Product availability may vary by country.)

GP4

eng

✎When connecting wirelessly, attach the dongle and connect it if the model

needs the Magic Remote Control dongle. (AN-MR400, sold separately)

✎For wireless connection, if the device fails to connect. Check the device

power to connect and if the LG Audio device is in a proper operating

condition.

✎If two or more devices are detected, the first detected device is connected

first. To view more detected devices to connect, press the Show More button.

GP4

eng

❐To use Analog Out/Headphone

[Depending on model]

SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ External Speaker

(Audio Out) / Headphone

Select Headphone or External Speaker (Audio Out) depending on the device

connected to the analog out port.

✎The available menu may vary depending on whether you select Headphone

or External Speaker (Audio Out) in the Sound Option Setting > Analog Out.

✎Some models may support only the Headphone function.

✎If you connect headphones while the TV is powered on, it automatically

detects the headphones and direct sound through them.

GP4

enga

TV Speaker

Set the Universal Control Channel Mode

Change Device Name SIMPLINK Setting

 

  

Selects external input.

Allows you to edit the

device label.

Sets SIMPLINK.





Selects speaker.

Selects input.

Sets the Channel Mode.

[Depending on country]

Sets OSS.

[Depending on country]

Antenna HDMI1 HDMI2 USB DLNA AV2

GP4

enga

 

SIMPLINK allows users to control and manage multiple multimedia devices using

the TV remote control and SIMPLINK menu.

1 Connect the TV's HDMI IN terminal with the SIMPLINK device's HDMI output

terminal using an HDMI cable. For home theater units with SIMPLINK support,

connect the HDMI ports and then use an optical cable to connect the Optical

Digital Audio Out from the TV to the Optical Digital Audio In of the SIMPLINK

device.

2 Select  ➾ SIMPLINK. The SIMPLINK menu window appears.

3 Select SIMPLINK Setting in the SIMPLINK menu window. The SIMPLINK setup

window appears.

4 Set SIMPLINK to On in the SIMPLINK setup window.

5 Close the SIMPLINK setup window.

6 Select the device to control from  ➾ SIMPLINK.

GP4

enga

✎ This function works only on devices with the SIMPLINK logo ( ).

Make sure that the external device has a SIMPLINK logo.

✎ To use the SIMPLINK function, use a high-speed HDMIⓇ cable (with CEC, or

Consumer Electronics Control feature added) and No. 13 pin connected for

information exchange between devices.

✎ Turn on or select the media of a device with home theater features to see the

speaker switch to External Speaker.

✎ Connect with an Optical cable (sold separately) to use an External Speaker.

✎ Switching to external input causes devices operating with SIMPLINK to stop.

✎ Use of a third-party device with HDMI-CEC features may cause malfunctions.

✎ An optical cable connection is supported only for models with the optical

digital port.

GP4

enga

 

Direct Play Play the multimedia device on the TV instantly without

extra steps.

Select

multimedia

device.

Select the desired device through the SIMPLINK menu and

instantly control it from the TV screen.

Disc playback Manage the multimedia device with the TV remote

control.

Power off all

devices

Turning the TV off with Auto Power function On in

SIMPLINK setting will turn the power off on all SIMPLINK-

connected devices.

GP4

enga

Sync Power on If the Auto Power function is set to On in the SIMPLINK

settings, turning on a SIMPLINK device will turn the TV on.

Speaker Selects speaker on the home theater unit or TV.

GP4

enga

 

 

Turns off the TV after a prescribed number of minutes.

To cancel the Sleep Timer, select Off.

GP4

enga

 

  

Checks or changes the time while watching TV.

Auto Synchronizes the TV clock to the digital time information sent by

the TV station.

Manual Sets the time and date manually if the auto setup does not

correspond to the current time.

GP4

enga

 

  

Sets On/Off time.

Select Off on Repeat to discontinue On Time/Off Time.

✎ To use On Time/Off Time, set the current time correctly.

✎ Even when the On Time function is on, the TV will turn off automatically in

120 minutes when no button is pressed within that time.

GP4

enga

 

 

Sets or changes TV password.

✎ The initial password is set as 「0000」.

GP4

enga

 

 

Permits only specific programs by blocking channels or external input.

Select the Lock System to On.

Block Channel

Blocks the channels that contain inappropriate contents for

children. The channels can be selected but the screen is blank

and the audio is muted.

To watch a locked channel, enter the password.

GP4

enga

Movie Rating

[Depending on model]

Blocks the movies that are only broadcasted on the TV and

contain inappropriate contents, based on the Motion Picture

Association of America (MPAA) rating.

• G : (General audiences) All ages admitted

• PG : (Parental guidance suggested) Some material may not

be suitable for children

• PG-13 : (Patents strongly cautioned) Some material may be

inappropriate for children under 13

• R : (Restricted) Under 17 requires accompanying parent or

adult guardian

• NC-17 : No one 17 and under admitted.

• X : Adults only

GP4

enga

TV Rating-

Children

[Depending on model]

Blocks the children’s TV programs that parents do not want

their children to watch. To block other TV programs, you

should set the TV Rating-General feature.

• Age : TV-Y (All children, including children from ages 2-6),

TV-Y7 (Directed to older children, suitable for children age

6 and above)

• Fantasy Violence : TY-Y7 (Directed to older children –

Fantasy violence, suitable for children age 6 and above,

containing more intense or combative fantasy violence)

GP4

enga

TV Rating-

General

Blocks the TV programs that you want based on the ratings

by using the Parental Control Function (V-Chip).

✎ The V-Chip electronically reads TV program ratings and

allows parents to block program that are unsuitable for

children.

• Age : TV-G (General audience, suitable for all ages)

TV-PG (Parental guidance suggested, containing material that

are unsuitable for younger children)

TV-14 (Parents strongly cautioned, containing material that

are unsuitable for children age 14 and under)

TV-MA (Mature audience only, unsuitable for children age

under 17)

• Dialog : (suggestive dialogue) TV-PG or TV-14

• Language : (coarse language)TV-PG, TV-14, or TV-MA

• Sex : (sexual situation) TV-PG, TV-14, or TV-MA

• Violence : TV-PG, TV-14, or TV-MA

GP4

enga

Downloadable

Rating

[In Digital mode Only]

This function operates only when TV has received Region5

Rating data. The name of the rating option may differ.

Input Block Block the input sources.

Application

Lock Lock the Application.

GP4

enga

 

 

Sets or changes TV password.

✎ The initial password is set as 「0000」.

GP4

enga

 

 

Permits only specific programs by blocking channels or external input.

Select the Lock System to On.

Block Channel

Blocks the channels that contain inappropriate contents for

children. The channels can be selected but the screen is blank

and the audio is muted.

To watch a locked channel, enter the password.

GP4

enga

TV Rating-

English

[Depending on model]

Selecting Canadian English rating system.

• E : Exempt

• C : Children

• C8+ : Children eight years and older

• G : General programming, suitable for all audiences

• PG : Parental Guidance

• 14+ : Viewers 14 years and older

• 18+ : Adult programming

• Blocking Off : Permits all programs

GP4

enga

TV Rating-

French

[Depending on model]

Selecting Canadian French rating system.

• E : Exempt

• G : General

• 8ans+ : General-Not convenient for little children

• 13ans+ : Not convenient for children of 13 years and

younger

• 16ans+ : Not convenient for children of 16 years and

younger

• 18ans+ : This programs is only for adults

• Blocking Off : Permits all programs

GP4

enga

Downloadable

Rating

[In Digital mode Only]

This function operates only when TV has received Region5

Rating data. The name of the rating option may differ.

Input Block Block the input sources.

Application

Lock Lock the Application.

GP4

enga

SMART ➾ Settings ➙ OPTION ➙ Language

Selects Menu Language and Audio Language displayed on the screen.

Language Selects a screen menu language.

Audio

Language

[In Digital Mode Only]

Selects the desired language when watching digital

broadcasting containing several audio languages.

Voice

Recognition

Language

Select the language to make voice search.

✎ Only the voice search adopted model can support this

setting.

GP4

enga

SMART ➾ Settings ➙ OPTION ➙ Caption

View subtitles when the TV station provides subtitled programing. Program

subtitles work only on digital/analog broadcasts or external input.

Change Caption to On and select caption setting.

Mode

CC 1-4 (Closed Captioning) / Text 1-4 Text 1-4

Displays the audio portion of a TV program as text on the TV screen.

CC1 is the most common mode in use.

Field 1 data channels: two Captions (CC1, CC2), two Text (T1, T2).

Field 2 data channels: two Captions (CC3, CC4), two Text (T3, T4).

Service 1-6

This is only available for the digital broadcasting system.

GP4

enga

Digital

Option

Set up the size and color of the subtitles on Digital Option. Please

select Set by Program or Custom.

Select Custom to adjust minute options such as the subtitles’ size

and color.

GP4

enga

 

To use the Magic Remote Control, register it with your TV first.

1 Turn on the TV and wait for about 10 seconds and then press Wheel(OK)

button while pointing the remote control at the TV.

2 The remote control is automatically registered and a registration completion

message appears on the TV screen.

✎ If you failed to register the Magic Remote Control, turn off the TV and try

again.

GP4

enga

 

1 Press the  and BACK buttons at the same time for about 5

seconds.

2 Press the Wheel (OK) button towards the TV to re-register the Magic Remote

Control.

✎ Press the  button and BACK button at the same time, for five

seconds, to reset the Magic Remote Control.

✎ Press the BACK button while pointing the remote control at the TV for five

seconds to reset and re-register it.

GP4

enga

 

 

Sets the speed and shape of the pointer that appears on the TV screen.

Speed Sets the moving speed of the pointer.

Shape Chooses from different shapes of the pointer.

Size Chooses the size of the pointer.

Alignment

Set it to On. If there is any misalignment between the pointer

and the actual direction the remote control indicates, move the

Magic Remote Control left and right to realign. The pointer will

automatically realign to the center, making it easier to control.

✎ If it is set to Off, the Alignment function will not work even

when you move the Magic Remote Control left and right.

GP4

enga

✎ If the pointer has not been used for a certain period of time, it will disappear.

When the pointer disappears from the screen, shake the Magic Remote

Control to the right and left. Then, it appears again.

✎ If you press the navigation button while moving the pointer on the screen, the

pointer disappears, and the Magic remote control works as a regular remote

control.

✎ Use within an effective distance of 33 ft. (10 meters). Using the Remote

Control from greater distances or when obstructions block the sight line may

cause malfunctions.

GP4

enga

✎ Electronic devices nearby may cause communication interference. Devices

such as microwave oven and wireless LAN use the same frequency range

(2.4 GHz) as the Magic Remote Control, which may interfere with the remote

control.

✎ The Magic Remote Control may be broken if dropped or damaged in any other

way.

✎ Do not drop or subject the Magic Remote Control to heavy impacts.

GP4

enga

 

Press the Wheel(OK) button with the normal video screen on and draw a pattern

toward the screen.

Previous channel: Moves back to the previous channel.

Recent list: Shows channels recently watched.



Shows channel lists which be related to pattern. Choose the

channel.

✎ It may not work when certain windows are open.

GP4

eng

 

 



Turns the standby light in the front panel of the TV on/off.

GP4

eng

 

 



You can adjust the LED brightness of the LG logo at the bottom of the TV.

Brightness You can set the brightness of LG Logo Light to Off/Low/

Medium/High when the TV power is off.

GP4

eng

When TV is on

You can set the off time of LG Logo Light when the TV

power is on.

• Off right now : The light is turned off as the TV power is

on.

• Off after 10 min. : The light is turned off after 10 minutes

when the TV power is on.

✎ The initial brightness is set to Low when the TV power is

on.

GP4

eng

 

 

Selects Home Use or Store Demo.

For use at home, select Home Use.

Store Demo is a mode used for store display.

GP4

eng

 

 

Deletes all optional settings and returns to initial default mode.

Once initialization is complete, the TV will turn off and on by itself.

✎ If Lock System is activated, a pop-up password prompt will appear.

✎ Do not turn off the power during initialization.

GP4

kor

 

 

This function sets your area as the ZIP Code.

✎ You can check the information of area when network is connected.

GP4

enga

 

 

Thanks to the Smart TV’s design, users have convenient access to a wealth of

Content and applications via the easy-to-use menu arranged by themes (Live

TV, Card, My Apps).

MY CARD

Select desired card.

My Apps

Card Edit

Input List Settings Internet Search Photos Smart Sh... LG Smart... Game Wo... User Guide Ch.List

Tron Toy story

Monster Ghost Abata

UP Thanks My Boy

SMART

SHARETM

More...

Cinema Weather

News Sports Viral Video

Photo Map Game

Premium

More...

11-1 MBC HD

July 4 8:30 pm

GP4

enga

 

 

To enable you to easily check and access a wide variety of content and

functions, the main functions are grouped into categories and displayed on

cards.

By selecting the card name, you can go to that category page.

Select Edit at the top of the home screen to switch the position of the cards or

create your own card. (You cannot edit the Live and Premium cards.)

GP4

enga

 

 

Select More at the bottom of the home screen.

Select More to check apps pre-installed apps and apps you have

downloaded.

Select the desired app to run.

Input List Settings Internet Search Photos Smart Sh... LG Smart... Game Wo... User Guide Ch.List

GP4

enga

 

 

On the My Apps page, select Edit at the top of the screen to move or delete

apps. Please note that system apps can be moved, but cannot be deleted.

✎ On models equipped with the Magic Remote Control, you can move apps or

delete them by selecting and then dragging them.



GP4

enga

A wireless or wired network connection is necessary to use the Smart TV

features.

Once the network connection is established, Premium Content, LG Smart World,

DLNA, and more are available.

 

It’s easy to connect to a wired/wireless network.

Select SMART ➾ Settings ➙ NETWORK ➙ Network Connection to be

automatically connected to an available network. Refer to prompts on the TV.

GP4

enga

 

 

Used in special circumstances such as in offices (For example, when a static IP

is needed).

1 Select a network connection either through Wired or Wireless.

2 When connecting via Wi-Fi, use the one of the following network connection

methods.

AP List Connects the network by selecting a network from the AP

(Access Point) List.

Enter the SSID Connects by typing in the name of wireless AP.

GP4

enga

WPS-PBC Connects easily by pressing the button of a wireless

access point supporting PBC.

WPS-PIN Connects easily by typing in the PIN from the admin page

of the desired wireless AP.

GP4

enga

 

 

Wi-Fi Direct is a function that allows your TV to connect with a Wi-Fi Direct

device without going through a router or gateway. With SmartShareTM, you

can watch the files stored on a device connected via Wi-Fi Direct.

1 Set Wi-Fi direct to On. (If you do not use it, please change it to Off.)

2 Enable the Wi-Fi Direct settings on the device that you want to connect to.

3 A list of devices that can be connected to the TV is displayed.

4 Select a device to connect.

5 Select Yes, when the connection request message appears.

6 If the device that you want to connect to accepts the request, Wi-Fi direct is

connected.

GP4

enga

 

 

You can view the screen of a device with Miracast™ and Intel’s WiDi

technologies on your TV.

1 Set Miracast™/Intel’s WiDi to On. (If you do plan on useing wither of these

features, please change it to Off.)

2 Enable the Miracast™ or Intel’s WiDi settings on the device that you want to

connect to.

3 A list of devices that can be connected to the TV is displayed.

4 Select a device to connect.

5 Select Yes, when the connection request message appears.

6 If the device that you want to connect accepts the request, Miracast™/

Intel’s WiDi is connected.

GP4

enga

✎ Some models may only support Intel’s WiDi.

✎ When Wi-Fi Direct is set to Off, if you set Miracast™/Intel’s WiDi to On,

Wi-Fi Direct is automatically set to On.

✎ When you set the Miracast™/Intel’s WiDi function to Off, Wi-Fi Direct

returns to the previous setting.

✎ It is recommended to connect a laptop using Intel’s WiDi within close range.

✎ Though Intel’s WiDi can be connected without a wireless router, it is

recommended to connect the wireless router first for optimal performance.

✎ You may not connect your TV to a non-LG Electronics device even when it is

detected.

✎ It is recommended you to connect a device to a 5GHz router.

✎ The response rate may vary depending on the user’s environment.

✎ For more information on the device you want to connect to, refer to its

owner’s manual.

GP4

enga

 

✎ Use standard LAN cable (connect to Cat5 or higher with RJ45 connector, 10

Base-T, or 100 Base TX LAN port).

✎ Resetting the modem may fix some network connection problems. Turn the

power OFF, disconnect and reconnect it, and then turn the power on to solve

the problem.

✎ LG Electronics is not responsible for any network connection problems or any

faults, malfunctions, or errors caused by network connection.

✎ The network connection may not work properly because of network settings

or the Internet service provider.

GP4

enga

✎ DSL service must use a DSL modem; and cable service must use a cable

modem. Since only a limited number of network connections may be

available, TV network setting may not be used depending on the contract

with Internet service provider. (If the contract does not allow more than one

device per line, only the already-connected PC may be used.)

✎ A wireless network can experience interference from other devices that

use the 2.4 GHz frequency (wireless phone, Bluetooth device, or microwave

oven). Although interference can also happen when using the 5 GHz

frequency, it is less likely to occur.

✎ The wireless environment can make wireless network service run slowly.

✎ Failure to turn off all local home networks may cause excessive traffic on

some devices.

GP4

enga

✎ The access point device must support wireless connections and wireless

connection feature must be enabled on the device to have AP (access

point) connection. Contact the service provider for availability of wireless

connections on the access point.

✎ Check SSID and security settings of the AP. Refer to the appropriate

documentation for SSID and security settings of the AP.

✎ Invalid settings of network devices (wired/wireless line sharer, hub) can

cause the TV to operate slowly or not operate properly. Install the devices

correctly according to the appropriate manual and network.

✎ The connection method may differ depending on the AP manufacturer.

GP4

enga

 

Connect a USB storage device (external hard drive or USB memory) to the USB

port of TV to enjoy multimedia files stored on the USB device.

To remove a USB storage device, choose the Quick Menu ➙ USB Device to

disconnect the device. Wait for the message that the USB has been removed

before taking it out physically. If detached early, an error may occur on the TV

or USB storage device.

✎ After selecting to remove USB device, it is impossible to read the USB storage

device. Remove USB storage device and reconnect it.

GP4

enga

 

✎ If a USB storage device has a built-in auto recognition program or uses its

own driver, it may not work.

✎ Some USB storage devices may not work or work improperly.

✎ If you use a USB extension cable, the USB device may not be recognized or

may not work properly.

✎ Only use USB storage devices formatted with FAT32 or NTFS File System

provided by Windows.

✎ For external USB hard drives, it is recommended to only use devices rated

at 5V and less than 500mA current.

✎ It is recommended to use a USB hub or hard disk drive with power supplied.

(If the power supplied is not enough, the USB storage device may not be

detected properly.)

GP4

enga

✎ It is recommended to use USB Memory Sticks with 32 GB or less and USB

hard drives with 2 TB or less.

✎ For USB hard drives with energy-saving features, turn off and turn on again

if it does not work properly. For more information, refer to the user manual of

USB HDD.

✎ Data on a USB storage device can be damaged so be sure to back up

important files in a separate storage device. Data maintenance is the user’s

responsibility and the manufacturer is not responsible for any data loss.

GP4

enga

❐To use SmartShare™

SMART ➾ SmartShare™

Provides photo/music/video files on the TV by connecting a USB device or home

network (DLNA).

Displays photo/music/video

files from all of the devices

connected to the TV.

Shows how to connect PCs,

Smartphones, and USB drives.

SmartShare™

Recent

Video


Music

Recorded TV

Linked Device

Settings Delete History Connecting guide

Recently Played

Newly Added

000 001 002 003 004

005 006 007 008 009

010 011 012 013 014

GP4

enga

❐To control video playback

Controls playback and sets options while viewing videos.

Play Controls

Selects the desired point and plays

Sets Options

Option

GP4

enga

❐To control photo view

Controls playback and sets options while viewing pictures in full screen.

Sets options.

Sets the filter.

[Depending on model]

Displays photos as a

slideshow.

Plays background music.

Rotates or enlarges the picture.

Option

GP4

enga

❐To control music playback

Controls playback and sets options while playing music.

Selects the desired point and

plays

Sets options

Listen to music with the screen

turned off.

Sets the repeat/random

function.

Plays

GP4

enga

✎You can control playback using the ꕚ , ꕖ and ꕙ keys on a standard

remote control.

✎When using a USB device, time information will be not shown on screen.

GP4

enga

❐To set SmartShare™ related functions

SMART ➾ SmartShare™ ➙ Settings

Changes settings related to SmartShare™ content play.

❌Advanced Setting

My TV Name Changes the name that appears when searching for the TV

from other devices.

Network Status Checks the network connection.

Wi-Fi direct Allows use of wireless connection functions such as Wi-Fi

direct and WiDi.

Auto Play on

Receive Accepts/Rejects Content transferred from other devices.

GP4

enga

DivX(R) VOD

Registers or releases DivX.

Checks DivX Registration Code for playing DivX-protected

videos. Register at http://vod.divx.com.

Uses Registration Code to rent or purchase movies at www.

divx.com/vod.

✎When using the DivX Registration Code of another device,

the rented/purchased DivX file cannot be played. Use

only the DivX Registration Code granted to this device.

✎Converted files not conforming to DivX Codec Standard

may produce abnormal images and sound.

GP4

enga

❌Delete History

To delete contents history, press Delete History button below. Use the contents

at Recent menu.

GP4

enga

❐SmartShare™ supporting file

Maximum data transfer rate :

20 Mbps (Mega bit per second)

External supported subtitle formats :

*.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0),

*.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX), *.dcs (DLP Cinema)

Internal supported subtitle formats :

XSUB (Supports internal subtitles generated from DivX6)

GP4

enga

❌Video Supported Codec

Maximum: 1920 x 1080 @30p

Extension Codec

.asf

.wmv

Video VC-1 Advanced Profile, VC-1 Simple and Main Profile

Audio WMA Standard, WMA 9 Professional

.divx

.avi

Video DivX3.11, DivX4, DivX5, DivX6, XViD, H.264/AVC,

Motion Jpeg, MPEG-4 Part 2

Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3),

Dolby Digital, Dolby Digital Plus, LPCM, ADPCM, DTS

.mp4

.m4v

.mov

Video H.264/AVC, MPEG-4 Part 2

Audio MPEG-1 Layer III (MP3)

GP4

enga

Extension Codec

.3gp

.3g2

Video H.264/AVC, MPEG-4 Part 2

Audio AMR-NB, AMR-WB

.mkv Video H.264/AVC

Audio Dolby Digital

.ts

.trp

.tp

.mts

.m2ts

Video H.264/AVC, MPEG-2, VC-1

Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3)

Dolby Digital, Dolby Digital Plus

.vob Video MPEG-1, MPEG-2

Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM

.mpg

.mpeg

Video MPEG-1, MPEG-2

Audio MPEG-1 Layer I, II, MPEG-1 Layer III(MP3)

GP4

enga

❌Available music file

File type Item Info

mp3

Bit rate 32 Kbps - 320 Kbps

Sample freq. 16 kHz - 48 kHz

Support MPEG1, MPEG2, Layer2, Layer3

GP4

enga

❌Available photo file

File type Item Profile

(jpeg, jpg, jpe) JPEG

Minimum: 64 x 64

Maximum:

Normal Type: 15360 (W) x 8640 (H)

Progressive Type: 1920 (W) x 1440 (H)

GP4

enga

❐Caution for playing video

✎Some subtitles created by users may not work properly.

✎The video and subtitle files should be placed in the same folder. In this case,

you must assign the same names for the video and subtitle files for proper

display.

✎Subtitles on an NAS (Network Attached Storage) device may not be

supported depending on the manufacturer and model.

✎We do not support any stream that contains GMC (Global Motion

Compensation) or Qpel (Quarterpel Motion Estimation).

✎Only H.264/AVC profile level 4.1 and lower is supported.

✎The file size limit is dependent on the encoding environment.

✎It only supports Window Media Audio V2 and newer.

GP4

enga

✎Video files created by some encoders may not be played back.

✎Video files in formats other than the ones specified here may not be played

back.

✎Playback of video files stored on a USB device that does not support High

Speed, may not work properly.

✎DTS audio is supported with HDMI input and USB drive playback.

GP4

enga

DLNA stands for Digital Living Network Alliance, which allows users to access

video/music/photo files stored on a PC or server and enjoy them on the TV via

home networking.

 

TV and the smartphone should be on the same network.

1 Enable Wi-Fi on the smartphone.

2 Install/run a DLNA app to share content on the smartphone (It’s called

SmartShare on LG phones).

3 Run “Share my mobile phone Content”.

4 Select the kind of Content (video/music/photo) to play.

5 Select the video, music, or photo file to play on the TV.

6 Select Add to Play List.

7 Select TV model name on the device to replay content. (TV model name is on the

label of the device.)

8 Press Play ▶ to enjoy the selected file on the TV.

GP4

enga

 

With the Windows 7 or Windows 8 PC operating system or DLNA-certified device

(e.g. mobile phone), music/videos/photos may be played on the TV without

installing a separate program.

1 Configure the TV and PC on the same network. Configure the Windows 7 or

Windows 8 PC on the network.

2 To play a music/video/photo file, right-click on the file and use the Remote

Playback or PlayTo Windows 7 or Windows 8 feature.

For playback on devices like a mobile phone, refer to the model’s user guide.

3 Content will be played on only one device even if more than one TV or device

is connected. Play speed can vary depending on network speed.

GP4

enga

 

With a PC having SmartShare PC Software, music/video/photo files may be

played on the TV via home networking.

1 Configure the TV and the PC on the same network. The TV and each device

should be connected through a single access point to enable DLNA service.

2 Install the SmartShare PC Software from the web site onto a PC. Before

installation, close all running programs including firewall and Anti-Virus

programs.

3 The sever should be running in order to watch shared files on your TV.

✎ For the website information, go to SMART ➾ Settings ➙ SUPPORT ➙

Product/Service Info.

✎ For how to use the SmartShare PC software, refer to the software help.

GP4

enga

 

✎ If a DLNA feature does not work properly, check network settings.

✎ A 5-GHz access point is needed to view 1080p videos via DLNA.

A 2.4-GHz access point may cause frequent buffering or other problems.

✎ DLNA may not work properly on a wireless network. It is recommended to use

a wired connection.

✎ Multi audio and internal subtitles are not supported in DLNA mode.

✎ If more than one TV is connected to a single server in DLNA mode, the

content may not play depending on server performance.

✎ Subtitles may not be supported depending on DLNA device.

✎ The DLNA feature may not work properly in all network environments.

GP4

enga

✎ The DLNA feature cannot be used with some access points that do not

support multicasting. For more information, refer to access point manual or

consult with the manufacturer.

✎ Supported file types may differ depending on the DLNA server environment,

even for the file types supported by TV.

✎ Too many sub-folders and files included in one folder may cause a

malfunction.

✎ Information about the file from DLNA server may not be displayed correctly.

✎ SmartShare PC Software is recommended when watching video subtitles

from a DLNA server.

✎ To add a subtitle file later, turn off the shared folder and reset.

✎ DRM files located in SmartShare PC Software server are not played.

✎ ULTRA HD video (3840 X 2160) file does not work.

GP4

enga

 

 

This service gives you easy access to a wide variety of content, such as video,

news and UCC (User Created Content), at any time, as long as you are connected

to a network. For Premium content, specialized country-specific services are

offered that take into account regional content, in addition to globally provided

content.

WEB Movie Map SNS Play

NEWS Comic Entertainment Information TV

Add to My Apps

Sets options

PREMIUM

Option

Add to My Apps

Premium Content

Select desired

Content.

GP4

enga

 

Some Premium Content is provided as for-fee services. To purchase for-fee

services, use either LG Electronics’ proprietary billing system or that of each

content provider.

Before using the LG billing system, you will need to sign up for membership and

You can sign up for membership on the login screen on your TV or our website.

You can then log into both the TV and the website with one ID.

GP4

enga

1 Click Sign In button in upper right corner of Home screen to sign in.

2 Move to the desired Premium service.

(For some premium services, separate sign-in is required after signing up for

the premium service.)

3 After checking the content’s pricing and service information, click the

Purchase button. (There may be limitations on the available period and

number of times depending on content.)

4 Once the purchasing process is completed, view the paid content by clicking

the Buy button.

5 Select your ID on upper menu of Home screen and check history of

purchases from My Page ➙ Payment inquiry. It is also available on My Page

➙ Purchase History of web site (www.lgappstv.com).

GP4

enga

 

 

Premium list, Premium information, country setting, and user sign-in information

will be reset. When an error occurs during Premium update, reset will fix the

problem.

GP4

enga

✎ Content on offer by service providers are subject to change to enhance

their service quality or deletion without any prior notice. Refer to the

web site of each content provider for questions, troubleshooting, or

latest information about Content. LG Electronics does not take any legal

responsibility for content services and related information including

discontinuation of service by the service provider.

✎ The quality of Premium service may be affected by Internet connections.

For any questions related to Internet speed or any other service problems,

contact the Internet service provider.

✎ For best service quality, subscribe to an Internet service of 4.0 Mbps

(1.5 Mbps or faster). Contact the ISP (Internet service provider) for any

problems related to Internet speed.

✎ Content providers may make available content that is unsuitable for minors.

Parental discretion advised.

GP4

enga

❐To use LG Smart World

[This function may not be applied some countries.]

SMART ➾ LG Smart World

LG Smart World is a TV application service available through Smart TV Service.

You can download and enjoy many different apps (for fee or free) including

education, entertainment, life and news.

Select the app to install.

When you sign in, ID is displayed.

When you select the ID, you can select

My Page and Sign Out.

SMART WORLD

All

Hot

Top Paid

Top Free

New

18+

All

Game

Entertainment

Life

Education

News/Info.

My Apps

GP4

enga

 

 

1 Select Sign Up and agree to Legal Notice.

2 Enter ID and password.

3 In Confirm Password box, enter password again.

4 Select OK to complete sign-up process.

✎ You can sign up for membership on either your TV or the website (www.

lgappstv.com).

✎ After signing up for membership, log into your TV and our website with the

same ID.

✎ You can sign in up to five TVs with a single ID.

GP4

enga

 

 

1 Click the Sign In button at the top of the home screen to log in.

2 Select the LG Smart World card.

3 Select an app you want from the list.

4 Check the details of the app, then select the Install or Buy button.

5 Check that you have the functions or TV accessories required to install the

app, then select the OK button.

6 For paid apps, payment and purchase authentication is required.

7 Select Run once installation is complete to run the app immediately.

If you do not want to run immediately, select Close. If you want to run the app

later, select My Apps to check the list of apps installed on TV.

GP4

enga

✎ You can purchase apps from PC or TV but you must use the TV to install and

run them.

✎ If you have insufficient storage space on the TV, you can download apps to a

USB storage device connected to the TV’s USB Apps port. Apps stored on a

USB device are available to run/delete/move via the My Apps screen.

✎ A USB Memory Stick containing apps cannot be used for other data. (For

USB Apps Only)

GP4

enga

 

 

1 Sign in.

2 Select the currently signed-in ID at the top of the screen.

3 Select My Page.

4 Manages by examining Member Information, My Purchased Apps List and TV

Installed Apps List.

GP4

enga My Information

Shows basic information about the ID currently signed

in. To change your member information, please visit

www.lgappstv.com on your PC.

Payment Inquiry Views Payment History with the ID you have signed in.

Purchased Apps

Vews My Purchased Apps List with the ID you have

signed in. You can delete/re-install the purchased

apps.

GP4

enga

SMART ➾ Search

You can search apps and contents using the Search function of the LG Smart TV.

When you enter keywords using the input device, such as the remote control,

you can find apps from LG Smart World and some contents of the Premium

service. Links are also provided to go for web search. If you are using

SmartShareTM, you can also search the contents of SmartShareTM. The Search

categories and content types vary depending on the country and will be kept

updating.

Detailed information

about the search item

Category of

search results

Related Keywords

Search results

Enters search

terms. All

Premium

Smart World

APP Contents

Youtube

News

GP4

ENG

❐To use the voice recognition function

❌Using this function through search

1 Go to SMART ➾ Search. Select the voice recognition icon ( ) on the left of

the text field.

2 Speak slowly and clearly after the voice recognition window appears. After

the voice recognition is completed, the Similar List window pops up. If

the pop-up window does not have the results you want, press Retry to try

again. Select the most similar result, then it will be displayed in the text

field. Press the Search button to get the result you want.

GP4

ENG

❌Using this function in the Internet (Web browser)

1 Go to SMART ➾ Internet. Move the Magic Remote Control pointer in the

text field on a website to open the virtual keyboard.

2 Select the voice recognition icon ( ) on the left of the text field on the virtual

keyboard.

3 Speak slowly and clearly after the voice recognition window appears.

4 After the voice recognition is completed, the Similar List window pops up. If

the pop-up window does not have the results you want, press Retry to try

again. Select the most similar result, then it will be displayed on the text field.

Press the Search button on the website to get the result you want.

GP4

ENG

✎You can use Voice Search when you press the Voice recognition( ) on the

Magic remote control even if QWERTY keyboard is shown on your screen.

✎Check the network connection before using the voice recognition function.

✎When speaking, hold the remote within 10cm of your mouth.

✎The voice recognition may fail if you speak too fast or too slowly.

✎The recognition rate may vary depending on the user's characteristics (voice,

pronunciation, intonation, and speed) and the environment (noise and TV

volume).

✎To change the voice recognition language, go to SMART ➾ Settings ➙

OPTION ➙ Language ➙ Voice Recognition Language.

✎You can turn the avatar On/Off in SMART ➾ Settings ➙ OPTION ➙ See

Avatar.

[This function may not be available on some models.] Powered by

GP4

ENG

 

Voice Mate allows you to search desirable programs and content with your

voice and adjust the TV.

1 Press the Voice recognition ( ) button on the Magic Remote Control.

2 When the Voice Display bar ( ) is activated on the left of the

screen, say what you want to watch.

3 Press the Wheel (OK) button with the Voice Search standby to see the

supported language in the voice guide.

Tell me what you want.

“Show me the hottest YouTube video,

and timer-record it (a program).”

WHEEL(OK) button: See voice user guide.

GP4

ENG

 

✎ To use all the functions and services of Voice Mate, you need to set Smart

Wizard and Time. Set up the network, region, auto tuning, and universal

remote control through the Smart Wizard.

✎ In order to use Voice Mate, you must set up the network, time, region, and

tuning.

✎ Set the language of your country to use Voice Mate.

✎ You can change the language for Voice Search in SMART ➾ Settings ➙

OPTION ➙ Language ➙ Voice Recognition Language.

✎ You can turn the avatar On/Off in SMART ➾ Settings ➙ OPTION ➙ See

Avatar.

GP4

ENG

✎ It is recommended you to point the universal remote control towards the set-

top box when you use Voice Mate with it.

✎ When speaking a command, hold the remote within 10cm of your face.

✎ The voice search may fail when you speak too fast or too slow.

✎ The recognition rate of Voice Mate may vary depending on the user’s

characteristics (voice, pronunciation, intonation and speed) and the

environment (noise and TV volume).

✎ If your voice is not recognized properly, Voice Mate may function

regardless of your intention.

GP4

ENG

 

You can access various TV features using Voice Mate.

Channel

You can tune TV channels and search channel

information.

Example: “What time is American Idol on?”

Recommendation

and Search

You can recommend and search TV programs and

content files.

Example: “Look up American Idol”

Information and

Internet

You can also search other information such as today’s

weather.

Example: “How’s the weather today?”

✎ Available functions may vary depending on the country.

✎ For more supported examples, see the voice user guide.

GP4

enga

SMART ➾ Internet (Web browser)

You can type in a URL manually or visit a Web site from the Favorites list.

Open a new tab.

Type in Web addresses here. Add the current page to favorites.

GP4

enga

✎ The Internet (Web browser) supports up to Flash 11 but does not support

platform-dependent technology like ActiveX.

✎ The Internet (Web browser) only works with pre-installed plug-ins.

✎ The Internet (Web browser) only replays the following media file formats:

JPEG / PNG / GIF

✎ The Internet (Web browser) is forcibly closed when memory is insufficient.

✎ For the Internet (Web browser) , fonts installed on the TV are used and may

not be displayed normally depending on the content played.

✎ The Internet (Web browser) does not support file and font download.

✎ The Internet (Web browser) is made for a TV so it may function differently

from PC browsers.

✎ The Internet (Web browser) is a TV browser and may not work properly when

playing some content files.

GP4

enga

Free apps are available immediately after signing up, but you need to register

your payment method in order to use paid apps.

You can sign up and register payment methods on the TV or on our website

(www.lgappstv.com).

Problem Solution

When entering menu,

the "Initializing" message

always appears.

• The "Initializing" message shows you how long it takes to

reboot the microprocessor and hardware, set up network

communications, and communications with SDP (device

authentication and basic information download). It takes

about 20 seconds and this is a normal process.

There is no content shown

on the Premium card.

• Content may not be shown after changing the country

setting on Smart TV. Change to desired country in

SMART ➾Settings➙OPTION➙Service Country

Setting

GP4

enga

Problem Solution

While using internet

features, there is a blank

space on some Web

pages.

• The internet of the TV supports up to Flash 11 and may

not replay any file format other than the following

: JPEG, PNG, GIF

Internet (Web Browser)

closes automatically when

visiting website.

• If memory is insufficient because of large volume of image

information in the web page, internet may be forced to

close.

I already signed up on

TV. Do I need to sign

up again at web site

(www.lgappstv.com)?

• If you sign up on your TV, no additional sign-up on the LG

website (www.lgappstv.com) is required.

After signing up on TV, you can sign into the website

by using the same ID and password and entering the

additional information to complete the email verification

process.

GP4

enga

Problem Solution

Can each family member

use a different ID with a

single TV?

• It is possible to register and use more than one ID on one

TV.

• To check the ID registered with TV from

SMART ➾Sign in➙ID List.

• You can check the list of apps purchased by each ID.

However, you can see all apps installed by each ID in

SMART ➾Sign in➙My Page.

What should I do if I forget

my ID?

• After signing up on a PC, use “Forgot ID?” feature on web

site (www.lgappstv.com) when needed.

• After signing up on TV, check it from

SMART ➾Sign in➙Find ID.

GP4

enga

Problem Solution

I purchased an app from

the LG TV Apps Web site.

How can I use it on TV?

• To check purchased apps from the TV, sign in and open

the Purchased Apps menu.

Select the ID at the top of Home and check the app in

My Page➙Purchased Apps.

Can I see history of my

purchased apps?

• Select the ID at the top of Home and check the app in

My Page➙Purchased Apps.

• Sign in to website (www.lgappstv.com) and then select

MyPage➙PurchaseHistory.

GP4

enga

Problem Solution

I deleted a paid app. Do I

have to purchase again to

download it?

• If a purchased app is accidentally deleted, you can

download and reinstall it without having to buy it again, as

long as it is still in service.

Select the ID at the top of Home and re-download apps in

My Page➙Purchased Apps. (Previously owned apps may

not be re-downloaded or run depending on the software

version.)

Can I use apps from LG

Smart TV's LG Smart

World on both a TV and a

PC?

• Please check if the TV model supports LG Smart World.

• The apps provided from LG Smart TV's LG Smart World can

only be used on an LG Smart TV.

• Apps may be purchased from the website (www. lgappstv.

com) but cannot be used on a PC or Mac. Use care when

purchasing.

GP4

enga

Problem Solution

How can I check the ID

currently signed in on the

TV?

• Select the ID at the top of Home and check the currently

signed-in ID in My Page➙My Information.

I installed an app on the

TV. Where can I check the

installed app?

• Select SMART ➾My Apps. All paid and free apps

installed on TV are displayed.

There is a difference

between the app size

shown on the screen

and the actual app size

installed on TV.

• The app size shown in the screen includes the additional

space needed for installing apps so it may be different from

actually installed app size.

GP4

enga

Problem Solution

I forgot my password on

the TV. What should I do?

• If you only provide the ID and password when signing up

on your TV, you cannot recover your password when it is

lost. Create a new ID and sign up with the ID.

• If you provide other information than the ID and password

when signing up on your TV or the LG website (www.

lgappstv.com), you can recover your password on the

website.

GP4

enga

Problem Solution

Do I have to enter

payment information to

purchase paid apps?

• To purchase paid apps, you should have a credit card

registered on the LG Smart World website (www.lgappstv.

com) or have an account credit. If you do not want your

credit card details to be saved, you may add a credit to

your account before buying an app. Charging credit is only

available on our website, and you cannot purchase paid

apps if your credit card details are not registered or you

don’t have enough credit.

Can I cancel an app that I

have purchased?

• As a member you cannot demand refund just because you

changed your mind after purchase.

• If there is a defect in the product or a problem of using the

product, which does not caused by your fault, you can ask

for a refund. However, the valid reason for refund must be

provided.

GP4

enga

Problem Solution

I signed up on my TV, but

I cannot purchase paid

apps.

• To purchase paid apps, you need to have a credit card

registered with the website (www.lgappstv.com).

Also, you can have place a credit on your account ahead of

time.

You cannot purchase paid apps if your credit card details

are not registered with us or you don’t have enough credit.

Should I only use an email

address for my ID?

• For new sign-up members, the ID format has changed from

a combination of alphanumerics to your email address.

• You can only use an email address for your ID when signing

up.

GP4

enga

Problem Solution

Do I need to change my

ID format to the email

address?

• For new sign-up members, the ID format has changed from

a combination of numbers and letters to using an email

address.

• If you are already a member, you can still use your existing

ID or change it to an email address.

What is the LG account?

• The LG account allows you to sign into all of the LG Smart

services with a single ID and password.

You can use the following services with your LG account:

LG Smart TV, LG Smart World (excluding some countries),

LG Smart ThinQ, and LG Smart air conditioning, etc.

• Additional information may be required depending on the

service.

GP4

ENG

 

 

You can change the country setting of your Smart TV.

The Premium service and LG Smart World that are available for the country you

selected will be provided.

Auto Setting A service country is automatically set for your Smart TV.

Manual Setting A service country can be set manually for your Smart TV.

✎ If a network is disconnected while setting the service country, it may not be

set properly.

NC4H

ENG

 

 

Use the Magic Remote Control to select buttons on the Screen Remote displayed

on the screen.

NC4H

ENG

 

✎ The type of buttons on the Screen Remote varies depending on the region

or the type of connected device.

✎ Image shown may differ from your TV.

Exits the Screen Remote

Moves the position of the Screen Remote to left or right

TV operation buttons

✎ The type of buttons varies depending on the model.

Change Device tab

Time Machine II

REC.

NC4H

ENG

 



You can control a device connected via SimpLink or MHL using the Screen

Remote.

1 Check if the device is connected to the TV.

2 After pressing the button on the Magic Remote Control, select the

device you want to control in the Change Device tab. The Screen Remote that

can control the device appears.

✎ This may not work with the button for some models.

✎ For more information about SimpLink or MHL connection, please refer to

the connection section of "Owner's Manual" provided with the TV.

NC4H

ENG

 

[For Magic Remote Control only]

[This function may not be applied some countries.]

With the Magic Remote Control, you can control a set-top box, Blue-ray player,

home theater system, etc.

1 Connect the device you wish to control to the TV.

2 After pressing the button on the Magic Remote Control, select the icon

of a device you want in the Change Device tab.

If the device you wish to control is not listed, press the on the tab, and

select the external device you want. Once the setup is complete, the name of

the selected device is displayed in the Change Device tab.

3 When you select a device in the Change Device tab, the Screen Remote that

can control the device appears on the screen. To see more control buttons,

select at the bottom of theScreen Remote.

NC4H

ENG

 

1 After pressing the button on the Magic Remote Control, select the

(TV/input selection) button.

2 Select Change Setting or Cancel Setting at the bottom of the device to be

changed.

✎ When Change Setting, check if the power of the device to be changed is

turned on.

NC4H

ENG

✎ You can set one device per type.

✎ With the Screen Remote, you can only control the devices of a brand or

manufacturer that you can select in the setup screen.

✎ If you connect to a network before setting the universal remote control,

update for the latest manufacturer list is available.

✎ Some buttons may not work depending on the external device model.

✎ Place the device near the TV for seamless operation.

✎ If the device is in a drawer, open the drawer.

✎ Go to SMART ➾ Universal Control or SMART ➾ INPUT LIST ➙ Set the

Universal Control and add, delete, or change a device.

GP4

ENG

 

You can control the TV simply by gesturing for the camera.

You can use the Motion Recognition function to turn the TV off, change the

channel, or control the volume.

✎ Motion Recognition is only a function for watching TV and it is not supported

when using the smart menu, such as when connecting wireless devices,

including TV apps or USB ports.

TV HDMI1 Component

Move Select

GP4

ENG

 

1 Prepare the Smart TV camera for use. If your Smart TV is not equipped

with a camera, install an LG video call camera (sold separately). (For more

information, please refer to the installation manual or owner's manual of the

camera.)

2 The camera is activated 20 to 30 seconds after the TV is switched on.

3 Go to SMART ➾ Settings ➙ OPTION and check if Motion Recognition is

set to On.

4 Stare at the camera while the TV is on and hold your hand up close to your

face. The motion recognition controller appears on the TV screen. (You can

check the motion recognition range of the camera in SMART ➾ Settings

➙ OPTION ➙ Camera Setting Help.)

GP4

ENG

5 Move your hand left, right, up or down to select a function. Close and open

your fist to start the function.

6 If you lower your hand out of the range of motion recognition, the controller

disappears from the screen.

✎ If you clench your fist for more than one second, the selected function is

performed repeatedly until you open your hand.

✎ If you are watching TV using a set-top box, install an IR blaster (AN-

BL100, sold separately) to control the volume and the channel of the set-

top box using Motion Recognition.

GP4

ENG

✎ Motion Recognition may not work properly if:

• The room is either too bright or too dark. (Optimal ambient brightness:

50 lux - 600 lux)

• There is a bright light behind you.

• You are wearing a hat.

• You are too far away or too close to the camera (Ideal distance: 1.5 m -

4.5 m).

• Your fingers cannot be detected by the camera because you are wearing

gloves or a bandage.

• You moved your arm forward or your hand is not close enough to your

face.

• Your skin color is similar to the background color.

• The background is striped.

GP4

ENG

✎ A gesture may not be recognized in the following cases.

• If Motion Recognition is set to Off in SMART ➾ Settings ➙ OPTION,

: Set it to On.

• If any other menu than the motion recognition controller is displayed on

the TV screen,

: Make it disappear.

• (For built-in camera) If the camera is not lifted up,

: Make sure to lift-up the camera.

✎ Devices connected through a USB port or a wireless connection cannot be

switched via Motion Recognition.

GP4

ENG

✎ If more than one hand is detected by the camera, it works with the first

detected hand only. To use another hand to operate the controller, lower your

hand down to clear the controller from the screen and then raise your hand

up again.

✎ If you hold your hand up with it spread out or gripped, the camera may not

detect your hand. Make sure that you raise your hand with all five fingers

clearly displayed.

✎ Be careful not to move your hand too fast or make too big motion. Move

your hand slowly near your face.

✎ If Motion Recognition does not work properly, lower your hand and then lift it

up again.

✎ If you open your hand at an angle, the camera might mistake this as a fist and

perform the selected function.

GP4

kor

You can download the LG TV Remote app from Google Play Store or Apple App

Store and control a TV that is on the same network ads your smartphone.

• Now you can enjoy your favourite TV shows on your smartphone. (Some

models only)

• You can easily enter your account information to log in.

• You can add your favourite channels on your smartphone.

• You can use the functions such as PREMIUM, MY Apps, and SmartShareTM

directly on your smartphone.

• The text input function is supported, so you can enter text easily. (Text

cannot be entered on some screens.)

• Select the app's touch pad to control the cursor in the same way the pointer

of the Magic Remote Control works.

• You can control the game app of the TV by selecting the Game Pad in the

LG TV Remote app.

GP4

kor

• Keypad will allow you to control some set-top box and media devices. (Some

models with specified conditions only.)

• You can set the TV to the power-saving mode while watching TV on your

smartphone.

• You can capture the screen you are watching and share it through social

network services such as Twitter and Facebook.

✎The supported functions may vary depending on the TV or the version of

the LG TV Remote app.

GP4

ENG

 

Connect your mouse to a USB port on the TV. Use the mouse to move the

pointer on the TV screen and select the menu you want.

Mouse Magic Remote Control

Left Button OK Button on Magic Remote Control

Wheel Button Wheel Button on Magic Remote Control

✎ The right mouse button and any special buttons will not work with the TV.

✎ The usability of a wireless USB mouse and keyboard may be affected by

Radio Frequency environment and the distance.

GP4

ENG

 

Connect your keyboard to a USB port on the TV. You can enter text with the

keyboard when using the search function and the Web browser.

✎ Text cannot be entered on some screens.

✎ It is recommended to use a product which has been tested for compatibility

with LG TVs.

LOGITECH K200, LOGITECH K400, MICROSOFT Comfort Curve 2000,

MICROSOFT MS800, and LG Electronics ST-800

✎ You can change the input language by pressing the language switch key (or

the right Alt key) on your keyboard.

GP4

ENG

 

Connect your gamepad to the USB port on the TV if the game requires a

gamepad.

✎ It is recommended to use an authorized gamepad which is tested for

compatibility with LG TVs.

Logitech F310, Logitech F510, Logitech F710, Logitech Rumblepad 2

Logitech Cordless Rumblepad 2, Logitech Dual Action Gamepad,

Microsoft Xbox 360 Controller (wired) and SONY PLAYSTATION(R)3 Controller

GP4

enga

SMART ➾ Settings ➙ SUPPORT ➙ Software Update

Uses Software Update to check and obtain the latest version.

It is also possible to check manually for available updates.

Software Update

Set it to On.

If an update is available, a prompt will appear to perform

the update.

Automatic

update mode

If an update is available, the update automatically starts

without prompting.

Check Update

Version

Checks the version installed and when an update is

available, the download process can be performed

manually.

GP4

enga

✎ When the update starts, the update progress window appears for a short

time and disappears.

✎ The latest version can be obtained via digital broadcast signals or internet

connections.

✎ Changing the channel while downloading the software via digital broadcast

signal interrupts the download process. Returning to the initial channel allows

downloading to resume.

✎ If software is not updated, certain functions may not work properly.

GP4

enga

If the following symptoms occur, please recheck the system. It may not be a

failure.

 

Problem Solution

Cannot view certain

channels.

• Adjust the location or orientation of the antenna.

• Save the desired channels on Auto Tuning or Channel Edit.

After turning on the TV,

there is a delay before

full images appear.

• It is not a problem because this process was intended to

clean up the image noises that may occur when turning on

the TV.

GP4

enga

 

 

Check if the image signal output is normal by beginning with Picture Test.

If there is no problem with the test image, check external device connections or

broadcast signals.

Problem Solution

Images from previous

channel or other channels

linger or the screen shows

annoying lines.

• Try adjusting the antenna to the direction of the TV

station or refer to the manual for proper way to connect

the antenna.

GP4

enga

Problem Solution

Vibrating horizontal/vertical

lines and fishnet patterns

appear momentarily.

• Such a problem may happen when there is strong

electronic interference. Turn off other electronic devices

such as mobile phones, power tools and other small

electrical appliances.

The screen display freezes

or does not work properly in

digital broadcast.

• It may happen when the signals are weak or the

reception unstable. Adjust the antenna’s orientation or

cable connections.

• If the signal strength or quality is low on Manual Tuning,

call the TV station or administration office for checkup.

Digital broadcast is not on

even though the cable is

connected.

• Check with cable operator regarding the subscription

and/or signal. (Depending on the subscription, digital

broadcasting may not be supported.)

GP4

enga

Problem Solution

Image is not on or not clear

when connected to HDMI.

• Check the HDMIⓇ cable specifications. Use only HDMIⓇ

cable. Other cables may cause images to fade in and

out or not be displayed properly.

• Verify that all cable connections are securely

connected. When connections are not secure, images

may not be properly displayed.

Does not work when USB

storage device is connected.

• Verify that the USB device and cable is version 2.0 or

higher.

GP4

enga

 

 

Try Sound Test first to verify that sound signal output is normal.

When the test sound is normal, check external device connections or broadcast

signals.

Problem Solution

Screen display is on but no

sound.

• Check other TV channels.

• Make sure the TV Speaker is set to On.

For analog broadcast, stereo

is not clear or sound comes

from one speaker only.

• In a poor reception area (areas with weak or unstable

signal) or if multi audio is not stable, select Mono on

Multi Audio.

• Adjust the balance with the Navigation button.

GP4

enga

Problem Solution

TV sound is not in sync with

the lips or the sound breaks

up occasionally.

• If it happens on a certain TV channel, it may be caused

by problems with an individual station’s broadcast

signal. Check with the TV station or local cable

operator.

Whenever changing the

channel, the volume is

different.

• Depending on the channel, there can be differences in

volume.

• Please set Auto Volume to On.

GP4

enga

Problem Solution

On certain channels, sound

does not come out or only

the background music plays.

(If it is a program created for

overseas)

• On Language, set Language ➙ Audio Language as the

desired language. Even if the language on Multi Audio

is changed, once the power is turned off or the channel

is changed, the default settings will be reset.

There is no sound when

connected to HDMI/USB.

• Verify that the HDMIⓇ cable is high speed.

• Check if the USB device and cable is version 2.0 or

higher.

• Use only regular music (*mp3) files.

GP4

enga

 

Problem Solution

The screen display is not

on after connecting to

the computer.

• Verify that the computer and the TV are securely

connected.

• Turn the TV off and back on using the remote control.

• Restart the PC with the TV on.

• Check if the resolution is correctly set for PC input.

• To use the TV as a secondary monitor, check if the

connected desktop or laptop supports dual monitor

displays.

• Reconnect the HDMI cable.

There is no sound after

connecting the computer

with the HDMI cable.

• Check with the video card manufacturer to ensure it

supports HDMI voice output. (Video cards manufactured in

DVI format require connection of a separate sound cable.)

GP4

enga

Problem Solution

When connected to the

computer, the display is

partially cut off or shifts

to one side.

• Set up the resolution supporting PC input. (If it does not

work, please reboot the computer.)

GP4

enga

 

Problem Solution

Files on the Movie List are

not displayed.

• Check if the file on the USB storage device can be read

on a computer.

• Check that the file extension is supported.

"This file is invalid." The

above error message

appears or the image

display is not normal even

though the sound is okay.

• Verify that the file replays normally on the video player in

the computer. (Check for damaged files.)

• Check if the resolution is supported by the computer.

• Verify that the video/audio codec is supported.

• Verify that the frame rate is one that is supported.

GP4

enga

Problem Solution

"Unsupported Audio."

The above error message

appears or the sound is not

normal even though the

image display is okay.

• Verify that the file replays normally on the video player in

the computer. (Check for damaged files.)

• Check that the audio codec is supported by the

computer.

• Verify that the bit rate is supported.

• Verify that the sample rate is supported.

GP4

enga

Problem Solution

Subtitle is not displayed.

• Verify that the file replays normally on the video player in

the computer. (Check for damaged files.)

• Check if the video file shares the same name with the

subtitle file.

• Verify that the video and subtitle files are placed in the

same folder.

• Verify that the subtitle file format is supported.

• Verify that the subtitle language is supported. (Open the

subtitle files in Notepad to check for the language.)

✎ Image shown may differ from your TV.

✎ For information on requesting service, refer to the TV's menu.

SMART ➾ Settings ➙ SUPPORT ➙ Product/Service Info.

 

You are cautioned that changes or modi󷕕cations not expressly approved by the part

responsible for compliance could void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o󷕔 and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit di󷕔erent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

1 this device may not cause harmful interference, and

2 this device must accept any interference received, including interference that

may cause undesired operation of the device.

 

FCC Caution: for indoor use only, use outdoors or in other modes not covered by this

manual may violate the FCC regulation and violate the user authority to use the product.

Specially, within the 5.15-5.25 GHz band, U-NII device is restricted to indoor operations to

reduce any potential for harmful interference to co-channel MSS operations.

 

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This transmitter must not be co-located or operating in conjunction with any

other antenna or transmitter.

 

This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to

the following two conditions:

1 this device may not cause interference and

2 this device must accept any interference, including interference that may

cause undesired operation of the device

 

Cet appareil est conforme à la norme CNR-210 des règlements d’Industrie Canada. Son

fonctionnement est sujet aux deux conditions suivantes :

1 Cet appareil ne doit pas provoquer d’interférences et

2 Cet appareil doit accepter toutes les interférences, y compris celles pouvant

entraîner son dysfonctionnement.

 

This equipment complies with IC radiation exposure limits set forth for an uncontrolled

environment.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH

MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

 

Cet appareil est conforme aux limites d’exposition aux rayonnements d’Industrie Canada

pour un environnement non contrôlé.

REMARQUE : LE FABRICANT N’EST PAS RESPONSABLE DES INTERFÉRENCES

RADIOÉLECTRIQUES CAUSÉES PAR DES MODIFICATIONS NON AUTORISÉES APPORTÉES

À CET APPAREIL. DE TELLES MODIFICATIONS POURRAIENT ANNULER L’AUTORISATION

ACCORDÉE À L’UTILISATEUR DE FAIRE FONCTIONNER L’APPAREIL.

 

La operación de este equipo está sujeta a las siguientes dos condiciones:

(1) es posible que este equipo o dispositivo no cause interferencia perjudicial y

(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda

causar su operación no deseada.

 

LG Electronics o󷕔ers a customized e-waste take-back & recycling service that meets

local needs and requirements in the countries where e-waste regulations are in place, and

also provides product and packaging take-back & recycling service voluntarily in some

countries. LG Electronics evaluates products’ recyclability at the design step using LG’s

recyclability evaluation tool, with the goal of improving recyclability where practicable.

Through these activities, LG seeks to contribute to conserving natural resources and

protecting the environment.

For more information about the LG Recycling Policy, please visit our global site at

http://www.lg.com/global/sustainability/environment/take-back-recycling

LG 60LN5600 User Manual Guide NC4 HM U L08 2SU 161116 ENGA 151209 New;

Navigation menu

Versions of this User Manual:

Views

Navigation
