LAUNDRY
DLE1501W/ DLG1502W
Ultra Large Capacity High Efciency Front Control w/ NFC Tag On
PRODUCT FEATURES
7.3 cu.ft. Ultra Large Capacity
Aluminized Alloy Steel Drum
8 Drying Programs
NFC Tag On
Sensor Dry System
LoDecibel™ Quiet Operation
Anti-Bacterial Cycle
ENERGY STAR Qualied
KEY FEATURES
CAPACITY
Capacity 7.3 cu. ft.
ENERGY
ENERGY STAR Qualified •
APPEARANCE
Design Look Front Control
Hard Buttons •
Front Electronic Control Panel with LED Display •
DRYING PROGRAMS
No. of Programs 8
Programs (Sensor Dry) Cotton/Normal, Perm. Press/Casual,
Heavy Duty, Delicates, Anti-Bacterial
Programs (Manual Dry) Speed Dry, Air Dry, Download
No. of Options 7
Options Wrinkle Care, Custom Program, Child Lock,
More Time, Less Time, End of Cycle Signal, Damp Dry Signal
Temperature Settings High, Medium High, Medium, Low, Ultra Low
Drying Levels Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry
Manual Dry Times 60 min., 50 min., 40 min., 30 min., 20 min., More Time/Less Time
FABRIC CARE FEATURES
Sensor Dry •
Precise Temperature Control and Variable Heater •
CONVENIENCE FEATURES
NFC Tag On •
LoDecibel™ Quiet Operation •
SmartDiagnosis™ •
FlowSense™ Duct Clogging Indicator •
Anti-Bacterial Cycle •
Wrinkle Care Option •
Remaining Time Display/Status Indicator(s) •
End of Cycle Signal •
Child Lock •
Drum Light •
Reversible Door •
Leveling Legs 4 Adjustable Legs
Venting Option Electric: 4 Way Venting / Gas: 3 Way Venting
3 Minute Installation Check •
MATERIALS AND FINISHES
Aluminized Alloy Steel Drum (Alcosta) •
Cabinet Painted Steel
Control Panel Plastic/Sheet
Top Cover Plastic
Lid Solid/Silver
Available Colors White (W)
POWER SOURCE
Ratings CSA Listed
Electrical Requirements 120V, 15 Amps (Gas) / 240V 30 Amps (Electric)
Type Gas/Electric
OPTIONS
LP Conversion Kit 4948EL4002B
Side Venting Kit 383EEL9001B
DIMENSIONS
Product (WxHxD) 27" x 40 5/32" x 28 3/8"
(50 1/4" D with door open)
Carton (WxHxD) 29 1/2" x 43 7/10" x 31 1/4"
Weight (Product/Carton) Electric 121.7 lbs / 139.6 lbs
Weight (Product/Carton) Gas 125.4 lbs / 143.3 lbs
LIMITED WARRANTY
1 Year Parts and Labor
UPC CODES
DLE1501W Electric Dryer (White) 048231 015912
DLE1502W Gas Dryer (White) 048231 015929
WT1501CW Washer (White) 048231 015905
Design, features and specifications are subject to change without notice. Non-metric weights and measurements are
approximate.
© 2015 LG Electronics USA, Inc. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp. All other product
and brand names are trademarks or registered trademarks of their respective companies. 10/15/15
