BEAUTIFUL ON THE INSIDE.
BEAUTIFUL ON THE OUTSIDE.
A lot of thought went into this LG refrigerator. On the outside –
contoured doors, hidden hinges and commercial steel handles. And
Inside is enhanced LED lighting and an integrated 4-compartment
crisper system with a full width Glide N’ Serve™ drawer.
REFRIGERATOR
LFC25776
3 Door French Door
Refrigerator
HIGHLIGHTS
Sophisticated Style & Design
10-Yr Warranty on Linear Compressor
Energy Star / CEE Tier 3
10-Year Warranty on Linear Compressor
When you buy a refrigerator, you don’t want
to worry that it won’t last. Because the Linear
Compressor uses fewer moving parts and
operates more efficiently, LG confidently backs
the compressor with a 10-year warranty.
Energy Star / CEE Tier 3
When your refrigerator uses at least 30% less
energy than required by federal standards you’re
going to make an impact – on your energy bill,
your energy consumption, and most importantly,
the environment.
Sophisticated Style & Design
Contoured doors, hidden hinges, and a host of
great interior features give your refrigerator a look
as sophisticated as it is functional.
STYLE AND DESIGN
• LFC25776–25.0cu.ft.
LFC21776–20.7cu.ft(CounterDepth)
• FrenchDoorRefrigerator
withBottomFreezer
• PremiumFinishesinStainlessSteel,
SmoothWhiteandSmoothBlack
• ContouredDoorswithMatching
CommercialHandles
• HiddenHinges
• PremiumLEDInteriorLight
ORGANIZATION
• 4Slide-Out,SpillProtector™Tempered
GlassShelves
• GlideN’Serve™Drawer
• 2HumidityCrispers/1BonusDrawer
• 6DoorBaskets(5Adjustable
GallonSize)andDairyCorner
• UtilityBin
• FreezerDrawerwithFullWidth
DuraBase™inside
PERFORMANCE
• EnergyStar/CEETier3,uses30%
LessEnergythanFederalStandards
• LinearCompressorforBetterEnergy,
QuietOperation,andDurability
• Multi-AirFlowCooling
• InternalLEDTouchPadDigital
TemperatureControls
• IcePlus™AcceleratedFreezingFunction
• DoorAlarm
• LoDecibel™QuietOperation
withLinearCompressor
HARF-LFC25776-SS07/01/10
REFRIGERATOR
LFC25776
www.LG.com
LGElectronicsU.S.A.,Inc.
1000SylvanAvenueEnglewoodCliffs,NJ07632
CustomerServiceandTechnicalSupport:(800)243-0000
Dimensionsandweightsareapproximate.Design,featuresandspecifications
subjecttochangewithoutnotice.
©2010LGElectronicsUSA,Inc.Allrightsreserved.“LGLife’sGood”isa
registeredtrademarkofLGCorp.Allotherproductandbrandnamesare
trademarksorregisteredtrademarksoftheirrespectivecompanies.
CAPACITY – LFC25776
Refrigerator 17.7cu.ft.
Freezer 7.3cu.ft.
Total 25.0cu.ft.
CAPACITY – LFC21776 (Counter Depth)
Refrigerator 14.7cu.ft.
Freezer 6.0cu.ft.
Total 20.7cu.ft.
FEATURES
EnergyRating EnergyStar
FreezerDoorType Drawer
Multi-AirFlowCooling •
DigitalTemperatureControls InternalLEDTouchPad
DigitalTemperatureSensors 5
LoDecibel™Operation •
DoorAlarm •
REFRIGERATOR
No.ofShelves 4Split
Slide-OutShelves 4
CantileveredShelves •
ShelfConstruction SpillProtector™TemperedGlass
CrisperBins 2HumidityCrispers/1BonusDrawer
GlideN’Serve™Drawer •
UtilityBin 2PieceBin(withcover)
RefrigeratorLight PremiumLED
REFRIGERATOR DOOR
No.ofShelves/Bin 6(5AdjustableGallonSize)
DairyCorner •
FREEZER
Drawers 2
WireDrawer •
DuraBase™SolidDrawerBase •
Divider •
FreezerDoorBin 1Tilting(LFC25776only)
IcePlus™ •
IceBin •
FreezerLight 60W
MATERIALS AND FINISHES
FoamDoorInsulation •
ContourDoors •
HiddenHinges •
ToeGrille •
Surface CoatedMetal,StainlessSteel
Back Flush&Metalcoverovermechanicalparts
AvailableColors(LFC25776) SmoothWhite(SW),SmoothBlack(SB),
 StainlessSteel(ST)
AvailableColors(LFC21776) StainlessSteel(ST)
Handles MatchingCommercialHandles
DIMENSIONS/CLEARANCES/WEIGHT – LFC25776
DepthwithHandles 341/4"
DepthwithoutHandles 313/4"
DepthwithoutDoor 277/8"
Depth(TotalwithDoorOpen) 461/2"
HeighttoTopofCase 683/8"
HeighttoTopofDoorHinge 693/4"
Width 353/4"
Width(DoorOpen90°withHandle) 441/4"
Width(DoorOpen90°withoutHandle) 391/4"
DoorEdgeClearancewithHandle 41/2"
DoorEdgeClearancewithoutHandle 13/4"
InstallationClearance Sides1/8",Top1",Back1"
Weight(Unit/Carton) 302lbs./355lbs.
CartonDimensions(WxHxD) 38"x73"x37"
DIMENSIONS/CLEARANCES/WEIGHT – LFC21776
DepthwithHandles 30"
DepthwithoutHandles 271/2"
DepthwithoutDoor 235/8"
Depth(TotalwithDoorOpen) 421/4"
HeighttoTopofCase 683/8"
HeighttoTopofDoorHinge 693/4"
Width 353/4"
Width(DoorOpen90°withHandle) 441/4"
Width(DoorOpen90°withoutHandle) 391/4"
DoorEdgeClearancewithHandle 41/2"
DoorEdgeClearancewithoutHandle 13/4"
InstallationClearance Sides1/8",Top1",Back1"
Weight(Unit/Carton) 278lbs./333lbs.
CartonDimensions(WxHxD) 38"x73"x33"
WARRANTY
 1YearPartsandLabor,
 7YearsontheSealedSystem,
 10YearsonLinearCompressor
UPC CODES
LFC25776SW SmoothWhite 048231783569
LFC25776SB SmoothBlack 048231783576
LFC25776ST StainlessSteel 048231783583
LFC21776ST CounterDepth–StainlessSteel 048231783811
