LG STB 3000 User Manual Commercial Mode Setup Guide 206 4272 Comm Rev I

2017-02-03

User Manual: LG STB-3000 Commercial Mode Setup Guide (Commercial Mode Setup Guide)

Open the PDF directly: View PDF .
Page Count: 90

EZ-Manager Wizard

pages 16 – 25

Custom Master STB Setup

pages 41 – 43

Cloning Procedures

pages 44 – 50

EXPERIENCED INSTALLER

STB-3000

(webOS 2.0)

HD Commercial Interface Set-top Box

•

Interactive Pro:Centric ®

Functionality

RF or IP Content Delivery

Commercial Mode Setup Guide

Note: Screen examples and procedural

text in Revisions H and later of this

document correspond to the webOS 2.0

operating system, which is available with

CPU v4.10.50 and later software. Please

refer to earlier revisions of this document

for sample screens and text pertaining to

webOS 1.0.

2206-4272

MODEL and SERIAL NUMBER

The model and serial numbers of this STB are located on the

back of the cabinet. For future reference, LG suggests that you

record those numbers here:

Model No._________________ Serial No._______________

WARNING:

TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER-

SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

WARNING:

This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive

harm. Wash hands after handling.

NOTE TO CABLE/TV INSTALLER:

This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electrical Code

(U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be

connected to the grounding system of the building, as close to the point of the cable entry as practical.

REGULATORY INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION:

Do not attempt to modify this product in any way without written authorization from LG Electronics U.S.A., Inc.

Unauthorized modification could void the user’s authority to operate this product.

COMPLIANCE:

The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc.

1000 Sylvan Avenue, Englewood Cliffs, NJ 07632, USA • Phone: 1-201-816-2000

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

For Customer Support/Service, please call:

1-888-865-3026

The latest product information and documentation is

available online at:

www.lg.com/us/commercial

Marketed and Distributed in the United States by LG Electronics U.S.A., Inc.

1000 Sylvan Avenue, Englewood Cliffs, NJ 07632

206-4272

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accor-

dance with the manufacturer’s instructions.

8. Do not install near any heat sources, such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding-type plug

has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If

the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched,

particularly at plugs, convenience receptacles, and the

point where it exits from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer or sold with the apparatus.

When a cart is used, use caution when moving the cart/

apparatus combination in order to avoid injury from

tip-over.

13.

Refer all servicing to qualied service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally,

or has been dropped.

14. Never touch this apparatus or antenna during a thunder or

lightning storm.

15. When mounting an STB on the wall, make sure that none of

the electrical cabling bears any of the weight of the STB.

Install in accordance with the manufacturer’s instructions.

16. Power Cord

Caution: Check the STB specifications in the Owner’s

Manual to determine power requirements.

Periodically examine the cord of your appliance, and if its

appearance indicates damage or deterioration, unplug it,

discontinue use of the appliance, and have the cord replaced

with an exact replacement part by an authorized servicer.

Protect the power cord from physical or mechanical abuse,

such as twisting, kinking, or pinching or being closed in a

door or walked upon. Pay particular attention to plugs, wall

outlets, and the point where the cord exits the appliance.

Do not use a damaged or loose power cord. Be sure to grasp

the plug when unplugging the power cord. Do not pull on the

power cord to unplug the STB.

Do not stick metal objects or any other conductive material

into the power cord. Do not touch the end of the power cord

while it is plugged in.

17. Overloading

Do not connect too many appliances to the same AC power

outlet as this could result in fire or electric shock. Do not

overload wall outlets. Overloaded wall outlets, loose or

damaged wall outlets, extension cords, frayed power cords,

or damaged or cracked wire insulation are dangerous. Any of

these conditions could result in re or electric shock.

18. Outdoor Use/Wet Location

Warning: To reduce the risk of re or electrical

shock, do not expose this product to rain,

moisture or other liquids.

Do not touch the STB with wet hands. Do not install this

product near ammable objects such as gasoline or candles or

expose the STB to direct air conditioning.

Do not expose to dripping or splashing and do not place

objects lled with liquids, such as vases, cups, etc., on or over

the apparatus (e.g., on shelves above the unit).

19. Grounding

(Except for devices that are not grounded) Ensure that you

connect the earth ground wire to prevent possible electric

shock (i.e., an STB with a three-prong grounded AC plug must

be connected to a three-prong grounded AC outlet). If ground-

ing methods are not possible, have a qualied electrician install

a separate circuit breaker. Do not try to ground the unit by

connecting it to telephone wires, lightning rods, or gas pipes.

20. Disconnect Device

The power plug is the disconnecting device. The power plug

must remain readily accessible.

As long as this unit is connected to the AC wall outlet, it is not

disconnected from the AC power source even if the unit is

turned off.

(Continued on next page)

IMPORTANT SAFETY INSTRUCTIONS

PORTABLE CART WARNING

4206-4272

(Continued from previous page)

21. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the

product, follow the precautions below.

An outdoor antenna system should not be located in the

vicinity of overhead power lines or other electric light or power

circuits or where it can come into contact with such power

lines or circuits as death or serious injury can occur.

Be sure the antenna system is grounded so as to provide

some protection against voltage surges and built-up static

charges.

Article 810 of the National Electrical Code (NEC) in the U.S.A.

provides information with respect to proper grounding of the

mast and supporting structure, grounding of the lead-in wire

to an antenna-discharge unit, size of grounding conductors,

location of antenna-discharge unit, connection to grounding

electrodes, and requirements for the grounding electrode.

Antenna Grounding According to NEC, ANSI/NFPA 70

22. Cleaning

When cleaning, unplug the power cord and wipe gently with

a soft cloth to prevent scratching. Do not spray water or other

liquids directly on the STB as electric shock may occur. Do not

clean with chemicals such as alcohol, thinners or benzene.

23. Transporting Product

Make sure the STB is turned Off and unplugged and that

all cables have been removed. Do not press against or put

stress on the STB.

24. Ventilation

Install the STB where there is proper ventilation. Do not

install in a conned space such as a bookcase. Do not cover

the STB with cloth or other materials (e.g., plastic) while it is

plugged in. Do not install in excessively dusty places.

25. If you smell smoke or other odors coming from the STB or

hear strange sounds, unplug the power cord, and contact an

authorized service center.

26. Keep the product away from direct sunlight.

27. Do not install this product on a wall if it could be exposed to

oil or oil mist. This may damage the product and cause it to

fall.

28. Do not allow an impact shock or any objects to fall into the

product.

29. Do not touch the ventilation openings, as they may become

hot while the STB is operating. This does not affect the per-

formance of the product or cause defects in the product.

30. Do not use high voltage electrical equipment near the STB

(e.g., a bug zapper). This may result in product malfunction.

IMPORTANT SAFETY INSTRUCTIONS

Antenna Lead in Wire

Antenna Discharge Unit

(NEC Section 810-20)

Grounding Conductor

(NEC Section 810-21)

Ground Clamps

Power Service Grounding

Electrode System (NEC

Art 250, Part H)

Ground Clamp

Electric Service

Equipment

206-4272

Table of Contents

Safety Warnings .................................. 2

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 3 – 4

Table of Contents ................................. 5

STB-3000 Introduction / Setup Checklist............. 6

Introduction .................................... 6

Setup Checklist ................................. 6

STB-3000 Cabling Connections ..................7 – 9

Before You Begin ............................... 7

Connect the STB to the Display Panel ............... 7

STB-3000 Cabling Diagram ....................... 9

Commercial Mode Overview ...................10 – 12

Pass-through Mode............................. 10

FTG Mode.....................................11

Determining the STB Operating Mode . . . . . . . . . . . . . . 12

Pro:Centric Operation ........................13 – 14

Pro:Centric Interactive Menu Features .............. 13

Pro:Centric Interactive Menu Navigation ............ 13

Pro:Centric Setup .............................. 14

Setting the Video Output Resolution ............... 15

EZ-Manager Wizard ..........................16 – 25

Before You Begin .............................. 16

Initiate Configuration or Exit the EZ-Manager Wizard .. 17

STB Configuration Options ........................ 18

Zones and Room Number Assignments ............. 18

Configure Pro:Centric Settings .................... 20

USB Configuration ............................. 24

Ez Download Utility ..........................26 – 29

Before You Begin .............................. 26

Accessing and Using the Ez Download Utility ........ 26

Installer Menu ...............................30 – 40

Accessing the Installer Menu ..................... 30

Using the Installer Menu ......................... 31

Exiting the Installer Menu and Activating Settings ..... 31

Custom Master STB Setup ................... 41 – 43

Before You Begin .............................. 41

Clonable STB Setup Menu Features ............... 41

Custom Master STB Setup Procedure .............. 42

Cloning Procedures ..........................44 – 50

Exporting a Clone File .......................... 44

Importing a Clone File........................... 46

FTG File Manager Utilities Overview.............51 – 56

Creating an FTG Configuration File ................ 51

FTG File Manager Main Screen ................... 53

FTG Channel Map Configuration Utility ............. 54

FTG Channel Map Editor ........................ 55

FTG Installer Menu Configuration Utility............. 56

IP Environment Setup ........................57 – 64

Accessing the IP Environment Menu ............... 57

Network Configuration .......................... 57

Pro:Centric Setup .............................. 61

Media Share Setup ............................. 63

Pre-loaded Applications ......................... 64

References

Updating STB Software using a USB Memory

Device......................................65

–

Display Panel Specifications ....................... 67

STB Aux Input Configuration ....................... 68

Auto Input(s) Sensing Feature ...................... 69

Restoring Factory Defaults on the STB(s) ............. 70

Using the STB’s Zoning Features ................71 – 74

Using Media Share Features ....................75 – 79

STB-3000 Jack Panels............................ 80

External IR Receiver Specications................... 81

External Audio Line Out Specications ................ 82

Installer Remote Typical Key Functions ............... 83

STB Installer Remote ............................. 84

Troubleshooting ..............................85 – 87

General Troubleshooting......................... 85

STB Quick Check ............................... 86

Commercial Mode Check ........................ 87

Glossary of Terms ............................... 88

Document Revision History / Open Source Software Notice 89

Back Cover..................................... 90

Notes

• Installer Menu content is intended for use primarily by qualied TV electronics technicians.

• Refer to the STB-3000 Owner’s Manual for additional information on STB installation, specications, maintenance, and safety instructions.

• Design and specications subject to change without prior notice. This document provides examples of typical screen displays. Your displays

may vary from those shown in this document.

6206-4272

STB-3000 Introduction / Setup Checklist

Introduction

The STB-3000 set-top box is designed to be connected to a compatible commercial display panel to

create a system that can provide Pro:Centric ® functionality, as well as either RF or IP content delivery.

The STB-3000 may be used with LG Commercial Hospitality TVs (LP645H, LT670H, etc.) that support

Multiple Protocol Interface (MPI), or the STB-3000 may be used with LG Commercial Public Display TVs

(LD450C, LT560C, etc.) or LG Commercial Monitors (M3203CCBA, M3204C, etc.) that support the

TV-Link Monitor (TLM) interface. The STB-3000 may also be used with commercial non-LG TVs that

support SONIFI’s Multiple Television Interface (MTI) protocol.

Setup Checklist

See also the STB-3000 Owner’s Manual for information on STB installation and hardware and cable

connections.

Installation and Setup

__ Unpack the STB and all accessories.

Accessories provided:

• AC/DC Power Adapter

• HDMI Cable

• MPI/MTI Cable (proprietary cable for LG MPI or SONIFI MTI control of display panel)

• TLM Cable (proprietary cable for LG TLM control of display panel)

• A/V Adapter Cable

__ Obtain an LG Installer Remote for configuration purposes.

If you are connecting the STB to an LG display panel, the LG remote provided with the display should

be sufficient. If you are connecting the STB to a non-LG display panel or if you intend to use multiple

STBs/displays in a single room installation environment, an LG Installer Remote dedicated to STB

control is available for purchase. For additional information and/or to purchase an STB Installer

Remote, contact your LG service representative. See also Reference section, “STB Installer Remote.”

__ Determine the installation location for the STB and display panel stand or mount.

__ Determine mounting and installation requirements, for example, AC power source outlet, antenna/cable

service connectors, any external equipment required for system operation, all necessary cables, wires,

and connectors, and any other additional required hardware, etc.

__ Install the display panel on VESA mount or stand.

Note: It may be advisable to make all cable connections before installing on VESA mount or stand.

Hardware Connections

__ Install any additional hardware as appropriate to your institution, LAN, etc.

Cable Connections

__ Make all required connections to the STB jack panels, as described in this document.

Commercial Mode Setup

__ Complete appropriate procedures as described in this document for Commercial Mode operation.

206-4272

STB-3000 Cabling Connections

This section describes how to connect the STB-3000 to establish communication with a compatible

commercial display panel (LG Hospitality TV, LG Public Display TV, LG Commercial Monitor, or

commercial non-LG TV with MTI support).

Before You Begin

Refer to the appropriate subsection(s) below before proceeding to connect the STB. In particular,

make sure each display panel is in the proper, known state.

LG Display Panel Prerequisites

• The display panel should be in a known state. That is, the display panel should be either in a

factory default state or custom congured (in its default mode) with selected settings, for example,

the aspect ratio, that you wish to use in conjunction with the STB (see also bullet below).

• If you are using the STB with a commercial LG display panel that supports the Data Channel

Auto Search feature (for example, LT777H, LP870H, etc.), set Installer Menu item 119 DATA

CHANNEL on the display panel to 0 before connecting the STB.

• For newer LG Public Display TVs, when you power ON the TV for the rst time, a Welcome

Wizard will be displayed, and you will need to complete the rst two steps of the wizard before

you can successfully connect the STB. First, you will need to select the Language (Step 1), and

then you will need to select the Mode Setting (Step 2). For Step 2, you MUST select “Home

Use.” After this, you can either continue with the wizard and select additional desired conguration

settings, or you can use the EXIT key on the remote to exit the wizard.

Commercial Non-LG Display Panel Prerequisites

• The display panel must be in a known state; however, note that you may need to perform initial

steps to configure the display (i.e., the TV) and/or its MTI port for MTI communication. Refer to

the manufacturer’s documentation for further information.

• It is highly recommended that you set the display’s start channel/Power On source to HDMI1

since the STB default conguration automatically sends Television/Display Control commands to

switch the connected display panel to its HDMI1 input. Because some non-LG displays default

to an RF channel at turn ON (or at loss of communication), setting the Power On source to

HDMI1 will eliminate the potential for momentary signal interruption from the STB each time the

STB/display is turned ON. This will also eliminate the potential for temporary signal interruption

from the STB when the STB’s PTC is being updated.

LG Installer Remote

• An LG Installer Remote (not supplied) is required to complete the procedure below, as well as

STB/display panel conguration procedures in this document. If you are connecting the STB

to an LG display panel, the LG remote provided with the display should be sufcient. However,

if you are connecting the STB to a non-LG display panel or if you wish to take advantage of the

STB’s multi-code feature, LG’s STB-dedicated Installer Remote will be required. See Reference

sections, “Installer Remote Typical Key Functions” and “STB Installer Remote,” for further

information.

8206-4272

STB-3000 Cabling Connections (Cont.)

Connect the STB to the Display Panel

This procedure only describes the essential STB/display panel connections. See Reference section,

“STB-3000 Jack Panels,” for further information on the additional jack panel ports and connectors.

1. Turn ON the display panel.

2. Refer to the STB-3000 Cabling diagram on page 9, and complete the following connections:

a) Make the appropriate Television/Display Control connection between the STB-3000 and the

display panel. (See also * on following page.)

• For LG Hospitality TVs: Use the MPI/MTI cable provided to connect MPI/MTI TELEVISION

CONTROL on the STB-3000 front jack panel to the MPI port on the rear jack panel of the

display.

• For LG Public Display TVs or LG Commercial Monitors: Use the TLM cable provided to

connect RS-232C TELEVISION CONTROL on the STB-3000 rear jack panel to the DB9

RS-232 CONTROL connector on the rear jack panel of the display.

• For commercial non-LG TVs: Use the MPI/MTI cable provided to connect MPI/MTI

TELEVISION CONTROL on the STB-3000 front jack panel to the MTI (typically labeled

“DATA”) port on the rear jack panel of the display.

b) Use the HDMI cable provided to connect HDMI OUT on the STB-3000 rear jack panel to the

HDMI1 input connector on the rear jack panel of the display. (See also ** on following page.)

c) For RF delivered content, connect a 75 ohm coaxial wire from the Antenna/CATV wall jack to

ANTENNA/CABLE IN on the STB-3000 rear jack panel. For IP delivered content, connect an

RJ-45 Ethernet (CAT5) cable from the institution’s network to the LAN port on the STB-3000

rear jack panel.

d) Insert the DC power plug of the AC/DC power adapter provided into the POWER connector

on the rear jack panel of the STB-3000, and then plug the AC/DC adapter into a standard

120V 60 Hz AC power outlet.

Once power is applied to the STB-3000, the LED on the STB’s front jack panel will light

steadily, indicating that the STB is in standby mode. Also, the display panel will be turned

OFF by the STB as soon as the STB is powered and establishes Television/Display Control

communication with the display.

Note: Once Television/Display Control communication is established between the STB-3000

and the display panel, the STB-3000 will be in control of the display panel, and certain resident

panel functions, like panel buttons, typically will no longer operate.

3. Use the Installer Remote to turn ON the STB/display panel.

While the STB is turning ON and sending the turn ON command to the display, the STB LED

blinks at a constant rate. Once both the STB and the display panel are ON, the STB LED

remains lit but blinks off twice in rapid succession every ve seconds. The rst image you should

see on the display panel is a prompt to select the video output resolution (see “Setting the Video

Output Resolution” on page 15).

4. Select the video output resolution (i.e., the STB’s video output format), and complete the

appropriate Commercial Mode setup procedures, as described in this document.

Note: It is recommended that you complete STB-3000 Commercial Mode setup procedures before

you make external equipment connections to the STB-3000.

206-4272

STB-3000 Cabling Connections (Cont.)

IN 1

(ARC)

IN 2

USB IN 2

USB IN 1

OUT

LAN

DIGITAL

AUDIO

IR IN

SERVICE

AV IN

AUDIO

LINE OUT

ANTENNA/

CABLE IN

STB-3000 Front Panel

STB-3000 Rear Panel

EXT MPI

CONTROL

RS-232C

TELEVISION

CONTROL

POWER

MPI/MTI

TELEVISION

CONTROL

c) & d) Complete STB Power

and Antenna/Cable connections.

b) Connect HDMI OUT

on STB to HDMI IN on

display panel. **

a) Connect RS-232C

TELEVISION CONTROL to LG

Public Display or Commercial

Monitor display panel DB9

RS-232 connector. *

* Only one Television/Display Control connection should be used. The proper connection depends on

the type of display panel to be controlled. Also, note that on early STB-3000 models, the RS-232C

TELEVISION CONTROL jack is labeled “DISPLAY CONTROL 1” and the MPI/MTI TELEVISION

CONTROL port is labeled “DISPLAY CONTROL 2.”

** The STB default conguration automatically sends Television/Display Control commands to switch the

connected display panel to its HDMI1 input.

a) Connect MPI/MTI

TELEVISION CONTROL to LG

Hospitality display panel MPI

port or to commercial non-LG

display panel MTI (DATA) port. *

STB-3000 Cabling Diagram

more on the Installer Remote.

18 206-4272

EZ-Manager Wizard (Cont.)

STB Conguration Options

From the STB Conguration Options screen, you can choose how to proceed with the conguration

of this STB/display (assuming you do not opt to exit the wizard, which you may also do at any time).

Note: If you intend to use the Zoning feature(s) on the STB for location-specic

conguration purposes, select the “Zones & Room Number” option from this screen

and assign the appropriate TV Zone # and/or the Wi-Fi Zone # in the STB BEFORE

you continue with additional conguration.

STB CONFIGURATION OPTIONS

NEXTUSB CONFIGURATION

To conﬁgure the STB for Pro:Centric operation, select NEXT.

. To set the optional Zoning features, select ZONES & ROOM NUMBER.

. To conﬁgure the STB using a USB memory device, select USB CONFIGURATION.

This setup wizard will continue automatically in 60 seconds.

ZONES & ROOM NUMBER

EXIT

Note: If there is no user action in this screen within one minute, the wizard will automatically

continue to the next conguration step.

Use the Left/Right arrow keys on the Installer Remote to navigate between options on this screen.

Each time you select/highlight one of the following options, the screen text and elds will change in

accordance with your selection.

• To continue with Pro:Centric conguration, select NEXT (default) and press OK on the Installer

Remote. Refer to “Congure Pro:Centric Settings” on pages 20 to 24 for additional information.

• To set the Zoning feature(s) on the STB, select ZONES & ROOM NUMBER. See “Zones and

Room Number Assignments” below for further information.

• To access the STB Manager / USB download options, select USB CONFIGURATION. See “USB

Conguration” on pages 24 to 25 for further information.

Note: If you choose to exit the EZ-Manager Wizard from this point on, you will have the option to

save any settings made by selecting SAVE & EXIT in the exit conrmation pop-up window. Or, you

can exit the wizard without saving any settings by simply selecting OK in the conrmation pop-up

window.

Zones and Room Number Assignments

You may complete one or more of the elds in the Zones, Label, and Room Number screen or

leave them at their default settings (TV Zone and Wi-Fi Zone) or blank (Label and Room Number),

as desired. However, if you intend to use either of the Zoning features—TV Zoning and/or Wi-Fi

Zoning—on this STB, you MUST specify the appropriate values in the TV Zone and/or Wi-Fi Zone

elds as described on the following page. See also Reference section, “Using the STB’s Zoning

Features,” for further information.

206-4272

EZ-Manager Wizard (Cont.)EZ-Manager Wizard (Cont.)

Note: Zoning features are only applicable for STBs that will be congured using a “.tlx” le (local or

remote conguration).

ZONES, LABEL, AND ROOM NUMBER

NEXTUSB CONFIGURATION

. If creating Wi-Fi Zones for AP settings, select the appropriate Wi-Fi Zone #

(1-99) based on the Wi-Fi Zone in which this STB is installed.

. If creating Zones for Installer Menu settings and/or Channel Mapping,

select the appropriate TV Zone # (0-8) based on the Zone in which this STB

is installed.

(See Commercial Mode Setup Guide for more information.)

. Select a Label and/or input the Room Number, as required.

. When done, select NEXT to continue.

ZONES & ROOM NUMBER

EXIT

Wi-Fi Zone

TV Zone

Label

-----

Room Number

1. Complete the appropriate eld(s) as described below. Use the Left/Right arrow keys on the

Installer Remote to navigate between each of the elds.

• Wi-Fi Zone: Enables you to set a Wi-Fi Zone # so that the STB can be congured with a

particular access point’s login data for wireless networking. Login data (i.e., SSID, security

type, and security key) may be provided in a Clone/Conguration (.tlx) le.

To assign a Wi-Fi Zone, navigate to the Wi-Fi Zone eld at the top left of the screen, and use

the Left/Right arrow keys to specify the desired Wi-Fi Zone # (1–99).

• TV Zone: Enables you to set a TV Zone # so that the STB can be congured with Installer

Menu and/or TV Setup Menu settings intended only for the assigned Zone. The Installer

Menu and/or TV Setup Menu settings may be provided in a Clone/Conguration (.tlx) le. If

the STB is being congured for FTG Mode, the TV Zone # setting also allows the STB to omit

channels that have been restricted in the FTG Channel Map.

To change the TV Zone from its default value (0), navigate to the TV Zone eld, and use the

Left/Right arrow keys to specify the desired TV Zone # (1–8).

• Label: Allows you to select a North, South, East, or West text label for this STB. In the Label

eld, use the Left/Right arrow keys to select the applicable label.

• Room Number: Allows you to specify the number of the room—up to 16 characters—in which

the TV is located. To enter a room number, navigate to the Room Number eld and press OK.

You can then use the number keys on the Installer Remote to direct enter a room number,

or you can use the arrow keys to select the appropriate alphanumeric character(s) from the

pop-up virtual keyboard at the bottom of the screen. When you are done, select Enter from the

virtual keyboard, and then press OK on the Installer Remote.

2. When you are ready to continue, select the appropriate option, as follows:

• To proceed to the next EZ-Manager screen, use the arrow keys to select NEXT, and then

press OK on the Installer Remote. Continue to the “Congure Pro:Centric Settings” section

on the following page.

• To use a USB memory device to complete the conguration, continue to “USB Conguration”

on pages 24 to 25.

20 206-4272

EZ-Manager Wizard (Cont.)

Congure Pro:Centric Settings

Once you select “NEXT” from the STB Conguration Options screen, the Searching for Pro:Centric

Server screen is displayed.

Note: Select the “BACK” button, where available, to check previous settings, as necessary.

SEARCHING FOR PRO:CENTRIC SERVER...

EXIT

This step automatically searches for the Pro:Centric Server.

If there is no Pro:Centric server installed, you do not need to continue with this procedure.

Please select either EXIT or MANUAL PRO:CENTRIC.

Status: Tuning channel 30

STB is now searching the pre-deﬁned channels for the data channel...

MANUAL PRO:CENTRICBACK

You have the following options:

• You can allow the EZ-Manager Wizard to proceed with a series of automated steps to congure

the STB for Pro:Centric operation and then to look for the Pro:Centric application and maintenance

(E-Z Installation) les to download. In this case, the wizard uses a search algorithm to determine

the Data Channel and the Pro:Centric Application Mode to set in the STB.

Continue with the “Automated Pro:Centric Conguration” subsection below.

• If you already know the settings (i.e., Data Channel and Pro:Centric Application Mode) that need

to be congured in order for the STB to connect to the Pro:Centric server and/or if the Pro:Centric

server is not yet installed, you may expedite the setup process by entering this data manually.

Continue with the “Manual Pro:Centric Conguration” subsection on page 22.

Automated Pro:Centric Conguration

Note: If the server is not yet congured on the system, use the manual conguration option to

congure the Pro:Centric operation. See also note below.

Note: If Pro:Centric data delivery will be over IP and there is a DNS server at the site, you can

create a DNS entry “procentric.local” for the Pro:Centric server that will enable automated

Pro:Centric IP conguration via the EZ-Manager. If there is no DNS entry for procentric.local, you

must use the manual conguration option to congure the Pro:Centric IP operation.

Once the Pro:Centric data channel is found (a Pro:Centric Server Was Found screen will be

displayed) and the Pro:Centric Application Mode is determined, the wizard will advance to the

Processing the Pro:Centric Conguration screen, which shows the progress of the data

downloads (see example on following page). Note that some steps may require a few minutes.

(Continued on next page)

206-4272

EZ-Manager Wizard (Cont.)

(Continued from previous page)

If the process is successful, no further user interaction is required, though, in some instances, where

the option (for example “NEXT”) is available, you may manually move forward to subsequent steps

within the wizard to speed up the process.

PROCESSING THE PRO:CENTRIC CONFIGURATION

Downloading the Pro:Centric application ﬁles takes a few minutes.

Please wait...

Retrieving ﬁles from data channel 70

Application ﬁles In progress...

Maintenance Files Synchronizing...

Warning - Do not remove AC power or the signal cables during these steps.

Note: If, after completing the search, the STB is unable to nd the Pro:Centric data channel (while

the Searching for Pro:Centric Server screen is on display), the wizard will stop and show a

Diagnostics screen that enables you to manually return to the previous screen (to reinitiate the

conguration) or exit the wizard.

When the Pro:Centric Conguration is complete, an EZ-Manager Conguration Complete screen is

displayed (see example below), and after 10 seconds, the wizard exits, and the STB turns OFF.

Installed Components

Pro:Centric Application GEM application downloaded

Maintenance Files LY970H_Conﬁg.tlx

TURN OFF

REBOOT

EZ-MANAGER CONFIGURATION COMPLETE

STB will turn o in 10 second(s)

Installed Components

Pro:Centric Application GEM application downloaded

Maintenance Files STB-3000_Conﬁg.tlx

TURN OFF

REBOOT

Note: With the EZ-Manager Conguration Complete screen on display, you can also manually turn

off or reboot the STB. If desired, select TURN OFF or REBOOT, respectively, and then press OK

on the Installer Remote.

22 206-4272

EZ-Manager Wizard (Cont.)

Manual Pro:Centric Conguration

1. With the Searching for Pro:Centric Server screen on display, use the Left/Right arrow keys on

the Installer Remote to select MANUAL PRO:CENTRIC at the bottom right of the screen, and

then press OK.

In the Pro:Centric Manual Conguration screen (see examples below), you will be able to

congure the appropriate Pro:Centric settings in the STB. Use the Up/Down arrow keys on the

Installer Remote to navigate between elds.

PRO:CENTRIC MANUAL CONFIGURATION

EXIT

Pro:Centric Mode

Media Type

Data Channel

Signal Strength

Signal Quality

CONFIGURATION ONLY

SEARCHBACK

No Signal

PRO:CENTRIC MANUAL CONFIGURATION

EXIT

Pro:Centric Mode

Media Type

IP Address

IP Port

255 255 255 255

SEARCHBACK

IP server not found

CONFIGURATION ONLY

2. In the Pro:Centric Mode eld, use the Left/Right arrow keys to select the appropriate Pro:Centric

Application Mode—FLASH, GEM, HTML, or CONFIGURATION ONLY.

Note: For remote management only, select CONFIGURATION ONLY. The STB will search for

E-Z Installation data downloads; however, Pro:Centric application data will not be downloaded,

i.e., Installer Menu item 098 PRO:CENTRIC will be set to 0.

3. Refer to the appropriate subsection below, depending on the Pro:Centric server conguration, to

complete the remaining elds.

Pro:Centric Manual Configuration Screen

with RF Media Fields

Note: By default, the Pro:Centric Manual

Conguration screen initially shows RF

conguration elds.

Pro:Centric Manual Configuration Screen

with IP Media Fields

(Continued on next page)

206-4272

* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.

EZ-Manager Wizard (Cont.)

(Continued from previous page)

RF Conguration

a) In the Media Type eld, use the Left/Right arrow keys to select RF.

b) In the Data Channel eld, use the Left/Right arrow keys to select the RF channel number

that will be used by the Pro:Centric server as its data channel. The Data Channel value can

be set from 1 to 135. *

IP Conguration

a) In the Media Type eld, use the Left/Right arrow keys to select IP.

Note: When you select “IP” as the Media Type, the default RF Data Channel and Signal

Strength/Quality elds are replaced with IP Address and IP Port elds.

b) Enter the Pro:Centric server IP address and port number in the IP Address and IP Port elds,

respectively. The IP address must match the IPv4 multicast address and the port number

must match the port number that is set in the Pro:Centric server.

For each data entry eld: Use the arrow keys to select the eld and press OK. Then, you can

either use the number keys on the Installer Remote to direct enter data values, or you can use

the arrow keys to select the appropriate number(s) from the pop-up virtual keyboard displayed

at the bottom of the screen. When you are done, select Enter from the virtual keyboard, and

then press OK on the Installer Remote.

4. Once all elds are completed as required, you have two options:

• To save the data entered and exit the wizard, use the arrow keys to select EXIT and then press

OK. In the subsequent pop-up conrmation window, select SAVE & EXIT, and then press OK

once more. The Pro:Centric application and/or E-Z Installation data will be downloaded to the

STB at a later time. This option is useful, in particular, if the Pro:Centric server has not yet been

congured.

• To initiate a real-time download of Pro:Centric application and/or E-Z Installation data, use the

arrow keys to select SEARCH and press OK to verify the conguration data provided in step 3.

When the data is veried, the “SEARCH” button becomes a “NEXT” button. Select NEXT and

press OK to continue (see also note below).

Note: With RF conguration, Pro:Centric server data must be present on the RF channel

selected as the STB’s Data Channel in order for you to select “NEXT” (you will see a “data

channel found” message below the Signal Quality indicator). With IP conguration, Pro:Centric

server data must be present via the wired LAN cable connection in order for you to select

“NEXT” (you will see a “IP server found” message below the IP Port eld).

If you opt to initiate a real-time download in the last step, the EZ-Manager Wizard will proceed with

the Pro:Centric application and/or E-Z Installation data downloads (see Processing the Pro:Centric

Conguration screen example on page 21). When the Pro:Centric conguration is complete, an

EZ-Manager Conguration Complete screen (see example on page 21) is displayed, and after 10

seconds, the wizard exits, and the STB turns OFF.

Note: With the EZ-Manager Conguration Complete screen on display, you can also manually turn

off or reboot the STB. If desired, select TURN OFF or REBOOT, respectively, and then press OK

on the Installer Remote.

24 206-4272

USB Conguration

The STB Manager / USB download options enable you to download conguration or software

les individually from a USB memory device to the STB. You can also use the Ez Download utility

available from the menu to select one of each type of le to be downloaded at one time using one

process.

Each of the USB download functions requires that you have the appropriate le(s) loaded on a

USB memory device. If you wish to perform a software update, the software update le(s) must

be stored in a folder named “LG_DTV” in the root directory of the USB memory device. Clone/

Conguration (.tlx) les should simply be stored in the root directory of the USB device.

The procedure below assumes the desired le(s) is/are already loaded onto the USB device. For

further information on the STB Manager / USB download options and le requirements, and/or for

information on creating Clone/Conguration (.tlx) les, refer to the appropriate section(s) in this

document.

Before You Begin

• If you intend to use the Zoning feature(s) on this STB, make sure to assign the appropriate TV

Zone # and/or Wi-Fi Zone # in the EZ-Manager’s Zones, Label, and Room Number screen

BEFORE continuing with USB Conguration. See “STB Conguration Options” on page 18 for

further information.

• Ensure the USB device to be used has been formatted with FAT format.

• When creating les to be downloaded, avoid using special characters (?, &, @, etc.) in lenames.

• Refer to “Ez Download Utility” on pages 26 to 29 for further information on the Ez Download utility.

• Refer to “Custom Master STB Setup” on pages 41 to 43 for information on creating a Clone (.tlx)

file, and/or refer to “Creating an FTG Conguration File” on pages 51 to 52 for information on

creating a FTG Conguration (.tlx) le for FTG Mode conguration.

• See Reference section, “Updating STB Software using a USB Memory Device,” for further

information on software updates.

USB Conguration via EZ-Manager Wizard

With either the STB Conguration Options or the Zones, Label, and Room Number screen on

display, proceed as follows to congure the STB/display using the USB memory device.

1. Insert the USB memory device with the appropriate le(s) into either of the STB’s USB ports.

2. Use the arrow keys on the Installer Remote to select USB CONFIGURATION, and then press

OK.

You will be redirected to the STB Manager / USB download options (see example below).

Note: You can select the EXIT button and press OK on the Installer Remote at any time to

return to the EZ-Manager Wizard.

Note: Ez Download is always selected by default when you initially access the STB Manager.

Also note that Diagnostics is for service use only.

EZ-Manager Wizard (Cont.)

(Continued on next page)

206-4272

EZ-Manager Wizard (Cont.)

(Continued from previous page)

Select the ﬁle(s) to download, and then select UPDATE below.

Update STB Software

STB_CPU_SW.epk

Update PTC Software

STB_PTC_SW.txt

Import Clone File

STB_IM.tlx

UPDATE

USB DEVICE

EXIT

STB MANAGER

USB 1:

Device Name

Ez Download

Update STB Software

Update PTC Software

Import Clone File

Diagnostics

Current STB SW Version:

version#

None

ﬁlename

.epk/Version:

version#

3. If more than one USB memory device is currently connected to the STB, be sure to select the

USB device that contains the le(s) you wish to use. If necessary, use the arrow keys on the

Installer Remote to select/highlight the USB DEVICE button at the top right of the screen and

press OK. Then, use the Up/Down arrow keys to select the appropriate USB device from the

pop-up list of USB devices displayed at the top of the screen.

4. Select the appropriate option from the STB Manager, and initiate the desired download(s).

Update progress will be shown on the screen. Do NOT remove the USB device while updates

are in progress. When the update process is complete, the STB will reboot.* Upon restart,

depending on the type of update(s) completed, either the EZ-Manager STB Configuration Options

screen will be redisplayed (only software was updated) or the STB will tune according to the

Start Channel setting in the Installer Menu (the STB was configured with a Clone/Configuration

file).

Note: If the STB Configuration Options screen is redisplayed (only software was updated),

you can either proceed with configuration via the EZ-Manager Wizard or exit the EZ-Manager

Wizard, as required.

Note: If you updated the STB configuration with a Clone/Configuration file that included a

change to Installer Menu item 105 VID OUT FORMAT, when the reboot is complete, you will be

prompted to conrm the new video output resolution. See item 105 description on page 38 for

further information.

5. Remove the USB memory device, and verify that the appropriate configuration/update(s) is/are

resident on the STB.

* STB-3000s with CPU software earlier than v3.00.70 will only reboot upon completion of a Clone/Configuration (.tlx) update if

the file included a change to Installer Menu item 105 VID OUT FORMAT (see also note regarding item 105 above).

26 206-4272

Ez Download Utility

The Ez Download utility, available from the STB Manager, enables you to select multiple les (one

of each le type) at one time from the les loaded on a USB memory device. You may use this utility

to download any one or all of the following to an STB: a Clone or FTG Conguration (.tlx) le, an STB

(CPU) software update, a PTC software update.

Before You Begin

• Ensure the USB device has been formatted with FAT format.

• Software update les must be stored in a folder named “LG_DTV” in the root directory of the USB

memory device. Clone/Conguration (.tlx) les should simply be stored in the root directory of the

USB device.

• If the EZ-Manager Wizard appears on the screen when you turn ON the STB/display, you can use

the wizard’s “USB Conguration” option to access the Ez Download utility (see “STB Conguration

Options” and/or “USB Conguration” on pages 18 and 24, respectively, as necessary).

• If the STB is currently in Pass-through Mode and you intend to use the Zoning feature(s) on this

STB for location-specic conguration purposes, make sure to assign the appropriate TV Zone #

and/or Wi-Fi Zone # in the STB when directed to do so in the procedure below.

• When creating les to be downloaded, avoid using special characters (?, &, @, etc.) in lenames.

• Refer to “Custom Master STB Setup” on pages 41 to 43 for information on creating a Clone (.tlx)

file, and/or refer to “Creating an FTG Conguration File” on pages 51 to 52 for information on

creating an FTG Conguration (.tlx) le for FTG Mode conguration.

• See Reference section, “Updating STB Software using a USB Memory Device,” for further

information on software updates.

Caution: Do not unplug the STB power cord or remove the USB memory device

during a data download, as doing so may cause the STB to malfunction or harm the

USB device, respectively.

Accessing and Using the Ez Download Utility

1. If it is not ON already, turn ON the STB/display panel.

2. The next step depends on whether the EZ-Manager Wizard appears on the screen when you

turn ON the STB/display:

• If the wizard is displayed, you can access the Ez Download utility via the wizard, as indicated

above (see “Before You Begin”). However, to continue with this procedure and access the Ez

Download utility from the STB menus, exit the EZ-Manager Wizard. Then, continue with step 3.

• If the wizard is not displayed, go directly to step 3.

3. If the STB is currently in Pass-through Mode, you would like to transfer (import) a “.tlx” le to the

STB via the Ez Download utility, and you intend to use one or both of the STB’s Zoning feature(s),

assign the appropriate TV Zone # and/or Wi-Fi Zone # in the STB at this time. See Reference

section, “Using the STB’s Zoning Features,” for further information.

Note: In order for the proper location-specic TV Zone and/or Wi-Fi Zone prole

data to be applied, the Zone designation(s) must be assigned in the Target STB(s)

BEFORE you continue with the Ez Download utility.

(Continued on next page)

206-4272

(Continued from previous page)

4. Insert the USB memory device with the appropriate le(s) into either of the STB’s USB ports.

5. To access the STB Manager from the STB menus:

• Press MENU on the Installer Remote to display the STB setup menus (STB is in Pass-through

Mode) or the Function Menu (STB is not in Pass-through Mode).

• If the Quick Settings Menu is displayed at the right of the screen (i.e., the STB is in Pass-

through Mode), select the Advanced menu icon and press OK to access the advanced

STB setup menus.

• Use the arrow navigation keys to select/highlight either the General menu icon from the STB

setup menus or the Safety menu icon from the Function Menu. Then, press the number “7”

key a total of seven times.

Note: Ez Download is always selected by default when you initially access the STB Manager.

Also note that Diagnostics is for service use only.

Select the ﬁle(s) to download, and then select UPDATE below.

Update STB Software

STB_CPU_SW.epk

Update PTC Software

STB_PTC_SW.txt

Import Clone File

STB_IM.tlx

UPDATE

USB DEVICE

EXIT

STB MANAGER

USB 1:

Device Name

Ez Download

Update STB Software

Update PTC Software

Import Clone File

Diagnostics

Current STB SW Version:

version#

None

ﬁlename

.epk/Version:

version#

6. If more than one USB memory device is currently connected to the STB, be sure to select the

USB device that contains the le(s) you wish to use. If necessary, use the arrow keys on the

Installer Remote to select/highlight the USB DEVICE button at the top right of the screen and

press OK. Then, use the Up/Down arrow keys to select the appropriate USB device from the

pop-up list of USB devices displayed at the top of the screen.

USB Device

USB 1: Device 1

USB 2: Device 2

7. If it is not currently selected, use the arrow keys to select Ez Download, and then press OK.

Ez Download Utility (Cont.)

(Continued on next page)

28 206-4272

Ez Download Utility (Cont.)

(Continued from previous page)

As illustrated above, when Ez Download is selected, a list of up to three les is displayed

on the screen, one each of the STB Software (CPU) and PTC Software les stored in the

LG_DTV folder and the Clone/Conguration (.tlx) les stored in the root directory on the USB

device.

Note: Press on the Installer Remote or select EXIT in the top right corner of the screen to

exit the STB Manager (if accessed from the STB menus, you may also press EXIT on the

Installer Remote to exit). If you accessed the STB Manager via the EZ-Manager Wizard, you will

be returned to the last screen on display before you selected the “USB Conguration” option.

If you accessed the STB Manager via the STB menus, you will be returned to program viewing.

8. To select a le:

• Use the arrow keys on the Installer Remote to select/highlight the appropriate le type eld,

and then press OK. A list of available les will be displayed to the right of the le type elds.

• Then, use the arrow keys to select the desired le.

Note: The utility will only allow you to select one of each le type for downloading. For example,

if there are two les in the Ez Download “Import Clone File” list, you can only select one or the

other of those two les.

Note: The initial default value for each le type is “None.” After the Ez Download utility is

run, a le is automatically created and stored on the USB device that was used. The le,

which will have a “.dzm” le extension, maintains a history of the le(s) previously used with

the Ez Download utility. The next time(s) you use this USB device with the Ez Download utility,

the le(s) selected for the last download will be pre-selected for the current download, thus

facilitating the process of conguring additional STB-3000s using the same USB device.

Note: The current STB software (CPU) or PTC software version is always displayed above

the listing of available STB software and PTC software les, respectively. Ensure the software

version of the selected le is the correct version before applying the update to this STB.

9. If a Clone/Conguration (.tlx) le that includes an FTG Channel Map is selected, a Channel

Tuning / Channel Banner Display eld will be displayed at the right of the screen. If the FTG

Channel Map comprises RF channels and Aux inputs only (the latter designated by 130-0

through 137-0), you can choose the format for the channel tuning/banner display. Use the

arrow keys on the Installer Remote to select Logical tuning or Physical tuning. A checkmark

will appear at the left of the selected option. Logical tuning is selected by default.

Note: If an FTG Channel Map includes IP channels, only logical tuning is available. Also, if

the selected “.tlx” le does not include an FTG Channel Map, the message, “No Channel Map

in Clone le,” will be displayed at the right of the screen.

10. When you are ready to continue, use the arrow keys on the Installer Remote to select UPDATE,

and then press OK.

Update progress will be shown in a new screen. Do NOT remove the USB device while

updates are in progress. When the Ez Download process is complete, an overview of the

results will briey be displayed and then, the STB will reboot. *

(Continued on next page)

* STB-3000s with CPU software earlier than v3.00.70 will only reboot upon completion of a Clone/Configuration update if the

Clone/Configuration (.tlx) file included a change to Installer Menu item 105 VID OUT FORMAT (see also note regarding item

105 on the following page).

206-4272

Ez Download Utility (Cont.)

(Continued from previous page)

11. Remove the USB memory device, and verify that the appropriate configuration/update(s) is/are

resident on the STB.

Note: If you updated the STB configuration with a Clone/Conguration file, upon restart (and, if

applicable, conrmation of new video output resolution—see note below), the STB tunes according

to the Start Channel setting in the Installer Menu. If a Start Channel is specied, the STB will

tune to that channel, though in the case of FTG Mode conguration, a channel banner will only

be displayed if the Start Channel is included in the FTG Channel Map (depending on your selection

in step 9, the channel banner will display either the Start Channel’s logical channel number or

physical RF channel number). Otherwise, the STB will either return to the last channel tuned (STB

in Pass-through Mode) or tune to the rst channel in the FTG Channel Map (STB in FTG Mode).

In the latter case, remember that the channels in the FTG Channel Map are always arranged in

logical order, regardless of your selection in step 9.

Note: If you updated the STB configuration with a Clone/Conguration file that included a change

to Installer Menu item 105 VID OUT FORMAT, when the reboot is complete, you will be prompted to

conrm the new video output resolution. See item 105 description on page 38 for further information.

30 206-4272

PTC INSTALLER MENU

STB_3000

CPU

CTV

000 INSTALLER SEQ 000

UPN 000-000-000-000 ASIC D279

PTC V#.##.### CPU V#.##.##.##

Installer Menu

Use the Installer Menu to set up, change, or view operational settings. This section describes how to

access, use, and exit the Installer Menu on location; however, you should also refer to the Installer

Menu descriptions in this document if you are conguring the STB using an FTG Conguration (.tlx)

le created using LG’s FTG File Manager software.

Refer to the table on pages 32 to 34 for brief descriptions of Installer Menu items. More detailed

descriptions follow the table listing.

Accessing the Installer Menu

1. Turn ON the STB/display panel.

If the EZ-Manager Wizard appears on the screen when you turn ON the STB/display, exit the

wizard.

2. Using an Installer Remote, press MENU repeatedly until the on-screen display of the setup

menus (if the STB is in Pass-through Mode) or the Function Menu (if the STB is not in

Pass-through Mode) no longer toggles, and then press the STB Installer Menu entry sequence

(e.g., 9-8-7-6) + EXIT to access the STB Installer Menu.

Note: The default Installer Menu entry sequence is “9876”; however, if Installer Menu item 000

INSTALLER SEQUENCE has been modied, the entry sequence may be one of three additional

options. See Installer Menu detailed descriptions for further information.

The Installer Menu opens with item 000 INSTALLER SEQ 000.

Note: If the password (entry sequence) is not entered or registered correctly, you will see the message

“ENTER STB PASSWORD 0000” at the top of the screen instead of the STB Installer Menu header.

Once you re-enter the correct password (e.g., press 9-8-7-6 + EXIT), the STB Installer Menu will display.

Note: If an LG Hospitality TV (for example, LP645H, LT670H, etc.) is being used as the display panel

(connected to MPI/MTI TELEVISION CONTROL on the STB) and you press the TV Installer Menu entry

sequence + OK, you will access the TV’s Installer Menu instead of the STB’s Installer Menu. The TV’s

Installer Menu is accessible as read-only.

Note: If the STB is not in Pass-through Mode, the Installer Menu is accessible as read-only. Also,

the TV Zone # will be indicated in the Installer Menu header under the conguration mode indicator

described on the following page.

Typical Installer Menu

The menu header identies this as the

STB-3000 Installer Menu. In the Installer

Menu footer, you can see the current

software versions of the STB, as indicated.

PTC Version CPU Version

206-4272

As part of the Installer Menu header (in all modes), two 3-character acronyms are displayed to

indicate the STB’s current conguration mode. The table below lists all possible mode identiers

for the STB-3000.

Acronym Description

CPU-CTV Pass-through Mode with Channel Lineup in CPU

CPU-FTG FTG Mode via CPU

CPU-P:C Application Tuning Mode via CPU

MPI-EXT External MPI Control

PTC-CTV Pass-through Mode with Channel Map in PTC

Using the Installer Menu

Refer to the table starting on the next page for an overview of the available Installer Menu items,

including their item numbers, functions, value ranges, and default values.

Installer Menu items not relevant to the STB are not present in the Installer Menu; therefore, some

numbers are missing. For example, item 006 will not appear. In addition, items that are dependent

on other Installer Menu item settings will not be initially accessible. For example, item 046 STRT

AUX SRCE will not display in the Installer Menu unless item 004 STRT CHANNEL is set to 0. See

Installer Menu detailed descriptions for further information.

Navigation within the Installer Menu

Use the Up/Down arrow keys on the Installer Remote to sequence through the available menu items,

or access an item directly by keying in the item number and then pressing MENU. For example, to

access the SLEEP TIMER option, which is item 015, press 0-1-5 + MENU.

Changing Installer Menu Settings

To change an Installer Menu item value, use the Left/Right arrow keys on the Installer Remote, or

enter a valid value directly. To save the new setting, press OK, or use the Up/Down arrow keys to

navigate to a new Installer Menu item if you have additional items to edit. Note that invalid values

will not be saved.

Exiting the Installer Menu and Activating Settings

After you have adjusted all required Installer Menu item settings, press OK once on the Installer

Remote to save your changes; then, press OK again to exit the Installer Menu. Any changes you

make will be stored in non-volatile memory.

Note: Each time you exit the Installer Menu in Pass-through Mode, all V-Chip (Parental Control)

settings in the STB are reset to their default values; that is, the Lock System, if previously enabled

from the Safety Menu, will now be disabled, and the individual Parental Control settings will be

restored to default values.

Installer Menu (Cont.)

Caution: Installer Menu settings may affect options available

from the STB setup menus or the Function Menu.

32 206-4272

Installer Menu (Cont.)

Installer Menu Items 000 through 069

Item Function Value Range Default Value Brief Description of Function

000 INSTALLER SEQ 0 – 3 0 Leave default set to 0.

001 POWER MANAGE 0 – 7 0 Selects the number of hours of inactivity allowed before the STB automatically

turns itself OFF. Set to 0 to disable Power Management.

002 AC ON 0 – 3 0 Set to 1 to enable STB/display panel to turn ON when AC power is applied. Set to

2 or 3 to enable Instant ON when AC power is applied. (See detailed descriptions.)

003 BAND/AFC 0 – 3 1 Selects Tuning Band: 0=Broadcast, 1=CATV, 2=HRC, 3=IRC

004 STRT CHANNEL 0 – 127, 253, 255 255

Channel tuned when STB/display panel is turned ON. (Set to 255 to tune to

channel tuned before STB/display turned OFF.)

005 CHAN LOCK 0 / 1 0If set to 1, cannot tune from current channel.

007 STRT VOLUME 0 – 63, 255 255 Volume level when STB/display panel is turned ON. (Set to 255 to use

volume level before STB/display turned OFF.)

008 MIN VOLUME 0 – 63 0 Sets minimum allowable volume setting.

009 MAX VOLUME 0 – 63 63 Sets maximum allowable volume setting.

010 MUTE DISABLE 0 / 1 0 Set to 1 to disable Mute Function.

011 KEY DEFEAT 0 / 1 0

If set to 1, menu navigation buttons/functions on LG Hospitality and commercial

non-LG display panels are not functional/available. N/A for LG Public Displays or

LG Commercial Monitors.

015 SLEEP TIMER 0 / 1 1Set to 1 to enable Sleep Timer.

016 EN. TIMER 0 / 1 0Set to 1 to enable On/Off Timers.

017 ALARM 0 / 1 1Set to 1 to enable Alarm.

020 FEATURE LEVEL 0, 16 – 24 0 Determines an additional IR code scheme to which the STB will respond.

021 V-CHIP 0 / 1 1Set to 1 to enable V-Chip (Parental Control) functions.

022 MAX BLK HRS 0 – 99 12 Sets number of V-Chip blocking hours.

023 CAPTION LOCK 0 / 1 0Set to 1 to retain caption setting set before STB/display panel turned OFF.

028 CH. OVERIDE 0 / 1 1If set to 0, user access to channel settings in the STB setup menus is restricted

and users can only tune to channels that are included in the channel lineup.

029 OLD OCV 0 / 1 0 Set to 1 to remap the PTC’s direct tune channels for Aux inputs from 13x to 9x.

030 ACK MASK 0 / 1 0If set to 1, enables ACK feature of MPI.

031 POLL RATE 20 – 169 94 Selects poll rate for MPI.

032 TIMING PULSE 186 – 227 207 Sets baud rate for MPI.

035 HDMI1 ENABLE 0 – 2 1 Set to 0 to disable HDMI 1. Set to 1 (DTV Mode) or 2 (PC Mode), as

applicable, to enable HDMI 1.

039 REAR AUX EN. 0 / 1 1Set to 1 to enable display panel AV input jack.

041 SIMPLINK EN 0 / 1 0Determines the status of the SIMPLINK feature. (See detailed descriptions.)

042 AUTO INPUTS 0 – 255 0 Determines the Aux inputs for which auto-sensing is enabled. (See detailed

descriptions.)

046 STRT AUX SRCE 1, 3, 5, 255 255 Sets the starting Aux source (if item 004 STRT CHANNEL is set to 0).

047 AUX STATUS 0 / 1 0Set to 1 for MPI Aux source to be reported as a channel number instead of

Channel 0.

049 DIS. AUDIO M. 0 – 9 * 0Determines the availability of the Sound Out (Audio) Menu in the STB menus, as

well as the default Audio Mode when STB is turned ON. (See detailed descriptions.)

053 DIS. CH-TIME 0 / 1 0Set to 1 to disable the STB’s native Channel-Time display.

069 EN. CH-T COL. 0 / 1 1Set to 1 to enable custom color for MPI display characters.

* Values 8 & 9 applicable with PTC v2.00.004 or later.

206-4272

Installer Menu Items 070 through 117

Item Function Value Range Default Value Brief Description of Function

070 FOR. CH-TIME 0 – 7 2 Chooses custom foreground color for MPI display characters.

071 BCK. CH-TIME 0 – 7 2 Chooses custom background color for MPI display characters.

073 CH NOT AVBLE 0 / 1 0

If set to 1 and item 028 CH. OVERIDE is set to 0, a “CHANNEL NOT

AVAILABLE” message is displayed if user attempts to direct tune a channel that

is not included in the channel lineup.

075 REVERT CH 0 / 1 0If set to 1 and loss of MPI communication occurs, STB tunes to Start Channel.

078 UPN MSB 0 – 255 0 User programmable number, most significant byte.

079 UPN MSB-1 0 – 255 0 User programmable number, most significant byte - 1.

080 UPN MSB-2 0 – 255 0 User programmable number, most significant byte - 2.

081 UPN LSB 0 – 255 0 User programmable number, least significant byte.

082 CHKSM ERROR 0 / 1 1Enforces rigid MPI checksum.

083 HANDSHK TIME 0 – 5 5 Relaxes MPI timing to be compatible with PC-based Windows-controlled systems.

084 PERMANENT BLK 0 / 1 0Removes block hours setting for Parental Control and makes block permanent.

086 V. MUTE TIME 0 – 50 0 Use to extend the normal video mute time during channel change.

088 EN NOISE MUTE 0 / 1 1(Analog channels only) If set to 1, audio is muted if no signal is present.

090 KEY LOCK 0 / 1 1If set to 1, all LG Hospitality and commercial non-LG display panel button

functions are locked. N/A for LG Public Displays or LG Commercial Monitors.

091 HDMI2 ENABLE 0 – 2 1 Set to 0 to disable HDMI 2. Set to 1 (DTV Mode) or 2 (PC Mode), as

applicable, to enable HDMI 2.

094 SAP MENU EN 0 / 1 1Set to 1 to enable SAP feature in Function Menu.

096 DEF. ASP. RATIO 0 – 4 2 Sets default aspect ratio at power up. See detailed descriptions and item 106.

097 AUDIO OUTPUT 0, 8, 9 *

Set as required in accordance with external audio equipment connected to the

STB. (See detailed descriptions.)

098 PRO:CENTRIC 0 ~ 3

Set to 0 to disable Pro:Centric operation. Set to 1 for Flash Mode. Set to 2 for

GEM (Java Application) Mode. Set to 3 for HTML Mode.

100 VIDEO INTERFAC 3 – 5 3 Selects HDMI connection for display panel: 3 = HDMI1, 4 = HDMI2, 5 = HDMI3

101 IR FEEDBACK 0 / 2 0Set to 2 to disable the STB’s MMR feature.

102 ATSC BAND 0 ~ 4 4Selects ATSC band.

103 ATSC TUNE MODE 0 / 1 1Set to 1 (default) for Physical Channel scan. Set to 0 for Virtual Channel scan.

104 START MINOR CH 0 – 255 0 Selects Minor Start Channel. Set to 0 for NTSC.

105 VID OUT FORMAT 1, 4, 5 1Sets format for video output: 1 = 720p, 4 = 1080p, 5 = 1366 x 768

106 ASP RATIO LOCK 0 / 1 0To retain set aspect ratio on power cycle, set to 1. Set to 0 for default ratio on

power cycle.

107 BANNER SELECT ** 0 / 1 1Selects the type of banner to display during channel change.

108 PANEL COM 0 – 3 2 Sets display panel baud rate: 0 = 1200, 1 = 2400, 2 = 9600, 3 = 115200

110 PANEL DELAY 0 – 15 8 Sets the display panel communication delay time.

111 PANEL VOL PRE 0 – 100 100 Determines a preset fixed volume level to set in the display panel.

113 PANEL TYPE 0 – 4 4 Sets display panel communication command set. (See detailed descriptions.)

116 VIDEO MUTE EN 0 / 1 0(Analog channels only) If set to 1, video mutes (blank screen) when no

signal is present.

117 FACT DEFAULT 0 / 1 0Set to 1 to restore the factory default settings of all Installer Menu items.

* Value 8 applicable with PTC v2.00.004 or later.

** Applicable with CPU v4.10.50 or later and PTC v2.00.004 or later.

Installer Menu (Cont.)

34 206-4272

Installer Menu (Cont.)

000 - INSTALLER SEQUENCE

Species entry sequence to the Installer Menu.

0 = 9876 1 = 4321

2 = 1478 3 = 3698

001 - POWER MANAGE (Power Management)

Energy saving feature. Determines the number of hours, in the

range 1 to 7, of inactivity allowed, either at the display control

panel or from the remote, before the STB automatically turns itself

OFF. If set to 0, Power Management is disabled.

002 - AC ON (AC Power Switchable)

Set to 0 (default) for standard STB/display turn ON/OFF operation.

If set to 1, this allows the STB/display panel to turn ON when AC

power is applied. Pressing the POWER button is not necessary.

This is desirable if the STB is plugged into a switched AC outlet.

Though, with PTC v2.00.004 or later, note that if the Pro:Centric

application is loaded (i.e., item 098 PRO:CENTRIC is not set to

0), the STB will reboot and initiate an update event once every 24

hours. During the update event, the STB checks for and downloads

any available updates from the Pro:Centric server (item 119 DATA

CHANNEL set from 1 to 135 or 253). The time at which this event

occurs depends on the setting of item 121 UPDATE TIME HR.

See item 119 and 121 descriptions for further information. Once

the update cycle is complete, the STB completes the reboot and

resumes its ON state.

Note: If set to 1, the STB does not respond to ON/OFF commands

from the remote, and the SLEEP TIMER is also nonfunctional.

Set to 2 or 3 to enable the Instant ON feature (see additional

information below).

The Instant ON feature allows the STB to turn ON when AC power

is applied, while the display panel remains OFF. The STB retains

its ON status, and the POWER button only toggles the display On

and Off.

• If this item is set to 2, the STB will reboot and, if applicable (i.e.,

item 119 set from 1 to 135 or 253), check for and download any

available updates from the Pro:Centric server each time the

display panel is turned OFF. This setting is not recommended if

the STB will be congured with a resident application.

• If this item is set to 3, the STB will not reboot to check for and

download updates each time the display panel is turned OFF,

with the following exception: the rst time the display is turned

OFF after this item is set to 3, the STB will reboot and initiate an

update event (Data Channel Auto Search and/or check for and

download of updates—see also paragraph below). This setting

is recommended if the STB will be congured with a resident

application. In this mode, the standard check for and download

of updates is under application control. Refer to your site-specic

documentation for further information on conguring the STB with

a resident application.

When this item is set to 2 or 3, the STB also will reboot and initiate

an update event once every 24 hours. During the update event, the

STB, as applicable, performs a Data Channel Auto Search (item

119 set to 255) and/or checks for and downloads any available

updates from the Pro:Centric server (item 119 set from 1 to 135 or

253). The time at which this event occurs depends on the setting of

item 121. See item 119 and 121 descriptions for further information.

Once the update cycle is complete, the STB completes the reboot

and resumes its ON state with the display panel OFF.

003 - BAND/AFC (Band/Automatic Frequency Control)

There are four possible settings for this option:

0 = Broadcast 1 = CATV (default)

2 = HRC 3 = IRC

If some channels were not found by Auto Tuning (Channel

Search), select the appropriate Band setting here, and add the

channels using the Channel Edit option in the Channel Menu.

004 - STRT CHANNEL (Start Channel)

If active, this function allows you to determine the initial Major

Start Channel number when the STB/display panel is turned

ON. This feature is useful for an in-house information channel,

since the STB/display would always select that channel when it is

turned ON. If set to 255, the last channel tuned before the STB/

display was turned OFF will be the channel tuned when the STB/

display is turned ON again.

Note: For a digital Start Channel, always remember to set item

104 to the Minor Start Channel number.

Detailed Descriptions of Installer Menu Items

Installer Menu Items 119 through 122

Item Function Value Range Default Value Brief Description of Function

119 DATA CHANNEL 0 – 135, 253,

255 255

Set to 0 to disable. Set from 1 to 135 to match the RF channel number used by

the Pro:Centric server as its data channel. Set to 255 to use Auto Search to find

the Pro:Centric RF channel. (See detailed descriptions.)

121 UPDATE TIME HR 0 – 23, 128 128 Sets the Wake For Update hour. The value “128” is displayed as “OFF.” Directly

entering 128 turns the Wake For Update feature OFF.

122 UPDATE TIME MN 0 – 59, 255 0Sets the minute for Wake For Update. (See detailed descriptions.)

206-4272

0 = Aux 127 = Map to Major CH 4

1 ~ 125 = Major Ch. # 253 = IP Start Channel

126 = Map to Major CH 3 255 = Last Channel

Note: 126 and 127 are mapped only in SONIFI PPV Mode.

Note: If setting this item to 0 (Aux), make sure to also set item 046

STRT AUX SRCE to the appropriate value.

Note: The IP Start Channel shown above can only be set in the

FTG File Manager, which is used to congure STB CPUs for FTG

Mode. The same applies for the additional Major Channel number

range of 128 – 135 in Physical tuning and 128 – 999 in Virtual tuning

mode. This means that these values, if set, will only be visible in

the read-only Installer Menu when the STB is in FTG Mode. The

read-only display also will show additional information about the

channel, for example, the IP address and port number, etc.

005 - CHAN LOCK (Channel Lock)

Channel Lock is ideal if the system must always be on the same

channel. Changing channels with the Channel Up/Down or keypad

numbers is impossible. Channel Lock is inactive if set to 0 (default).

Generally, this feature is used in connection with item 004 STRT

CHANNEL where the Start Channel may, for example, be set to 3

or 4. If the Start Channel is 3, then the STB will remain locked on

channel 3.

NOTE: For items 007, 008, and 009

For legacy reasons, the scale used is 0 – 63. The PTC software

will translate this to the 0 – 100 scale used by the STB.

To translate an STB volume level to the Installer Menu value,

use the following formula:

Installer Value = STB Value x 63

100

Enter only the whole number (disregard fractions).

007 - STRT VOLUME (Start Volume)

This function allows the Installer to determine the initial volume

level setting when the STB/display panel is turned ON. This feature

is useful for an in-house information channel, since the STB/display

will always select that volume level when it is turned ON. The range

of values is 0 to 63, 255. If set to 255, the last volume level before

the STB/display was turned OFF will be the current volume level

when the STB/display is turned ON again.

008 - MIN VOLUME (Minimum Volume)

This function determines the minimum volume level allowable

with the Volume (VOL) Up/Down control. In this way, for example,

someone cannot set the volume too low to hear. The value range

is from 0 to 63. The factory default is 0, which provides the full

range of volume control, if item 009 MAX VOLUME is set to 63. It

is recommended to set the same value on every STB.

Note: The minimum volume level cannot have a value setting

higher than the maximum volume level (described below).

009 - MAX VOLUME (Maximum Volume)

This function determines the maximum volume level allowable

with the Volume (VOL) Up/Down control. In this way, for example,

someone cannot set the volume level high enough to disturb others.

The value range is 0 to 63, with 63 as the default, which gives the

user the full range of volume control, if item 008 MIN VOLUME is

set to 0. It is recommended to set the same value on every STB.

Note: The maximum volume level cannot have a value setting

lower than the minimum volume level (described above).

010 - MUTE DISABLE

Enables or disables sound mute function. If set to 1, sound cannot

be muted. If set to 0, sound can be muted.

011 - KEY DEFEAT

Applicable for LG Hospitality and commercial non-LG display

panels only. If set to 1, Key Defeat is enabled, which means that

end users cannot access or navigate within the STB’s on-screen

menu(s) from the display panel; i.e., menu navigation buttons will

not function. Set to 0 to disable Key Defeat. Note that all IR features

remain functional regardless of this setting; users can always

access the STB’s menus by pressing MENU on the remote.

Note: This feature does not apply to LG Public Displays or LG

Commercial Monitors since the STB will always disable those

displays’ panel buttons and the processing of IR.

015 - SLEEP TIMER

If set to 1, the Sleep Timer feature may be used. If set to 0, the

Sleep Timer is not available.

016 - EN. TIMER (Enable On/Off Timers)

If set to 1, the Timer function is available to the end user and

enabled continuously. Set to 0 to disable On/Off timers.

Note: The STB clock must be set in order for timers to be used.

017 - ALARM

Gives the installer the option of making the Alarm function available

to the end user. If set to 1, the Alarm function is available to the end

user. Set to 0 to disable the Alarm function.

Note: The STB clock must be set before the Alarm function will

work.

020 - FEATURE LEVEL

Determines an additional IR code scheme to which the STB will

respond, allowing for the use of unique IR codes based on “bed

number” in a multi-STB/display single room installation. First

determine the IR mode; then select the bed number.

Values IR Mode Bed #

0 Disabled N/A

16 – 24 Multi-code Remote 1 – 9

Note: The STB-dedicated Installer Remote is required for use of

this feature. For further information, see Reference section, “STB

Installer Remote.”

Installer Menu (Cont.)

36 206-4272

Installer Menu (Cont.)

021 - V-CHIP (Parental Control)

Set to 1 to activate V-Chip (Parental Control) and have it available

to the end user to lter and control or otherwise restrict program-

ming content that can appear. Set to 0 to turn the V-Chip feature

Off (not available to user); no programming restrictions can be set.

022 - MAX BLK HRS (Maximum Block Hours)

Sets hours from 0 to 99 for the maximum V-Chip (Parental Control)

block hours. Default setting is for 12 blocking hours.

Note: This item is not available in the Installer Menu when item

021 V-CHIP is set to 0 or when item 084 PERMANENT BLK is set

to 1.

023 - CAPTION LOCK

If set to 0, captions are OFF when the STB/display panel is turned

ON. Set to 1 to use the caption setting congured before the STB/

display was turned OFF when the STB/display is turned ON.

028 - CH. OVERIDE (Channel Override)

This item either allows or restricts tuning of channels that are NOT

in the PTC Channel Map. If set to 1, end users can tune channels

that are not in the PTC Channel Map by direct keypad entry. If

set to 0, users are restricted to only the channels that are in the

PTC Channel Map. In the case of CPU-CTV Mode, there are no

channels in the PTC Channel Map; therefore, direct keypad entry

is not available. Also, when this item is set to 0, the PTC Channel

Map (PTC-CTV Mode)/CPU channel lineup (CPU-CTV Mode)

is locked, and user access to channel settings in the STB setup

menus is restricted.

Note: This item is not applicable when the STB is in FTG Mode.

029 - OLD OCV (On Command Video™)

Set to 1 to remap the PTC’s direct tune channels for Aux inputs

from 13x to 9x. This allows 2-digit only tuning systems (i.e., legacy

OCV) to direct tune Aux inputs. See also Reference section, “STB

Aux Input Conguration.”

030 - ACK MASK

MPI Communication Parameter. When set to 1, enables ACK

feature of MPI.

031 - POLL RATE

MPI Communication Parameter. Selects poll rate for MPI. Step size

of 16 ms. Changing from default may affect communication via MPI.

032 - TIMING PULSE

MPI Communication Parameter. Sets baud rate for MPI. Step size

of 4.3 uS. Changing from default may affect communication via

MPI.

035 - HDMI1 ENABLE

Set to 1 to enable HDMI 1 input in DTV Mode. Set to 2 to enable

HDMI 1 input in PC Mode. Set to 0 to disable display panel HDMI

1 input.

039 - REAR AUX EN. (Rear Aux Enable)

Set to 1 to enable display panel rear Aux (AV) input. Set to 0 to

disable display panel rear Aux (AV) input.

041 - SIMPLINK EN

Set to 0 to disable the SIMPLINK feature. Set to 1 to enable

SIMPLINK functionality (does not enable remote control access to

the SIMPLINK Menu).

Note: When both this item and item 042 AUTO INPUTS are

enabled in the Installer Menu, HDMI inputs will be detected by

SIMPLINK, but the Auto Input(s) Sensing Feature will not function.

042 - AUTO INPUTS

Determines the Aux inputs for which auto-sensing is enabled. Set

to 0 to disable auto-sensing for all available inputs. Set to 255 to

enable auto-sensing for all available inputs. For information on

options for individual input settings, see Reference section, “Auto

Input(s) Sensing Feature.”

Note: In order for auto-sensing to be enabled for an input, that

input must also be enabled in the Installer Menu. For example, to

enable auto-sensing for HDMI 1, item 035 HDMI1 ENABLE must

also be set to 1 or 2. Also, see note above regarding STB operation

when both this item and item 041 SIMPLINK EN are enabled.

046 - STRT AUX SRCE (Start Aux Source)

Sets the starting Aux source. When turned ON, the STB/display

panel will tune to starting Aux source if item 004 STRT CHANNEL

is set to 0.

1 = AV 3 = HDMI 1

5 = HDMI 2 255 = Last Aux (default)

Note: Above is applicable only if all Aux sources are enabled.

Note: This item is not available in the Installer Menu unless item

004 STRT CHANNEL is set to 0.

047 - AUX STATUS

Set to 1 for MPI Aux source to be reported as a channel number

instead of channel 0. Set to 0 to disable Aux identication change.

Controls MPI status channel response for Aux inputs.

049 - DIS. AUDIO M. (Disable Audio Menu)

Determines the availability of the Sound Out (Audio) Menu in the

STB menus. Also determines the default Audio Mode when STB

is turned ON. See the table below and set as required.

Note: If a SIMPLINK-enabled device is connected to the STB

and item 041 SIMPLINK EN is set to 1 (enabled), the SIMPLINK

device Audio Mode will have priority over the setting of this item

when the STB/display is turned ON.

Note: When this item is set to 6 or 7, the Bluetooth Sound Sync

Media Share feature is not available. If Bluetooth Sound Sync is

currently enabled in the IP Environment / Media Share Menu, it

will be disabled.

206-4272

Value Sound Out

Menu Status

Default Audio Mode at STB

Turn ON

0 (default) Enabled Display Speaker

1 Disabled Display Speaker

2 Enabled External Speaker (Optical**/HDMI ARC**)

3 Disabled External Speaker (Optical**/HDMI ARC**)

4 Enabled LG Sound Sync (Optical**)

5 Disabled LG Sound Sync (Optical**)

6 Enabled LG Sound Sync (Wireless**)

7 Disabled LG Sound Sync (Wireless**)

8* Enabled Display Speaker + Audio Out (Optical**)

9* Disabled Display Speaker + Audio Out (Optical**)

* Values 8 & 9 only applicable with PTC v2.00.004 or later.

** Connect to/via STB.

053 - DIS. CH-TIME (Disable Channel-Time Display)

Set to 1 to disable the STB’s native Channel-Time display, when a

custom channel label/channel information will be provided by the

MPI command. Set to 0 to enable the STB’s native Channel-Time

display.

069 - EN. CH-T COL. (Enable Display Characters Custom Color)

Set to 1 to enable custom color for MPI display characters. Set to

0 to disable custom color for MPI display characters.

070 - FOR. CH-TIME (Display Characters Foreground Color)

Set the foreground color for MPI display characters according to

the following color chart:

0 = Black 2 = Green 4 = Red 6 = Yellow

1 = Blue 3 = Cyan 5 = Violet 7 = White

If foreground color and background color for display characters

are the same, the background will be transparent.

Note: This item and item 071 BCK. CH-TIME also apply to the

“Channel Not Available” message if item 073 CH NOT AVBLE is

set to 1 (enabled).

Note: Items 070 FOR. CH-TIME and 071 BCK. CH-TIME are only

available in the Installer Menu when item 069 EN. CH-T COL. is

set to 1.

071 - BCK. CH-TIME (Display Characters Background Color)

See description for item 070 FOR. CH-TIME above. The color

chart is the same for both items.

073 - CH NOT AVBLE (Channel Not Available)

If set to 1 and item 028 CH. OVERIDE is set to 0, a “CHANNEL

NOT AVAILABLE” message is displayed when a user attempts to

direct tune a channel that is not included in the channel lineup.

Note: This item is not available in the Installer Menu when item

028 CH. OVERIDE is set to 1.

Note: This item is only applicable when the STB is in PTC-CTV

Mode.

075 - REVERT CH (Revert to Start Channel)

If set to 1 and loss of MPI communication occurs, the STB auto-

matically tunes to the specied Start Channel.

Note: This item is not available in the Installer Menu when item

004 STRT CHANNEL is set to 255.

078 - UPN MSB (UPN Most Signicant Byte)

User programmable number, most signicant byte readable by

MPI command. Note: Not linked to serial number.

079 - UPN MSB-1 (UPN Most Signicant Byte-1)

User programmable number, most signicant byte-1 readable by

MPI command. Note: Not linked to serial number.

080 - UPN MSB-2 (UPN Most Signicant Byte-2)

User programmable number, most signicant byte-2 readable by

MPI command. Note: Not linked to serial number.

081 - UPN LSB (UPN Least Signicant Byte)

User programmable number, least signicant byte readable by

MPI command. Note: Not linked to serial number.

082 - CHKSM ERROR (Checksum Error)

Enforces rigid MPI checksum validation. Set to 1 for validation.

Set to 0 to disable (does not check checksum on MPI async port).

SPI is always checked.

083 - HANDSHK TIME (Handshake Time)

Adds an additional delay to the handshake time which is 64 msec,

thus relaxing MPI timing requirements to be compatible with PC-

based Windows controlled systems. Range is 0 - 5.

(Timeout = 25.5MS + [25.5 MS* Handshake time].)

084 - PERMANENT BLK (Permanent Block)

Allows Lock (Parental Control) blocking schemes to be permanent

by disabling the blocking hours function. Set to 1 to install Parental

Control restrictions permanently. Set to 0 for user-specied hours

control of blocking schemes.

Note: This item is not available in the Installer Menu when item

021 V-CHIP is set to 0.

086 - V. MUTE TIME (Video Mute Time)

Use to extend the normal video mute time during channel change.

For example, you may wish to extend the normal video mute time

to prevent the display of encrypted video (i.e., from a Pro:Idiom

encrypted channel) that has not yet been decrypted. When set to

0, the normal video mute time is not extended. Set from 1 to 50

to increase the normal video mute time in 100 ms step increments

up to a maximum of 5 seconds (e.g., the value of 25 represents 2.5

seconds, or 25 x 100 ms = 2.5 seconds).

088 - EN NOISE MUTE (Enable Noise Mute)

Applicable for analog channels only. If set to 1, audio mutes if no

signal is present.

Installer Menu (Cont.)

38 206-4272

090 - KEY LOCK

Applicable for LG Hospitality and commercial non-LG display

panels only. If set to 1 (default), Key Lock is enabled, which

means that all display panel button functions will be locked, i.e.,

non-functional. Set to 0 to disable Key Lock.

Note: This feature does not apply to LG Public Displays or LG

Commercial Monitors since the STB will always disable those

displays’ panel buttons and the processing of IR.

091 - HDMI2 ENABLE

Set to 1 to enable HDMI 2 input in DTV Mode. Set to 2 to enable

HDMI 2 input in PC Mode. Set to 0 to disable display panel HDMI

2 input.

094 - SAP MENU EN (2nd Audio Program)

Set to 1 to enable the SAP feature in the Function Menu, when

the Function Menu is available (i.e., STB is not in Pass-through

Mode). Set to 0 to disable the SAP feature in the Function Menu,

when the Function Menu is available.

096 - DEF. ASP. RATIO (Default Aspect Ratio)

Selects default aspect ratio at power up:

0 = Set By Program 1 = 4:3

2 = 16:9 (default) 3 = Just Scan

4 = Zoom

Note: This item is not available in the Installer Menu unless item

106 ASP RATIO LOCK is set to 0.

097 - AUDIO OUTPUT

(Value 8 only applicable with PTC v2.00.004 or later) Determines

availability of the analog audio output to be used by external audio

equipment connected to the Audio Line Out jack on the STB. Set

to 0 to disable audio output. Set to 8 to enable volume control of

audio output. Set to 9 (default) to enable xed line level (typically

400 mVrms ± 100 mVrms @10KΩ) output. See also Reference

section, “External Audio Line Out Specifications.”

098 - PRO:CENTRIC

Selects the Pro:Centric Application Mode. Set to 0 (default) to

disable the Pro:Centric application. Set to 1 for Flash Mode. Set

to 2 for GEM (Java Application) Mode. Set to 3 for HTML Mode.

In order to retrieve the Pro:Centric application, when enabled (for

Flash, GEM, or HTML Mode), the STB must be turned OFF/ON two

times. Once you exit the Installer Menu, turn OFF the STB/display

panel for at least one minute. When you turn the STB/display back

ON, the STB will start the appropriate library based on the setting

of this item. Wait until TV programming appears on the display, and

then turn the STB/display back OFF, this time for a few minutes, to

initiate the application download. When you turn the STB/display

back ON, press the PORTAL key on the Installer Remote, and

verify that the Pro:Centric application appears on the display.

Note: This item is not available in the Installer Menu when item

119 DATA CHANNEL is set to 0.

100 - VIDEO INTERFAC

Selects the HDMI port on the display panel to be used for HDMI

input from the STB. Set to 3 for HDMI 1 (default). Set to 4 for

HDMI 2. Set to 5 for HDMI 3.

If you change the value of this item, make sure to reconnect the

HDMI cable from the STB to the appropriate HDMI port on the

display panel once you have exited the Installer Menu.

101 - IR FEEDBACK

If set to 0, the STB’s MMR (Magic Motion Remote) feature is

enabled (default), and a compatible LG MMR (not supplied) may

be used with the STB. If set to 2, the MMR feature is disabled.

102 - ATSC BAND

Sets up STB to receive different types of incoming signals.

0 = Broadcast 1 = CATV 2 = HRC

3 = IRC 4 = Same as NTSC

103 - ATSC TUNE MODE

Sets ATSC tuning mode. Default set to 1 for Physical Channel

scan. Set to 0 for Virtual Channel scan.

104 - START MINOR CHANNEL

Sets Minor Start Channel number at power up. 0 = NTSC. If not

0, number selected is the digital channel’s Minor Start Channel

number.

Note: This item is not available in the Installer Menu when item

004 STRT CHANNEL is set to 0 or 255.

105 - VID OUT FORMAT

Selects the format for video output (i.e., the resolution):

1 = 720p (default) 4 = 1080p 5 = 1366 x 768

If you change the video output format on location, once you exit

the STB Installer Menu, a Changing Video Output Resolution

pop-up banner will appear at the bottom of the display screen,

and then the STB will reboot to change the resolution per your

selection. When the reboot is complete, a conrmation pop-up

banner for the new video output resolution will be displayed. To

conrm the new video output resolution, use the arrow keys on

the Installer Remote to select YES in the conrmation banner, and

then press OK on the Installer Remote.

If there is no user interaction within 10 seconds of the prompt for

conrmation, or if you select “NO” in the conrmation banner, the

STB will reboot and revert to the former resolution.

Note: If this item is updated via a Clone/Conguration (.tlx) le

loaded on a Pro:Centric server, no conrmation is required.

Note: Refer to documentation for the applicable display panel(s)

to determine the appropriate resolution setting. The selected

resolution should be compatible with the display panel’s native

video output resolution. If necessary/desired, you can use TV Zone

designations to create multiple proles to differentiate item 105

settings by display panel brand. See Reference section, “Using the

STB’s Zoning Features,” for further information on TV Zones.

Installer Menu (Cont.)

206-4272

Installer Menu (Cont.)

106 - ASP RATIO LOCK (Aspect Ratio Lock)

Set to 1 to retain previous aspect ratio with power off. Set to 0 to

retain default aspect ratio with power off. See item 096 DEF. ASP.

RATIO above.

107 - BANNER SELECT

(Applicable with CPU v4.10.50 or later and PTC v2.00.004 or

later) Selects the type of banner to display during channel change.

Set to 1 for channel label display, plus channel information (full

banner). Set to 0 for channel label display only (small banner).

108 - PANEL COM (Panel Communication)

Sets the display panel baud rate:

0 = 1200 1 = 2400

2 = 9600 (default) 3 = 115200

110 - PANEL DELAY

After the STB sends the turn ON command to the display panel,

the display panel requires time to complete its power on sequence

before it begins accepting commands from the STB. This item sets

the time, in seconds, to delay the STB’s initial communication with

the display panel. The default value is 8 seconds.

Note: The amount of time required for the display’s power on

sequence varies by display panel brand/model. Thus, depending

on the brand/model of display panel connected to the STB, you

may be able to decrease or you may need to increase the Panel

Delay value, accordingly. For example, if you are using the STB

with an LG PW1000 or PW1500 projector, it is recommended that

you set the delay to 10 or more seconds.

Note: This item does not apply to LG Hospitality display panels.

111 - PANEL VOL PRE (Panel Volume Preset)

Determines a preset xed volume level (gain) to set in the display

panel. The audio signal (volume level) is dynamically controlled

in the STB. The default value is 100 to provide a typical 1:1 ratio

of volume level to sound output when the STB is connected to an

LG display panel.

Note: Sound output may vary by display panel brand/model. Thus,

depending on the brand/model of display panel connected to the

STB, you may need to adjust the preset volume level to achieve

the desired sound output.

113 - PANEL TYPE

Sets the TLM command set to communicate with the display

panel. This setting is only applicable for LG Public Display TVs

and Commercial Monitors that use the RS-232C TELEVISION

CONTROL port for STB-to-display panel communication.

The default value (4) will be appropriate for most current display

models. See Reference section, “Display Panel Specications,”

to determine the appropriate setting for the display panel being

used.

116 - VIDEO MUTE EN (Video Mute Enable)

Applicable for analog channels only. If set to 1, video mutes

(blank screen) when no signal is present.

117 - FACT DEFAULT (Factory Default)

Set to 1 and press OK to restore the factory default settings of all

Installer Menu items. Once complete, the value returns to 0.

Caution: If set to 1, this clears all STB Installer Menu

custom settings and restores the factory default

settings. It also clears the channel lineup, including

any assigned channel icons and custom text labels.

Note: See also Reference section, “Restoring Factory Defaults on

the STB(s),” for further information.

119 - DATA CHANNEL

Set to 0 to disable. Set from 1 to 135 to match the RF channel

number that will be used by the Pro:Centric server as its data

channel. If left at the default value (255), the STB’s Data Channel

Auto Search feature will be enabled (see additional information

below). *

Data Channel Auto Search feature: When this item is set to 255

(default), once every 24 hours, the STB will initiate a search of 10

predened channels (10, 20, 30, ... 100) and then, if necessary,

perform a complete search of the RF channels (1 to 135) in an

attempt to nd the RF channel used by the Pro:Centric server as

its data channel. If the Pro:Centric RF channel is found, the DATA

CHANNEL value will be changed from 255 to match the server’s

RF channel number. The time at which the Auto Search occurs

depends on the setting of item 121 UPDATE TIME HR. See item

121 description for further information.

Note: Pro:Centric updates are downloaded from the Pro:Centric

server to the STB when the STB/display panel is turned OFF.

While Pro:Centric updates are in progress, it is not possible to

turn ON the STB/display.

Note: The Data Channel is automatically set to “253” if Media

Type is set to “IP” either in the EZ-Manager Wizard or in the

STB’s IP Environment / Pro:Centric Menu (see “EZ-Manager

Wizard” on pages 16 to 25 or “Pro:Centric Setup” on pages 61

to 62, respectively) or if Installer Menu item #119 Data Channel

is set to “IP Address” in the FTG File Manager, which is used to

congure STB CPUs for FTG Mode operation. It is not possible to

change the value to “253” directly in the Installer Menu.

* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.

40 206-4272

121 - UPDATE TIME HR

Based on the settings of this item and item 122 UPDATE TIME

MN, the Wake For Update feature wakes the STB once daily to

check for and, if applicable, download updates from the Pro:Centric

server.

Set the Wake For Update hour from 0 to 23. This item uses the

24-hour clock format. The value “128” (default) is displayed as

“OFF.” Directly entering 128 resets the default value (OFF) for this

item, though note that this setting does not mean the STB will not

initiate update events—see additional information below.

Under standard STB/display panel OFF/ON operating conditions

(i.e., item 002 AC ON is set to 0), a Wake For Update event occurs

when the STB/display is OFF and causes the STB to temporarily

turn ON, perform the update cycle, and then turn back OFF, all

while the display remains OFF. If item 002 AC ON is set to 2 or 3

for Instant ON, then the STB is always ON and Wake For Update

occurs when the display is OFF. The Wake for Update event

causes the STB to reboot in order to perform the update cycle and

then return to its ON state with the display panel OFF. See also

description for item 002.

Random Distribution of Update Time: If this item is set to 128

(OFF), the time at which a Data Channel Auto Search (item 119

set to 255) and/or an Instant ON update (item 002 set to 2 or 3)

occurs is determined as follows: Each STB initiates the search

and/or checks for updates during the 2 AM hour (if the STB clock

is set) or after two hours of elapsed time from when AC power

was applied (if the STB clock is not set). Also, in this case, a xed

update time minute from 0 to 59 that has been assigned to each

STB is used. (The intention of this feature is to prevent all of the

installed STBs from performing updates at the same time; however,

note that in installations that have a large quantity of STBs with this

feature, there will be some STBs that have the same update minute

assignments.) The update time for the STB is displayed at the right

of this item in the Installer Menu, for example:

121 UPDATE TIME HR OFF 02:34

If the display is ON when a Wake For Update is to occur, the

update will take place the next time the display is turned OFF.

Note: This item is not available in the Installer Menu when item

119 DATA CHANNEL is set to 0, except when item 002 AC ON is

set to 2 or 3 for Instant ON.

Note: The STB clock must be set in order for a Wake For Update

event to occur at the precise time of day in accordance with item

121 and item 122 settings.

122 - UPDATE TIME MN

Set the Wake For Update minute from 0 to 59. If item 121 is NOT

set to 128 and you wish to invoke the “random” minute assignment

on the STB, set this item to 255. See also description for item 121

UPDATE TIME HR above.

Note: This item is not available in the Installer Menu unless item

121 UPDATE TIME HR is set from 0 to 23.

Note: The STB clock must be set in order for a Wake For Update

event to occur at the precise time of day in accordance with item

121 and item 122 settings.

Installer Menu (Cont.)

206-4272

Custom Master STB Setup

This section describes how to create a customized Master STB Setup for cloning purposes when

the STB is in Pass-through Mode. All cloning (export and import) processes on the STB are

performed via USB memory device / “.tlx” le. The Master STB Setup may be exported to a Clone

(.tlx) file, which can then be used (i.e., imported) to configure either STBs that are to remain in

Pass-through Mode or STBs that are to be configured for FTG Mode.

Cloning requirements and procedures are described in detail on pages 44 to 50.

Note: You can also use the FTG File Manager to create an FTG Conguration (.tlx) le for FTG

Mode conguration/cloning purposes, if desired (see pages 51 to 52). However, it is not possible to

customize STB setup menu settings in the FTG File Manager. If you wish to include customized

STB setup menu settings in the STB conguration, in addition to the channel lineup and Installer

Menu settings, perform the Master STB Setup procedure to create a Clone (.tlx) conguration le.

Before You Begin

• It is recommended that you disconnect all Aux inputs if you intend to run Auto Tuning (Channel

Search). Under certain conditions, Auto Tuning is disabled if there is an Aux input active.

• A Clone (.tlx) le comprises Installer Menu settings, IP Environment Menu settings (with the

exception of unique STB attributes and settings), and all STB sources’ (analog, digital, AV1,

HDMI, etc.) clonable setup menu settings. See also “Clonable STB Setup Menu Features” list

below.

• If the “.tlx” le (either a Clone or FTG Conguration le) to be imported on the Target STB(s)

contains an FTG Channel Map, the Target STB(s) will be congured for FTG Mode, though as

part of the import process, depending on the types of channels included in the Channel Map, you

may have the option to select either logical or physical channel tuning. If you would like the Target

STB(s) to remain in Pass-through Mode, the “.tlx” le should not include an FTG Channel Map.

Clonable STB Setup Menu Features

Sound

Sound Out

Channels

Channel Tuning

Channel Manager

Channel Label

General

Language

Time & Date

−Clock Mode (Auto/Manual)

−Time Zone

Timers (No Signal Power Off)

SIMPLINK

Accessibility

Pointer Options

Closed Captions

Audio Guidance

Note: Some menu options vary between analog and digital channels and Aux inputs.

Note: The Quick Settings Menu is initially displayed when you press the MENU key on the

Installer Remote. Select the Advanced menu icon to access the advanced STB setup menus.

Several advanced settings are duplicated in the Quick Settings Menu.

42 206-4272

PTC INSTALLER MENU

STB_3000

CPU

CTV

000 INSTALLER SEQ 000

UPN 000-000-000-000 ASIC D279

PTC V#.##.### CPU V#.##.##.##

Custom Master STB Setup (Cont.)

Custom Master STB Setup Procedure

1. Turn ON the STB/display panel.

The next step depends on whether the EZ-Manager Wizard appears

on the screen when you turn ON the STB/display:

• If the wizard is displayed, the STB is in the required factory default

state. Exit the wizard, and then continue with step 2.

• If the wizard is not displayed, restore the STB to a factory default

condition before continuing with this procedure. See Reference

section, “Restoring Factory Defaults on the STB(s),” as necessary,

for further information.

2. Set Installer Menu items.

This step provides specic instruction only on the Installer Menu items

that should be set on a Master STB. Refer to pages 30 to 40 for detailed

information on all Installer Menu items.

a) Use the Installer Remote to access the PTC Installer Menu (see

“Accessing the Installer Menu” on page 30 for further information).

b) Set Installer Menu item 003 BAND/AFC, as appropriate.

• Broadcast: Set to 0. • HRC: Set to 2.

• CATV: Set to 1 (default). • IRC: Set to 3.

c) Set any other Installer Menu items that affect your TV programming

network to the required conguration. For example, set the panel

display type (if applicable), enable/disable Aux inputs, set a Start

Channel, etc.

d) After you have adjusted all Installer Menu item settings as required,

and if you do not need to congure any IP Environment settings (see

note below), press OK once on the Installer Remote to save your

changes; then, press OK again to exit the menu.

Note: If you intend to congure settings in the IP Environment Menu,

which is accessible from the Installer Menu, you can proceed directly

to step 3. All Installer Menu settings will be saved automatically when

you access the IP Environment Menu.

3. Congure IP Environment settings.

Note: You cannot return directly to the Installer Menu from the IP

Environment Menu; thus, you may wish to set all Installer Menu items

as needed before you access the IP Environment Menu. Otherwise,

you will need to reaccess the Installer Menu to set additional items.

Navigate to Installer Menu item 119 DATA CHANNEL, and press

2-5-3 + MENU to launch the IP Environment Menu. Then, complete

network conguration as required. In particular, if you intend to use

the Wi-Fi Zoning feature, you must congure the wireless network

connection as part of the Master STB Setup. See “IP Environment

Setup” on pages 57 to 64 for further information.

Typical Installer Menu

Adjust the value for this

Installer Menu item, as required.

003 BAND/AFC 001

(Continued on next page)

206-4272

Custom Master STB Setup (Cont.)

(Continued from previous page)

4. Set up STB/display panel features.

On-screen setup menus control the features of the STB/display.

Press MENU on the Installer Remote, and select the Advanced

menu icon from the Quick Settings Menu to access the advanced

STB setup menus. Then, set Picture, Sound, Channels, etc. options

to the desired configurations. See “Clonable STB Setup Menu

Features” list on page 41 and also notes below.

Note: If you intend to use the Zoning feature(s) on this STB, make

sure to assign the appropriate TV Zone # and/or Wi-Fi Zone # at this

time as described in Reference section, “Using the STB’s Zoning

Features.”

Note: If desired and if appropriate, you can run Auto Tuning (see

step 5) prior to completing this step.

5. (Optional) Run Auto Tuning.

If you are creating a Master STB Setup for cloning purposes and

you want the Target STB(s) to remain in Pass-through Mode, do

NOT run Auto Tuning. If you export a Master STB Setup that

includes an auto-tuned/edited channel lineup, thereby creating a

Clone (.tlx) file with an FTG Channel Map, and then import the

Clone file to a Target STB, this will put the Target STB in FTG

Mode.

Note: When you import a Clone/Configuration (.tlx) file that contains

an FTG Channel Map on a Target STB (for FTG Mode configuration),

depending on the types of channels included in the Channel Map,

you may have the option to select either logical or physical channel

tuning. For either selection, the channel sequence will be based on

the order in which the channels appear in the FTG Channel Map.

You can view and/or edit the channel sequence in the FTG File

Manager, as required.

a) Use the Installer Remote to access the Channels Menu. Then,

select Channel Tuning and follow the on-screen instructions to

search for all available analog and digital channels.

b) Use the Channel Manager option in the Channels Menu to edit

the channel lineup, as necessary. Add/delete channels per your

system requirements.

6. Verify the STB/display panel setup.

Make sure the STB/display features are set per your requirements.

Also, if applicable, verify that the channel lineup is correct.

The Master STB Setup is now ready to be saved (exported) to a USB

memory device. See “Cloning Procedures” on pages 44 to 50.


Sound

Channels

General

Safety

Accessibility


Aspect Ratio

16:9

Use the STB setup menus to set

the display features to the desired

configuration for the end user.

This example illustrates the

advanced STB setup menus.

(Optional) Use Channels Menu

options to run Auto Tuning and

edit the channel lineup.

CHANNELS



Sound

Channels

General

Safety

Accessibility

Channel Tuning

Channel Manager

Channel Label

Multi Audio

MONO

(

MONO

)

Audio Language

None

44 206-4272

Cloning Procedures

Cloning typically refers to the process of using a Master STB Setup to configure a Target STB.

This section describes how to save (export) a Master STB Setup and transfer (import) it to a Target

STB using a USB memory device / Clone (.tlx) le.

You can also create an FTG Conguration (.tlx) le using the FTG File Manager and then use the

Import Clone File procedure to transfer the conguration to Target STBs. Refer to “Creating an

FTG Conguration File” on pages 51 to 52, as necessary.

Exporting a Clone File

This section describes how to use the STB Manager “Export Clone File” option to export Master

STB Setup conguration to a USB memory device / Clone (.tlx) le.

Before You Begin

• Ensure the USB device has been formatted with FAT format.

• If the STB is not already in FTG Mode, complete the Custom Master STB Setup procedure (see

pages 41 to 43).

• If you would like the Target STB(s) to remain in Pass-through Mode after the Clone le is

imported, ensure the Master STB does not have an auto-tuned/edited channel lineup; otherwise,

importing the exported le will result in the Target STB(s) being congured for FTG Mode.

• If you intend to use the STB Zoning feature(s), make sure to assign the appropriate TV Zone #

and/or Wi-Fi Zone # as described in Reference section, “Using the STB’s Zoning Features,”

BEFORE performing the procedure below. Also, for Wi-Fi Zoning in particular, the STB’s wireless

network connection settings should be congured in the IP Environment Menu before exporting

is initiated.

• It is not possible to clone a Master STB’s clock. Either set a Target STB’s clock manually, or use

the Auto Clock setting in the STB setup menus.

Caution: Do not unplug the STB power cord or remove the USB memory device while

exporting is in progress, as doing so may cause the STB to malfunction or harm the

USB device, respectively.

Export Clone File Procedure

1. Ensure the Master STB/display panel is set up completely and turned ON.

2. Insert the USB memory device into either of the USB ports on the Master STB.

3. Press MENU on the Installer Remote to display the STB setup menus (STB is in Pass-through

Mode) or the Function Menu (STB is already in FTG Mode).

4. (STB in Pass-through Mode only) From the Quick Settings Menu displayed at the right of the

screen, select the Advanced menu icon and press OK to access the advanced STB setup

menus.

5. Use the arrow navigation keys to select/highlight either the General menu icon from the STB

setup menus or the Safety menu icon from the Function Menu. Then, press the number “7” key

a total of seven times to display the STB Manager.

Note: Ez Download is always selected by default when you initially access the STB Manager.

Also, note that Diagnostics is for service use only.

(Continued on next page)

206-4272

Cloning Procedures (Cont.)

(Continued from previous page)

Select the ﬁle(s) to download, and then select UPDATE below.

Update STB Software

STB_CPU_SW.epk

Update PTC Software

STB_PTC_SW.txt

Import Clone File

STB_IM.tlx

UPDATE

USB DEVICE

EXIT

STB MANAGER

USB 1:

Device Name

Ez Download

Update STB Software

Update PTC Software

Import Clone File

Diagnostics

Current STB SW Version:

version#

None

ﬁlename

.epk/Version:

version#

6. If more than one USB memory device is currently connected to the STB, be sure to select the

USB device on which you wish to save the Clone le. If necessary, use the arrow keys on

the Installer Remote to select/highlight the USB DEVICE button in the top right corner of the

screen and press OK. Then, use the Up/Down arrow keys to select the appropriate USB device

from the pop-up list of USB devices displayed at the top of the screen.

USB Device

USB 1: Device 1

USB 2: Device 2

7. To gain access to the “Export Clone File” option in the STB Manager, key in the following

number sequence on the Installer Remote: 9-8-7-6.

8. Use the Up/Down arrow keys to select Export Clone File, and then press OK.

Clone lename parameters will be displayed on the screen.

Select the ﬁlename, and then select EXPORT below.

EXPORT

USB DEVICE

EXIT

STB-3000-UA_1.TLX

STB MANAGER

USB 1:

Device Name

Ez Download

Update STB Software

Update PTC Software

Import Clone File

Export Clone File

Diagnostics

(Continued on next page)

46 206-4272

Cloning Procedures (Cont.)

(Continued from previous page)

9. Modify the lename, as required. While the STB model element of the lename may not be

changed, you can differentiate this Clone le from other STB-3000 Clone les by changing

the numeric assignment appended to the end of the lename. Select/highlight the lename,

and then use the Up/Down arrow keys on the Installer Remote to scroll through numeric

assignments until the desired number is shown.

10. When you are ready to continue, i.e., when you have selected the desired lename, press OK

on the Installer Remote to select/activate the EXPORT button at the bottom of the screen, and

then press OK on the Installer Remote once more to export the le.

Export progress will be displayed on the screen. This process may take a few minutes.

Do NOT remove the USB device while exporting is in progress. When the export process is

complete, an EXPORT COMPLETE pop-up banner will be displayed at the bottom of the

screen.

11. Press OK to return to STB Manager screen. To return to program viewing, select EXIT at the

top right corner of the screen.

12. Remove the USB memory device from the Master STB.

Note: If the Master STB has a channel lineup, during the export process, logical

channel numbers are automatically assigned in ascending order, starting with 0

(zero), to the physical RF channels of the STB channel lineup to create an FTG

Channel Map. See also note below.

Note: If the exported Clone file is to be used for FTG Mode configuration (i.e., it

contains an FTG Channel Map), it is highly recommended that you open the file in

the FTG File Manager—BEFORE transferring (importing) the file to any Target

STBs—to verify FTG Channel Map and FTG Installer Menu settings. This will also

enable you to confirm channels and add channel attributes, labels, etc.

Importing a Clone File

This section describes how to transfer (import) a Clone or Conguration (.tlx) le from a USB

memory device to an STB using the STB Manager “Import Clone File” option. The “.tlx” le may

be created either from a Master STB Setup that was saved (exported) from a Master STB or in

the FTG File Manager.

Before You Begin

• Ensure the USB device has been formatted with FAT format.

• Avoid using special characters, such as ?, &, @, etc., in the Clone/Conguration (.tlx) lename.

• If the EZ-Manager Wizard appears on the screen when you turn ON the Target STB/display

panel, you can use the wizard’s “USB Conguration” option to access the STB Manager and

complete the import procedure (see “STB Conguration Options” and/or “USB Conguration” on

pages 18 and 24, respectively, as necessary).

• You may also use the Ez Download utility to import the Clone/Conguration (.tlx) le. See “Ez

Download Utility” on pages 26 to 29 for further information.

(Continued on next page)

206-4272

Cloning Procedures (Cont.)

(Continued from previous page)

• If the Target STB is currently in Pass-through Mode and you intend to use the STB’s Zoning

feature(s)—i.e., the Clone/Conguration (.tlx) le you are importing contains an FTG Channel

Map and/or FTG prole(s) with TV Zone and/or Wi-Fi Zone assignments—make sure to assign

the appropriate TV Zone # and/or Wi-Fi Zone # in the STB when directed to do so in the procedure

below. See Reference section, “Using the STB’s Zoning Features,” for further information.

• If you would like the Target STB(s) to remain in Pass-through Mode after the Clone/Conguration

(.tlx) le is imported, ensure the “.tlx” le does not contain an FTG Channel Map; otherwise, the

import procedure will result in the Target STB(s) being congured for FTG Mode.

• If a Clone (.tlx) le (exported Master STB Setup) contains an FTG Channel Map, the physical RF

channels in the FTG Channel Map have been assigned logical channel numbers (see “Exporting

a Clone File” above). When you import the Clone le with the FTG Channel Map to the Target

STB(s), you will have the option to select either logical or physical channel tuning. Even if you

select physical channel tuning, the (list of) physical RF channels in the FTG Channel Map will

remain in logical order.

• If an FTG Conguration (.tlx) le (created in the FTG File Manager) contains an FTG Channel

Map, each logical channel number in the FTG Channel Map has been assigned a physical RF

channel, an IP channel, or an Aux input (the latter designated by 130-0 through 137-0—see also

Reference section, “STB Aux Input Conguration”).

Note: If the FTG Channel Map includes RF channels and Aux inputs only, when you import

the FTG Conguration le on the Target STB(s) you will have the option to select either logical

or physical channel tuning. If you select physical channel tuning, the physical RF channels and

Aux inputs in the FTG Channel Map will remain in logical order. Physical channel tuning is not

available when the FTG Channel Map includes IP channels.

• If the Clone/Conguration (.tlx) le was edited/created in the FTG File Manager, it may contain

multiple zoned FTG Installer Menu proles for different STB/TV models. Make sure it includes the

appropriate Installer Menu prole(s) for the Target STB(s) before performing the procedure below.

Caution: Do not unplug the STB power cord or remove the USB memory device while

importing is in progress, as doing so may cause the STB to malfunction or harm the

USB device, respectively.

Import Clone File Procedure

1. Turn ON the Target STB/display panel.

2. The next step depends on whether the EZ-Manager Wizard appears on the screen when you

turn ON the STB/display:

• If the wizard is displayed, you can complete the import procedure via the wizard, as indicated

above (see “Before You Begin”). However, to continue with this procedure and access the

“Import Clone File” option from the STB menus, exit the EZ-Manager Wizard. Then, continue

with step 3.

• If the wizard is not displayed, go directly to step 3.

3. If applicable (see also “Before You Begin” above), make sure to assign the appropriate Zone

designation(s) in the Target STB at this time.

(Continued on next page)

48 206-4272

(Continued from previous page)

Note: In order for the proper location-specic TV Zone and/or Wi-Fi Zone prole

data to be applied, the Zone designation(s) must be assigned in the Target STB(s)

BEFORE importing is initiated.

4. Insert the USB memory device with the Clone/Conguration (.tlx) le into either of the USB

ports on the Target STB.

5. Press MENU on the Installer Remote to display the STB setup menus (STB is in Pass-through

Mode) or the Function Menu (STB is already in FTG Mode).

6. (STB in Pass-through Mode only) From the Quick Settings Menu displayed at the right of the

screen, select the Advanced menu icon and press OK to access the advanced STB setup

menus.

7. Use the arrow navigation keys to select/highlight either the General menu icon from the STB

setup menus or the Safety menu icon from the Function Menu. Then, press the number “7” key

a total of seven times to display the STB Manager.

Note: Ez Download is always selected by default when you initially access the STB Manager.

Also note that Diagnostics is for service use only.

Select the ﬁle(s) to download, and then select UPDATE below.

Update STB Software

STB_CPU_SW.epk

Update PTC Software

STB_PTC_SW.txt

Import Clone File

STB_IM.tlx

UPDATE

USB DEVICE

EXIT

STB MANAGER

USB 1:

Device Name

Ez Download

Update STB Software

Update PTC Software

Import Clone File

Diagnostics

Current STB SW Version:

version#

None

ﬁlename

.epk/Version:

version#

8. If more than one USB memory device is currently connected to the STB, be sure to select the

USB device that contains the “.tlx” le you wish to use. If necessary, use the arrow keys on

the Installer Remote to select/highlight the USB DEVICE button in the top right corner of the

screen and press OK. Then, use the Up/Down arrow keys to select the appropriate USB device

from the pop-up list of USB devices displayed at the top of the screen.

USB Device

USB 1: Device 1

USB 2: Device 2

9. Use the Up/Down arrow keys to select Import Clone File, and then press OK.

Cloning Procedures (Cont.)

(Continued on next page)

206-4272

Cloning Procedures (Cont.)

(Continued from previous page)

A list of the “.tlx” les stored in the root folder of the USB memory device will be displayed on

the screen.

Select the ﬁle to download, and then select UPDATE below.

UPDATE

USB DEVICE

EXIT

STB-3000-UA_1.TLX

STB_ChMap_IM.tlx Channel Tuning / Channel Banner Display

Logical

Physical

STB MANAGER

USB 1:

Device Name

Ez Download

Update STB Software

Update PTC Software

Import Clone File

Diagnostics

10. Use the arrow keys on the Installer Remote to select/highlight the “.tlx” le to import, and then

press OK.

Note: Filenames of exported Clone les are comprised of the STB model and a numeric

element, for example, STB-3000-UA_1.TLX.

11. If the Clone/Conguration (.tlx) le includes an FTG Channel Map with RF channels and Aux

inputs only, you can choose the format for the channel tuning/banner display. Use the arrow

keys to select the desired Channel Tuning / Channel Banner Display option—either Logical or

Physical—at the right side of the screen. A checkmark will appear at the left of the selected

option. Logical tuning is selected by default.

Note: If an FTG Channel Map includes IP channels, only logical tuning is available. Also, if the

“.tlx” le does not include an FTG Channel Map, the message, “No Channel Map in Clone le,”

will be displayed at the right of the screen.

12. When you are ready to continue, select UPDATE on the screen and then press OK on the

Installer Remote.

Import progress will be displayed on the screen. This process may take a few minutes. Do

NOT remove the USB device while importing is in progress. When the import process is

complete, an IMPORT COMPLETE pop-up banner will briey be displayed at the bottom of

the screen, and then, the STB will reboot. *

13. Remove the USB memory device from the Target STB, and verify that the appropriate

conguration is now resident on the Target STB.

* STB-3000s with CPU software earlier than v3.00.70 will only reboot upon completion of a Clone/Conguration update if the

Clone/Conguration (.tlx) file included a change to Installer Menu item 105 VID OUT FORMAT (see also note regarding item

105 on following page).

(Continued on next page)

50 206-4272

(Continued from previous page)

Note: If the Target STB was previously in Pass-through Mode, and the Clone/Conguration (.tlx)

le that was imported contained an FTG Channel Map, the Target STB CPU is now in FTG Mode.

Upon restart (and, if applicable, conrmation of new video output resolution—see note below),

the STB tunes according to the Start Channel setting in the Installer Menu. If a Start Channel is

specied, the STB will tune to that channel, though, in the case of FTG Mode conguration, a

channel banner will only be displayed if the Start Channel is included in the FTG Channel Map

(depending on your selection in step 11, the channel banner will display either the Start Channel’s

logical channel number or physical RF channel number). Otherwise, the STB will either return to

the last channel tuned (STB in Pass-through Mode) or tune to the rst channel in the FTG Channel

Map (STB in FTG Mode). If the latter, remember that the channels in the FTG Channel Map are

always arranged in logical order, regardless of your selection in step 11.

Note: If you updated the STB conguration with a Clone/Conguration (.tlx) le that included a

change to Installer Menu item 105 VID OUT FORMAT, when the reboot is complete, you will be

prompted to conrm the new video output resolution. See item 105 description on page 38 for

further information.

Cloning Procedures (Cont.)

206-4272

FTG File Manager Utilities Overview

This section provides an overview of the FTG File Manager, which is used for FTG Mode configuration.

FTG File Manager software is available online at: www.lg.com/us/commercial/display-solutions/ftg.

Creating an FTG Conguration File

The procedure below describes how to use the FTG File Manager utilities (see sample screens on pages

53 to 56) to create an FTG Conguration (.tlx) le that can be saved to a USB memory device. In order to

enable decryption of Pro:Idiom encrypted channels, it is recommended that you create or view/edit an

FTG Conguration le using the FTG File Manager.

Note: There is also an option to save (export) FTG Conguration from an STB, which may be desirable

or required if you want to save customized STB setup menu settings to the FTG Conguration le and/or

if you do not know the RF channels at the site. See “

Exporting

a Clone File

” on

pages 44 to 46 for further

information.

This procedure provides an overview of the steps required to create the FTG Configuration (.tlx) file.

Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.

1. Install (if necessary) and launch the FTG File Manager (v1.2.1 or later) on the PC that will be used to

create the FTG Configuration (.tlx) file.

2. You have a number of options:

• To view and/or base a new FTG Conguration le on an existing FTG Conguration (.tlx) le, click

the Open button in the TLX File command section of the FTG File Manager main screen, and select/

double-click on the desired “.tlx” file.

A list of the file’s contents will be displayed in the TLX File Contents window. Either double-click on an

individual item to copy it, or click the Copy All button directly above the TLX File Contents window to

automatically copy all the contents of the opened file to the FTG Configuration List and, if applicable,

TV Setup Menu List. Note, though, that while setup menu settings can be included in the new FTG

Configuration file, the setup menu settings are not available for editing.

Edit the configuration of the items in the FTG Configuration List as well as the FTG Configuration

List itself and/or the TV Setup Menu List, as necessary, to create a new file. Then, proceed to step 3

when you are ready to continue.

• To open an existing FTG Conguration (.rml) le created in the FTG Device Conguration Application

to use its FTG Channel Map and/or FTG Installer Menu settings, click File and then Open from the

FTG File Manager menu bar, and select/double-click on the desired “.rml” le.

Edit channels and/or settings as necessary. Then, proceed to step 3 when you are ready to continue.

• Create a new FTG Channel Map using the FTG Channel Map Editor in the FTG Channel Map

Conguration Utility. Up to 600 logical channels (combined total of both RF and IP mapped channels)

can be defined in the FTG Channel Map.

When you are ready to continue, click Congure and then FTG File Manager from the FTG File

Manager menu bar to return to the FTG File Manager main screen, and then proceed to step 3.

Note: To remove an individual item from the FTG Configuration List or the TV Setup Menu List, click on/

highlight the item to be removed, and then click the Remove Item button directly above the applicable

“List” window. To clear both the current FTG Configuration List and TV Setup Menu List contents, click

the Clear button in the List command section of the FTG File Manager main screen.

(Continued on next page)

52 206-4272

FTG File Manager Utilities Overview (Cont.)

(Continued from previous page)

Note: To clear the current TLX File Contents, click the New button in the TLX File command section of

the FTG File Manager main screen (above the TLX File Contents window).

3. To add an FTG Channel Map to the FTG Configuration List, click under FTG Channel Map. This

will copy the current mapped RF and IP channels to the FTG Configuration List.

Note: If you make any change(s) in the FTG Channel Map Configuration Utility to the current data to

be included in the FTG Configuration List, you will need to recopy the FTG Channel Map to the FTG

Configuration List.

4. (Optional) Load default FTG Installer Menu settings for the STB. In the Installer Menu Templates section

of the FTG File Manager main screen:

• If it is not already selected, click the down arrow at the right of the Region eld, and select North

America. Then, click the down arrow at the right of the Chassis eld, and select STB-3000 from the

drop-down list of available models.

• Click the Load button.

• Use the FTG Installer Menu Conguration Utility to modify settings, if necessary, including Media

Share settings, Wi-Fi Zoning settings, etc. Then, return to the FTG File Manager main screen.

5. If you wish to change the Zone assignment for the current FTG Installer Menu settings, click on the

down arrow at the right of the Zone eld (below the FTG Installer Menu Settings eld), and select the

appropriate Zone (0–8).

Note: See Reference section, “Using the STB’s Zoning Features,” for further information on the TV

Zoning feature and setting the TV Zone # in the STB(s).

6. To add FTG Installer Menu settings to the FTG Configuration List, click under FTG Installer Menu

Settings. This will copy the selected model settings to the FTG Conguration List.

Note: If you make any change(s) in the FTG Installer Menu Configuration Utility to the current data to

be included in the FTG Configuration List, you will need to recopy the FTG Installer Menu settings to

the FTG Configuration List.

Note: Above both the FTG Conguration List and TV Setup Menu List windows, an Edit Zone eld

enables you to change the Zone assignment for each STB Installer Menu and/or TV Setup Menu

prole, if desired. Select/highlight the desired prole, and then click on the down arrow at the right of

the applicable Edit Zone eld to select the appropriate Zone.

7. Click the Save button in the List command section of the FTG File Manager main screen to save the

FTG Configuration List and, if present, TV Setup Menu List contents to an FTG Configuration (.tlx) file

on the PC’s hard drive for later use.

In the Save As pop-up window, name the file (avoid using special characters, such as ?, &, @, etc.)

and click Save. The default folder path is C:\Program Files\Zenith\FTG\TLX. Note that the FTG

Configuration file will have a “.tlx” file extension.

Note: To remove an individual item from the FTG Conguration List or the TV Setup Menu List before

saving the new le, click on/highlight the item to be removed, and then click the Remove Item button

directly above the applicable window. To clear both the current FTG Conguration List and TV Setup

Menu List contents, click the Clear button in the List command section of the FTG File Manager main

screen.

8. Transfer the FTG Configuration (.tlx) file to a USB memory device, and proceed to “Importing a Clone

File” on pages 46 to 50 to transfer the FTG Configuration file to an STB-3000.

206-4272

FTG CONFIGURATION LIST

Data to be saved in FTG

Configuration (.tlx) file.

FTG File Manager Utilities Overview (Cont.)

Note: The data referenced in the FTG Conguration List is only a snap-

shot of the current FTG Channel Map and FTG Installer Menu settings

when copied to the list. If you make any change(s) to the current data

to be included in the FTG Conguration List, you will need to recopy

Channel Map and Installer Menu settings to the FTG Conguration List.

Load default FTG Installer

Menu for STB-3000.

Copy FTG Channel Map

to and from FTG

Configuration List.

Filename of opened FTG

Configuration (.rml) file

created using FTG Device

Configuration Application.

NEW/OPEN

TLX File options.

CLEAR/SAVE

FTG Configuration

and TV Setup Menu

List options.

TV SETUP MENU LIST

STB Setup Menu data to be

saved in FTG Configuration file.

TLX FILE CONTENTS

Data contained in opened

FTG Configuration (.tlx) file.

FTG File Manager Main Screen

The FTG File Manager main screen enables you to compile, modify, and save FTG Configuration (.tlx)

files. It also allows you to change the Zone assignment for each Installer Menu profile, if desired (see

Reference section, “Using the STB’s Zoning Features,” for further information).

Copy FTG Installer Menu

settings to and from FTG

Configuration List. Assign

Zone as applicable.

54 206-4272

FTG File Manager Utilities Overview (Cont.)

FTG Channel Map Conguration Utility

The FTG Channel Map Configuration Utility enables you to create, view, edit, and print a Logical

Channel Map.

PRINT MAP

Click to display a printable

FTG Channel Map Report. The

report can also be exported as

an HTML or Text file.

EDIT/ADD MAP

Click to open the FTG

Channel Map Editor to create

or edit an FTG Channel Map

(see next page).

Filename of opened FTG

Configuration (.rml) file created

using FTG Device Configuration

Application.

206-4272

FTG File Manager Utilities Overview (Cont.)

DELETE

Click to remove highlighted

channel from FTG Channel

Map.

ADD

After defining a new

Logical Channel, click to

add channel to the FTG

Channel Map.

FTG Channel Map Editor

The FTG Channel Map Editor shows a single Logical Channel’s data and the FTG Channel Map.

EXIT

Click to exit editor and

return to FTG Channel

Map Configuration Utility.

LOGICAL CHANNEL MAPPING

Select a Logical Channel number. Then,

assign the RF, Major, and Minor channel

numbers to complete the mapping.

CUSTOM CHANNEL LABELS/ICONS

Enter custom labels and select icons

by name on menu or by number.

SET CHANNEL ATTRIBUTES

Check/select Encrypted, OSD,

or Blank Video.

UPDATE

After editing an existing

Logical Channel’s data,

click to commit the changes

in the FTG Channel Map.

ZONE RESTRICTION

Set Zone restriction(s)

per channel. See

Reference section,

“Using the STB’s

Zoning Features,” for

further information.

56 206-4272

FTG File Manager Utilities Overview (Cont.)

CONFIGURATION SETTINGS

Select tabs for categories of Installer

Menu items to set up STB.

FTG Installer Menu Conguration Utility

Notes:

• The STB I/O tab enables you to set up selected display panel video parameters; the

Pro:Centric tab enables you to set up Pro:Centric-specic parameters; and the LAN tab

enables you to set up a variety of LAN features, including the Wi-Fi Zoning feature. Refer

to the Free-To-Guest (FTG) File Manager User Guide for further information. Also, see

Reference section, “Using the STB’s Zoning Features,” for additional information on Wi-Fi

Zoning.

• Hospital parameters are not applicable for the STB-3000.

Filename of opened FTG Configuration

(.rml) file created using FTG Device

Configuration Application.

206-4272

IP Environment Setup

The IP Environment Menu enables you to set up the network features of the STB. If you intend to

create a Master STB Setup for cloning purposes (see Master STB Setup procedure on pages 41 to

43), all IP Environment settings, with the exception of Wired Network Connection settings, the STB

name (editable in the Media Share Menu), DIAL, and SoftAP settings, may be cloned.

Note: With the exception of Network Setting conguration, the IP Environment settings are editable

(with the Installer Remote) only if the STB is in Pass-through Mode and read-only when the STB is

not in Pass-through Mode.

Accessing the IP Environment Menu

Note: When you enter the IP Environment Menu, the Installer Menu is exited (all current settings

are saved automatically upon exit). If you are also in the process of updating Installer Menu items,

you may wish to set all items as needed before you access the IP Environment Menu. Otherwise,

after exiting the IP Environment Menu, you will need to reaccess the Installer Menu to set additional

items.

1. Use the Installer Remote to access the Installer Menu (see “Accessing the Installer Menu” on page

30 for further information).

2. Navigate to Installer Menu item 119 DATA CHANNEL, and press 2-5-3 + MENU to launch the IP

Environment Menu.

Use the Up/Down arrow keys on the Installer Remote to select the desired menu option and then

press OK. Refer to the following sections for information on each of the IP Environment setup options.

When you have completed your IP Environment conguration as required, press EXIT or on

the Installer Remote to exit the IP Environment Menu.

Network Conguration

This section describes each of the options available in the Network

Menu (see example at right). Refer to the appropriate subsection(s)

on the following pages.

Note: If you intend to use the Wi-Fi Zoning feature with

cloning conguration, you must congure the wireless

network connection as part of the Master STB Setup.

See “Conguring a Wi-Fi Network Connection” on page

59 for further information.

Accessing the Network Menu

With the IP Environment Menu on display, use the arrow keys on the

Installer Remote to select the Network menu option. Then, press

OK.

Note: The STB’s MAC address is displayed at the top of the Network

Menu screen and cannot be modied.

MAC Address

Network Setting

IP Stream Control

Wake On LAN

NETWORK

Network

Pro:Centric

Media Share

Pre-loaded

Apps

C8:08:E9:40:49:F5

58 206-4272

Conguring a Wired Network Connection

Note: If desired, you can congure both wired and wireless

connections. However, note that a wired connection is always

prioritized over a wireless connection. That is, when the STB is

turned OFF and then back ON, if a LAN cable is detected between

the STB and the network, the STB will default to the wired

connection. If the LAN cable is removed, the STB will then attempt

to establish the wireless connection. Whenever the LAN cable is

reconnected, the STB will re-establish the wired connection.

1. Connect the appropriate cable between the STB and the network.

2. With the Network Menu on display, use the arrow keys on the

Installer Remote to select Network Setting. Then, press OK. A

second Network screen (see example at right), with Wired and

Wi-Fi Connection setup options, will be displayed.

By default, the STB uses DHCP, and if a LAN cable is detected,

the STB will attempt to connect to the network as soon as you

select “Network Setting” above. If the STB is able to connect to

the network, a “Connected to Internet” message will be displayed

below the Wired Connection eld.

3. If the network is not congured for DHCP or you want to specify

static conguration data or you would like to change the network

conguration from Manual to Automatic, edit the IP conguration

for this STB as follows:

• In the second Network screen, select Wired Connection and

press OK. Then, in the Wired screen, select Edit (if not already

selected) and press OK.

• In the Edit IP screen, select or de-select the “Set Automatically”

checkbox, as required. A checkmark indicates that Automatic

conguration is enabled.

• To manually edit the IP conguration, for each data entry

eld: Use the arrow keys on the Installer Remote to select

the eld and press OK. You can use the number keys on the

Installer Remote to direct enter numeric values or use the

arrow keys to select the appropriate numbers from the pop-up

virtual keyboard displayed at the bottom of the screen. (Note,

however, that you must use the dot “.” key from the virtual

keyboard to separate each octet of an IP address.) When you

are done, select Enter from the virtual keyboard, and then

press OK on the Installer Remote.

• When all Edit IP elds are set as required, use the arrow keys

on the Installer Remote to select Connect and press OK.

At the top of the screen, you will see a progress display that

indicates status as each network element is conrmed (see

example at right).

NETWORK SETTING

Wired Connection (Ethernet)

Not Connected

Wi-Fi Connection

Not Connected

Network

Pro:Centric

Media Share

Pre-loaded

Apps

EDIT IP

Network / Network Setting / Wired Connection (...

Connected to Internet

Set Automatically

IP Address 10.1.2.4

Subnet Mask 255.255.255.0

Gateway 10.1.2.3

DNS Server 10.1.2.3

DNS

CONNECT

Network

Pro:Centric

Media Share

Pre-loaded

Apps

WIRED

Network / Network Setting /

Connected to Internet

IP (Automatic)

IP Address 10.1.2.4

Subnet Mask 255.255.255.0

Gateway 10.1.2.3

DNS Server 10.1.2.3

MAC Address C8:08:E9:40:49:F5

EDIT

Network

Pro:Centric

Media Share

Pre-loaded

Apps

DNS

(Continued on next page)

IP Environment Setup (Cont.)

206-4272

IP Environment Setup (Cont.)

(Continued from previous page)

If the network is connected successfully, a “Connected to Internet” message will appear just

below the progress display. If the network connection is not successful, the progress display will

identify the network element in which the connection failed. Check your cabling and/or verify the

conguration data, as necessary.

4. Once the wired network conguration is complete, use the arrow keys on the Installer Remote to

return to the IP Environment Menu, as necessary, or press to return to the previous Network

Menu level(s) and/or exit the IP Environment Menu.

Conguring a Wi-Fi Network Connection

1. With the Network Menu on display, use the arrow keys on the

Installer Remote to select Network Setting. Then, press OK.

2. A second Network screen (see example at right), with Wired and

Wi-Fi Connection setup options, will be displayed. Select Wi-Fi

Connection and press OK.

3. In the Wi-Fi screen, available access points are listed in the top

half, while additional menu options are listed in the bottom half, of

the screen. Use the arrow keys on the Installer Remote to select the

desired access point, or select the type of wireless connection to

congure (see descriptions below). Then, press OK.

• Add a hidden wireless network: Direct enter the SSID of an

access point whose SSID has not been enabled for broadcast

(i.e., the access point does not appear in the list of access points).

• WPS PBC: Connect to a network via an access point that

is enabled for PBC.

• WPS PIN: Complete network/PIN verication via the access

point web interface.

Make sure you have the network security password/PIN available

if you are attempting to connect to a secured network.

4. Follow the on-screen instructions to complete the appropriate

network conguration. Use the Installer Remote to navigate

between elds and make entries, etc.

Note: As with a wired connection, you will have the option to specify

the IP conguration for this network connection. Once the initial

connection is established, you can select Advanced Settings

(initially greyed out) at the bottom of the Wi-Fi screen to view the IP

conguration data. In the Advanced screen, select Edit and press

OK, and then modify the IP data, as required. See step 3 of the

wired connection procedure above for further information on the Edit

IP screen elds.

5. Once the wireless network conguration is complete, use the arrow

keys on the Installer Remote to return to the IP Environment Menu,

as necessary, or press to return to the previous Network Menu

level(s) and/or exit the IP Environment Menu.

NETWORK SETTING

Wired Connection (Ethernet)

Not Connected

Wi-Fi Connection

Not Connected

Network / Network Setting /

AAA

BBB

CCC

DDD

EEE

FFF

Add a hidden wireless network

Connect via WPS PBC

Connect via WPS PIN

Advanced settings

Network

Pro:Centric

Media Share

Pre-loaded

Apps

Network

Pro:Centric

Media Share

Pre-loaded

Apps

60 206-4272

IP Environment Setup (Cont.)

IP Stream Control

If necessary, due to an audio and/or video stream delay, IP Stream

Control options enable you to compensate for synchronization

irregularities by allowing audio PTS and video PTS offset modications.

This menu also enables you to specify the IGMP version (2 or 3). Note

that any modications to these settings should be performed by

qualied personnel only.

1. With the Network Menu on display, use the arrow keys on the

Installer Remote to select IP Stream Control. Then, press OK.

2. In the IP Stream Control screen, use the Up/Down arrow keys on

the Installer Remote to select/highlight the appropriate eld—Audio

PTS Offset, Video PTS Offset, or IGMP Version—and then press

OK.

3. If you are modifying an offset value, use the Left/Right arrow keys

to select the appropriate value for the selected eld. Offset values

represent offset time in milliseconds (ms) and can be adjusted

from -500 ms to +500 ms in 10 ms increments. When you are

done, press OK on the Installer Remote.

If you are modifying the IGMP version, use the Up/Down arrow

keys to select the appropriate version number and press OK.

4. Once all modications are completed as required, use the arrow

keys on the Installer Remote to return to the IP Environment Menu,

as necessary, or press to return to the Network Menu and/or exit

the IP Environment Menu.

Wake On LAN Setup

The Wake On LAN feature enables the STB to receive software

updates and/or be powered ON upon receipt of Wake Up Frame

packets and/or Magic Packet data via the wired LAN. To facilitate

use of this feature, note that the appropriate wired connection must

be made. This menu option enables you to specify Wake On LAN

parameters.

1. With the Network Menu on display, use the arrow keys on the

Installer Remote to select Wake On LAN. Then, press OK.

2. In the Wake On LAN screen, use the Up/Down arrow keys on the

Installer Remote to select/highlight the desired eld and press OK.

Then, use the arrow keys to select the desired setting—Disabled,

Update, or Power On—from the drop-down list of options.

3. Once all elds are completed as required, use the arrow keys on

the Installer Remote to return to the IP Environment Menu, as

necessary, or press to return to the Network Menu and/or exit the

IP Environment Menu.

Network

Pro:Centric

Media Share

Pre-loaded

Apps

IP STREAM CONTROL

Network

Pro:Centric

Media Share

Pre-loaded

Apps

WAKE ON LAN

WOL (Wake Up Frame)

Disabled

WOL (Magic Packet)

Disabled

Audio PTS Oset

Video PTS Oset

IGMP

206-4272

IP Environment Setup (Cont.)

* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.

Pro:Centric Setup

Pro:Centric options enable you to congure the STB with the appropriate

settings to connect to the Pro:Centric server. Use the Up/Down arrow

keys on the Installer Remote to navigate between elds.

1. With the IP Environment Menu on display, use the arrow keys on

the Installer Remote to select the Pro:Centric menu option. Then,

press OK.

2. Select/highlight the Media Type eld and press OK on the Installer

Remote to display the drop-down list of options. Then use the Up/

Down arrow keys to select either RF or IP, as applicable.

Note: If the Media Type has already been set in the EZ-Manager

Wizard, the specied value will be reected in this eld.

Note: By default, the Pro:Centric Menu shows RF conguration

elds initially. When “IP” is selected as the Media Type, IP Address

and Port Number elds appear on the screen (in place of the Data

Channel eld).

3. Refer to the appropriate subsection below to congure the STB’s

Pro:Centric settings to match those of the Pro:Centric server.

While the Pro:Centric application itself is an additional feature (see

step 4), the appropriate Pro:Centric server conguration must be

completed to enable E-Z Installation (conguration and software/

rmware) data downloads and, if congured, the Pro:Centric appli-

cation download.

RF Conguration

For STBs in Pass-through Mode or FTG Mode via CPU, if the Data Channel is left at its

default value (AUTO), the STB’s Data Channel Auto Search feature will be enabled. See

Installer Menu item 119 DATA CHANNEL description on page 39 for further information.

• To toggle between AUTO or MANUAL settings for the Data Channel, select/highlight the

Data Channel eld and press OK.

• When the Data Channel eld is set to “MANUAL,” a data entry eld is available on the

screen, and you can specify the RF channel number that will be used by the Pro:Centric

server as its data channel. The Data Channel value can be set from 0 (disabled) to 135. *

Use the arrow keys on the Installer Remote to select the Data Channel data entry eld and

press OK. You can then use the number keys on the Installer Remote to direct enter the

Data Channel, or you can use the arrow keys to select the appropriate number(s) from the

pop-up virtual keyboard displayed at the bottom of the screen. When you are done, select

Enter from the virtual keyboard, and then press OK on the Installer Remote.

Note: If the Data Channel has already been set in the Installer Menu (Installer Menu item 119)

or in the EZ-Manager Wizard, the specied channel will appear in the Data Channel data entry

eld. If you change the Data Channel in this menu, Installer Menu item 119 will now show the

value you entered here.

(Continued on next page)

Network

Pro:Centric

Media Share

Pre-loaded

Apps

PRO:CENTRIC

Mode

Conﬁguration Only

Media Type

Data Channel AUTO

Update Event OFF

62 206-4272

IP Environment Setup (Cont.)

(Continued from previous page)

IP Conguration

Enter the Pro:Centric server IP address and port number in the IP Address and Port Number

elds, respectively. The IP address must match the IPv4 multicast address and the port number

must match the port number that is set in the Pro:Centric server.

For each data entry eld: Use the arrow keys to select the eld and press OK. Then, you can

either use the number keys on the Installer Remote to direct enter data values, or you can use

the arrow keys to select the appropriate number(s)/alphanumeric character(s) from the pop-up

virtual keyboard displayed at the bottom of the screen. When you are done, select Enter from

the virtual keyboard, and then press OK on the Installer Remote.

Note: If the server IP address and port number have already been set in the EZ-Manager

Wizard, the specied data will be reected in the elds displayed.

Note: Setting the Media Type to “IP” automatically sets item 119 DATA CHANNEL in the

Installer Menu to 253. You cannot alter this setting unless you revert Media Type to “RF.” Also,

it is not possible to direct enter “253” in the Installer Menu.

4. Select/highlight the Mode eld and press OK on the Installer Remote to display the drop-down

list of options. Then, use the Up/Down arrow keys to select the appropriate Pro:Centric Application

Mode setting—Conguration Only, FLASH, GEM, or HTML. If the Pro:Centric Application Mode

is set to “Conguration Only,” Pro:Centric application data will not be downloaded.

Note: If the mode has already been set in the Installer Menu (item 098 PRO:CENTRIC) or in the

EZ-Manager Wizard, the specied mode will be reected in this eld. If you change the mode in

this menu, Installer Menu item 098 will now reect the value you selected here.

5. Select/specify the appropriate Update Event setting(s), as required. Based on Update Time

settings, the Wake For Update feature wakes the STB once daily to check for, and if applicable,

download updates from the Pro:Centric server. See Installer Menu item 121 UPDATE TIME HR

description on page 40 for additional information on Wake For Update functionality.

• To toggle between ON and OFF in this menu, select/highlight the Update Event eld and

press OK on the Installer Remote. When Update Event is set to “ON,” an Update Time eld is

displayed on the screen.

• If Update Event is ON, set the Update Time as required. Use the arrow keys on the Installer

Remote to select/highlight the Update Time eld, and then press OK. Hour, Minute, and

Meridiem elds will be displayed. Select each eld in turn and specify the appropriate Wake

For Update time, as desired. Note that the Update Time set in this menu is based on a 12-hour

clock. Ensure the meridiem (AM/PM) specication is set accordingly.

6. Once all elds are completed as required, use the arrow keys on the Installer Remote to return to

the IP Environment Menu, as necessary, or press to exit the IP Environment Menu.

206-4272

IP Environment Setup (Cont.)

1. With the IP Environment Menu on display, use the arrow keys on

the Installer Remote to select Media Share. Then, press OK.

2. In the Media Share screen, all features with the exception of

SoftAP may be toggled from DISABLE to ENABLE and vice versa

as follows: Use the Up/Down arrow keys on the Installer Remote

to select/highlight the desired feature, and then press OK. (See

also notes at right regarding Wi-Fi Direct requirement and Bluetooth

Sound Sync conrmation.)

3. If you would like to enable SoftAP, complete the SoftAP access

conguration as follows:

• Select/highlight SoftAP and press OK on the Installer Remote.

• When you initially access the SoftAP screen, the OFF/ON toggle

button at the top right of the screen is selected/highlighted by

default. Press OK on the Installer Remote to turn SoftAP ON.

• To enable use of a randomly generated security key for SoftAP

access, set the Use Default eld to “Enable” (the Security Key

eld will subsequently be grayed out and the random security key

will be displayed).

Media Share Setup

The Media Share Menu allows you to enable the following Media Share

features on this STB:

• LG Smart Share ®: Allows guests to use the STB/display panel to

access and view data shared either by wired DLNA Certied ® devices

connected to the same LAN as the STB or by wireless LG devices

using LG’s Smart Share application with Wi-Fi Direct ®.

• Screen Share: Enables screen sharing with a Miracast ® or Wireless

Display (WiDi) capable device (e.g., a laptop with Intel ® hardware).

• Media Renderer: Enables the STB to act as a media renderer

device to receive content from DLNA Certied devices on the same

network.

• Bluetooth Sound Sync: Allows guests to listen to audio from a

Bluetooth-enabled mobile device through the display panel’s speakers.

• DIAL (Discovery and Launch): Allows guests to play selected

application media on the STB/display panel from a device with

DIAL capability. The device may be used to cast any application for

which an STB-compatible application has been created/selected for

inclusion in the Pre-loaded Apps Menu (for example, YouTube—see

also following page). Note that the device must be connected to the

same network as the STB.

• SoftAP: Enables the STB to function as a 2.4 GHz wireless access

point for up to five devices. Note that a wired network connection

MUST be established in order for guests to use SoftAP.

Note: See also Reference section, “Using Media Share Features,” for

additional information on these features.

(Continued on next page)

MEDIA SHARE

Network

Pro:Centric

Media Share

Pre-loaded

Apps

Smart Share

Screen Share

Media Renderer

Bluetooth Sound Sync

DIAL

STB Name

406KCEA6Q508

SoftAP

ENABLE

DISABLE

SOFTAP

Network

Pro:Centric

Media Share

Pre-loaded

Apps

Use Default

Disable

Security Key

00000000

Wi-Fi Signal Strength

Not Used

Wi-Fi Channel

Auto

Notes:

• With webOS 2.0, Screen Share MUST

be enabled in addition to Smart Share

in order for guests to use Wi-Fi Direct.

• Bluetooth Sound Sync is only available

with CPU v3.00.18 or later.

• If you enable Bluetooth Sound Sync,

a pop-up conrmation banner will be

displayed since enabling Bluetooth

Sound Sync renders Wireless LG

Sound Sync unavailable. Select

Conrm to continue.

• DIAL is only available with CPU

v4.10.50 or later.

64 206-4272

IP Environment Setup (Cont.)

(Continued from previous page)

• To specify your own security key for SoftAP access, set the Use Default eld to “Disable.”

Then, select the Security Key eld and press OK. In the data entry eld, you can use the

number keys on the Installer Remote to direct enter a numeric security key, or you can use

the arrow keys to select the appropriate alphanumeric characters—at least eight, but no

more than 64—from the pop-up virtual keyboard displayed at the bottom of the screen. Note

that the security key may not contain any special characters (:, /, \, @, etc.). When you are

done, select Enter from the virtual keyboard, and then press OK on the Installer Remote.

• Select the appropriate values in the Wi-Fi Signal Strength, and Wi-Fi Channel elds, as

required.

4. If desired, you can specify a name for this STB so that it is easy to identify and differentiate

from other STBs/TVs for which sharing has been/will be enabled.

To edit the STB name (default: STB’s serial number), use the Up/Down arrow keys to select the

STB Name eld, and then press OK. You can then use the number keys on the Installer Remote

to direct enter a numeric STB name, or you can use the arrow keys to select the appropriate

alphanumeric character(s) from the pop-up virtual keyboard at the bottom of the screen. When

you are done, select Enter from the virtual keyboard, and then press OK on the Installer Remote.

5. Once all elds are completed as required, use the arrow keys on the Installer Remote to return

to the IP Environment Menu, as necessary, or press to exit the IP Environment Menu.

Note: While Smart Share, Screen Share, Media Renderer, and Bluetooth Sound Sync settings

are clonable, DIAL and SoftAP settings, as well as the STB name cannot be cloned.

Pre-loaded Applications

This option allows you to select which of the pre-loaded application

icons to display in the STB’s Smart Launcher, which appears along the

bottom of the screen.

When the Pro:Centric application is disabled, the Smart Launcher is

available to end users via the PORTAL button on the remote control.

Depending on the remote control being used, the Smart Launcher may

also be available to end users via a SMART button.

1. With the IP Environment Menu on display, use the arrow keys on

the Installer Remote to select Pre-loaded Apps. Then, press OK.

2. In the Pre-loaded Apps Menu, a list of available application

options is displayed. Use the Up/Down arrow keys to highlight each

application you wish to select or de-select, and press OK on the

Installer Remote. When an application is selected, a checkmark is

displayed at the left of the application name.

Note: Though not included in the application list on this screen,

all Screen Share applications are available in the Smart Launcher

once they are enabled in the Media Share Menu. See “Media Share

Setup” above.

3. When you are done selecting the pre-loaded application icons to be

displayed in the Smart Launcher, as required, use the arrow keys

on the Installer Remote to return to the IP Environment Menu, as

necessary, or press to exit the IP Environment Menu.

PRE

LOADED APPS

Network

Pro:Centric

Media Share

Pre-loaded

Apps

Application1

Application2

Application3

Application4

Application5

Application6

Note: Make sure to select

any application(s) that may be

used in conjunction with the

DIAL feature, if applicable.

206-4272

Reference: Updating STB Software using a USB Memory Device

This section describes how to update STB (CPU) and/or PTC software using the STB Manager

“Update STB Software” and/or “Update PTC Software” option(s), respectively, though you may also

use the Ez Download utility to update software, if desired. See “Ez Download Utility” on pages 26 to

29 for further information.

Before You Begin

• Software update les must be stored in a folder named “LG_DTV” in the root directory of the

USB memory device.

• Ensure the USB device has been formatted with FAT format.

Update the STB/PTC Software

Note: You can check the STB/PTC software versions by accessing the Installer Menu with the

Installer Remote. See “Accessing the Installer Menu” on page 30 for further information. PTC and

CPU versions are displayed in the Installer Menu footer.

Note for STB CPU Software Update only: If the STB detects a software le on the USB device,

it will automatically display an Update STB Software screen, and if the le contains a later version of

software than is currently running on the STB, you can start the software update from this screen

(select UPDATE and press OK). Otherwise, you can exit the screen (select CANCEL and press

OK), and access the STB Manager as described below.

1. Turn ON the STB/display panel, and then insert the USB memory device into either of the USB

ports on the STB.

Press MENU on the Installer Remote to display the STB setup menus (STB is in Pass-through

Mode) or the Function Menu (STB is not in Pass-through Mode).

3. (STB in Pass-through Mode only) From the Quick Settings Menu displayed at the right of the

screen, select the Advanced menu icon and press OK to access the advanced STB setup

menus.

4. Use the arrow navigation keys to select/highlight either the General menu icon from the STB

setup menus or the Safety menu icon from the Function Menu. Then, press the number “7”

key a total of seven times to display the STB Manager (see example on following page).

Note: Ez Download is always selected by default when you initially access the STB Manager.

Also note that Diagnostics is for service use only.

5. If more than one USB memory device is currently connected to the STB, be sure to select the

USB device that contains the software le you wish to use. If necessary, use the arrow keys

on the Installer Remote to select/highlight the USB DEVICE button in the top right corner of

the screen and press OK. Then, use the Up/Down arrow keys to select the appropriate USB

device from the pop-up list of USB devices displayed at the top of the screen.

USB Device

USB 1: Device 1

USB 2: Device 2

(Continued on next page)

66 206-4272

(Continued from previous page)

Select the ﬁle(s) to download, and then select UPDATE below.

Update STB Software

STB_CPU_SW.epk

Update PTC Software

STB_PTC_SW.txt

Import Clone File

STB_IM.tlx

UPDATE

USB DEVICE

EXIT

STB MANAGER

USB 1:

Device Name

Ez Download

Update STB Software

Update PTC Software

Import Clone File

Diagnostics

Current STB SW Version:

version#

None

ﬁlename

.epk/Version:

version#

ﬁlename

.epk/Version:

version#

6. Use the Up/Down arrow keys to select Update STB Software or Update PTC Software, as

applicable, and press OK.

Depending on your selection, a list of either STB or PTC software files stored in the LG_DTV

folder on the USB memory device will be displayed on the screen. Above the listing of files,

you can also see the current version of STB or PTC software. The following screen sample

illustrates an Update STB Software screen.

UPDATE

USB DEVICE

EXIT

STB MANAGER

USB 1:

Device Name

Ez Download

Update STB Software

Update PTC Software

Import Clone File

Diagnostics

Select the ﬁle to download, and then select UPDATE below.

Current STB Software Version: version#

ﬁlename

.epk/Version: version#

ﬁlename

.epk/Version: version#

7. Use the arrow keys to select/highlight the update le to download, and then press OK.

8. When you are ready to download the update, select UPDATE on the screen, and then press

OK on the Installer Remote.

Software update progress will be displayed on the screen. Do NOT remove the USB device until

the software update is complete. When the software update is complete, an UPDATE COMPLETE

pop-up banner will briey be displayed at the bottom of the screen, and then, the STB will reboot.

Reference: Updating STB Software using a USB Memory Device

(Cont.)

206-4272

Reference: Display Panel Specications

This section describes the types of commercial display panels that may be used with the STB-3000.

LG Hospitality TV Panels

The STB-3000 may be used with LG Hospitality TVs (LP645H, LT670H, etc.) that support Multiple

Protocol Interface (MPI).

Use the MPI/MTI cable provided to connect the RJ-12 MPI/MTI TELEVISION CONTROL port on

the STB-3000 front jack panel to the MPI port on the rear jack panel of the display. *

LG Commercial Monitors & Public Display TV Panels

The STB-3000 may be used with LG Commercial Monitors (M3203CCBA, M3204C, etc.) or Public

Display TVs (LD450C, LT560C, etc.) that support the TV-Link Monitor (TLM) interface.

Use the 3.5 mm-to-DB9 TLM cable provided to connect the 3.5 mm RS-232C TELEVISION

CONTROL jack on the STB-3000 rear jack panel to the RS-232 CONTROL connector on the rear

jack panel of the display. *

Note that when you use these model display panels, you must set Installer Menu item 113 PANEL

TYPE appropriately. For example, if you are using an LG Commercial Monitor or Public Display TV

that does not support an xb Input Select command, set Installer Menu item 113 to 2. If you are using

an LG Commercial Monitor or Public Display TV that does support an xb Input Select command, set

Installer Menu item 113 to 4 (default).

Note: Installer Menu item 113 values 0, 1, and 3 are available to support legacy panel types.

Commercial Non-LG TV Panels

The STB-3000 may be used with commercial non-LG TVs that support SONIFI’s Multiple Television

Interface (MTI) protocol.

Use the MPI/MTI cable provided to connect the RJ-12 MPI/MTI TELEVISION CONTROL port on

the STB-3000 front jack panel to the MTI (typically labeled “DATA”) port on the rear jack panel of

the display. *

Note that some MTI interface configuration may be required on non-LG TVs. Refer to the TV

manufacturer’s documentation to determine if any configuration is required.

* On early STB-3000 models, the RS-232C TELEVISION CONTROL jack is labeled “DISPLAY CONTROL 1” and the

MPI/MTI TELEVISION CONTROL port is labeled “DISPLAY CONTROL 2.”

68 206-4272

Reference: STB Aux Input Conguration

DIRECT ACCESS

Tuning * STB

ENABLE MPI DATA

Installer

Menu Item

046 START

AUX SRCE

(Start Aux

Source)

Value

Installer Menu

MPI DATA

STATUS TYPE

0x41 SOURCES

ENABLED (R/W)

DATA STATUS

TYPE 0xD2

CURRENT AV

SOURCE (R)

DATA STATUS

TYPE 0x0D

AUX

SOURCE (R)

Installer

Item 029

OLD OCV

= 0

Installer

Item 029

OLD OCV

= 1

Aux

Input

Mode Item Function Value Enable

Bit Label Value Value Description

131-0 91-0 AV

(Rear) CV 39 REAR AUX

EN 1 1 Rear Video (Aux) 1 0 VIDEO 1

132-0 92-0 HDMI2

DTV

91 HDMI2

ENABLE

2 S-Video Rear 2

0 VIDEO

PC 2 2

COMPUTER

133-0 93-0 HDMI1

DTV

35 HDMI1

ENABLE

Front

Computer 3

0 VIDEO

PC 2 2

COMPUTER

* Use Installer Remote to enter channel number indicated based on OLD OCV Installer Menu setting.

206-4272

Reference: Auto Input(s) Sensing Feature

This section provides detailed settings information for Installer Menu item 042 AUTO INPUTS.

Note: When both item 042 AUTO INPUTS and item 041 SIMPLINK EN are enabled in the Installer Menu,

HDMI inputs will be detected by SIMPLINK, but the Auto Input(s) Sensing Feature will not function.

In the Installer Menu, an informational code is displayed at the right of each Auto Inputs value, for example:

PTC INSTALLER MENU

STB_3000

CPU

CTV

042 AUTO INPUTS 193 76XXXXX0

UPN 000-000-000-000 ASIC D279

PTC V#.##.### CPU V#.##.##.##

Each code consists of eight characters that identify the Aux input(s) for which auto-sensing is enabled. The

following table identies the Installer Menu display code Input # for each Aux input that is available on the

STB-3000. The table also identies the Installer Menu item associated with each Aux input. Remember that

in order for auto-sensing to be enabled for an input, that input must also be enabled in the Installer Menu.

Installer Menu

Display Code

Input #

Aux

Input

Installer Menu

Item Function

0AV 039 REAR AUX EN

6 HDMI 1 035 HDMI1 ENABLE

7 HDMI 2 091 HDMI2 ENABLE

To disable auto-sensing for all available Aux inputs, set item 042 to 0. To enable auto-sensing for all available

Aux inputs, set item 042 to 255. All other available settings (i.e., settings for individual inputs), are listed in the

table below.

Item 042

Value

Inputs Installer Menu

Display

AV HDMI 1 HDMI 2

001 Enabled Disabled Disabled DDXXXXX0

064 Disabled Enabled Disabled D6XXXXXD

065 Enabled Enabled Disabled D6XXXXX0

128 Disabled Disabled Enabled 7DXXXXXD

129 Enabled Disabled Enabled 7DXXXXX0

192 Disabled Enabled Enabled 76XXXXXD

193 Enabled Enabled Enabled 76XXXXX0

X = Aux input source is Disabled or Not Available (i.e., on this STB model)

D = Auto-sensing for input is Disabled

Input # = Auto-sensing for input is Enabled

AUTO INPUTS Display Code

This example illustrates Installer Menu item 042 value

193, which enables auto-sensing for all available Aux

inputs. The input #s in the display code (7, 6, 0 in this

example) identify the enabled Aux inputs. See first

table below for a listing of the STB-3000 Aux inputs

and their corresponding display code input #s. The

second table below shows the display codes for all

item 042 values.

70 206-4272

This section describes how to restore all factory defaults or just the Installer Menu factory defaults either

on a single STB that is currently in Pass-through or FTG Mode or on multiple STBs that are currently in

FTG Mode.

Restore All Factory Defaults

This section describes how to restore a single STB, regardless of its current mode, to a factory default

condition. The following procedure requires that you contact LG technical support to obtain a predened

value/password for Installer Menu item 117 FACT DEFAULT that enables access to initiate a factory

“IN-STOP” process, which restores all factory defaults on the STB. This procedure will also reactivate the

EZ-Manager Wizard.

1. Use the Installer Remote to access the STB’s Installer Menu.

2. Navigate to Installer Menu item 117 FACT DEFAULT, and key in the value provided by technical support.

Then, press OK.

3. At the prompt for conrmation, key in the password provided by technical support. This will initiate the

IN-STOP that restores the factory defaults on the STB.

Installer Menu Item 117 FACT DEFAULT

If the STB is currently in Pass-through Mode, you can set Installer Menu item 117 FACT DEFAULT to 1

to restore the Installer Menu factory defaults and clear the PTC Channel Map, including any assigned

channel icons and custom text labels. Note, however, that if a complete restoration of the STB’s factory

defaults is required, see “Restore All Factory Defaults” above.

Additional FTG Mode Options

There are two additional options for restoring Pass-through Mode/Installer Menu factory defaults on STBs

that are in FTG Mode. The rst enables you to restore a single STB to Pass-through Mode, while the

second enables you to restore multiple STBs to Pass-through Mode at one time. However, both options

require that you create a “Zero Mapped Channels” FTG Conguration (.tlx) le, i.e., an FTG Conguration

le with no data. Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.

• Using a USB memory device, import a “Zero Mapped Channels” FTG Conguration (.tlx) le to the STB.

Refer to “Importing a Clone File” on pages 46 to 50 for further information on the import procedure.

• If your system uses a Pro:Centric server for remote management, use the Pro:Centric server Admin

Client to load a “Zero Mapped Channels” FTG Conguration (.tlx) le on the Pro:Centric server. Refer to

the Pro:Centric Server Admin Client User Guide for further information.

Reference: Restoring Factory Defaults on the STB(s)

206-4272

Reference: Using the STB’s Zoning Features

This section describes the TV Zoning and Wi-Fi Zoning features available with the STB-3000. These

features are primarily intended for use when the STB is congured for FTG Mode operation; however,

Wi-Fi Zoning, along with selected elements of TV Zoning (Installer Menu and TV [STB] Setup Menu prole

Zone assignments), may also be used with STB cloning processes using a USB memory device / “.tlx” le.

Refer to the appropriate section(s) below for further information on the Zoning features and how to set the

TV Zone # or Wi-Fi Zone # in an STB that is currently in Pass-through Mode.

TV Zoning Feature

The TV Zoning feature enables you to create localized congurations for STBs/displays in selected locations,

or “Zones,” within the installation environment, for example, a hotel lobby, tness center, restaurant, etc.

Using the TV Zoning Feature with FTG Mode Conguration

The FTG File Manager may be used to create an FTG Conguration (.tlx) le that contains multiple Installer

Menu and TV Setup Menu proles, each with its own Zone assignment. Up to nine unique Zones can be

designated for STB-3000 FTG Installer Menu and/or TV Setup Menu proles. Zone restrictions can also be

placed on individual channels in the FTG Channel Map. Thus, for example, you may create an FTG Installer

Menu and/or TV Setup Menu prole to specically congure an STB/display in the hotel lobby and also

restrict the channels that are available to be tuned on that STB/display.

The TV Zone # must be set appropriately on each STB in order for the STBs to be congured correctly.

See “Set the TV Zone # and/or Wi-Fi Zone # in the STB” on page 73, and set the TV Zone # in all the

STBs in a select area, so that the STBs/displays are congured with corresponding FTG Installer Menu

and/or TV Setup Menu settings and/or can omit channels that have been restricted in the FTG Channel

Map. TV Zone 0 is the default TV Zone #.

The following subsections briey describe how to assign Zone designations in the FTG File Manager.

Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.

FTG Installer Menu Prole Zone Assignments

The FTG File Manager main screen enables you to change the Zone assignment (default = Zone 0) for each

Installer Menu prole to be included in an FTG Conguration (.tlx) le. For example, you may wish to create

one STB-3000 Installer Menu prole for the hotel lobby and another STB-3000 Installer Menu prole for the

tness center, both of which are different from the Installer Menu prole used for standard guest rooms. The

TV Zoning feature enables you to save multiple STB-3000 FTG Installer Menu proles, each with its own

Zone assignment, in one FTG Conguration le. If each STB in the aforementioned locations (Zones) has

had its TV Zone # set appropriately, as described in the procedure on page 73 or via the EZ-Manager Wizard,

the STB(s) will only be congured by the Installer Menu prole that matches its(their) Zone setting.

In the FTG File Manager main screen, you can also edit the Zone assignment for each Installer Menu prole

and/or TV Setup Menu prole already present in the FTG Conguration List and TV Setup Menu List windows.

Note: See also the FTG File Manager main screen overview on page 53. In addition, note that TV Setup

Menu proles cannot be created in the FTG File Manager; they must be saved (exported) from a TV/STB.

FTG Channel Map Zone Restrictions

The FTG Channel Map Editor in the FTG File Manager’s FTG Channel Map Conguration Utility enables

you to place Zone restrictions on individual channels that may be prohibited or deemed unsuitable for

certain locations. In the FTG Channel Map Editor, one or more Zone restrictions (1–8) may be placed on

each channel that is to be restricted. For example, if you wish to restrict a channel from Zones 2 and 4,

select both “Zone 2” and “Zone 4” in the Zone Restriction section of the FTG Channel Map Editor screen

when dening or editing that channel.

72 206-4272

Reference: Using the STB’s Zoning Features (Cont.)

Note: While a channel can be restricted from up to eight Zones, an STB can only ever be in (set for) one

Zone. See also the FTG Channel Map Editor overview on page 55.

At the same time, keep in mind that the TV Zone designations are not mutually exclusive. That is, you may

opt to place Zone restrictions on selected channels in the FTG Channel Map, but at the same time, you

can choose to congure all STBs/displays at the site with the same Installer Menu and/or TV Setup Menu

settings. For example, an FTG Conguration (.tlx) le being used to congure the STBs/displays at a site

may contain multiple Installer Menu and TV Setup Menu proles with different Zone assignments, as well

as an FTG Channel Map with Zone restrictions on several channels. Each STB that still has the default TV

Zone 0 setting will only be congured by the Installer Menu and/or TV Setup Menu prole(s) with a Zone 0

designation. If, on the other hand, the TV Zone # is set to 1, the STB will rst look in the le for the STB-3000

Installer Menu and/or TV Setup Menu prole(s) with a Zone 1 designation. If none of the STB-3000 Installer

Menu and/or TV Setup Menu proles has a Zone 1 designation, the STB will then look for the STB-3000

prole(s) with a Zone 0 designation. For the FTG Channel Map conguration, when the TV Zone # is set to

0, the STB will ignore any Zone restrictions (1–8) that may be placed on channels in the FTG Channel Map.

However, when the TV Zone # is set to 1, the STB will omit any channels that have been restricted from

Zone 1 in the FTG Channel Map.

Using the TV Zoning Feature with Cloning Conguration

A location-specic conguration / Clone (.tlx) le may be saved (exported) from a Master STB and then be

used to congure Target STBs. For example, if the TV Zone # in the Master STB is set to 3 before the Clone

le export is initiated, the Master STB’s Installer Menu and TV Setup Menu proles will be saved with the

TV Zone 3 assignment. In order to congure the Target STBs with the Zone 3 Installer Menu and TV Setup

Menu proles exported from the Master STB, you must set the TV Zone # accordingly in the Target STBs

before importing the Clone le. See “Set the TV Zone # and/or Wi-Fi Zone # in the STB” on the following

page. Also, see “Cloning Procedures” on pages 44 to 50 for additional information on the cloning processes.

TV Zone 0 is the default TV Zone #.

Wi-Fi Zoning Feature

The Wi-Fi Zoning feature enables you to use a Clone/Conguration (.tlx) le to congure an individual

STB or group of STBs with a particular Wi-Fi access point’s login data to create “Wi-Fi Zones” within the

installation environment.

Using the Wi-Fi Zoning Feature with FTG Mode Conguration

The FTG File Manager may be used to create an FTG Conguration (.tlx) le with an FTG Installer Menu

prole that contains login data for multiple Wi-Fi access points, each assigned a Wi-Fi Zone #. Up to 100

Wi-Fi Zones can be designated within each FTG Installer Menu prole, thus allowing for distribution of the

Wi-Fi network load. For example, if a site has 50 STB-3000s within close proximity, you may wish to create

10 Wi-Fi Zones, each with its own access point that has unique login data, so that no more than ve of the

STBs are connected to one access point at any given time.

In order for an STB to be congured by the proper Installer Menu prole with the desired Wi-Fi access point

# and the Wi-Fi Zone # in the STB (see “Set the TV Zone # and/or Wi-Fi Zone # in the STB” on the following

page for further information). If the Wi-Fi Zone # in the STB is set to 0 (default), the STB will not obtain

access point login data from the Installer Menu prole with which it is congured unless the prole contains

the global Wi-Fi Zone 100. Any STB that does not nd its matching Wi-Fi Zone # in the FTG Conguration

le, but that does nd the global Wi-Fi Zone 100, will be congured with the global access point login data.

Refer to the Free-To-Guest (FTG) File Manager User Guide for further information on dening Wi-Fi

Zones in the FTG File Manager.

206-4272

Reference: Using the STB’s Zoning Features (Cont.)

Using the Wi-Fi Zoning Feature with Cloning Conguration

A location-specic Wi-Fi conguration / Clone (.tlx) le may be saved (exported) from a Master STB and

then be used to congure Target STBs. First, the wireless network (i.e., the access point login data) must

be congured in the Master STB’s IP Environment Menu (see “Conguring a Wi-Fi Network Connection” on

page 59). Then, a Wi-Fi Zone # must be set in the Master STB (see “Set the TV Zone # and/or Wi-Fi Zone

# in the STB” below). If desired, a TV Zone # may also be set in the Master STB.

For example, if the Wi-Fi Zone # is set to 4 and the TV Zone # is set to 5 before the Clone le export is

initiated, the Master STB’s Installer Menu prole will be saved with the Zone 5 assignment, and within that

Installer Menu prole, the access point login data for wireless networking (i.e., SSID, security type, and

security key) will be saved with a Wi-Fi Zone 4 assignment. In order to congure the Target STBs with the

proper Installer Menu prole and access point login data, you must set both the TV Zone # and the Wi-Fi

Zone # in the Target STBs accordingly before importing the Clone le. See “Set the TV Zone # and/or Wi-Fi

Zone # in the STB” below. Also, see “Cloning Procedures” on pages 44 to 50 for additional information on

the cloning processes. If the Wi-Fi Zone # in the STB is set to 0 (default), the STB will not obtain access

point login data from the Installer Menu prole with which it is congured unless the prole contains the

global Wi-Fi Zone 100. Any STB that does not nd its matching Wi-Fi Zone # in the Clone le, but that

does nd the global Wi-Fi Zone 100, will be congured with the global access point login data.

Set the TV Zone # and/or Wi-Fi Zone # in the STB

You can set the TV Zone # and/or the Wi-Fi Zone # in the EZ-Manager Wizard (see “EZ-Manager Wizard”

on pages 16 to 25) or, if the STB is in Pass-through Mode, via the STB’s setup menus as described below.

Note that the following procedure can only be performed while the STB is in Pass-through Mode. You will

also be able to specify a Label (North, South, East, West) and Room Number for this STB, if desired.

1. Turn ON the STB/display panel.

2. Press MENU on the Installer Remote, and use the arrow navigation keys to select/highlight the

General menu icon. Then, press OK.

3. In the General Menu, use the Up/Down arrow keys to select Room Info, and then press OK.

4. In the Room Info screen, complete the appropriate elds as described below. Use the Up/Down arrow

keys on the Installer Remote to navigate between each of the elds.

• Wi-Fi Zone: Enables you to set a Wi-Fi Zone # so that the STB can be congured with a particular

access point’s login data for wireless networking. Login data (i.e., SSID, security type, and security

key) may be provided in a Clone/Conguration (.tlx) le.

To assign a Wi-Fi Zone, select/highlight the Wi-Fi Zone eld and press OK. Then, use the Left/Right

arrow keys to specify the desired Wi-Fi Zone # (1–99). Press OK when you are nished.

• TV Zone: Enables you to set a TV Zone # so that the STB can be congured with Installer Menu and/or

STB Setup Menu settings intended only for the assigned Zone. The Installer Menu and/or STB Setup

Menu settings may be provided in a Clone/Conguration (.tlx) le. If the STB is being congured for

FTG Mode, the TV Zone # setting also allows the STB to omit channels that have been restricted in the

FTG Channel Map (see “FTG Channel Map Zone Restrictions” on page 71).

To change the TV Zone, select/highlight the TV Zone eld and press OK. Then, use the Left/Right

arrow keys to specify the desired TV Zone # (0–8). Press OK when you are nished.

(Continued on next page)

74 206-4272

(Continued from previous page)

• Label: Allows you to select a North, South, East, or West text label for this STB. Select/highlight the

Label eld and press OK. Then, use the Up/Down arrow keys to select the applicable label. Press

OK when you are nished.

• Room Number: Allows you to specify the number of the room—up to 16 characters—in which the STB

is located. To enter a room number, use the Up/Down arrow keys to select/highlight the Room Number

eld and press OK. You can then use the number keys on the Installer Remote to direct enter a room

number, or you can use the arrow keys to select the appropriate alphanumeric character(s) from

the pop-up virtual keyboard at the bottom of the screen. When you are done, select Enter from the

virtual keyboard, and then press OK on the Installer Remote.

5. When you have completed the elds as necessary, press to return to and/or exit the STB menus, or

press MENU to return to program viewing.

Reference: Using the STB’s Zoning Features (Cont.)


Sound

Channels

General

Safety

Accessibility

GENERAL

Language

Room Info

Time & Date

Timers

Set ID

SIMPLINK

USB Eject


Sound

Channels

General

Safety

Accessibility

ROOM INFO

General /

Wi-Fi Zone

TV Zone

Label

-----

Room Number

206-4272

Reference: Using Media Share Features

When the appropriate Media Share options are enabled in the IP Environment / Media Share Menu (see

“Media Share Setup” on pages 63 to 64, as necessary), guests have the ability to use one or more of the

following Media Share features:

• Smart Share: Allows guests to use the STB/display panel to access and view media les (photos, videos,

music, etc.) shared either by wired DLNA Certied devices (the devices must be connected to the same

LAN as the STB) or by wireless LG devices using LG’s Smart Share application with Wi-Fi Direct.

• Screen Share: Allows guests to select a Miracast or WiDi capable device, whose screen can be displayed

on the display panel screen.

• Bluetooth Sound Sync: Allows guests to listen to audio from a Bluetooth-enabled mobile device through

the display panel’s speakers.

• DIAL: Allows guests to play selected application media on the STB/display panel from a device with

DIAL capability. The device may be used to cast any application for which an STB-compatible application

has been created/selected for inclusion in the Pre-loaded Apps Menu (see “Pre-loaded Applications” on

page 64).

• SoftAP: Allows guests to use the STB as a 2.4 GHz wireless access point for up to ve devices.

This section provides an overview of the Smart Share, Screen Share, Bluetooth Sound Sync, DIAL, and

SoftAP functionality.

Note: Typically, only one Media Share feature may be used at a time. If one feature is

currently in use, you may have to exit or turn it OFF in order to use/turn ON another. In some

cases, you will be prompted to conrm your action. Follow the display prompts as necessary.

Smart Share

Refer to the subsections below for information on using the Smart Share features.

Smart Share with DLNA Certified Devices

The following steps describe how to access and use the Smart Share feature with wired DLNA Certied

devices on the same LAN as the STB.

1. Turn ON the STB/display panel, and then use one of the following methods to access media les/folders,

depending on the current conguration of the STB:

• If the Pro:Centric application is not loaded, press PORTAL on the Installer Remote, and use the Left/

Right arrow keys to select Smart Share from the STB’s Smart Launcher.

• If the Pro:Centric application is loaded, press MENU on the Installer Remote to display the Function

Menu, use the Up/Down arrow keys to select/highlight the General menu icon, and then press OK.

In the General Menu, use the Up/Down arrow keys to select SmartShare.

Note: Depending on the remote control being used (in any mode), you may also access the Smart

Launcher via the SMART button.

2. In the Smart Share screen, select the desired Smart Share device, and then select the desired media

category to view les.

76 206-4272

Reference: Using Media Share Features (Cont.)

Smart Share with Wi-Fi Direct

The following steps describe how to access and use Wi-Fi Direct (i.e., to connect to a wireless LG device).

Remember that you must also turn ON Wi-Fi Direct and launch the Smart Share application on the LG

device.

Note: Screen Share MUST be enabled in the Media Share Menu in addition to Smart Share in order for

guests to use Wi-Fi Direct (see “Media Share Setup” on pages 63 to 64).

1. Turn ON the STB/display panel, and press MENU on the Installer Remote to display the STB menus

(either the setup menus or the Function Menu depending on whether the STB is or is not in Pass-through

Mode).

2. Use the Up/Down arrow keys to select/highlight the General menu icon, and then press OK.

3. In the General Menu, use the Up/Down arrow keys to select Wi-Fi Direct, and then press OK.

Note: The example at left

shows the General Menu when

the STB is in Pass-through

Mode. The Wi-Fi Direct screen

is the same whether the STB is

or is not in Pass-through Mode.


Sound

Channels

General

Safety

Accessibility

GENERAL

Language

Room Info

Time & Date

Timers

Wi-Fi Direct

Set ID

SIMPLINK

USB Eject


Sound

Channels

General

Safety

Accessibility

FI DIRECT

General /

[TV]LG Smart TV

REFRESH LIST

Note: If Wi-Fi Direct is currently grayed out, you may need to exit/turn OFF another Media Share

feature in order to use Wi-Fi Direct. For example, make sure that SoftAP is turned OFF. See also note

on previous page regarding simultaneous use of Media Share features.

4. When you access the Wi-Fi Direct screen, the STB will automatically initiate a search for all available

Wi-Fi Direct enabled wireless devices, including mobile devices, laptops, etc. Devices found will be listed

in the lower half of the screen.

Note: If the search does not initially locate any devices, you can select REFRESH LIST and press OK

to rescan.

5. Use the Up/Down arrow keys to select/highlight the device with which you wish to share, and then

press OK.

The share request will be sent to the targeted device. The user of that device may choose to allow or not

allow the share connection. Similarly, other devices may request share connections with this STB (pop-up

share requests typically appear in the bottom right of the display panel screen).

6. Use one of the following methods to access media les/folders, depending on the current conguration

of the STB:

(Continued on next page)

206-4272

Reference: Using Media Share Features (Cont.)

(Continued from previous page)

• If the Pro:Centric application is not loaded, press PORTAL on the Installer Remote, and use the Left/

Right arrow keys to select SmartShare from the STB’s Smart Launcher.

• If the Pro:Centric application is loaded, use the Up/Down arrow keys to select SmartShare from the

General Menu.

Note: Depending on the remote control being used (in any mode), you may also access the Smart

Launcher via the SMART button.

7. In the Smart Share screen, select the desired Smart Share device, and then select the desired media

category to view les.

Screen Share (Miracast / WiDi)

The following steps describe how to access and use the Miracast / WiDi features.

1. Turn ON the STB/display panel, and then use one of the following methods to access the Screen Share

application, depending on the current conguration of the STB:

• If the Pro:Centric application is not loaded, press PORTAL on the Installer Remote, and use the Left/

Right arrow keys to select Screen Share from the STB’s Smart Launcher.

• If the Pro:Centric application is loaded, press MENU on the Installer Remote to display the Function

Menu, use the Up/Down arrow keys to select/highlight the General menu icon, and then press OK. In

the General Menu, use the Up/Down arrow keys to select Input. In the Input Menu, use the Up/Down

arrow keys to select Screen Share.

Note: Depending on the remote control being used (in any mode), you may also access the Smart

Launcher via the SMART button.

Note: If Screen Share is currently not available in the Smart Launcher or in the Input Menu (the latter

applicable to FTG Mode only), you may need to turn OFF another Media Share feature in order to use

Screen Share. For example, access the General Menu and make sure that SoftAP is turned OFF. See

also note on page 75 regarding simultaneous use of Media Share features.

2. Follow the on-screen instructions to initiate the Miracast / WiDi connection from your Miracast / WiDi

device. Note that you may be prompted to enter a PIN number that appears on the display panel screen

into your Miracast / WiDi connection window to complete the connection.

Once the connection is established, the STB display may be used as a second screen for the Miracast /

WiDi device.

Bluetooth Sound Sync

The following steps describe how to access and use the Bluetooth Sound Sync feature.

Note: Bluetooth Sound Sync is only accessible from the STB’s Smart Launcher. If the Pro:Centric

application is loaded, you will need a remote with a SMART button in order to display the Smart Launcher.

1. Turn ON the STB/display panel, and then use one of the following methods to display the STB’s Smart

Launcher, depending on the current conguration of the STB:

(Continued on next page)

78 206-4272

Reference: Using Media Share Features (Cont.)

(Continued from previous page)

• If the Pro:Centric application is not loaded, press PORTAL on the Installer Remote.

• If the STB is not in Pass-through Mode, press SMART on the Installer Remote (see note above

regarding remote with SMART button).

2. Use the Left/Right arrow keys on the Installer Remote to select Bluetooth Sound Sync, and then

press OK.

3. Follow the on-screen instructions to initiate and conrm pairing between your device and the STB.

Once Bluetooth pairing is successful, audio from the device may be heard through the display panel’s

speakers. (Make sure the STB volume is at the appropriate level.)

DIAL

The following steps describe how to access and use DIAL. Remember that the device used MUST be

connected to the same network as the STB.

Note: DIAL may only be used with device applications for which a STB-compatible application (for

example, YouTube) has been created/selected for inclusion in the Pre-loaded Apps Menu (see “Pre-loaded

Applications” on page 64).

Note: The applications that may be used in conjunction with DIAL are only accessible from the STB’s

Smart Launcher. If the Pro:Centric application is loaded, you will need a remote with a SMART button in

order to display the Smart Launcher.

1. Turn ON the STB/display panel, and then use one of the following methods to display the STB’s Smart

Launcher, depending on the current conguration of the STB:

• If the Pro:Centric application is not loaded, press PORTAL on the Installer Remote.

• If the Pro:Centric application is loaded, press SMART on the Installer Remote (see note above

regarding remote with SMART button).

2. Use the Left/Right arrow keys on the Installer Remote to select the desired application, and then press

OK.

3. On your device, launch the same application, and use the appropriate options (typically available

via Settings) to initiate a connection/pairing with the STB. You may also need to access the Settings

options from the application on the STB to complete the pairing operation. Follow the on-screen

instructions.

Once the connection/pairing is successful, you will be able to view media from the application on the STB/

display panel.

SoftAP

The following steps describe how to access and use the SoftAP feature.

1. Turn ON the STB/display panel, and press MENU on the Installer Remote to display the STB

menus (either the setup menus or the Function Menu depending on whether the STB is or is not in

Pass-through Mode).

(Continued on next page)

206-4272

(Continued from previous page)

2. Use the Up/Down arrow keys to select/highlight the General menu icon, and then press OK.

3. In the General Menu, use the Up/Down arrow keys to select SoftAP, and then press OK.

Note: If SoftAP is currently grayed out, make sure a wired LAN connection has been established.

4. When you initially access the SoftAP screen, the OFF/ON toggle button at the top right of the screen

is selected/highlighted by default. If SoftAP is currently OFF, press OK on the Installer Remote to turn

SoftAP ON. When SoftAP is ON, the SoftAP access information, including the SSID and security key, is

displayed in the lower half of the screen.

Note: The example at left

shows the General Menu when

the STB is in Pass-through

Mode. The SoftAP screen is

the same whether the STB is

or is not in Pass-through Mode.


Sound

Channels

General

Safety

Accessibility

GENERAL


Sound

Channels

General

Safety

Accessibility

SOFTAP

General /

SoftAP enables the STB to act as a wireless access point to

provide Internet access for up to ﬁve Wi-Fi devices.

Note: A wired network connection MUST be established

and the STB/display panel must be turned ON.

SoftAP Access Information

SSID

410KKTF1J505

Security Key

LGxxxxxx

Number of Connected Devices

Language

Room Info

Time & Date

Timers

SoftAP

Set ID

SIMPLINK

USB Eject

5. Make sure Wi-Fi is turned ON on your device, and then look for the STB’s SSID in the list of available

Wi-Fi networks. Initiate the connection, and enter the security key as requested.

Once a device is connected successfully to the STB’s network, you can use it to access the Internet. Up

to ve devices may be connected at a time; the Number of Connected Devices eld in the SoftAP screen

shows the number of devices currently connected to the STB Wi-Fi access point.

Note: A wired network connection MUST be established in order for guests to use SoftAP. Also, the

SoftAP feature may only be used while the STB/display panel is turned ON.

Note: If the Wi-Fi frequency is not automatically detected, set the frequency in the device(s) to 2.4 GHz.

Reference: Using Media Share Features (Cont.)

80 206-4272

ANTENNA/

CABLE IN

LAN

IN 2

IN 1

USB IN 2

USB IN 1

OUT

(ARC)

EXT MPI

CONTROL

MPI/MTI

TELEVISON

CONTROL

POWER

RS-232C

TELEVISON

CONTROL

IR IN

SERVICE

AV IN

AUDIO

LINE OUT

DIGITAL

AUDIO

Reference: STB-3000 Jack Panels

AV (AUDIO/VIDEO) IN

(3.5 mm jack) Connect composite audio/

video output from external device. Use A/V

adapter cable provided.

ANTENNA/CABLE IN

Connect to Antenna/CATV.

SERVICE

Restricted to service updates.

DIGITAL AUDIO (Optical Digital Audio Out)

Use for amps and home theater systems. Note:

When the STB is OFF, this port is not enabled.

LAN

Use for video IP and/or network connections.

POWER (DC IN)

Use 19V 2.1A AC/DC

power adapter (provided).

AUDIO LINE OUT

(3.5 mm jack) Connect audio equipment to use fixed line

level analog audio output. See also Reference section,

“External Audio Line Out Specifications.”

HDMI OUT

Use HDMI cable (provided) to connect

to display panel HDMI input.

IR IN

(3.5 mm jack) Connection for external IR receiver

(optional). Use when IR pass-through is not

supported by the display panel. See also Reference

section, “External IR Receiver Specications.”

RS-232C TELEVISION CONTROL

(3.5 mm jack)

Use TLM cable provided to

connect

LG Public Display/Commercial Monitor

display

panel’s RS-232 connector.

* On early STB-3000 models, the EXT MPI CONTROL port is labeled “MPI.”

** Only one Television/Display Control connection should be used depending on the type of display panel to be controlled.

Refer to “STB-3000 Cabling Connections” on pages 7 to 9, and/or see Reference section, “Display Panel Specifications,”

for information on determining the appropriate connection. Also, note that on early STB-3000 models, the RS-232C

TELEVISION CONTROL jack is labeled “DISPLAY CONTROL 1” and the MPI/MTI TELEVISION CONTROL port is

labeled “DISPLAY CONTROL 2.”

EXT MPI CONTROL *

When the STB is in Pass-through Mode, the MPI

function enables an external MPI control device

(i.e., VOD/PPV STB, etc.) to control the STB.

HDMI IN

1 & 2

Connections for HDMI output

from external devices.

USB 2 & 1

Insert USB memory device for software updates,

cloning purposes, FTG Mode configuration, picture/

music entertainment, etc., as applicable.

MPI/MTI TELEVISION CONTROL

(RJ-12 port) Use MPI/MTI cable provided to

connect to LG Hospitality display panel’s MPI

port or commercial non-LG display panel’s

MTI (DATA) port.

STB-3000 LED

STB-3000 Front Panel

STB-3000 Rear Panel

206-4272

IR IN

1+3.5 v (VCC)

2IR SIGNAL (VOUT)

3 GND

Reference: External IR Receiver Specications

The IR IN 3.5 mm stereo jack on the rear panel of the STB-3000 provides an input for an optional external

IR receiver (Example: Sung Nam Electronics EAD61273113). The jack provides external IR VCC of 3.5

volts. Refer to the following diagram for pinout details.

Caution: Do NOT plug in a mono connector, as this may damage the STB.

82 206-4272

Reference: External Audio Line Out Specications

AUDIO

LINE OUT

1LEFT (Tip)

2RIGHT (Ring)

3GROUND (Sleeve)

The AUDIO LINE OUT 3.5 mm stereo jack on the rear panel of the STB-3000 provides stereo analog audio

output for external audio equipment. Installer Menu item 097 AUDIO OUTPUT must be set to either 8 or 9

to make analog audio output available. See Installer Menu item 097 AUDIO OUTPUT description on page

38 for additional information. Also, refer to the following diagram for pinout details.

Caution: Do NOT plug in a mono connector, as this may damage the STB.

206-4272

Reference: Installer Remote Control Typical Key Functions

An LG Installer Remote is required to set up and operate the STB/display panel. The LG Installer Remote

illustrated below shows typical remote control functions and is provided for reference only.

DVD/USB buttons

Use to control DVD player or view USB

memory device content.

, PIP, PIP CH +/-, PIP INPUT,

SWAP, and are N/A for these STB models.

CHVOL

1 2 3

4 5 6

7 8

SMART

CHAR/NUM

FLASHBK

EXIT

ENTER

GUIDE

PORTAL

TV DVD

INPUT

TIMER

VD/

MUTE

INFO

PIP PIPCH+ PIPCH

SWAP

PIP

INPUT

SETTINGS

abc def

ghi jkl mno

pqrs tuv wxyz

.,;@

DELETE

SAP notes:

• If SAP is selected and no SAP is provided,

sound may not be heard on channel.

• Each channel may have its own SAP setting.

• Each time digital channels are tuned, the STB

attempts to locate the default audio program

language. If the default audio program language

is not available, the STB will use the rst available

audio program.

SMART

Displays the STB’s Smart Launcher.

TV/DVD

Select the remote’s operating mode:

TV or DVD.

INPUT

Displays available Aux inputs.

TIMER

Sets the amount of time before the STB

automatically turns itself OFF.

Arrows (Up/Down/Left/Right) & OK

Use to navigate on-screen menus, direct tune

channels, and adjust STB settings.

MENU SETTINGS

Displays and removes the STB setup menus (or,

if applicable, the Function Menu).

PORTAL

Displays and removes the Pro:Centric interactive

menu.

INFO

Displays channel information.

GUIDE

Displays and removes the Pro:Centric channel

guide/EPG.

(RETURN)

Returns one level to the previous menu/

display.

EXIT

Clears all on-screen displays and returns to

program viewing.

(POWER)

Turns the STB/display ON or OFF

Color buttons access special functions

in some menus.

Numbers (0 - 9) & DASH

Use to enter a channel or program number.

Dash is used for sub-channel numbers such

as 2-1, 2-2, etc.

FLASHBK (FLASHBACK)

Returns to the previously tuned channel or

input.

VOLUME UP/DOWN

Increases/decreases sound level.

Activates subtitles.

VD/

Enables VD function. Also enables SAP

feature (Analog Mode: Selects MTS sound

[Mono, Stereo, or SAP]. DTV Mode: Changes

audio program language, if additional

languages are available). *

MUTE

Switches sound ON or OFF.

CHANNEL/PAGE UP/DOWN

Changes channels based on channels in

the channel lineup. Moves to previous or

next screen in Pro:Centric channel guide.

84 206-4272

Reference: STB Installer Remote

If you are using an LG display panel, the LG remote provided with the

display panel should be sufficient. However, if you are using a commercial

non-LG display panel or if you intend to use multiple STBs/displays in a

single room installation environment, an LG Installer Remote dedicated

to STB control (see example at right) is available for purchase.

The STB Installer Remote illustrated on the right shows typical remote

control functions and is provided for reference only.

For additional information and/or to purchase an STB Installer Remote,

please contact your LG service representative.

Installer Remote Functionality

The STB Installer Remote provides the same standard configuration

functionality as a typical LG Installer Remote, along with multi-code

capability. See also “Installer Remote Control Typical Key Functions”

information on the previous page.

Set the STB Installer Remote IR Code Scheme

(Multi-code Feature)

This section describes how to set the STB Installer Remote to send

unique IR codes based on “bed number” in a multi-STB/display single

room installation. The remote may be set from Bed 1 to Bed 9.

Note: The STB will always respond to the standard LG Installer Remote

IR code scheme, i.e., you can always use an LG TV Installer Remote with

the STB, regardless of its multi-code IR setting.

The following procedure describes how to set the bed number in the STB

Installer Menu and in the STB Installer Remote.

1. Installer Menu item 020 FEATURE LEVEL determines the additional IR

code scheme to which the STB will respond. Access the STB Installer

Menu, and set item 020 to the desired value (16 – 24).

The STB Installer Remote must now be set to match the FEATURE

LEVEL setting. That is, if item 020 is set to 17 for Bed 2, the STB

Installer Remote must also be set to multi-code Bed 2.

Note: By default, the STB Installer Remote IR code scheme is the

same as the standard LG TV Installer Remote IR code scheme.

2. On the STB Installer Remote, press and hold OK along with the

desired (bed) number key (1 – 9).

The TV LED at the top left of the remote will light for three seconds

and then turn OFF.

3. Once the TV LED turns OFF, release both keys on the remote.

4. Verify that the STB Installer Remote now controls the STB/display,

based on your settings.

Note: If necessary, you can restore the STB Installer Remote IR code

scheme to the standard LG Installer Remote IR code scheme by pressing

and holding OK on the remote along with the “0” key.

VOL

TIMER

TV INPUT

SAP

DVD

MUTE

FLASHBK

VD/

EXIT

GUIDE

INFO

PORTAL

206-4272

Troubleshooting

General Troubleshooting (Some Quick and Easy Tips for Resolving Problems)

Installation

Symptom Possible Cause(s) Possible Solution(s)

Cannot direct enter

channel number.

(STB in Pass-through Mode) Installer

Menu item 028 CH. OVERIDE is set to

0, i.e., disabled (recommended setting).

If Installer Menu item 028 CH. OVERIDE is set to 0, only channels

that are active in the STB’s channel lineup can be selected. Set

item 028 to 1 to allow access for direct keypad entry to all channels.

(STB in FTG Mode) The channel entered

is not included in the FTG Channel Map.

Channel access is restricted to channels included in the FTG

Channel Map. If necessary, make changes to the FTG Channel

Map using the FTG File Manager.

Power

Symptom Possible Cause(s) Possible Solution(s)

No power. See STB Quick Check flow chart on following page.

Picture Reception and Sound

Symptom Possible Cause(s) Possible Solution(s)

No picture.

* See also STB Quick

Check flow chart on

following page.

** See “STB Cabling

Connections” on pages

7 to 9.

Display panel is turned OFF. * • Check the Television/Display Control cabling. **

• Check that the display panel is connected to its AC power source.

Display panel is not receiving signal

from STB or is not displaying STB

content. *

• Check the HDMI cabling. ** If you are not using HDMI1 on

the display panel, make sure Installer Menu item 100 VIDEO

INTERFAC is set correctly.

• (TLM or MTI connection only) Check that Installer Menu item

110 PANEL DELAY is set appropriately.

Antenna/cable not connected. Connect antenna/cable signal to STB.

Encrypted program. Try another channel.

Wrong tuning band. Adjust Installer Menu settings.

Normal picture,

poor or no sound.

Audio muted. Press MUTE or use Volume Up key to increase sound level.

Broadcast problem. Try a different channel.

Erratic Operation

Symptom Possible Cause(s) Possible Solution(s)

Installer Menu setup. Wrong Installer Menu settings. Adjust Installer Menu settings as required.

Installer Remote (not supplied with STB)

Symptom Possible Cause(s) Possible Solution(s)

Remote doesn’t work. Television/Display Control not connected

properly.

Use appropriate Television/Display Control cable (provided)

to connect the STB to the display panel. See “STB Cabling

Connections” on pages 7 to 9.

Remote not in TV Mode. Use MODE key to select “TV”; puts remote into TV Mode.

Not aimed at IR receiver. Point remote at IR receiver on display panel.

Remote too far from IR receiver or

IR path is obstructed.

Move remote closer to IR receiver on display panel, darken room,

and/or remove obstructions.

MPI not connected. If applicable, connect MPI cable to MPI device.

Weak batteries. Replace batteries.

Wrong battery polarity. Check that “+” and “-” match in battery compartment.

Too much light in room. Dim room light.

Wrong Installer Remote. Requires compatible LG Installer Remote (see examples in this

document). Contact your LG representative.

86 206-4272

Troubleshooting (Cont.)

STB Quick Check

STB

Quick Check

Yes

Press POWER on

LG Installer Remote.

Yes

Both STB

and display panel

conected to

AC power?

Yes

Check the Television/

Display Control connection

between the STB and

the display panel.

STB LED

blinking? *

STB LED

steady red?

No Bad

STB

Plug STB AC/DC power

adapter into AC outlet.

Connect display panel to

its AC power source.

STB LED

blinks off twice

every five

seconds?

Yes

End

Bad

STB

STB video

visible on

display panel?

Check the HDMI connection between the

STB and the display panel. If the cable is

not connected to HDMI1 on the display

(default configuration for STB audio/video

output), either restore the connection to

HDMI1 or make sure Installer Menu item

100 VIDEO INTERFAC is set in accordance

with the HDMI port being used.

Problem

solved?

Yes

Repeat the STB Cabling

Connections procedure on pages 7

to 9. If there is still a problem, please

contact your LG representative.

* While the STB is turning ON and sending commands to turn ON the display panel, the LED on the STB’s front

panel blinks at a constant rate. Once both the STB and the display panel are ON, the STB LED remains lit but

blinks off twice in rapid succession every ve seconds.

This flowchart assumes that you have installed the STB/display panel in accordance with the STB

Cabling Connections procedure on pages 7 to 9 and a subsequent functionality and/or communication

failure has occurred.

206-4272

Troubleshooting (Cont.)

Commercial Mode Check

Yes

Press POWER on

LG Installer Remote.

STB is not in Commercial

Mode. Call Technical

Support for assistance.

STB is in

Commercial Mode.

On-screen

menu display

no longer

toggles?

Yes

Press MENU repeatedly

as if to access the

STB Installer Menu.

Leave STB/display ON,

and press MENU on the

Installer Remote.

STB is in

Commercial Mode.

Yes

See STB Quick

Check flow chart.

Function

on display?

STB/display

turned ON?

Use this flowchart to determine whether the STB is currently in Commercial Mode.

88 206-4272

Glossary of Terms

Channel Lineup

Channels set in the STB memory, via Auto

Tuning/manual editing.

Cloning

The process of capturing a Master STB

Setup and transferring it to a Target STB

using a USB memory device.

Commercial Mode

A mode of operation that provides a broad

range of commercial STB features based on

control (settings) provided by the PTC and/

or an MPI control device.

CPU

The STB’s Central Processing Unit.

Responsible for the presentation of video

and audio from content received via the

STB’s tuner or Aux inputs.

E-Z Installation

Enables STB conguration and software/

rmware le downloads to selected STB

models from a Pro:Centric server. Managed

and administered via the Pro:Centric Admin

Client.

EZ-Manager Wizard

Lodging model STB conguration wizard

that provides conguration options for

Pro:Centric operation as well as an option

for using a USB memory device to congure

an STB.

FTG Channel Map

Typically refers to a logical channel mapping

of physical RF channels. This allows digital

channels, like analog channels, to be tuned

without requiring the dash key. Also, channels

(analog or digital) can be arranged in any

order that seems logical for customer tuning/

viewing.

FTG Mode

LG commercial STB mode that enables

decryption of Pro:Idiom encrypted channels

and logical channel mapping. STBs may

be congured locally using LG’s proprietary

PC software or remotely using an applicable

head end device.

Function Menu

Available via Installer Remote “MENU” key.

Indicates the STB is not in Pass-through

Mode. Restricts menu options to a subset

of the STB setup menus, allowing users

to retain functional control, while disabling

setup options.

Installer Menu

Denes commercial STB functionality based

on the parameters set.

LG Free-To-Guest (FTG)

Refers to a particular commercial mode of

operation within an LG STB. See also FTG

Mode.

Logical Channel Number

A number assigned to either a physical or

virtual channel number in a Logical Channel

Map.

Major Channel Number

Typically, the RF channel number assigned

to a digital video stream.

Master STB

An STB whose Channel Map and Installer

Menu and STB setup menu settings have

been congured as a Master STB Setup for

cloning purposes.

Minor Channel Number

A sub-channel or program number assigned

to the content embedded in the digital video

stream.

MPI

Multiple Protocol Interface. An EXT MPI

CONTROL port or, for some STB models,

an MPI card slot provides external control

options for solution providers.

MTI

Multiple Television Interface. SONIFI

Solutions, Inc. proprietary protocol used

for STB conguration/control via an MTI

(typically labeled “DATA”) port.

Pass-through Mode

The STB’s factory default mode of operation.

STBs can be congured for stand-alone use

or as Master STBs for cloning purposes,

and/or STBs may be controlled externally in

this mode.

Physical Channel Number

The major channel number assigned to

represent a specic 6 MHz RF band as

specied by either the broadcast or CATV

channel plan. See CEA (formerly EIA) or

NCTA specications for further information.

Pro:Centric Application

LG content delivery and communication

interface that provides interactive entertain-

ment, weather, amenities, etc. information

for end users. (Powered by Pro:Centric

server.)

Pro:Centric Admin Client

Web editor/content wizard provided for

service provider and customer conguration

of Pro:Centric application and management

elements.

Pro:Idiom

Zenith proprietary security software that

unlocks access to premium content to help

assure rapid, broad deployment of HDTV

and other high-value digital content.

PTC

Protocol Translator Card. The commercial

controller (microprocessor) of the commercial

STB.

Target STB

An STB to which a Master STB Setup will

be transferred.

STB Setup Menus

Available via Installer Remote “MENU” key

in Pass-through Mode only. Menus provide

access to setup and functional features of

the STB.

USB Memory Device

A USB ash drive or USB storage device,

etc. that can be used for STB conguration

purposes (typically cloning or FTG Mode

via CPU conguration) or for updating STB

software.

Virtual Channel Number

An alias (virtual) channel number provided

in the data stream, by the broadcaster, of a

digital broadcast channel to be displayed

by consumer STBs in place of the physical

channel number. The major number is the

same as the original analog channel number

and the minor number is the nth program

available in that digital video stream.

206-4272

Document Revision History / Open Source Software Notice

Document Revision History

Date Description

January 2015 Revision A: New document

January 2015 Revision B: Installer Menu update

June 2015 Revision C: Installer Menu, cabling connections, and labeling updates

July 2015 Revision D: Teach To STB (TLX) and Media Share updates

October 2015 Revision E: STB cable connections update

November 2015 Revision F: Bluetooth Sound Sync added

March 2016 Revision G: Installer Menu item 049 update

May 2016 Revision H: Updates for webOS 2.0

January 2017 Revision I: IM item 119 setup update

Product documentation is available online at: www.lg.com/us/commercial.

Open Source Software Notice

To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please

visit http://opensource.lge.com. In addition to the source code, all referenced license terms, warranty disclaimers and copyright

notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering

the cost of performing such distribution (such as the cost of media, shipping and handling) upon e-mail request to opensource@

lge.com. This offer is valid for three (3) years from the date on which you purchased the product.

206-4272

Revision I

For Customer Support/Service, please call:

1-888-865-3026

www.lg.com/us/commercial

Pro:Idiom is a registered trademark of Zenith Electronics LLC. Pro:Centric, Smart Share, and

the “LG” logo are registered trademarks of LG Electronics Inc. DLNA Certied is a registered

trademark of Digital Living Network Alliance. Intel is a registered trademark of Intel Corporation in

the U.S. and/or other countries. Wi-Fi Direct and Miracast are registered trademarks of Wi-Fi

Alliance. All other trademarks or registered trademarks are the property of their respective owners.

LG STB 3000 User Manual Commercial Mode Setup Guide 206 4272 Comm Rev I
