OWNER’S MANUAL
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
WK7
Copyright © 2018 LG Electronics Inc. All Rights Reserved
www.lg.com
MFL70521708
1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sufcient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instructions
in the literature accompanying the
product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
CAUTION: The apparatus should not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, should be placed on the
apparatus.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not use high voltage products around
this product. (ex. Electrical swatter) This product may
malfunction due to electrical shock.
CAUTION: No naked ame sources, such as lighted
candles, should be placed on the apparatus.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of
the product and to protect it from over heating.
The openings shall never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
Getting Started 3
Getting Started
1
CAUTION concerning the Power Cord
The Power Plug is the disconnecting device. In case
of an emergency, the Power Plug must remain readily
accessible.
Check the specication page of this owner’s manual
to be certain of the current requirements.
Do not overload wall outlets. Overloaded wall outlets,
loose or damaged wall outlets, extension cords, frayed
power cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could result
in electric shock or re. Periodically examine the
cord of your device, and if its appearance indicates
damage or deterioration, unplug it, discontinue use of
the device, and have the cord replaced with an exact
replacement part by an authorized service center.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention to
plugs, wall outlets, and the point where the cord exits
the device.
NOTICE: For safety marking information including
product identication and supply ratings, please refer
to the main label on the bottom or the other surface
of the product.
CAUTION when using this product in environments
of low humidity
yIt may cause static electricity in environments of
low humidity.
yIt is recommended to use this product after
touching any metal object which conducts
electricity.
For models using an adapter
Only use the AC adapter supplied with this device.
Do not use a power supply from another device or
another manufacturer. Using any other power cable
or power supply may cause damage to the device and
void your warranty.
Getting Started4
Getting Started
1
Symbols
~Refers to alternating current (AC).
0Refers to direct current (DC).
Refers to class II equipment.
1Refers to stand-by.
!Refers to “ON” (power).
Refers to dangerous voltage.
Table of Contents 5
1
2
3
4
5
1 Getting Started
2 Safety Information
6 Unique features
6 Introduction
7 Front
8 Rear
2 Connecting
9 Network connection
9 Setting up the Speaker
9 – Connecting the AC Adapter
10 – Installing “Google Home” App
10 – Launch the app to connect Wi-Fi
13 – Reference site for Google Assistant Help
3 Operating
14 Basic Operations
14 – Function LED status
15 – Simple Operation Guide
16 How to use Google Assistant
16 – Google Assistant LED status
16 – Talk to the Google Assistant
17 – Control Smart Home devices
17 – Voice command
19 LG Wi-Fi Speaker
19 – Installing "LG Wi-Fi Speaker" App
20 – BLUETOOTH connection lock
20 – Sound adjustment
21 Using BLUETOOTH® technology
21 – Listening to music stored on the
BLUETOOTH devices
23 Other Operations
23 – Turn off the microphone temporarily
23 – Auto function change
24 – Edit speaker name
24 – Resetting
4 Troubleshooting
25 Troubleshooting
25 – General
26 – Network
26 – Application
5 Appendix
27 Trademarks and Licenses
27 Handling the Unit
28 OPEN SOURCE
29 Specifications
Table of Contents
Getting Started6
Getting Started
1
Unique features
BLUETOOTH®
Listen to music stored on your Bluetooth device.
"Google Home" application
You can enjoy various functions of this speaker by
connecting to network and your smart device with
"Google Home" app.
The speaker and your smart device must be
connected to the same network. Visit or "Google
Play” or “App Store” to search for "Google Home"
app. For detailed information, refer to page 10
Voice recognition
You can use a variety of voice commands to control
the speaker with Google Assistant.
"LG Wi-Fi Speaker" application
Listens to music stored on your smart device.
You can control this speaker with your iPhone or
Android device via "LG Wi-Fi Speaker" app. Visit
"Google Play” or “App Store” to search for "LG Wi-Fi
Speaker" app. For detailed information, refer to page
19
yDepending on the application’s version and the
software of smart device, "LG Wi-Fi Speaker" app
may not be operated normally.
ySome smart devices may not be compatible with
this speaker.
Introduction
Symbol used in this manual
, Note
Indicates special notes and operating features.
> Caution
Indicates cautions for preventing possible damages
from abuse.
Getting Started 7
Getting Started
1
Front
e
g
a
d
b
c
f
a
Plays, pauses or skip playback.
b
Function LED
Changes LED status in according function.
Bluetooth: Blue / Wi-Fi: White (Page 14)
c
(Function)
Changes Wi-Fi or Bluetooth. (Page 15)
d
- Use in Instead of "Hey Google" by long pressing
the (Page 16)
- Plays or pauses a music and stops Google
Assistant feedback. (Page 15)
e
,
Adjusts the volume.
f
Built-in microphones
g
Google Assistant LED
Changes LED status in according perform Google
Assistant. (Page 16)
Precautions in using the touch buttons
yUse the touch buttons with clean and dry
hands.
- In a humid environment, wipe out any
moisture on the touch buttons before using.
yDo not press the touch buttons hard to make
it work.
- If you apply too much strength, it can be
damaged the sensor of the touch buttons.
yTouch the button that you want to work in
order to operate the function correctly.
yBe careful not to have any conductive
material such as metallic object on the touch
buttons. It can cause malfunctions.
, Note
2 Connecting
Connecting 9
Connecting
2
Network connection
You can enjoy various functions of this speaker by
connecting to network and your smart device with
"Google Home" app.
Choose the connection method considering your
network environment.
The "Google Home" app is required to connect the
speaker wirelessly to the network.
Setting up the Speaker
Connecting the AC Adapter
Connect the speaker to the power supply with the
supplied AC adapter.
1. Connect the supplied AC power cord to the AC
adapter.
2. Connect the AC adapter cable to DC IN adapter
input.
3. Plug the AC power cord into an AC outlet.
4. Function LED rotates for tens of seconds (Approx.
30 ~ 50 seconds) during booting.
5. The speaker has completed booting when
Function LED blinks in white with the sound.
If the speaker is connected to Wi-Fi, Function
LED is solid white when booting is completed.
, Note
Only use the AC adapter supplied with this
device. Do not use a power supply from another
device or manufacturer. Using any other power
cable or power supply may cause damage to the
device and void your warranty.
> Caution
Connecting10
Connecting
2
Installing “Google Home” App
The "Google Home" app allows you to use various
functions of this speaker through your smart device:
There are a ways to install “Google Home” app onto
your Smart device.
Requirements before setup
yA wireless router must be connected to the
internet. A smart device such as Android or iOS
devices must be connected to the wireless router
via Wi-Fi connection.
yIt needs Google account to use this app. During
connect Wi-Fi, this app may request to create
Google account.
Through "Google Play or “App Store”
1. Tap the“Goolge Play Store” icon or “App Store”
icon on your smart device.
2. Type in “Google Home” in the search bar and tap
“Search” on “Goolge Play” or “App Store”
3. Select “Google Home” in the search result list to
download.
Google Home
yDepending on the device version, “Google
Home” app may not work.
yFor more information, visit the web site.
https://www.google.com/cast/setup/
, Note
Launch the app to connect Wi-Fi
Make sure your smart device Wi-Fi feature is turned
on. Once a connecting operation is performed, it does
not need to be performed again.
In case of iOS devices, it should be turned on
Bluetooth setting on your smart device.
, Note
1. Tap the "Google Home" icon to launch the app.
2. Follow the screen on app to set speaker. Follow
these instructions in order.
a
b
Connecting 11
Connecting
2
c
d
e
f
g
h
i
i
Connecting12
Connecting
2
j
k
l
yFor more information on the setup, visit
the web site. https://support.google.com/
assistant/answer/7538816
yUse the same Wi-Fi connection to set the
speaker and your smart device.
yIf the Bluetooth setting turned on your
smart device, it will be easy to connect Wi-Fi.
yDuring installation, you should create a
speaker name. It is needed when pairing the
Bluetooth device. You can check and edit
the speaker name. Follow the “Edit speaker
name”. (Page 24)
, Note
3. When the speaker is properly connected to Wi-Fi,
the Function LED will be solid white with sound.
yIf the app is already installed, this speaker is
display in main screen of the app.
yDepending on wireless router status, it might
not work well Wi-Fi connection.
yIt is recommended that you use WiFi Group
Play with less than 5 speakers.
yFor more information (Set up, Usage, Help
etc.), research “Google Assistant Help” or
visit the web site. http://support.google.com/
assistant
yThe speaker is not available for use on some
functions from the “Google Assistant Help”
site. (ex. Call etc.) (Page 13)
y“Google Home” app is provided by Google. It
might be revised by a change of Google Policy.
yThe speaker is not compatible with ”Smart
ThinQ" app. Therefore it is not available in
setup and cannot be controlled by using
"Smart ThinQ" app
, Note
Connecting 13
Connecting
2
Reference site for Google Assistant Help
Set up Google Assistant on your
speakers https://support.google.com/assistant/answer/7538816
Listen to music https://support.google.com/assistant/answer/7539710
Play music on your TV or speakers https://support.google.com/assistant/answer/7539867
Play TV shows & movies https://support.google.com/assistant/answer/7539991
Control smart home devices https://support.google.com/assistant/answer/7540703
Create a shopping list https://support.google.com/assistant/answer/7540969
Buy items on your shopping list https://support.google.com/assistant/answer/7384588#speaker
Set up and manage My Day https://support.google.com/assistant/answer/7393908#speaker
Listen to radio https://support.google.com/assistant/answer/7540307
See which Google Account is linked
to your Assistant https://support.google.com/assistant/answer/7539992
Control volume of your speakers https://support.google.com/assistant/answer/7538817
Change your language https://support.google.com/assistant/answer/7394513#speaker
3 Operating
Operating14
Operating
3
Basic Operations
Function LED status
LED Status Description
LED blinks in
white.
Ready for Wi-Fi
connection.
LED turns on
white with the
sound.
Wi-Fi
connection is
success.
LED blinks in
Blue with the
sound.
Searching for
Bluetooth
device.
LED turns on
Blue with the
sound.
Bluetooth
device is
connected.
When operation of speaker is completed,
Function LED turns off after 3 seconds.
, Note
Operating 15
Operating
3
Simple Operation Guide
Function How to Status
Bluetooth pairing
When Function LED blinks in blue,
select speaker name that is set on
“Google Home” app from phone’s smart
device list
Function LED turns on blue with the
sound.
Play / Pause Tap or Plays or pause a song.
Forward skip Tap X 2 Plays next song.
Backward skip Tap X 3 Plays previous song.
Wi-Fi / Bluetooth Tap Changes function and Function LED's
color. (Bluetooth: Blue / Wi-Fi: White)
Volume control Tap or (0~15 level). When you adjust volume, the Google
Assistant LED changes.
Google Assistant
Long press 2 seconds. Activates Google Assistant.
(= Hey Google)
Tap Stops Google Assistant feedback
Enable/ Disable
Voice recognition
Press (Micropone off) on rear of
speaker.
- When microphone is off, Google
Assistant LED turns on amber with
"The MIC is muted" sound.
- When microphone is on, Google
Assistant LED turns off with "The
MIC is back on" sound.
Reset Press RESET for 5 seconds. (Page
24)
When speaker enter reset mode,
Function LED starts to rotate quickly
with sound.
yPlay, pause, skip, volume may not be supported depending on the your smart device or some of TV
operated differently.
yThe speaker might not synchronize volume with some of TV.
ySome of PC may not be automatically connected to Bluetooth.
, Note
Operating16
Operating
3
How to use
Google Assistant
Google Assistant LED status
LED Status Description
All four LEDs
are on.
Ready to listen
to your voice
command.
All four LEDs
blink.
Responds to
your voice
command.
Microphone
is off and the
solid amber
LED will be on.
Voice
recognition is
disable
The Google Assistant LED status may be
changed without notice.
, Note
Talk to the Google Assistant
You can use a variety of voice commands to control
this speaker with Google Assistant. Try to say a voice
command to the speaker. The speaker will activate
Google assistant and perform your voice command.
Hey, Google.
Set the alarm at 4 PM.
There, your alarm
set for 4 PM.
1. Turn on the speaker and connect Wi-Fi. Follow
the "Setting up the Speaker". (page 9-13)
2. Say "Hey Google".
Or long press for 2 seconds on top of the
speaker.
Then the speaker is activated and ready to receive
your voice commands.
Hey,
Google. Or
3. Just say the thing you want to do. Then the
speaker recognizes and performs your voice
command.
4. After a few seconds, the Google Assistant will
respond to your command.
Each time you use voice recognition, say "Hey,
Google" or tap and long press the .
, Note
Operating 17
Operating
3
Comfortable Function
You can control smart home devices such as TVs,
lights, switches, plugs, thermostats, and more using
voice command. You should be used Smart Home
devices for compatible with Google Assistant.
For more information, visit the below web site.
ySet up, Usage and more: http://support.google.
com/assistant/answer/7540703
yCompatible LG appliance models:
Visit http://www.lg.com and then search the
information
Voice command
1. Time
"What time is it?", "What time is now?", What
time is it in Spain?"
2. Weather
"What's the weather?", "What's the weather this
weekend?", "What's the weather in Paris?", "Will
it rain tomorrow?"
3. Plan
"Tell me about my day.", "What’s my next
meeting?", "Set a reminder to check schedule at
6pm."
4. Alarms
"Set an alarm" , "Set an alarm for 9am", "Wake
me up at 9am", "What alarms are set?"
5. Music
"Play the music.", "Next song.", "Previous song.",
"Pause the music"
6. Volume
"Volume level 9.", "Maximum volume.", "Mute.",
"Turn it up", "Turn it down"
7. Smart Home devices
"Set the heat to 70"
"Turn on lights in the kitchen"
"Watch on TV"
For more information on the voice commands,
refer to the “Google Home” app screen or
visit the web site. http://support.google.com/
assistant
, Note
Operating18
Operating
3
yAfter connecting to Wi-Fi, this function is
available to use. If Function LED (White)
blinks, the speaker is not connected to Wi-
Fi. Follow the “Installing “Google Home” App”
and try again. (page 10-13)
yIf Google Assistant LED is solid amber, the
microphone is off. In that case, "Google
assistant" is not available to receive your
comment. Press the button on back of the
speaker.
yIf "Google Assistant" fails to understand your
commands, it will say answers such as "Sorry, I
can't help with that yet","My apologies. I don't
understand."
yAvoid noisy places, because the speaker may
not receive your commands or "Hey, Google".
Instead of "Hey Google", long press for 2
seconds.
yWhen the voice recognition time limit is
exceeded on smart devices, this function
automatically cancels.
ySpeaking with correct pronunciation will
increase the voice recognition rate.
y"Google Assistant" may be slow to recognize
or act depending on the Wi-Fi connection
status or Google server status..
, Note
Operating 19
Operating
3
LG Wi-Fi Speaker
The "LG Wi-Fi Speaker"app is provided by LG
Electronics. This app allows you to use various
functions of this speaker through your smart device:
Requirements before using
You should connect to Wi-Fi by using "Google Home"
app prior to use this app. (Page 10-13)
"LG Wi-Fi Speaker" app will be available in the
following software versions: Android OS: Ver 5.0
(or later) iOS: Ver 10 (or later)
, Note
Enjoying music on your device and
home network server
You can listen to music on your smart device and
home network server.
Using Chromecast built-in
You can enjoy music contents through this speaker.
Installing "LG Wi-Fi Speaker"
App
Through Apple "Google Play" or "App
Store"
1. Tap the “Google Play Store” icon or “App Store”
icon on your smart device.
2. Type in "LG Wi-Fi Speaker" in the search bar and
tap "Search".
3. Select "LG Wi-Fi Speaker" in the search result list
to download.
Depending on the device, "LG Wi-Fi Speaker"
app may not work.
, Note
Setting and controlling the speaker
You can manage the speaker settings and control the
speaker.
For more informations of "LG Wi-Fi Speaker",
follow the application instructions or see the
owner’s manual of "LG Wi-Fi Speaker".
, Note
Operating20
Operating
3
BLUETOOTH connection lock
You can limit Bluetooth connection to only
Bluetooth function to prevent unintended Bluetooth
connection.
1. Install the "LG Wi-Fi speaker" app.
Follow the "LG Wi-Fi Speaker" (page 19)
2. Follow these instructions in order.
[] [ [My Speakers] [ [ ] [ [Bluetooth
connection restriction]
3. Tap on [Bluetooth connection restriction]
yWhen you turn off this function, tap on
[Bluetooth connection restriction] again.
- [ ] [ [My Speakers] [ [ ] [
[Bluetooth connection restriction]
yIf a Bluetooth device has paired to the
speaker previously, you can connect the
Bluetooth device and the speaker.
, Note
Sound effect
This system has a number of pre-set surround sound
elds. You can select a desired sound effect by using
"LG Wi-Fi Speaker" app.
Status Description
Function
Enhanced Bass +
Clear Vocal
You can enjoy Clear
Vocal and Enhanced
Bass at the same
time.
Enhanced Bass
You can enjoy Wide
sound eld and rich
bass with emphasis
the bass and warmth
of the music.
- Enhanced Bass is
more effective for
music with bass.
Clear Vocal
Yon can enjoy High-
delity sound with
improved the vocal
clarity of every lyric.
- Clear Vocal is more
effective for music
with vocal.
Standard
You can enjoy pure
and natural sound.
yWhen you turn the speaker back on, the last
used option will be on.
yWhen you select ”Standard” “Enhanced Bass”,
“Clear Vocal” or “Clear Vocal + Enhanced
Bass” sound effect, you can enjoy premium
sound with MERIDIAN technology.
yBecause ne-tune sound to provide optimal
high-quality sound, It might be a little
difference between sound effect modes.
, Note
Operating 21
Operating
3
Using BLUETOOTH®
technology
About BLUETOOTH
Bluetooth is wireless communication technology for
short range connection.
The sound may be interrupted if the connection has
interference by some other electronic waves or you
connect the Bluetooth in some other room.
Connecting individual devices under Bluetooth
wireless technology does not incur any charges.
A mobile phone with Bluetooth wireless technology
can be operated via the Cascade if the connection
was made via Bluetooth wireless technology.
yAvailable Devices: Smart phone, Notebook, etc.
yVersion: 4.2
yCodec: SBC
BLUETOOTH Profiles
In order to use Bluetooth wireless technology,
devices must be able to interpret certain proles.
This unit is compatible with following prole.
A2DP (Advanced Audio Distribution Prole)
Listening to music stored on the
BLUETOOTH devices
Pairing your unit and BLUETOOTH
device
Before you start the pairing procedure, make sure the
Bluetooth feature is turned on in to your Bluetooth
device. Refer to your Bluetooth device’s user guide.
Once a pairing operation is performed, it does not
need to be performed again.
1. Turn on the speaker and connect Wi-Fi. Follow
the "Setting up the Speaker". (page 9-13)
2. When you change to Bluetooth function by
pressing the F button, the Function LED's color
will change from white to blue.
- Function LED (Blue) will blink.
3. Operate the Bluetooth device and perform the
pairing operation. When searching for this unit
with the Bluetooth device, a list of the devices
found may appear in the Bluetooth device display
depending on the type of Bluetooth device. Your
unit appears as "Speaker name (App setup)".
Operating22
Operating
3
4. Select "Speaker name (App setup)".
Speaker
name
yApp setup means that you set the name in
the "Google Home" app. For example, if the
speaker name is set to Smart speaker in the
"Google Home" app, you will see “ Smart
speaker” on your Bluetooth device.
yYou may check and edit the speaker name on
"Google Home" app (Page 24)
yDepending on the Bluetooth device type,
some device have a different pairing way.
Enter the PIN code (0000) as needed.
, Note
5. When this unit is successfully connected with
your Bluetooth device, the Function LED will be
solid blue with sound.
6. Listen to music.
To play a music stored on your Bluetooth device,
refer to your Bluetooth device’s user guide.
yWhen using Bluetooth technology, you
should be as close and possible when you are
attempting to make a connection between
the unit and a Bluetooth device. You should
also keep the distance close.
However you may experience issues in the
cases below:
- There is an obstacle between the unit and
the Bluetooth device.
- There is a device using same frequency
with Bluetooth technology such as a
medical equipment, a microwave or a
wireless LAN device.
yIf Bluetooth connection does not work
well, go to step 1 of “Pairing your unit and
BLUETOOTH device” and try again.
yThe sound may be interrupted when the
connection has interference from some other
electronic waves.
yPairing is limited to one per unit and multi-
pairing is not supported
yDepending on the type of the device, you may
not be able to use the Bluetooth function.
yYou can enjoy Bluetooth function using
Smart phone, Notebook, etc..
yThe more distance between the unit and the
Bluetooth device, the lower the sound quality
becomes.
yBluetooth connection will be disconnected
when the unit is turned off or the Bluetooth
device gets too far from the unit.
yWhen Bluetooth connection is disconnected,
connect the Bluetooth device to the unit
again.
yWhen you connect Bluetooth device (iOS
device etc.) to this unit or operate the device,
the volume level can be synchronized with
each other.
yWhen the unit is not connected, Function LED
(Blue) will blink.
, Note
Operating 23
Operating
3
yBluetooth connection will be disconnected
when you change the Bluetooth function
to another function. When you switch to
Bluetooth function again, the speaker will
automatically reconnect the Bluetooth
device. Some Bluetooth devices may not be
connected in automatic.
ySome of PC may not be automatically
connected to Bluetooth.
, Note
Using Voice command to connect
Bluetooth
If the speaker has paired to a Bluetooth device
before, you can use "Google Assistant" to pair
Bluetooth. Say "Connect", "Connect to Bluetooth" or
"Hey Bluetooth".
To disconnect it, say "Cancel", "Unpair devices" or
"Clear all devices".
Controls connected Bluetooth device
You can control connected Bluetooth device from
the unit; play, pause, skip, volume.
yOnly Android OS and iOS is available to use
this function.
yThis function may not be supported
depending on the Bluetooth device or some
of TV operated differently.
yYou can control connected Bluetooth devices
by voice recognition. Follow the “How to use
Google Assistant" (Page 16-18).
, Note
Other Operations
Turn off the microphone
temporarily
You can turn off the microphone to temporarily
disable the detect voice recognition by pressing
(Microphone off) button. All Google Assistant LED
turns amber and "The mic is muted" is heard.
To cancel it, press (Microphone off) again. Google
Assistant LED turns off and "The mic is back on" is
heard.
Auto function change
This speaker recognizes input signals Wi-Fi,
Bluetooth and then changes suitable function
automatically.
When Wi-Fi signal comes in
When you use the Google Cast and voice command
this unit changes the function to Wi-Fi.
When you try to connect Bluetooth
device
When you try to connect your Bluetooth device to
this unit, Bluetooth function is selected. Play your
music on the Bluetooth device.
If the Bluetooth connection lock function is set,
Bluetooth connection will be only available on
Bluetooth function. (Page 20)
, Note
Operating24
Operating
3
Edit speaker name
You can check and edit the speaker name on the
"Google Home" app, follow these instructions.
[] [ [ ] [ [Settings] [ [Device info] [
[Name]
Resetting
To initialize information of existing connection, follow
these instructions.
1. Press and hold the RESET button for 5 seconds.
The Function LED will be filled when RESET is
pressed.
2. When the speaker enters reset mode, Function
LED starts to rotate quickly with sound. Wait
until resetting is complete.
It takes about 1 minute to reset the speaker.
, Note
3. The speaker has completed resetting when
Function LED blinks slowly with sound.
yThe first beep sound means that the speaker
entered reset mode. Please don't unplug the
power cord.
yIf you do not press and hold the RESET
button for more than 5 seconds, speaker is
not reset.
yWhen you reset this speaker, it needs to
reconnect to Wi-Fi or Bluetooth.
, Note
4 Troubleshooting
Troubleshooting 25
Troubleshooting
4
Troubleshooting
General
Problem Cause & Correction
No Power
yThe power cord is unplugged. Plug in the power cord.
yCheck whether electricity failed.
Check the condition by operating other electronic devices.
No sound or sound
distortion.
yThe unit or your smart device’s volume is set to minimum. Check and adjust the
volume of the speaker or your device’s volume.
yWhen you use an external device at high volume, the sound quality may be
deteriorated. Lower the volume of the devices.
yIf you use the unit for purposes other than listening to music, the sound quality
may be lowered or the unit may not work properly.
Wi-Fi connection does
not work well.
yCheck your router. Try turning it off and back on.
yCheck that the Wi-Fi feature is turned on in your smart device.
yCheck that the speaker and your smart device are connected to same Wi-Fi.
Bluetooth pairing does
not work well.
ySwitch Bluetooth off and on again on your Bluetooth device, then try pairing
again.
yBe sure your Bluetooth device is on.
yRemove the obstacle in the path of the Bluetooth device and the unit.
yDepending on the type of the Bluetooth device or surrounding environment,
your device may not be paired with the unit.
Voice recognition does
not work well.
yThe speaker may not be recognized because of the surrounding noise.
yInstead of "Hey Google", long press for 2 seconds.
yCheck and make sure the microphone is not turned "off". Press the button.
The unit does not
operate normally.
yIn case of malfunction, please use the unit in proper place where the
temperature or humidity is not so high or low.
yWhen Function LED is blinking in red, unplug the power cord from the electrical
outlet and plug it again.
yWhen Function LED is solid red, press the RESET button for 5 seconds. (Page
24)
The unit does not
connect with Bluetooth
device.
yTurn off the Bluetooth connection lock function. (Page 20)
Above solutions do not
work.
yPress the RESET button for 5 seconds. (Page 24)
Troubleshooting26
Troubleshooting
4
Network
Symptoms Cause & Solution
Cannot connect the
speaker to your home
network.
The wireless communication may be interrupted from household devices that are
using radio frequencies. Move the speaker away from them.
Media servers are not
displayed on the device
list.
yThe rewall or anti-virus software on your media server is running. Turn off
the rewall or anti-virus software running on your media server.
yMake sure that the speaker is connected to the same network that your
media server is connected.
The application doesn’t
work properly.
Is the application plugged in?
yPlug in the application.
Is the LAN cable connected to the wireless router and the application properly?
yConnect the LAN cable to the LAN port on the back of the application and to
your wireless router.
If you restart the router?
yYou need to turn the speaker’s power off and on again.
If you install new router.
yYou need to perform a factory set and setup the network connection for
speaker.
Application
Symptoms Cause & Solution
The application doesn’t
work properly.
Does an error occur when accessing the app?
yMake sure that your smart device is compatible with the app.
yMake sure that the application is the latest version.
yMake sure that the speaker’s front LED turns from red to white.
5 Appendix
Appendix 27
Appendix
5
Trademarks and
Licenses
The Bluetooth® word mark and logos are
registered trademarks owned by the Bluetooth
SIG, Inc. and any use of such marks by LG
Electronics is under license.
Other trademarks and trade names are those of
their respective owners.
Handling the Unit
When shipping the unit
Please save the original shipping carton and packing
materials. If you need to ship the unit, for maximum
protection, re-pack the unit as it was originally
packed at the factory.
Keeping the exterior surfaces clean
yDo not use volatile liquids such as insecticide spray
near the unit.
yWiping with strong pressure may damage the
surface.
yDo not leave rubber or plastic products in contact
with the unit for a long period of time.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not use
strong solvents such as alcohol, benzine, or thinner,
as these might damage the surface of the unit.
Appendix28
Appendix
5
OPEN SOURCE
You can nd “Open Source Software Notice” at
the"LG Wi-Fi Speaker" app or "Google Home" app
LGE OPEN SOURCE
1. Launch "LG Wi-Fi Speaker" app on your smart
device.
2. Follow these instructions in order.
[] [ [ Settings]
3. Tap [Open source licenses] on [ Settings]
Shows LGE Open Source Software Notice.
Chromecast and Google Assistant
OPEN SOURCE
1. Launch "LG Wi-Fi Speaker" app on your smart
device.
2. Follow these instructions in order.
[] [ [ Settings] [ [Chromecast] [
[Chromecast built-in open legal documents]
3. Tap [Open source licenses] on [Chromecast built-
in open legal documents] Shows Chromecast and
Google Assistant Open Source Software Notice.
Android Things OPEN SOURCE
1. Launch "Google Home" app on your smart device.
2. Follow these instructions in order.
[] [ [ ] [ [Settings] [ [ ]
3. Tap [Open source licenses] on [ of Device
settings] Shows Android Things Open Source
Software Notice.
OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code under GPL, LGPL, MPL, and
other open source licenses, that is contained in this
product, please visit
http://opensource.lge.com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices are
available for download. LG Electronics will also provide
open source code to you on CDROM for a charge
covering the cost of performing such distribution
(such as the cost of media, shipping and handling)
upon email request to opensource@lge.com. This
offer is valid for a period of three years after our last
shipment of this product. This offer is valid to anyone
in receipt of this information.
For more information about Google's open source,
visit device settings of Google home app.
Appendix 29
Appendix
5
Specifications
Speaker
Power consumption Refer to main label.
Networked standby : 4.7 W
AC adapter
yModel: ADS-45SN-19-2 19040G
yManufacturer: SHENZHEN HONOR ELECTRONIC CO.,LTD
yInput: 100-240 V~ 50-60 Hz
yOutput: 19 V
0
2.1 A
Dimensions (W x H x D) Approx. 135 mm X 210.7 mm X 135 mm
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 60 %
yDesign and specications are subject to change without notice.
www.lg.com
OWNER’S MANUAL
LG
Wi-Fi Speaker
Table of Contents 2
1
2
Table of Contents
1 Getting Started
3 ”LG Wi-Fi Speaker”
3 – Installing “LG Wi-Fi Speaker” App
2 Operating
4 Enjoying the Music with “LG Wi-Fi Speaker”
app
4 – Overview of the side menu
5 – Overview of [My Speakers]
5 – Playing a song
6 – Managing a song
7 – Overview of Playback
9 Settings
9 – Settings of the connected speaker
11 – Settings of “LG Wi-Fi Speaker” app
1 Getting Started
Getting Started3
Getting Started
1
”LG Wi-Fi Speaker”
The “LG Wi-Fi Speaker”app is provided by LG
Electronics. This app allows you to use various
functions of this speaker through your smart device:
Requirements before using
You should connect Wi- by using “Google Home”
app prior to use this app.
"LG Wi-Fi Speaker" app will be available in
version of the software as follow; Android OS :
Ver 5.0 (or later) iOS : Ver 10 (or later)
, Note
Enjoying music on your device and
home network server
You can listen to the music on your smart device and
home network server.
Using Chromecast built-in
You can enjoy music contents through this speaker.
Installing “LG Wi-Fi Speaker”
App
Through Apple “App Store” or Google
“Play Store”
1. Tap the Apple “App Store” icon or Google “Play
Store” icon.
2. Type in “LG Wi-Fi Speaker” in the search bar and
tap “Search”.
3. Select “LG Wi-Fi Speaker” in the search result list
to download.
Depending on the device, "LG Wi-Fi Speaker"
app may not work.
, Note
Setting and controlling the speaker
You can manage the speaker settings and control the
speaker.
2 Operating
Operating 4
Operating
2
Enjoying the Music with
“LG Wi-Fi Speaker” app
With “LG Wi-Fi Speaker” app, you can play music in
your smart device.
Some of the content in this part may differ
from “LG Wi-Fi Speaker” app depending on the
application’s version.
, Note
Overview of the side menu
1. Launch “LG Wi-Fi Speaker” app on your smart
device. [My Speakers] appears.
2. Tap [ ] button.
3. Side menu appears.
a[My Speakers] – Displays the connected
speaker.
b[My Phone] – Displays the songs on this smart
device.
c[Music Server] – Displays the songs on the
connected devices (Media server).
d[Playlist] – Displays the playlists.
e[Settings] – Displays the application settings.
It may request permission to use music.
, Note
Operating5
Operating
2
Overview of [My Speakers]
a[ ] – Connect additional speakers.
b[ ] – Selects a function of the connected
speaker.
c[ ] – Set up the connected speaker settings.
(Page 9)
d[ ] – Adjust volume level of the connected
speaker.
e[Status] – Shows state of the connected
speaker.
Playing a song
1. Select [My Phone] or [Music Server] on the side
menu.
2. You can see songs on your smart device or music
server. Select a song to play.
In [My Phone] menu, the songs are sortd by
[Album], [Artists], [Songs], [Genres] and [Folders]
(Android device) or [iPhone Playlist] (iOS device).
In [Music Server] menu, the connected servers
appear.
3. Tap [ ] and select the speaker. You can listen to
music through the connected speaker with
Chromecast.
Operating 6
Operating
2
Managing a song
On the song list of [My Phone] or [Music Server], tap
[ ] of the desired song.
The pull down menu appears.
a[Play next] – Selects music to play next.
b[Add to queue] – Adds to queue list.
c[Add to playlist] – Adds to a desired playlist.
Depending on your wireless environment, playing
a song with the speaker may not work smoothly.
, Note
Using Playlist
You can enjoy music to suit your taste by making
Playlist.
1. On the song list of [My Phone] or [Music Server],
tap [ ] of the desired song and [Add to playlist].
2. [Add to playlist] window appears.
-Select a playlist to add the song.
-If you want to make another playlist, select
[Make a new].
Operating7
Operating
2
Overview of Playback
You can conrm and adjust various information on
the playback screen.
a[ / ] - Cast music to the connected speaker
by Chromecast and stop casting the music.
b[ ] - Edits the current playlist.
c[ ] - Adjusts the volume of smart device or the
volume of Chromecast.
d[ ] - Adjusts the sound effect.
e
Adjusts playback.
[ ] - Pauses playback.
[ ] - Starts playback.
[ ]/[ ] - Skips fast backward or forward.
[ ] - Repeats the desired contents.
Every time you click it, the state changed in [ ]
(Repeat One) - [ ] (Repeat All) - [ ] (Repeat
Off) order.
[ ] - Shufes the music on the list. Music will
be played in random order.
fDisplays information about the currently playing
song.
[ ] is not available when you listen to music by
your smart device or listen to music from
speakers grouped with the Google [Home] app.
, Note
Selecting Sound effect
The app provides 4 sound effects (Clear
Vocal+Enhanced Bass, Clear Vocal, Enhanced Bass or
Standard). You can select a desired sound mode by
tapping [ ].
The displayed items for the equalizer may be different
depending on the connected speaker, sound sources
and effects.
1. During playback, tap [ ].
2. Select sound effect using A and D and tap [OK].
You can customize the sound effect by using [ ]
to adjust Treble and Bass value.
yWhen you listen to music via [My Phone]
without speaker, the sound effect is not
supported.
yDepending on the connected speaker,
displayed sound effect may differ.
, Note
Operating 8
Operating
2
Sound effect mode
This system has a number of pre-set surround sound
elds. You can select a desired sound effect by using
“LG Wi-Fi Speaker” app.
Status Description
Function
Enhanced Bass +
Clear Vocal
You can enjoy Clear
Vocal and Enhanced
Bass at the same
time.
Enhanced Bass
You can enjoy Wide
sound eld and rich
bass with emphasis
the bass and warmth
of the music.
Enhanced Bass is
more effective for
music with bass.
Clear Vocal
Yon can enjoy High-
delity sound with
improved the vocal
clarity of every lyric.
Clear Vocal is more
effective for music
with vocal.
Standard
You can enjoy pure
and natural sound.
yWhen you turn the speaker back on, the last
used option will be on.
yWhen you select ”Standard” “Enhanced Bass”,
“Clear Vocal” or “Clear Vocal + Enhanced
Bass” sound effect, you can enjoy premium
sound with MERIDIAN technology.
yBecause ne-tune sound to provide optimal
high-quality sound, It might be a little
difference between sound effect modes.
, Note
Operating9
Operating
2
Settings
With “LG Wi-Fi Speaker” app, you can set the
connected speaker in your smart device.
Some of the content in this part may differ
from “LG Wi-Fi Speaker” app depending on the
application’s version.
, Note
Settings of the connected
speaker
You can set up setting of the connected speaker.
On [My Speakers] screen, select [ ] to set up the
connected speaker settings.
You cannot see some menu depending on the
connected device.
, Note
Operating 10
Operating
2
Settings of the connected speaker appear. a[IP Info.] - Shows the IP address of the speaker.
b
[Sound Effect] - Selects a sound effect mode
(Clear Vocal+Enhanced Bass, Clear Vocal,
Enhanced Bass or Standard). (Page 8)
c
[Bluetooth connection restriction] –
It enables you to connect Bluetooth device only
on Bluetooth.
d
[Reset settings] – Resets the speaker settings
(Volume, Sound effect, Function, Bluetooth
setting).
e
[Software version information] – Displays
the current Software version information and
updates the software to latest version.
Operating11
Operating
2
Settings of “LG Wi-Fi Speaker”
app
Select [Settings] on the side menu.
Settings of “LG Wi-Fi Speaker” app appear.
a[Participate in user enhancement] – Allows to
send user logs for service quality enhancement.
b[Chromecast] – Displays the Chromecast menu.
c[App version information] – Displays this
application version information.
d[Terms of Service] – Displays Terms of Service.
e[Open source licenses] – Shows LGE Open
Source Software Notice.
[Chromecast] Menu
a[Learn how to cast] - Shows how to use
Chromecast.
b
[Cast Groups] - Select [Learn about Cast
Groups] or [How to cast to a group] to show
the selected information.
c
[Chromecast built-in open legal documents]
- Select [Google Terms of Service], [Google
Privacy Policy] or [Open source licenses] to
show the selected information.
d[Time zone] - Sets time zone.
To use Cast Groups, install Google [Home]
application. Download the application from
Apple “App Store” or Google “Play Store”.
, Note
[Time Zone] Menu
Automatic Time zone
It offers to use network provided time.
Set Time Zone
If you deselect [Automatic Time zone], you can select
your time zone yourself.
