MAKE LAUNDRY DAY
ANYTHING BUT ROUTINE
Can inspiration be found in the laundry room? Look no further
than LG’s stunning new front load washer. Huge 5.2 cu. ft.
Mega Capacity cleans a king-size comforter and a full set of
bedding in one fell swoop. And, with the turbocharged power
of LG TurboWash®, a normal load gets done up to 30 minutes
faster. And, master multi-taskers take note: This LG washer
is TWINWash™ compatible, which means you can add the
ingenious LG SideKick™ pedestal washer to tackle two loads of
laundry—both large and small—all at the same time.
SPECIFICATIONS
• 29” Width
• 5.2 cu. ft. Ultra Capacity with
NeveRust™ Stainless Steel Drum
• Direct Drive Motor with
10-Year Limited Warranty
• 1,300 RPM
• 14 Washing Programs
• 5 Temperature Settings
(All Cold Rinses)
STYLISH DESIGN
• On-Door Electronic Control Panel with
LED Display and Dial-A-Cycle™
• Large Tinted Glass Door with
On-Door Controls
• Ergonomically Angled Drum & Door
• Extra Wide Door Opening
• Optional Matching Drawer Pedestal
• Optional Sidekick™ Pedestal Washer
(WD200)
INNOVATIONS
• 2016 ENERGY STAR® Most Efcient
• CEE Tier 3
• CSA Sustainability
• TurboWash® 2.0 Technology
• LG Steam Technology
• AAFA Qualied Allergiene™ Cycle
• Smart ThinQ™ (Wi-Fi)
• ColdWash™ Option
• 6Motion™ Technology
• SmartDiagnosis™
• TrueBalance™ Anti-Vibration System
• LoDecibel™ Quiet Operation
• SenseClean™
• Delay Wash (Up to 19 Hours)
• Easy Loading 10° TilTub™
TurboWash® Technology
Soccer practice. Groceries. Dinner. Dishes.
Shouldn’t your laundry move as fast as you?
Now it can, with LG’s enhanced TurboWash®
technology. Powerful high-pressure nozzles
save up to 30 minutes per load* —without
shortcutting cleaning performance, even on
larger loads. Innovation that keeps up with your
family calendar? That’s not just laundry done
fast—it’s laundry at the speed of life.
5.2 cu.ft. MEGA Capacity
Towers of towels, piles of sweatshirts, and a
mountain of jeans? Go for it. The ultra large
capacity (5.2 cu.ft.) tub lets you do more laundry
in fewer loads. That’s time saved and sore backs
avoided.
Integrated Electronic Control Panel
with Dual LED Display
Electronic control panel is integrated into
the door for a distinct style plus the intuitive
functionality you expect from an LG washer.
*Compared to other LG top load washers without TurboWash. Based on AHAM-HLW-1-2010 test protocol. Cotton / Normal or comparable cycle at default settings, 8 lb. loads. Excludes quick wash or comparable cycles intended for small, lightly soiled loads only
KEY FEATURES
WM9000H_A
5.2 cu.ft. MEGA Capacity w/ On-Door Control Panel & TurboWash®
LAUNDRY
LG Electronics U.S.A., Inc.
1000 Sylvan Avenue Englewood Cliffs, NJ 07632
Customer Service and Technical Support: (800) 243-0000
LG.com
Design, features and specifications are subject to change without notice. Non-metric weights and measurements
are approximate.
© 2016 LG Electronics USA, Inc. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp. All other
product and brand names are trademarks or registered trademarks of their respective companies. 1/4/16
CAPACITY
Capacity 5.2 cu. ft.
APPEARANCE
Design Look Front Control
On-Door Electronic Control Panel with LED Display •
Touch Buttons •
Dial-A-Cycle™ •
ENERGY
2016 ENERGY STAR® Most Efficient •
CEE Tier 3
WASH PROGRAMS
No. of Programs 14
Wash Programs
Normal, Perm. Press, Delicates, Speed Wash, TubClean™,
Sanitary, Allergiene™, Heavy Duty, BrightWhites™, Towels, Rinse+Spin, Download, Jumbo Wash, Bedding
No. of Options 13
Options
Prewash, Delay Wash, Extra Rinse, Child Lock, ColdWash™, FreshCare™,
Steam, TurboWash™, Custom Program, Drum Light, Smart Grid, Remote Start, Wi-Fi Connect
No. of Wash/Rinse Temps 5
Extra Hot, Hot, Warm, Cold, Tap Cold (All Cold Rinses)
Spin Speeds Extra High (1,300 max.), High, Medium, Low, No Spin
No. of Water Levels Automatically adjusts to the size of load
No. of Soil Levels 5
FABRIC CARE FEATURES
TurboWash® 2.0 Technology •
Steam Technology •
Allergiene™ Cycle •
Sanitary Cycle •
ColdWash™ Option •
SenseClean™ System •
CONVENIENCE FEATURES
TrueBalance™ Anti-Vibration System •
4 Tray Dispenser Prewash, Main Wash (with liquid detergent cup), Bleach, Fabric Softener
LoDecibel™ Quiet Operation •
End of Cycle Signal •
LoadSense •
Child Lock •
Auto Suds Removal •
Forced Drain System •
Leveling Legs 4 Adjustable Legs
SmartDiagnosis™ • (v 3.0)
Smart ThinQ™ (Wi-Fi) Smart Grid Ready, Smart Access,
Smart Adapt, Energy Monitoring, Laundry Starts
MOTOR AND AGITATOR
Motor Type Inverter Direct Drive Motor
Motor Speed Variable
Max RPM 1,300
Axis Horizontal
MATERIALS AND FINISHES
NeveRust™ Stainless Steel Drum •
Cabinet PCM
Control Panel Plastic
Top Plate Painted
Door Rim Glass/Chrome
Door Cover Dark Black Tinted Square Cover
Door Opening 42 1/8"
Available Colors White (W), Graphite Steel (V)
POWER SOURCE
Ratings UL Listed
Electrical Requirements 120V, 10 Amps
Type Electric
OPTIONS
Pedestal WDP5W, WDP5V
Pedestal (WxHxD) 29" x 14 1/8" x 30 7/8"
Sidekick™ Pedestal Washer WD200CW, WD200CV
Sidekick™ Pedestal Washer (WxHxD) 29" x 14 1/10" x 30 4/5"
ACCESSORIES
Hose Included •
DIMENSIONS
Product (WxHxD) 29" x 41 1/4" x 33 3/4"
(55 15/16" W with door open)
Carton (WxHxD) 31 5/16" x 44 19/64" x 35 5/8"
Weight (Product/Carton) 227.1 lbs / 233.7 lbs
LIMITED WARRANTY
1 Year Parts and Labor, 10 Years Motor, Lifetime on Drum
UPC CODES
WM9000HVA Washer (Graphite Steel) 048231 015349
WM9000HWA Washer (White) 048231 015356
DLEX9000V Electric Dryer (Graphite Steel) 048231 015363
DLEX9000W Electric Dryer (White) 048231 015370
DLGX9001V Gas Dryer (Graphite Steel) 048231 015387
DLGX9001W Gas Dryer (White) 048231 015394
WDP5V Pedestal (Graphite Steel) 048231 012904
WDP5W Pedestal (White) 048231 012898
WD200CV Sidekick™ Pedestal Washer (Graphite Steel) 048231 015189
WD200CW Sidekick™ Pedestal Washer (White) 048231 015196
