PRODUCT FEATURES KEY FEATURES
WM9500HKA
LG SIGNATURE Washer
© 2016 LG Electronics USA, Inc. All rights reserved. "LG Life’s Good" is a registered trademark of LG Corp. All other product and brand names are trademarks or registered trademarks of their respective owners. Design, features and specifications
are subject to change without notice. Non-metric weights and measurements are approximate. Some features may require Internet access. Content and services may vary by product and are subject to change without notice. 10/10/16
MEGA
Capacity
TurboWash®
SideKick™
Compatible
WD205CK
5.8 cu.ft. MEGA Capacity
Premium Black Stainless Steel
TurboWash® Technology - Save Up to 30 minutes Per Load*
SideKick™ Compatible (WD205CK)
Ergonomic Angled Door for Easier Access
Full Touch On-Door Control Panel
Smart ThinQ™ Technology
Steam Technology
ENERGY STAR® Most Efficient 2016
10-Year Warranty on Direct Drive Motor
CAPACITY
Capacity 5.8 cu. ft.
APPEARANCE
Design Look Front Control
Full Touch On-Door Control Panel
with LED Display
•
Touch Buttons •
ENERGY
ENERGY STAR® Most Efficient 2016 •
CEE Tier 3
WASH PROGRAMS
No. of Programs 14
Wash Programs Normal, Perm. Press, Delicates, Speed Wash,
TubClean™, Sanitary, Allergiene™, Heavy Duty,
BrightWhites™, Towels, Rinse+Spin, Download,
Jumbo Wash, Bedding
No. of Options 13
Options Prewash, Delay Wash, Extra Rinse, Child Lock,
ColdWash™, FreshCare™, Steam, TurboWash™,
Custom Program, Drum Light, Smart Grid,
Remote Start, Wi-Fi Connect
No. of Wash/Rinse Temps 5 (Extra Hot, Hot, Warm, Cold, Tap Cold
(All Cold Rinses)
Spin Speeds
Extra High (1,300 max.), High, Medium, Low, No Spin
No. of Water Levels Automatically adjusts to the size of load
No. of Soil Levels 5
FABRIC CARE FEATURES
TurboWash® 2.0 Technology •
Steam Technology •
Allergiene™ Cycle (AAFA Certified) •
Sanitary Cycle •
ColdWash™ Option •
SenseClean™ System •
CONVENIENCE FEATURES
Ergonomic Angled Door •
TrueBalance™ Anti-Vibration System •
4 Tray Dispenser Prewash, Main Wash (with liquid detergent cup),
Bleach, Fabric Softener
LoDecibel™ Quiet Operation •
End of Cycle Signal •
LoadSense •
Child Lock •
Auto Suds Removal •
Forced Drain System •
Leveling Legs 4 Adjustable Legs
SMART THINQ™ TECHNOLOGY
WiFi •
SmartDiagnosis™ (v3.0) •
Smart Grid Ready •
Smart Access •
Smart Adapt •
Energy Monitoring •
Laundry Starts •
MOTOR AND AGITATOR
Motor Type Inverter Direct Drive Motor
Motor Speed / Max RPM Variable / 1,300
Axis Horizontal
MATERIALS AND FINISHES
NeveRust™ Stainless Steel Drum •
Cabinet PCM
Control Panel Plastic
Top Plate Painted
Door Rim Glass/Chrome
Door Cover Dark Black Tinted Square Cover
Door Opening 42 1/8"
Available Colors Black Stainless Steel (K)
POWER SOURCE
Ratings UL Listed
Electrical Requirements 120V, 10 Amps
Type Electric
OPTIONS
Pedestal WDP5K
Pedestal (WxHxD) 29" x 14 1/8" x 29 2/5"
ACCESSORIES
Hose Included •
DIMENSIONS/CLEARANCES/WEIGHTS
Product (WxHxD) 29 5/8" x 41 3/16" x 33 1/16"
(55 15/16" W with door open)
Carton (WxHxD) 31 5/16" x 44 15/16" x 35 5/8"
Weight (Product/Carton) 239 lbs / 263.3 lbs
LIMITED WARRANTY
Limited Warranty 1 Year Parts and Labor, 10 Years on Direct Drive
Motor, Lifetime on Drum
UPC CODES
WM9500HKA Washer 048231 017039
DLEX9500K Electric Dryer 048231 017046
DLGX9501K Gas Dryer 048231 017053
WDP5K Pedestal 048231 018364
On-Door
Electronic Touch
Control Panel
*Compared to an LG front load washer without TurboWash. Based on AHAM-HLW-1-2010 test protocol. Cotton / Normal or comparable
cycle at default settings, 8 lb. loads. Excludes quick wash or comparable cycles intended for small, lightly soiled loads only.
