Quick Start
Guide
1
2
4
TIPS FOR SUCCESSFUL SETUP
• Check that you have an Internet connection by connecting a computer
directly to your modem.
• If you cannot connect to the Internet after setup, turn off your modem,
router and computer. Restart them in that order.
• For more tips, see the Documentation CD included in your router package.
IN A DO-IT-YOURSELF MOOD?
• Connect your computer to your router with an Ethernet cable.
• Visit http://myrouter.local in a browser.
• Default router name and password are “admin”.
GET HELP
• Internet: linksys.com/support
• Twitter: @LinksysCares
• Phone (US/Canada): 800-326-7114 (complimentary for 90 days from date
of original purchase)
AS YOU COMPLETE SETUP,
RECORD YOUR ROUTER SETTINGS HERE:
5 GHz network name (SSID)
2.4 GHz network name (SSID)
5 GHz network password
2.4 GHz network password Router password (default is “admin”)
If replacing an existing router,
disconnect that router first.
N600
Dual-Band
Smart
Wi-Fi Router
Model# EA2750
Open a web browser to launch the Linksys Smart Wi-Fi
Router setup instructions. If you don’t see the instructions,
type linksyssmartwifi.com in the address bar.
Unplug and plug in your modem before connecting your
new router.
Twist the antennas until they are straight up, and plug in the
router to a power source.
3Connect to the secure wireless name on the sticker. (You can
change these details later.) Select the option to automatically
connect to this network in the future. You will not have Internet
access until you complete router setup (see Step 4).
Connect the Internet cable from your modem to the yellow
Internet port on your router. Wait until the indicator light on the
back panel of the router is solid.
