LINKSYS WUSB6100M Max-Stream AC600 Wi-Fi Micro USB Adapter User Manual 2

LINKSYS LLC Max-Stream AC600 Wi-Fi Micro USB Adapter 2

Contents

User Manual-2

User Guide
Max-Stream AC600
Wi-Fi Micro USB Adapter
WUSB6100M
1
Contents
Product Overview ................................................................................................... 3
Installation ................................................................................................................. 4
Connect with Network Manager ........................................................................................................ 4
Troubleshooting ...................................................................................................... 5
Your computer does not recognize the adapter. .......................................................................... 5
Your adapter’s LED is orange. ............................................................................................................. 5
Your computer cannot communicate with other computers on your Wi-Fi network. ...... 5
Specifications .......................................................................................................... 6
Linksys WUSB6100M ........................................................................................................................... 6
Environmental ........................................................................................................................................... 6
2
Product Overview
The USB6100M adapter upgrades Wi-Fi connectivity on your Windows-based desktop or
laptop computer. To help protect your data and privacy, you can configure your home network
and this adapter to use Wi-Fi Protected Access 2 (WPA2) encryption.
USB plug—Connect this end to any available USB port on your computer.
LED—Blinks during WPS and is solid when connected to a Wi-Fi network.
LED Behavior
Off Not connected to a Wi-Fi network
Solid Orange Disabled
Solid White Connected to a Wi-Fi network
Blinking White WPS in process
3
Installation
1. Insert the USB adapter into an open USB port on your computer.
2. Watch your monitor/screen as the device automatically installs.
3. Connect to your Wi-Fi network using your computer’s network manager.
Note—If the adapter did not install automatically, use the provided CD or download and run
the driver installation file available at linksys.com/support/wusb6100m.
Connect with Network Manager
Choose your operating system.
• Windows 10
• Windows 8.1
• Windows 7
Windows 10
1. Click the Wi-Fi network icon . The Network menu opens from the right side of the
screen, showing you available Wi-Fi networks and your current connection status.
2. Choose a network. If prompted, enter any additional required network information
(such as password).
Windows 8.1
1. Click Settings in the lower-right corner of the screen.
2. Click the Wi-Fi network icon . The Network menu opens from the right side of the
screen, showing you available Wi-Fi networks and your current connection status.
3. Choose a network. If prompted, enter any additional required network information
(such as password).
Windows 7
1. Click the Wireless Network Configuration utility icon in the lower-right corner of the
screen. A list of available Wi-Fi networks will appear.
2. Choose a network and click Connect.
3. If prompted to enter a network security key, type your password (security key) into the
network security key field. Click OK.
4
Troubleshooting
Your computer does not recognize the adapter.
• Make sure that the adapter is properly inserted into your computer’s USB port.
• Connect the adapter into a different USB port.
Your adapter’s LED is orange.
• Your adapter has been disabled.
• Go to your computer’s network settings page and make sure the adapter was installed.
• Enable the adapter.
Your computer cannot communicate with other computers
on your Wi-Fi network.
• Make sure that the computers are powered on.
• Make sure that the adapter is configured with the same Wi-Fi network name and wireless
security settings as the other computers on your Wi-Fi network.
5
Specifications
Linksys WUSB6100M
Model Name Max-Stream AC600 Wi-Fi Micro USB Adapter
Model Number WUSB6100M
Standards 802.11a, 802.11b, 802.11g, 802.11n,
802.11ac
Interface USB 2.0
LED Connection Status
Antennas 1 internal dual-band
Security Features WEP, WPA and WPA2, Personal, WPA and
WPA RADIUS
Security Key Bits Up to 128-bit encryption
OS requirements Windows 7, Windows 7 64-bit, Windows 8.1,
Windows 8.1 64-bit, Windows 10 64-bit,
Windows 10 32-bit
Environmental
Dimensions 40.6mm x 12mm x 18mm
Unit Weight
6.15g
Certifications FCC, IC, CE, Wi-Fi (IEEE a/b/g/n/ac),
Windows 7, Windows 8.1, Windows 10
Operating Temp.
32°F to 104°F (0°C to 40°C)
Storage Temp.
-4°F to 140°F (-20°C to 60°C)
Operating Humidity 10% to 80% relative humidity, non-
condensing
Storage Humidity
5% to 90% non-condensing
Specifications are subject to change without notice.
6
Notes:
For regulatory, warranty, and safety information, see the CD that came with your USB adapter or
go to Linksys.com/support/wusb6100m.
Specifications are subject to change without notice.
Maximum performance derived from IEEE Standard 802.11 specifications. Actual performance
can vary, including lower Wi-Fi network capacity, data throughput rate, range and coverage.
Performance depends on many factors, conditions and variables, including distance from the
access point, volume of network traffic, building materials and construction, operating system
used, mix of wireless products used, interference and other adverse conditions.
BELKIN, LINKSYS and many product names and logos are trademarks of the Belkin group of
companies. Third-party trademarks mentioned are the property of their respective owners.
Licenses and notices for third party software used in this product may be viewed here:
http://support.linksys.com/en-us/license. Please contact http://support.linksys.com/en-
us/gplcodecenter for questions or GPL source code requests.
© 2016 Belkin International, Inc. and/or its affiliates. All rights reserved.
LNKPG-00305 Rev. A02
