QUICK REFERENCE GUIDE
INSTALLATION
1
2
3
1
HOW TO MOUNT THE PND-K3.
Find a spot suitable for the navigation device. Stick the
suction cup against the desired mounting location. Press
the lever to secure the suction cup.
Guide the navigation device onto the cradle.
Gently push until a click sound is heard and the device is
locked in place.
HOW TO REMOVE THE PND-K3.
Press on the button immediately behind the navigation
device. This will release the unit forward. Gently lift the
device from its cradle.
>
>
PND-K3
Portable Navigation System
CONTROLS
PRIMARY BUTTON CONTROLS
>
Press and hold for 2 seconds
to turn on/off the device.
POWER
For music playback.
SD CARD SLOT
HEADPHONE JACK
VOLUME DOWN
VOLUME UP
MAIN MENU
Press this to start entering
a destination.
“GO TO” BUTTON
Press this to go to the
music player.
“PLAY” BUTTON
Press this to change
system settings.
“SETTINGS” BUTTON
Press this to go to the
map.
“HOME” BUTTON
Press this to check
information such as:
• GPS receiver status
• Speed and trip information
“INFO” BUTTON
Press this to go to a saved
home location.
“MAP” BUTTON
MAP
MAP WITHOUT GUIDANCE
>
Goes back to Main
Menu screen.
Zooms Map View In
Zooms Map View Out
Changes map view
(2D, 3D)
MAP WITH GUIDANCE
>
Changes map view
(2D, 3D)
Change navigation mode
to arrow only mode
Goes back to Main
Menu screen.
Zooms Map View In
Zooms Map View Out
Press to repeat voice
guidance
Press to view route
menu (see next page)
ROUTE MENU
THE ROUTE MENU ALLOWS YOU TO EASILY MODIFY OR CANCEL
ROUTING TO A DESTINATION.
>
Press to add or reorder
waypoints
Press to change route options
(shortest, quickest, etc)
Press to view list of
upcoming manuevers
Cancel the current route
Press to calculate a
detour route
REALLY COOL FEATURES
CHOOSE YOUR FAVORITE COLOR
>
Select “Display” from the settings menu to change your color scheme.
REALLY COOL FEATURES
POINTS OF INTEREST ALONG ROUTE
>
POINTS OF INTEREST KEYWORD SEARCH
>
Want to find a restaurant on the way home? This option finds only Points of
Interest (POI) that are on the way to your current destination.
Don’t know the full POI name? Type in what you know and find relevant
results. This search method returns place names containing, and not
necessarily beginning with, the search term.
