LITE ON TECHNOLOGY ST9074 Bluetooth keyboard User Manual
Lite-on Technology Corp. Bluetooth keyboard Users Manual
Users Manual
User’s Manual
SK-9074 Bluetooth Keyboard Product Guide
Getting Started
Thank you for choosing this Bluetooth Keyboard . ST-9074 is is a Rechargeable BT Keyboard for mobile device, such as
Media Tablet or Smart phone. The HID Human input device interface is fully compatible with APPLE ISO system.
Set up the keyboard.
1. keyboard Power SW ON (Blue LED light)
2. Press Fn+ += The battery light flashes blue.
3. Complete Bluetooth pairing on your device.
● Low battery warning
Orange-colored LED on upper-right edge of keyboard will keep flashing when it operates in low power.
●The following description of keys applies for the operating systems that support these functions:
Mute (Fn+9) Press this key to mute/un mute the audio.
Volume Down (Fn+0) Press this key to decrease the volume.
Volume Up(Fn+-) Press this key to increase the volume.
Previous Track (Fn+6) Multimedia key to skip to the previous track in the active player.
Play/Pause (Fn+7) Multimedia key to play or pause the track or video in the active player.
Next Track
(Fn+8)
Multimedia key to skip to the next track in the active player.
User’s Manual
-2-
Technical data
Designation Value
Wireless Bluetooth EDR 2.0
Operating Frequency 2402MHz~2480MHz
Storage temperature –20 °C ... +60 °C
Operating temperature 0 °C ... +40 °C
Battery type Li battery
Supply voltage 3.7V(3.5~4.2V)
Current consumption max. 100 mA
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is con nected.
● Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement
est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout
brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
CAUTION:
The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not
expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. In cases where the
manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section
may be included in the manual in that alternative form, provided the user can reasonably be expected to have the capability to access
information in that form.
PRODUCT DISPOSAL INFORMATION
Dispose of this product in accordance with local and national disposal regulations.
