LM Technologies LM960 OLED BLUETOOTH BRACELET User Manual Usermanulal
LM Technologies Ltd. OLED BLUETOOTH BRACELET Usermanulal
Users Manual
BW08
1
1. Charging
The Bluetooth bracelet comes with a built in rechargeable battery.
Before using the bracelet for the first time please charge the
battery fully (Approximately 6 hour charge).
1.1 How to Charge
To charge the bracelet please plug the appropriate end in to the
bracelet charge port on the bracelet and the USB end either into a
computer or the wall adapter provided.
1.2 Normal Charging Time
The bracelet will normally take 2 hours charge from completely
flat. When the battery is fully charged the screen will show
“ charge OK”
1.3 Charge Indication
The screen will first show “Charger In”, and then show
“Charging”.
1.4 Standby Time
Up to 60 hours standby time, note that the stand by time is effected
by how often the bracelet vibrates and screen display.
1.5 Low Battery Notification
2
When the battery is running low the screen will show “Low
Battery”. When this occurs please charge the bracelet to ensure
greater battery life.
2. Turning the Bracelet OFF/ON
To turn the bracelet on hold down the main button for 2 seconds
until the screen show “power on”, and will enter the connecting
status directly and show “connecting” on the screen.
To turn the bracelet off hold the main button down until the screen
show “power off”.
3. Pairing Bracelet with phone
To pair the bracelet with your phone:
· Keep bracelet within 1 meter of your phone
· Ensure bracelet is turned off to begin
· Hold the main button down for 4 seconds until the screen show
“ Pairing”
· Search for the device on your phone, it will come up with the
name “Bracelet”
· Press yes to pair the device
· It will then ask for a pass code enter “0000”
· Press yes to connect the device and authorize it
· The screen will show “connected” once the pair success.
Remarks: The screen will first show “Pair Fail”, and then “No
Connect” once the pairing failed.
4. Accept/reject a call
While you receiving a call, you can press the button 5 seconds to
accept a call and the screen will show “Call accepted”. To reject a
3
call, press the button one second to reject a call and the screen will
show “ Call rejected”.
5. Link loss
The screen will first show “ Link Loss” and then show “No
connect” and vibrate once the link have been cut.
6. Linking Bracelet with phone
When the bracelet is turned back on, depending on your phone it
should re-link automatically
To re-link the bracelet with the phone manually go to the
Bluetooth menu on your phone select the bracelet in this list and
choose the connect with device option. Ensure that your bracelet is
now turned on. You may have to re-enter the pass code.
7. Bracelet Operation
The bracelet will vibrate and show the caller’s ID when you have
an incoming call.
8. To Reset Bracelet
You may want to reset the bracelet back to the original factory
settings, this function clears all current pairings with bracelet:
· Ensure that bracelet is switched of
· Connect the power charge cable to the bracelet and charge for
a few seconds
· The bracelet will now turn off and all parings have been
cleared.
9. Safety Guidelines
· Do not submerse the bracelet in liquid or expose to a high
amount of moisture or humidity
4
· Do not use abrasive cleaning solvents to clean the bracelet
· Do not expose the bracelet to extreme temperatures high or
low.
· Do not stick anything on the inside of the bracelet as this may
damage or stop the bracelet from working
· Store bracelet in a safe dry place away from extreme
temperatures and dust
· Do not attempt to replace the bracelet's battery yourself
· Only used the charge cable hat came with the bracelet
· Do not use the charger outdoors
Product Specification
Bluetooth Version 1.2
Frequency Range: 2.4GHz
Charging Time: 2 Hours
Stand By Time: 60 Hours
5
FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: The manufacturer is not responsible for and radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user’s authority to operate the
equipment.
