Zebra ZT600 Series Industrial Printers
THE NEXT GENERATION Xi SERIES, NOW WITH MORE
INTELLIGENCE AND INDUSTRIAL BRAWN
Advancing the legacy of their industry-leading Xi Series predecessors, the ZT610 and ZT620 combine rugged durability and exceptional
performance on a user-friendly, future-ready platform. These next-generation workhorses are designed to help you navigate the rapidly
evolving business technology landscape. So, whether you're concerned about growing production line demands, increasing operational
complexities, integrating disparate systems or controlling investment costs, ZT600 Series Industrial Printers have you covered today—and
for years to come.
ZT610™
ZT620™
A Leap Forward in Industrial
Thermal Printing
Zebra’s industrial printers are well known for their durability, fast print
speed, long life span and unparalleled reliability. The ZT610 and ZT620
build on that legacy, with the most advanced, comprehensive feature
sets of any Zebra stationary printer series. To keep your critical
operations running smoothly across a broad range of applications,
ZT600 Series printers provide:
24/7 Reliability in the Harshest Environments
ZT600 Series printers are built to withstand the most demanding
industrial conditions, virtually eliminating operational downtime due to
printer failure. Plus, they meet your high-volume production needs, day
in and day out, with superior print quality and speed across the widest
range of applications.
Micro-Consistent Printing for Top-Quality Micro Labels
Featuring highly precise registration and print line adjustment, the ZT610
oers 600 dpi printing for labels as small as 3 mm for applications like
circuit boards, chips and miniature components—all without wasting
expensive media due to improper printing.
User-Friendly Setup, Use, Maintenance & Troubleshooting
Intuitive Link-OS® applications and user-friendly design features
streamline everything from deployment to daily use to routine
maintenance. Compatibility with other printing systems and technologies
simplifies integration and management, while onboard sensors,
diagnostics and help resources guide troubleshooting so users don’t
have to call in support for every minor issue.
Highly Adaptable, Future-Ready Platforms
The last thing you need is a new piece of technology that will be
obsolete in just a couple of years. That’s why the ZT600 Series was
engineered with the future in mind—from an adaptable design that
allows communications, media handling and other upgrades in the field,
to compatibility with SOTI and AirWatch device management software, to
intuitive Link-OS applications that simplify updates and reconfiguration
as needed.
For more information about ZT600 Series Industrial Printers, visit www.zebra.com/zt600
or access our global contact directory at www.zebra.com/contact
PRODUCT SPEC SHEET
ZT600 SERIES INDUSTRIAL PRINTERS
Unparalleled Performance Today
• All-metal heavy gauge structural components are engineered to
withstand the demands of 24/7 operations for years of continuous use
• Built-in thermal management eliminates vents and cooling fans,
blocking dust and debris for trouble-free printing even in challenging
environments
• High-quality print mechanism and internal components are meticulously
designed to ensure outstanding performance and reliability
• Best-in-class, high-resolution printing for micro labels oers exceptional
quality for precision applications
• Long-life printheads reduce replacement costs and printer downtime
• Easy-adjust printhead pressure toggles feature a scale and color-coded
pressure indicators to simplify printer setup and operation
User-Friendly for Day-to-Day Operations
•
Simple, intuitive side-loading of media increases printer uptime and
reduces training requirements
• Highly visible color display turns red when the printer is in an error
state, allowing users to determine printer status from a distance
• Guided media paths change color when a media error occurs, providing
simple visual cues to help users locate and resolve problems quickly
•
Color graphic display with icon menu system and local language support
streamlines daily operation for a better user experience
•
Interior cabinet light illuminates ribbon and media paths for optimal
visibility
•
Color-coded components enable easy identification of all touch points
•
QR codes link to error-specific help videos for fast problem resolution
•
Quick-change printhead simplifies maintenance with easy-in/easy-out
socket, no wires—and no hassles
•
Fused upper and lower media sensors oer the convenience of single-
knob adjustment without compromising alignment
Insight for a Smarter Tomorrow
• Link-OS Printer Profile Manager Enterprise lets administrators monitor
networked Link-OS printers from a single user-friendly, browser-based
interface
• Mobile Device Management connectors easily integrate networked
printers into AirWatch or SOTI Device Management systems
• Link-OS Cloud Connect provides a direct, encrypted and authenticated
connection to link printers to on-premise or cloud-based servers
• Zebra’s Visibility Services Portfolio enables enterprises to track and
analyze printer health, performance and usage, facilitating improved
business performance
Adaptability for a Bright Future
• Optional advanced RFID encoding capabilities are easy to install
and use
• Field-installable media handling options utilize bulkhead electrical
connectors for quick installation to expand printer capabilities
• Two USB host ports oer the flexibility to connect a wide range of
peripheral devices
• Two open communication slots for fast and easy addition of
connectivity options including 802.11ac, parallel, Ethernet, IPv6 and
applicator interface
Consistently Exceptional Zebra Certified Supplies
Printing supplies can impact everything from printhead lifespan to
operational eciency. That’s why we design, produce and rigorously
pretest our own line of thermal printing supplies to ensure consistent,
optimized performance in your Zebra printer—and peace of mind for
you. For industry-leading quality, service and thermal printing expertise,
choose Zebra Certified Supplies.
Exceptional Today, Ready for Tomorrow, Built for the Future.
PRODUCT SPEC SHEET
ZT600 SERIES INDUSTRIAL PRINTERS
2
Complete Visibility & Control
Operational & Asset Visibility Services (OVS/AVS) perfectly complement
your business technology investments by giving you deep insight into
the status, utilization and functionality of Link-OS enabled printing
systems critical to your core processes. Plus, with Printer Profile Manager
Enterprise, you can manage settings, firmware and more, on-site or
remotely, so you’re always in control.
ZT610 & ZT620
Feature Comparison
ZT610 ZT620
Maximum Print Width 4.09" (104 mm) 6.6" (168 mm)
Maximum Ribbon Length 450 m 450 m
Maximum Print Speed
14 ips at 203 dpi
12 ips at 300 dpi
6 ips at 600 dpi
12 ips at 203 dpi
8 ips at 300 dpi
User Interface Color, graphical LCD, status icons Color, graphical LCD, status icons
Print Resolution (dpi) 203, 300, 600 203, 300
Printer Control Language ZPL, ZPL II ZPL, ZPL II
Zebra OneCare® Services
To enable predictable performance and improved business outcomes
while eliminating unbudgeted repair costs, Zebra OneCare delivers
expert technical assistance, repair services and software support for
your ZT600 Series printer. Choose from a variety of plans to fit your
specific operational needs—both today and as your operations evolve.
PRODUCT SPEC SHEET
ZT600 SERIES INDUSTRIAL PRINTERS
3
ZT600 Series Specifications
STANDARD FEATURES
• Print Methods: Thermal transfer and direct thermal printing
• Construction: Metal frame and bi-fold metal media cover with enlarged clear
viewing window
• Side-loading supplies path for simplified media and ribbon loading
• Thin film printhead with E
3
™ Element Energy™ Equalizer for superior print quality
• Communications: USB 2.0, high-speed, RS-232 Serial, Gigabit Ethernet,
Bluetooth 4.0
• Highly visible color display that turns red when the printer is in an error state allows
operators to determine printer status from a distance
• Simplified icon menu navigation system categorizes settings into logical groups
of functions
PRINTER SPECIFICATIONS
Resolution 203 dpi/8 dots per mm
300 dpi/12 dots per mm (optional)
600 dpi/24 dots per mm (optional for ZT610 only)
Memory 1 GB RAM memory
2 GB on-board linear Flash memory
Maximum Print
Width
ZT610: 4.09"/104 mm
ZT620: 6.6"/168 mm
Maximum Print
Speed
ZT610: 14 ips/356 mm per second
ZT620: 12 ips/305 mm per second
Media Sensors Dual media sensors: transmissive and reflective
Maximum
Continuous Print
Length
ZT610
• 203 dpi: 150"/3810 mm
• 300 dpi: 130"/3302 mm
• 600 dpi: 30"/762 mm
ZT620
• 203 dpi: 150"/3810 mm
• 300 dpi: 100"/2540 mm
MEDIA CHARACTERISTICS
Media Width ZT610
• 1.00"/25.4 mm to 4.5"/114 mm tear/cutter
• 1.00"/25.4 mm to 4.25"/108 mm peel/rewind
ZT620
• 2.00"/51 mm to 7.0"/178 mm tear/cutter
• 2.00"/51 mm to 6.75"/171 mm peel/rewind
Maximum Media
Roll Size
8.0"/203 mm O.D. on a 3"/76 mm I.D. core
Thickness 0.0023"/0.058 mm to 0.010"/0.25 mm
Media Types Continuous, die-cut, notch, black-mark
RIBBON CHARACTERISTICS
(Thermal-transfer option only)
Standard Length 1476'/450 m
Width ZT610: 2.00"/51 mm to 4.33"/110 mm
ZT620: 2.00"/51 mm to 6.85"/174 mm
Core 1.0"/25.4 mm I.D.
OPERATING CHARACTERISTICS
Environmental Operating Temperature:
• Thermal transfer = 40ºF to 104ºF/5ºC to 40ºC
• Direct thermal = 32ºF to 104ºF/0ºC to 40ºC
Operating Humidity: 20% to 85% non-condensing
Storage/Transportation Temperature: -22F to 140F/
-30C to 60C
Storage Humidity: 20% to 85% non-condensing
Electrical Auto-detectable (PFC Compliant) 90-265 VAC, 47-63Hz,
rated at 250 Watts
ENERGY STAR qualified
Agency Approvals IEC 60950, EN 55022 Class B, EN 55024, EN 61000-3-2,
EN 61000-3-3
cTUVus, CE Marking, FCC-B, ICES-003, VCCI, C-Tick, NOM,
S-Mark (Arg), CCC, CU, BSMI, KCC, SABS, IN-Metro
PHYSICAL CHARACTERISTICS
ZT610 closed ZT620 closed
Length 19.88"/505 mm 19.88"/505 mm
Width 10.56"/268.2 mm 13.44"/341.45 mm
Height 15.58"/395.68 mm 15.58"/395.68 mm
Weight 50 lbs/22.7 kg 57.4 lbs/26 kg
SOFTWARE TOOLS
Link-OS Solutions
Document Design
–
Quickly design a customized print solution using your business
data and Zebra’s intuitive plug-and-print design tools.
Device Integration
–
Zebra offers apps and products designed to help you integrate
Zebra devices into your existing systems.
Device Management
–
Manage your print operations locally and globally with Zebra’s
suite of device management tools.
Developer Tools
–
Provides you the tools you need to create your own apps, including
documentation, source code, programming languages, templates and more.
Web View
Connect and control Zebra barcode printers using ZPL II via the printer’s web interface
using common web browsers.
Alert
Printers equipped with ZebraNet print servers will notify you via any email-enabled,
wired or wireless device to minimize downtime..
FIRMWARE
ZBI 2.0™ – Optional powerful programming language that lets printers run stand-
alone applications, connect to peripherals and much more.
ZPL and ZPL II® – Zebra Programming Language provides sophisticated label
formatting and printer control, and is compatible with all Zebra printers.
XML-enabled Printing – allows XML communications for barcode label printing.
BARCODE SYMBOLOGIES
Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC
Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit
extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5,
Logmars, MSI, Codabar, Planet Code
2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39,
MicroPDF, RSS-14 (and composite), Aztec
FONTS AND GRAPHICS
16 resident expandable ZPL II bitmap and two resident scalable ZPL fonts
Asian and other international scalable and smooth bitmapped fonts
Unicode™: For multi-language printing
Downloadable objects include graphics, scalable and bitmap fonts, label templates
and formats
IBM Code Page 850 international character sets are available in the fonts A, B, C, D,
E, F, G and 0 through software control
Code Page 1250, 1252, 1253, 1254, 1255 Support with font 0
32 MB user available DRAM
512 MB user available on-board Flash
OPTIONS AND ACCESSORIES
Connectivity
• Two open communication slots to add internal cards for 802.11ac, parallel,
Ethernet, and applicator interface. IPv6 option is available as an external dongle
attached to a parallel port
Media Handling
• Rewind: Internally rewinds a full roll of printed labels on 3" core, or peels and
rewinds liner
• Cutter: Front-mount guillotine cutter and catch tray
• 1" I.D. Core media supply hanger
• Ink-side in ribbon supply spindle
RFID
• Supports tags compatible with: UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN
RFID protocols
• Integrated RFID system is user-upgradable in the field and available on both
4" and 6" models
• Adaptive Encoding Technology automatically selects optimum encode settings
Keyboard Display Unit
• ZKDU™ keyboard display units for stand-alone printing applications
Ideal for These
Applications:
Manufacturing
• Work-in-process
• Product ID / serial
numbers
• Package labeling
• Receiving / put-away
labeling
Transportation
and Logistics
• Order picking /
packing
• Shipping / receiving
• Cross docking
• Compliance labeling
Retail
• Distribution centers
• Back-of-store
operations
Healthcare
• Laboratory labeling
• Blood bank labeling
• Asset tracking
• Pharmacy labeling
©2017 ZIH Corp and/or its affiliates. All rights reserved. ZEBRA and the stylized Zebra head are trademarks of ZIH Corp, registered in many jurisdictions
worldwide. All other trademarks are the property of their respective owners. Specifications subject to change without notice. 06/02/2017
NA and Corporate Headquarters
+1 800 423 0442
inquiry4@zebra.com
Asia-Pacific Headquarters
+65 6858 0722
contact.apac@zebra.com
EMEA Headquarters
zebra.com/locations
mseurope@zebra.com
Latin America Headquarters
+1 847 955 2283
la.contactme@zebra.com
PRODUCT SPEC SHEET
ZT600 SERIES INDUSTRIAL PRINTERS
