Landis Gyr Technology WGRS3 RF-UTILITY METER USAGE READER User Manual 04 0203 Manual Cover
Landis+Gyr Technology, Inc. RF-UTILITY METER USAGE READER 04 0203 Manual Cover
USERS MANUAL
5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598
FCC Part 15.247 Certification
Test Report
FCC ID: R7PWGRS3
FCC Rule Part: 15.247
ACS Report Number: 04-0203-15C
Manufacturer: Cellnet Technology, Inc.
Equipment Type: Utility Data Usage Transceiver
Model: WANGATE with Utilinet DC Radio
Installation and Operators Guide
UtiliNet®
Technical Reference Guide
Revision 2.1
ii
Proprietary Rights Notice
This manual is an unpublished work and contains the trade secrets and confidential infor-
mation of Cellnet which are not to be divulged to third parties and may not be reproduced
or transmitted in whole or part, in any form or by any means, electronic or mechanical for
any purpose, without the express written permission of Cellnet. All rights to designs or
inventions disclosed herein, including the right to manufacture, are reserved to Cellnet
The information contained in this document is subject to change without notice.
Cellnet reserves the right to change the product specifications at any time without incur-
ring any obligations.
Trademarks Used in This Manual
UtiliNet is a registered trademark of Cellnet.
Windows is a trademark of Microsoft Corporation.
MapInfo is a registered trademark of MapInfo Corporation
UtiliNet Technical Reference Guide
UTLG-0002-GB-08.04
Cellnet
30000 Mill Creek Ave., Suite 100
Alpharetta, GA 30022
Tel: (678) 258-1500
Fax: (678) 258-1550
Copyright© 2004
Cellnet
All rights reserved.
iii
Compliance With FCC Regulations
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a resi-
dential installation. This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equip-
ment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
RF Exposure
In accordance with FCC requirements of human exposure to radiofrequency
fields, the radiating element shall be installed such that a minimum separation
distance of 20cm is maintained between it and the user or general population.
Industry Canada
All Equipment:
This Class B digital apparatus meets all requirements of the Canadian Interfer-
ence Causing Equipment Regulations. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
Cet appareillage numérique de la classe B répond à toutes les exigences de l'inter-
férence canadienne causant des règlements d'équipement. L'opération est sujette
aux deux conditions suivantes: (1) ce dispositif peut ne pas causer l'interférence
nocive, et (2) ce dispositif doit accepter n'importe quelle interférence reçue, y
compris l'interférence qui peut causer l'opération peu désirée.
Changes or modifications to this device not expressly approved by Cellnet could void
the user s authority to operate the equipment.
Notes:
iv
UtiliNet Technical Reference Guide v
Proprietary Rights Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
Trademarks Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
Compliance With FCC Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
RF Exposure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Industry Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
All Equipment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Chapter 1 Introduction
System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
UtiliNet Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Network of Intelligent Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Mesh Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Radios With Programmable Intelligence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Packets Hop From Radio To Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Polling and Report By Exception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Contacting Technical Support 5
Telephone 5
Fax 6
Email 6
Chapter 2 Integrated WanGate Radio (IWR)
IWR VDC Version (P/N 269550000-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
120 VAC to 12 VDC Power Adapter (P/N 105690-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
IWR Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
IWR DC Version Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
IWR AC Version (P/N 269560000-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
IWR AC Version Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Antenna Kit (P/N 105665-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Filter (P/N 106460-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Bandpass Filter Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
IWR General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
IWR Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
IWR With AC Power Supply Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Chapter 3 WanGate Radios
120/240 VAC WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
120/240 VAC, w/Battery WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
120/240 VAC, w/Filter WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
120/240 VAC, w/Battery, w/Filter WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
AC Power Cable, 10’ Unterminated #16 SJO (P/N 105704-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Table of Contents
Table of Contents
vi UtiliNet Technical Reference Guide
AC Power Cable, 10’ Unterminated #10 Two Wires (P/N 105627-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
AC Power Cable, 6’ Terminated AC Plug (P/N 105628-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
RS-232 Signal, 40’ Unterminated (P/N 105554-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
RS-232 Signal & DC Power Cable, 10’ Unterminated (P/N 105552-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
RS-232 Programming Cable, 6’ Terminated Two DB-9 (P/N 105617-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Battery (P/N 105360-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
UtiliNet WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
WanGate Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
UtiliNet WanGate Radio Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
UtiliNet Radio General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
WanGate Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Chapter 4 UtiliNet MicroRTU WanGate Radio
120/240 VAC, w/Battery MicroRTU WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
RS-232 Signal & I/O Cable, 10’ Unterminated (P/N 106459-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
RS-232 Programming Cable, 6’ Terminated DB-9 (P/N 106468-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
UtiliNet Micro RTU WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
MicroRTU WanGate Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
UtiliNet Micro RTU WanGate Radio Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
UtiliNet Radio General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
MicroRTU WanGate Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Chapter 5 UtiliNet Network Radio
120 VAC Network Radio (P/N 105644-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
120 VAC, “N” Connector Antenna Mount Network Radio (P/N 105646-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
240 VAC Network Radio (P/N 105645-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
240 VAC, “N” Connector Antenna Mount Network Radio (P/N 105647-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
UtiliNet Network Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Network Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Network Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
UtiliNet Network Radio Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
UtiliNet Radio General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Chapter 6 Antenna Guide
Antenna Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Antenna Mounting Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Remote Mount Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Vertical Pipes and Tower Legs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Wooden Poles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Antenna Cable Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Antenna Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Jumper Cable Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Application Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Mounting Antenna Directly to the Equipment Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Using a Bulkhead Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Impulse Suppressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Table of Contents
UtiliNet Technical Reference Guide vii
Weather Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Chapter 7 SCADA Application Development
Connection Oriented Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Master/Slave Architectures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Polling Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Communications Architectures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Round-Robin Polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Communications Exchanges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Connectionless Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Packet-Switched Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
SCADA Protocol Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Master Request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Opcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Data - Opcode Dependent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Checksum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
RTU Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Opcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Data - Opcode Dependent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Checksum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
UtiliNet System Integration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
The Open System Interconnection (OSI) Reference Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Physical Layer (Layer 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Data Link Layer (Layer 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Network Layer (Layer 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Design Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Latency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Indeterminate Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Integration Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Transparent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Normal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Prepending . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Frame Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Standard Middleware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Custom Middleware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Development Environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Device Control Word (DCW) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Lan Packet Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Engineering Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Unsolicited Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Minimized Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13
Multiple Outstanding Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13
Table of Contents
viii UtiliNet Technical Reference Guide
Chapter 8 Network Engineering
Network Design Plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
OSI Layers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Traditional Radio Comparisons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Line-Of-Sight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Network Design for 900 MHz Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Calculating Latitude/Longitude Coordinates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Global Positioning System (GPS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
United States Geological Survey Maps - USGS Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
MapInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
RF Considerations and System Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Radio Link Budget . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Transmit Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Ground Plane Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Transmitter Transmission Line Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Total Path Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Free Space Path Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
Additional Path Loss Attenuation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
Receiver Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Receiver Transmission Line Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Noise Floor Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Multipath Fade Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Margin of Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Keeping a Check on Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
In-Band Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
Antenna Spacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
Out-of-Band Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
Cellular Base Station Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
Paging System Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
RF Filter Recommendation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
Performing RF Field Studies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13
Design Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
Use of Directional or Gain Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
Directional Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15
Site Surveying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15
Weak Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16
Chapter 9 Network Installation
Radio Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Configuring a Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Reconfiguring a Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Network Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Limitations of Standard Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Problem Routing Situations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Cul-de-sacs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6
Indications of Routing Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Excessive Delays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Table of Contents
UtiliNet Technical Reference Guide ix
Lost Packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Identifying Routing Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-9
Customizing Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Improving Connectivity: Additional Routers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Non-Routers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-12
Fake Latitude/Longitudes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-14
Domain Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
Domain Routing Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-20
Route to Core . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-20
Core Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
Mobile Radio Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-23
Configuring Mobile Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-23
Unconfiguring Mobile Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-23
Talking From Mobile Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-24
Talking to Mobile Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-24
Mobile Radio Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-24
Upgrading Radio Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-25
Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-25
Series I Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-26
Chapter 10 Support Products and Services
Miscellaneous Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
Antenna, 5 dB Gain Whip, 915 MHZ, N-Male (P/N 106119-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
RPLC MetriModem (P/N 102740-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
General Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
RadioShop Software (P/N 107558-000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
UtiliNet ToolBox (P/N 512971-020) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
Firmware Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Serial Download Tool (SDT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Network Download Tool (NDT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Middleware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-4
Allen Bradley DF1 Full-Duplex Intercept Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-4
Allen Bradley DF1 Full-Duplex Intercept Drivers-Corporate License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-5
Table of Contents
xUtiliNet Technical Reference Guide
Appendix A Unlicensed Radio Using Spread Spectrum: a Technical Review
Abstract . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Technology and Licensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Frequency Hopping: The Most Robust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
Capacity—The Windfall of Spread Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
But What Happens When Everyone Is On The Band? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8
Appendix B Implementation of Unlicensed Wireless Technology
Abstract . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Frequency Hopping Techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
Synchronous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
Asynchronous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
How It’s Done . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
New FCC Regulations For 902 To 928 MHZ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-5
References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-5
Glossary
Index 1
UtiliNet Technical Reference Guide xi
1.1 UtiliNet Technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
2.1 Integrated WanGate Radio DC Version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Integrated WanGate Radio DC Version Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.3 120 VAC to 12VDC Power Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.4 IWR DC Version Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.5 IWR Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.6 Integrated WanGate Radio AC Version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.7 Integrated WanGate Radio AC Version Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.8 IWR AC Version Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.9 Antenna Kit Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
2.10 Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
2.11 IWR Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.12 IWR with AC Power Supply Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
3.1 WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.3 AC Power Cable #16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.4 AC Power Cable #10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
3.5 AC Power Cable 6’. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
3.6 RS-232 Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
3.7 RS-232 Signal and Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
3.8 RS-232 Programming Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3.9 Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
3.10 WanGate Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.11 WanGate Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.12 WanGate Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
4.1 MicroRTU WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 MicroRTU WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4.3 RS-232 Signal and I/O Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.4 RS-232 Programming Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.5 MicroRTU WanGate Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.6 MicroRTU WanGate Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4.7 MicroRTU WanGate Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
5.1 Network Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 Network Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.3 Network Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
5.4 Network Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
5.5 Network Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
6.1 Integrated WanGate Radio Antenna Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6.2 Antenna Mounting Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6.3 Antenna Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6.4 Jumper Cable Assemblies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6.5 Antenna Mounting to Equipment Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
6.6 Bulkhead Connector - 91100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
6.7 Impulse Suppressor - LA900 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
9.1 Standard Format (Geographic Routing). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
9.2 Problem Routing Situations - Obstructed Sites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
9.3 Problem Routing Situations - Localized Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
9.4 Problem Routing Situations - Routing Efficiency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
List of Figures
Figure Figure Titles Page
List of Figures
xii UtiliNet Technical Reference Guide
9.5 Problem Routing Situations - Non-Forward Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6
9.6 Cul-de-sacs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
9.7 WAN Nodes Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
9.8 Scan List Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
9.9 Customizing Routing-Adding New Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11
9.10 Customizing Routing - Non-Routing Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-13
9.11 Customizing Routing - Faking Geographic Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-15
9.12 Customizing Routing - Faking to Exclude Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-16
9.13 Customizing Routing - Domain Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-18
9.14 Domain Routing Report from Domain Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
9.15 Domain Routing Query Report from Core Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-22
10.1 5 dB Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
10.2 RPLC Metrimodem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
Figure Figure Titles Page
UtiliNet Technical Reference Guide xiii
2.1 IWR DC Version Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.2 IWR AC Version Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3 IWR General Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
3.1 UtiliNet WanGate Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.2 UtiliNet Radio General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
4.1 UtiliNet MicroRTU WanGate Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
4.2 UtiliNet Radio General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
5.1 UtiliNet Network Radio Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5.2 UtiliNet Radio General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
8.1 Free-Space Path Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
8.2 Multipath vs. Percent Coverage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
8.3 Example Link Budget Calculation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
8.4 Minimum Free-Space Antenna Spacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
8.5 RF Filter Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
8.6 Connectivity Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
8.7 Directional Antenna FCC Candidates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15
List of Tables
Table Table Titles Page
List of Tables
xiv UtiliNet Technical Reference Guide
Notes:
UtiliNet Technical Reference Guide 1-1
Chapter 1 Introduction
This manual provides technical information for the line of radios used in the
UtiliNet® Wireless System. Included are photos, specifications, diagrams, and
accessories for each radio type as well as detailed information on applications
using the radios and other related information.
System Overview
UtiliNet is a comprehensive wireless data communications solution that utilizes
spread-spectrum radios in the 902-928 MHz area of the radio spectrum to provide
reliable network answers for remote telemetry or distributed control applications.
UtiliNet radios combine three important technologies: a mesh architecture for
peer-to-peer communications and true networking functionality, asynchronous
spread spectrum frequency hopping for maximum use of bandwidth, and packet
switching for guaranteed message transfer and automatic store-and-forward
routing.
Figure 1.1 UtiliNet Technologies
These three technologies work together to ensure that UtiliNet networks are fast
(up to 9600 bps), operate transparently, and are reliable in the delivery of all data
messages. These are the key advantages of UtiliNet.
Introduction
1-2 UtiliNet Technical Reference Guide
UtiliNet Basics
UtiliNet is a wireless data communications network based on spread-spectrum
radio technologies.
Network of Intelligent Radios
UtiliNet radios form the foundation of a UtiliNet network and serve multiple
functions.
• Each radio can communicate to end devices for some data collection or
control function.
This may involve transparent applications where data is merely passed
through UtiliNet radios, or it may involve programs running in radios and/or
other gateway devices to perform custom applications, higher network
efficiency or enhanced functionality.
• Each radio interacts with its UtiliNet radio RF neighbors to form a wide area
network (WAN) into which it may initiate a packet, automatically route a
packet between other radios, or accept a packet as the final destination.
• Each radio automatically integrates itself into an RF wide area network and
routes packets.
Upon power up or reboot, and at intervals while powered on, a radio
automatically scans the frequency band searching for other UtiliNet radios in
its vicinity to learn about its RF neighbors. As the radios learn about one
another, they pass their geographic address coordinates for routing and to
keep communication statistics for choosing the best data transmission paths.
This allows the radios to automatically route packets and dynamically build
routing tables to choose the best paths if RF conditions change. Once
configured by the user, radios automatically acquire radios and route packets.
• Each radio can execute one or more programs written in the Device Control
Word (DCW) language.
These programs can send, receive, and process packets to and from other
radios. They also are able to send, receive, and process data to and from end
devices connected to the radio. Examples of DCW applications include: radio
configuration, radio queries, data collection, communication to end devices,
protocol translation and peer-to-peer control.
Several types of UtiliNet radios are available:
• The Integrated WanGate Radio (IWR) and WanGate radio are used with RS-232
end devices and as additional repeaters if necessary (the IWR is designed for
installation inside another enclosure and the WanGate is designed for
independent outdoor installations).
• The MicroRTU WanGate radio allows an integrator to install an appropriate
RTU into the specialized MicroRTU WanGate enclosure to create a combined
RTU and radio communication package.
• The Network radio is used with Reliable Power Line Carrier (RPLC) end
devices.
Introduction
UtiliNet Technical Reference Guide 1-3
Mesh Architecture
Much like a giant net over a service area—UtiliNet radios work together to create a
mesh. At each point where one thread of the net crosses over another, a node is
created in the wider area network.
Because each radio can forward messages to and respond to every other radio in
the network, each radio is an equal participant in the network. The result is
increased communication reliability because there is no single point of failure.
While a radio is interacting with an end-device, it can be simultaneously acting as
part of the mesh network. The concept of creating a mesh is central to what makes
UtiliNet a truly robust data communication solution.
Radios With Programmable Intelligence
Each radio is similar to a programmable logic controller (PLC). The radio acts
much like a small computer, carrying out any number of computing and command
functions. The intelligence in each radio enables it to perform many functions not
normally associated with radios such as making intelligent routing decisions,
transporting industry protocols, and recognizing operating conditions and
responding with pre-programmed logic.
Packets Hop From Radio To Radio
When an end device generates a message that needs to traverse the network, the
end-device radio packets the data, places the data into an envelope—addressed to
the destination radio—and enters it into the network. The data packet traverses
the network by hopping from radio to radio in the direction of the destination
radio. The number of hops between origin and destination radio(s) is automatically
minimized to increase transmission speed. The route chosen for traversing the
network is dynamic and employs automatic re-routing in the event a particular
data path is not clear.
Polling and Report By Exception
Traditional point-to-multipoint systems are prone to network latency as only one
radio can communicate with the master at a time. A mesh network eliminates this
problem as data is evenly spread across the entire mesh (i.e., a multipoint-to-
multipoint network). Further, most traditional network topologies poll, gathering
data sequentially. UtiliNet radios can be programmed to respond under
predetermined parameters or on an unsolicited, report-by-exception basis—which
is both faster and more efficient.
A node could be represented by one radio attached to end-devices.
Introduction
1-4 UtiliNet Technical Reference Guide
About This Manual
This technical reference guide explains UtiliNet in great detail from application
design through implementation and operation to after-sales services and support.
Also included are a glossary of important terms and papers on extended UtiliNet
topics.
Chapter Title Description
1Introduction Provides introductory information about the Utilinet
network and this manual.
2 Integrated WanGate Radio (IWR) Describes the Integrated WanGate Radio.
3 WanGate Radios Describes the WanGate Radios.
4 UtiliNet MicroRTU WanGate Radio Describes the UtiliNet MicroRTU WanGate Radio.
5 UtiliNet Network Radio Describes the UtiliNet Network Radio.
6 Antenna Guide Provides information on antenna installations.
7 SCADA Application Development Gives detailed information on SCADA structure and
development, as well as UtiliNet system integration.
8 Network Engineering Contains information on network design, latitude/
longitude calculations, system design, field studies,
and use of directional antennas.
9 Network Installation
Provides information and drawings for radio
configuration, transparent configuration, radio
installation, network routing, mobile radio
configuration, as well as upgrading radio firmware.
10 Support Products and Services Provides descriptions of commonly used UtiliNet
radio support products and services.
Appendix A FCC Regulations Appendix A contains the FCC rules and regulations
pertaining to UtiliNet radios.
Appendix B Unlicensed Radio Using Spread
Spectrum: a Technical Review Appendix B presents a paper providing additional
information on using spread-spectrum technology.
Appendix C Implementation of Unlicensed
Wireless Technology
Appendix C presents a paper providing additional
information on the implementation of unlicensed
wireless technology.
Glossary Provides a list of terms and definitions commonly
used in UtiliNet radio applications.
Index Provides an index into this Technical Reference
Guide.
Introduction
UtiliNet Technical Reference Guide 1-5
Icons
Throughout the document, various icons are used to draw your attention to
important information. Below are examples:
Contacting Technical Support
Within the United States, Cellnet technical support is available Monday through
Friday, 8:00 A.M. to 6:30 P.M. Eastern Standard Time by telephone, fax, or email.
Whichever method you use to contact technical support, be prepared to give the
following information:
• Exactly what problem you encountered.
• A description of what happened and what you were doing when the problem
occurred.
• A description of how you tried to solve the problem.
Telephone
Technical support is available by calling 1-866-877-2007. If all support technicians
are helping other customers, your call will be routed to the Cellnet Support voice
mail system. Please leave a brief message that includes the following information:
•Your name
• Your company’s name
• Your telephone number
A support technician will return your call as soon as possible within normal
business hours. Technicians return all calls in the order that they are received.
The warning icon identifies information that is critical to maintaining
the integrity of the software or data.
The caution icon identifies important information.
The note icon identifies information that clarifies a point within the text.
Introduction
1-6 UtiliNet Technical Reference Guide
Fax
If you prefer, you may fax a description of your problem any time to 1-864-638-
4850. A support technician will answer your fax within 24 hours. Follow these
instructions when sending a fax:
• Address the fax to “Cellnet UtiliNet Support.”
• Include a brief description of the problem.
• Tell Cellnet the best time of day to contact you.
Email
If you prefer, you may email a description of your problem to:
elecsupt@slb.com
A support technician will return your email as soon as possible within normal
business hours. Technicians return all emails in the order that they are received.
UtiliNet Technical Reference Guide 2-1
Chapter 2 Integrated WanGate Radio (IWR)
The UtiliNet Integrated WanGate Radio (IWR) communicates via RS-232 to end
devices and is designed for internal mounting, such as inside a remote terminal
unit enclosure. The radio is commonly interfaced with such devices as remote
terminal units (RTUs), programmable logic controllers (PLCs), and other
intelligent end devices (IEDs).
The Integrated WanGate has two RS-232 serial ports—a LAN Packet Protocol Port
and a Transparent Port. The LAN Packet Protocol Port is used to communicate to
devices which use UtiliNet LAN Packet Protocol (ULPP), such as a PC with
configuration or diagnostic software, or an end device which has implemented
ULPP. The Transparent Port is a general data port and used to transport byte-
oriented data, such as that generated by industry standard protocols.
The Integrated WanGate Radio comes in a 12/24 VDC version and an AC version
which combines the DC radio with a 120 VAC power supply.
IWR VDC Version (P/N 269550000-000)
The IWR, DC version, comes in a metal enclosure and is designed to be placed
inside an RTU or like enclosure (see Figure 2.1).
Figure 2.1 Integrated WanGate Radio DC Version
The radio has a two-pin Molex connector for 12/24 VDC input. It has one DB-9 RS-
232 connector for transparent data and one DB-9 connector for ULPP operations.
Integrated WanGate Radio (IWR)
2-2 UtiliNet Technical Reference Guide
The radio comes with a standard N-Female antenna connector mount and
mounting hardware (see Figure 2.2).
Included are the following:
• Integrated WanGate Radio
• Two mounting brackets
• Four 6-32 screws
•Four 10-32 screws
• Four 10-32 hex nuts
• DC power connector with 48" cable
• Reference mounting drawing
Figure 2.2 Integrated WanGate Radio DC Version Components
120 VAC to 12 VDC Power Adapter (P/N 105690-000)
This Power Adaptor Cube (see Figure 2.3) plugs into a 120 VAC outlet and provides
12 VDC to the IWR, DC version. The cable is 68" long. Since the DC version of the
IWR is intended to be wired directly to 12 VDC in a final installation, this is
typically only used for demonstration and test purposes.
Figure 2.3 120 VAC to 12VDC Power Adapter
Integrated WanGate Radio (IWR)
UtiliNet Technical Reference Guide 2-3
See Figure 2.4 for dimensional drawing and mounting options.
Figure 2.4 IWR DC Version Mounting
Integrated WanGate Radio (IWR)
2-4 UtiliNet Technical Reference Guide
IWR Pinout
Figure 2.5 IWR Pinout
IWR DC Version Specification
Table 2.1 IWR DC Version Specification
Data Ports/Formats
UtiliNet LAN Packet Port
Serial Interface
Data Rate
Protocol
Transparent Port
Serial Interface
Data Rate
Parity
Data Bits
Stop Bits
Duplex
Protocol
RS-232C
1200 or 9600 bps (N, 8, 1, FDX)
UtiliNet LAN Packet Protocol
RS-232C
300, 600, 1200, 2400, 4800, 9600, 19200, or 38400 bps
Odd, Even, or None
7 or 8
1 or 2
FDX
Any Asynchronous Byte-Oriented Protocol
Power
Input Voltage Range
Input Current
Input Current (RF transmit max) 1
Noise & Ripple allowed @ 12 VDC (max)
12 VDC Operation
10.5 - 16.0 VDC
130 mA
260 mA
200 mV p-p
24 VDC Operation
20 - 2/8 VDC
70 mA
135mA
Agency Approvals
FCC Certified Part 15.247
Integrated WanGate Radio (IWR)
UtiliNet Technical Reference Guide 2-5
IWR AC Version (P/N 269560000-000)
The IWR, AC version (see Figure 2.6) is the DC version of the IWR with a rugged
AC power supply, both mounted together on a plate. It is designed to be placed
inside an RTU or like enclosure. The radio has an unterminated 3-wire pigtail for
120 VAC input. It has one DB-9 RS-232 connector for transparent data and one DB-
9 connector for ULPP operations. The radio comes with a standard N-Female
antenna connector mount and mounting hardware.
Figure 2.6 Integrated WanGate Radio AC Version
Mechanical
Interface Connections
Power
Data Ports
Antenna
Enclosure (indoor)
Weight
Size
Amp Mate-N-Lock
DB-9
“N” Type, Female
Sheet Metal
1 lb. 6 oz.
5.38"W x 7.97"D x 1.95"H
(8.25"W w/mounting brackets)
1Maximum transmit duty cycle is estimated to be 15%
Integrated WanGate Radio (IWR)
2-6 UtiliNet Technical Reference Guide
Figure 2.7 displays the following components:
• Integrated WanGate Radio (w/AC power supply)
•Four 10-32 screws
• Four 10-32 hex nuts
• Reference mounting drawing
Figure 2.7 Integrated WanGate Radio AC Version Components
Integrated WanGate Radio (IWR)
UtiliNet Technical Reference Guide 2-7
Figure 2.8 displays the dimensional drawing and mounting options.
Figure 2.8 IWR AC Version Mounting
IWR AC Version Specifications
Table 2.2 IWR AC Version Specifications
Data Ports/Formats
UtiliNet LAN Packet Port
Serial Interface
Data Rate
Protocol
Transparent Port
Serial Interface
Data Rate
Parity
Data Bits
Stop Bits
Duplex
Protocol
RS-232C
1200 or 9600 bps (N, 8, 1, FDX)
UtiliNet LAN Packet Protocol
RS-232C
300, 600, 1200, 2400, 4800, 9600, 19200, or 38400 bps
Odd, Even, or None
7 or 8
1 or 2
FDX
Any Asynchronous Byte-Oriented Protocol
Integrated WanGate Radio (IWR)
2-8 UtiliNet Technical Reference Guide
Antenna Kit (P/N 105665-000)
The antenna kit provides a simple 5dB gain whip antenna and extends the IWR
antenna connection to an adaptor on the enclosure in which it is installed.
Figure 2.9 displays the following components:
• Antenna, 5 dB gain whip, 915 MHz, N-Male
• Coax jumper cable, RG 58, 18" N-Male to N-Male
• Antenna mounting plate
• Bulkhead connector w/O-ring gasket, lock washer, and nut
• Reference drawing
Power
120 VAC Operation
Input Voltage Range
Input Current
Input Current (RF transmit max) 1
96 - 144 VAC
45 mA
80 mA
Agency Approvals
FCC Certified Part 15.247
Mechanical
Interface Connections
Power
Data Ports
Antenna
Enclosure (indoor)
Weight
Size
3-wire pigtail, 18 AWG, 600 V
DB-9
“N” Type, Female
Sheet Metal
4 lb. 12 oz.
8.00"W x 10.00"D x 2.12"H
1Maximum transmit duty cycle is estimated to be 15%
Integrated WanGate Radio (IWR)
UtiliNet Technical Reference Guide 2-9
Figure 2.9 Antenna Kit Components
Filter (P/N 106460-000)
This band-pass filter (see Figure 2.10) attenuates out-of-band signals and is used to
reject interference from sources such as paging and cellular phones. It is designed
to be used with the IWR (both DC and AC) and to be placed inside an RTU or like
enclosure. It is a passive filter and connects in-line with the antenna coaxial cable.
The coaxial cable on the filter is RG-223 and is 35" long. Only sites that exhibit
interference from out-of-band sources require this filter. UtiliNet radios are
designed to be in-band interference tolerant; in-band interference has rarely been a
problem.
Figure 2.10 Filter
Integrated WanGate Radio (IWR)
2-10 UtiliNet Technical Reference Guide
Bandpass Filter Specifications
IWR General Specifications
Table 2.3 IWR General Specifications
Environmental Specifications
Temperature -40°C to 85°C
Operational Vibration 5 to 7.5 Hz 0.5” double amplitude
7.5 to 500 Hz 1.5g
Humidity 95% non-condensing
Electrical Specifications
Center Frequency (nominal) 915 MHz
Insertion Loss (906-920 MHz) < 1.8 dB
Insertion Loss (902-906 MHz) <3.0 dB
Insertion Loss (920-924 MHz) <3.0 dB
Characteristic Impedance 50 Ohms
Max VSWR (902-924 MHz) 1.45:1.0
Ripple (906-920 MHz) <0.5 dB
30 dB Stopband 800 to 894 MHz
929 to 1030 MHz
65 dB Stopband DC to 800 MHz
1030 to 2000 MHz
RF Power Capability > 10 Watts
General
Frequency Range
Channels
Channel Spacing
Raw RF Data Rate
Spreading Technique
Hopping Technique
Hopping Patterns
Network Address
902 - 928 MHz
240, 25 kHz wide
100 kHz
9600 bps
Frequency Hopping
Pseudo Random, Asynchronous
65,536 (Unique per Network)
Latitude/Longitude Coordinates
Receiver
Type
Dynamic Range
Packet Error Rate
IF Selectivity
45 MHz IF Rejection
Frequency Stability
Double Conversion Superheterodyne;
1st IF 45 MHz, 2nd IF 455 kHz
-104 to -20 dBm
1x10 -2 (1x10 -6 BER)
6 dB down @ 30 kHz
< 90 dB
2.5 ppm (0.00025%) @ -30 to +75 °C
5 ppm (0.0005%) @ -40 to +85 °C
