Lasmex HB65 Bluetooth Headset User Manual HB 65
Shenzhen Lasmex Industrial Co., Limited Bluetooth Headset HB 65
Lasmex >
User Manual
HB-65
Thank you for purchasing the LASMEX HB-65 Stereo Bluetooth
Headset , we encourage you to read this quick installation guide
thoroughly to get the most of this innovative bluetooth headset.
- Wireless stereo listening to music;
- Wireless hands-free phone;
- Remote control the music play;
- High sensitivity Mic. With chatting function, and noise reduction;
- Applicable equipment: mobile phone with bluetooth function,
iphone, laptop etc;
- Distance: up to 10m.
01
Introduction
Function
02
Button functions
03
Operation Instructions
1. If you cannot power on the headset, please check the battery
state, Charge it before powering on.
2. Please remember to power off the headset when you don't use.
3. If you don't use the headset for a long time, please charge
it firstly before the next time using.
4. Please don't open the headset or change the Li-battery by
yourself.
5. Please don't put the headset in wet place.
6. Please don't store it where the temperature is beyond 45
degree Celsius. Don’t put it in the fire, in order to prevent battery
explosion; please don’t disassemble the headset.
04
Attention:
Turn on
Press the ” button for 3 seconds when the
device is off. (Red LED slowly flashes and a
tone voice “power on”).
“
Enter the
pairing mode
When the device is off,
for 6 seconds. (Blue LED and Red LED quickly
flash alternately with a “ paring” voice).
Press the “ ” buttons
Pairing
In pairing mode use a Bluetooth function
mobile phone or other Bluetooth Master
Device and to perform pairing action
(Detail refer to the chapter about pairing).
Play / pause
Press “ ” to play when the device is pausing
and Press “ ” to pause when the dvice is
playing.
Previous Long press “ ” button for previous music.
Next Long press “ ” button for next music.
Volume up Short press the “ ” button for volume up.
Volume down Short press the “ ” button for volume down.
Turn off
Press the “ ” button for 3 seconds when the
device is on. (a tone voice “power off ” and all
LED is off).
Low battery warning (The Red LED flash).
Charging P
is on).
lug the charger to port of the device.(Red LED
Answer call Short Press the
coming.
“ ” button while the call is
Desired Result Required Action
In case of low battery, the Headset will send a low battery
alert tone, please charge up the HB-65 immediately.
1. This headset
2. Please use the equipped USB charging line to connect for
charging.
3. Charge time: we suggest 3 hours for the first time, then 2.5
hours each time next, Red LED will turn on when charging,
when fully charged, the LED indicator light turns blue.
uses a rechargable Lithium battery.
Charging:
End call Short Press the “ ” button while on going call.
Transfer call voice
To transfer the call voice between the mobile
phone and device, please press button “ ”
for two second then release it while a phone
call is on going.
Reject call Press the
when the call is ringing.
“ ” button for 2 second to reject call
Desired Result Required Action
Specification
Parameter
Bluetooth Specification
Bluetooth Profile
Bluetooth 4.1
A2DP1.2/AVRCP1.4/HSP1.2/HFP1.6
Speaker diameter
Speaker impedance
SPL
Distortion
Playback Time
Charging Time
Frequency Response
Dimension (LxWxH)
Weight
20Hz– 20KHZ
40mm
32ohm
95dB
2.5 hours
12 hours
≤3.0%
147x190x73mm
72g
Parameter
Speaker rated power 20mW
Value
Value
Volume+ / Forward
Volume- / Backward
Power / Pair / Play / Pa use
5V Charging input
Microphone
LED light
05 0 6
User Manual
Stereo bluetooth headset
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the
party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure
condition without restriction.
interference
by one or more of the following measures:
