Le Shi Zhi Xin Electronic Technology LEPBH301 Bluetooth sports headset User Manual
Le Shi Zhi Xin Electronic Technology (Tian jin) Limited Bluetooth sports headset
user manual
WARNING
Use these headphones at your own risk. The headphones may
reduce your ability to hear surrounding sounds. Do not use these
headphones while driving, riding a bike, or in situations where
failure to hear sounds in your environment could be dangerous.
Volume in excess of 85 decibels and for extended periods of
time may cause permanent hearing damage. Adjust the volume
to the appropriate level. Please take care when inserting into
your ear canal.
说明书示意图
R29 G173 B229
R170 G204 B3
R215 G12 B24
R92 G103 B103
R68 G79 B84
C83 M1 Y0 K0
C40 M5 Y100 K0
C0 M96 Y93 K2
C40 M20 Y10 K50
C50 M35 Y15 K65
PANTONE 2995C
PANTONE 382C
PANTONE 1795C
PANTONE 431C
PANTONE 432C
logo颜色
曹俊峰
胡鹤云
薛利文
王兴刚
宁 博
宁 博
王沛 朱逢春
吴世荣
2016.07.03
运动蓝牙耳机说明书
LePBH301
材质：157g无光铜，4c+4c , 折页
User Manual
LeEco Sports Bluetooth Headphones
Product Specifications
Bluetooth version: Bluetooth 4.1
Supported protocols: A2DP V1.2, AVRCP V1.4,
HSP1.2, HFP1.6
Digital signal processor (DSP): CVC 6.0
Frequency response: 20-20000Hz
Driver diameter: 0.27 in (6.8 mm)
Driver impedance: 16 ohm
SNR: ≥ 90 dB
Driver rated power: 5mW
Rated power: 10 mW
Sensitivity: 100±3dB
Charging current: 150mA
Battery type: lithium-ion battery 60mAh*2
Music playback time: approximately 8H
Talk time: approximately 8H
Standby time: approximately 200H
Full charging time: 1H~1.5H
Charging port: micro USB
Wireless transmission distance: approximately 32ft (10m)
Note: The headphones have a water protection rating
of IPX5 (splash proof) but they are not intended to be
submerged in water.
Changing earbud tips
How to wear (right ear is illustrated)
Left
LED
Volume down
Multifunction button
Volume up
USB
Right
50mm
85mm
Magnetic suction
Headphones Diagram
The magnetic earbuds clip together, so you can hang the
headset on your neck like a necklace when not in use.
Product Name: LeEco Sports Bluetooth Headphones
Product Model: LePBH301
Website: www.lemall.com
Customer Service: +1 (855) 343-6688
Made in China
Buttons Function
description Approach
blue light will come on. (2) When a connection is established, press and hold button for 3 seconds
When receiving an incoming call, press button.
When receiving an incoming call, press and hold button.
During a call, press button.
(1) When a third-party call comes in, press button quickly to answer the call and to end the
current call. Press and hold button in order to answer the call and put the current call on hold.
(2) When one call is on hold, press button quickly to hang up the current call and answer the
call on hold; press and hold button to shift between the two calls.
While call is connected, press button.
While call is connected, press button.
Pair
Answer
Reject the call
Stop the call
3-way calling
Volume up
Volume down
Play/pause music
Volume up/
next song
Volume down/
previous song
When music is playing, press button.
To turn volume up, press button.
To play the next song, press and hold button.
To turn volume down, press button.
To play the next song, press and hold button.
VOL"–"
VOL"+"
VOL"–"
VOL"+"
Multifunction
Button
Multifunction
Button
Multifunction
Button
Connect
Call
Music
The LED light will blink between red and blue. (2) When the power is on, the headphones will
automatically pair after 10 seconds if the LED light blinks blue. If pairing fails, the headset will
automatically search for devices to connect to as the LED blinks between red and blue.
Description of Functions
LeEco Sports Bluetooth Headphones (1)
Earbud tips (2)
Data cable and bag (1)
What’s Inside
Instructions
Buttons and LED Signals
Thank you for purchasing LeEco Sports Bluetooth
Headphones. Before using, please read the user's
guide carefully.
WARRANTY SERVICE
LeEco warrants the included hardware product and accessories
against defects in materials and workmanship for NINETY (90)
DAYS from the original retail purchase. LeEco does not warrant
against normal wear and tear, damage caused by accident or
abuse or damage resulting from improper charging. This warranty
is valid only in the country in which the product is purchased. For
service, contact us at 1-855-343-6688. Shipping charges may apply.
You may be required to provide proof of purchase in submission of
your warranty claim. If you submit a valid claim under this warranty,
LeEco will at its option repair your device or replace it with a new
or refurbished device subject to the full terms and conditions of the
warranty at www.lemall.com/us/warranty and any applicable
service policies at www.lemall.com. This warranty is in addition to
rights provided under local consumer laws.
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1)this device may not cause interference, and(2) this device must
accept any interference, includinginterference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables auxappareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes :(1) l'appareil ne doit
pas produire de brouillage, et(2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre lefonctionnement.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
