Le Shi Zhi Xin Electronic Technology LEUBP-201E Letv Selfie Stick User Manual
Le Shi Zhi Xin Electronic Technology (Tian jin) Limited Letv Selfie Stick
User manual
How to connect via Bluetooth
Product
Weight: 173g Extended length: 66cm
Materials: aluminum, plasc
Packing dimensions: 213x61x41mm
Baery
Capacity: 65mAh Standby me: 3 days
Working me: 30H Charging voltage: 5V
Input current: 300MA-2A Charging me: 1.5H
Charge cycles: ≥ 300
In the Box: selfie sck x1 lanyard x1
user manual x1 3R warranty cerficate x1
data cable x1
85mm
45mm
Kind noce: If the Letv selfie sck is not connected to a phone 10
minutes aer it is powered on, the indicator will go off and the selfie
sck will go into the hibernaon mode. In the photo-taking mode, the
indicator will go off and the selfie sck will go into the hibernaon
mode if idle for 24 hours. If the connected phone goes out of range
(10m in tesng environment), the selfie sck will go into the
hibernaon mode. You can wake it up by pressing the selfie buon.
Step 1.
Press the buon for 3 seconds and the LED indicator will
glow blue, indicang that the selfie sck is powered on.
When the indicator flashes blue, the device is in the
Bluetooth pairing mode (if it has never been connected)
Reconnecng mode (auto connecng to a paired device
in 5 seconds)
Step 2.
Turn on Bluetooth on the phone, search for “letv-ZPG”,
and tap it to auto pair and connect. When connected, the
indicator on the selfie sck will glow blue, and the
photo-taking mode is ready to use
Step 3.
Place the phone into the bracket, launch Camera on the
phone, and press the selfie buon to take photos/record
videos
Notes
1. Store and use the product in normal temperature.
2. Do not expose this product to rain and water or use in
a wet environment.
3. Do not throw the product to avoid damage.
4. Do not use chemical solvents to coat or wipe the
product.
5. The maximum weight capacity of the phone bracket
and connecng rod is 1kg.
6. Do not use the selfie sck where you are not
prohibited.
7. Check it in as luggage when taking a flight.
How to use the Letv selfie sck
Bluetooth connecon
*
Press for 3 second to power on
Press for 3 second to power off
4
5
6
Press the selfie buon
to take photos/record
videos
We suggest you to remove the phone case when using this device.
Do not twist the selfie sck using extra force.
(The indicator glows red during charging and goes off
when fully charged)
(The indicator glows blue when powered on and
flashes blue when pairing)
LeUBP-201E
The statements should be displayed in the user manual:
changes or modifications not expressly approved by the
party responsible for compliance could void the user’s aut-
hority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Oper-
ation is subject to the following two conditions: (1) this dev-
ice may not cause harmful interference, and (2) this device
must accept any interference received, including interferen-
ce that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide re-
asonable protection against harmful interference in a resid-
ential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and use-
d in accordance with the instructions, may cause harmful i-
nterference to radio communications. However, there is no
guarantee that interference will not occur in a particular ins-
tallation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following m-
easures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician
for help.
