Lee Technology Korea LT2001S NEXCALL COASTER PAGER User Manual
Lee Technology Korea Co., Ltd. NEXCALL COASTER PAGER
USERS MANUAL
Guestcall TM
“LT2001S, Guest paging system”
Operational Manual
www.leetek.org
leetek2001@yahoo.co.kr
Lee Technology Korea.Co.,Ltd(LEETEK)
3rd #499-2 Sang3dong, Wonmi-gu,
Puchon-city, kyunggi-do, Korea
T:82-32-324-9838/9
F:82-32-324-9840
FCC ID : QBT-LT2001S
Trade Name : Nexcall Coaster Pager
Model No. : LT2001S
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS :
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
NOTE:THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USERS AUTHORITY TO
OPERATE THE EQUIPMENT.
Operational Manual
SPECIFICATION
MODEL LT2001S
Frequency Range 450.000MHz~457.000MHz
Channel Spacing 25KHz
Sensitivity 5 ㎶/m
Selectivity 60dB @±25KHz
Spurious
Rejection 60dB Below Darrier
Modulation
Scheme F S K
Standard
Deviation ±4.5KHz
Baud Rate 512/1200/2400BPS
Power Supply 2.4VNimh Recharge Battery
Battery Life 2~3years
Low Battery
Level 1.1Volts
Dimensions(HWD) 110mm x 106mm x 26mm
Weight
wo/Battery 55g
Frequency
Stavility ±10ppm
Code Format POCSAG
1. Handing out the Coasters
Give the guest a coaster. Note their name and Coaster number on the sign out sheet.
Tell the guest the coaster will signal when their table (or Food) is ready. The default page for this
system is for the coaster to flash and vibrate for 3 minutes. After the coaster is finished vibrating it
automatically goes back into standby mode waiting for the next page. You can hand the coasters out
right from the charging stack (They will “demo” Page each time they are removed from the stack) or
you can simply store them in a basket and hand them out. A fully
Charged coaster will function without being recharged for 8 – 12 hours.
2. Paging the Guest
When the guest’s table (or food) is ready simply press the coaster number on the transmitter
Keypad followed by the “SEND” key. For example, Press “11-SEND” and coaster # 11 will signal.
3. Out of Range Feature
With this feature, the coaster will play a melody to inform your customer that they are Out of Range
and will miss their page. The melody will only stop if they are within range.
Default from the factory is Out of Range Off.
Out of Range on “9494”
Out of Range off “9393”
4. To turn the Out of Range feature an follow these procedures
Remove all the coasters from the charger base or simply unplug the power supply that is connected to
the charging unit. Press “911-ENTER-9494-SEND” on the transmitter. All the coasters will light up to
tell you that they have received the new code. To test the coasters, unplug the power supply that is
connected to the LEETEK transmitter. After 30 seconds, all the coasters will play a melody since they
are not receiving a signal from the transmitter. Return all the coasters to the charger base or plug in the
power supply. The coasters are ready to receive a page with the Out of Range feature turned on.
Follow the same procedure to turn the Out of Range feature off, but use the code “9393”
5. To Change the page type on a Coaster pager
With this feature you have the option of changing the way your coasters alert the guest.
Vibrate Only “9292”
Flash & Beep “9595”
Note: the beep alert will only sound for the first 10second of the 3 minute alert.
Flash & Vibrate “9696”
Flash only “9797”
Beep, Flash & Vibrate “9898”
To change the page mode of your coasters follow these instructions
Remove all the coasters from the charging unit or unplug the power supply that is connected to
the charger base. Press “911-ENTER” on the transmitter. For the message, enter the code (see
above) that corresponds to the alert that you want. For example, if you want the coasters to
flash Only, Press “911-ENTER–9797-SEND”. After sending the code, the lights on all the
coasters will flash.
Return all the coasters to the charger base or plug in the power supply. The coasters are ready
to receive the page with the new alert.
6. Auto-Locate Feature
This feature causes ALL coasters (that are not on the charging stack) to signal at once.
This feature is useful when you are closed and would like to locate any misplaced coasters around
your restaurant. To locate ALL coasters, press “1249–SEND” Any coaster not on the charging stack will
signal (Flash & Beep). Search your restaurant for missing coasters. Remember to check the parking lot
and look in the bushes! After finding all the missing coasters, put all the coasters on the charging rack
to stop the “auto locate” alert. Never press “1249-SEND” while coasters are with the guest – All
coasters will alert at once!!!
GuestCall Guest Paging System Operation
1. When a guest arrives, remove a coaster from the stack. It will alert for 10 seconds while you show them and explain what
they will be looking for when they are paged. Write the coaster number next to the person's name on the wait list.
2. When their table becomes available, simply enter their coaster number into the transmitter and press "SEND"
Example of Host/Guest Greeting
Host: Good evening Sir. Welcome to ______________. How many are in your party tonight?
Guest: Hello, there will be 4 of us.
Host: Your name please.
Guest: Smith
Host: Thank you Mr. Smith, do you have a smoking preference?
Guest: Yes, non-smoking.
Host: OK Sir, that’s the Smith party of 4 for a non-smoking table, correct?
Guest: Yes
Host: We currently have a 30 minutes waited for a table. Here, please take one of our Coasters. (Remove a coaster from
the stack… it signals… hand it to the guest.)
Host: Keep this coaster with you. It will flash / vibrate just like this when your table is ready. When it goes off, come back to
the host stand and we will seat you. You may go to the bar if you’d like and use the coaster for your drink or you can
sit out front on one of our benches. The coaster has a built in alarm that will “sing” if you have gone Out of Range
and cannot be paged. If it starts to sing, simply walk back towards the restaurant and it will stop singing when you get
back into range.
Guest: WOW! This is great. What a neat idea! You guys really know how to take care of your guests.
Host: Thank you Mr. Smith, we’ll see you in about 30 minutes.
GuestCall Troubleshooting
Charge light will not come on
a. Make sure there is power to the outlet
b. Try changing the position of the coasters on the stack. Make sure they are seated properly with the numbers
facing front.
c. Using a damp rag, clean metal contacts on coaster that will not light
d. Check all connections on charger bases. If only one stack of coasters will not light on the charger,
There is probably a bad connection. Move wires and be sure they are all plugged into back of black coaster
charger.
If you try all this and the coaster charging light will not come on you most likely have a blown power supply.
No range on coaster pagers
a. Be sure transmitter is not near any large metal objects, fire walls, etc.
b. Be sure antenna is connected properly and not broken.
Coasters are not paging or paging in a manner you did not program
Review Coaster modes and enter the code for the mode you would like. It probably has changed.
Coasters are not answering the page or acting strange
Make sure the Coaster has a full charge.
Before you call, try some of the following suggestion
*Remember that the capability of your system will be affected by: Foil backed wallboard, Metal mesh,
wire reinforced glass, metal sheeting, large mirrors, suspended ceilings, lift shafts etc. These can all
reflect and thereby reduce the signaling capability of the transmitter. A little forethought prior to
installation, coupled with a few tests, can normally avoid most of these problems.
1.Read through the manual. Answers to most questions can be found there.
A trouble shooting section further assists you in diagnosing the problem.
2. IMPORTANT NOTICE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
The changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device
is permitted. Any change to the antenna or the device could result in the device exceeding the RF
exposure requirements and void user’s authority to operate the device.
Warning: Changes or modifications made to this equipment not expressly approved by
LEETEK may void the FCC authorization to operate this equipment.
3. CAUTION : Never use any cleaner other than alcohol for the maintenance of this equipment. Organic solvent
such as benzene, toluene or acetone may spoil the plastic parts of this equipment.
4.RF Radiation Exposure
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment must be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
5.Do not subject this equipment to:
1)Mechanical shock 2)Excessive humidity or moisture 3)Extremes of temperature 4)Corrosive liquids
6.Warning ! No user serviceable parts
Alteration or modification to any part of this equipment, without the prior written consent of the manufacturer,
will invalidate all manufacturer approvals and warranty. No adjustments can be undertaken except by qualified
and licensed persons as defined by the FCC Rules and Regulations. Operation of altered equipment can result
in fines, imprisonment, and /or confiscation of such equipment.
I need to send some transmitter in for repair - What do
I do?
Within warranty period / Covered by our Product-Care Program:
Ship malfunctioning components to the following address:
3rd FL, #499-2 Sang 3-dong, Wonmi-gu, Puchon-city, Kyunggi-do, Korea
Tel: 82-32-678-8605 Fax: 82-32-324-9840
1. Pack the components securely
2. Enclose a note with a brief description of the problem
3. Include a business card
4. Ship the equipment in a traceable manner for your protection. (ie UPS ).
5. Insure the shipment for replacement value.
There are no charges for repaired equipment within the warranty period, or if covered by Product-Care, other than your
shipping costs. We will pay shipping one way back to you.
(Shipping by the courier service is available at an additional charge on request)
Out of warranty items will be repaired and sent back C.O.D.
Hints and Tips
Training is the key to success with a paging system.
Orientating your entire staff and training your host staff on the use of the paging system is key to the success of the system.
As a part of the general host training program, time must be set aside to teach new hires about the use and care of the
paging system. Be certain staff members understand the importance of asking for the transmitter back after work.
Benefits of a VISUAL paging system
Staff members are alerted thru the pager and know to quickly close the tab of a guest to help speed table turns.
LEE TECHNOLOGY KOREA CO., LTD.
WARRANTY
LeeTek warrants this product against any defects that are due to faulty material or workmanship for a one-
year period after the original date of consumer purchase. This warranty does not include damage to the
product resulting from accident, misuse or improper electrical connection. Power supplies are warranted
for 60 days. We recommend the use of a surge protector with all equipment. If this product should
become defective within the warranty period, we will repair or replace with equivalent product, free of
charge. We will return your product, transportation charges prepaid standard shipping mode, provided the
product is shipped prepaid to:
LEETEK, 3rd FL #499-2 Sang 3-dong, Wonmi-gu, Puchon-city, Kyunggi-do, KOREA
No return will be received without prior authorization and the proper RMA # posted to the outside of the
shipping container.
This warranty gives you specific legal rights and you may also have rights which vary from state to state.
