Lee Technology Korea LTK-1600T PAGING TRANSMITTER User Manual
Lee Technology Korea Co., Ltd. PAGING TRANSMITTER
USERS MANUAL
TableCall Transmitter
Operation Manual
LEE TECHNOLOGY KOREA CO., LTD.
FCC ID : QBTLTK-1600T
TRADE NAME: TABLECALL TRANSMITTER
MODEL NO.: LTK-1600T
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS :
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
FCC NOTICE
WARNING : The antenna must be installed in a manner that ensures a
minimum separation distance of 20 centimeters between the antenna and
human beings.
TableCall TRANSMITTER
1. RECEIVER (PAGER)
1) SPEC
z 7 Segments Display
z Rechargeable Battery Included
z 1 Button Switch
z 5 LEDs
z Vibe and LED Flashing Alert
z Maximum 10 Table Number Can Be Stored.
2) PAGER SETUP
1. Insert your pager into the slot of its charger base.
2. The red LED on the top lights up and it indicates the pager is charged properly.
3. Whenever you remove a charged pager from its slot, red light will blink with
vibration for 10 seconds.
4. “READY” is displayed on LCD.
3) POWER ON/OFF
z Press switch more than 3 seconds while displaying “READY” or “CALL”.
4) PAGING
z The corresponding table number is displayed with the alert for 3 minutes. When
paged.
z Press the button to stop alert.
z After 3 minutes alert, pager displays “CALL” and blink 2 LEDs
z Table number is displayed when press the button while displaying “CALL”
z The table number is deleted if press the button more than 3 seconds while the
table number is displaying.
2. TRANSMITTER
1) SPEC
z 3 Buttons
z 2 LEDs
z Rechargeable
2) TO PAGE WAITER
(1) When you press Waiter Button shortly, it transmits table number data to
corresponding waiter pager.
(2) After transmitting is finished, green LED is blinking
(3) When you press Cancel Button shortly, it transmits cancel data to corresponding
waiter pager.
3) TO PAGE MANAGER
(1) When you press Manager Button shortly, it transmits cancel table number data to
corresponding manager pager.
(2) After transmitting is finished, red LED is blinking
(3) When you press Cancel Button shortly, it transmits cancel data to corresponding
manager pager.
4) TO CANCEL
z Cancel signal is received, the corresponding table number is deleted after
displaying the table number and “CANCEL” twice.
z Then pager goes to waiting mode and display “READY”
z All the table number stored deleted when reset or turn pager OFF and ON.
5) TO CHARGE
When you make it charged, charging LED at the right side of number label is ON.
Troubleshooting
Transmitter will not display anything
a. Make sure there is power to the outlet
a. Check all connections.
If you try all this and the transmitter still won’t power up your power supply may be bad. If
display is still blank, call us
Before you call, try some of the following suggestion
*Remember that the capability of your system will be affected by: Foil backed wallboard, Metal
mesh, wire reinforced glass, metal sheeting, large mirrors, suspended ceilings, lift shafts etc. These
can all reflect and thereby reduce the signaling capability of the transmitter. A little forethought prior
to installation, coupled with a few tests, can normally avoid most of these problems.
1.Read through the manual. Answers to most questions can be found there.
A trouble shooting section further assists you in diagnosing the problem.
2. IMPORTANT NOTICE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
To comply with the FCC RF exposure compliance requirements, no change to the
antenna or the device is permitted. Any change to the antenna or the device could
result in the device exceeding the RF exposure requirements and void user’s
authority to operate the device.
This device complies with Part 15 of the FCC Rules .
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications made to this equipment not expressly approved by
Leetek may void the FCC authorization to operate this equipment.
3. CAUTION : Never use any cleaner other than alcohol for the maintenance of this equipment.
Organic solvent such as benzene, toluene or acetone may spoil the plastic parts of this equipment.
4.RF Radiation Exposure
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment must be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
5.Do not subject this equipment to:
1)Mechanical shock 2)Excessive humidity or moisture 3)Extremes of temperature 4)Corrosive
liquids
6.Warning ! No user serviceable parts
Alteration or modification to any part of this equipment, without the prior written consent of the
manufacturer, will invalidate all manufacturer approvals and warranty. No adjustments can be
undertaken except by qualified and licensed persons as defined by the FCC Rules and Regulations.
Operation of altered equipment can result in fines, imprisonment, and /or confiscation of such
equipment.
I need to send some transmitter in for repair - What do I do?
Ship malfunctioning components to the following address:
LEE TECHNOLOGY KOREA CO., LTD.
3rd FL #499-2 Sang3-dong, Wonmi-gu, Pucheon-city, Kyunggi-do, Korea
TEL: 82-32-324-9838, FAX: 82-32-324-9840
WARRANTY
LEETEK warrants this product against any defects that are due to faulty material or
workmanship for a one-year period after the original date of consumer purchase. This
warranty does not include damage to the product resulting from accident, misuse or
improper electrical connection. Power supplies are warranted for 60 days. We
recommend the use of a surge protector with all equipment. If this product should
become defective within the warranty period, we will repair or replace with equivalent
product, free of charge. We will return your product, transportation charges prepaid
standard shipping mode, provided the product is shipped prepaid to:
3rd FL #499-2 Sang3-dong, Wonmi-gu,
Pucheon-city, Kyunggi-do, Korea
No return will be received without prior authorization and the proper RMA # posted to
the outside of the shipping container.
This warranty gives you specific legal rights and you may also have rights which vary
from state to state.
TableCall Transmitter
User Instruction Manual
LEE TECHNOLOGY KOREA CO., LTD.
FCC ID : QBTLTK-1600T
TRADE NAME: TABLECALL TRANSMITTER
MODEL NO.: LTK-1600T
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS :
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
TableCall Transmitter
1. Equipment Setup
Set up the Tablecall Transmitter on the table in Café, Restaurant and Beer house
without any additional setting.
2. System Operation
1) TRANSMITTER
(1) SPEC
z 3 Buttons
z 2 LEDs
z Rechargeable
(2) TO PAGE WAITER
(a) When you press Waiter Button shortly, it transmits table number data to
corresponding waiter pager.
(b) After transmitting is finished, green LED is blinking
(c) When you press Cancel Button shortly, it transmits cancel data to
corresponding waiter pager.
(3) TO PAGE MANAGER
(a) When you press Manager Button shortly, it transmits cancel table number data
to corresponding manager pager.
(b) After transmitting is finished, red LED is blinking
(c) When you press Cancel Button shortly, it transmits cancel data to
corresponding manager pager.
(4) TO CANCEL
z Cancel signal is received, the corresponding table number is deleted after
displaying the table number and “CANCEL” twice.
z Then pager goes to waiting mode and display “READY”
z All the table number stored deleted when reset or turn pager OFF and ON.
(5) TO CHARGE
(a) When you make it charged, charging LED at the right side of number label is
ON.
Troubleshooting
Transmitter will not display anything
a. Make sure there is power to the outlet
a. Check all connections.
If you try all this and the transmitter still won’t power up your power supply may be bad. If
display is still blank, call us
Before you call, try some of the following suggestion
*Remember that the capability of your system will be affected by: Foil backed wallboard, Metal
mesh,
wire reinforced glass, metal sheeting, large mirrors, suspended ceilings, lift shafts etc. These can
all reflect and thereby reduce the signaling capability of the transmitter. A little forethought prior
to installation, coupled with a few tests, can normally avoid most of these problems.
1.Read through the manual. Answers to most questions can be found there.
A trouble shooting section further assists you in diagnosing the problem.
2. IMPORTANT NOTICE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may
cause harmful interference to radio communications. However, there is no guarantee that
interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
To comply with the FCC RF exposure compliance requirements, no change to the
antenna or the device is permitted. Any change to the antenna or the device could
result in the device exceeding the RF exposure requirements and void user’s
authority to operate the device.
This device complies with Part 15 of the FCC Rules .
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation..
Warning: Changes or modifications made to this equipment not expressly approved by
Leetek may void the FCC authorization to operate this equipment.
3. CAUTION : Never use any cleaner other than alcohol for the maintenance of this equipment.
Organic solvent such as benzene, toluene or acetone may spoil the plastic parts of this equipment.
4.RF Radiation Exposure
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment must be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
5.Do not subject this equipment to:
1)Mechanical shock 2)Excessive humidity or moisture 3)Extremes of temperature 4)Corrosive
liquids
6.Warning ! No user serviceable parts
Alteration or modification to any part of this equipment, without the prior written consent of the
manufacturer,
will invalidate all manufacturer approvals and warranty. No adjustments can be undertaken
except by qualified
and licensed persons as defined by the FCC Rules and Regulations. Operation of altered
equipment can result in fines, imprisonment, and /or confiscation of such equipment.
I need to send some transmitter in for repair - What do I do?
Ship malfunctioning components to the following address:
LEE TECHNOLOGY KOREA CO., LTD.
3rd FL #499-2 Sang3-dong, Wonmi-gu, Pucheon-city, Kyunggi-do, Korea
TEL: 82-32-324-9838, FAX: 82-32-324-9840
WARRANTY
LEETEK warrants this product against any defects that are due to faulty material or
workmanship for a one-year period after the original date of consumer purchase. This
warranty does not include damage to the product resulting from accident, misuse or improper
electrical connection. Power supplies are warranted for 60 days. We recommend the use
of a surge protector with all equipment. If this product should become defective within the
warranty period, we will repair or replace with equivalent product, free of charge. We will
return your product, transportation charges prepaid standard shipping mode, provided the
product is shipped prepaid to:
3rd FL #499-2 Sang3-dong, Wonmi-gu,
Pucheon-city, Kyunggi-do, Korea
No return will be received without prior authorization and the proper RMA # posted to the
outside of the shipping container.
This warranty gives you specific legal rights and you may also have rights which vary from
state to state.
