Leedarson Lighting DLN9RAA10FR1 LED Downlight User Manual
LEEDARSON LIGHTING CO., LTD. LED Downlight Users Manual
Users Manual
LED Downlight User Manual
Electrical Specifications:
Model No. Rated Wattage
Rated
voltage
Frequency Rated Input
current
DL-N9RaA10FR1 10W 120 60Hz 85mA
WARNING：
IC NOTICE TO CANADIAN USERS
This device complies with Industry Canada license‐exempt RSS standard(s). Operation is subject to the
following two conditions: (1) This device may not cause interference, and (2) This device must accept any
interference, including interference that may cause undesired operation of the device. This device complies
with RSS‐247 of Industry Canada. Operation is subject to the condition that this device does not cause
harmful interference. This Class B digital apparatus complies with Canadian ICES‐003 (Cet appareil numérique
de la Classe B conforme à la norme NMB‐003 du Canada).
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body
Installation Instruction
STEP1:
Turn off the power before installation, Remove the diffuser existing bulb if necessaryand
remove the existing trim. Attach the relamping label to the inside of recessedluminaire housing.
STEP2:
As shown in Figure 1. Twist the lamp base into the lamp holder.
STEP3:
As shown in Figure 2,Connect Fixture Ground Wire to
housing.
Then connectedthe lamp,connector with lamp baseconnector.
STEP4:
①The lamp at both ends of the springare arranged inside the lamp holderbayonet,
(as shown in Figure 3) through the spring pressing on bothsides,
so that it can be on both sidesof the bayonet.
②If using friction clip blades,whilewearing gloves squeeze.
oposingclips to gether until clips fit insidehousing.
then carefully insert retrofitkit into housing allowing springs toexpand to hold in housing.
STEP5:
As shown in Figure 4Push the LED retrofit kit into therecessed light fixture,
allowing themounting clips to pull the LED retrofit kitup into the recessed light fixture.
Continue to push the LED retrofit kit untilits outer edge is flush against theceiling surface.
