LED User Manual

Model: y-A880ST-Q1R-xx

Electronic

Data

Parameter Units Min. Rated Max. Remark

Supply Voltage V 90 120 132

Supply Frequency Hz 60

Supply Current mA 88

Power Consumption W 8.5 9.5 10.5

Power Factor - 0.9

Drive output voltage V 48

Drive output current mA 153 170 187

LED Data

LED Model - 3535

LED Circuit Mode - 8S2P

LED Vendor - /

Chromaticity

Data

Parameter Units Min. Rated Max. Remark

Luminous Flux lm 800 880

Max Luminous

Intensity cd 94

Beam Angle ° 0.5 Imax：240

0.1 Imax：330

Luminous Efficiency lm/W 90

CRI - 80

CCT K 2580 2725 2870

SCDM -

Dominant

Wavelength nm

Dimming % Wireless

Rated luminous flux

in a 900(Φ900） lm

Rated luminous flux

in a 1200(Φ1200） lm

Energy Efficiency

Index (EEI) -

% 5 100

Light Distribution

Curve

Parameter Units Min. Rated Max. Remark

Standard IEEE 802.15.4

Wireless frequency GHz 2.4

Operating Frequency 2.4GHz ~

2.5GHz

Protocol - ZigBee HA 1.2

Effective Indoor

Connection Range m 40

In door direct range,

no walls or other

obstacles in

between.

Wireless IC NXP JN5168A

Wireless Module Part

number

A470S-A7R-01-

Antenna PCB Antenna

Operating

Condition

Parameter Units Min. Rated Max. Remark

Operating Ambient

Temperature ℃-20 25 40

Rated Lamp Life H 25000 25℃

L70,F50

Starting Time s 0.5

Lamp Warms-up time to

60% Φ s

Lamp Warms-up time to

95% Φ s

Drawings mm

StateBehaviordescription

1FactorystateFast2flashes,keepconstantlight(max

2Thematchstate1flashes

3NetworkstatusAdjustablelighting,eachpowerupbothtomaintainthe

brightnessofMax

4TurnoffthelightsactionWithin1seconddowntothedarkaftertheclose

5Fromthenetworkstate

1flashes,intothedark.Andnotthenet,torejointhe

newnetwork,youneedtosupplya.

6Resetaction

Fastswitch5times,powerontimemaintainedat

between0.5‐2seconds.Thesixthtimeafterpowerona

secondafter2flashesof100ms/100msisthemostdark

bright.Ifyouwanttorejointhenewnetwork,youneed

tosupplya.

Company:LEEDARSONLIGHTINGCO.,LTD.

Address:XingdaRoad,XingtaiIndustrialZone,ChangtaiCounty,Zhangzhou,Fujian,

China

ContactPerson:VickZhang

TEL:+86‐592‐3699897

E‐mail:cert@leedarson.com

FCCWarning

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwo

conditions:

(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptany

interferencereceived,includinginterferencethatmaycauseundesiredoperation.

NOTE1:Anychangesormodificationstothisunitnotexpresslyapprovedbytheparty

responsibleforcompliancecouldvoidtheuser'sauthoritytooperatetheequipment.
