Lenovo Mobile Communication Technology A706 Mobile Phone GSM/WCDMA User Manual Lenovo A706 UserMan
Lenovo Mobile Communication Technology Ltd. Mobile Phone GSM/WCDMA Lenovo A706 UserMan
user manual
User Manual
Model: Lenovo A706
Read this manual carefully
before operating the handset
lenovo
Mobile Phone GSM/WCDMA
English
2
Technical Parameters
Product Mobile Phone GSM/WCDMA
Model Lenovo A706
System Android 4.1.2
Size Approximately 136.3 mm × 69.3 mm × 10.4mm
Weight Approximately 138g (including battery)
Standby Time Max 120 hours*
Battery Capacity 2000 mAh
NOTES:*May vary depending on local signal strength.
3
Initial Setup Procedure
Removing and mounting battery cover
To remove the cover, perform the following procedure as shown in the
figure.
1. Find the recess in the lower-left corner.
2. Hold the top of your mobile phone.
3. Lift up from the recess.
4. Open the cover.
To mount the battery cover, gently fit and press it onto phone body until it
completely clicks into place.
4
Charging the phone
Inserting the SIM card
5
Inserting the memory card
6
Port Assignment and Button Layout
KEY Description
1 HOME KEY Can return to the idle interface.
2 MENU KEY Can enter the commonly used, the
characteristic and more menus.
3 BACK KEY Can return to the superior menu.
4 VOLUME KEY According to the volume switch increase
or decrease volume.
5 POWER ON/OFF
Short click this button to lock screen
function, long press the key to power
on/off the phone.
4
7
Applications Overview
Icon Name Note
Browser
Browses websites. The web browser in this unit
can access the Internet via the WIFI network for
business and personal use.
Email Receives/Sends and views mails by linking
directly to your mailbox.
Gallery
Browses and edits images. In an image
full-screen page it supports slideshow functions
and such operations as, Share, Set as, and
Details.
Contacts Allows you to add or delete contacts and edit or
delete particulars of a contact.
Calendar
Creates new events, toggles the day view, the
week view and the month view, and enables the
event reminder function.
8
Gravity sensor
Auto rotate screen according to the rotation of the device. To unlock the
screen direction: Menu > Settings > Display > Auto-rotate screen.
After launching one application, you can rotate the screen to your preferred
direction.
9
Precautions and Tips for A706 Safety and
Maintenance
When using mobile phone, please abide by the following.
Read the user manual thoroughly before using your mobile phone.
Do not turn on your mobile phone if use is prohibited or may cause
interference or danger.
Your mobile phone should be switched off while on airplanes. If the
alarm or schedule settings can cause the mobile phone to turn on
automatically when it is in “off” mode, the settings should be checked
to ensure they have been deselected before boarding.
When using your mobile phone, keep it away from hot or high-voltage
environments, such as electric appliances or cooking equipment.
To prevent fire, turn off your mobile phone in areas containing
flammable objects, such as filling stations and fuel storage.
Do not hold your mobile phone when driving. Do not place your phone
above an air bag in a car or any area that may be occupied by an
expanded air bag. You may get hurt if the phone is impacted by a
strong force by the air bag expanding.
Only Lenovo approved batteries, chargers and accessories may be
used. Lenovo is not responsible for any consequences due to the use
of accessories from a third party.
Do not disassemble your mobile phone.
When your mobile phone is close to other electronic devices,
interference may occur. Keep your mobile phone away from other
electronic devices, such as televisions, radios, personal computers,
pacemakers, hearing aids, medical equipment, etc. Do not store your
phone near credit cards or magnetic fields. In hospitals or other
10
special areas, use your mobile phone in accordance with the site’s
regulations.
Mechanically vibrating or shaking the mobile phone may cause
damage. Do not knock your phone screen with a sharp item.
Using a cell-phone case or plastic case may damage the surface of
your phone.
Do not use solvents (such as benzene, diluents, alcohol, etc.) to wipe
the mobile phone's cover. Similarly, do not bring your phone into
contact with corrosive chemicals or detergents. Only a clean, soft cloth
should be used to gently wipe your phone.
Avoid exposing the mobile phone to the sun or placing it in a smoky or
dusty environment.
Keep your mobile phone dry. It should never be used in a high
humidity environment, such as a bathroom. Your mobile phone is not
waterproof and should not be exposed to rain or other moisture.
If an external antenna is used on your mobile phone, do not touch the
antenna. Only the original antenna should be used. Your phone may
be damaged by using any other antenna.
When pulling out the charger plug from your mobile phone, hold and
pull the plug outwards. Do not jerk the power cord.
Do not depend only on your mobile phone as the sole communication
equipment for an emergency, such as a medical rescue.
To prevent hazards, place your mobile phone in a safe location out of
reach of children.
Be aware of heat generated by your mobile phone
When your Mobile phone is turned on or the battery is charging, some
parts might become hot. The temperature that they reach depends on the
amount of system activity and the level of charge in the battery. Extended
11
contact with your body, even through clothing, could cause discomfort or
even a skin burn. Avoid keeping your hands, your lap, or any other part of
your body in contact with a hot section of the Mobile phone for any
extended time.
Protect your data and software
Do not delete unknown files or change the name of files or directories that
were not created by you; otherwise, your Mobile phone software might fail
to work.
Be aware that accessing network resources can leave your Mobile phone
vulnerable to computer viruses, hackers, spyware, and other malicious
activities that might damage your Mobile phone, software, or data. It is your
responsibility to ensure that you have adequate protection in the form of
firewalls, antivirus software, and anti-spyware software and keep this
software up to date.
Keep electrical appliances such as an electric fan, radio, high-powered
speakers, air conditioner, and microwave oven away from your Mobile
phone because the strong magnetic fields generated by these appliances
can damage the screen and the data on the Mobile phone.
When using the battery, please abide by the following.
Before use, carefully read the user manual and labels on the battery.
Charge the battery in a cool and ventilated room. If the environment is
too hot, the battery may overheat, smoke, burn, deform, or even
explode.
There are special protective circuits and mechanisms within the
battery and must not be disassembled. Doing so may cause a short
circuit or electrolyte leakage. There is a risk of blindness if electrolyte
12
enters your eye. Should this occur, immediately use clean water to
rinse the eye (do not rub the eye), and seek medical treatment.
Prevent the battery from being squeezed, compressed, vibrated or
shaken. Always try to prevent the battery from short circuit, as this
may cause damage to the battery or components connected to it. A
short circuit can be caused by accidental contact between the battery
and metal objects; for example, coins, pens, and clips, in contact with
the positive and negative poles of the battery. Therefore, never store
the battery with metal objects.
Ensure metal contacts and the battery are clean.
Do not use damaged or dead batteries.
Replace the battery when it is unable to meet functional requirements.
Batteries can be charged hundreds of times before they require
replacement. Batteries are consumables; even though they can be
recharged, their storage capacity will reduce over time. When you
notice the service time (call and standby time) is reduced, the battery
should be replaced.
Avoid exposing the battery to the sun or placing it in a smoky or dusty
environment. The battery should never be used in a high humidity
environment, such as a bathroom. The battery is not waterproof and
should not be exposed to rain or other moisture.
Avoid placing the battery in an overly warm or cold environment; the
battery’s performance will be reduced when operating in temperatures
above 122 °F (50 °C) or below 14 °F (-10 °C).
To prevent explosion, never place the battery into fire.
To prevent short circuit leading to overheating, smoking, deformation,
damage or explosion, never place the battery into water.
13
Dispose of the battery in accordance with regulations (such as
recycling regulations). To prevent explosion or pollution, never
dispose of batteries as domestic waste.
This battery can only be charged by its dedicated charger. Do not
charge out range of 32 °F to 113 °F (0 °C to 45 °C). Charging must not
exceed 12 hours.
To prevent hazards, place the battery in a safe location out of reach of
children.
When using the battery charger, please abide by the following.
Before use, carefully read the user manual and labels on the charger.
Do not disassemble or refit the charger. Never use the charger when
power cord is damaged, as this may cause electric shock, fire or
damage the charger.
Never touch the charger with wet hands. If the charger comes into
contact with water or other liquids, cut off the power immediately.
Do not short circuit the charger, vibrate or shake it, expose it to direct
sunlight, or use it in high humidity environments (such as bathrooms).
The charger is not waterproof, and should not be exposed to rain or
moisture.
Do not use the charger near electric appliances, such as televisions or
radios.
When unplugging, hold the charger firmly; as pulling the power cord
could damage it.
To prevent hazards, place the charger in a safe location out of reach
of children.
14
When using headphones (which you may need to purchase
separately), please abide by the following.
When using headphones, to avoid hearing damage, remember to
adjust the volume to an appropriate level.
To avoid breakage, do not pull or drag headphone cables.
Using headphones in a high temperature and high humidity
environment for a long time can easily damage the headphones or
reduce their service life.
To avoid traffic accidents, do not use headphones when you are
driving, riding bicycles or walking near traffic.
To prevent hazards, place headphones in a safe location out of reach
of children.
Prevent hearing damage
Your mobile phone has a headphone connector. Always use the
headphone connector for headphones (also called a headset) or
earphones.
CAUTION:
Excessive sound pressure from earphones and headphones can
cause hearing loss. Adjustment of the equalizer to maximum
increases the earphone and headphone output voltage and the sound
pressure level. Therefore, to protect your hearing, adjust the
equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time at
high volume can be dangerous if the output of the headphone or earphone
connectors do not comply with specifications of EN 50332-2.
The headphone output connector of your Mobile phone complies with EN
50332-2 Sub clause 7. This specification limits the Mobile phone maximum
15
wide band true RMS output voltage to 150 mV. To help protect against
hearing loss, ensure that the headphones or earphones you use also
comply with EN 50332-2 (Clause 7 limits) for a wide band characteristic
voltage of 75 mV. Using headphones that do not comply with EN 50332-2
can be dangerous due to excessive sound pressure levels.
If your Mobile phone came with headphones or earphones in the package,
as a set, the combination of the headphones or earphones and the Mobile
phone already complies with the specifications of EN 50332-1. If different
headphones or earphones are used, ensure that they comply with EN
50332-1 (Clause 6.5 Limitation Values). Using headphones that do not
comply with EN 50332-1 can be dangerous due to excessive sound
pressure levels.
This device has been tested to comply with the Sound Pressure Level
requirement laid down in the applicable EN 50332-1and/or EN
50332-2standards. Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods of time.
Warning statement:
A pleine puissance, l'écouteprolongée du
baladeurpeutendommagerl'oreille de l'utilisateur.
European Community Compliance Statement
Users have to use the connection to USB interfaces with USB 2.0 version
or higher.
Caution:
Risk of explosion if battery replaced aced by an incorrect type.
16
Dispose of used batteries according to the instructions.
The device could be used with a separation distance of 1.5cm to the
human body.
The adapter shall be installed near the equipment and shall be easily
accessible.
Only can use adapter as below: Adapter mfg: lenovo
Adapter model: C-P38
I/P:100-240V,50/60Hz,0.15A,O/P 5V,1.0A
The plug considered as disconnect device of adapter
Assessment of compliance of the product with the requirements relating to
the Radio and Telecommunication Terminal Equipment Directive (EC
Directive 1999/5/EC) was performed by PHOENIX TESTLAB (Notified
Body No.0700), based on the following standards:
Health (Article 3.1(a) of the R&TTE Directive)
Applied Standard(s):
EN 50360:2001/A1:2012
EN62209-1:2006/EN62311:2008/EN62209-2:2010
EN 62479 :2010
Safety (Article 3.1(a) of the R&TTE Directive)
Applied Standard(s):
EN 60950-1:2006+A11:2009+A1:2010+A12:2011
EN 50332-1:2000
EN 50332-2:2003
Electromagnetic compatibility (Article 3.1 (b) of the R&TTE Directive)
Applied Standard(s):
EN 301 489-1 V1.9.2/-3 V1.4.1/-7 V1.3.1/-17 V2.2.1/-24 V1.5.1
Radio frequency spectrum usage (Article 3.2 of the R&TTE Directive)
Applied Standard(s):
17
EN 301 511 V9.0.2
EN 301 908-1/ -2 V5.2.1
EN 300 328 V1.7.1
EN 300 440-1V1.6.1/ -2 V1.4.1
18
Important Notices – Medical Device
Any radio equipment (including this mobile phone) may interfere with the
function of medical devices if insufficient measures are taken. Consult the
medical personnel or the manufacturer of the medical device if you have
any question or you are not sure whether the medical device can shield all
RF output. Follow the relevant provisions and prohibitions of using
electronic equipment or radio transmission.
Cardiac Pacemaker
Take the following suggestions as a reference if you are using a cardiac
pacemaker:
Always keep a distance of more than 6 inches (15.3 cm) between your
mobile phone and the pacemaker.
Do not put your mobile phone into your breast pocket.
Answer calls with the ear that is opposite to cardiac pacemaker, to
prevent any potential interference.
Hearing Aid and Cochlear Implant
If you use a hearing aid or cochlear implant, consult the authorized medical
personnel and take the manufacturer instructions as a reference before
using the mobile phone.
Turn off your phone and move it to a distant position if interference occurs.
Plastic bag notice
CAUTION:
Plastic bags can be dangerous. Keep plastic bags away from babies
and children to avoid danger of suffocation.
Polyvinyl Chloride (PVC) cable and cord notice
WARNING:
19
Handling the cord on this product or cords associated with
accessories sold with this product will expose you to lead, a chemical
known to the State of California to cause cancer, and birth defects or
other reproductive harm. Wash hands after handling.
20
Electronic emission notices
Federal Communications Commission (FCC) Declaration of
Conformity
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult an authorized dealer or service representative for help.
Lenovo is not responsible for any radio or television interference caused by
unauthorized changes or modifications to this equipment. Unauthorized
changes or modifications could void the user’s authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
21
Responsible Party:
Lenovo (United States) Incorporated
1009 Think Place - Building One
Morrisville, NC 27560
Telephone: 1-919-294-5900
FCC Caution
Any Changes or modifications not expressly approved by the party
responsible for compliance void the user’s authority to operate the
equipment.
The antenna(s) used for this transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
NOTE:
The country code selection is for non-US model only and is not available to
all US model. Per FCC regulation, all Wi-Fi products marketed in US must
be fixed to US operation channels only.
Specific Absorption Rate information
This phone is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the United States, Industry Canada of
Canada.
During SAR testing, this device was set to transmit at its highest certified
power level in all tested frequency bands, and placed in positions that
simulate RF exposure in usage against the head with no separation, and
near the body with the separation of 10 mm. Although the SAR is
determined at the highest certified power level, the actual SAR level of the
device while operating can be well below the maximum value. This is
22
because the phone is designed to operate at multiple power levels so as to
use only the power required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the power output.
The exposure standard for wireless devices employing a unit of
measurement is known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6W/kg, and 1.6W/kg by Industry Canada.
This device is complied with SAR for general population /uncontrolled
exposure limits in ANSI/IEEE C95.1-1992 and Canada RSS 102, and had
been tested in accordance with the measurement methods and procedures
specified in OET Bulletin 65 Supplement C, and Canada RSS 102. This
device has been tested, and meets the FCC, IC RF exposure guidelines
when tested with the device directly contacted to the body.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model phone is on file with
the FCC and can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID: YCNA706.
For this device, the highest reported SAR value for usage against the head
is 0.79 W/kg, for usage near the body is 1.49 W/kg.
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirements.
23
SAR compliance for body-worn operation is based on a separation
distance of 10 mm between the unit and the human body. Carry this device
at least 10 mm away from your body to ensure RF exposure level
compliant or lower to the reported level. To support body-worn operation,
choose the belt clips or holsters, which do not contain metallic components,
to maintain a separation of 10 mm between this device and your body.
RF exposure compliance with any body-worn accessory, which contains
metal, was not tested and certified, and use such body-worn accessory
should be avoided.
24
Recycling and environmental information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment to
responsibly recycle their equipment when it is no longer needed. Lenovo
offers a variety of programs and services to assist equipment owners in
recycling their IT products. For information on recycling Lenovo products,
go to: http://www.lenovo.com/recycling.
Important WEEE information
Country-specific information is available at
http://www.lenovo.com/recycling.
The WEEE marking on Lenovo products applies to countries with WEEE
and e-waste regulations (for example, European Directive 2002/96/EC,
India E-Waste Management & Handling Rules, 2011) . Appliances are
labeled in accordance with local regulations concerning waste electrical
and electronic equipment (WEEE). These regulations determine the
framework for the return and recycling of used appliances as applicable
within each geography. This label is applied to various products to indicate
that the product is not to be thrown away, but rather put in the established
collective systems for reclaiming these end of life products.
Users of electrical and electronic equipment (EEE) with the WEEE marking
must not dispose of end of life EEE as unsorted municipal waste, but use
the collection framework available to them for the return, recycle, and
25
recovery of WEEE and to minimize any potential effects of EEE on the
environment and human health due to the presence of hazardous
substances. For additional WEEE information go to:
http://www.lenovo.com/recycling.
China recycling information for Waste Electrical and Electronic
Equipment (WEEE)
Recycling information for India
Recycling and disposal information for India is available at:
http://www.lenovo.com/social_responsibility/us/en/sustainability/ptb_india.
html.
Additional recycling statements
Additional information about recycling computer components and batteries
is in your User Guide. See “Accessing your User Guide” for details.
Battery recycling mark
Battery recycling information for the European Union
Batteries or packaging for batteries are labeled in accordance with
26
European Directive 2006/66/EC concerning batteries and accumulators
and waste batteries and accumulators. The Directive determines the
framework for the return and recycling of used batteries and accumulators
as applicable throughout the European Union. This label is applied to
various batteries to indicate that the battery is not to be thrown away, but
rather reclaimed upon end of life per this Directive.
In accordance with the European Directive 2006/66/EC, batteries and
accumulators are labeled to indicate that they are to be collected
separately and recycled at end of life. The label on the battery may also
include a chemical symbol for the metal concerned in the battery (Pb for
lead, Hg for mercury, and Cd for cadmium). Users of batteries and
accumulators must not dispose of batteries and accumulators as unsorted
municipal waste, but use the collection framework available to customers
for the return, recycling, and treatment of batteries and accumulators.
Customer participation is important to minimize any potential effects of
batteries and accumulators on the environment and human health due to
the potential presence of hazardous substances. For proper collection and
treatment, go to: http://www.lenovo.com/recycling.
27
Restriction of Hazardous Substances Directive
(RoHS)
European Union RoHS
Lenovo products sold in the European Union, on or after 3 January 2013
meet the requirements of Directive 2011/65/EU on the restriction of the use
of certain hazardous substances in electrical and electronic equipment
(“RoHS recast” or “RoHS 2”).
For more information about Lenovo progress on RoHS, go to:
http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.
pdf.
28
China RoHS
The information in the following table is applicable for products
manufactured on or after March 1, 2007 for sale in the People’s Republic of
China.
29
Turkish RoHS
The Lenovo product meets the requirements of the Republic of Turkey
Directive on the Restriction of the Use of Certain Hazardous Substances in
Electrical and Electronic Equipment (EEE).
Ukraine RoHS
India RoHS
RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
EurAsia Compliance Mark
