Lenovo Mobile Communication Technology S660 Lenovo Mobile Phone User Manual Lenovo VV38 QSG EN 110 74mm v1 0

Lenovo Mobile Communication Technology Ltd. Lenovo Mobile Phone Lenovo VV38 QSG EN 110 74mm v1 0

Contents

User Manual.pdf

Read this guide carefully before using your device.
Quick Start Guide v1.0
Lenovo S660
Type: CMOS
Pixels: 6 MP (back) + 0.3 MP (front)
Height: 137 mm (5.39
inches
) Width: 68.8 mm (2.7
inches
)
Depth: 9.95 mm (0.39
inches
) Weight: 151 g
CPU: MTK 6582m 1.3 GHz Quad Core
Capacity: 6 GB ROM + 1 GB RAM
Size: 4.7 inches (diagonal) Screen: Multi-Touch display
Resolution: 960 x 540 LCD type: IPS
Model: Lenovo S660 System: Android 4.2
*Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS
Standby time: Up to 450 hours
Battery: 3000 mAh
Model and System
Actual product may differ.
*Launch with Android 4.2 which only supports BT 4.0 PXP profile.
Display
Power and Battery
CPU and Capacity
Size and Weight
Camera
Wireless Communication
Technical specifications
Back camera
On/Off button
Flashlight
Receiver Microphone
Volume key
Speaker
Earphone jackMicro USB port 5
10
Front camera2
6
3
789
4
1
10
9
43
25 3
6
7
8
1
First glance
You need to insert the SIM card provided by your carrier to use
cellular services. Install your phone as shown.
DO NOT insert or remove the SIM cards while your phone is turned on.
Doing so may permanently damage your SIM cards or your phone.
SIM2
SIM1
SIM2
SIM1
SIM2
SIM1
b
a
SIM2
SIM1
SIM1
SIM2
SIM2
SIM1
SIM1
SIM2
Step 1. Open the back cover.
Step 2. Insert the SIM cards and
the memory card.
TIP: Insert the SIM1 (USIM)
card into SIM1 slot and
SIM2 card into SIM2 slot.
Step 3. Install the battery.
Align the battery
connectors on the battery
with the pins in the
battery compartment.
Then push the battery
down into place.
Step 4. Install the back cover.
Preparing your phone
Method 1. Connect your phone to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
Your device has a rechargeable battery. For more information about
battery safety, see “Rechargeable battery notice” in the Important
Product Information Guide.
2
1
Charge the battery as shown.
Charging the battery
XXXXXXXXXX
Printed in China
First Edition (February 2014) © Copyright Lenovo 2014.
Learn more
Legal notices
Lenovo, the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be
trademarks or service marks of others.
For more information about Lenovo Mobile Phone functions，
Regulatory Notices and other useful manuals, go to
http://support.lenovo.com/.
Getting support
For support on network service and billing, please contact
your wireless network operator. For instructions on how to use
your device, go to
http://support.lenovo.com/.
