User Manual: Lenovo 65W Std Acadapter Usbc 4X20M26268 X1 Carbon 5th Gen - Kabylake (Type 20HR, 20HQ) Laptop (ThinkPad) X1 Carbon 5th Gen - Kabylake (Type 20HR, 20HQ)

Open the PDF directly: View PDF PDF.
Page Count: 4

1
Overview for Lenovo 65W Standard AC Adapter (USB Type-C) (4X20M26268)
This Lenovo 65W Standard AC Adapter (USB Type-C) Power Adapter offers fast,
efficient charging at home, in the office, or on the go. This power adapter is
compatible with ThinkPad USB-C enabled Notebook and Tablet.
Key Benefits:
Smart Voltage: Its PD technology automatically detects and delivers
5V/2A,9V/2A ,15V/3A or 20V/3.25A
Tested and reliable: tested, reliable and backed by a one year limited
warranty
TECHNICAL INFORMATION
The Lenovo 65W Standard AC Adapter (USB Type-C) for ThinkPad laptops
PERFORMANCE SPECIFICATIONS
AC
o AC type: Universal Input, Worldwide Agency Support
o AC input voltage: 100 V to 240 V; 50/60 Hz
o Input connection: Includes standard AC power cord
o Output: 20V/3.25A; 15V/3A; 9V/2A; 5V/2A
PHYSICAL SPECIFICATIONS
Approximate height: 28.5 mm (1.12 in)
Approximate width: 46 mm (1. 81in)
Approximate length: 108 mm (4.25 in)
Weight: 222 g (0.49 lb)
Package dimension:
Approximate dimension: 238 x 144 x 54 mm (9.37x5.67x2.13 in)
Weight: 460 g
OPERATING ENVIRONMENT
Temperature: 5 to 40 deg C (41 to 104 deg F)
Relative humidity: 8% to 80% non-condensing
Storage Temperature: -31 to 60 deg (C) (-40 to 140 deg (F))
2
AGENCY APPROVALS
AU/N. Zealand Safety Num.
BSMI
CB Certificate/Report
CCC (Safety & EMI)
CE
CECP
Croatia EMC Approval
C-Tick
C-UL
FCC
GOST
GS
IARM (Argentina)
ICES
KC
NEMKO
MEPS
NOM (Mexico)
PSE
PSB
Serbia
ST CoA/SIRIM
CABLE ORDERS REQUIRED: No
INSTALLATION TIME: Approximately five minutes
PACKAGING: One brown box
SHIPMENT GROUP
Lenovo 65W Standard AC Adapter (USB Type-C)
Warranty poster
AC power cord
3
CHARGES - FRU PARTS
Field Replaceable Units (FRU)
US/CAN
Power
Adapter
FRU
Line Cord
FRU
H
CRU
Option PN
Lenovo 65W Standard AC
Adapter (USB Type-C)-US,
CAN,MX
01FR025
42T5008
R
YES
4X20M26268
AP
Lenovo 65W Standard AC
Adapter (USB Type-C)-Japan
01FR025
04T0753
R
YES
4X20M26271
01FR024
42T5083
R
YES
4X20M26274
Lenovo 65W Standard AC
Adapter (USB Type-C) -HK
01FR024
42T5035
R
YES
4X20M26276
Lenovo 65W Standard AC
Adapter (USB Type-C) -
Malaysia
01FR024
42T5035
R
YES
4X20M26283
Lenovo 65W Standard AC
Adapter (USB Type-C) -
Australia/NZ/Fiji/PNG
01FR024
42T5050
R
YES
4X20M26280
Lenovo 65W Standard AC
Adapter (USB Type-C) -Korea
01FR024
42T5029
R
YES
4X20M26272
Lenovo 65W Standard AC
Adapter (USB Type-C) -China
01FR024
42T5065
R
YES
4X20M26281
Lenovo 65W Standard AC
Adapter (USB Type-C) -
TW/THA/PHI/Guam
01FR024
42T5071
R
YES
4X20M26282
Lenovo 65W Standard AC
Adapter (USB Type-C) -
Indonesia
01FR024
42T5029
R
YES
4X20M26272
Lenovo 65W Standard AC
Adapter (USB Type-C) -Sri
Lanka
01FR024
42T5035
R
YES
4X20M26276
LA
Lenovo 65W Standard AC
Adapter (USB Type-C) -
Argentina
01FR025
42T5020
R
YES
4X20M26269
Lenovo 65W Standard AC
Adapter (USB Type-C) -Brazil
01FR025
42T5180
R
YES
4X20M26270
EMEA
4
Lenovo 65W Standard AC
Adapter (USB Type-C) -EU
01FR024
42T5029
R
YES
4X20M26272
Lenovo 65W Standard AC
Adapter (USB Type-C) -Saudi
Arabia
01FR024
42T5035
R
YES
4X20M26276
Lenovo 65W Standard AC
Adapter (USB Type-C) -
Denmark
01FR024
42T5041
R
YES
4X20M26273
Lenovo 65W Standard AC
Adapter (USB Type-C) -South
Africa
01FR024
42T5056
R
YES
4X20M26275
Lenovo 65W Standard AC
Adapter (USB Type-C) -UK
01FR024
42T5035
R
YES
4X20M26276
Lenovo 65W Standard AC
Adapter (USB Type-C) -
Switzerland
01FR024
42T5044
R
YES
4X20M26277
Lenovo 65W Standard AC
Adapter (USB Type-C) -Italy
01FR024
42T5047
R
YES
4X20M26278
Lenovo 65W Standard AC
Adapter (USB Type-C) -Israel
01FR024
42T5062
R
YES
4X20M26279
