Lenovo A1000LF Tablet PC IdeaTab A1000L-F User Manual User Guide

Lenovo (Shanghai) Electronics Technology Co., Ltd Tablet PC IdeaTab A1000L-F User Guide

Contents

User Guide

IdeaTab A1000L-F
HQ60110715000
Learn more
For more information about IdeaTab functions and useful
manuals, go to http://support.lenovo.com/. To read this manual
on your IdeaTab, please access “User Guide” from the Browser
favorites in your IdeaTab.
Getting support
For support on network service and billing, please contact your
wireless network operator. For instructions on how to use your
IdeaTab, go to http://support.lenovo.com/.
Legal notices
Lenovo, the Lenovo logo, and IdeaTab are trademarks of
Lenovo in the United States, other countries, or both.
Other company, product, or service names may be trademarks
or service marks of others.
First Edition (July 2013)
© Copyright Lenovo 2013.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or
software is delivered pursuant a General Services Administra-
tion “GSA” contract, use, reproduction, or disclosure is subject
to restrictions set forth in Contract No. GS-35F-05925.
Printed in China
Radio and Telecommunications Terminal Equipment Directive
This product is in compliance with the essential requirements
and other relevant provisions of the Radio and Telecommuni-
cations Terminal Equipment Directive, 1999/5/EC.
European Union conformity
Screen lock/unlock
In standby mode, press the Power button to lock your IdeaTab.
To unlock the screen, press the Power button, and then drag the on-screen
slider to enter the interface displayed before it locks.
Sleep/Wake
If you do not touch the screen for a while, IdeaTab dims its screen to enter
sleep mode for power saving.
You can charge your IdeaTab whether it is on or off.
When the battery level falls below the threshold, IdeaTab will alert you with
a tone and the battery status icon will change into . We recommend you
plug the AC power adapter into your IdeaTab in the direction of the orange
arrow as shown above figure.
If your IdeaTab is being charged while it is on, the battery status icon
(located on the status bar of the screen) will appear as . After the battery
has finished charging, the status bar will show the fully charged icon .
For more information on battery safety, see the Important Product
Information Guide.
Turning IdeaTab off
While in standby mode, press and hold the Power button and then follow the
on-screen instructions to confirm shutdown.
Model:IdeaTab A1000L-F
*Based on actual measurements.
Version: Wi-Fi
Volume button Micro USBEarphone jack
L × W × H: 199x121x10.7mm
3500mAh
*Weight: 350g Color: Black
Android 4.1 (Jelly Bean)
7", 16:9 TN,
1,024 x 600 dpi
Micro USB
0.3 MP (front)
32 GB (max.)American National Standards
Wi-Fi
MTK 8317, dual-core, 1.0GHz
Dimensions/Weight/Color
Integrated camera Screen
Battery
CPU
3.5 mm earphone jack micro SD card slot
Operating system
Hardware
Operating system
Interface
Communication
Getting started Technical specifications Charging IdeaTab
Inserting micro SD card
Camera
There are two modes available for the camera: photo and video.
Touch > Camera. Now you can record the wonderful moments of
your life with the camera.
Touch > Gallery. Now you can view photos/videos from your IdeaTab.
Album
You can zoom in/out a photo by double-tapping or moving your two fingers
apart/together while touching the screen.
Add a bookmark
Search or type a URL
Bookmarks, history and saved pages
The above functions require your IdeaTab to connect to the Internet via
Wireless network.
Touch > Browser. Now you can browse the Web and download
applications.
Adding apps/widgets to the desktop
Tap and hold the icon of your desired application or widget, until the
desktop background pattern appears on the screen, and then place the
icon wherever you wish.
Touch > WIDGETS. You can drag your favorite applications and
widgets onto the desktop.
Tap and hold any icon on the desktop and then drag it to your preferred
location or delete it from the desktop.
You can connect IdeaTab to the PC's USB port with the cable provided for
battery charging or data transferring with the PC.
Installing apps and games
Transfer the APK setup file from the PC to IdeaTab, and then open it in the
file manager on IdeaTab. The installer will run automatically. Editing the desktop
There are three connection methods available: USB storage, Media device
(MTP) and Camera (PTP).
Keep the metal surface down for micro SD card.
Wi-Fi connection
You can connect your Ide aTab to the Internet using Wi-Fi. When Wi-Fi is on,
your IdeaTab will automatically scan for Wi-Fi hotspots within range. Select
the Wi-Fi hotspot you want to connect to.
SD Card
Reset
IdeaTab supports micro SD card extension. To insert an micro SD card, do
the following:
1. Open the micro SD card cover.
2. Insert the micro SD card as shown by the arrow.
3. Close the micro SD card cover.
Browsing the web Camera
Connecting IdeaTab to PC Customizing the desktop Communication
