Lenovo A3500FL Portable Tablet Computer User Manual

Lenovo (Shanghai) Electronics Technology Co., Ltd Portable Tablet Computer

Contents

User Manual.pdf

Lenovo TAB A7-50
Quick Start Guide v1.0
Read this guide carefully before using your tablet.
All information labeled with * in this guide refers only to
the WLAN + 3G model (Lenovo A3500-H/HV).
Height: 198 mm Width: 121.2 mm Depth: 9.9 mm
Weight: 320 g
Size: 7 inches (diagonal) Screen: Multi-touch display
Resolution: 1280 × 800 LCD type: IPS
① Actual product may differ.
② Launch with Android 4.2 which only supports BT 4.0 PXP profile.
A3500-FL does not have a rear camera.
Technical specifications
5.0 MP FF (rear) + 2.0 MP FF (front)
*Version: WLAN + 3G
②Bluetooth 4.0 WLAN 802.11 b/g/n GPS
*WCDMA, GSM
3450 mAh
Wireless
communication
Display
Battery
CPU
① Size and weight
Camera
Lenovo TAB A7-50
Model & version
Model: Lenovo A3500-FL
Version: WLAN
*Model: Lenovo A3500-HV
MTK MT8121 Quad Core 1.3 GHz
*MTK MT8382 Quad Core 1.3 GHz
(Data only)
*Model: Lenovo A3500-H
*Version: WLAN + 3G
(Voice)
Model: Lenovo A3500-F
Version: WLAN
③
③
Volume Key
*SIM card Slot
Receiver
On/Off button
Micro USB
Speaker *Rear camera
5
10
Earphone jack 2
6
3
78
Microphone
11
9
4
1
Front camera
microSD card slot
The WLAN model ( Lenovo A3500-F/FL ) does not have a SIM card slot.
A3500-FL does not have a rear camera.
First glance
5
1 2
34
6
8
9
10
11
7
Step 1. Open the SIM card & microSD card slot cover.
Step 2. Insert the SIM card into the SIM card slot and insert the
microSD card into the microSD card slot.
Step 3. Replace the SIM card & microSD card slot cover .
You can use cellular services with the WLAN + 3G model (Lenovo
A3500-H/HV) by inserting the SIM card provided by your carrier
services. Install the SIM card & microSD card as shown.
Do not insert or remove the SIM card while your tablet is turned on.
Doing so may permanently damage your SIM card or tablet.
*Installing the SIM card & microSD card
SIM
microSD
SIM
SIM
SIM
SIM
1 2 3
Method 1. Connect your tablet to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
For more information about battery safety, see the Important Product
Information Guide.
2
1
Before using your tablet, you might need to charge the battery.
Charge the battery as shown.
Charging the battery
70110781
Printed in China
Learn more
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be trademarks
or service marks of others.
First Edition (March 2014) © Copyright Lenovo 2014.
For other useful manuals, please access “User Guide” from the
Browser favorites in your tablet.
For “Regulatory Notices” , please go to
http://support.lenovo.com/.
Getting support
For support on network service and billing, please contact your
wireless network operator. For instructions on how to use your
tablet, go to
http://support.lenovo.com/.
Radio and Telecommunications Terminal Equipment Directive
This product is in compliance with the essential requirements
and other relevant provisions of the Radio and Telecommuni-
cations Terminal Equipment Directive, 1999/5/EC.
European Union conformity
