Lenovo (Shanghai) Electronics Technology Co., Ltd Portable Tablet Computer User Guide

Contents

User Guide

YOGA TABLET 8 /
YOGA TABLET 10
Quick Start Guide v1.0
Read this guide carefully before using your YOGA TABLET.
All information labeled with * in this guide refers only to the WLAN + 3G
model (Lenovo B6000-H(V) / Lenovo B8000-H ).
① Actual product may differ.
② Launch with Android 4.2 which only supports BT 4.0 PXP profile.
Technical specifications
5 MP AF (back) + 1.6 MP HD (front)
Size: 8 inches
Resolution: 1280 × 800
*Version: WLAN + 3G
②Bluetooth 4.0 WLAN 802.11 b/g/n GPS
*WCDMA, GSM
6000 mAh
Wireless
communication
Display
Battery
CPU
① Weight
Camera
YOGA TABLET 8 YOGA TABLET 10
60044; Z0AG
60043; Z0AF
Model & version
Model: Lenovo B8000-F;
Version: WLAN
60046; Z0AL
*Model: Lenovo B8000-H
Android 4.2
60047; Z0AJ
System
Approx. 401 g *404 g Approx. 605 g *610 g
MTK MT8125 Quad Core 1.2 GHz
*MTK MT8389 Quad Core 1.2 GHz
9000 mAh
Size: 10.1 inches
Resolution: 1280 × 800
*Version: WLAN + 3G
60045; Z0AH
(Data only)
( Voice)
*Model: Lenovo B6000-HV;
*Model: Lenovo B6000-H;
*Version: WLAN + 3G
(Data only)
Model: Lenovo B6000-F;
Version: WLAN
Microphone
Bracket
Front camera On/Off button
Volume key
Back camera
Earphone jack
Speakers 5
10
Micro USB
2
6
3
789
4
1
3
11
microSD card slot *Micro SIM card slot
①
213 mm
①144 mm
②
261 mm
②
180 mm 3 mm
1
2
3
4 4
5
6
78
9
10
11
②
8.1 mm
①
7.3 mm
① Actual product may differ and this dimension only refers to YOGA TABLT 8.
② Actual product may differ and this dimension only refers to YOGA TABLT 10.
* The WLAN model ( Lenovo B6000-F / Lenovo B8000-F) does not have a Micro SIM
card slot.
21 mm
First glance
Step 3. Push back the bracket.
You can use cellular services with the WLAN + 3G model ( Lenovo B6000-H(V) /
Lenovo B8000-H) by inserting the Micro SIM card provided by your carrier.
Install the Micro SIM card and the microSD card as shown.
Only Micro SIM card works with your YOGA TABLET.
!!! DO not insert or remove the Micro SIM card while your YOGA TABLET is turned
on. Doing so can permanently damage your Micro SIM card or YOGA TABLET.
microSD
Step 1. Lift the bracket.
Step 2. Insert the Micro SIM card
and microSD card.
Micro SIM
Installing the *Micro SIM card & microSD card
Connect your
YOGA TABLET
to a power outlet using the included cable and
USB power adapter.
Low battery Fully charged Charging
For more information about battery safety, see the Important Product
Information Guide.
Before using your YOGA TABLET, you might need to charge the battery.
Charge the battery as shown.
Turn on/off
Turn on: Press and hold the On/Off button until
the Lenovo logo is displayed.
Tur n of f: Press and hold the On/Off button for a
few seconds, then tap Power off .
Charging and turning on/off your YOGA TABLET
SSC9A463BX
Printed in China
Learn more
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States,
other countries, or both.
Other company, product, or service names may be trademarks or service
marks of others.
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
First Edition (September 2013)
© Copyright Lenovo 2013.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is
delivered pursuant a General Services Administration “GSA” contract, use,
reproduction, or disclosure is subject to restrictions set forth in Contract
No. GS-35F-05925.
For more information about your YOGA TABLET functions, please refer to
the “Feature Guide” app in your YOGA TABLET.
For other useful manuals, please access “User Guide” from the Browser
favorites in your YOGA TABLET.
For “Regulatory Notices” , please go to http://support.lenovo.com/.
Getting support
For support on network service and billing, please contact your wireless
network operator. For instructions on how to use your YOGA TABLET, go
to http://support.lenovo.com/.
Radio and Telecommunications Terminal Equipment Directive
This product is in compliance with the essential requirements and other
relevant provisions of the Radio and Telecommunications Terminal
Equipment Directive, 1999/5/EC.
European Union conformity
