1

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

PLANARS

03T8422 NFRU C30 Planar-TPM Enabled

03T6501 N FRU D30 Planar - TPM Enabled

03T8421 N FRU D30 Planar-TPM Enabled

03T6729 N FRU C30 Planar for Win8 STD

03T6730 N FRU C30 Planar for Win8 Pro

03T6731 N FRU D30 Planar for Win8 STD

03T6732 N FRU D30 Planar for Win8 Pro

03T6735 N FRU D30 Planar for Win7ME8.0

03T6737 N FRU C30 Planar for Win7ME8.0

OPTICAL

71Y5545 1FRU DVD Record

03T8423 1Blu-Ray DVD Burner

71Y5543 1FRU DVD-ROM Drive 16x/48x SATA

45K0487 1 FRU recordable drive

MEMORY

03T6803 1 FRU,ECC UDIMM,4G,DDR3,1866

03T6808 1 FRU,ECC UDIMM,8G,DDR3,1866

03T6809 1 FRU,ECC RDIMM,4G,DDR3,1866

03T6812 1 FRU,ECC RDIMM,8G,DDR3,1866

POWER SUPPLY

54Y8903 2CRU, 1120W 90plus W/S PSU

54Y8904 2CRU, 800W 90plus W/S PSU

HARD DISK DRIVES

03T7041 1FRU 500G SATA HDD 6Gb/s

45K0629 2FRU DT HDD 500GB

45K0641 NFru HGST Mariner2TB

45K0610 NFRU 2TB

45K0625 2FRU X HDD 2TB

03T7042 1FRU 1TB SATA HDD 6Gb/s

45K0623 2FRU X HDD 1TB

45J4899 1FRU 450GB SAS

03X3622 1FRU 3.5" SAS 15K 450G SAS 6G

03X3797 1FRU 300G SAS 6G 2.5"

03X3623 2FRU 3.5 SAS 600G

03T7039 2FRU 250G SATA HDD 6Gb/s

45K0627 2FRU DT HDD 250GB

03X3796 1FRU 146G SAS 6G 2.5"

03T6720 1 FRU 1TB 2.5" SATA

03T6721 1 FRU 250GB 10KRPM SATA 2.5"

03T8317 1 FRU 500GB 2.5" SATA

45N8175 1 mSATA 128GB Samsung

03X3621 1FRU, 3.5" SAS 15K 300G SAS 6

03X4440 1 3.5inch SATA6Gbps 4TB HDD

04X2605 2FRU DT/WS SSD 256G

04X2604 2FRU DT/WS SSD 128G

04X2601 2FRU DT/WS SSD 128G

04X2602 2FRU DT/WS SSD 256G

03T8343 1Fru Intel S3500 SATA 6G MLC

03T8623 1FRU Intel S3500 SATA 6G MLC

03T8571 2FRU 400GB Intel Ramsdale PCIe flash storage

03X3795 1Seagate Muskie+ 3.5 SATA 6G 7.2K RPM 2000G/p

03X4431 13.5inch 7200RPM SATA6G 3TB HDD

04X9108 1FRU mSATA 256GB SanDisk X110

04Y2102 1FRU mSATA SSD 128GB Toshiba HG5d-128

45K0626 13.5inch,7200RPM,SATA6G,3TB,4KB,STD,HDD,FRU for DT

45K0648 13.5inch,7200RPM,SATA6G,1TB,STD,Self-Pin,Hybird HDD,FRU for DT

45K0649 13.5inch,7200RPM,SATA6G,2TB,STD,Self-Pin,Hybird HDD,FRU for DT

04X9107 2 FRU mSATA 128GB SanDisk X110

45K0499 2 FRU-2.5" SATA 6Gb/s SSD 240G for DT

00FC108 2 FRU-2.5" SATA 6Gb/s SSD Sandisk X110 256G for DT/WS

00FC441 2 FRU-2.5" SATA 6Gb/s SSD Samsung PM851 256G eDrive for DT/WS

45K0636 2 FRU-2.5" SATA 6Gb/s SSD 180G Intel Cherryville for DT/WS

00FC100 2 FRU-2.5" SATA 6Gb/s SSD 180G for DT

00FC435 2 FRU-2.5" SATA 6Gb/s SSD Sandisk X210 512G for DT/WS

00FC109 2 FRU-2.5" SATA 6Gb/s SSD Sandisk X110 128G for DT/WS

91Y1657 1FRU 300GB 2.5" SATA

91Y1656 1FRU 150GB 2.5" SATA

91Y1658 1FRU 600GB 2.5" SATA

CPU

03T8572 NFRU Intel Xeon Phi Coprocess

00FC802 NFRU,Intel,Xeon E5-1680v2

03T6762 N FRU,Intel,Xeon E5-2687Wv2

2

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

03T6763 N FRU,Intel,Xeon E5-1660v2

03T6764 N FRU,Intel,Xeon E5-1650v2

03T6765 N FRU,Intel,Xeon E5-1620v2

03T6766 N FRU,Intel,Xeon E5-1607v2

03T7808 N FRU Xeon E5-2697v2/2.7G/12C/30M/130W CPU

03T7809 N FRU Xeon E5-2695v2/2.4G/12C/30M/115W CPU

03T7810 N FRU Xeon E5-2690v2/3.0G/10C/25M/130W CPU

03T7811 N FRU Xeon E5-2680v2/2.8G/10C/25M/115W CPU

03T7812 N FRU Xeon E5-2670v2/2.5G/10C/25M/115W CPU

03T7813 N FRU Xeon E5-2660v2/2.2G/10C/25M/95W CPU

03T7814 N FRU Xeon E5-2650Lv2/1.7G/10C/25M/70W CPU

03T7815 N FRU Xeon E5-2667v2/3.3G/8C/25M/130W CPU

03T7816 N FRU Xeon E5-2650v2/2.6G/8C/20M/95W CPU

03T7817 N FRU Xeon E5-2640v2/2.0G/8C/20M/95W CPU

03T7818 N FRU Xeon E5-2643v2/3.5G/6C/25M/130W CPU

03T7819 N FRU Xeon E5-2630v2/2.6G/6C/15M/80W CPU

03T7820 N FRU Xeon E5-2620v2/2.1G/6C/15M/80W CPU

03T7821 N FRU Xeon E5-2630Lv2/2.4G/6C/15M/60W CPU

03T7822 N FRU Xeon E5-2637v2/3.4G/4C/15M/130W CPU

03T7823 N FRU Xeon E5-2609v2/2.5G/4C/10M/80W CPU

03T7824 N FRU Xeon E5-2603v2/1.8G/4C/10M/80W CPU

03T8390 N FRU,Intel,Xeon E5-1603

ADAPTER CARD

03X3744 1FRU LSI 9260-8i 8ports SAS RAID Card(New PCB)

ADAPTERS

89Y1712 1FRU - PCIE 13

03W5425 1FRU,Adapter,SAS to SATA

03W5438 2FRU2.5to3.5AdapterBracket

03T8424 1FRU Intel 82574L Gigabit CT2

03T8162 1FRU PCI-e x1 1000M ASF NIC F

CABLES

41R5534 1FRU CABLE

03W5542 NFRU, SAS HDD Cable Asm

54Y9937 2FRU SATA CABLE

54Y9929 1FRU SATA CABLE

41R3308 NFRU eSATA Cab

90Y1611 2FRU SAS Cable

03W5424 1FRUCableLSI92608iCardLED

63Y9163 1FRU 1.5GB NVID

54Y9933 2FRU SATA CABLE

54Y8255 1FRU Cable DVI_Adapter

03W5436 2FRU,Power/LED cable

03W5423 2FRUFPIOCableCamus2Martell3

03W5465 2FRU,Cable 150W CPU Power

41R5721 1FRU ODD CBL

03W5460 2FRU, Speaker, LED, Pwr Switc

03W5458 2FRU, FPIO Cable, Remy 3

03T8313 1 FRU, SLI Cable

03X4351 NFRU Cable asm 880mm,Mini SAS

43N9146 2FRU,cable,PS2 cable_R_370mm_knockout

MECHANICALS

03W5428 2FRU, Heatsink, <= 135W

03W5429 2FRU, Heatsink, > 135W

03T8401 1FRU DP to DVI Dongle(dual li

03W5455 2FRU, Memory Chiller Asm (con

03T8404 1FRU DP to HDMI Dongle

41R5630 2FRU Miscellane

03W5454 2FRU, Miscellaneous Parts Kit

03W5426 2FRU,Heatsink,CPU 1,<= 135W

45K2268 2FRU Bezel Kit

41R5628 2FRU Bezel Kit

03W5453 2FRU, Bezel Kit, D30

03T8400 1FRU DP to DVI Dongle(Single

03W5446 1FRU,Remy

03W5445 1FRU, Camus 2 Main Bezel

41A5334 2Spkr Ext BTL

03T8366 1FRU Card Reader-longer cable

03T8427 NFRU SAS HDD Enablement Module(1-5HDDs)

03W5434 NFRU,Shell Kit,Camus 2

03W5541 2FRU, Miscellaneous Parts

03W5435 1FRUCamus2CoverAsmwithboard

41R2511 2FRU, PCI RiserCard

03W5437 2FRU,Card HolderBracketAsm

3

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

41R5673 2FRU Parts Kit

41R5614 2FRU Mech shell

03T8426 NFRU SAS HDD Enablement Module(1-3HDDs)

03X3617 1LSI 9260-8i 8 Port SAS Raid Card -B4

03T6554 1FRU LSI 9260-8i SAS/SATA RAI

03T8418 1FRU Nvidia Quadro 2000D

03T8428 NFRU SATA HDD Enablement Module(1-5HDDs)

03T8040 1FRU NVIDIA 400(DVI+DP)

03W5456 NFRU, Shell Kit, Remy 3 (D30)

03W5459 2FRU, Board I/O Shield, Remy

03W5461 2FRU, Fan, 92 mm HDD/PCI, Rem

03W5463 2FRU, (5x) HDD Carrier Asms,

03T8152 1FRU NVIDIA Quadro NVS300(DMS

03T8402 1FRU DMS59 to Dual DVI(single

03T7030 1FRU PCI-E USB 3.0 Card FH

03T8403 1FRU DMS59 to Dual DP Dongle

03T8314 2 FRU,29-in-1 CardReader,3.5"

03T8316 1 FRU, Nvidia Quadro K2000D (D

03T8318 2 FRU, mini Display Port to HD

03T8319 2 FRU, mini Display Port to Di

03T8320 2 FRU, mini Display Port to DV

03T6725 1 FRU NVIDIA Quadro NVS300(DMS

03T8254 1 FRU NV Quadro410(DVI+DP)HP

03T8255 1 FRU NVIDIA NVS310 (DP+DP)HP

03T8322 1 FRU PCI-Ex1 USB 3.0 Card

03X3604 1LSI 9220-8i SAS RAID 5 Key

03T6739 1 LSI 9240-8i 8ports w/o R5 SA

03T8328 1 FRU Nvidia Quadro 600 HP UEFI

03W5467 2 FRU,NV Stereo 3D Bracket

03W5430 2 FRUFrontFanandBracketAsm120

03T6745 1 FRU NVIDIA NVS310 (DP+DP)HP

03T6747 1 FRU NVIDIA Quadro 410(DVI+DP

03T8808 2 FRU, Shell Kit, Remy 3 (D30)

03W5448 2 FRU,Shell Kit,Camus 2

03T8824 1 FRU AMD FirePro V4900 (DVI,

03T8823 1 FRU AMD FirePro V3900 (DVI,

03T8822 1 FRU AMD FirePro 2460 Multi-V

03T8821 1 FRU AMD FirePro 2270 (DMS-59

03T8760 1 FRU Intel EthernetI350-T4

03T6752 1 FRU,NVS315 ATX-1GB GDDR3

03T8826 N FRU AMD FirePro W7000 (DP x

03T8825 N FRU AMD FirePro W5000 (DVI,

03T6767 N FRU Teradici 2240 accessory kit

03T6768 N FRU Teradici 2220 accessory kit

03T8817 2 FRU,Nvidia Quadro K6000 (Dual link DVI x 2, DP, DP) - 12GB GDDR5

03W5464 1 FRU,Label,Remy 3/Holmes

03W5439 1 FRU, Label, Service

KEYBOARD & MOUSE

45J4889 1FRU Optical Wheel Mouse USB

RECOVERY MEDIA

03T6427 1FRU Adobe Acrobat X Standard

03W0123 1FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 CS

03W0124 1FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 FR

03W0125 1FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 GR

03W0126 1FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 IT/EN

03W0127 1FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 JP/EN

03W0128 1FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 SP

03W0129 1FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 US

03W0130 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 AR/EN

03W0131 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 BR

03W0132 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 CS

03W0133 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 CT/EN

03W0134 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 CZ/EN

03W0135 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 FR

03W0136 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 GK/EN

03W0137 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 GR

03W0138 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 HB/EN

03W0139 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 HK/EN

03W0140 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 HU/EN

03W0141 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 IT/EN

03W0142 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 JP/EN

03W0143 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 KR/EN

03W0144 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 PL

4

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

03W0145 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 PO/EN

03W0146 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 RO/EN

03W0147 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 RU

03W0148 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 SK/EN

03W0149 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 SP

03W0150 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 SR/EN

03W0151 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 TR/EN

03W0152 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 US

03W0153 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 C&L EMEA

03W0154 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 C&L Nordics

03W0155 1FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 C&L SL/CR/EN

00HC183 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 TR/EN

00HC179 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 RU

00HC164 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 BR

00HC185 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 C&L EMEA

00HC168 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 FR

00HC170 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 GR

00HC186 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 C&L Nordics

00HC167 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 CZ/EN

00HC172 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 HK/EN

00HC173 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 HU/EN

00HC169 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 GK/EN

00HC171 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 HB/EN

00HC177 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 PO/EN

00HC176 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 PL

00HC174 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 JP/EN

00HC175 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 KR/EN

00HC180 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 SK/EN

00HC178 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 RO/EN

00HC182 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 SR/EN

00HC166 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 CT/EN

00HC181 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 SP

00HC187 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 C&L SL/CR/EN

00HC184 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 US

00HC163 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 AR/EN

00HC423 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 RO/EN

00HC428 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 TR/EN

00HC413 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 FR

00HC418 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 HU/EN

00HC425 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 SK/EN

00HC414 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 GK/EN

00HC411 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 CT/EN

00HC420 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 KR/EN

00HC424 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 RU

00HC416 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 HB/EN

00HC426 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 SP

00HC430 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 C&L EMEA

00HC432 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 C&L SL/CR/EN

00HC419 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 JP/EN

00HC408 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 AR/EN

00HC421 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 PL

00HC427 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 SR/EN

00HC417 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 HK/EN

00HC422 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 PO/EN

00HC415 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 GR

00HC429 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 US

00HC409 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 BR

00HC412 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 CZ/EN

00HC431 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 C&L Nordics

00HC390 1 FAP Foreman-Holmes-Ali DVD Win8x64 PL

00HC278 1 FAP Foreman-Holmes-Ali DVD Win7HPx64 SP1 FR

00HC237 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 SR/EN

00HC402 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 PO/EN

00HC277 1 FAP Foreman-Holmes-Ali DVD Win7HPx64 SP1 CS

00HC283 1 FAP Foreman-Holmes-Ali DVD Win7HPx64 SP1 SP

00HC235 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 SK/EN

00HC282 1 FAP Foreman-Holmes-Ali DVD Win7HPx64 SP1 KR/EN

00HC393 1 FAP Foreman-Holmes-Ali DVD Win8x64 SK/EN

00HC279 1 FAP Foreman-Holmes-Ali DVD Win7HPx64 SP1 GR

00HC236 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 SP

00HC280 1 FAP Foreman-Holmes-Ali DVD Win7HPx64 SP1 IT/EN

00HC392 1 FAP Foreman-Holmes-Ali DVD Win8x64 RO/EN

00HC281 1 FAP Foreman-Holmes-Ali DVD Win7HPx64 SP1 JP/EN

5

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

00HC284 1 FAP Foreman-Holmes-Ali DVD Win7HPx64 SP1 US

00HC394 1 FAP Foreman-Holmes-Ali DVD Win8x64 SP

00HC380 1 FAP Foreman-Holmes-Ali DVD Win8x64 CT/EN

00HC244 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 FR

00HC247 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 JP/EN

00HC217 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 AR/EN

00HC239 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 US

00HC204 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 HK/EN

00HC199 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 CZ/EN

00HC231 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 JP/EN

00HC198 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 CT/EN

00HC256 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 SP

00HC200 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 FR

00HC246 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 IT/EN

00HC398 1 FAP Foreman-Holmes-Ali DVD Win8x64 C&L SL/CR/EN

00HC251 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 AR/EN

00HC395 1 FAP Foreman-Holmes-Ali DVD Win8x64 US

00HC404 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 SP

00HC203 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 HB/EN

00HC205 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 HU/EN

00HC202 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 GR

00HC222 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 CZ/EN

00HC201 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 GK/EN

00HC207 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 KR/EN

00HC218 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 BR

00HC255 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 RU

00HC206 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 JP/EN

00HC259 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 US

00HC209 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 PO/EN

00HC211 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 SK/EN

00HC208 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 PL

00HC212 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 SP

00HC210 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 RO/EN

00HC215 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 C&L Nordics

00HC216 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 C&L SL/CR/EN

00HC214 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 C&L EMEA

00HC188 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 AR/EN

00HC213 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 US

00HC162 1 FAP Foreman-Holmes-Ali DVD Win8.1CNx64 CS

00HC190 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 FR

00HC189 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 BR

00HC193 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 SP

00HC165 1 FAP Foreman-Holmes-Ali DVD Win8.1PROx64 CS

00HC195 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 TR/EN

00HC191 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 PO/EN

00HC192 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 RU

00HC194 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 SR/EN

00HC196 1 FAP Foreman-Holmes-Ali DVD Win8.1SLx64 US

00HC228 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 HK/EN

00HC219 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 CS

00HC220 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 CT/EN

00HC221 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 FR

00HC225 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 HB/EN

00HC224 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 GR

00HC223 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 GK/EN

00HC226 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 HU/EN

00HC233 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 RO/EN

00HC232 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 PO/EN

00HC234 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 RU

00HC229 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 KR/EN

00HC238 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 TR/EN

00HC230 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 PL

00HC240 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 C&L EMEA

00HC241 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 C&L Nordics

00HC242 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 C&L SL/CR/EN

00HC197 1 FAP Foreman-Holmes-Ali DVD Win8.1x64 CS

00HC243 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 CS

00HC245 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 GR

00HC248 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 SP

00HC289 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 CT/EN

00HC290 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 HK/EN

00HC249 1 FAP Foreman-Holmes-Ali DVD Win7PROx32 SP1 US

00HC396 1 FAP Foreman-Holmes-Ali DVD Win8x64 C&L EMEA

6

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

00HC258 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 TR/EN

00HC254 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 PO/EN

00HC252 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 BR

00HC253 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 FR

00HC260 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 AR/EN

00HC257 1 FAP Foreman-Holmes-Ali DVD Win7HBx32 SP1 SR/EN

00HC266 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 SR/EN

00HC265 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 SP

00HC268 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 US

00HC267 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 TR/EN

00HC261 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 BR

00HC403 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 RU

00HC406 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 TR/EN

00HC262 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 FR

00HC263 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 PO/EN

00HC271 1 FAP Foreman-Holmes-Ali DVD Win7HPx32 SP1 GR

00HC264 1 FAP Foreman-Holmes-Ali DVD Win7HBx64 SP1 RU

00HC407 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 US

00HC270 1 FAP Foreman-Holmes-Ali DVD Win7HPx32 SP1 FR

00HC276 1 FAP Foreman-Holmes-Ali DVD Win7HPx32 SP1 US

00HC275 1 FAP Foreman-Holmes-Ali DVD Win7HPx32 SP1 SP

00HC274 1 FAP Foreman-Holmes-Ali DVD Win7HPx32 SP1 KR/EN

00HC273 1 FAP Foreman-Holmes-Ali DVD Win7HPx32 SP1 JP/EN

00HC269 1 FAP Foreman-Holmes-Ali DVD Win7HPx32 SP1 CS

00HC272 1 FAP Foreman-Holmes-Ali DVD Win7HPx32 SP1 IT/EN

00HC410 1 FAP Foreman-Holmes-Ali DVD Win8PROx64 CS

00HC433 1 FAP Foreman-Holmes-Ali DVD Win8CNx64 CS

00HC227 1 FAP Foreman-Holmes-Ali DVD Win7PROx64 SP1 IT/EN

00HC384 1 FAP Foreman-Holmes-Ali DVD Win8x64 GR

00HC385 1 FAP Foreman-Holmes-Ali DVD Win8x64 HB/EN

00HC397 1 FAP Foreman-Holmes-Ali DVD Win8x64 C&L Nordics

00HC387 1 FAP Foreman-Holmes-Ali DVD Win8x64 HU/EN

00HC399 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 AR/EN

00HC405 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 SR/EN

00HC382 1 FAP Foreman-Holmes-Ali DVD Win8x64 FR

00HC388 1 FAP Foreman-Holmes-Ali DVD Win8x64 JP/EN

00HC383 1 FAP Foreman-Holmes-Ali DVD Win8x64 GK/EN

00HC386 1 FAP Foreman-Holmes-Ali DVD Win8x64 HK/EN

00HC381 1 FAP Foreman-Holmes-Ali DVD Win8x64 CZ/EN

00HC389 1 FAP Foreman-Holmes-Ali DVD Win8x64 KR/EN

00HC400 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 BR

00HC391 1 FAP Foreman-Holmes-Ali DVD Win8x64 PO/EN

00HC401 1 FAP Foreman-Holmes-Ali DVD Win8SLx64 FR

KEYBOARD

41A5318 1Russian/Cyr441

41A5329 1Slovenian 234

41A5290 1Arabic 253

41A5300 1French 189

41A5325 1Turkish 440

41A5319 1Serbian/Cyr118

41A5291 1Arabic/Fren462

45J4880 1Arabic 470

41A5292 1Belgium/Fr 120

41A5309 1Italian 141

41A5303 1German 129

41A5321 1Spanish 172

41A5320 1Slovakian 245

54Y8381 1Preferred Pro USB Keyboard

41A5326 1Turkish 179

41A5295 1Bulgarian 442

41A5293 1Belgium/UK 120

41A5327 1UK English 166

41A5328 1US Euro 103P

45J4896 1Lithuanian 494

41A5297 1Czech(QWRT)489

41A5289 1US English103P

41A5312 1LA Spanish 171

41A5304 1Greek 319

41A5307 1Hungarian 208

41A5305 1GREEK/US 359

41A5294 1Brazil/Port275

41A5306 1Hebrew 212

51J0059 1Estonia454 105

7

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

41A5322 1Swedish/Fin153

41A5308 1Iceland 197

41A5324 1Thailand 191

41A5313 1Norwegian 155

41A5296 1Chinese/US 467

41A5317 1Romanian 096

41A5314 1Polish 214

41A5315 1Portuguese 163

41A5298 1Danish 159

41A5311 1Korean 413

41A5310 1Japanese 194

41A5323 1Swiss, F/G 150

41A5299 1Dutch 143

54Y8380 1 Lenovo Slim New F5 USB Keyboard

54Y9293 1 Slim New F5 USB US103P

54Y9294 1 Slim New F5 USB Arabic 253

54Y9295 1 Slim New F5 USB Arabic/French462

54Y9296 1 Slim New F5 USB Belgium/French 120

54Y9297 1 Slim New F5 USB Belgium/UK 120

54Y9298 1 Slim New F5 USB Brazil/Portuguese275

54Y9299 1 Slim New F5 USB Bulgarian 442

54Y9300 1 Slim New F5 USB Traditional Chinese467

54Y9301 1 Slim New F5 USB Czech (QWERTY or ABB)489

54Y9302 1 Slim New F5 USB Danish 159

54Y9303 1 Slim New F5 USB Dutch 143

54Y9304 1 Slim New F5 USB French 189

54Y9305 1 Slim New F5 USB French Canadian 445

54Y9306 1 Slim New F5 USB French Canadian(Bilingual)58

54Y9307 1 Slim New F5 USB German 129

54Y9308 1 Slim New F5 USB Greek 319

54Y9309 1 Slim New F5 USB Greek/US459

54Y9310 1 Slim New F5 USB Hebrew 212

54Y9311 1 Slim New F5 USB Hungarian 208

54Y9312 1 Slim New F5 USB Iceland 197

54Y9313 1 Slim New F5 USB Italy 141

54Y9314 1 Slim New F5 USB Japanese194

54Y9315 1 Slim New F5 USB Korean413

54Y9316 1 Slim New F5 USB LA Spanish 171

54Y9317 1 Slim New F5 USB Norwegian 155

54Y9318 1 Slim New F5 USB Polish 214

54Y9319 1 Slim New F5 USB Portugese 163

54Y9320 1 Slim New F5 USB Romanian96

54Y9321 1 Slim New F5 USB Russian/Cy441

54Y9322 1 Slim New F5 USB Serbian/Cyrilic 118

54Y9323 1 Slim New F5 USB Slovak245

54Y9324 1 Slim New F5 USB Spanish 172

54Y9325 1 Slim New F5 USB Swedish/Finn 153

54Y9326 1 Slim New F5 USB Swiss, F/G 150

54Y9327 1 Slim New F5 USB Thailand 191

54Y9328 1 Slim New F5 USB Turkish (TF)440

54Y9329 1 Slim New F5 USB Turkish (TQ)179

54Y9330 1 Slim New F5 USB UK English 166

54Y9331 1 Slim New F5 USB US Euro103P

54Y9332 1 Slim New F5 USB Slovenian234

54Y9333 1 Slim New F5 USB Arabic(New)470

54Y9334 1 Slim New F5 USB Lithuanian494

54Y9335 1 Slim New F5 USB ESTONIAN454

54Y9336 1 Slim New F5 USB Nordic

54Y9400 1 NetVista Keyboard (USB) US English

54Y9401 1 NetVista Keyboard (USB) Arabic 253

54Y9402 1 NetVista Keyboard (USB) Arabic/French 462

54Y9403 1 NetVista Keyboard (USB) Belgium French 120

54Y9404 1 NetVista Keyboard (USB)Belgium English 120

54Y9405 1 NetVista Keyboard (USB) Brazilian Portuguese 275

54Y9406 1 NetVista Keyboard (USB) Bulgarian 442

54Y9407 1 NetVista Keyboard (USB) Chinese/US 467

54Y9408 1 NetVista Keyboard (USB) Czech (ABB) 489

54Y9409 1 NetVista Keyboard (USB) Danish 159

54Y9410 1 NetVista Keyboard (USB)Dutch 143

54Y9411 1 NetVista Keyboard (USB) French

54Y9412 1 NetVista Keyboard (USB)French Canadian 445

54Y9413 1 NetVista Keyboard (USB) French Canadian 058

54Y9414 1 NetVista Keyboard (USB) German 129

8

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

54Y9415 1 NetVista Keyboard (USB) Greek

54Y9416 1 NetVista Keyboard (USB) Greek/US 459

54Y9417 1 NetVista Keyboard (USB) Hebrew 212

54Y9418 1 NetVista Keyboard (USB)Hungarian 208

54Y9419 1 NetVista Keyboard (USB) Iceland

54Y9420 1 NetVista Keyboard (USB) Italy 141

54Y9422 1 NetVista Keyboard (USB) Japanese 194

54Y9423 1 NetVista Keyboard (USB) Korean 413

54Y9424 1 NetVista Keyboard (USB)LA Spanish 171

54Y9425 1 NetVista Keyboard (USB) Norwegian

54Y9426 1 NetVista Keyboard (USB) Polish 214

54Y9427 1 NetVista Keyboard (USB) Portugese 163

54Y9428 1 NetVista Keyboard (USB) Romanian 096

54Y9429 1 NetVista Keyboard (USB) Russian/Cyrillic 441

54Y9430 1 NetVista Keyboard (USB) Serbian/Cyrillic 118

54Y9431 1 NetVista Keyboard (USB) Slovak 245

54Y9432 1 NetVista Keyboard (USB) Spanish

54Y9433 1 NetVista Keyboard (USB) Swedish/Finnish 153

54Y9434 1 NetVista Keyboard (USB) French/German 150

54Y9435 1 NetVista Keyboard (USB) Thailand 191

54Y9436 1 NetVista Keyboard (USB) Turkish 440

54Y9437 1 NetVista Keyboard (USB) Turkish 179

54Y9438 1 NetVista Keyboard (USB) UK English 166

54Y9439 1 NetVista Keyboard (USB) US Euro103P

54Y9440 1 NetVista Keyboard (USB) Slovenian 234

54Y9441 1 NetVista Keyboard (USB) Arabic(New) 470

54Y9442 1 NetVista Keyboard (USB)Lithuanian 494

54Y9443 1 NetVista Keyboard (USB) India

54Y9444 1 NetVista Keyboard (USB) India(Marathi and Hindi)

54Y9445 1 NetVista Keyboard (USB) Estonia 454

54Y9446 1 NetVista Keyboard (USB) Nordic

54Y9489 1 Edge KB New F5 USB US English 103P

54Y9490 1 Edge KB New F5 USB USB Arabic 253

54Y9491 1 Edge KB New F5 USB Arabic/French 462

54Y9492 1 Edge KB New F5 USB Belgium French

54Y9493 1 Edge KB New F5 USB Belgium English 120

54Y9494 1 Edge KB New F5 USB Brazilian Portuguese 275

54Y9495 1 Edge KB New F5 USB Bulgarian

54Y9496 1 Edge KB New F5 USB Chinese/US 467

54Y9497 1 Edge KB New F5 USB Czech

54Y9498 1 Edge KB New F5 USB Danish 159

54Y9499 1 Edge KB New F5 USB Dutch 143

54Y9500 1 Edge KB New F5 USB French 189

54Y9501 1 Edge KB New F5 USB French Canadian 445

54Y9502 1 Edge KB New F5 USB French Canadian 058

54Y9503 1 Edge KB New F5 USB German 129

54Y9504 1 Edge KB New F5 USB Greek 319

54Y9505 1 Edge KB New F5 USB Greek/US 459

54Y9506 1 Edge KB New F5 USB Hebrew 212

54Y9507 1 Edge KB New F5 USB Hungarian 208

54Y9508 1 Edge KB New F5 USB Iceland 197

54Y9509 1 Edge KB New F5 USB Italy 141

54Y9511 1 Edge KB New F5 USB Japanese 194

54Y9512 1 Edge KB New F5 USB Korean 413

54Y9513 1 Edge KB New F5 USB LA Spanish 171

54Y9514 1 Edge KB New F5 USB Norwegian 155

54Y9515 1 Edge KB New F5 USB Polish 214

54Y9516 1 Edge KB New F5 USB Portugese 163

54Y9517 1 Edge KB New F5 USB Romanian 096

54Y9518 1 Edge KB New F5 USB Russian/Cyrillic 441

54Y9519 1 Edge KB New F5 USB Serbian/Cyrillic 118

54Y9520 1 Edge KB New F5 USB Slovak 245

54Y9521 1 Edge KB New F5 USB Spanish 172

54Y9522 1 Edge KB New F5 USB Swedish/Finnish 153

54Y9523 1 Edge KB New F5 USB Swiss French/German 150

54Y9524 1 Edge KB New F5 USB Thailand 191

54Y9525 1 Edge KB New F5 USB Turkish 440

54Y9526 1 Edge KB New F5 USB Turkish 179

54Y9527 1 Edge KB New F5 USB UK English 166

54Y9528 1 Edge KB New F5 USB US Euro103P

54Y9529 1 Edge KB New F5 USB Slovenian

54Y9530 1 Edge KB New F5 USB Arabic(New) 470

54Y9531 1 Edge KB New F5 USB Lithuanian 494

9

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

54Y9532 1 Edge KB New F5 USB India

54Y9534 1 Edge KB New F5 USB Estonia 454

54Y9535 1 Edge KB New F5 USB Nordic

54Y9536 1 Fingerprint(EPEAT GOLD) KB US English 103P

54Y9537 1 Fingerprint(EPEAT GOLD) KB Arabic 253

54Y9538 1 Fingerprint(EPEAT GOLD) KB Arabic/French 462

54Y9539 1 Fingerprint(EPEAT GOLD) KB Belgium French 120

54Y9540 1 Fingerprint(EPEAT GOLD) KB Belgium English 120

54Y9541 1 Fingerprint(EPEAT GOLD) KB Brazilian Portuguese 275

54Y9542 1 Fingerprint(EPEAT GOLD) KB Bulgarian 442

54Y9543 1 Fingerprint(EPEAT GOLD) KB Chinese/US 467

54Y9544 1 Fingerprint(EPEAT GOLD) KB Czech

54Y9545 1 Fingerprint(EPEAT GOLD) KB Danish 159

54Y9546 1 Fingerprint(EPEAT GOLD) KB Dutch 143

54Y9547 1 Fingerprint(EPEAT GOLD) KB French 189

54Y9548 1 Fingerprint(EPEAT GOLD) KB French Canadian 445

54Y9549 1 Fingerprint(EPEAT GOLD) KB French Canadian 058

54Y9550 1 Fingerprint(EPEAT GOLD) KB German 129

54Y9551 1 Fingerprint(EPEAT GOLD) KB Greek 319

54Y9552 1 Fingerprint(EPEAT GOLD) KB Greek/US 459

54Y9553 1 Fingerprint(EPEAT GOLD) KB Hebrew 212

54Y9554 1 Fingerprint(EPEAT GOLD) KB Hungarian 208

54Y9555 1 Fingerprint(EPEAT GOLD) KB Iceland 197

54Y9556 1 Fingerprint(EPEAT GOLD) KB Italy 141

54Y9558 1 Fingerprint(EPEAT GOLD) KB Japanese 194

54Y9559 1 Fingerprint(EPEAT GOLD) KB Korean 413

54Y9560 1 Fingerprint(EPEAT GOLD) KB LA Spanish 171

54Y9561 1 Fingerprint(EPEAT GOLD) KB Norwegian 155

54Y9562 1 Fingerprint(EPEAT GOLD) KB Polish 214

54Y9563 1 Fingerprint(EPEAT GOLD) KB Portugese 163

54Y9564 1 Fingerprint(EPEAT GOLD) KB Romanian 096

54Y9565 1 Fingerprint(EPEAT GOLD) KB Russian/Cyrillic 441

54Y9566 1 Fingerprint(EPEAT GOLD) KB Serbian/Cyrillic 118

54Y9567 1 Fingerprint(EPEAT GOLD) KB Slovak 245

54Y9568 1 Fingerprint(EPEAT GOLD) KB Spanish 172

54Y9569 1 Fingerprint(EPEAT GOLD) KB Swedish/Finnish 153

54Y9570 1 Fingerprint(EPEAT GOLD) KB French/German 150

54Y9571 1 Fingerprint(EPEAT GOLD) KB Thailand 191

54Y9572 1 Fingerprint(EPEAT GOLD) KB Turkish 440

54Y9573 1 Fingerprint(EPEAT GOLD) KB Turkish 179

54Y9574 1 Fingerprint(EPEAT GOLD) KB UK English 166

54Y9575 1 Fingerprint(EPEAT GOLD) KB US Euro103P

54Y9576 1 Fingerprint(EPEAT GOLD) KB Slovenian 234

41A5039 1 US ENG 103P

41A5040 1 Arabic 253

41A5041 1 Arabic/Fre 462

41A5042 1 Bel/Fren 120

41A5043 1 Bel/UK 120

41A5044 1 Brazil/Port275

41A5045 1 Bulgarian 442

41A5046 1 CHN/US 467

41A5047 1 Czech(ABB)243

41A5048 1 Danish 159

41A5049 1 Dutch 143

41A5050 1 French 189

41A5051 1 Fren Cana445

41A5052 1 Fren Can 58

41A5053 1 German129

41A5054 1 Greek 319

41A5055 1 Hebrew 212

41A5056 1 Hungarian 208

41A5057 1 Iceland 197

41A5058 1 Italian 142

41A5059 1 JPN 194

41A5060 1 Korean 413

41A5061 1 LA Spanish 171

41A5062 1 Norwegian 155

41A5063 1 Polish 214

41A5064 1 Portugese 163

41A5065 1 Romanian 096

41A5066 1 Russian/Cyr441

41A5067 1 Serbian/Cyr118

41A5068 1 Slovak 153

10

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

41A5069 1 Spanish 172

41A5070 1 Swd/Finn 153

41A5071 1 Swiss, F/G 150

41A5072 1 Thailand 191

41A5073 1 Turkish 440

41A5074 1 Turkish 179

41A5075 1 UK ENG 166

41A5076 1 US Euro 103P

41A5077 1 Slovenian+++

41A5080 1 Greek/US

54Y8382 1 Preferred Pro PS2 Keyboard Indian

54Y9447 1 NetVista Keyboard (PS2) US English

54Y9448 1 NetVista Keyboard (PS2) NetVista PS/2 Arabic 253

54Y9449 1 NetVista Keyboard (PS2) NetVista PS/2 Arabic/French 462

54Y9450 1 NetVista Keyboard (PS2) NetVista PS/2 Belgium French 120

54Y9451 1 NetVista Keyboard (PS2) NetVista PS/2 Belgium English 120

54Y9452 1 NetVista Keyboard (PS2)Brazilian Portuguese 275

54Y9453 1 NetVista Keyboard (PS2) NetVista PS/2 Bulgarian 442

54Y9454 1 NetVista Keyboard (PS2) Chinese/US 467

54Y9455 1 NetVista Keyboard (PS2) NetVista PS/2 Czech (ABB) 489

54Y9456 1 NetVista Keyboard (PS2) NetVista PS/2 Danish 159

54Y9457 1 NetVista Keyboard (PS2) NetVista PS/2 Dutch 143

54Y9458 1 NetVista Keyboard (PS2) French 189

54Y9459 1 NetVista Keyboard (PS2) French

54Y9460 1 NetVista Keyboard (PS2) French Canadian 058

54Y9461 1 NetVista Keyboard (PS2) German

54Y9462 1 NetVista Keyboard (PS2) Greek

54Y9463 1 NetVista Keyboard (PS2) Greek Us

54Y9464 1 NetVista Keyboard (PS2) NetVista PS/2 Hebrew 212

54Y9465 1 NetVista Keyboard (PS2) Hungaria

54Y9466 1 NetVista Keyboard (PS2) Icelandic

54Y9467 1 NetVista Keyboard (PS2) Italy

54Y9469 1 NetVista Keyboard (PS2) Japanese 194

54Y9470 1 NetVista Keyboard (PS2) Korean 413

54Y9471 1 NetVista Keyboard (PS2) LA Spanish 171

54Y9472 1 NetVista Keyboard (PS2) Norwegian

54Y9473 1 NetVista Keyboard (PS2) Polish

54Y9474 1 NetVista Keyboard (PS2) Portugese

54Y9475 1 NetVista Keyboard (PS2) Romanian

54Y9476 1 NetVista Keyboard (PS2) Russian

54Y9477 1 NetVista Keyboard (PS2) NetVista PS/2 Serbian/Cyrillic 118

54Y9478 1 NetVista Keyboard (PS2) NetVista PS/2 Slovak 245

54Y9479 1 NetVista Keyboard (PS2) NetVista PS/2 Spanish 172

54Y9480 1 NetVista Keyboard (PS2) NetVista PS/2 Swedish/Finnish 153

54Y9481 1 NetVista Keyboard (PS2) NetVista PS/2 Swiss French/German 150

54Y9482 1 NetVista Keyboard (PS2) Thailand 191

54Y9483 1 NetVista Keyboard (PS2) NetVista PS/2 Turkish 440

54Y9484 1 NetVista Keyboard (PS2) NetVista PS/2 Turkish 179

54Y9485 1 NetVista Keyboard (PS2) NetVista PS/2 UK English 166

54Y9486 1 NetVista Keyboard (PS2) NetVista PS/2 US Euro103P

54Y9487 1 NetVista Keyboard (PS2) NetVista PS/2 Slovenian 234

54Y9488 1 NetVista Keyboard (PS2) India

LINE CORDS

41R3232 11.8m Powercord

41R3212 11.8m Powercord

41R3208 11.8m Powercord

41R3196 11.8m Powercord

41R3236 11.8m Powercord

41R3228 11.8m Powercord

41R3176 11.8mIRAM Cable

41R3175 1Fig.68--1.8m

43N9029 1TIS 250V C13

45J9503 1Power Cord 1.8

41R3260 11.8m Powercord

41R3224 11.8m Powercord

41R3256 11.8m Powercord

41R3220 11.8m Powercord

45J9502 1Power Cord 1.8

45J9595 11.8m linecord

43N9057 1Cable Group

24R2632 13/2 Con. Plug

41R3252 11.8m Powercord

24R2633 1Power Cord 1.8M - Japan

11

ThinkStation C30 Service Parts Listing

MT: 1095, 1096, 1097

FRU P/N CRU ID Description

GRAPHICS CARD

89Y8629 1FRU Nvidia6000

89Y8856 1FRU Nvidia2000

03T8365 1FRU Nvidia Tesla C2075

03T8009 1FRU Nvidia Q600(DVI+DP)

89Y8628 1FRU Nvidia5000

89Y8627 1FRU Nvidia4000

64Y9895 1Nvidia Quadro

03T8425 1FRU SoundBlaster

03T8308 1 FRU, NVIDIA NVS510(mini DPx4

03T8309 1 FRU, Nvidia Quadro 610 (Dual

03T8310 1 FRU, Nvidia Quadro 2100 (Dua

03T8311 1 FRU, Nvidia Quadro 5100 (Dua

03T8312 1 FRU, NVIDIA Quadro 4100 (Dua

03X3640 1Intel® 1Gbps Gigabit ET Dual Port Server Adapter

03T8818 1 FRU,NV Tesla K20-5GB GDDR5

03T8819 1 FRU,Teradici 2240 remote WS card

03T8820 1 FRU,Teradici 2220 remote WS card

MODULE

03T8396 1FRU 2GB 1600MHz 1Rx8 ECC RD

03T8431 1FRU 4GB UDIMM 10600E DDR3

03T8397 1FRU 4GB 1600MHz 2Rx8 ECC RDI

03T8398 1FRU 8GB 1600MHz 2Rx4 ECC RDI

03T8399 1FRU 16GB 1600MHz 2Rx4 ECC RD

03T8433 1FRU 2GB RDIMM 10600R DDR3

03T8434 1FRU 4GB RDIMM 10600R DDR3

03T8435 1FRU 8GB RDIMM 10600R DDR3

03T8430 1FRU 2GB UDIMM 10600E DDR3

03T8371 NFRU Intel Xeon E5-2680 130W

03T8429 1FRU 8GB DDR3 ECC UDIMM

03T8374 NFRU Intel Xeon E5-2660 95W

03T8377 NFRU Intel Xeon E5-2640 95W

03T8375 NFRU Intel Xeon E5-2650 95W

03T8436 1FRU 16GB RDIMM 10600R DDR3

03T8379 NFRU Intel Xeon E5-2620 95W

03T8381 NFRU Intel Xeon E5-2609 80W

03T8378 NFRU Intel Xeon E5-2630 95W

03T8380 NFRU Intel Xeon E5-2643 130W

03T8382 NFRU Intel Xeon E5-2603 80W

03T8370 NFRU Intel Xeon E5-2687W 150W

03T8383 NFRU Intel Xeon E5-2637 80W

03T8384 NFRU Intel Xeon E5-2650L 70W

03T8372 NFRU Intel Xeon E5-2670 115W

03T8385 NFRU Intel Xeon E5-2630L 60W

03T8369 NFRU Intel Xeon E5-2690 135W

03T8376 NFRU Intel Xeon E5-2667 130W

03T8373 NFRU Intel Xeon E5-2665 115W

03T8260 1 FRU 2GB PC3-12800E 1600MHz D

03T8261 1 FRU 4GB PC3-12800E 1600MHz D

03T8262 1 FRU 8GB PC3-12800E 1600MHz D

03T8408 1FRU 2GB ECC RDIMM PC3-10600

03T8409 1FRU 4GB ECC RDIMM PC3-10600

03T8410 1FRU 8GB ECC RDIMM PC3-10600

03T8411 1FRU 16GB ECC RDIMM PC3-10600

03T6748 1 FRU 32GB DDR3 ECC RDIMM PC3-

03T8387 N FRU Intel Xeon E5-1650 130W
