Lenovo E2110 Overview TV E 2017 User Manual Think Vision E21 10 20.7” Wide FHD TN Monitor Type 61B9

User Manual: Lenovo E2110 Overview ThinkVision E21-10 20.7” Wide FHD TN Monitor - Type 61B9 61B9-JAR1-WW

Open the PDF directly: View PDF .
Page Count: 1

Name

Bezel color

Type-model

Panel

Viewable image size

Max view area (W x H)

Native resolution

Aspect ratio

Pixel pitch (mm)

Dot/Pixel per Inch

Brightness

Contrast ratio

Pixel response time

Color gamut

Viewing angle at 10:1 CR

Stand

Bezel width

Dimensions (HxWxD)

Power supply

Weight

Limited warranty

Available date

VESA-compliant

Power management

Ergonomics

Emission standards

Environmental

Preset resolutions

Presets display modes

Viewing adjustments

Rotating screen

On screen display

Control features

USB hub

Multiple input

Monitor connectors

Signal cables

Mounting features

Security

Ship group

Lenovo ThinkVision E21

Lenovo

August 2017

Product Specifi cations Reference (PSREF)

Limited Warranty

See details at http://support.lenovo.com/en_US/guides-and-manuals/de-

tail.page?DocID=UM008281

Accessories

Kensington MicroSaver Cable Lock 73P2582

Kensington Twin Head Cable Lock 45K1620

See details at www.lenovo.com/support/monitoraccessories

See all monitors at www.lenovo.com/thinkvision

ThinkVision E21 Wide Monitor

Features

• Widescreen 20.7-inch monitor

• Supports 1920x1080 resolution

• Supports ThinkCentre Tiny Clamp Bracket

• Supports optional soundbar

• EPEAT Gold certifi ed

• Low Blue Light certifi cation

• Microsoft® Windows® 7 certifi ed

• Microsoft Windows 10 certifi ed

E21 Wide Flat Panel Monitor

Black

61B9JAR1US / 61B9JAT1EU

TFT-LCD, twisted nematic (TN), White LED backlight

20.7" (525.78mm) diagonal

18.03" x 10.14" (457.92mm x 257.58mm)

1920x1080

16:9

0.2385 x 0.2385 mm

106 dpi

250 nits or cd/m2 (typical)

1000:1 (typical)

5ms (typical)

72%

170° (+/- 85°) horizontal, 178° (+/- 89°) vertical

Tilt adjustable stand

Sides: 0.6" (15.3mm)

14.6" H x 19.31" W x 8.07" D;

370.9mm H x 490.5mm W x 204.9mm D

18 watts typical,

23 watts maximum,

<0.3 watts standby/suspend, universal,

integrated (no external brick-like power supply)

5.82 lb; 2.64 kg

3 year (includes backlight)

August 2017

VESA DDC2B/CI

ENERGY STAR® qualifi ed

ISO 9241-307

FCC Class B

TCO Displays 7.0, TCO Certifi ed Edge 2.0, WEEE,

RoHS, EPEATTM Gold rating

VGA: 640x350, 640x480, 720x400

SVGA: 800x600, 832x624

XGA: 1024x768, 1152x864

SXGA: 1280x1024

WXGA+: 1440x900

WSXGA+: 1680x1050

Full HD: 1920x1080

Standard presets: 22

Tilt: 22° back, -5° forward

None

On screen display with digital user controls (8 languages)

Direct access (buttons on front) for power, menu, input source select and brightness

None

Dual input (two different PCs attach to two different connectors; one PC shows image; select via button)

(1) VGA

15-pin D-shell,

analog,

blue

(2)

DisplayPort (1.2), digital, black, HDCP-compliant

(1) detachable, VGA

15-pin D-shell at each end, analog, 1.8 meter

Wall or desk mounting using the Extend Arm or third-party accessories, 100mm x 100mm mount

Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)

Monitor with stand, Safety and Warranty Information, 1.8 meter analog signal cable, 1.8 meter black power cord
