PN CRU ID Description

45N0242 1 Common Delta 90W 3pin

45N0246 1 Common Liteon 90W 3pin

45N0248 1 Common Liteon 90W 2pin

45N0250 1 Common Chicony 90W 3pin

45N0252 1 Common Chicony 90W 2pin

45N0254 1 Common Delta 65W 3pin

45N0256 1 Common Delta 65W 2pin

45N0258 1 Common Liteon 65W 3pin

45N0260 1 Common Liteon 65W 2pin

45N0262 1 Common Chicony 65W 3pin

45N0264 1 Common Chicony 65W 2pin

45N0326 1 Com Del B 65W S-Plug 2p <Primary>

45N0328 1 Com Lit B 65W S-Plug 2p <Secondary>

04W3763 2 CBT 2*2 Combo

04W3764 2 LTN 2*2 Combo

04W3765 2 Jackson Peak 1

04W3794 2 CBT 43142

04W3795 2 LTN 43142

04W3823 2 Ericsson N5321 MA

04X1074 N Power Button Sub Card14W

04X1075 N DC-IN RJ45 with BRK 14W

04X1076 N card reader and USB 14W

04X1917 N DC-IN bracket 14W

04X1139 N ANTENNA WLAN SET-14 AMP <Primary>

04X1140 N ANTENNA WLAN SET-14 ICT <Secondary>

04X1141 N ANTENNA WWAN/WLAN-14 AMP <Primary>

04X1142 N ANTENNA WWAN/WLAN-14 ICT <Secondary>

04W4118 1 RTC Battery

45N1043 1 SMB C01 SANYO 6cell 2.2Ah

45N1045 1 SMB C01 Simplo 6cell 2.2Ah

45N1047 1 SMB C01 Sony 6cell 2.2Ah

45N1049 1 SMB C01 LGC 6cell 2.2Ah

45N1053 1 SMB C01 Simplo 6cell 2.8Ah

45N1055 1 SMB C01 LGC 6cell 2.8Ah

04Y1247 N 720p HD camera w/MIC-CCY<Primary>

04Y1248 N 720p HD camera w/MIC-BIS<Secondary>

04Y1249 N 720p HD camera w/MIC-LTN<Secondary>

04X1133 1 14W Rubber Cap LCD

ADAPTERS

E431 List - MT 6277 Non-Touch

ANTENNAS

BATTERIES

CAMERAS

WIRELESS AND SUB-CARDS

CAPS

04X1918 1 14W Screw Mylar LCD(500)

91P9642 1 TP CAP set

04W4440 N Dual core i3-3120M

04X0935 N CPU Ivy Bridge i5-3340M

04Y1166 N i7-3632QM

04Y1313 N Dual core i5-3230M

04Y1314 N Dual core i3-3130M

04Y1315 N Pentium 2030M

04Y1316 N Celeron 1000M

04Y1365 N CPU Sandy Bridge i3-2348M

04Y1289 N 14" Planar HM77 Integ

04Y1290 N 14" Planar HM77 IntegW8P

04Y1291 N 14" Planar HM77 IntegW8S

04Y1292 N 14" Planar HM77 N14M-GL

04Y1293 N 14" Planar HM77 N14M-GLW8P

04Y1294 N 14" Planar HM77 N14M-GLW8S

04Y1295 N 14" Planar HM77 N14P-GV2

04Y1296 N 14" PlanarHM77 N14P-GV2W8P

04Y1297 N 14" PlanarHM77 N14P-GV2W8S

04X0945 1 SBLIO Rambo HLDS - Primary

04X0946 1 SBLIO Rambo PSN - Secondary

04X1135 N LCD Cover 14W Black Pl

04X1136 N LCD Cover 14W Red Pl

04X1147 N BaseCover 14W ROW N-TS

04X1148 N BaseCover 14W TW65W N-TS

04X1149 N BaseCover 14W TW90W N-TS

04X1934 N Base Cover 14W ROW Y-TS

04X1935 N BaseCover 14W TW65W Y-TS

04X1936 N BaseCover 14W TW90W Y-TS

04X4142 N connecter cover

04W3330 N CMI 14.0"HD A

04W3331 N LGD 14.0"HD+ A

04W3364 N CMI 14.0"HD A

04W3650 N AUO 14.0"HD A

04W3651 N AUO 14.0"HD A

04W3921 N AUO 14.0"HD+ A

04X3843 N LGD 14.0"HD A

04X4143 N 14.0"HD Gl Flat panel LGD

04Y1270 N 14.0"HD AG SEC<Secondary>

04Y1271 N 14.0"HD AG BOE<Secondary>

04Y1273 N 14.0"HD Glare SEC<Secondary>

04Y1274 N 14.0"HD Glare BOE<Secondary>

CPU'S

PLANARS

OPTICALS

COVERS

LCD'S

04X1137 N LCD Bezel 14W

04X1143 N 14W LCD Cable

04X1065 N Thermal Door w/Screw 14W

04X1066 N Mini Door w/ Screw 14W

04X0913 1 HDD 320G 5400rpm Toshiba - Primary

04X0914 1 HDD 320G 5400rpm Toshiba - Secondary

04X0915 1 HDD 320G 5400rpm HGST - Secondary

04X0916 1 HDD 500G 5400rpm WD - Primary

04X0917 1 HDD 500G 5400rpm Toshiba - Secondary

04X0918 1 HDD 500G 5400rpm Toshiba - Secondary

04X0919 1 HDD 500G 5400rpm HGST - Secondary

04X0920 1 HDD 1TB 5400rpm WD - Primary

04X0921 1 HDD 1TB 5400rpm HGST - Secondary

04X0922 1 HDD 1TB 5400rpm Toshiba - Secondary

04X0923 1 HDD 320G 7200rpm HGST - Primary

04X0924 1 HDD 320G 7200rpm Toshiba - Secondary

04X0925 1 HDD 320G 7200rpm Seagate - Secondary

04X0926 1 HDD 500G 7200rpm Toshiba - Primary

04X0927 1 HDD 500G 7200rpm HGST - Secondary

45K0676 1 2.5 5400RPM SATAII 1TB HDD FRU

45N8471 1 M.2 24GB LiteOn

04X0928 1 SSD 128G Samsung - Primary

04X0931 1 SSD 128G LiteOn - Secondary

04Y1366 N Int/dis Thermal AVC

04Y1367 N Intel UMV SV Thermal AVC<Primary>

04Y1368 N Intel Dis Thermal Delta

04Y1369 N Intel UMV Thermal Delta<Secondary>

04X1144 N Hinge 14W,(CJ)<Primary>

04Y2726 2 KBD USE CHY <Primary>

04Y2727 2 KBD CFA CHY <Primary>

04Y2728 2 KBD CFR CHY <Primary>

04Y2729 2 KBD LAS CHY <Primary>

04Y2730 2 KBD BRA CHY <Primary>

04Y2731 2 KBD ARA CHY <Primary>

04Y2732 2 KBD BEL CHY <Primary>

04Y2733 2 KBD BUL CHY <Primary>

04Y2734 2 KBD CZH CHY <Primary>

04Y2735 2 KBD DEN CHY <Primary>

04Y2736 2 KBD SPA CHY <Primary>

04Y2737 2 KBD FRA CHY <Primary>

HDD'S

THERMALS

HINGES

KEYBOARDS

mSATA DRIVES

SSD's

DOORS

04Y2738 2 KBD GER CHY <Primary>

04Y2739 2 KBD GRK CHY <Primary>

04Y2740 2 KBD HBW CHY <Primary>

04Y2741 2 KBD HGN CHY <Primary>

04Y2742 2 KBD ICE CHY <Primary>

04Y2743 2 KBD ITA CHY <Primary>

04Y2744 2 KBD KAZ CHY <Primary>

04Y2745 2 KBD NET CHY <Primary>

04Y2746 2 KBD NOR CHY <Primary>

04Y2747 2 KBD POL CHY <Primary>

04Y2748 2 KBD POR CHY <Primary>

04Y2749 2 KBD RUS CHY <Primary>

04Y2750 2 KBD SLK CHY <Primary>

04Y2751 2 KBD SCB CHY <Primary>

04Y2752 2 KBD SWE CHY <Primary>

04Y2753 2 KBD SWS CHY <Primary>

04Y2754 2 KBD TUR CHY <Primary>

04Y2755 2 KBD UKE CHY <Primary>

04Y2756 2 KBD USI CHY <Primary>

04Y2757 2 KBD JPN CHY <Primary>

04Y2758 2 KBD KOR CHY <Primary>

04Y2759 2 KBD TWN CHY <Primary>

04Y2760 2 KBD THA CHY <Primary>

04Y2761 2 KBD TUF CHY <Primary>

04Y2762 2 KBD IND CHY <Primary>

04Y2763 2 KBD USE LTN <Secondary>

04Y2764 2 KBD CFA LTN <Secondary>

04Y2765 2 KBD CFR LTN <Secondary>

04Y2766 2 KBD LAS LTN <Secondary>

04Y2767 2 KBD BRA LTN <Secondary>

04Y2768 2 KBD ARA LTN <Secondary>

04Y2769 2 KBD BEL LTN <Secondary>

04Y2770 2 KBD BUL LTN <Secondary>

04Y2771 2 KBD CZH LTN <Secondary>

04Y2772 2 KBD DEN LTN <Secondary>

04Y2773 2 KBD SPA LTN <Secondary>

04Y2774 2 KBD FRA LTN <Secondary>

04Y2775 2 KBD GER LTN <Secondary>

04Y2776 2 KBD GRK LTN <Secondary>

04Y2777 2 KBD HBW LTN <Secondary>

04Y2778 2 KBD HGN LTN <Secondary>

04Y2779 2 KBD ICE LTN <Secondary>

04Y2780 2 KBD ITA LTN <Secondary>

04Y2781 2 KBD KAZ LTN <Secondary>

04Y2782 2 KBD NET LTN <Secondary>

04Y2783 2 KBD NOR LTN <Secondary>

04Y2784 2 KBD POL LTN <Secondary>

04Y2785 2 KBD POR LTN <Secondary>

04Y2786 2 KBD RUS LTN <Secondary>

04Y2787 2 KBD SLK LTN <Secondary>

04Y2788 2 KBD SCB LTN <Secondary>

04Y2789 2 KBD SWE LTN <Secondary>

04Y2790 2 KBD SWS LTN <Secondary>

04Y2791 2 KBD TUR LTN <Secondary>

04Y2792 2 KBD UKE LTN <Secondary>

04Y2793 2 KBD USI LTN <Secondary>

04Y2794 2 KBD JPN LTN <Secondary>

04Y2795 2 KBD KOR LTN <Secondary>

04Y2796 2 KBD TWN LTN <Secondary>

04Y2797 2 KBD THA LTN <Secondary>

04Y2798 2 KBD TUF LTN <Secondary>

04Y2799 2 KBD IND LTN <Secondary>

42T5004 1 US/Canada-1.0M

42T5008 1 US/Canada-1.0M

42T5014 1 Japan-1.0M

42T5020 1 Argentina-1.0M

42T5029 1 Europe-1.0M

42T5035 1 UK-1.0M

42T5041 1 Denmark-1.0M

42T5044 1 SWS-1.0M

42T5047 1 Italy-1.0M

42T5050 1 ANZ-1.0M

42T5056 1 SA-1.0M

42T5062 1 Israel-1.0M

42T5065 1 China-1.0M

42T5071 1 Taiwan-1.0M

42T5077 1 Korea-1.0M

42T5083 1 India-1.0M

42T5180 1 Brazil-1.0M 2p

04X1063 N Palmrest 14W FPR Pl

04X1064 N Palmrest 14W W/O FPR Pl

03X6655 1 2GB DDR3L 1600 SODIMM

03X6656 1 4GB DDR3L 1600 SODIMM

03X6657 1 8GB DDR3L 1600 SODIMM

04X1078 N MIC Module

04Y9339 1 Win8PROx64 HB/EN

04Y9340 1 Win8PROx64 HU/EN

04Y9341 1 Win8PROx64 JP

04Y9342 1 Win8PROx64 KR/EN

LINE CORDS

MECHANICALS

MEMORY

MICROPHONE

RECOVERY MEDIA

04Y9343 1 Win8PROx64 PL

04Y9344 1 Win8PROx64 PO/EN

04Y9345 1 Win8PROx64 RO/EN

04Y9346 1 Win8PROx64 RU

04Y9347 1 Win8PROx64 SK/EN

04Y9348 1 Win8PROx64 SP

04Y9349 1 Win8PROx64 SR/EN

04Y9350 1 Win8PROx64 TR/EN

04Y9351 1 Win8PROx64 US

04Y9352 1 Win8PROx64 C&L EMEA

04Y9353 1 Win8PROx64 C&L HK/CS/EN

04Y9354 1 Win8PROx64 C&L Nordics

04Y9355 1 Win8PROx64 C&L SL/CR/EN

04Y9356 1 Win8PROx64 UD

04Y9357 1 Win8PROx64 UK

04Y9358 1 Win8SLx64 AR/EN

04Y9359 1 Win8SLx64 BR

04Y9360 1 Win8SLx64 FR

04Y9361 1 Win8SLx64 PO/EN

04Y9362 1 Win8SLx64 RU

04Y9363 1 Win8SLx64 SP

04Y9364 1 Win8SLx64 SR/EN

04Y9365 1 Win8SLx64 TR/EN

04Y9366 1 Win8SLx64 US

04Y9367 1 Win8x64 CT/EN

04Y9368 1 Win8x64 CZ/EN

04Y9369 1 Win8x64 FR

04Y9370 1 Win8x64 GK/EN

04Y9415 1 Win7PROx64 SP1 AR/EN

04Y9416 1 Win7PROx64 SP1 BR

04Y9417 1 Win7PROx64 SP1 CS

04Y9418 1 Win7PROx64 SP1 CT/EN

04Y9419 1 Win7PROx64 SP1 CZ/EN

04Y9420 1 Win7PROx64 SP1 FR

04Y9421 1 Win7PROx64 SP1 GK/EN

04Y9422 1 Win7PROx64 SP1 GR

04Y9423 1 Win7PROx64 SP1 HB/EN

04Y9424 1 Win7PROx64 SP1 HU/EN

04Y9425 1 Win7PROx64 SP1 JP

04Y9426 1 Win7PROx64 SP1 KR/EN

04Y9427 1 Win7PROx64 SP1 PL

04Y9428 1 Win7PROx64 SP1 PO/EN

04Y9429 1 Win7PROx64 SP1 RO/EN

04Y9430 1 Win7PROx64 SP1 RU

04Y9431 1 Win7PROx64 SP1 SK/EN

04Y9432 1 Win7PROx64 SP1 SP

04Y9433 1 Win7PROx64 SP1 SR/EN

04Y9434 1 Win7PROx64 SP1 TR/EN

04Y9435 1 Win7PROx64 SP1 US

04Y9436 1 Win7PROx64 SP1 C&L EMEA

04Y9437 1 Win7PROx64 SP1 C&L HK/CS

04Y9438 1 Win7PROx64 SP1 C&L Nordi

04Y9439 1 Win7PROx64 SP1 C&L SL/CR

04Y9440 1 Win7PROx64 SP1 UD

04Y9441 1 Win7HBx64 SP1 BR

04Y9442 1 Win7HBx64 SP1 CS

04Y9443 1 Win7HBx64 SP1 PO/EN

04Y9444 1 Win7HBx64 SP1 RU

04Y9445 1 Win7HBx64 SP1 SP

04Y9446 1 Win7HBx64 SP1 US

04Y9447 1 Win7HPx64 SP1 CS

04Y9448 1 Win7HPx64 SP1 CT/EN

04Y9449 1 Win7HPx64 SP1 JP

04Y9450 1 Win7HPx64 SP1 KR/EN

04Y9451 1 Win7HPx64 SP1 SP

04Y9452 1 Win7HPx64 SP1 US

04Y9453 1 Win7HPx64 SP1 C&L HK/CS/

04Y9455 1 Win8CNx64 CS

04Y9456 1 Win8PROx64 AR/EN

04Y9457 1 Win8PROx64 BR

04Y9458 1 Win8PROx64 CS

04Y9459 1 Win8PROx64 CT/EN

04Y9460 1 Win8PROx64 CZ/EN

04Y9461 1 Win8PROx64 FR

04Y9462 1 Win8PROx64 GK/EN

04Y9463 1 Win8PROx64 GR

04Y9496 1 Win8x64 GR

04Y9497 1 Win8x64 HB/EN

04Y9498 1 Win8x64 HU/EN

04Y9499 1 Win8x64 JP

04Y9500 1 Win8x64 KR/EN

04Y9501 1 Win8x64 PL

04Y9502 1 Win8x64 PO/EN

04Y9503 1 Win8x64 RO/EN

04Y9504 1 Win8x64 SK/EN

04Y9505 1 Win8x64 SP

04Y9506 1 Win8x64 US

04Y9507 1 Win8x64 C&L EMEA

04Y9508 1 Win8x64 C&L HK/CS/EN

04Y9509 1 Win8x64 C&L Nordics

04Y9510 1 Win8x64 C&L SL/CR/EN

04Y9511 1 Win8x64 UD

04Y9512 1 Win8x64 UK

MISC

03T6427 1 Adobe Acrobat X Standard

04X1134 N Screw Kit

04X1072 N Speaker Assembly
