FRU PN CRU ID Description
42T4417 1 Liteon65W20V3P
42T4419 1 Liteon65W20V2P
42T4429 1 Liteon90W20V3P
42T4431 1 Liteon90W20V2P
42T4439 1 Hipro90W20V2P
42T5282 1 Delta65W20V2p
42T5283 1 Delta65W20V3p
45N0068 1 Hipro90W20V3P
45N0080 1 BRAZIL65WEPA2P
45N0110 1 DELBRA65WEPA2P
45N0120 1 CHICONY 65W 3pin FRU
45N0122 1 CHICONY 65W 2pin FRU
45N0180 1 Delta EuP 65W 3pin FRU
45N0182 1 Delta EuP 65W 2pin FRU
45N0184 1 Liteon EuP 65W 3pin FRU
45N0186 1 Liteon EuP 65W 2pin FRU
45N0192 1 Chicony EuP 65W 3pin FRU
45N0194 1 Chicony EuP 65W 2pin FRU
45N0196 1 Delta EuP 90W 3pin FRU
45N0198 1 Delta EuP 90W 2pin FRU
45N0200 1 Liteon EuP 90W 3pin FRU
45N0202 1 Liteon EuP 90W 2pin FRU
E435 - MT 3256
AC ADAPTERS
45N0202 1 Liteon EuP 90W 2pin FRU
45N0208 1 Chicony EuP 90W 3pin FRU
45N0210 1 Chicony EuP 90W 2pin FRU
45N0212 1 Delta EuP 65W Brazil FRU
45N0214 1 Liteon EuP 65W Brazil FRU
60Y3195 2 FRU 6250 WiMax
60Y3247 2 FRU FXC 11WLAN
60Y3249 2 FRU LTN 11WLAN
60Y3257 2 FRU Gobi3 WWAN
60Y3297 2 FRU H5321w
04W4316 N FRU ANTENNA WLAN WNC RT
04W4317 N FRU ANTENNA WLAN YAGEO RT
04W4118 N RTC Battery
45N1043 1 SMB C01 SANYO 6cell 2.2Ah
45N1045 1 SMB C01 Simplo 6cell 2.2Ah
45N1049 1 SMB C01 LGC 6cell 2.2Ah
45N1051 1 SMB C01 SANYO 6cell 2.8Ah
45N1053 1 SMB C01 Simplo 6cell 2.8Ah
45N1055 1 SMB C01 LGC 6cell 2.8Ah
WIRELESS CARDS
ANTENNAS
BATTERIES
04W2668 N FRU HD CAMERA LEE/GLENN BSN
04W2669 N FRU HD CAMERA LEE/GLENN LTN
04W4065 N FRU 0.3M camera Camera(Bison)
04W4066 N FRU 0.3M camera Camera(Chicony)
04W4067 N FRU 0.3M camera Camera(Liteon)
63Y0248 N FRU CAMERA KD4/DS2/CM2/BL/CD
63Y0250 N FRU CAMERA KD4/DS2/CM2/BL/CD
04W0492 N FRU CPU i5-2520M 2.50GHz
04W0495 N FRU CPU i3-2310M 2.10GHz
04W1891 N CPU i3-2330M
04W1892 N CPU i3-2350M
04W1894 N CPU Pentium B940
04W1895 N CPU Pentium B950
04W3399 N CPU Celeron B800
04W3989 N FRU CPU Intel Core i3-3110M
04W4021 N FRU AMD Radeon HD 7470M 1GB
04W4093 N FRU CPU Intel Pentium B960
04W4094 N FRU CPU Intel i3-2370M
04W4095 N FRU CPU Intel i5-2450M
04W4096 N FRU CPU Intel Celeron B815
04W4097 N FRU CPU ASM Intel Core B970
04W4137 N FRU CPU Intel Core i5-3320M
04W4138 N FRU CPU Intel Core i5-3360M
04W4139 N FRU CPU Intel Core i7-3520M
CAMERAS
CPU'S AND PLANARS
04W4139 N FRU CPU Intel Core i7-3520M
04W4140 N FRU CPU Intel Core i5-3210M
04W4141 N FRU CPU Intel Core i7-3612QM
04W4320 N FRU CPU ASM AMD A10-4600M
04W4321 N FRU CPU ASM AMD A8-4500M
04W4322 N FRU CPU ASM AMD A6-4400M
04W4323 N FRU CPU ASM AMD A4-4300M
04W4420 N FRU CPU SandyBridge i3-2308
04W4421 N FRU CPU Intel Celeron B820
04W4422 N FRU CPU Dual Core B980M
04W4445 N Dual core i3-2328M
04W4125 N FRU RJ45 Sub Card 14W
04W4126 N FRU USB_Audio Sub Card 14W
04W4129 N FRU Power Button Sub Card 14W
04W4236 N FRU DC-in Jack 14W
04W4089 1 FRU SBD12L Rambo PLDS
04W4090 1 FRU SBD12L Rambo Optiarc
04W4091 1 FRU SBD12L Rambo PSN
04W4092 1 FRU SBD12L Rambo HLDS
SUBCARDS
CD-ROM/OPTICALS
COVERS
04W4156 N FRU Base Cover Asm 14W ROW
04W4158 N FRU Base Cover Asm 14W TW 65W
04W4160 N FRU Base Cover Asm 14W TW 90W
04W4162 N LCD Cover Kit 14W Black Pl
04W4163 N LCD Cover Kit 14W Red Pl
04W4164 N LCD Cover Kit 14W Black Al
04W4234 N FRU LCD Cover 14W Blue Pl
03T2887 1 Adobe PremiereElements 10
03T6427 1 FRU Adobe Acrobat X Standard
04T4056 1 FAP Win7PROx32 SP1 CS
04T4057 1 FAP Win7PROx32 SP1 EI
04T4058 1 FAP Win7PROx32 SP1 FR
04T4059 1 FAP Win7PROx32 SP1 JP
04T4060 1 FAP Win7PROx32 SP1 US
04T4061 1 FAP Win7PROx64 SP1 AR/EN
04T4062 1 FAP Win7PROx64 SP1 BR
04T4063 1 FAP Win7PROx64 SP1 CS
04T4064 1 FAP Win7PROx64 SP1 CT/EN
04T4065 1 FAP Win7PROx64 SP1 CZ /EN
04T4066 1 FAP Win7PROx64 SP1 EI
04T4067 1 FAP Win7PROx64 SP1 FR
04T4068 1 FAP Win7PROx64 SP1 GK/EN
04T4069 1 FAP Win7PROx64 SP1 GR
04T4070 1 FAP Win7PROx64 SP1 HB/EN
04T4071 1 FAP Win7PROx64 SP1 HU/EN
RECOVERY MEDIA
04T4071 1 FAP Win7PROx64 SP1 HU/EN
04T4072 1 FAP Win7PROx64 SP1 JP
04T4074 1 FAP Win7PROx64 SP1 PL
04T4075 1 FAP Win7PROx64 SP1 PO/EN
04T4076 1 FAP Win7PROx64 SP1 RO/EN
04T4077 1 FAP Win7PROx64 SP1 RU
04T4078 1 FAP Win7PROx64 SP1 SK/EN
04T4079 1 FAP Win7PROx64 SP1 SP
04T4080 1 FAP Win7PROx64 SP1 SR/EN
04T4081 1 FAP Win7PROx64 SP1 TR /EN
04T4082 1 FAP Win7PROx64 SP1 UD
04T4083 1 FAP Win7PROx64 SP1 US
04T4084 1 FAP Win7PROx64 SP1 C&L Nordi
04T4085 1 FAP Win7PROx64 SP1 C&L EMEA(
04T4086 1 FAP Win7PROx64 SP1 C&L Hong
04T4087 1 FAP Win7PROx64 SP1 C&L Croat
04T4088 1 FAP Win7HBx32 SP1 CS
04T4089 1 FAP Win7HBx32 SP1 US
04T4090 1 FAP Win7HBx64 SP1 AR/EN
04T4091 1 FAP Win7HBx64 SP1 BR
04T4092 1 FAP Win7HBx64 SP1 CS
04T4093 1 FAP Win7HBx64 SP1 EI
04T4094 1 FAP Win7HBx64 SP1 FR
04T4095 1 FAP Win7HBx64 SP1 PO/EN
04T4096 1 FAP Win7HBx64 SP1 RU
04T4097 1 FAP Win7HBx64 SP1 SP
04T4098 1 FAP Win7HBx64 SP1 SR/EN
04T4099 1 FAP Win7HBx64 SP1 TR /EN
04T4100 1 FAP Win7HBx64 SP1 US
04T4101 1 FAP Win7HPx32 SP1 CS
04T4102 1 FAP Win7HPx32 SP1 EI
04T4103 1 FAP Win7HPx32 SP1 US
04T4104 1 FAP Win7HPx64 SP1 AR/EN
04T4105 1 FAP Win7HPx64 SP1 BR
04T4106 1 FAP Win7HPx64 SP1 CS
04T4107 1 FAP Win7HPx64 SP1 CT/EN
04T4108 1 FAP Win7HPx64 SP1 CZ /EN
04T4109 1 FAP Win7HPx64 SP1 EI
04T4110 1 FAP Win7HPx64 SP1 FR
04T4111 1 FAP Win7HPx64 SP1 GK/EN
04T4112 1 FAP Win7HPx64 SP1 GR
04T4113 1 FAP Win7HPx64 SP1 HB/EN
04T4114 1 FAP Win7HPx64 SP1 HU/EN
04T4115 1 FAP Win7HPx64 SP1 JP
04T4117 1 FAP Win7HPx64 SP1 PL
04T4118 1 FAP Win7HPx64 SP1 PO/EN
04T4119 1 FAP Win7HPx64 SP1 RO/EN
04T4120 1 FAP Win7HPx64 SP1 RU
04T4120 1 FAP Win7HPx64 SP1 RU
04T4121 1 FAP Win7HPx64 SP1 SK/EN
04T4122 1 FAP Win7HPx64 SP1 SP
04T4123 1 FAP Win7HPx64 SP1 SR/EN
04T4124 1 FAP Win7HPx64 SP1 TR /EN
04T4125 1 FAP Win7HPx64 SP1 UD
04T4126 1 FAP Win7HPx64 SP1 US
04T4127 1 FAP Win7HPx64 SP1 C&L Nordic
04T4128 1 FAP Win7HPx64 SP1 C&L EMEA(N
04T4129 1 FAP Win7HPx64 SP1 C&L Hong K
04T4130 1 FAP Win7HPx64 SP1 C&L Croati
04T4131 1 FAP Win7StarterX32 SP1 AR/EN
04T4132 1 FAP Win7StarterX32 SP1 BR
04T4133 1 FAP Win7StarterX32 SP1 EI
04T4134 1 FAP Win7StarterX32 SP1 FR
04T4135 1 FAP Win7StarterX32 SP1 RU
04T4136 1 FAP Win7StarterX32 SP1 SP
04T4137 1 FAP Win7StarterX32 SP1 TR /E
04T4138 1 FAP Win7StarterX32 SP1 US
04T4139 1 FAP Win7PROx64 SP1 KR/EN
04T4140 1 FAP Win7HPx64 SP1 KR/EN
HDD'S
04W4070 1 FRU HDD 320G 5400rpm Toshiba
04W4071 1 FRU HDD 320G 5400rpm HGST
04W4072 1 FRU HDD 320G 5400rpm Seagate
04W4073 1 FRU HDD 500G 5400rpm WD
04W4075 1 FRU HDD 500G 5400rpm Toshiba
04W4076 1 FRU HDD 500G 5400rpm HGST
04W4077 1 FRU HDD 750G 5400rpm WD
04W4079 1 FRU HDD 750G 5400rpm HGST
04W4080 1 FRU HDD 1TB 5400rpm WD
04W4081 1 FRU HDD 1TB 5400rpm HGST
04W4082 1 FRU HDD 320G 7200rpm WD
04W4084 1 FRU HDD 320G 7200rpm HGST
04W4085 1 FRU HDD 320G 7200rpm Seagate
04W4086 1 FRU HDD 500G 7200rpm WD
04W4087 1 FRU HDD 500G 7200rpm Toshiba
04W4088 1 FRU HDD 500G 7200rpm HGST
03T8188 1 FRU 320GB 7200RPM SATA 2.5"
03T8189 1 FRU 500GB 7200RPM SATA 2.5"
54Y8372 1 FRU 320G 5400 RPM SATA 2.5"
54Y8373 1 FRU 500G 5400 RPM SATA 2.5"
54Y8375 1 FRU 750G 5400 RPM SATA 2.5"
45K0642 1 FRU 1T HDD
04W4306 N FRU Thermal Fan Delta
04W4307 N FRU Thermal Fan 14W/15W, PCC
04W4312 N FRU AMD discrete H/S Delta
THERMALS
04W4312 N FRU AMD discrete H/S Delta
04W4313 N FRU AMD discrete SV H/S FKW
04W2520 2 LEE/PERRIN-KBD USE
04W2521 2 LEE/PERRIN-KBD CFA
04W2522 2 LEE/PERRIN-KBD CFR
04W2523 2 LEE/PERRIN-KBD LAS
04W2524 2 LEE/PERRIN-KBD BRA
04W2525 2 LEE/PERRIN-KBD ARA
04W2526 2 LEE/PERRIN-KBD BEL
04W2527 2 LEE/PERRIN-KBD BUL
04W2528 2 LEE/PERRIN-KBD CZH
04W2529 2 LEE/PERRIN-KBD DEN
04W2530 2 LEE/PERRIN-KBD SPA
04W2531 2 LEE/PERRIN-KBD FRA
04W2532 2 LEE/PERRIN-KBD GER
04W2533 2 LEE/PERRIN-KBD GRK
04W2534 2 LEE/PERRIN-KBD HBW
04W2535 2 LEE/PERRIN-KBD HGN
04W2536 2 LEE/PERRIN-KBD ICE
04W2537 2 LEE/PERRIN-KBD ITA
04W2538 2 LEE/PERRIN-KBD KAZ
KEYBOARDS
04W2539 2 LEE/PERRIN-KBD NET
04W2540 2 LEE/PERRIN-KBD NOR
04W2541 2 LEE/PERRIN-KBD POL
04W2542 2 LEE/PERRIN-KBD POR
04W2543 2 LEE/PERRIN-KBD RUS
04W2544 2 LEE/PERRIN-KBD SLK
04W2545 2 LEE/PERRIN-KBD SCB
04W2546 2 LEE/PERRIN-KBD SWE
04W2547 2 LEE/PERRIN-KBD SWS
04W2548 2 LEE/PERRIN-KBD TUR
04W2549 2 LEE/PERRIN-KBD UKE
04W2550 2 LEE/PERRIN-KBD USI
04W2551 2 LEE/PERRIN-KBD JPN
04W2552 2 LEE/PERRIN-KBD KOR
04W2553 2 LEE/PERRIN-KBD TWN
04W2554 2 LEE/PERRIN-KBD THA
04W2555 2 LEE/PERRIN-KBD TUF
04W2556 2 LEE/PERRIN-KBD IND
04W2557 2 LEE/PERRIN-KBD USE
04W2558 2 LEE/PERRIN-KBD CFA
04W2559 2 LEE/PERRIN-KBD CFR
04W2560 2 LEE/PERRIN-KBD LAS
04W2561 2 LEE/PERRIN-KBD BRA
04W2562 2 LEE/PERRIN-KBD ARA
04W2563 2 LEE/PERRIN-KBD BEL
04W2564 2 LEE/PERRIN-KBD BUL
04W2564 2 LEE/PERRIN-KBD BUL
04W2565 2 LEE/PERRIN-KBD CZH
04W2566 2 LEE/PERRIN-KBD DEN
04W2567 2 LEE/PERRIN-KBD SPA
04W2568 2 LEE/PERRIN-KBD FRA
04W2569 2 LEE/PERRIN-KBD GER
04W2570 2 LEE/PERRIN-KBD GRK
04W2571 2 LEE/PERRIN-KBD HBW
04W2572 2 LEE/PERRIN-KBD HGN
04W2573 2 LEE/PERRIN-KBD ICE
04W2574 2 LEE/PERRIN-KBD ITA
04W2575 2 LEE/PERRIN-KBD KAZ
04W2576 2 LEE/PERRIN-KBD NET
04W2577 2 LEE/PERRIN-KBD NOR
04W2578 2 LEE/PERRIN-KBD POL
04W2579 2 LEE/PERRIN-KBD POR
04W2580 2 LEE/PERRIN-KBD RUS
04W2581 2 LEE/PERRIN-KBD SLK
04W2582 2 LEE/PERRIN-KBD SCB
04W2583 2 LEE/PERRIN-KBD SWE
04W2584 2 LEE/PERRIN-KBD SWS
04W2585 2 LEE/PERRIN-KBD TUR
04W2586 2 LEE/PERRIN-KBD UKE
04W2587 2 LEE/PERRIN-KBD USI
04W2588 2 LEE/PERRIN-KBD JPN
04W2589 2 LEE/PERRIN-KBD KOR
04W2590 2 LEE/PERRIN-KBD TWN
04W2591 2 LEE/PERRIN-KBD THA
04W2592 2 LEE/PERRIN-KBD TUF
04W2593 2 LEE/PERRIN-KBD IND
42T5004 1 US/Canada-1.0M
42T5008 1 US/Canada-1.0M
42T5014 1 Japan-1.0M
42T5020 1 Argentina-1.0M
42T5029 1 Europe-1.0M
42T5035 1 UK-1.0M
42T5041 1 Denmark-1.0M
42T5044 1 SWS-1.0M
42T5047 1 Italy-1.0M
42T5050 1 ANZ-1.0M
42T5056 1 SA-1.0M
42T5062 1 Israel-1.0M
42T5065 1 China-1.0M
42T5071 1 Taiwan-1.0M
42T5077 1 Korea-1.0M
42T5083 1 India-1.0M
42T5180 1 Brazil-1.0M 2p
LINE CORDS
MEMORY
42T5180 1 Brazil-1.0M 2p
03X6560 1 FRU-Lenovo 2GB PC3-12800 DDR3-1600MHz SoDIMM Memory
03X6561 1 FRU-Lenovo 4GB PC3-12800 DDR3-1600MHz SoDIMM Memory
03X6562 1 FRU-Lenovo 8GB PC3-12800 DDR3-1600MHz SoDIMM Memory
04W4006 N FRU 14.0" HD Glare LED(AUO)
04W4007 N FRU 14.0" HD Glare LED(LGD)
04W4008 N FRU 14.0" HD Glare LED(CMI)
04W4009 N FRU 14.0" HD AG LED(AUO)
04W4010 N FRU 14.0" HD AG LED(LGD)
04W4011 N FRU 14.0" HD AG LED(CMI)
04W4022 N FRU 14.0" HD AG LED(SEC)
04W4023 N FRU 14.0" HD Glare LED(SEC)
04W4173 N FRU Lee Screw Kit
04W4165 N Speaker ASM 14W
04W3789 N FRU Macheen SIM
04W3761 N FRU CBT 1*1 Combo
04W3762 N FRU LTN 1*1 Combo
04W3763 N FRU CBT 2*2 Combo
04W3764 N FRU LTN 2*2 Combo
MECHANICALS AND MISC
MEMORY
LCD'S
04W3765 N FRU Jackson Peak 1
04W3775 N FRU ATT 4G SIM
04W4099 1 FRU 14W Blank Bezel Fixed
04W4171 1 LCD Bezel 14W mainstream
04W4172 1 LCD Bezel 14W Retail
04W4166 N LCD Cable HD Dis 14W W/ MIC
04W4131 N Rubber Cap LCD Mainstream
04W4132 N Rubber Cap LCD Retail
04W4335 1 FRU 14W Rubber Cap LCD MS
04W4336 1 FRU 14W Rubber Cap LCD Ret
91P9642 1 FRU TP CAP set
04W4151 1 Thermal Door w/ Screw 14W
04W4152 1 Mini Door w/ Screw 14W
04W4153 N Hinge 14W, Sliver(KEM)
04W4154 N Hinge 14W, Sliver(Sinher)
04W4155 N Hinge 14W, Sliver(Jarlly)
04W4148 N Palmrest 14W FPR Al cover
04W4149 N Palmrest 14W FPR Pl cover
04W4150 N Palmrest 14W W/OFPR Pl cover
