Fru P/N Cru Id Description

00HM611 1 45W,20VDC,3P,WW,DEL

00HM612 1 45W,20VDC,2P,WW,DEL

00HM613 1 45W,20VDC,3P,WW,LTN

00HM614 1 45W,20VDC,2P,WW,LTN

00HM615 1 45W,20VDC,3P,WW,CHY

00HM616 1 45W,20VDC,2P,WW,CHY

00HM624 1 45W,20VDC,3P,WW,ACB

00HM625 1 45W,20VDC,2P,WW,ACB

00NY623 N WLAN KIT,HighTEK

00NY624 N WLAN KIT,SmartAPP

00NY625 N WWAN KIT,HighTEK

00NY486 1 Ext,6C,48Wh,LION,LGC

00NY487 1 Ext,6C,48Wh,LION,LGC

00NY488 1 Ext,6C,48Wh,LION,Pana

00NY489 1 Ext,6C,48Wh,LION,Pana

04W0010 1 Battery,RTC,Toshiba

04Y1784 1 RTC,CR2032,3V,Mitsubishi

00UR700 N Celeron,WIN,noAMT,TPM,LNV

00UR701 N Celeron,WIN,noAMT,noTPM,LNV

00UR702 N Celeron,NOK,noAMT,TPM,LNV

00UR703 N Celeron,NOK,noAMT,noTPM,LNV

00UR704 N i3-6100U,WIN,noAMT,TPM,LNV

00UR705 N i3-6100U,WIN,noAMT,noTPM,LNV

00UR706 N i3-6100U,NOK,noAMT,TPM,LNV

00UR707 N i3-6100U,NOK,noAMT,noTPM,LNV

00UR708 N i5-6200U,WIN,noAMT,TPM,LNV

00UR709 N i5-6200U,WIN,noAMT,noTPM,LNV

00UR710 N i5-6200U,NOK,noAMT,TPM,LNV

00UR711 N i5-6200U,NOK,noAMT,noTPM,LNV

00UR712 N i5-6300U,WIN,AMT,TPM,LNV

00UR713 N i5-6300U,WIN,AMT,noTPM,LNV

00UR714 N i5-6300U,NOK,AMT,TPM,LNV

00UR715 N i5-6300U,NOK,AMT,noTPM,LNV

00NY604 1 ODD blank bezel

00NY614 N DC-IN cable,LNV

00NY616 N Audio cable,FPC

00NY618 N eDP cable,LNV

00NY619 N ClickPad cable,FFC,LNV

00NY622 N Smart card,FFC

CABLES

ThinkPad L560 FRU BOM; MT: 20F1, 20F2

AC ADAPTERS

ANTENNAS

BATTERIES

PLANARS

BEZELS

00HN328 N Camera,720P,Front,MIC,WTB,Chny

00HN329 N Camera,720P,Front,MIC,WTB,Ltn

00HN330 N Camera,720P,Front,MIC,WTB,Bsn

00NY611 N Audio card,LNV

00NY627 N RJ45 card,LNV

00NY630 N USB card,LNV

00NY631 N ODD card with FFC

00NY632 N Power button card with FFC,LNV

00NY634 N Without Camera board

00NY635 N Lid sensor board

00HW553 N FRU for JAE Card Reader

00NY607 N Express card slot,Deren

00HT624 N INX 15.6” HD TN AG, slim 220nit

00HT919 N 15.6,FHD,AG,N-Touch,IPS,SDC,slim

00HT921 N 15.6,FHD,AG,N-Touch,IPS,LGD,slim

00HT987 N BOE,15.6'',HD,TN AG,3.8t,N-touch

00NY500 N 15.6",HD,grar,non-touch,220n

00UP056 N 15.6,HD,AG,N-Touch,TN,SDC

00NY528 N FAN,Delta

00NY529 N FAN,Sunon

00PA946 1 HDD,500G,7200,7mm,SEA,SATA3

00PA947 1 HDD,500G,7200,7mm,HGST,SATA3

00PA948 1 HDD,500G,7200,7mm,TOS,SATA3

00PA949 1 HDD,500G,7200,7mm,WD,SATA3

00PA950 1 HDD,1T,5400,7mm,HGST,SATA3

00PA951 1 HDD,1T,5400,7mm,WD,SATA3

01AW239 1 SSHD,500G,5400,7mm,Seagate,SATA

00NY598 N Hinge,L/R,Silver,JR,LNV

00NY599 N Hinge,L/R,Silver,LH,LNV

04T0752 1 JP,AntiTR,0.9M,2P,NON-LH,LTK

04T0753 1 JP,AntiTR,0.9M,2P,NON-LH,LUX

04T0754 1 TH,1M,3P,NON-LH,LUX

42T5004 1 US/CA,1M,3P,NON-LH,LGW

42T5008 1 US/CA,1M,2P,NON-LH,LGW

42T5020 1 AR,1M,2P,NON-LH,LGW

42T5029 1 EU,1M,3P,NON-LH,LGW

42T5035 1 GB,1M,3P,NON-LH,LGW

42T5041 1 DK,1M,3P,NON-LH,LGW

42T5044 1 CH,1M,3P,NON-LH,LGW

42T5047 1 IT,1M,3P,NON-LH,LGW

42T5050 1 AU,1M,3P,NON-LH,LGW

HINGES

LINE CORDS

CAMERAS

SUB CARDS

DISPLAYS

THERMALS

HDD'S

42T5056 1 ZA,1M,3P,NON-LH,LGW

42T5062 1 IL,1M,3P,NON-LH,LGW

42T5065 1 CN,1M,3P,NON-LH,LGW

42T5071 1 TW,1M,3P,NON-LH,LGW

42T5077 1 KR,1M,3P,NON-LH,LGW

42T5083 1 IN,1M,3P,NON-LH,LGW

42T5089 1 US/CA,1M,3P,NON-LH,VLX

42T5093 1 US/CA,1M,2P,NON-LH,VLX

42T5105 1 AR,1M,2P,NON-LH,VLX

42T5114 1 EU,1M,3P,NON-LH,VLX

42T5120 1 GB,1M,3P,NON-LH,VLX

42T5126 1 DK,1M,3P,NON-LH,VLX

42T5129 1 CH,1M,3P,NON-LH,VLX

42T5132 1 IT,1M,3P,NON-LH,VLX

42T5135 1 AU,1M,3P,NON-LH,VLX

42T5141 1 ZA,1M,3P,NON-LH,VLX

42T5147 1 IL,1M,3P,NON-LH,VLX

42T5150 1 CN,1M,3P,NON-LH,VLX

42T5156 1 TW,1M,3P,NON-LH,VLX

42T5162 1 KR,1M,3P,NON-LH,VLX

42T5180 1 BR,1M,2P,NON-LH,LGW

42T5183 1 BR,1M,2P,NON-LH,VLX

45N0129 1 US/CA,1M,3P,NON-LH,LUX

45N0130 1 US/CA,1M,2P,NON-LH,LUX

45N0131 1 CN,1M,3P,NON-LH,LUX

45N0377 1 CN,1M,3P,NON-LH,LTK

45N0379 1 DK,1M,3P,NON-LH,LTK

45N0380 1 CH,1M,3P,NON-LH,LTK

45N0382 1 IL,1M,3P,NON-LH,LTK

45N0383 1 US/CA,1M,3P,NON-LH,LTK

45N0384 1 GB,1M,3P,NON-LH,LTK

45N0385 1 IN,1M,3P,NON-LH,LTK

45N0386 1 IT,1M,3P,NON-LH,LTK

45N0387 1 KR,1M,3P,NON-LH,LTK

45N0388 1 AU,1M,3P,NON-LH,LTK

45N0389 1 TW,1M,3P,NON-LH,LTK

45N0391 1 ZA,1M,3P,NON-LH,LTK

45N0392 1 EU,1M,3P,NON-LH,LTK

45N0394 1 AR,1M,2P,NON-LH,LTK

45N0397 1 BR,1M,2P,NON-LH,LTK

45N0399 1 US/CA,1M,2P,NON-LH,LTK

45N0410 1 DK,1M,3P,NON-LH,LUX

45N0411 1 CH,1M,3P,NON-LH,LUX

45N0413 1 IL,1M,3P,NON-LH,LUX

45N0414 1 GB,1M,3P,NON-LH,LUX

45N0415 1 IN,1M,3P,NON-LH,LUX

45N0416 1 IT,1M,3P,NON-LH,LUX

45N0417 1 KR,1M,3P,NON-LH,LUX

45N0418 1 AU,1M,3P,NON-LH,LUX

45N0419 1 TW,1M,3P,NON-LH,LUX

45N0421 1 ZA,1M,3P,NON-LH,LUX

45N0422 1 EU,1M,3P,NON-LH,LUX

45N0423 1 AR,1M,2P,NON-LH,LUX

45N0426 1 BR,1M,2P,NON-LH,LUX

00JT971 N CS15W_3+2BCP,MYLR,BLK,ALPS

00NY583 1 Base cover ASM,LNV

00NY585 1 Door ASM,LNV

00NY587 N LCD Bezel ASM,LNV

00NY589 N LCD Rear cover ASM,LNV

00NY591 N KBD Bezel ASM for FPR,LNV

00NY593 N KBD Bezel ASM for noFPR,LNV

00NY596 N Saddle ASM,Mg,Left

00NY597 N Saddle ASM,Mg,Right

00NY602 N CAM subparts,Mylar,Rubber

00NY608 N Express card dummy,Plastic

00NY609 N Smart card dummy,Plastic

03X6655 1 2GB DDR3L 1600 SODIMM

03X6656 1 4GB DDR3L 1600 SODIMM

03X6657 1 8GB DDR3L 1600 SODIMM

00PA575 2 KBD,US,CHY

00PA576 2 KBD,CFA,CHY

00PA577 2 KBD,CFR,CHY

00PA578 2 KBD,LAS,CHY

00PA579 2 KBD,BR,CHY

00PA580 2 KBD,ARA,CHY

00PA581 2 KBD,BE,CHY

00PA582 2 KBD,BG,CHY

00PA583 2 KBD,CZ,CHY

00PA584 2 KBD,DK,CHY

00PA585 2 KBD,ES,CHY

00PA586 2 KBD,FR,CHY

00PA587 2 KBD,DE,CHY

00PA588 2 KBD,GR,CHY

00PA589 2 KBD,IL,CHY

00PA590 2 KBD,HU,CHY

00PA591 2 KBD,IS,CHY

00PA592 2 KBD,IT,CHY

00PA593 2 KBD,KZ,CHY

00PA594 2 KBD,NL,CHY

00PA595 2 KBD,NO,CHY

00PA596 2 KBD,PL,CHY

00PA597 2 KBD,PT,CHY

00PA598 2 KBD,RU,CHY

MECHANICALS

MEMORY DIMMS

KEYBOARDS

00PA599 2 KBD,SK,CHY

00PA600 2 KBD,SI,CHY

00PA601 2 KBD,SE,CHY

00PA602 2 KBD,CH,CHY

00PA603 2 KBD,TR,CHY

00PA604 2 KBD,GB,CHY

00PA605 2 KBD,USI,CHY

00PA606 2 KBD,JP,CHY

00PA607 2 KBD,KR,CHY

00PA608 2 KBD,TW,CHY

00PA609 2 KBD,TH,CHY

00PA610 2 KBD,TUF,CHY

00PA611 2 KBD,IN,CHY

00PA612 2 KBD,EE,CHY

00PA613 2 KBD,CFB,CHY

00PA614 2 KBD,LT,CHY

00PA616 2 KBD,US,LTN

00PA617 2 KBD,CFA,LTN

00PA618 2 KBD,CFR,LTN

00PA619 2 KBD,LAS,LTN

00PA620 2 KBD,BR,LTN

00PA621 2 KBD,ARA,LTN

00PA622 2 KBD,BE,LTN

00PA623 2 KBD,BG,LTN

00PA624 2 KBD,CZ,LTN

00PA625 2 KBD,DK,LTN

00PA626 2 KBD,ES,LTN

00PA627 2 KBD,FR,LTN

00PA628 2 KBD,DE,LTN

00PA629 2 KBD,GR,LTN

00PA630 2 KBD,IL,LTN

00PA631 2 KBD,HU,LTN

00PA632 2 KBD,IS,LTN

00PA633 2 KBD,IT,LTN

00PA634 2 KBD,KZ,LTN

00PA635 2 KBD,NL,LTN

00PA636 2 KBD,NO,LTN

00PA637 2 KBD,PL,LTN

00PA638 2 KBD,PT,LTN

00PA639 2 KBD,RU,LTN

00PA640 2 KBD,SK,LTN

00PA641 2 KBD,SI,LTN

00PA642 2 KBD,SE,LTN

00PA643 2 KBD,CH,LTN

00PA644 2 KBD,TR,LTN

00PA645 2 KBD,GB,LTN

00PA646 2 KBD,USI,LTN

00PA647 2 KBD,JP,LTN

00PA648 2 KBD,KR,LTN

00PA649 2 KBD,TW,LTN

00PA650 2 KBD,TH,LTN

00PA651 2 KBD,TUF,LTN

00PA652 2 KBD,IN,LTN

00PA653 2 KBD,EE,LTN

00PA654 2 KBD,CFB,LTN

00PA655 2 KBD,LT,LTN

01AV279 2 KBD,NDC,CHY

01AX353 2 KBD,NDC,LTN

00NY515 1 OPT_DRIVE,SMD,PLDS,9mm,x24,SB9

00NY516 1 OPT_DRIVE,SMD,HLDS,9mm,x24,SB9

00NY518 1 OPT_DRIVE,DVD,PLDS,SATA,9mm,x8

00NY519 1 OPT_DRIVE,DVD,HLDS,SATA,9mm,x8

00XE083 1 FAPWin7HBx64SP1CS

00XE084 1 FAPWin7PROx32SP1CS

00XE085 1 FAPWin7PROx32SP1FR

00XE086 1 FAPWin7PROx32SP1GR

00XE087 1 FAPWin7PROx32SP1HK/EN

00XE088 1 FAPWin7PROx32SP1JP

00XE089 1 FAPWin7PROx32SP1SP

00XE090 1 FAPWin7PROx32SP1US

00XE091 1 FAPWin7PROx32SP1C&LEMEA

00XE092 1 FAPWin7PROx32SP1C&LNordic

00XE093 1 FAPWin7PROx64SP1AR/EN

00XE094 1 FAPWin7PROx64SP1BR

00XE095 1 FAPWin7PROx64SP1CS

00XE096 1 FAPWin7PROx64SP1CT/EN

00XE097 1 FAPWin7PROx64SP1CZ/EN

00XE098 1 FAPWin7PROx64SP1FR

00XE099 1 FAPWin7PROx64SP1GK/EN

00XE100 1 FAPWin7PROx64SP1GR

00XE101 1 FAPWin7PROx64SP1HB/EN

00XE102 1 FAPWin7PROx64SP1HK/EN

00XE103 1 FAPWin7PROx64SP1HU/EN

00XE104 1 FAPWin7PROx64SP1JP

00XE105 1 FAPWin7PROx64SP1KR/EN

00XE106 1 FAPWin7PROx64SP1PL

00XE107 1 FAPWin7PROx64SP1PO/EN

00XE108 1 FAPWin7PROx64SP1RO/EN

00XE109 1 FAPWin7PROx64SP1RU

00XE110 1 FAPWin7PROx64SP1SK/EN

00XE111 1 FAPWin7PROx64SP1SP

00XE112 1 FAPWin7PROx64SP1SR/EN

00XE113 1 FAPWin7PROx64SP1TR/EN

00XE114 1 FAPWin7PROx64SP1US

RECOVERY MEDIA

OPTICAL DRIVES

00XE115 1 FAPWin7PROx64SP1C&LEMEA

00XE116 1 FAPWin7PROx64SP1C&LNordic

00XE117 1 FAPWin7PROx64SP1C&LSL/CR/

01AU736 1 Win10PROx64ModularAR/EN

01AU737 1 Win10PROx64ModularBR

01AU739 1 Win10PROx64ModularCT/EN

01AU740 1 Win10PROx64ModularCZ/EN

01AU741 1 Win10PROx64ModularFR

01AU742 1 Win10PROx64ModularGK/EN

01AU743 1 Win10PROx64ModularGR

01AU744 1 Win10PROx64ModularHB/EN

01AU745 1 Win10PROx64ModularHK/EN

01AU746 1 Win10PROx64ModularHU/EN

01AU747 1 Win10PROx64ModularJP

01AU748 1 Win10PROx64ModularKR/EN

01AU749 1 Win10PROx64ModularPL

01AU750 1 Win10PROx64ModularPO/EN

01AU751 1 Win10PROx64ModularRO/EN

01AU752 1 Win10PROx64ModularRU

01AU753 1 Win10PROx64ModularSK/EN

01AU754 1 Win10PROx64ModularSP

01AU755 1 Win10PROx64ModularSR/EN

01AU756 1 Win10PROx64ModularTR/EN

01AU757 1 Win10PROx64ModularUS

01AU758 1 Win10PROx64ModularC&LEMEA

01AU759 1 Win10PROx64ModularC&LNordi

01AU760 1 Win10PROx64ModularC&LSL/CR

00NY605 1 Screw Kit

00NY626 N Speaker ASM,L/R

00HT951 1 SSD,128G,2.5'',7mm,SATA,SAM

00UP008 1 SSD,512G,2.5",7mm,SATA3,SAM

00UP010 1 SSD,512G,2.5",7mm,SATA3,LTN

00UP013 1 SSD,256G,2.5'',7mm,SATA,SAM,OPAL

00UP014 1 SSD,256G,2.5'',7mm,SATA,TOS,OPAL

00UP016 1 SSD,256G,2.5'',7mm,SATA,LTN,OPAL

00UP017 1 SSD,240G,2.5'',7mm,SATA,Int,OPAL

00UP018 1 SSD,192G,2.5'',7mm,SATA3,SAM

00UP019 1 SSD,180G,2.5'',7mm,SATA,Int,OPAL

00UP046 1 SSD,512G,2.5'',7mm,SATA3,TOS

00JT478 2 Wireless,CMB,LTN,4356

00JT479 2 Wireless,CMB,FXN,4356

00JT491 2 Wireless,CMB,HW,ME906S

00JT513 2 Wireless,CMB,LTN,4356FCC

00JT515 2 Wireless,CMB,FXN,4356FCC

SCREW KIT

SPEAKERS

SSD'S

WIRELESS CARDS

00JT516 2 Wireless,CMB,LTN,4356Indo

00JT517 2 Wireless,CMB,FXN,4356Indo

00JT518 2 Wireless,CMB,LTN,4356agn

00JT519 2 Wireless,CMB,FXN,4356agn

00JT530 2 Wireless,CMB,IN,8260 MP Vpro

00JT531 2 Wireless,CMB,IN,8260MPVP IND

00JT532 2 Wireless,CMB,IN,8260 MP NV

00JT533 2 Wireless,CMB,IN,8260MPNV IND

00JT542 2 Wireless,CMB,SIE,EM7455
