Lenovo S400Z Aio Spec Sheet 201509 User Manual All In One (Lenovo) Type 10HB
1970-01-01
User Manual: Lenovo Lenovo S400Z Aio Spec Sheet 201509 S400z All-in-One (Lenovo) - Type 10HB Lenovo S400z All In One (Type 10HB)
Open the PDF directly: View PDF
.
Page Count: 2
This trendy 21.5" All-in-One computer is an affordable yet high-performance fusion of style
and substance. It’s a true productivity performer, available in either black or white, so it fits any
modern office, retail or reception area. Delivering great power savings along with security features
such as Smart USB Protection and Lenovo™ Bluetooth® Lock, the s400z is an ideal all-rounder.
Plus, Intel® Small Business Advantage and Intel® Ready Mode ensures user productivity for any
business need.
Stay stylish, productive and connected
A trendy All-in-One that’s built for business
Lenovo™ S400z All-in-One
WHY YOU SHOULD BUY THE LENOVO™ S400z ALL-IN-ONE
A 21.5" space-saver that raises the bar on
style. Available in either black or white, it suits
any office, retail or reception environment.
Stylish and trendy
Users are always connected with
Intel® Small Business Advantage and
Ready Mode – file sharing, chat,
remote access, and more.
Pure productivity
Smart USB Protection allows you to restrict
port access while allowing keyboard and
mouse inputs. Lenovo™ Bluetooth® Lock
means your desktop will automatically lock
once you step away.
Secure
A versatile space-saving All-in-One, S400z
also reduces power consumption, which
translates into real cost savings.
Space-saving and power-saving
THE LENOVO™ S400z ALL-IN-ONE IS BEST SUITED FOR
Small and medium-sized
businesses looking for a stylish,
space-saving solution for a
modern office environment.
1Small and medium-sized
businesses looking a solution
with modern office features
such as file sharing, remote
desktop capabilities and
remote file access.
2Small and medium-sized
businesses seeking a
stylish solution that is truly
power-efficient.
3
PERFORMANCE
Processor
Intel® Core™ i5-6200U Processor
Intel® Core™ i3-6100U Processor
Intel® Pentium® 4405U Processor
Operating System
Windows 10 Pro
Windows 10 Home for EM
Windows 10 Home for MM
Windows 7 Professional 64-bit (pre-intalled through
downgrade rights in Windows 10 Pro 64-bit)
Windows 7 Professional 32-bit (pre-intalled through
downgrade rights in Windows 10 Pro 64-bit)
DOS
Graphics
Intel® HD Graphics
Memory
Up to 8 GB (4 GB / 8 GB) DDR4
1866 MHz - SO-DIMM Slot
Webcam
720p HD with Microphone
Storage
2.5" 1 TB 5400 rpm / 500 GB 7200 rpm /
1 TB + 8 GB SSHD 5400 rpm / 120 GB / 192 GB
Audio
2.0 Speaker 2 x 3W
DESIGN
Display
All-in-One 21.5" FHD (1920 x 1080) 16:9,
Wide LED Backlit LCD, 250 nits
Dimensions (W x D x H)
With Frame Stand
(mm) : 535.2 x 63.7 x 382.7
(inches) : 21.07" x 2.51" x 15.07"
With Monitor Stand
(mm) : 535.2 x 227.9 x 435.7
(inches) : 21.07" x 8.97" x 17.15"
Weight
With Frame Stand
Starting at 14.1 lbs (6.4 kg)
With Monitor Stand
Starting at 16.1 lbs (7.3 kg)
Stand Offering
Frame
Monitor
Keyboard
Lenovo™ Ultraslim Plus Wireless Keyboard1
Lenovo™ Slim USB Keyboard
Physical Security
Kensington® Lock
SOFTWARE
Windows 10 Preloads
• Lenovo™ Business Vantage
• Lenovo™ Driver and Application
Installation
• Lenovo™ Solution Center
• Lenovo™ SHAREit
• Lenovo™ OneKey Recovery
• Lenovo™ Bluetooth® Lock
• McAfee® LiveSafe™
• Microsoft Office (trial)2
• Synacor®
• Lenovo™ Settings
• Lenovo™ Companion
Windows 7 Preloads
• Lenovo™ Business Vantage
• Lenovo™ Driver and Application
Installation
• Lenovo™ Solution Center
• Lenovo™ SHAREit
• Lenovo™ OneKey Recovery
• Lenovo™ Bluetooth® Lock
• McAfee® LiveSafe™
• Microsoft Office (trial)2
• Synacor®
GREEN CERTIFICATION
• ENERGY STAR® 6.1
CONNECTIVITY
Connectors
Front and Top
Camera and Microphone
Camera Switch Cover
Side
2 x USB 3.0 Ports
6-in-1 Card Reader
Headphone and Microphone Combo Port
Power-on
Rear
Power DC-in
LAN-in
3 x USB 2.0 Ports
1 x HDMI™-out Port
WLAN
WiFi 1 x 1 802.11 a/c + Bluetooth®
WiFi 2 x 2 802.11 a/c + Bluetooth®1
SPECIFICATIONS
©2015 Lenovo. All rights reserved. Availability: Offers, prices, specifications and availability may change without notice. Lenovo is not responsible for photographic or typographic errors. Warranty: For a copy of applicable warranties, write
to: Warranty Information, 500 Park Offices Drive, RTP, NC, 27709, Attn: Dept. ZPYA/B600. Lenovo makes no representation or warranty regarding third-party products or services. Trademarks: Lenovo, the Lenovo logo, Rescue and Recovery,
ThinkPad, ThinkCentre, ThinkStation, ThinkServer, ThinkVantage and ThinkVision are trademarks or registered trademarks of Lenovo. Microsoft, Windows and Vista are registered trademarks of Microsoft Corporation. Intel, the Intel logo, Intel Inside
logo, Intel Atom and Intel Atom Inside are trademarks of Intel Corporation in the U.S. and/or other countries. Other company, product and service names may be trademarks or service marks of others. Battery life (and recharge times) will vary based
on many factors including system settings and usage. Visit Lenovo.com/safecomputing periodically for the latest information on safe and effective computing.
WWW.LENOVO.COM
1 Optional.
2 Not available in Japan.
RECOMMENDED SERVICES
PRIORITY TECHNICAL SUPPORT 3
Makes your priority, our priority. 24x7 priority call
routing to advanced-level technicians, electronic
incident tracking, and escalation management
services.
WARRANTY UPGRADES - ON-SITE AND
NEXT BUSINESS DAY
Maximizes PC uptime and productivity by
providing convenient, fast repair service at your
place of business.
WARRANTY EXTENSIONS
(1 TO 5 YEARS TOTAL DURATION)
This fixed-term, fixed-cost service helps
accurately budget for PC expenses, protect
your valuable investment, and lower the cost of
ownership over time.
KEEP YOUR DRIVE
Retain your drive if it should happen to fail, giving
you the peace of mind to know that your valuable
data is secure.
Lenovo™ offers a comprehensive portfolio of services to support and protect your Lenovo™ S-series
investment. Succeed with substance, and let Lenovo’s Service support you all the way.
3 Not available in all regions.
Lenovo™ S400z All-in-One
OPTIONS & ACCESSORIES
Lenovo™ Universal
All-in-One Stand
Rotate, Tilt and Adjust
Lenovo™ In-ear
Headphone
Simple & Comfortable
Lenovo™
Ultraslim Wireless
Keyboard and
Mouse Combo
Fast & Fluid
Kensington®
Twin Head
Cable Lock
from Lenovo™
Ultra Protection
Against Thieves
